Fujitsu FTP-040HF Holder Series, FTP-040HS Holder Series Specifications

FTP-040HF/HS Holder Series

5

(0.197)

5(0.197)

35 (1.378)
50 (1.969)

40

(1.575)

65

(2.560)

30 (1881)

5

(0.197)

15

(0.591)

1.5
(0.060)

5(0.197)

¿ 12

(¿0.472)

¿70 (¿2.756)

¿ 12.7

(¿0.5)

7(0.039)

17

(0.670)

2.1(0.083)

*rebmuNtraPgniredrO

0200P020-PTF 100UP020-PTF 100P020-PTF

0200P030-PTF 100UP030-PTF

0200P040-PTF 100UP040-PTF 100P040-PTF

THERMAL PRINTER PAPER HOLDER

FTP-040HF/HS Holder Series

n FEATURES

• This is a paper holder for 2-inch, 3-inch and 4-inch thermal printers,

dedicated to specic thermo paper.

• With a structure having additional back tension, paper meadering

is prevented and winding feed is decreased.

• This molded product, which is light and compact, is easy to

handle.

n SPECIFIED PAPER

• This holder can be used for the following specied papers.

* Inner diameter of core: Ø 12.5±0.5 mm (0.492±0.02 inches);

outer diameter of roll:ø56mm (2.205 inches) maximum of
specied thermo paper.

n DIMENSIONS

Flange

Stand

Unit: mm (inches)

1

FTP-040HF/HS Holder Series

n ORDERING PART NUMBRS

Flange: FTP-040HF

Stand: FTP-040HS

Note: For normal use, one ange and one stand are required at the left and right respectively.

Fujitsu Components International Headquarter Ofces

Japan

Fujitsu Component Limited
Gotanda-Chuo Building

3-5, Higashigotanda 2-chome, Shinagawa-ku
Tokyo 141 8630, Japan
Tel: [phone]
Fax: [phone]
Email: [e-mail]
Web: www.fcl.fujitsu.com

North and South America

Fujitsu Components America, Inc.
250 E. Caribbean Drive
Sunnyvale, CA 94089 U.S.A.
Tel: [phone]
Fax: [phone]
Email: [e-mail]
Web: http://us.fujitsu.com/components/

Europe

Fujitsu Components Europe B.V.
Diamantlaan 25
2132 WV Hoofddorp

Netherlands

Tel: [phone]
Fax: [phone]
Email: [e-mail]
Web: emea.fujitsu.com/components/

Asia Pacic

Fujitsu Components Asia Ltd.
102E Pasir Panjang Road
#01-01 Citilink Warehouse Complex
Singapore 118529
Tel: [phone]
Fax: [phone]
Email: [e-mail]
Web: http://www.fujitsu.com/sg/services/micro/components/

©2009 Fujitsu Components America, Inc. All rights reserved. All trademarks or registered trademarks are the property of their respective
owners.

Fujitsu Components America or its afliates do not warrant that the content of datasheet is error free. In a continuing effort to improve our
products Fujitsu Components America, Inc. or its afliates reserve the right to change specications/datasheets without prior notice.
Rev. February 26, 2009.
