DATASHEET FUJITSU LIFEBOOK AH530 NOTEBOOK PC

Fujitsu recommends Windows 7.

®

®

TM

Windows

LI FE WIT HOUT WAL LS

DATASHEET

LIFEBOOK® AH530 NOTEBOOK PC

THE LATEST INTEL® CORE™ i3 PROCESSOR PROVIDES ALL THE
POWER NEEDED FOR YOUR FAVORITE APPS. WHEN COUPLED WITH
ITS MULTIMEDIA FEATURES AND SLEEK DESIGN THE LIFEBOOK
AH530 NOTEBOOK IS AN EXCELLENT CHOICE.

EASY TO OWN

There are two ways of approaching your notebook
investment. One is to purchase a low cost unit, but the
savings are generally eaten up by the maintenance
costs and the hassle of dealing with a poorly constructed
substandard notebook. On the other hand, high-quality
units may cost a little more, but the maintenance costs

are lower because the reliability is signicantly higher.

What if you could purchase a high-quality notebook at a
reasonable price? The best of both worlds just became a
reality with the affordable LIFEBOOK® AH530 notebook.

The old adage, “you get what you pay for” certainly applies
in the highly competitive world of notebook computers.
Now the upfront costs of top quality notebooks just
became less. Designed to the high standards of Fujitsu
(a leader in quality and reliability) the LIFEBOOK AH530
notebook provides you an easy way to cut costs without
cutting performance or reliability.

PERFORMANCE AND FEATURES

A smart choice for home and ofce, the Intel® Core™

i3 processor, with Intel® HD Graphics, delivers a
revolutionary new architecture for an unparalleled
computing experience. This processor comes equipped
with Intel HD Graphics, an advanced video engine that
delivers smooth, high-quality HD video playback, and
advanced 3D capabilities, providing an ideal graphics
solution for everyday computing.

The LIFEBOOK AH530, comes with a Dual-layer, Multi­format DVD writer optical drive. The Dual-layer DVD-R
or RW technology lets you record up to 8.5 GB of data
on a single disc. This nearly doubles the standard DVD
capacity of 4.7 GB.

The gesture enabled touchpad adds a whole new
dimension in going through documents. Scrolling,
zooming and sorting documents and images is actually
fun. With Intel HD graphics you will be treated to excellent

performance, sharp photos, high-denition video

playback.. The HDMI port allows you to play your DVDs

on compatible at screen televisions—bigger is always

better. The separate 10-key keypad is what having a full
size keyboard is all about. It makes crunching numbers
and in some cases gaming much faster and easier.

FLEXIBLE CONNECTIVITY

The built-in Ethernet LAN, provides a way to easily

connect to your ofce network and the Internet at home

or at work. For wireless connectivity, the Atheros XSPAN®
BGN (802.11BGN) wireless offers you a seamless and

exible way to stay in touch using transfer rates as high

as 300 Mbps. The webcam adds a fun (and very useful)
dimension to staying in touch with family, friends, and
business associates. With Bluetooth® technology you will
be able to wirelessly connect to other Bluetooth devices
such as cell phones, headphones, or speakers cutting
down on workspace clutter.

STABLE AND RELIABLE

The LIFEBOOK AH530 delivers all the key features that
have contributed to Fujitsu LIFEBOOK notebooks being
named some of the most reliable in the industry.

The new LIFEBOOK AH530 notebook features a solid
exterior, highly durable hinges, and a spill-resistant
keyboard.

POWERED BY THE LATEST INTEL 
PROCESSOR

OFFERED WITH GENUINE WINDOWS 
PREMIUM OPERATING SYSTEM

FAST AND LONG RANGE 802.11 BGN WIRELESS 
CONNECTIVITY

DUAL LAYER DVD-RW FOR PLAYING DVDS OR 

8.5 GB OF STORAGE

HDMI JACK LETS YOU EN JOY YOUR HIGH- 
DEFINITION ON LARGER HI-DEF TV SCREENS

STANDARD WEBCAM WITH DIGITAL 
MICROPHONE

MEMORYSTICK 
PORTS TO EASILY TRANSFER FILES

SPILL-RESISTANT, FULL-SIZE KEYBOARD 

®

, SD CARD SLOT, AND USB

®

CORE™ i3

®

7 HOME

Page 1 of 2 http://solutions.ca.fujitsu.com/products/notebooks/

DATASHEET FUJITSU LIFEBOOK AH530 NOTEBOOK PC

Fujitsu recommends Windows 7.

®

®

TM

Windows

LI FE WIT HOUT WAL LS

TECHNICAL DETAILS

SOFTWARE

OPERATING SYSTEMS: Genuine Windows® 7 Home Premium (64 bit)
SOFTWARE: Microsoft® Ofce Starter 20101, Adobe Acrobat Reader®, CyberLink YouCam, Norton Internet Security™ 20102 (60-day free trial),

Roxio Media Creator, CyberLink MakeDisc, CyberLink PowerDirector, CyberLink PowerDVD

KEY SPECIFICATIONS (listed specications are for the current model only and not for earlier models or revisions to this product.)

PROCESSOR: Intel® Core™ i3-350M Processor (2.26 GHz, 3 MB L3 cache, 1066 MHz FSB)
CHIPSET: Mobile Intel® HM55 Express Chipset
MEMORY: 4 GB (2 GB x 2): DDR3 1066 MHz SDRAM dual-channel memory
DISPLAY: 15.6” Crystal View WXGA HD Display
MAXIMUM RESOLUTION: Internal display: 1366 x 768, 16M colours

External monitor: 1920 x 1200, 16M colours
Simultaneous display: 1366 x 768, 16M colours

VIDEO: Intel® HD graphics
HARD DRIVE3: 500 GB SATA 5400 rpm hard drive
WEB CAM: 1.3 megapixel with digital microphone
OPTICAL DRIVE: Dual-layer Multi-format DVD writer
AUDIO: Realtek® codec ALC269 with 2-channel High-Denition (HD) audio

Stereo headphone/line-out jack
Stereo microphone/line-in jack

COMMUNICATION: Gigabit Ethernet LAN
WIRELESS COMMUNICATION: Atheros XSPAN® Wireless LAN (802.11 BGN)

Bluetooth® (V2.1) device for wireless personal area network communication
USER INTERFACE: 101-key standard spill-resistant keyboard with integrated 10-key keypad
Integrated touchpad pointing device
PORTS: One 15-pin D-SUB connector for VGA external monitor, one HDMI jack, 3 USB 2.0 (Universal Serial Bus), one DC In connector, one

LAN (RJ-45) connector, one stereo headphone/line-out jack, one stereo microphone/line-in jack

CARD SLOTS: ExpressCard® slot (34 mm/54 mm)
Combination Memory Stick® (MS/MS Pro) / Secure Digital (SD/SDHC) Card slot
BATTERY4: Lithium ion battery, rechargeable, 6-cell, (10.8 V, 4400 mAh)
Battery life up to 4 hours 10 minutes

AC ADAPTER: Auto-sensing AC100-240 V, Output: 19 V, 4.22 A, 80 W
DIMENSIONS/WEIGHT: Dimensions: 14.9” x 9.0” x 1.4” (1.51” with rubber boot)

Weight: 5.5 lbs with battery

OPERATING TEMPERATURE: 41°F to 95°F (ambient temperature), 20% to 85% relative humidity, non-condensing
NON-OPERATING TEMPERATURE: 5°F to 140°F, 8% to 85% relative humidity, non-condensing
KEY ACCESSORIES: Additional battery, additional AC adapter, carrying case

COMPLIANCE AND SERVICE INFORMATION

COMPLIANCE: FCC Part 15B Class B and FCC Part 15C; FCC Part 15E; IC ICES-003 Class B and RSS-210; UL-cUL Listed CE Marking (Not

supported when congured with the WLAN module); ExpressCard® (Pending); CB Generic Report; Energy Star Qualied

WARRANTY5: One year International Limited Warranty; 24/7 technical support; Fujitsu extended service plans available

FUJITSU CANADA, INC.

6975 Creditview Road, Unit 1
Mississauga, Ontario L5N 8E9, Canada
Telephone: [phone]
or 1 800 263 8716
Fax: [phone]
Web: solutions.ca.fujitsu.com

1000 Sherbrooke Street West, Suite 1400
Montréal, Quebéc H3A 3R2, Canada
Telephone: [phone]
or 1 800 663 0756
Fax: [phone]
Web: solutions.ca.fujitsu.com/fr

Microsoft1. ® Ofce Starter, (32 bit) includes
reduced functionality versions of Microsoft®
Word and Excel only, with advertising.

Preinstalled with a free 60-day trial version 2.
of Symantec Norton Internet Security 2010.
The 60-day trial version is activated upon
user’s acceptance of software license
agreement. After 60 days, the user must
purchase a subscription from Symantec to

download latest virus denitions.

One gigabyte (GB) = one billion bytes; 3.
accessible capacity will be less and
actual capacity depends on the operating
environment and formatting. Approximately

16.2GB of the hard drive is reserved for
system recovery software.

Battery life tested using MobileMark 2007 4.
and may include audio muted. Battery life will

vary depending on the product conguration,

product model, application loaded on the
product, power management settings on
the product, Operating System, and the
product features used by the customer. As
with all batteries, the maximum capacity
of the installed batteries will decrease with
time, usage, and how often the batteries are
charged by the user.

Service and warranty turnaround time may 5.
vary by country and product. International
warranty valid only for products purchased
in North, Central, and South America.

Fujitsu, the Fujitsu logo, and LIFEBOOK are
registered trademarks of Fujitsu Limited.
Intel, Intel Core Duo, the and the Intel logo
are trademarks or registered trademarks of
Intel Corporation or its subsidiaries in the
United States and other countries. Atheros
XSPAN is a registered trademark of Atheros
Communications, Inc. Microsoft, and Windows
are either registered trademarks or trademarks
of Microsoft Corporation in the United States
and/or other countries. Adobe Acrobat Reader
is a registered trademark of Adobe Systems,
Inc. The ExpressCard wordmark and logo
are owned by PCMCIA and any use of such
marks by Fujitsu Computers Corporation is
under license. ENERGY STAR is a registered
trademark of the U.S. Government. All other
trademarks mentioned herein are the property
of their respective owners. Product description
data represents Fujitsu design objectives and
is provided for comparative purposes; actual
results may vary based on a variety of factors.

Specications are subject to change without

notice.

©2010 Fujitsu Canada, Inc.
All rights reserved.
FCI-07.15.2010-E
