FUJITSU MEDIA DEVICE

DATA SHEET

ASSP

Mobile Communication Systems

DS04-23117-3E

Piezoelectric SAW BPF (700 to 1700 MHz)

F5/F6 Series (K2 type)

DESCRIPTION

■■■■

The F5CE/F6CE-K2 series of SAW band pass filters is a vailable in the 700-1700 MHz frequency range and e xhibit high stability by using single crystal Lithium Tantalate (LiTaO F5CE/F6CE-K2 series provides low insertion loss and wide passband width by taking advantage of Fujitsu’s unique “Ladder-type” design.

3) with a large electro-mechanical coefficient. The

The F5CE/F6CE-K2 series is housed in a small package (3.0 mm square) contributing to a significant savings in mounting space. This package is 40 % smaller than our F5CH-L2 series (3.8 mm square) . Typical applications for the F5CE/F6CE-K2 series include RF interstage filter in mobile communications systems. Standard devices are available for AMPS/TDMA/CDMA,GSM, EGSM and various Japanese standards. If higher attenuation is preferred, our F5CE-D2 series is also recommended.

FEATURES

■■■■

• Low insertion loss and high stopband attenuation

• Wide pass band width

• Compact and light package (3.0 mm sq.)

• External matching circuits are not required. (50 ohms I/O)

• Surface mount package (SMT)

• Standard devices are available for mobile communication standards (AMPS/CDMA/TDMA,GSM,EGSM,PDC800, J-CDMA, PDC 1.5 G)

PACKAGE

■■■■

F5/F6 Series (K2 type)

PIN ASSIGNMENT

■■■■

(BOTTOM VIEW)

1 2 3

654

PIN DESCRIPTION

■■■■

Pin No. Pin name Description

1 GND Ground Pin 2 IN Input Pin 3 GND Ground Pin 4 GND Ground Pin 5 OUT Output Pin 6 GND Ground Pin

ABSOLUTE MAXIMUM RATINGS

■■■■

Parameter Symbol

Operating temperature Ta −30 +85 °C Storage temperature Tstg −40 +100 °C Input level P Input DC voltage DC −5 +5V

WARNING: Piezoelectric devices can be permanently damaged by application of stress (voltage, current,

temperature, etc.) in excess of absolute maximum ratings. Do not exceed these ratings.

IN +23 dBm

Min. Max.

Rating

Unit

RECOMMENDED OPERATING CONDITIONS

■■■■

F5/F6 Series (K2 type)

Parameter Symbol

Operating temperature Ta −30 +85 °C

WARNING: The recommended operating conditions are required in order to ensure the normal operation of the

piezoelectric device. All of the device’s electrical characteristics are warranted when the device is operated within this range.

Always use piezoelectric devices within their recommended operating condition ranges. Operation outside these ranges may adversely affect reliability and could result in device failure.

No warranty is made with respect to uses, operating conditions, or combinations not represented on the data sheet. Users considering application outside the listed conditions are advised to contact their FUJITSU representatives beforehand.

STANDARD FREQUENCIES

■■■■

AMPS /TDMA /CDMA

System

Center freq.

(MHz)

836.5 25 25 FAR-F5CE-836M50-K225 Low loss type

836.5 25 30 FAR-F5CE-836M50-K230 High Att. type

836.5 25 36 FAR-F5CE-836M50-K236 Low loss type

836.5 25 89 FAR-F5CE-836M50-K289 High Att. type

881.5 25 35 FAR-F5CE-881M50-K235 Low loss type

881.5 25 10 FAR-F5CE-881M50-K210 High Att. type

B/W

(MHz)

Min. Max.

Part

symbol

Value

Unit

Part number Remarks

GSM

EGSM

PDC800 (20 MHz passband width standard)

J-CDMA

PDC1.5 G

Tx 902.5 25 13 FAR-F5CE-902M50-K213

947.5 25 33 FAR-F5CE-947M50-K233 Ultra low loss

Tx 950.0 20 01 FAR-F5CE-950M00-K201

Rx 851.0 38 12 FAR-F5CE-851M00-K212 Tx 1441.0 24 20 FAR-F6CE1G4410-K220 Rx 1489.0 24 21 FAR-F6CE1G4890-K221 Lo 1619.0 24 22 FAR-F6CE1G6190-K222

947.5 25 14 FAR-F5CE-947M50-K214 Low loss type

947.5 25 28 FAR-F5CE-947M50-K228 High Att. type

897.5 35 26 FAR-F5CE-897M50-K226

897.5 35 31 FAR-F5CE-897M50-K231 Low loss type

942.5 35 88 FAR-F5CE-942M50-K288 Low loss type

942.5 35 37 FAR-F5CE-942M50-K237

820.0 20 02 FAR-F5CE-820M00-K202 Low loss type

820.0 20 04 FAR-F5CE-820M00-K204 High Att. type

906.0 38 11 FAR-F5CE-906M00-K211 Low loss type

906.0 38 19 FAR-F5CE-906M00-K219

906.0 38 15 FAR-F5CE-906M00-K215 High Att. type

906.0 38 38 FAR-F5CE-906M00-K238

F5/F6 Series (K2 type)

ELECTRICAL CHARACTERISTICS

■■■■

1. AMPS/TDMA/CDMA (Tx) Low Loss type Part number : FAR-F5CE-836M50-K225

Parameter Conditions

Insertion loss 824 MHz to 849 MHz  2.0 2.5 dB Inband ripple 824 MHz to 849 MHz  0.9 1.5 dB

DC to 800 MHz 20 23  dB Absolute attenuation

Inband VSWR (Return loss)

869 MHz to 894 MHz 28 30  dB

894 MHz to 2000 MHz 22 25  dB

824 MHz to 849 MHz

Min. Typ. Max.



(6.2)

2. AMPS/TDMA/CDMA (Tx) High Attenuation type Part number : FAR-F5CE-836M50-K230

Value

2.6

(7.0)

2.9

()  (dB)

(Ta = −30 °C to +85 °C)

Unit Remarks

(Ta = −30 °C to +85 °C)

Parameter Conditions

Insertion loss 824 MHz to 849 MHz  2.7 3.5 dB Inband ripple 824 MHz to 849 MHz  1.0 2.0 dB

DC to 800 MHz 28 30  dB

Absolute attenuation

Inband VSWR (Return loss)

869 MHz to 894 MHz 30 43  dB

894 MHz to 1200 MHz 35 37  dB

1200 MHz to 2000 MHz 20 25  dB

824 MHz to 849 MHz

Min. Typ. Max.



(8.5)

Value

1.7

(11.7)

Unit Remarks

2.2

()  (dB)

3. AMPS/TDMA/CDMA (Tx) Low Loss type Part number : FAR-F5CE-836M50-K236

F5/F6 Series (K2 type)

(Ta = −30 °C to +85 °C)

Parameter Conditions

Insertion loss 824 MHz to 849 MHz  2.2 3.0 dB Inband ripple 824 MHz to 849 MHz  0.9 1.7 dB

DC to 800 MHz 25 26 2.2 dB

869 MHz to 894 MHz 30 35  dB Absolute attenuation

Inband VSWR (Return loss)

894 MHz to 1050 MHz 25 27  dB 1050 MHz to 1210 MHz 25 28  dB 1210 MHz to 2000 MHz 20 27  dB

824 MHz to 849 MHz

Min. Typ. Max.



(8.5)

Value

1.8

(10.9)

Unit Remarks

2.2

()  (dB)

4. AMPS/TDMA/CDMA (Tx) High Attenuation type Part number : FAR-F5CE-836M500-K289

Parameter Conditions

Min. Typ. Max.

Insertion loss 824 MHz to 849 MHz  3.0 3.8 dB Inband ripple 824 MHz to 849 MHz  1.0 2.0 dB

Value

Unit Remarks

(Ta = −30 °C to +85 °C)

Absolute attenuation

Inband VSWR (Return loss)

DC to 800 MHz 30 32  dB

869 MHz to 894 MHz 36 45  dB

894 MHz to 1050 MHz 38 43  dB 1050 MHz to 1210 MHz 35 37  dB 1210 MHz to 2000 MHz 20 28  dB

824 MHz to 849 MHz



(9.0)

2.0

(9.5)

2.1

()  (dB)

F5/F6 Series (K2 type)

5. AMPS/TDMA/CDMA (Rx) Low Loss type Part number : FAR-F5CE-881M50-K235

(Ta = −30 °C to +85 °C)

Parameter Conditions

Insertion loss 869 MHz to 894 MHz  2.0 3.0 dB Inband ripple 869 MHz to 894 MHz  0.8 1.8 dB

DC to 800 MHz 20 24  dB

824 MHz to 849 MHz 35 40  dB Absolute attenuation

Inband VSWR (Return loss)

939 MHz to 1049 MHz 28 31  dB 1049 MHz to 1200 MHz 28 32  dB 1200 MHz to 2000 MHz 25 30  dB

869 MHz to 894 MHz

Min. Typ. Max.



(9.5)

Value

1.7

(11.7)

Unit Remarks

2.0

()  (dB)

6. AMPS/TDMA/CDMA (Rx) High Attenuation type Part number : FAR-F5CE-881M50-K210

Parameter Conditions

Min. Typ. Max.

Insertion loss 869 MHz to 894 MHz  2.7 3.5 dB Inband ripple 869 MHz to 894 MHz  1.0 2.0 dB

Value

Unit Remarks

(Ta = −30 °C to +85 °C)

Absolute attenuation

Inband VSWR (Return loss)

DC to 849 MHz 30 32  dB

914 MHz to 939 MHz 20 38  dB

939 MHz to 1049 MHz 30 35  dB

1049 MHz to 2000 MHz 25 30  dB

869 MHz to 894 MHz



(7.4)

2.0

(9.5)

2.5

()  (dB)

7. GSM (Tx) Part number : FAR-F5CE-902M50-K213

F5/F6 Series (K2 type)

(Ta = −30 °C to +85 °C)

Parameter Conditions

Insertion loss 890 MHz to 915 MHz  3.0 3.5 dB Inband ripple 890 MHz to 915 MHz  1.0 2.0 dB

DC to 845 MHz 30 32  dB

845 MHz to 870 MHz 20 35  dB Absolute attenuation

Inband VSWR (Return loss)

935 MHz to 980 MHz 20 35  dB

980 MHz to 1200 MHz 35 37  dB

1200 MHz to 2000 MHz 30 35  dB

890 MHz to 915 MHz

Min. Typ. Max.



(7.4)

Value

2.0

(9.5)

Unit Remarks

2.5

()  (dB)

8. GSM (Rx) Ultra Low Loss type Part number : FAR-F5CE-947M50-K233

Parameter Conditions

Min. Typ. Max.

Insertion loss 935 MHz to 960 MHz  1.7 2.0 dB Inband ripple 935 MHz to 960 MHz  0.5 1.0 dB

Value

Unit Remarks

(Ta = −30 °C to +85 °C)

Absolute attenuation

Inband VSWR (Return loss)

DC to 905 MHz 17 19  dB

905 MHz to 915 MHz 15 25  dB

980 MHz to 1000 MHz 10 20  dB 1000 MHz to 1500 MHz 18 21  dB 1500 MHz to 2000 MHz 20 25  dB

935 MHz to 960 MHz



(7.4)

2.0

(9.5)

2.5

()  (dB)

F5/F6 Series (K2 type)

9. GSM (Rx) Low Loss type Part number : FAR-F5CE-947M50-K214

(Ta = −30 °C to +85 °C)

Parameter Conditions

Insertion loss 935 MHz to 960 MHz  2.7 3.0 dB Inband ripple 935 MHz to 960 MHz  1.0 1.5 dB

DC to 800 MHz 20 25  dB

890 MHz to 915 MHz 20 35  dB Absolute attenuation

Inband VSWR (Return loss)

980 MHz to 1025 MHz 20 25  dB 1025 MHz to 1600 MHz 27 32  dB 1600 MHz to 2000 MHz 25 30  dB

935 MHz to 960 MHz

Min. Typ. Max.



(7.4)

Value

2.0

(9.5)

Unit Remarks

2.5

()  (dB)

10. GSM (Rx) High Attenuation type Part number : FAR-F5CE-947M50-K228

Parameter Conditions

Min. Typ. Max.

Insertion loss 935 MHz to 960 MHz  3.0 3.5 dB Inband ripple 935 MHz to 960 MHz  1.0 2.0 dB

Value

Unit Remarks

(Ta = −30 °C to +85 °C)

Absolute attenuation

Inband VSWR (Return loss)

DC to 855 MHz 30 32  dB 855 MHz to 871 MHz 32 37  dB 890 MHz to 915 MHz 20 35  dB

980 MHz to 1025 MHz 20 35  dB 1025 MHz to 1105 MHz 33 37  dB 1105 MHz to 2000 MHz 30 37  dB 2000 MHz to 3000 MHz 25 30  dB

935 MHz to 960 MHz



(7.4)

2.0

(9.5)

2.5

()  (dB)

11. EGSM (Tx) Part number : FAR-F5CE-897M50-K226

F5/F6 Series (K2 type)

(Ta = −30 °C to +85 °C)

Parameter Conditions

Insertion loss 880 MHz to 915 MHz  2.5 3.5 dB Inband ripple 880 MHz to 915 MHz  1.0 2.0 dB

DC to 845 MHz 20 23  dB

Absolute attenuation

Inband VSWR (Return loss)

925 MHz to 935 MHz

935 MHz to 2000 MHz 25 30  dB

880 MHz to 915 MHz

Min. Typ. Max.

4.5



(6.8)

Value

7dBTa = +25 °C to +85 °C

8 

2.2

(8.5)

2.7

()  (dB)

Unit Remarks

dB Ta = −30 °C to +25 °C

12. EGSM (Tx) Low Loss type Part number : FAR-F5CE-897M50-K231

Parameter Conditions

Min. Typ. Max.

Insertion loss 880 MHz to 915 MHz  2.3 3.0 dB Inband ripple 880 MHz to 915 MHz  1.0 1.5 dB

DC to 800 MHz 17 19  dB

Value

Unit Remarks

(Ta = −30 °C to +85 °C)

Absolute attenuation

Inband VSWR (Return loss)

800 MHz to 860 MHz 15 25  dB 925 MHz to 935 MHz 4 dB 935 MHz to 960 MHz 20 25  dB

960 MHz to 1850 MHz 20 25  dB

1850 MHz to 3000 MHz 7 12  dB

880 MHz to 915 MHz



(8.5)

2.0

(9.5)

2.2

()  (dB)

F5/F6 Series (K2 type)

13. EGSM (Rx) Low Loss type Part number : FAR-F5CE-942M50-K288

(Ta = −30 °C to +85 °C)

Parameter Conditions

Insertion loss 925 MHz to 960 MHz  2.0

Inband ripple 925 MHz to 960 MHz  0.5 1.5 dB

DC to 905 MHz 17 18  dB

Absolute attenuation

Inband VSWR (Return loss)

905 MHz to 915 MHz

980 MHz to 1000 MHz 13 20  dB

1000 MHz to 2000 MHz 20 22  dB

925 MHz to 960 MHz

Min. Typ. Max.



(6.8)

Value

2.5 dB Ta = +25 °C ± 2 °C

2.7 dB Ta = −10 °C to +60 °C

3.0 dB Ta = −30 °C to +85 °C

8dBTa = −10 °C to +60 °C 5dBTa = −30 °C to +85 °C

16 

2.2

(8.5)

2.7

()  (dB)

Unit Remarks

dB Ta = +25 °C ± 2 °C

14. EGSM (Rx) Part number : FAR-F5CE-942M50-K237

F5/F6 Series (K2 type)

(Ta = −30 °C to +85 °C)

Parameter Conditions

Insertion loss 925 MHz to 960 MHz

Inband ripple 925 MHz to 960 MHz  1.3 1.9 dB

DC to 100 MHz 30 33  dB 100 MHz to 700 MHz 23 25  dB 700 MHz to 800 MHz 25 28  dB 800 MHz to 890 MHz 28 31  dB 890 MHz to 905 MHz 35 41  dB

Absolute attenuation

905 MHz to 915 MHz

980 MHz to 1000 MHz 20 33  dB 1000 MHz to 1200 MHz 30 32  dB 1200 MHz to 1550 MHz 30 35  dB 1550 MHz to 1950 MHz 25 31  dB 1950 MHz to 2800 MHz 20 27  dB 2800 MHz to 3000 MHz 15 23  dB

Min. Typ. Max.

 2.5 3.0 dB Ta = +10 °C to +60 °C 3.5 dB Ta = −30 °C to +85 °C

15 20  dB Ta = +25 °C ± 2 °C 11 20  dB Ta = +10 °C to +60 °C

Value

Unit Remarks

710 dB Ta = −30 °C to +85 °C

Inband VSWR (Return loss)

925 MHz to 960 MHz



(6.5)

2.6

(7.0)

2.8

()  (dB)

15. PDC800 (Tx) Part number : FAR-F5CE-950M00-K201

Parameter Conditions

Insertion loss 940 MHz to 960 MHz  3.0 3.5 dB Inband ripple 940 MHz to 960 MHz  1.5 2.0 dB

DC to 680 MHz 30 36  dB

680 MHz to 696 MHz 33 37  dB Absolute attenuation

Inband VSWR (Return loss)

810 MHz to 830 MHz 35 40  dB

1015 MHz to 1106 MHz 40 44  dB 1106 MHz to 2000 MHz 30 37  dB

940 MHz to 960 MHz

Min. Typ. Max.



(7.4)

Value

1.8

(10.9)

Unit Remarks

2.5

()  (dB)

(Ta = −30 °C to +85 °C)

F5/F6 Series (K2 type)

16. PDC800 (Rx) Low Loss type Part number : FAR-F5CE-820M00-K202

(Ta = −30 °C to +85 °C)

Parameter Conditions

Insertion loss 810 MHz to 830 MHz  2.1 2.5 dB Inband ripple 810 MHz to 830 MHz  1.4 1.9 dB

DC to 700 MHz 20 24  dB

Absolute attenuation

Inband VSWR (Return loss)

875 MHz to 1070 MHz 25 28  dB 1070 MHz to 1090 MHz 26 30  dB 1090 MHz to 2000 MHz 20 28  dB

810 MHz to 830 MHz

Min. Typ. Max.



(9.5)

Value

1.7

(11.7)

Unit Remarks

2.0

()  (dB)

17. PDC800 (Rx) High Attenuation type Part number : FAR-F5CE-820M00-K204

Parameter Conditions

Min. Typ. Max.

Insertion loss 810 MHz to 830 MHz  3.0 3.5 dB Inband ripple 810 MHz to 830 MHz  1.5 2.0 dB

DC to 130 MHz 35 41  dB

Value

Unit Remarks

(Ta = −30 °C to +85 °C)

Absolute attenuation

Inband VSWR (Return loss)

130 MHz to 760 MHz 30 34  dB 855 MHz to 875 MHz 35 38  dB

875 MHz to 1090 MHz 33 38  dB

1090 MHz to 2000 MHz 30 38  dB

810 MHz to 830 MHz



(7.4)

2.0

(9.5)

2.5

()  (dB)

18. J-CDMA (Tx) Low Loss type Part number : FAR-F5CE-906M00-K211

F5/F6 Series (K2 type)

(Ta = −30 °C to +85 °C)



Value

2.3

(8.1)

Unit Remarks

2.5

()  (dB)

Parameter Conditions

Insertion loss 887 MHz to 925 MHz  2.5 3.5 dB Inband ripple 887 MHz to 925 MHz  1.0 2.0 dB

DC to 720 MHz 17 20  dB 720 MHz to 800 MHz 20 22  dB 832 MHz to 870 MHz 28 30  dB

Absolute attenuation

Inband VSWR (Return loss)

940 MHz to 942 MHz 15 25  dB 942 MHz to 950 MHz 20 30  dB

950 MHz to 2000 MHz 20 23  dB

2000 MHz to 3000 MHz 15 17  dB

887 MHz to 925 MHz

Min. Typ. Max.

(7.4)

19. J-CDMA (Tx) Part number : FAR-F5CE-906M00-K219

Parameter Conditions

Min. Typ. Max.

Value

Unit Remarks

(Ta = −30 °C to +85 °C)

Insertion loss 887 MHz to 925 MHz  2.7 3.7 dB Inband ripple 887 MHz to 925 MHz  1.0 2.2 dB

DC to 720 MHz 20 22  dB 720 MHz to 800 MHz 20 23  dB 832 MHz to 870 MHz 32 33  dB

Absolute attenuation

Inband VSWR (Return loss)

940 MHz to 942 MHz 15 25  dB 942 MHz to 950 MHz 20 30  dB

950 MHz to 2000 MHz 20 23  dB

2000 MHz to 3000 MHz 15 17  dB

887 MHz to 925 MHz



(6.8)

2.2

(8.5)

2.7

()  (dB)

F5/F6 Series (K2 type)

20. J-CDMA (Tx) High Attenuation type Part number : FAR-F5CE-906M00-K215

(Ta = −30 °C to +85 °C)

Parameter Conditions

Insertion loss 887 MHz to 925 MHz  3.0 4.5 dB Inband ripple 887 MHz to 925 MHz  1.5 3.0 dB

DC to 720 MHz 25 26  dB 720 MHz to 800 MHz 25 30  dB 832 MHz to 870 MHz 30 35  dB

Absolute attenuation

Inband VSWR (Return loss)

940 MHz to 942 MHz 20 25  dB 942 MHz to 950 MHz 25 30  dB

950 MHz to 2000 MHz 20 25  dB

2000 MHz to 3000 MHz 15 20  dB

887 MHz to 925 MHz

Min. Typ. Max.



(5.1)

Value

3.0

(6.0)

Unit Remarks

3.5

()  (dB)

21. J-CDMA (Tx) Part number : FAR-F5CE-906M00-K238

Parameter Conditions

Min. Typ. Max.

Value

Unit Remarks

(Ta = −30 °C to +85 °C)

Insertion loss 887 MHz to 925 MHz  2.7 4.0 dB Inband ripple 887 MHz to 925 MHz  1.0 2.3 dB

DC to 720 MHz 23 25  dB 720 MHz to 800 MHz 25 27  dB 832 MHz to 870 MHz 37 40  dB

Absolute attenuation

Inband VSWR (Return loss)

940 MHz to 942 MHz 15 23  dB 942 MHz to 950 MHz 20 28  dB

950 MHz to 2000 MHz 25 30  dB

2000 MHz to 3000 MHz 20 25  dB

887 MHz to 925 MHz



(5.6)

2.2

(8.5)

3.2

()  (dB)

22. J-CDMA (Rx) Part number : FAR-F5CE-851M00-K212

F5/F6 Series (K2 type)

(Ta = −30 °C to +85 °C)

—

Value

2.7

(6.8)

Unit Remarks

3.0

()  (dB)

Parameter Conditions

Insertion loss 832 MHz to 870 MHz  2.5 3.5 dB Inband ripple 832 MHz to 870 MHz  1.0 2.0 dB

DC to 170 MHz 20 24  dB 170 MHz to 720 MHz 18 20  dB 720 MHz to 770 MHz 20 22  dB 770 MHz to 815 MHz 25 27  dB

Absolute attenuation

1100 MHz to 2000 MHz 20 24  dB

Inband VSWR (Return loss)

818 MHz 15 40  dB 887 MHz to 897 MHz 20 30  dB 897 MHz to 925 MHz 23 25  dB

925 MHz to 1100 MHz 22 24  dB

832 MHz to 870 MHz

Min. Typ. Max.

(6.0)

23. PDC1.5 G (Tx) High Attenuation type Part number : FAR-F6CE-1G4410-K220

(Ta = −30 °C to +85 °C)

Parameter Conditions

Insertion loss 1429 MHz to 1453 MHz  2.2 3.0 dB Inband ripple 1429 MHz to 1453 MHz  1.0 2.0 dB

DC to 1380 MHz 25 27  dB

Absolute attenuation

Inband VSWR (Return loss)

1477 MHz to 1501 MHz 10 18  dB 1501 MHz to 1900 MHz 30 32  dB 1900 MHz to 2906 MHz 18 28  dB

1429 MHz to 1453 MHz

Min. Typ. Max.



(7.4)

Value

2.1

(9.0)

Unit Remarks

2.5

()  (dB)

+ 34 hidden pages
