Fujitsu Docomo F-07F Instruction Manual

F-07F

INSTRUCTION MANUAL

’14.5

Thank you for purchasing "F-07F".
Before using F-07F, read this manual to ensure safe use and handling.

About manuals for F-07F

The operations of F-07F are described in this manual, "
terminal) and "Instruction manual (detailed version)" (in pdf format, Japanese only).

Instruction manual (this
manual)

"

使いかたガイド

(installed in FOMA
terminal)

"Instruction manual
(detailed version)" (in
pdf format)

･

In this "F-07F INSTRUCTION MANUAL", "F-07F" mobile terminal is usually referred to as "FOMA terminal".

･

The images or illustration used in this manual are examples. They may differ from the actual displays.

･

This manual provides explanations as Kisekae Tool set to "Aluminium" and Color theme set to "White".

･

In this manual, "authenticate" indicates the operating procedure for entering the terminal security code in 4­8 digits (

⇒

(Guide) "

P36).

This manual provides information about screens and operations of basic
functions.

This guide provides overviews and operations of frequently-used
functions. (In Japanese only)
In F-07F stand-by display,
method

This manual provides detailed information and operations of all the
functions. (In Japanese only)
<From a PC> This manual can be downloaded from NTT DOCOMO
website.
https://www.nttdocomo.co.jp/support/trouble/manual/download/
index.html

*

The URL and contents are subject to change without prior notice.

使いかたガイド

mef

Toole# GuideeSelect a search

(Guide)" (installed in FOMA

Basic package

F-07F (including warranty)

Instruction ManualBattery Pack F22 Desktop Holder F33Back Cover F82

Compatible options⇒P79

･

Unauthorized copying of parts of or this entire manual is prohibited.

･

The contents in this manual, URL and contents are subject to change without prior notice.

Contents

FOMA terminal .................................

Part names and functions ...............

Precautions (Always follow these

directions) .....................................

Before Using .....................................

Screen Explanation ..........................

Character Entry ................................

Call Telephone..................................

Mail....................................................

Phonebook........................................

i-mode/Full Browser ........................

i-channel............................................

Map/GPS...........................................

Camera ..............................................

1Seg...................................................

Music .................................................

Osaifu-Keitai .....................................

i-concier.............................................

Convenient tools ..............................

Support .............................................

Appendix...........................................

Index..................................................

2

Handling precautions.......................

3

Waterproofness/Dustproofness .....

6

24

Sound/Screen Setting .....................

27

Lock/Security ...................................

31

40
48
51

52
53
54

56

i-αppli ................................................

58

i-motion/Movie ................................

60

63

Data Management ...........................

64
65

73
80
88

15
20

32
36

61
62

69

Introduction

Basic
Operation

Connect

Search

Enjoy

More
Convenient

Others

1

FOMA terminal

･

F-07F supports W-CDMA, GSM/GPRS, Wireless
LAN System.

･

Because your FOMA terminal uses wireless
transmission, it may not function in locations

Introduction

where it is difficult for radio waves to penetrate,
such as tunnels, underground passages and
some buildings, in areas where radio waves are
weak, or out of service area. Even when you are
high up in a tall building or condominium and
nothing blocks your view outside, your FOMA
terminal may not be able to receive or transmit
signals. Also, communication may be
interrupted even when the signal meter on your
FOMA terminal indicates there are strong radio
waves and you are not moving (traveling).

･

Because your FOMA terminal uses radio waves
to communicate, it is possible that a third party
may attempt to tap your calls. However, the W­CDMA, GSM/GPRS automatically applies a
confidential communication function to all calls,
so even if a third party could somehow tap a call,
they only hear noise.

･

Your FOMA terminal encodes voice
communication as digital data. When you are
operating your FOMA terminal while moving to
a location subject to weaker radio wave
conditions, the transmitted digital data may not
be correctly decoded and as a result the
decoded voice may differ somewhat from the
actual voice.

･

Maintain a separate record of the data you
saved in your FOMA terminal. Note that
DOCOMO assumes no responsibility for any

2

loss of saved contents of data resulting from
malfunction, repair, changing of the model or
other handling of FOMA terminal.

･

You are recommended to save important data to
microSD card. Using DOCOMO keitai datalink,
you can transfer and save phonebook, mail,
schedule and other data to a PC.

･

The user hereby agrees that the user shall be
solely responsible for the result of the use of
SSL/TLS.
Neither DOCOMO nor the certifier as listed
herein makes any representation and warranty
as for the security in the use of SSL/TLS. If the
data should be erased, DOCOMO assumes no
responsibility for the loss of any data.
Certifier : VeriSign Japan K.K., Cybertrust
Japan Co., Ltd., GlobalSign K.K., RSA
Security Japan Ltd., SECOM Trust Systems
Co., Ltd., Comodo CA Ltd., Entrust, Inc., Go
Daddy, Inc.

･

This FOMA terminal supports FOMA Plus-Area
and FOMA HIGH-SPEED Area.

･

For commercially available option devices,
DOCOMO is not liable to any failures or the
malfunctions.

･

Display is manufactured by taking advantage of
highly advanced technology but some dots may
be always or never lit. Note that, this shows
characteristics of displays and not defects in the
terminals.

･

Note that if you delete the dictionary of the
terminal, it cannot be restored.

Part names and functions

Part names of F-07F and major functions assigned to each part are as follows.

Introduction

3

a

Earpiece

b

Display

c

Light sensor for sensing the ambient
lightness to adjust the brightness of the
display

d

Microphone

e

Bluetooth/Wireless LAN antenna is built-

Introduction

*

in

f

1Seg/FM transmitter antenna is built-in

g

Light that turns on when receiving a call or
while charging

h

Sub-display

i

GPS antenna is built-in

j

FOMA antenna is built-in

k

Camera

l

Infrared data port for infrared

*

*

communication or infrared remote control
function

m

Speaker

n

mark for placing over IC card reader for

Osaifu-Keitai and iC transmission

o

Light/Shooting light

p

Back cover

To access docomo mini UIM card slot and the
microSD card slot, remove the back cover and
the battery pack.

q

Charging jack

r

Back cover lever

s

Strap opening

t

External connection jack for charger,
earphone, etc.

*

Covering around the antenna by the hand may
affect the quality.

am

Display the menu

b a

Display the mail menu or switch text input

modes

1 second or more : Check new mail/message

c c

Display i-channel or return to the previous

screen

d n

Start voice call or switch to hands-free call

1 second or more : Perform quick voice activation

e 0

*

- 9 Enter phone number or characters, or

select menu item

1 second or more : Perform function assigned to
shortcut (eco mode ON/OFF is assigned to
default)

f *

Enter "*" or voiced/semi-voiced sound

1 second or more : Start/cancel Public mode (Drive
mode)

g T

Start/Exit i-Widget

1 second or more : Start 1Seg

h U

(Search key) Activate Quick search

1 second or more : Shabette-Kensaku

i k

(Multi-cursor key) Move the cursor

g

Perform an operation

u

Display phonebook, adjust sound volume

d

Display shortcuts list or adjust sound volume.

l

Display MyFACE, switch screen or display
Received calls when MyFACE usage setting is
"OFF"

r

Display MyFACE, switch screen or display
Redial number when MyFACE usage setting is
"OFF"

j C

Start the still camera shooting

k I

Display iMenu

1 second or more : Display i-αppli folder

5

by

4

l f

Exit a running function

2 seconds or more : Turn ON/OFF the FOMA
terminal

m #

Enter "#" or punctuation

1 second or more : Start/cancel Silent mode

n s

(Multitask key) Start another function during

a call or operation

1 second or more : Activate/cancel Privacy view

o ZSD

(Side key) Light sub-display, switch display

Z

(Side camera key) Activate movie shooting
1 second or more : Record video during 1Seg
watching

SD

Adjusting volume

S

Stop ring alert, alarm or vibrator
1 second or more : Activate Quick recorded
message while receiving a call

D

1 second or more : Check new mail/message

Connection of Stereo Earphone Set 01
(Optional) for external connection jack

* AC adapter uses a common jack.

Introduction

Stereo Earphone Set

AC adapter

01

External
connection jack

5

Precautions (Always follow these directions)

・

Before using your FOMA terminal, or when
necessary, read the precautions below to
ensure safe use and handling. After reading this
manual, keep it carefully.

Introduction

・

These precautions are intended to protect you
and others around you. Read and follow them
carefully to avoid injury, damage to the product
or damage to property.

・

The signs below differentiate between the
levels of danger that can occur if the product is
not used within the specified guidelines.

This sign denotes that
death or serious injury

DANGER

may directly result from
improper use.

This sign denotes that
death or serious injury

WARNING

may result from
improper use.

This sign denotes that
minor injury or damage

CAUTION

・

The symbols below show specific directions.

Don’t

No disassembly

to property may result
from improper use.

This symbol denotes that the action
is prohibited.

This symbol denotes that
disassembling the phone or its
components is not allowed.

6

No liquids

No wet hands

Unplug

■

Precautions contain the description below.

Handling FOMA terminal, battery pack, adapter,

desktop holder and docomo mini UIM card

(common) ...................................................................7

Handling FOMA terminal ..............................................8

Handling battery pack .................................................10

Handling adapter and desktop holder .......................11

Handling docomo mini UIM card...............................12

Handling mobile phones near electronic medical

equipment.................................................................13

Material list ..................................................................13

This symbol denotes that using the
phone or its components in a
bathroom or other highly humid area
is not allowed.

This symbol denotes that using the
phone or its components with wet
hands is not allowed.

This symbol denotes that an
instruction must be obeyed at all
times.

Do

This symbol denotes that the
equipment should be unplugged.

Handling FOMA terminal, battery
pack, adapter, desktop holder and
docomo mini UIM card (common)

DANGER

Do not use, store or leave the terminal
in hot places (e.g. by the fire, near a
heater, under a kotatsu, in direct

Don’t

sunlight, in a car in the hot sun).

May cause fire, burns or injuries.

Do not put the terminal into heating
cooking device such as microwave oven
or high-pressure container.

Don’t

May cause fire, burns, injuries, electric shock.

Do not disassemble or remodel the
equipment.

May cause fire, burns, injuries, electric shock.

No disassembly

Do not let the terminal get wet with
water, drinking water, urine of pet
animals, perspiration, etc.

No liquids

May cause fire, burns, injuries, electric shock.
For waterproofness, refer to the page.⇒P20

"Waterproofness/Dustproofness"

Keep liquid (water, drinking water,
urine of pet animals, perspiration, etc.)
from coming in contact with the

No liquids

charging jack or external connection
jack.

May cause fire, burns, injuries, electric shock.

Use optional devices specified by NTT
DOCOMO for your FOMA terminal.

May cause fire, burns, injuries, electric shock.

Do

WARNING

Do not throw the equipment or give
strong force or hard shock to it.

May cause fire, burns, injuries, electric shock.

Don’t

Keep conductive materials (metal
pieces, pencil lead, etc.) from coming in
contact with the charging jack or

Don’t

external connection jack. Do not put
those materials inside the terminal.

May cause fire, burns, injuries, electric shock.

Do not cover or wrap the terminal with
a blanket, etc while using or charging.

May cause fire or burns.

Don’t

Turn FOMA terminal OFF and stop
charging before entering a place such as
a gas station where flammable gases

Do

are generated.

The gas may catch fire.
When using Osaifu-Keitai in a place as a gas
station, turn OFF the terminal before using it.
(When IC card lock is activated, deactivate it
before turning OFF the terminal.)

If the equipment starts giving off a
strange smell, overheats, becomes
discolored or deformed during use,

Do

charging or in storage, immediately
perform the following operations.

･

Remove the power plug from the wall outlet
or cigarette lighter socket.

･

Turn FOMA terminal OFF.

･

Remove the battery pack from FOMA
terminal.

May cause fire, burns, injuries, electric shock.

Introduction

7

CAUTION

Do not leave the equipment on unstable
or sloping surfaces.

May cause injuries.

Don’t

Do not store the equipment in

Introduction

extremely humid, dusty or hot areas.

May cause fire, burns, electric shock.

Don’t

Children using the equipment should be
instructed in proper operation by an
adult. Do not allow them to use the

Do

equipment without adult supervision.

May cause injuries.

Store the equipment out of reach of
small children.

May be accidentally swallowed or cause

Do

injuries.

Be careful especially when using FOMA
terminal connected to the adapter
continuously for a long time.

Do

If you use i-αppli, a videophone call or 1Seg
watching while charging the battery for a long
time, FOMA terminal, battery pack and adapter
may be heated.
Directly touching a hot part for a long time, you
may have redness, itching or rash on your skin,
or it may result in low-temperature burns
depending on your constitution and/or health
condition.

Handling FOMA terminal

WARNING

Do not direct the infrared data port
toward your eye and transmit signals.

May cause harmful effect on eyes.

Don’t

Do not direct the infrared data port
toward home electric appliances etc.
equipped with infrared device when

Don’t

using infrared communication.

May cause an accident because of malfunction
of infrared device.

Do not turn on the light by getting the
lighting part closer to other person's
eyes. When shooting infants, keep at

Don’t

least 1 m away from the object.

May impair eyesight. And may cause accidents
like injury etc., by dazzling or astounding other
people.

Do not put foreign objects such as liquid
like water, metal pieces or burnable
things into docomo mini UIM card or

Don’t

microSD card slot.

May cause fire, burns, injuries, electric shock.

Do not turn on the light aiming directly
at the driver of the car etc.

May disturb driving and cause an accident.

Don’t

Turn FOMA terminal OFF in areas where
use is prohibited, such as in airplanes
and hospitals.

Do

May cause electronic equipment or electronic
medical equipment to fail or malfunction. If the
function which automatically turns the power
ON is set, cancel the setting before turning the
power OFF.
When using the phone in a medical facility, be
sure to observe the regulations of the facility.
If you do prohibited act such as using the phone
in an airplane, you will be punished according to
law.
If usage of FOMA terminal in an aircraft is
admitted by setting airplane mode, etc., use
FOMA terminal under the direction of the airline.

8

When you talk by setting handsfree or
ring alert is sounding, keep FOMA
terminal away from your ear.

Do

And, when connecting the earphone/
microphone etc. to the FOMA terminal
and play a game, music, etc. adjust the
volume moderately.

Too loud volume may cause a hearing loss.
And, if you cannot hear the sound around you
clearly, it may cause an accident.

If you have weak heart, be careful when
setting the Vibrate alert (vibration) or
alert volume setting.

Do

May cause harmful effect on heart.

When you use electronic medical
equipment, check with the equipment
manufacturer to determine how the

Do

device is affected by radio waves before
using.

May cause harmful effect on electronic medical
equipment etc.

Turn FOMA terminal OFF near high­precision electronic control equipment
or electronic equipment using low-

Do

power signals.

May cause the equipment to fail or malfunction.

* Examples of electronic equipment to avoid.

Hearing aids, implanted pacemakers or defibrillators,
other electronic medical equipment, fire alarms,
automatic doors and other automatic control
equipment.
Users wearing implanted pacemakers or defibrillators
or other electronic medical equipment should check
with the manufacturer or sales outlet about the effect
of radio frequencies on the equipment.

When the display or camera lens is
accidentally broken, be careful of
broken glass or exposed internal parts

Do

of FOMA terminal.

Surfaces of display and camera lens are made of
plastic panels and they are structured for the
glass not to scatter, however, if you mistakenly
touch broken or exposed parts, you may be
injured.

To sound the high-pitched alarm,
always keep FOMA terminal away from
your ears.

Do

May cause hearing defect.

CAUTION

Do not swing FOMA terminal by its
strap etc.

May cause accident such as injury to yourself or

Don’t

others by hitting.

Do not use damaged FOMA terminal.

May cause fire, burns, injuries, electric shock.

Don’t

When using the motion sensor, check
the safety around you, hold FOMA
terminal firmly, and do not shake it

Don’t

unnecessarily.

May cause accident such as injuries.

Introduction

9

If the display part is accidentally broken
and the substance of the display such as
the liquid crystal leaks out, do not make

Don’t

the substance contact with your skin of
face or hands.

May cause loss of sight or skin problems.

Introduction

If the substance of the display such as the liquid
crystal gets into your eyes or mouth, rinse it with
clean water and see a doctor immediately.
And, if the liquid adheres to skin or clothing, use
alcohol etc. to wipe it off, then wash with soap.

To use the terminal in car, check with
automobile manufacturer or dealer to
determine how the device is affected by

Do

radio waves before using.

In rare cases, using the phone in some vehicle
models can cause the vehicle's electronic
equipment to malfunction. In that case, stop
using the terminal immediately.

Mobile phones can give some users skin
problems such as itching, allergic
reactions or rashes. If you develop skin

Do

problems, stop using the phone
immediately, and see a doctor.

For materials of each parts⇒P13 "Material list"

When opening or closing FOMA
terminal, take care not to have your
fingers or strap caught by the terminal.

Do

May cause accident such as injuries.

When watching the display, take a
certain distance from the display in a
fully bright place.

Do

May reduce visual acuity.

Handling battery pack

■

Check that the battery type matches the type

displayed on the battery pack label.

Display Battery type

Li-ion 00 Li-ion battery

DANGER

Do not connect a wire or other metal
objects to the jack. And, do not carry or
store FOMA terminal with objects like a

Don’t

metal necklace.

May cause the battery pack to ignite, burst, heat
or leak.

Check the orientation of battery pack to
install it to FOMA terminal, and do not
try to force the battery pack onto FOMA

Don’t

terminal if you are having trouble
installing it.

May cause battery pack to ignite, burst, heat or
leak.

Do not throw the terminal into the fire
or apply heat.

May cause battery pack to ignite, burst, heat or

Don’t

leak.

Do not nail the terminal, hit with a
hammer or apply excessive force such
as step on it.

Don’t

May cause battery pack to ignite, burst, heat or
leak.

If the battery pack's fluid etc. contacts
eyes, immediately flush the eyes with
clean water and see a doctor right

Do

away. Do not rub the eyes.

May cause loss of sight.

10

WARNING

If the battery pack seems to have
abnormalities such as deformation or
scratches due to falling, never use it.

Don’t

May cause battery pack to ignite, burst, heat or
leak.

If the battery pack leaks or gives off a
strange smell, immediately remove it
from the vicinity of open flames.

Do

The vapors from leaking battery pack fluid may
ignite or explode.

Be careful not to let your pet bite the
battery pack.

May cause battery pack to ignite, burst, heat or

Do

leak.

CAUTION

Do not discard old battery packs
together with other garbage.

May cause igniting or environmental

Don’t

destruction. Tape the terminals of old battery
packs to insulate them, and then bring them into
a sales outlet such as docomo Shop. If your local
municipality has a battery recycling program,
dispose of them as provided for.

Do not use or charge a wet battery pack.

May cause battery pack to ignite, burst, heat or
leak.

Don’t

If fluid etc. leaks out from the battery
pack, do not make the fluid contact with
your skin of face or hands.

Do

May cause loss of sight or skin problems.
If the fluid etc. put into your eyes or mouth, or
contacts skin or clothes, immediately flush the
contacted area with clean water.
If the fluid put into the eyes or mouth,
immediately see a doctor after flushing.

Handling adapter and desktop
holder

WARNING

Do not use the adapter cord if it gets
damaged.

May cause fire, burns, electric shock.

Don’t

Do not use the AC adapter or desktop
holder in a bathroom or other highly
humid area.

Don’t

May cause fire, burns, electric shock.

Always use the DC adapter with a
negative-ground vehicle. Do not plug it
into a positive-ground vehicle.

Don’t

May cause fire, burns, electric shock.

When it starts to thunder, do not touch
adapter.

May cause electric shock.

Don’t

Do not short the charging jack while it is
connected to the outlet or cigarette
lighter socket. Do not touch the

Don’t

charging jack with a part of your body
such as your hand or finger.

May cause fire, burns, electric shock.

Do not place heavy objects on the
adapter cord.

May cause fire, burns, electric shock.

Don’t

When you insert and remove AC
adapter from power outlet, do not
contact a metal strap or other metal

Don’t

objects with the jack.

May cause fire, burns, electric shock.

Introduction

11

Introduction

Do not apply excessive force to the
FOMA terminal up, down, left or right
with the adapter attached.

Don’t

May cause fire, burns, injuries, electric shock.

Do not touch the adapter cord, charging
terminal, desktop holder or outlet with
wet hands.

No wet hands

May cause fire, burns, electric shock.

Only use with the specified power
source and voltage.
When charging FOMA terminal

Do

overseas, use AC Adapter for global use.

If incorrect voltage is used, this may cause fire,
burns or electric shock.
AC adapter : 100V AC
DC adapter : 12 or 24V DC (specific for negative

ground vehicle)

AC adapter for global use : Between 100V and

240V AC (Connect to the AC outlet for internal
household use)

If the DC adapter's fuse blows, replace it
only with the specified fuse.

May cause fire, burns, electric shock. For the

Do

specified fuse, see the instructions that come
with the DC adapter.

Wipe off any dust that accumulates on
the power plug.

May cause fire, burns, electric shock.

Do

When you connect the AC adapter to an
outlet, firmly connect to the outlet.

May cause fire, burns, electric shock.

Do

When you disconnect the power plug
from the outlet or cigarette lighter
socket, do not pull the adapter cord

Do

with excessive force. Instead, hold the
adapter to disconnect.

May cause fire, burns, electric shock.

Remove or insert the adapter to the
FOMA terminal evenly without applying
excessive force.

Do

May cause fire, burns, injuries, electric shock.

Always remove the power plug from
the outlet or cigarette lighter when not
using the adapter for an extended

Unplug

period.

May cause fire, burns, electric shock.

Immediately remove the power plug
from the outlet or cigarette lighter
socket if water or other fluids get into

Unplug

the adapter.

May cause fire, burns, electric shock.

Always remove the power plug from
the cigarette lighter socket when
cleaning the equipment.

Unplug

May cause fire, burns, electric shock.

Handling docomo mini UIM card

CAUTION

Be careful of the cut surface when
handling docomo mini UIM card.

May cause injuries.

Do

12

Handling mobile phones near
electronic medical equipment

WARNING

Wearers of electronic medical
equipment such as implanted
pacemakers or defibrillators must carry

Do

and use FOMA terminal at least 15cm
away from the implanted device.

FOMA terminal's signals may affect the
performance of electronic medical equipment.

When electronic medical equipment
other than implanted pacemakers or
defibrillators are in use outside of

Do

medical facilities (such as in home care
settings), check with the device
manufacturer to determine how the
device is affected by electrical signals.

FOMA terminal's signals may affect the
performance of electronic medical equipment.

When you are in a crowd etc. and you
have difficulties to keep a distance of 15
cm or more from others, turn the

Do

airplane mode on or power off the
FOMA terminal not to transmit signals.

There may be wearers of medical equipment
such as implanted pacemakers or defibrillators
around you. FOMA terminal's signals may affect
the performance of electronic medical
equipment.

When using the FOMA terminal in a
medical facility, be sure to observe the
regulations of the facility.

Do

Material list

Part Material

Exterior
case

Case pad Urethane

Display panel High-intensity

Back panel Acrylate

Camera lens, camera
panel

Light lens part Acrylate resin Engraving

Side keys PC resin

Keypad Urethane

Hinges PC resin UV hard

Movable part
Sub-Display

Movable
part Display

Fixed part
Keypad

Fixed part
Battery

Hinge section
Movable side

Hinge section
Fixed side

Back cover PC+ABS resin

Back cover
plate

Back cover
lock lever

Back cover
lock plate

PC+GF resin

PA-GF resin

PA-GF resin

PC+ABS resin

PC+ABS resin

PC+ABS resin

PC sheet,
silicon rubber

POM resin Engraving

Stainless steel None

resin

acrylate resin

resin+PC resin

Acrylate resin

acrylate resin

Surface

treatment

UV hard
coating

UV hard
coating

UV hard
coating

UV hard
coating

UV hard
coating

UV hard
coating

UV hard
coating

None

None

UV hard
coating

UV hard
coating

UV hard
coating

UV hard
coating

UV hard
coating

coating

Introduction

13

Part Material

External
connection
jack cap

Introduction

External connection jack Stainless steel Tin plating

Battery
contacts

Screw (battery install
recess)

Battery
install
recess face

Battery Pack
F22

Charging
jack

Body PC+ABS resin

Flexure Elastomer

Water stop PC resin None

Tabs PC resin None

O ring Silicon rubber None

Battery
contacts
connector

Battery
contacts

Circuit
board

Inscription
sticker

Battery pack PC resin None

Contacts Beryllium

Contacts Stainless steel Gold plating

Attaching
holder
section

resin

PPS resin None

Beryllium
copper

Stainless steel None

Glass epoxy Solder resist/

PET None

copper

LCP resin None

Surface

treatment

UV hard
coating

None

Gold plating
(base : Ni-Pd
plating)

Gold plating

Gold plating

■

Desktop Holder F33

Part Material

Exterior
case

Charging
jack

Rubber part Urethane

Upper case ABS resin None

Lower case ABS resin None

Front hook POM resin None

Side hook POM resin None

Contacts
lever

Contacts Phosphor

POM resin None

bronze

foam

Surface

treatment

Gold plating

None

14

Handling precautions

General

・

F-07F is waterproof/dustproof, however, do not allow
water to seep into FOMA terminal and do not allow
accessories or optional devices to get wet or let dust
attach.

- Battery pack, adapter, desktop holder, docomo mini
UIM card are not waterproof/dustproof. Do not use in a
bathroom or other highly humid area or do not let rain
attached. Or putting the terminal on your body,
humidity of sweat may cause internal corrosion and
malfunction. Note that malfunctions, which are
determined to be caused by water as result of
inspections, are not covered by the warranty. Since
these conditions are outside the scope of the warranty,
a repair, if at all possible, is charged.

・

Clean FOMA terminal with a dry soft cloth (such as a
cloth for eyeglasses).

- Rubbing it roughly with a dry cloth may scratch the
display.

- Drops of water or dirt left on the display may cause
stains.

- If FOMA terminal is wiped with alcohol, paint thinner,
benzine or detergent, the printing may disappear or
color may fade.

・

Clean the jack occasionally with a dry cotton swab
etc.

- If the jack is soiled, connection gets worse and it may
cause power to be turned off or insufficient battery
charge, so clean the jack with a dry cotton swab etc.
Also, be careful never to damage the jack when
cleaning it.

・

Do not place FOMA terminal near an air-conditioner
outlet.

- The rapid change in temperature may cause
condensation, causing internal corrosion and
malfunction.

・

When using, be careful not to subject excessive force
to FOMA terminal or the battery.

- If FOMA terminal is crammed into a brimming bag or
placed in a pocket and sat on, display, internal PCBs or
battery pack may be damaged or malfunction. And, if
external devices are plugged into the external
connection jack (earphone/microphone jack), the
breakage of the connector or malfunction may result.

・

Do not rub or scrape the display with a metal piece
etc.

- May scratch the display, causing malfunction or
damage.

・

Carefully read the separate instructions that come
with optional devices.

FOMA terminal

・

Avoid extreme temperature.

- Use FOMA terminal where the temperature ranges
between 5 and 40℃ (limited to the temporary use in a
bathroom etc. when temperature is above 36℃) and

humidity ranges between 45 and 85%.

・

FOMA terminal may affect land-line phones, TVs or
radios in use nearby, so use it as far as possible from
these appliances.

・

Maintain a separate record of the data you saved in
your FOMA terminal.

- If the data is deleted, DOCOMO assumes no
responsibility for the loss of any data.

・

Do not drop FOMA terminal or subject it to shocks.

- May cause malfunction or damage.

・

Do not plug external devices into the external
connection jack (earphone/microphone jack) at a
slant, or do not pull it forcibly while it is plugged.

- May cause malfunction or damage.

・

Do not close FOMA terminal with the strap etc. held
inside.

- May cause malfunction or damage.

・

It is normal for FOMA terminal to become warm
during use or charging. Continue to use it.

Introduction

15

・

Do not leave FOMA terminal with the camera in areas
under strong direct sunlight.

- May cause discoloring or burn-in of elements.

・

Use FOMA terminal with the external connection jack
cap closed.

- Dust and/or water brought into FOMA terminal cause
troubles.

・

Do not use FOMA terminal with the back cover
removed.

Introduction

- May cause removal of battery pack, malfunction or
damage.

・

Do not put extreme thick sticker on the display or
keypad face.

- May cause malfunction, damage or erroneous
operation.

・

While microSD card is being used, do not take the
card out and do not turn off FOMA terminal.

- May cause data loss or malfunction.

・

Do not bring magnetic cards etc. close to FOMA
terminal nor clip it by FOMA terminal.

- Magnetic data in cash cards, credit cards, telephone
cards, floppy disks, etc. may be erased.

・

Do not bring magnetized objects close to FOMA
terminal.

- Bringing strong magnetism close may cause a
malfunction.

16

Battery pack

・

The battery pack is a consumable part.

- Replace the battery pack if FOMA terminal has
extremely short operation time on a full charge,
though it may vary by operating conditions. Purchase
a new battery pack of the specified type.

・

Charge the battery in an area within the proper
ambient temperature range (5-35

・

The operation time provided by the battery pack
varies by the operating environment and battery
pack's deterioration.

・

The battery pack may swell out as it comes to near the
end of its lifetime depending on the usage conditions,
but it is not a problem.

・

Be careful especially about the following points when
preserving the battery pack.

- Keeping under the state of the full charge (right after
charging ends)

- Keeping under the state of the empty charge (too
exhausted to turn on FOMA terminal)

They may cause the battery pack performance to be
degraded or its lifetime to be shortened.
A recommended battery level to keep the battery pack
is the battery icon in 2 cells or in 40 % of remaining
battery level as a guide.

℃

).

Adapter

・

Charge the battery in an area within the proper
ambient temperature range (5-35

・

Do not charge the battery in the areas below.

- In areas of excessive humidity, dust or vibrations

- Near land-line phones or TVs/radios

・

It is normal for the adapter to become hot while
charging. Continue to use it.

・

When using the DC adapter for charging, keep the
vehicle engine running.

- The vehicle's battery could become flat.

・

When using an outlet with a mechanism preventing
unplugging, follow the handling instructions for that
outlet.

・

Do not give strong shock. Do not deform the charging
jack.

- May cause malfunction.

℃

).

docomo mini UIM card

・

Do not use excessive force to install/remove docomo
mini UIM card.

・

Note that DOCOMO assumes no responsibility for
malfunctions occurring as the result of inserting and
using docomo mini UIM card with another IC card
reader/writer.

・

Always keep docomo mini UIM card ICs clean.

・

Clean docomo mini UIM card with a soft, dry cloth
(such as a cloth for eyeglasses).

・

Maintain a separate record of the data you saved in
docomo mini UIM card.

- If the data is deleted, DOCOMO assumes no
responsibility for the loss of any data.

・

To preserve the environment, bring the old docomo
mini UIM card to a sales outlet such as docomo Shop.

・

Take care not to scratch, touch accidentally or short
IC.

- May cause data loss or malfunction.

・

Do not drop docomo mini UIM card or subject it to
shocks.

- May cause malfunction.

・

Do not bend docomo mini UIM card or place heavy
objects on it.

- May cause malfunction.

・

Do not install docomo mini UIM card into FOMA
terminal with a label or sticker put on.

- May cause malfunction.

Bluetooth® devices

・

This FOMA terminal is equipped with the security
features, that are compliant with Bluetooth standards
for communicati on via Bluetooth. However,
depending on the settings, there may not be enough
security. Be aware of security risks when using
Bluetooth.

・

DOCOMO assumes no responsibility for any
information which may be leaked during
communication via Bluetooth.

・

Frequency bands

Frequency bands used by FOMA terminal Bluetooth
function are as below.

abdc

2.4FH1

a

2.4 : Radio equipment that uses the 2400 MHz band.

b

FH : The modulation is the FH-SS method.

c

1 : The expected interference distance is 10 m or
shorter.

d

and 2483.5 MHz are used, and the bandwidth used by
mobile object identification devices cannot be
avoided.

Available channel varies by countries.
Use of Bluetooth function is limited in some countries.
Confirm regulations of the country/region to use it.
To use in airplane, confirm with airline company in
advance.

Cautions on using Bluetooth devices

In the bandwidth used by the FOMA terminal, in
addition to home electric appliances such as a
microwave oven and industrial/scientific/medical
devices, in-plant radio stations used to identify mobile
objects used in production lines of a factory that require
a license, specified low power radio stations, or amateur
radio stations that do not require a license (hereafter
"other radio stations") can be in operation.

1. Before using the FOMA terminal, check whether
other radio stations are in operation in your
neighborhood.

2. If radio wave interference occurs between the FOMA
terminal and "other radio stations", use the terminal
in a different location or "Turn the power OFF" to
avoid the radio wave interference.

3. For details, contact "General Inquiries" on the last
page of this manual.

: All bandwidths between 2400 MHz

Introduction

17

Wireless LAN (WLAN)

・

Wireless LAN (WLAN) exchanges information using
radio waves, and allows you to freely establish LAN
connection if you are within an area where radio wave
reaches. On the other side, if you communicate
without appropriate security settings,
communications may be intercepted or hacked by

Introduction

malicious parties. It is recommended to make
necessary security settings on your judgement and
responsibility.

・

Wireless LAN

Do not use Wireless LAN in a place where magnetized
by electric products, AV, OA equipment, etc. or where
electromagnetic wave is generated.

- If magnetism or electrostatic noise affects FOMA
terminal, noise may be increased or communication
may not be available (especially when using
microwave oven, it may affect the terminal).

- Using near TV or radio may cause poor reception or TV
screen may be blurred.

- When multiple wireless LAN access points exist near
FOMA terminal and they use the same channel, search
may not be performed correctly.

・

Frequency bands

Frequency bands for WLAN devices are written on
battery pack insert section of phone. Label description
are as follows.

a

2.4DS/OF4

bc

d

To use in airplane, confirm with airline company in
advance.

Cautions on using 2.4GHz devices

In the bandwidth used by WLAN devices, in addition to
home electric appliances such as a microwave oven and
industrial/scientific/medical devices, in-plant radio
stations for identification of mobile objects used in
production lines of a factory (a license is required),
specified low power radio stations (a license is not
required), or amateur radio stations (a license is
required) can be in operation.

1. Before using this device, confirm that in-plant radio
stations for identification of mobile objects, specified
low power radio stations or amateur radio stations
are not in operation in your neighborhood.

2. If this device generates harmful radio wave
interference against in-plant radio stations for
identification of mobile objects, change the using
frequency promptly or stop using wireless LAN
function, and contact "General Inquiries" on the last
page of this manual, then cons ult about treatment for
prevention of the interference (for example,
installation of partitions etc.).

3. If this device generates harmful radio wave
interference against in-plant radio stations for
identification of mobile objects or amateur radio
stations, or if any trouble, contact "General Inquiries"
on the last page of this manual.

a

2.4 : Radio equipment that uses the 2400 MHz band.

b

DS : The modulation is the DS-SS method.

c

OF : The modulation is the OFDM method.

d

4 : The expected interference distance is 40 m or
shorter.

e

and 2483.5 MHz are used, and the bandwidth used by
mobile object identification devices can be avoided.

Available channel varies by countries. To use WLAN
overseas, check the conditions such as available
frequency, regulation, etc. for the country.

18

e

: All bandwidths between 2400 MHz

FeliCa reader/writer

・

FeliCa reader/writer function of FOMA terminal uses
weak waves requiring no licenses for radio stations.

・

It uses 13.56 MHz frequency band. When using other
reader/writer function in your surroundings, keep
FOMA terminal away sufficiently from them. Before
using the FeliCa reader/writer, confirm that there are
no radio stations using the same frequency band
nearby.

・

To use in airplane, confirm with airline company in
advance. Use is limited in some countries. Confirm
regulations of the country/region to use it.

FM transmitter

・

FM transmitter of FOMA terminal uses weak waves
requiring no licenses for radio stations.

・

It uses 77.4 - 85.0MHz frequency band. To use it, set
frequency not to common to FM radio station of the
area you use to avoid affecting FM radio users in
neighborhood.

CAUTION

・

Do not use a remodeled FOMA terminal. Using a
remodeled terminal violates the Radio Law/
Telecommunications Business Law.

FOMA terminal is compliant with rules on the technical
standard conformance of specified wireless
equipment based on the Radio Law/
Telecommunications Busi ness Act, and as a proof of it,
the "Technical Compliance Mark " is depi cted on the
electronic nameplate of the FOMA terminal.
If you remodel FOMA terminal by removing its screws,
your certification of technical standard conformance
becomes invalid.
Do not use the terminal with its certification of
technical standard conformance invalid as it violates
the Radio Law/Telecommunications Business Act.

・

Be careful when you use FOMA terminal while driving
a car etc.

Using a mobile phone while driving is subject to penal
regulations.
However, absolutely necessary cases such as rescue
of a sick person or maintaining public's safety are
exempted.

・

Use FeliCa reader/writer function only in Japan.

FeliCa reader/writer function of FOMA terminal
conforms to Japanese radio standards.
If you use this function overseas, you may be
punished.

・

Use FM transmitter only in Japan.

FM transmitter of FOMA terminal is compliant with
wireless standards and is authorized for use only in
Japan.
If you use this function overseas, you may be
punished.

・

Do not alter the basic software.

Repair may refused due to modification of the
software.

Introduction

19

Waterproofness/Dustproofness

F-07F provides waterproofness of IPX5*1, IPX8*2
and dustproofness of IP5X
the external connection jack cap and installing
the back cover in a locked state.

Introduction

*1

IPX5 means that a phone keeps functioning after
applying a jet flow of 12.5 L/min. from every
direction from a distance of approximately 3 m for at
least 3 minutes using water nozzle in 6.3 mm inner
diameter.

*2

For F-07F, IPX8 means that a phone keeps
functioning after F-07F is slowly submerged to depth
of 1.5m in static tap water at room temperature, left
there for 30 minutes and then taken out, and the
mobile phone keeps shooting still images or moving
pictures in approximately 30 minutes in static tap
water at room temperature.

*3

IP5X means a protection degree that a phone keeps
functioning and safety after it is placed in a device
with dust in diameter 75
agitated and then taken out.

✜

What you can do with waterproofness

of F-07F

・

You can talk or watch 1Seg programs without
using an umbrella in the rain (for rainfall of 20
mm or less per hour).

- When your hands or FOMA terminal are wet,
avoid installing/removing the back cover or
opening/closing the external connection jack
cap.

・

You can also shoot still images and moving
pictures in the pool depth of 1.5 m.

- Do not perform other operations underwater
than shooting still images and moving
pictures.

- If you put the terminal in water of swimming
pool, be sure to have it within 30 minutes.

20

*3

with firmly closing

μ

or less for 8 hours,

- If FOMA terminal gets wet with water from the
swimming pool or soak in water of swimming
pool, wash it in tap water in room temperature

⇒

P20) and drain water in specified procedure

(

⇒

P22).

(

・

You can wash FOMA terminal in tap water in
room temperature.

- Holding the external connection terminal cap
not to open, wash the terminal with tap water
without rubbing hard.

- Do not apply water flow stronger than allowed

⇒

P20).

(

- Do not use brush, sponge, soap, detergent, etc.

- If mud or soil is adhered to the terminal, do not
open or close the terminal. Eliminate the dirt
first by shaking several times in tap water of
wash-basin and then wash the terminal with
running water.

- Drain water in specified procedure (
after washing.

・

You can use FOMA terminal in a bathroom.

- Do not put the terminal in the bathtub. Do not
use the terminal in hot water. May cause
malfunction. If you should fall the terminal into
the bathtub, immediately pick it up to drain
water in specified procedure (

- Never put FOMA terminal in hot spring water
or water containing soap, detergent or bath
powder. In case the terminal gets wet with
water other than tap water, wash it in the
procedure above.

- You can use the terminal within 2 hours in a
bathroom where the temperature ranges
between 5 and 45

between 45 and 99%.

℃

and humidity ranges

⇒

P22).

⇒

P22)

- Rapid temperature change may cause
condensation. If you bring FOMA terminal
from a cold place to warm place such as a
bathroom, wait until FOMA terminal reaches
the room temperature.

- Do not put hot water from a faucet or shower.

To ensure waterproofness/dustproofness

To avoid water/dust ingress, be sure to observe
the following points.

・

When using the external connection jack, put
your finger into the groove as shown then pull
the cap up.

Groove

After using the external connection jack, close
the cap as the direction shown in the illustration,
and make sure that the cap is completely closed
without slack by pushing the tabs in.

・

Do not poke the microphone, earpiece or
speaker with a sharp object.

・

Do not let FOMA terminal fall. It may become
scratched causing the waterproof/dustproof
performance to degrade.

・

The external connection jack cap and the rubber
packing of the rear side of the back cover play an
important role for keeping waterproof/dustproof
performance. Do not deform the back cover by
twisting etc. or peel off or damage the rubber
packing. Also, prevent dust from adhering to it.

To keep the terminal waterproofness/
dustproofness, replacement of parts is required
every 2 years regardless of whether the terminal
appears normal or abnormal. DOCOMO takes
the FOMA terminal to replace the parts as a
chargeable service. Bring FOMA terminal to a
sales outlet such as a DOCOMO-specified repair
office.

Important precautions

Do not perform actions shown in the illustrations
below.

<Example>

Introduction

Tab

・

Installing the back cover is described in
"Installing back cover" of "Attaching docomo
mini UIM card/battery pack".

・

Securely lock the back cover and firmly close the
external connection jack cap. Even a fine
obstacle (one hair, one grain of sand, tiny fiber,
etc.) put between contact surfaces may allow
water to enter.

⇒

P24

Using Soap/Detergent/

Bath powder

Applying strong

water flow

Washing with

brush/sponge

Soaking in

ocean water

Machine-washing

Using in

hot spring

21

Observe the following precautions to use FOMA
terminal properly.

・

Accessories and optional devices are not
waterproof/dustproof. Do not use FOMA
terminal installed in the included desktop holder
in a bathroom, shower room, kitchen, lavatory
or other highly humid area even if they are not
connected to the AC adapter.

Introduction

・

Do not apply water flow stronger than allowed

⇒

P20). Even if the F-07F is waterproof in IPX5

(
waterproof, water may enter inside and cause
troubles such as electric shocks or corrosion of
the battery.

・

If FOMA terminal gets wet with salt water, sea
water, refreshing beverage or mud or soil
adhered, wash it immediately. If they dry out, it
is hard to remove the dirt and it may cause
damage or malfunction.

・

Do not put FOMA terminal in hot water, use it in
a sauna or apply hot airflow (from a hair dryer
etc.) to it.

・

Do not move in water or slam the terminal
against the surface of water with FOMA terminal
opened.

・

When you use the terminal in swimming pool,
obey rules of the facility.

・

FOMA terminal does not float on water.

・

Do not leave water on FOMA terminal. May
short-circuit the charging jacks, or in a cold
region, water may freeze causing malfunction.

・

Do not leave water on the microphone, earpiece
or speaker. Such water may interfere with
talking.

・

If the back cover is damaged, replace it. Water
may enter inside from a damaged section
causing troubles such as electric shocks or
corrosion of the battery.

・

If FOMA terminal gets wet with water or other
liquids with the external connection jack cap or
the back cover open, the liquid may get inside
the terminal causing electric shocks or
malfunction. Stop using FOMA terminal, turn
the power OFF, remove the battery pack and
contact a DOCOMO-specified repair office.

・

If the external connection jack cap, or the rubber
gasket on the rear side of the back cover is
damaged or deformed, replace it at DOCOMO­specified repair office.

DOCOMO does not guarantee actual operations
under all states. Malfunctions deemed to be
caused by inappropriate operation by the
customer are not covered by the warranty.

Draining water from FOMA
terminal

When FOMA terminal is wet, water may flow out
after wiping it off; drain the water in the following
steps.

a

Hold FOMA terminal firmly and wipe off
moisture on the terminal surface and back side
with dry, clean cloth etc.

22

b

Shake FOMA terminal approximately 20 times,
firmly holding its hinge section, until there is
no more water splattering.

Swing the FOMA terminal with
the speaker above to drain water off

c

Swing the FOMA terminal about 10 times
against a dry, clean cloth etc. to wipe off water
remaining in the microphone, earpiece,
speaker, keypad, hinges or charging jack, etc.

d

Wipe off water drained from FOMA terminal
with dry, clean cloth etc., and dry naturally.

･

Water, if any, remaining in FOMA terminal
may ooze up after wiping off.

･

Do not wipe off water remaining in gaps
directly with a cotton swab etc.

Charging

Check the following before and after charging.

・

Never try to charge the battery pack when
FOMA terminal is wet.

・

When charging the battery after FOMA terminal
is wet, adequately drain it and wipe off water
with a dry, clean cloth etc., before connecting
the accessory desktop holder or opening the
external connection jack cap.

・

When the external connection jack cap is
opened for charging, close the external
connection jack cap firmly after charging. It is
recommended to use the desktop holder for
charging to prevent water/dust from seeping
inside from the external connection jack.

・

Do not use the AC adapter or desktop holder in
a bathroom, shower room, kitchen, lavatory or
other highly humid area. May cause fire or
electric shock.

・

Do not touch the AC adapter or desktop holder
with wet hands. May cause electric shock.

Introduction

23

Before Using

c

Attaching docomo mini UIM card/battery pack

After turning power OFF, close FOMA terminal
and hold it in your hand so that you can properly
attach docomo mini UIM card/battery pack.

✜

Removing back cover

a

Slide the lever in
direct ion to unlock

Back cover

Basic Operation

b

Press and slide the back
cover in the arrow direction
approx.

2

mm to remove

✜

Attaching docomo mini UIM card

Corner cut

✜

Installing battery pack

With the label side up, fit
the convex parts to the
concave parts of the FOMA
terminal and insert in the
direction, then push in the
direction to set in.

✜

Installing back cover

Concave parts

a

b

a

Fit the 8 tabs to the notches of
the FOMA terminal and push

a

in the
forming any clearance, then

slide in the

Convex parts

direction not to

b

direction

IC

docomo mini UIM card

With facing IC side of the docomo mini UIM card down,
insert to the slot slowly and push it until it clicks

Point

･

Only docomo mini UIM card is available for the
FOMA terminal. If you have a UIM or FOMA card,
bring it to a docomo Shop to replace.

24

b

a

b

Slide the lever in the c
direction to lock

c

Point

･

Make sure the locations of the slots for docomo mini
UIM card and microSD card. If the cards cannot be
removed, bring the FOMA terminal to a docomo
Shop.

Before Using

Charging

The battery pack does not have a full charge at time of purchase. Use AC adapter for FOMA terminal to
charge the battery before using FOMA terminal.

Charging using desktop holder

a

Insert the connector of AC adapter
horizontally to the accessory desktop
holder, with the arrows mark side
upward

b

Unfold the power plug and insert it into
a 100V AC outlet

c

Close FOMA terminal and insert it into
the desktop holder

*

Make sure the orientation of FOMA terminal is
correct and insert it properly. Installing with
excessive force may cause damage.

d

Check that the charging light turns on

*

After charging is completed, remove FOMA terminal from the desktop holder.

Charging using AC adapter

a

Open the external connection jack cap
(

a

), hold the connector horizontally
with the arrows side upward and insert
it to the jack (

b

Unfold the power plug and insert it into
a 100V AC outlet

c

Check that the charging light turns on

*

When charging is over, pull out the power plug from
the outlet, and pull out from FOMA terminal
horizontally while pressing the release buttons on both sides of the connector.

b

)

Connector

Release
buttons

AC adapter

d

Connector

c

Desktop holder

External
connection jack

Release
buttons

a

c

External connection
jack cap

b

AC
adapter

b

AC
outlet

a

AC
outlet

100

100

V

V

Basic Operation

25

Before Using

Power ON - Default setting

Initial setting is an operation when FOMA terminal
is turned ON for the first time.

a f

(2 sec. or more)

The Initial setting screen appears.

b

Set required items

If you exit without setting Change security
code and Request permit/deny, Initial setting

Basic Operation

screen reappears when the power is turned
ON the next time.

c

On a confirmation screen of software
update function,
confirmation screen of Error info send
set.,

g

The stand-by display appears.

Point

･

If no operation is performed, the display light is
automatically turned off according to the settings in
Light time-out or eco mode setting. The display light
turns on again if there is any operation or incoming
call.

･

The battery usage state is automatically recorded
while using the FOMA terminal. The record is used
only for repair diagnosis.

Turning power off : f (2 sec. or more)
Changing the initial setting :
Changing screen display to English :

mehdde

eC

ge

mehib

Select "English"

[Complete]

On the

Before Using

Caller ID notification

Set whether to notify your phone number (caller
ID) to the other party's terminal when making a
voice call.

a meg

Receive call setting
notification

TEL functioned Dial/

ec

eb

Caller ID

Settingea ON or b

OFF

Point

･

If you hear an announcement of requesting caller ID
when making a call, set Caller ID notification or add
prefix "186" to the phone number to call again.

Before Using

Checking Profile

Check a model name or own phone number.

a me0

User information screen appears.

Point

Editing the profile :

Ce

･

On the profile edit screen, select first mail address
then select "Acquire Auto" to obtain your mail
address from the i-mode center. For details of
changing a mail address, refer to NTT DOCOMO
website.

Checking a phone number during a call :

Profile

On User information screen,

AuthenticateeSet required items

eC

se0

26

Screen Explanation

Viewing display

New arrival information and current state can be
checked by the icon appearing on the screen.
Major icons are as follows.

a

b

a

Status area

Status icons are displayed. Select an area on the
stand-by screen to display icon details screen.
Battery level (Battery icon)

Ample
charge

Signal strength (Antenna icon)

Almost exhausted

(Charge the battery)

Basic Operation

d

e

f

a
g

"

ひつじのしつじくん® (Butler Sheep)"

NTT DOCOMO

©

Strong

:

Self mode ON

:

c

In data transfer mode

:

Connecting to i-mode

:

Infrared communication in operation

:

Bluetooth ON

:

The total calls cost exceeds the limit

:

Communication using handsfree-compatible

device in progress

:

Handsfree ON

:

Femtocell available

:

Positioning with GPS

:

Location request setting

:

Connecting to Wireless LAN

:

Unread Area Mail exists

:

In-area auto-send mail exists

:

Unread i-mode mail exists

:

Arrival i-concier information exists

:

Unreceived i-mode mail exists in the Center

:

A phonebook entry, memo or schedule has

secret attribute

Out of service area or where

Weak

radio waves do not reach

27

:

High-pitched alarm is "ON"

:

Kid-safe mode ON

:

During i-αppli operation

: i-α

ppli call exists

:

Communication mode ON (USB cable

connected)

:

Alarm is set

:

1Seg watching/recording reserved or alarm

of Memo is set

:

Manner mode ON

:

Call alert volume OFF

:

Vibration mode for voice call ON

Basic Operation

:

In Public mode (Drive mode)

:

Manner support ON

:

Record message setting ON

:

Keypad dial lock ON

:

Personal data lock ON

:

IC card lock ON

:

Recording 1Seg in the FOMA terminal

:

eco mode ON

:

microSD card inserted

:

Connected to external device using USB

cable

:

Pedometer/ACT monitor is set

:

Software update rewrite notice

:

Auto-update of latest pattern definition

failure

b

Update notification of MyFACE⇒P30

c

Pedometer/ACT monitor

Steps and activity amount of the day are
displayed.

d

Machi-chara

Characters moving about the screen and giving
messages. In addition to the preinstalled
characters, you can obtain characters by
downloading.

e

New arrival

Starting from the left, missed call, recorded
message, message in voice mail service, unread
mail, unread ToruCa, i­Select an arrival information etc. on the stand-by
display using
corresponding information (Focus mode).

f

Shortcut⇒P30

g

Task area

Icons indicating running features (tasks) appear.

α

ppli call

g

and k to quickly display the

28

Screen Explanation

Basic operations for screen and keys

Menu operation Guide area

On the stand-by display, press m and then
perform the functions from the menu. You can
select a menu item with shortcut operations,
which use the keypad, etc. or with multi-cursor
key operation, which uses the multi-cursor key to
move the cursor.

<Example> Selecting "Calculator"

Shortcut operations

a me6e2

Multi-cursor key operations

a me

Point

･

To return to the previous screen, press c. To
return to the stand-by display, press

Move the cursor to "f Tool"

g

[OK]eMove the cursor to
"

b

Calculator"eg [OK]

f

.

Operations that
can be
performed by
pressing

m

I

,

are

a, g, C

and
displayed in the
guide area.

*

Ter ms
indicated with
[ ] in the
instructions of this manual are items displayed in

e

the guide area.

Guide area

Basic Operation

29

Screen Explanation

docomo Palette UI

MyFACE

In the right and left area of the stand-by display,
up to 12 MyFACEs downloaded from sites, etc.
can be pinned.

a l

or

r

Switch screens one after another in the same
way to display MyFACE you want to use.

Basic Operation

Point

･

Packet communication charges apply to refresh
content for other than MyFACEs set by default. Note
that using MyFACEs set by default is also charged if
the i-mode access point is changed or while
international roaming.

Shortcuts

Select a shortcut icon to activate a function. You
can view a shortcut list by pressing d when the
cursor is on a shortcut icon.

30

Screen Explanation

使いかたガイド

You can check outline of function, operations or
troubleshooting. (In Japanese only)

a mef

Toole# GuideeSelect a

(Guide)

search method

<Guide screen>

目次

(Contents) :

functions.

索引

(Index) :

sorted according to Japanese syllabary.

フリーワード検索

keyword to search for.

ブックマーク

of registered bookmarks.

困ったときには

from lists of troubles or error messages.

その他のご案内

guide page introducing useful site.

Point

･

On a description screen, select "
this function)" to perform a function. Selecting a link

item in "

関連機能

more)" displays a corresponding description screen.

Search from a list of

Search from a list of words

(Free word search) :

(Bookmark) :

(Troubleshooting) :

(More information) :

(related functions)" or "

Search from a list

Search

Access to

この機能を使う

コチラ

Enter a

(Use

(See

Character Entry

Entering characters

5-touch input and conversion

5-touch input is an input method to switch a
character by pressing a key repeatedly.

a

Enter character on the character entry
screen

When a character is entered, the cursor
automatically moves in a regular interval. To
quickly enter characters assigned to an
identical key consecutively, press

<Example> Entering "

"ろ" : 9 (5 times)
"っ" : 4 (3 times)
"ぽ" : 6 (5 times)
"ん" : 0 (3 times)
"ぎ" : 2 (twice)

Conversion options appear at the bottom of
the screen. You can select a character from the
options by pressing

b C

[Convert]

Characters on the character entry screen are
converted. Press
conversion options list.

Point

･

You can enter a character by pressing 2 keys in
combination (2-touch input).

<Example>

ろ

" :

95

"
"っ" :

8043

"ぽ" :

806505

"ん" :

03

"ぎ" :

2204

Entering "

ろっぽんぎ

e*

e*

e*

d

.

C

again to display a

ろっぽんぎ

r

.

"

(twice)

" by 2-touch input

Operations during character entry

Returning to the previous character :
Deleting characters :
Adding voiced/semi-voiced sound or switching

upper/lower case :

c

*

n

Switching input modes

a

On the character entry screen, press

a

[Text Mode]eSelect "Hiragana/
Kanji", "Katakana", "Alphanumeric",
"Number", etc. from the Switch input
mode palette

<Switch input mode palette>

Text input

Set a text input method or operation during text
entry.

a meh

input
method
[Set]

Settinged Text display/

ec

Text inputea Text input

e

Set required items

eC

Basic Operation

31

Useful functions on the entry
screen

Useful functions on the entry screen are explained
taking mail message editing screen as an
example.

Entering common phrases

a m

[Submenu]ed Quote phrase/

data

eb

PhraseeSelect phrase type

Select a phrase

Basic Operation

Entering pictograms/symbols

a

On the character entry screen, when
[Pict/Sym] is displayed,
Sym]

e

Select a pictogram

On the pictogram selection screen, press m
to display one-byte symbols/two-byte
symbols, press
(Deco-mail pictograms)/pictograms/D pictures
(Deco-mail pictures).

C

Entering smileys

a m

[Submenu]ed Quote phrase/

data

e0

Pict/Symbol/Smileyec

Smiley

e

Select a smiley typeeSelect a

smiley

Copying/Cutting, pasting characters

a m

[Submenu]ec Copy/Cut/etc.

a

Copy or b CuteSpecify the area

using the multi-cursor key

b m

[Submenu]ec Copy/Cut/etc.

c

Pasteeg [Paste]

32

C

[Pict/

to display pictogram D

Sound/Screen Setting

Sound settings

You can set tones, such as changing a ring alert,
adjusting the volume, or muting the sound
emitted from FOMA terminal.

Ring tone

You can set your favorite melody, etc. for a ring

e

alert.

<Example> Setting voice call ring tone

a meh

Manner

e

Point

･

When Voice call ring tone is set, the setting applies to
Incoming call.

･

Some music or moving pictures/i-motion may not be
set to the ring alert.

Adjust volume

You can set the volume of a ring alert, alarm
sound, etc.

a meh

Manner
item

Vibration mode

e

You are notified of an incoming call or alarm with
vibration, instead of sound.

a meh

e

Vibration/Manner

e

Settingeb Sound/Vibration/

ea

Ring toneea Call ring tone

Set required items

eC

Settingeb Sound/Vibration/

ec

Adjust volumeeSelect an

ek

or

SDeg

[Select]

Settingeb Sound/

ed

Vibration mode

Select an itemeSelect a vibrate alert

[Set]

Silent mode

This function mutes the sound emitted from the
FOMA terminal such as ring alert, Keypad sound,
open/close operation sound, Alarm sound,
confirmation sound for reading a code with Bar
code reader, and notifies incoming calls with
vibrator (vibration). The microphone is sensitized
in Silent mode, and you can call in a small voice.

a #

(1 sec. or more)

appears on the stand-by display in Silent

mode (manner mode).

Canceling Silent mode (manner mode) : #

(1 sec. or more)

Point

･

Shutter sound, Auto focus lock sound for shooting
still pictures, and count down sound of Auto timer
are emitted even in Silent mode.

System sound

Set sounds emitted for key operation, opening/
closing the FOMA terminal, and shutter sound for
shooting still images or moving pictures
(including recording for Voice recorder).

a meh

Manner
sound

Point

･

Even if Keypad sound is set to on, no sound is made
while i-

Settingeb Sound/Vibration/

eb

Other soundsed System

e

Select an itemeSelect a sound

α

ppli is activated.

Sound/Screen Setting

Setting display

Stand-by display setting

You can change the default stand-by display.

<Example> Setting an image

a meh

eb

Image/i-

When Kisekae Tool is set, select "Yes" on the
confirmation screen for canceling.

b

Select a foldereMove the cursor to an

Display light

You can set the brightness of screen and Light
time-out.

a meh

Illumination
an item

Privacy view

This function allows the display to be less-visible
to the people around you. You can start/cancel on
the screen other than the stand-by display.

a s

Canceling Privacy view : s (1 sec. or more)

Settingea Screen/Display

Stand-by display settingea

α

ppliea Set image

eC

[OK]e"Yes"

Settingec Backlight/

ea

Display lighteSelect

e

Select a time or operation

(1 sec. or more)

Basic Operation

33

Select startup menu

Select a menu to be displayed when m is
pressed on the stand-by display.

a meh

eg

startup menu

Settingea Screen/Display

Menu preferenceea Select

e

Select a menu type

Font size

a meh

Basic Operation

input
items

For some font sizes selected for overall, a
confirmation screen for changing the MENU
font size appears. When pressing "Yes",
Kisekae Tool can be selected.

Settinged Text display/

ea

Font sizeeSet required

e

Select font size

Setting Machi-chara

You can set a character to be displayed on the
stand-by display.

a meh

ef

setting
[Set]

Point

･

Machi-chara does not appear when i-αppli stand-by
display is set or while playing moving picture/i­motion set for the stand-by display.

･

If you set Friendly message to "ON", Machi-chara
asks your call name (user name) when you return to
the stand-by display. Press
user name.

Settingea Screen/Display

Machi-chara settingea Display

e

Set required items

g

twice to enter your

eC

Sound/Screen Setting

Kisekae Tool

You can set the stand-by display, menu, incoming/
outgoing call screens, etc. at once with a
predefined combination. By default, Kisekae Tool
matched to the FOMA terminal color is set.

<Example> Setting preinstalled Kisekae Tool

a mee

Tool

To display details of the Kisekae Tool, select a
Kisekae Tool. To display the image of
coordinate, select "Preview".

b

Move the cursor to a Kisekae Tool

C

Data Boxeg Kisekae

ec

Preinstall

[Setting]e"Yes"

e

34

Sound/Screen Setting

Light setting

Indicator light

You are notified of missed call or unread mail
(including SMS) by the indicator light.

a meh

ee

display & light

a

Point

･

The indicator light blinks at approximately 10
seconds interval. However, when you receive
information with the FOMA terminal closed or you
open the FOMA terminal and close without checking
the arrival information, the indicator light blinks at
approximately 30 minutes interval.

Light alert

You can set the light operation that is turned on
for incoming call or during a call.

<Example> Setting illumination collectively

a meh

Illumination
Setting

Settingea Screen/Display

Each display settinged Info

eb

Indicator light

ON or b OFF

Settingec Backlight/

eb

Light alertea All

e

Select an item

e

Sound/Screen Setting

eco mode

Save the battery power by adjusting the display
backlight or sound temporarily.

a meh

mode setting

a

When "ON" is set, appears on the stand-by
display.

Point

･

If you do not change the default Shortcut menu
setting, press
eco mode to ON/OFF.

･

You can set operations when eco mode is "ON" in
eco mode options.

Std. saving :

alert, Indicator light, Backlight, 1Seg eco mode,
etc. to save the battery power.

Full saving :

settings of motion sensor, Manner support, Auto
light on, Machi-chara, AUTO-G PS, Pedometer/ACT
monitor, etc. to save the battery power.

eco mode auto-start set.

eco mode is automatically switched to ON/OFF
according to the battery level.

a meh

mode auto-start set.
items

Settingeg Batteryea eco

ea

eco mode ON/OFF

ON or b OFF

5

for 1 second or more to switch

Change settings of System sound, Light

With Std. saving applied, change the

Settingeg Batteryeb eco

e

Set required

eC

[Set]

e

Basic Operation

35

Lock/Security

Security codes

Security codes vary by functions. Security code
protects personal information. Be careful about
handling the security code.

Terminal security code

(Default : 0000)

The code is the security code to be used when
changing settings or deleting all the items at once.

Basic Operation

To change the code, perform the following
operation.

a meh

c

security code

b

Enter a new terminal security code
Enter the new terminal security code in
New terminal security code-check field

eC

Point

･

If a wrong terminal security code is entered 5 times
consecutively, the power is turned OFF.

Network security code

(At subscription : Set any code)

Network security code is required when DOCOMO
identifies the subscriber at docomo Shop,
docomo Information Center or "
(user support)" or when you subscribe Network
Services. To change the code, perform the
following operation.

36

Settingef Lock/Security

Set authenticationsea Change

e

Authenticate

[Save]

お客様サポート

a Ie "お客様サポート

e "各種設定 (確認・変更・利用

(Settings (Check/Change/Use))"

ネットワーク暗証番号変更

"
Network security code)" (in Japanese

only)

i-mode password

(At subscription : 0000)

i-mode password is required to save to/delete My

e

Menu, use Message Service, subscribe/cancel i­mode charged services, etc. To change the code,
perform the following operation.

e

a Ie "お客様サポート

e "各種設定 (確認・変更・利用

(Settings (Check/Change/Use))"

ｉモードパスワード変更

"
mode Password)" (in Japanese only)

PIN1/PIN2 code

(At subscription : 0000)

You can set 2 security codes to the docomo mini
UIM card: PIN1 code and PIN2 code.
The PIN1 code is a security code to be used when
installing the docomo mini UIM card or turning
ON the FOMA terminal.
The PIN2 code is the security code to be used
when requesting the issuance of a user certificate,
resetting Total calls cost or resetting the total call
costs.

(User support)"

)

e

(Change

(User support)"

)

e

(Change i-

To change either code, perform the following
operation. When changing PIN1 code, set PIN1
entry ON/OFF to "ON" in advance.

a meh

i

or

b

Enter the current PIN codeeEnter a

Settingef Lock/Security

UIM settingea Change PIN1 code

b

Change PIN2 codeeAuthenticate

e

new PIN code in New PIN code field and
New PIN code - check field

eC

[Save]

Point

･

To display the PIN1 code entry screen when turning
power on,

mehficae

and then set PIN1 entry ON/OFF to "ON".

･

Ev en if PIN 2 co de is loc ked by en ter ing i nco rre ct PI N2
code 3 times consecutively, making/receiving calls or
sending/receiving mail is available; if PIN code is
locked by entering incorrect PIN code 3 times
consecutively, these operations are unavailable.

Enter PIN1 code,

The PUK code

PUK code is used if the PIN1/PIN2 code is locked.
PUK cannot be changed by users. If the docomo
mini UIM card is locked by entering the PUK code
incorrectly 10 times consecutively, contact
docomo Shop.

Point

･

The PUK code is written on a subscription form (copy
for user) handed at subscription in a docomo Shop.
For users subscribed in other than docomo Shop,
bring a document (a drivers license etc.) to identify
your subscription and the docomo mini UIM card to
a docomo Shop, or contact "General Inquiries" on the
last page of this manual.

･

To set a security code, avoid imaginable
numbers such as "birth date", "a part of phone
number", "street address or room number",
"1111" or "1234". Maintain a separate record not
to forget the numbers.

･

Be careful never to reveal your security code to
others. If a security code is known to and
misused by others, DOCOMO assumes no
responsibility for damages resulted from it.

･

If you forget your security codes, you need to
bring a document (a drivers license etc.) to
identify your subscription, the FOMA terminal
and the docomo mini UIM card to a docomo
Shop. For details, contact "General Inquiries"
on the last page of this manual.

Basic Operation

37

Lock/Security

Various lock functions

All lock

Menu operation is unavailable. You can use only a
part of operations such as answering calls, receiving
mails, turning power ON/OFF.

Activate :

mehfabe

Deactivate :

Enter the terminal security code

Self mode

Basic Operation

All functions requiring communication are
unavailable.

Activate/Deactivate :

e

"Yes"

Keypad dial lock

Calls can be made only by using phonebook.

Activate/Deactivate :

Authenticateea or

Auto-key lock

✜

Lock on close

Each time the FOMA terminal is folded, key
operations are locked. But the side key operations
are available when the FOMA terminal is folded.

Activate :

mehfaaae

Set required items

Deactivate temporarily :

and authenticate

✜

Unoperated lock setting

Lock key operation when no operation is
performed for a certain period of time.

Activate :

mehfaabe

Set required items

Unlock temporarily :

38

Authenticate

mehiaea

mehfade

b

eC

eC

me

Authenticate

Open the FOMA terminal

Authenticate

Authenticate

or

IC card lock

Osaifu-Keitai, obtainment of ToruCa from IC card
reader, iC transmission, etc are unavailable.

Activate/Deactivate :

me#dae

Authenticateea or

Omakase Lock

The personal data of phonebook etc. or IC card
function of Osaifu-Keitai is locked only by
contacting DOCOMO in case FOMA terminal is
misplaced etc. For details, refer to NTT DOCOMO

b

website.

■

Setting/Canceling Omakase Lock

0120-524-360 Business hours : 24 hours

(open all year round) (In Japanese only)

*

Unavailable from part of IP phones.

*

Omakase Lock can be set/canceled from My
docomo site using a PC etc. (in Japanese only)

e

e

b

Lock/Security

Incoming call restriction

Lock/Security

Resetting to default

Call rejection setting

Call reject setting allows you to reject calls from
phone numbers not saved in phonebook and
reject or accept calls from the specified numbers.
In addition, you can set a receiving operation for
each reason for hiding caller ID.

a meg

Receive call setting
setting

Rejecting unregistered calls :

ae

Setting to reject/accept incoming calls from
specified numbers :

a

Setting for anonymous, payphone,
unavailable incoming calls :

AuthenticateeSet each item

Point

･

Unregistered caller setting is available for calls
showing caller ID. For calls hiding caller ID, receiving
operation is performed according to the call reject
setting for Anonymous, Payphone, Unavailable. It is
recommended that you use both Caller ID request
and call reject setting for Anonymous, Payphone,
Unavailable.

･

The reasons for hiding caller ID are as follows:

Anonymous :
Payphone :
Unavailable :

such as an overseas call or call from land-line
phone using call forwarding service, etc.

TEL functioned Dial/

ei

e

Perform target operation

Authenticateea or

-

c

a call from public payphone, etc.

be

a call with hiding caller ID set

a call unavailable to notify caller ID

Call rejection

b

Authenticate

c

-

ee

e

Reset

Reset to default.

a meh

d

item to reset

Settingei Other setting

ReseteAuthenticateeSelect an

eC

[Reset]e"Yes"

e

Delete all data

You can delete data saved in FOMA terminal, and
restore the each function's settings to the default.

a meh

c

"Yes"

All data is deleted while restarting. Do not turn
power off until the stand-by display is
displayed.

Point

･

Even after all data is deleted, the data registered by
default is not deleted.

Settingei Other setting

Delete all dataeAuthenticate

e

e

Basic Operation

39

Call Telephone

Making a call/videophone call

Entering a phone number

a

Enter a phone number including area
code (Up to 80 digits)

or

C

(videophone call)eWhen

ending the call,

Point

･

Do not cover the microphone during a call.

en

f

Using phonebook

a ue

Connect

40

Search phonebook

The phonebook list search result of the Show
all names is displayed by default. You can
switch lines by

a

/ I.

b

Move the cursor to the party

To make a videophone call, move the cursor to
the party and operate as follows.

From Show all names :

Call type field

From other search :

h

or switch the pages by

meaae

bea

I

(voice call)

en

In the

Point

･

You can make calls using logs of mails, etc. if phone
numbers are saved in phonebook.

･

When mail address is registered to the phonebook,
you can create i-mode mail from the phonebook list.

Using redial/received calls

Up to 30 items can be displayed in Redial and
Received calls respectively. When the maximum
number is exceeded, older logs are overwritten.

a meg

Received calls
Redial

b

Move the cursor to a party
call) or

Deleting redial/received call log :

To delete selected items, select items
and to delete all items, you need to
authenticate.

Point

･

DOCOMO videophone specifications conform to
"3G-324M, an international standard prepared by
3GPP". The connection with the videophones of
different specifications cannot be established.

･

Because the FOMA terminal is not equipped with in­camera, images you can send to the other party are
Chara-den, still images and out-camera images.

TEL functionec Dialed/

ea

I

(videophone call)

cursor to a log

emeeea

Received calls or b

en

(voice

Move the

- ce"Yes"

eC

,

Koe-no-Takuhaibin International calls

Koe-no-Takuhaibin is a service sending messages
using voice call. You can record or play messages
between FOMA terminals without calling a party.
You are notified by record notification SMS when
a message is recorded, and by play notification
SMS when the party plays a message (when the
party sets play notification to on. It is set to on by
default). For details, refer to NTT DOCOMO
website.

Recording a message

Record a message in the Koe-no-Takuhaibin
service center.

a

Enter a phone number

e

Follow the guidance of Koe-no-

eI

[Koetaku]

Takuhaibin service center to operate

Point

･

To make a call from Phonebook via Koe-no­Takuhaibin, press

C

.

Checking message/Setting services

You can check messages or set service such as
Koe-no-Takuhaibin by using SMS, Koe-no­Takuhaibin website, the voice prompts.

Check messages via SMS :

folder

e

Check messages/Set service from website :

Check messages/Set service using voice prompt :

Select an SMS to viewe"Play"

meghae

megheb

aeae

"Yes"

or ce"Yes"

Select a

ea

You can make international calls from Japan
using WORLD CALL.

✜

WORLD CALL

"WORLD CALL" is the international call (voice call/
videophone call) service available from DOCOMO
mobile phones. You are subscribed to "WORLD
CALL" at the time of subscription to the FOMA
service (Unless you request not to subscribe to it).

･

No subscription or monthly charges apply.

･

DOCOMO charges customers for "WORLD CALL"
fee and monthly FOMA service call fee all
together.

･

For details of "WORLD CALL", contact "General
Inquiries" on the last page of this manual.

･

To use international call services except DOCOMO
service, contact the carrier for details.

･

For countries and overseas telecommunications
carriers available, refer to "Mobile Phone User's
Guide [International Services]" or DOCOMO
International Services website.

･

The image of the other party displayed on FOMA
terminal may be distorted or connection may not
be established depending on the other party's
terminal connected through the international
videophone line.

a

Enter "010-phone number without the
leading 0 of Country code (City code)"

n

(voice call) or C (videophone
call)

In some countries and areas such as Italy, "0"
is required.

Connect

e

41

Call Telephone

Receiving a call/videophone call

a

Receive

You are notified of an incoming call with ring
alert, light alert, etc. On the display, the phone
number appears when caller ID is sent, and
caller's name appears when phone number is
saved in the phonebook. When caller ID is not
sent ,the reason (Anonymous, Payphone or
Unavailable) appears.

j

:

Adjust the alert volume

S

:

Stop the ring alert and vibrator

f

:

On-hold

b n

Connect

(voice/videophone call) or I

(videophone call)

c

When ending the call,

Point

･

When you cannot answer an incoming call,
(The digit indicates the number of missed calls)
appears on the stand-by display. The incoming calls
are recorded as missed calls in Received calls.

f

Call Telephone

Operation during a call

You can use useful functions during a call.

On hold

A melody is played while on hold. For a
videophone call, the videophone on-hold image is
displayed on the phone of the other party and
yourself.

a

During a call, g [OnHold]

Point

Canceling the voice call on hold : g or
Canceling the videophone call on hold (send the image

before on hold) :

Canceling the videophone call on hold (send the

camera image) :

Canceling the videophone call on hold (send a

substitute image) :

g

I

a

or

Listening volume

You can adjust listening volume during a call.

a

During a call, j or

Point

･

This setting applies to Listen volume in Adjust
volume.

n

n

SD

42

Call Telephone

When you cannot answer a call

Record message Public mode

When Record message is set to "ON", a greeting
message is played and the caller can record message
when you cannot answer the call.

a meg

message/Voice memo
message

Point

･

You can record up to 4 voice/videophone calls in
total, approximately 30 seconds for each call. When
reaching the savable number, appears on the
stand-by display and Record message does not
work. Delete unnecessary recorded messages.

･

Even when Record message is not set to "ON", you
can activate it only once by pressing
or more while receiving a call (Quick recorded
message).

･

Even when the greeting message is being played or
a message/video is being recorded, you can answer
a call by pressing
In this case, the recorded contents before the call was
answered does not remain.

Setting a response time :

time

Playing a recorded message :

a message

TEL functioneb Record

ed

Record

ea

appears on the stand-by display.

ON

n

(for videophone call, I).

megbdce

e

Select whether to delete

megbae

S

for 1 second

Enter

Public mode is an automatic answering service
putting emphasis on manners in a highly public
place or when driving a car.

Public mode (Drive mode)

When there is an incoming call, a guidance
message is played to inform the other party of the
reason that you cannot answer the call and
request to call back, and then the call ends
automatically.

a *

(1 sec. or more)

appears on the stand-by display.

Point

･

In Public mode (Drive mode), no receiving action is
performed, and calls are recorded as Missed call.

Canceling : * (1 sec. or more)

Public mode (Power OFF)

When there is an incoming call while turning off
the power, a guidance message is played to
inform the other party of the reason that you
cannot answer the call and request to call back,
and then the call ends automatically.

Select

a

Enter "＊25251"

Even when Public mode (Power OFF) is set, no
indicators such as icons appear on the display.

Point

Canceling :
Checking the settings :

Enter "＊25250"

en

en

Enter "＊25259"

Connect

en

43

Call Telephone

Network Services

Service Application

Voice Mail Service

Missed Call Notification
Service

Call Waiting Service

Call Forwarding Service

Nuisance Call Blocking
Service

Caller ID Notification
Service

Connect

Caller ID Display Request
Service

English guidance

Multi Number

2in1

Koe-no-Takuhaibin

Public mode (Drive mode)

Public mode (Power OFF)

Melody Call

･

Network services are not available out of service
area or where radio waves are hard to reach.

･

For subscription and details of the services, contact
"General Inquiries" on the last page of this manual.

･

For details, refer to NTT DOCOMO website.

Required Charged

Not required

Required Charged

Required Free

Not

required

Not required

Not

required

Not required

Required Charged

Required Charged

Not required

Not required

Not required

Required Charged

Setting network service

The operations for major network services are as
follows.

44

Monthly

charge

Free

Free

Free

Free

Free

Free

Free

Free

Service Operating procedure

Voice Mail
Service

Call Waiting
Service

Call
Forwarding
Service

Point

･

When ring time is set to "0 sec." for Voice Mail service
or Call Forwarding service, incoming calls are not
recorded in Received calls.

･

To answer a call from another party during a call when
call waiting is activated, press
on hold, press

meg

TEL functione*
Voice mail service
following operation
Activate :

Enter ring time

Deactivate : ce"Yes"
Play messages :

"Yes"eFollow the guidance to
operate

meg

Other network service
waiting

e

Perform the following
operation
Activate :
Deactivate : be"Yes"

meg

Other network service
forwarding
following operation
Activate :

Enter a phone

number

"Yes"eEnter ring time

Deactivate : be"Yes"

I

to switch the parties to talk to.

e

Perform the

ae

"Yes"e"Yes"

eea

TEL functione#

ae

TEL functione#

e

ae

eCe

n

eb

"Yes"

ea

Perform the

"Yes"e"Yes"

. When a party is put

or

e

be

Call

Call

e

Call Telephone

Emergency call

You can make the following emergency calls from
the FOMA terminal.

Police

Fire and ambulance

Marine emergencies

･

This FOMA terminal supports "Emergency
Location Report". When making an emergency
call to 110, 119, 118, etc., information of your
location (location information) is automatically
informed to an emergency call receiving
organization such as police. The Emergency call
acceptance organization may not be able to
figure out your exact location depending on the
location where you place a call or radio wave
condition.
When the caller ID is hidden for the call, i.e., by
appending "184" to the dialed number, none of
location information or your phone number is
notified; however, the organization may acquire
the location information and phone number
regardless of your settings, if they have
determined that such information is necessary
for the protection of life etc. The area and timing
of implementing "Emergency Location Report"
vary by the preparatory state of respective
emergency call receiving organizations.

110

119

118

･

When calling to 110, 119 or 118 from the FOMA
terminal, inform them that you are calling from
a mobile phone and give your phone number
and your current location precisely since the
police or fire department has to call you back for
confirmation. To make sure that you are not cut
off during the call, do not move during the call
and do not turn OFF the phone just after the call,
but keep it on for about 10 minutes.

･

For some areas you are calling from, you are not
connected to the local police or fire department.

･

When Auto redial as voice of Operation is set to
"ON", videophone call to 110, 119 or 118 from
the FOMA terminal changes automatically to
voice call.

･

When you make an emergency call with the
following functions activated, the settings are
disabled, and approximately 5 minutes later,
enabled again automatically. The disabled
settings do not show the changes on the display
even while disabled.

- Unregistered caller

- Specified caller

- Accept/Reject call of Phonebook

- When Arrival call act is set to other than
"Answer"

･

If you make an emergency call while "Public
mode" or "Self mode" is set, the setting is
disabled.

Connect

45

Call Telephone

Using overseas

You can talk with FOMA terminal and use i-mode
overseas.

✜

International Roaming (WORLD WING)

International roaming (WORLD WING) is a service
that allows you to make voice calls and access i­mode using network of telecommunications
carriers affiliated with DOCOMO overseas. Before
using this service, check its subscription status.
For details, contact "General Inquiries" on the last
page of this manual.

･

The FOMA terminal is Class 4. The service is
available in areas that 3G Network or GSM/GPRS
Network covers. Also, it is available in countries

Connect

or districts where 3G 850 MHz is applied. Check
the service area.

･

Refer to the following documents before using
FOMA terminal overseas.

- "Mobile Phone User's Guide [International
Services]"

- DOCOMO International Services website

Available service overseas

Communication

Voice call

Videophone call

i-mode

i-mode mail

SMS

i-channel

i-concier

46

service

*1

*1, 2

*3

3G 3G850

○○ ○
○○
○○ ○
○○ ○
○○ ○
○○ ○
○○ ○

GSM

(GPRS)

×

Communication

service

*4

i-Widget

*5

GPS

Packet
communication
(PC connection)

*1

International settings of i-mode are required.

*2

International settings of i-channel are required.

3G 3G850

○○ ○
○○ ○

○○ ○

GSM

(GPRS)

Packet communication fee is also charged for
auto update for Basic channel (included in i­channel usage fee in Japan).

*3

International Settings of i-concier is required.
Packet communication fee is charged each time
you receive information.

*4

International Settings of i-Widget is required.
When multiple Widget Appli communicate, a
packet communication fee is charged per one
communication.

*5

No fee is charged for GPS positioning (Position
location). However, when displaying a map using
location information etc., a packet
communication fee is charged.

Point

･

Some services may not be available depending on
the network operator or network overseas.

Making a call from the country
you stay

You can make a voice call or videophone call from
overseas using international roaming service.

Making an international call

a 0

(1 sec. or more)

"+" is entered.

b

Enter "Country code (for Japan, 81)­phone number without the leading 0 of
Area code (City code)"
call) or

C

In some countries and areas such as Italy, "0"
is required.

(videophone call)

Making a call inside the country you stay

a

Enter a phone number
call) or

C

(videophone call)e"No,

use original"

The call may be made with no message
displayed.

Making a call to WORLD WING user
overseas

a 0

(1 sec. or more)eEnter "81 ­mobile phone number without the
leading 0"

en

(videophone call)

Point

･

The call is forwarded internationally from Japan
even when staying in the same country as the party
to be called, so enter "+" and the country code of
Japan, "81".

en

(voice

en

(voice

(voice call) or C

･

When you enter a number within 2 digits to call
overseas, a screen asking for selecting "Quick dial" or
"Call" appears. If you select "Quick dial", the call is
made to the other party in memory No. If you select
"Call", the call is made as it is (used for emergency
overseas).

Receiving a call inside the
country you stay

a

A call is received

I

(videophone call)

Point

･

Regardless of the country, from which the call is
made, the call is internationally forwarded from
Japan. The caller is charged for call fees to Japan,
and the receiver is charged for receiving the call.

en

(voice call) or

Setting after returning to
Japan

When you turn the FOMA terminal ON, the
connection to the FOMA network is established
automatically. If it is not automatically connected,
set Network search setting to "Auto" and 3G/GSM
setting to "Auto".

Connect

47

Mail

Sending i-mode mail/Sending SMS

b

Sending i-mode mail

Only by subscribing to i-mode, mails can be
exchanged not only with docomo terminals but
also with anyone who has an Internet mail
address such as other company's mobile phone/
smartphone or a PC.
You can attach up to 10 files and up to 2 MB of files
(image, moving picture, etc.) in total. And, Deco­mail is supported so that you can easily send
expressive emails by using Deco-mail pictograms/
Deco-mail pictures and changing text color, size or
back ground, etc.

Connect

･

For details, refer to NTT DOCOMO website.

a aea
b

Enter an address, title and text

[Write]

[Send]

When sending is completed correctly, the mail
is automatically saved in a folder of Outbox.

Point

Adding addresses :

"<No address>"

On the mail creation screen, select

Attachments

You can attach up to 10 files and up to 2 MB of
image or moving picture/i-motion, etc. in total.

a

On the mail creation screen, select the
attachment field
Attach a file

e

Select a file type

eC

e

Enter a recipient, title and message

C

Point

･

Sending an attachment file of a big size may take
time. After sending such file, a lot of mail in folders
of Outbox may be deleted.

Removing attachment :

select the attachment field
attachment
required)

Sending SMS

When you do not know receiver's mail address, you
can send a text message to mobile phone number
instead of the mail address.
SMS can be also sent to or received from the
parties using overseas service providers. For
countries and overseas network operators
available, refer to "Mobile Phone User's Guide
[International Services]" or DOCOMO
International Services website.

a aeg

recipient and message

Point

･

When there is an incoming SMS, FOMA terminal
operates in the same way as an incoming i-mode
mail.

[Send]

On the mail creation screen,

e

eCea

e

"Yes"

Move the cursor to the

- c (for eb, selection is

Compose new SMSeEnter a

eC

⇒

P50

e

[Send]

48

Mail

Deco-mail/Decome-Anime

Deco-mail

You can change a font size or background color, or
insert still images, Deco-mail picture or Deco-mail
pict.

<Example> Specifying decoration before entering

a

b
c

Point

･

When "Auto Deco-mail" is selected after the message
text entry, the message is automatically decorated
according to the message content. Each time you
press
another.

characters

On the creation screen, "Msg"

eI

[Decorate]

<Decoration menu>

Select a decoration iconeDecorate

Enter a recipient and title

C

, Deco-mail options appear one after

eC

[Send]

Decome-Anime

You can create more expressive Deco-mail using
templates made with Flash graphics.

a aee

Anime

b

Move to the cursor to a template
[OK]

c

Edit items

Changing template :

d C

eC

Point

･

To preview, after loading the template, press a
while editing text or images. To return to the
previous screen, press

Create new Decome-

e

"Edit"

<Decome-Anime Template list screen>

back to Step 2

meae

[Quit]eEnter a recipient and title

[Send]

m

.

eC

"Yes"eGo

Connect

49

Mail

Receiving i-mode mail

No specific operations or settings are required for
receiving mails (mail automatic reception).

a

Receive i-mode mails

Blinking

Connect

<Completion of mail reception screen>

b

On the completion of receiving mail
screen, "Mail"
a mail

Point

Checking mails in the mailbox :

a folder

e

Replying to mails

a aea

Select a mail
Reply/Forward
Decome-Anime

b

Edit a title and message

e

Select a foldereSelect

Select a mail

aea

InboxeSelect a folder

em

[Submenu]ea

ea

Reply - f Vreply

eC

- ceSelect

e

[Send]

Point

･

By selecting a mail and then pressing C, you can
reply easily using stored common phrases (Quick
reply).

Checking new mail/message

You can make inquiry for any i-mode mail or
MessageR/F delivered while you were out of service
area or the power was turned OFF.

a a

(1 sec. or more)

Point

Checking new SMS :

aei

Setting mail sort rule

Sent/received mails are sorted in created folders
with rules set.

a aea

the cursor to a folder

b m

Select a number

c

Select a sort ruleeSet a rule

d C

Point

Re-sorting saved i-mode mail/SMS :

emeee

Inbox or b OutboxeMove

[Submenu]ed Sort rules

[Complete]

Authenticatee"Yes"

aea

e

or

b

50

Mail

Early warning "Area Mail"

This is a service that you can receive emergency
earthquake flash report etc. delivered by the
Meteorological Agency. i-mode subscription is
not required.

Receiving Area Mail

When an Area Mail is received, turns on, and
you are notified of reception with blinking light,
the dedicated buzzer, dedicated ring alert or
vibrate alert.

Point

･

You cannot receive Area mail during a videophone
call or Omakase lock, while using infrared
communication/iC transmission.

Early warning "Area Mail"
setting

Make various settings for Area Mail.

a ae*

"Area Mail" setting

b

Perform target operation

Receive setting :
Beep time : beEnter time (1 - 30 seconds)
Manner/Public mode setting :
Check ring tone :
Other (Receive entry) :

e

Mail SettingeEarly warning

aea

or

dea

or

Perform target operation

eeae

b

cea

b

Authenticate

or

b

Phonebook

Phonebook new entry

There are two phonebooks: the FOMA terminal
phonebook and the UIM phonebook.

<Example>

a meg

Point

Saving to UIM phonebook :

name

Adding Phonebook entries
from redial/received call

a meg

b

c

Point

Searching a phonebook entry :
Editing a phonebook entry : ueSearch the phonebook

Move the cursor to a phonebook entry
Select an item and edit

Deleting a phonebook entry : ueSearch the

phonebook

emefea

for

Adding a FOMA terminal phonebook entry

TEL functionea Phonebook

eb

Add to phonebookeEnter a name

e

Set required items

e

Set required items

eC

[Save]

megace

eC

Enter a

TEL functionec Dialed/Received

calls

ea

Received calls or b Redial

Move the cursor to the party
[Submenu]
phonebook or

ed

Addea Add to

b

Update phonebookea

In phone memory or

To update a phonebook entry, select the entry
to add a phone number to.

Set required items

e

Move the cursor to a phonebook entry

c

, authenticate)e"Yes"

eC

eCe

- c (eFor b, select some items,

em

b

In UIM

[Save]

megaaea

emecae

"Overwrite"

or

"New entry"

e

Connect

-

g

51

i-mode/Full Browser

Displaying i-mode site/website

With i-mode, you can use services such as site
connection, Internet connection or i-mode mail by
the display of i-mode compatible terminal. You
can use Full Browser to display websites created
for a PC.

･

i-mode is a charged service requiring
subscription. For details, refer to NTT DOCOMO
website.

･

The contents of sites and Internet websites are
generally protected by copyright laws. All or
any portion of text, image or other data
imported to your i-mode compatible terminal
from a site or website cannot be altered except
for personal use, and cannot be sold or
redistributed in any form without the express
permission of the copyright holder.

･

If you attach a docomo mini UIM card except

Search

yours or turn ON the FOMA terminal without
docomo mini UIM card, still images/i-motion/
melodies downloaded from websites, attached
files sent/received by mail, screen memos and
MessageR/F cannot be displayed or played.

･

When the stand-by display, ring alert, etc. is set
by data with the docomo mini UIM card
operation restriction, if you replace the docomo
mini UIM card with another one or turn the
power ON without docomo mini UIM card, it
operates in the default data or standard data.

･

i-mode and Full Browser have different
charging systems. It is recommended that you
subscribe to i-mode packet flat-rate service
because a high packet communication fee is
required to use Full Browser according to data
communication volume.

52

Displaying i-mode site

a Ie

Select an item to view

During i-mode
communication, blinks
on the display.
To display English menu,
scroll down to the bottom
of the iMenu screen and
select "English".

<iMENU screen>

Displaying web pages
designed for PC

a meb

Browser Home

i-mode/webe* Full

Switching i-mode/Full Browser

a

While site or website is displayed, m
[Submenu]

Point

･

You can use Full Browser via Wireless LAN. If you
switch from Wireless LAN to the FOMA network,
packet communication fee is charged. Note that the
network connection will not return to Wireless LAN
automatically, once switched to the FOMA network.

eeb

Viewing and operating screen

Status, title/URL

Pointer

Scrolling up and down* : SD or
Scrolling up and down continuously* : k (1 sec.

or more)

Switching normal/scroll mode :
Changing pages : a [← Back]/ I [Next →]
Visual history : a [← Back] (1 sec. or more)/

I

[Next →] (1 sec. or more)

●

In scroll mode
Scrolling up or down : a [↑ Page]/ I [↓ Page]
Scrolling up or down successively : a [↑ Page] (1

sec. or more)/

I [↓

<Browser screen>

k

n

Page] (1 sec. or more)

Bookmark

Saving :

When a site or website is displayed, m
[Submenu]
folder

Displaying :

a bookmark

eabe

"OK"eSelect a saving

mebbe

Select a foldereSelect

Screen Memo

Saving :

When a site or website is displayed, m
[Submenu]

Displaying :

screen memo

ebbea

mebcea

or be"Yes"

or beSelect a

i-channel

Using i-channel

i-channel is a service that news, weather information,
etc. is distributed to the i-channel compatible terminal.
(In Japanese only) The auto-received information
appears in the ticker on the stand-by display. Press

c

to display the channel list.

●

Basic Channel

The channel is provided by DOCOMO, and the
packet communication fee for automatically
updating the distributed information is not charged.

●

Okonomi (Optional) channel

The channel is provided by an IP (Information
Provider), and the packet communication fee for
automatically updating the distributed
information is separately charged.
When viewing detail information in Basic Channel or
Okonomi Channel, a packet communication fee is
separately charged. For overseas use, packet
communication fee is charged for both automatic
update and viewing detail information.

･

i-channel is a charged service requiring subscription.
i-mode subscription is required for the service.

･

For details, refer to NTT DOCOMO website.

To view the detail information of the ticker
displayed, perform the following operation.

a

On the stand-by display,
channel

The site is connected and the detail
information appears.

Point

･

When the detail information of i-channel is
displayed, the same operations as the ones when i­mode sites or websites are available.

ce

⇒

Select a

P53

Search

53

Map/GPS

Using Map/GPS function

･

This function is unavailable as a navigation
device for aircraft, vehicles or persons or as
high-precision location surveying GPS.
DOCOMO is not liable to any purely economic
damages including troubles, if any, caused by
missing opportunities of viewing positioning
results or making communications due to
failures or malfunctions of the FOMA terminal
or external events such as defect, power
interruption (including battery exhaustion) in
using the FOMA terminal for purposes
including but not limited to the above.

･

Because GPS is managed by U.S. Department
of Defense, GPS wave conditions may be
controlled (accuracy degraded or wave
stopped) for security reasons of the U.S. And,
wave conditions differ by satellite locations;
therefore, positioning operations in the same

Search

location under the same environmental
conditions may not yield the same result.

･

Because GPS uses waves transmitted from
satellites, under the circumstances that waves
cannot be received or become hard to be
received, there may be a margin of error of 300
m or more in location information.

･

When using Location request and Notify
location functions, check instructions and
precautions given in website of GPS service
providers and NTT DOCOMO. And, you may be
charged for using these functions.

･

The GPS function except Position location is
unavailable out of service area.

54

Map/Navigation

You can start GPS compatible i-αppli to display
maps after positioning location or navigate.

a mei

b

Point

･

i-αppli set in Select map in Map setting starts. "

アプリ

Map/Overseasea Map or

Navigation

(Map Application)" is set by default.

地図

Position location

You can check where you are. No packet
communication fee applies for positioning of
Position location, but a packet communication fee
is required separately with map displayed using
location information.

a mei

Overseas
Position location/
Location notification

ea

location

When positioning is in
progress, blinks. When positioning is
completed, the position location menu appears.
From the menu, you can select options to read
map, use GPS compatible i­mail creation screen on which location
information is pasted, add to phonebook, etc.

Map/

ef

Position

<Location information usage menu>

α

ppi, display the

Map/GPS

AUTO-GPS

Your current location or information measured
by Pedometer/Activity monitor is automatically
sent to service providers on a regular basis
(approximately once in every 5 minutes), which
allows you to services that deliver information
about the weather or shops around where you
are, or sightseeing information. (In Japanese
only)

･

To use an AUTO-GPS compatible service, set
AUTO-GPS service information from its AUTO­GPS compatible i-

･

When using the AUTO-GPS function, check
instructions and precautions given in website
of GPS service providers and NTT DOCOMO.
And, you may be charged for using these
services.

･

Note that more power is consumed in FOMA
terminal due to a regular communication
depending on your usage condition.

･

You can set "Low battery setting" to deactivate
the AUTO-GPS function to save the battery
consumption when the battery level gets low.

α

ppli.

Setting AUTO-GPS

Set whether to use the AUTO-GPS function.

a mei

g
e

ea

Map/Overseas

Map&GPS setting/history

e

e

AUTO-GPSeb AUTO-GPS setting

ON or b OFF

Setting services provided by
DOCOMO

To use AUTO-GPS services that work with i­concier or services provided by DOCOMO, set
whether to send your location information to
DOCOMO on a regular basis. These services
require separate subscriptions to use.

a mei

Map&GPS setting/history
GPS

Map/Overseaseg

ea

DOCOMO service set

ee

AUTO-

e

"ON" or "OFF"

Setup service list

Display a list of the names of i-αppli (the service
name), to which AUTO-GPS service information is
set, and its status.

a mei

Map&GPS setting/history
GPS

Canceling the service (including AUTO-GPS) :

Map/Overseaseg

ee

AUTO-

ec

Setup service list

While a setting services list is displayed,

meaea

item, for

- c(eFor b, select an

c

, authenticate)e"Yes"

Search

55

Camera

Shooting still images/moving pictures

Viewing shooting screen

a

b

c

<Still image shooting screen>

a

Sense orientation icon

b

Focus frame, face detection frame

c

Name of detected person (Find-me focus)

d

Zoom rate

e

Available remaining time estimate

f

Setting icons

Attach location
Auto-focus

Enjoy

Shooting light Brightness
Auto timer Shoot by scene
Fix camera shake

Continuous mode Auto/Panorama shooting

number

Art camera HDR
Image quality Size
Snap movie White balance
Quick shooting
Best-shot select
Panorama
Smooth Slo-Mo

56

f

<Moving picture shooting screen>

d
e

Fast-Mo
Tracking focus Skew correction

Shooting type (Switch img/voice)

Shooting still images

a C
b

Point the camera at an object, g[]

or

Z

When Auto save mode is "OFF", a
confirmation screen for saving appears.

Shooting moving pictures

a Z
b

Point the camera at an object, g [Rec/
Record] or

c

To stop shooting, g [Stop] or

Point

･

If FOMA terminal is left in a warm place or exposed
to direct sunlight for a long time, images to be shot
may be deteriorated.

･

If the FOMA terminal is closed or no key operations
are performed for approximately 2 minutes during
shooting stand-by, the camera ends.

･

Note that your hand may cover the light depending
on how you hold the terminal.

･

If the inside temperature of the FOMA terminal
becomes high because of heat during camera
operation, the recording or camera function may be
deactivated before the maximum recording time to
protect the FOMA terminal. In this case, wait until the
temperature of the FOMA terminal drops and use t he
camera function. This is normal.

Z

Zea

Save

Viewing still images/moving
pictures

Still images/moving pictures are saved to Data Box.

a mee

My picture or for moving picture,
motion/Movie

Data BoxeFor still image, a

c

e

Select a foldereSelect

i-

data

Shooting in various methods

To do Operation

Switch camera­mode

Quick shooting

Best-shot select

Continuous
mode Auto

On the shooting screen, m
[Setting]

eee

Select an item

On the still image shooting
screen,

m

[Setting]

m

On the still image shooting
screen,
[Setting]

m

camera at an object,

or

Ze

one image, etc.

On the still image shooting
screen,
[Setting]

m

camera at an object,

or

Z

efbe

[Close]

m

efce

[Close]ePoint the

Operate Save all, Save

m

efde

[Close]ePoint the

g

[]

g

[]

To do Operation

Panorama shoot

Art camera

HDR

Snap movie

Smooth Slo-Mo/
Fast-Mo

The following operations are available on the
shooting screen.

Displaying Data Box : a [List]
Turning on/off camera light : I [Light]
Brightness :
Zooming in/out :
Focus lock :
Keypad guide display:

On the still image shooting
screen,

m

[Setting]

m

camera at an object,

or

Overlapping transparent parts,
repeat
maximum shooting number is
reached

On the shooting screen, C
[Effect]
item
with

On the still image shooting
screen,
Select an item ("Yes"
"No"other than "OFF")
[Close]

On the moving picture
shooting screen,
[Setting]

m

On the moving picture
shooting screen,
[Effect]
item

j

h

n

efee

[Close]ePoint the

Ze

g

[]

ece

Select an

em

[Close]eAdjust

h

C

[Effect]

efbe

[Close]

ede

Select an

em

[Close]

0

g

or Z until

ede

or

em

m

C

[]

Enjoy

57

1Seg

Watching 1Seg

●

Using 1Seg

1Seg is a service provided by TV broadcasting
enterprises (stations), etc. A communication fee for
receiving video picture and sound is not required.
Contact NHK for details on your NHK viewing fees.
*

For viewing "Data broadcasting site", "i-mode site",
etc., packet communication fees are charged. Some
sites require information fees (i-mode pay sites).

*

For details of "1Seg" service, refer to the following
websites.

The Association for Promotion of Digital
Broadcasting

From a PC :

(In Japanese only)

From i-mode :

(In Japanese only)

●

1Seg is one of the broadcast services and a
different type of radio waves (airwaves) from that
of FOMA service is received. In the following
cases, reception condition may become bad or
reception may be unavailable.

･

Enjoy

･

･

*

http://www.dpa.or.jp/

http://www.dpa.or.jp/1seg/k/

Airwaves

A place far from the tower that the airwaves are
sent from
Mountain-ringed regions or a place between
buildings
Tunnel, underground or far back from a building

To receive stronger radio waves, try moving the
FOMA terminal away from or close to the body or
moving to another location.

58

Creating a channel list

(for the first-time creation)

To watch 1Seg, you need to create a channel list.

<Example> Searching for broadcasting stations and

a med

channels that can be received in your
current location (Auto setting).

CAMERA/TV/MUSICeb

1Seg

eg

Channel settinge"Yes"

e

"Auto setting"e"Yes"

For "Auto setting", perform the operation in the
digital terrestrial broadcasting service area.
Select "Use preset" to load broadcasting
stations and channels that are pre-registered
to the FOMA terminal.

b

Select an areae"Yes"

Watching 1Seg

a T

(1 sec. or more)

Viewing and operating the
watching screen

You can watch 1Seg in full screen, or divide the
screen to watch the data broadcasting.

When Switch active operations in Image & Effect
is "OFF", the following operations are available.

Adjusting volume : a [Low]/ I [High]

Starting Program guide i-αppli : C [EPG]
Selecting a channel : 1 - 9, *, 0,

Selecting the previous and next channel :
Recording still images :
Starting/Stopping a video recording : Z (1 sec. or

Switching the watching screen :
Showing/Hiding Subtitle : n (1 sec. or more)

･

Displaying key function help :

<Horizontal display (full screen)>

SD

#

Z

more)

Point

You can reserve watching/recording, set Time out,
Smooth image, 1Seg eco mode, etc., or output via
FM transmitter, Bluetooth, etc.

n

While watching,

or

h

me0

Watching/Recording
reservation

a med

1Seg

b m

Select timer option

When selecting "Manual reception" or "Manual
recording", you proceed to set the reservation
details such as time and date or channel.
Selecting "By program guide" activates
program guide i­watching or recording a program by selecting
it in the program guide i­information is saved and displayed on the
setting screen.

c C

When you set "Manual recording", a
confirmation screen for radio waves status at
start of recording appears. Select "Yes" or
"Yes (default)" to complete the registration.

Point

･

If "Record to:" in "Record setting" is set to "Auto
(phone first)" or "Auto (microSD first)" on the
recording reservation screen, the saving location
switches automatically according to free space or
savable number.

CAMERA/TV/MUSICeb

ed

TV timer list

[Submenu]ea Set new timer

eC

[Save]

α

ppli. When you reserve

α

ppli, the reservation

[Save]

Playing a recorded program

a mee

a folder

Data Boxe0 1SegeSelect

e

Select data

e

Enjoy

59

Music

MUSIC Player

You can play Chaku-uta full downloaded from a
site and Windows Media
imported from music CDs, the Internet, etc. to a
PC. And Uta-moji lyrics downloaded from a site
can be displayed on the player screen by setting
Link lyrics & song.

*

For details of MUSIC Player, refer to NTT
DOCOMO website. For Windows Media Player,
contact the manufacturer of your PC.

Saving WMA file on a PC to
microSD card

For connection to a PC, FOMA USB Cable
(optional) is required.

a meh

connection
mode

e

"Yes"

b

With Windows Media Player activated,
connect FOMA terminal to a PC using
USB cable

Enjoy

®

Audio (WMA) files

Settingeh External

ea

USB modeec MTP

e

Send WMA file from the PC

Playing music data

a med

MUSIC Player
playlist

The following operations are available on the
player screen.

Pausing/Playing : g [PAUSE/PLAY]
Adjusting volume : j or
Rewinding/Fast forwarding : h (1 sec. or

Jumping to the beginning of track :

Jumping to the previous track :

Jumping to the next track : r or D (1 sec. or

Adding to Quick playlist :

End : Z (1 sec. or more)

Point

･

When downloading music data from Internet
websites etc., check the use conditions.

･

Music data saved in FOMA terminal or microSD card
is allowed for personal use only. When using the
music data, take extreme care not to infringe
intellectual property rights of a third party such as
copyrights etc.

CAMERA/TV/MUSICec

e

Select a folder or

e

Select music data

more)

or more in play time,
more)

seconds in play time,
more)

more)

quickly

SD

l

or S (1 sec. or

Less than 2

l

or S (1 sec. or

Press Z twice

or

Z

2 seconds

60

i-αppli

i-αppli/i-Widget

i-αppli is a software for i-mode compatible
terminals, which updates the information of stock
price or weather automatically, or provides
games that can be played without connecting to
the network. i-Widget is a convenient function
that allows you to easily access frequently-used
contents and tools (Widget Appli) such as
calculator, clock, memo, stock price information,
etc.
Either i-

α

ppli or i-Widget can be downloaded
from i-mode site or sites provided by IPs
(Information Providers). For details, refer to NTT
DOCOMO website.

･

A packet communication fee may be separately
required.

･

When downloading or displaying i-Widget
screen, etc. a packet communication fee may be
separately charged.

･

When i-Widget screen is displayed, multiple
Widget Appli may communicate.

･

A packet communication fee for overseas use
differs from the one in Japan.

･

DOCOMO assumes no responsibility for the
information set in Osaifu-Keitai compatible i-

α

ppli (IC card).

･

If you delete stored i-αppli,
you can download the
software from "

応援団

supporters)" site.

"＠F

ケータイ応援団

mobile phone supporters)"

(as of April , 2014)
iMenu

電話メーカー

＠Fケータイ

(@F mobile phone

(@F

⇒ メニューリスト

(Mobile phone manufacturer) ⇒

QR code for site
access

(Menu list) ⇒

ケータイ

＠Fケータイ応援団

supporters) (In Japanese only)

*

The access method may be changed without previous
notice.

(@F mobile phone

Downloading

a

Display a siteeSelect i-αpplieAfter
completion of downloading, "Yes" or
"No"

Downloaded i-αppli is saved to "My folder" of
Software list. When Message i­downloaded, the folders for Message i­are automatically created in the folder list.

α

ppli is

Starting i-αppli

a I

(1 sec. or more)eSelect a folder

Select i-αppli

Point

Starting Osaifu-Keitai compatible i-αppli :

#ae

Select i-αppli

Starting GPS compatible i-αppli :

Select i-αppli

me

meiee

Starting i-Widget

a Te

Select Widget Appli

α

ppli

e

Enjoy

61

i-motion/Movie

Playing i-motion/movie

You can obtain i-motion/movie (images, sound,
etc) from sites or websites.

✜

Playable i-motion

Type Playing action

Standard
type (can be
saved

Streaming
type (cannot
be saved)

*

Some i-motion cannot be saved.

✜

Playable movies

Enjoy

Streaming
type (cannot
be saved)

62

While the i-motion data is
downloaded, it is played.

*

)

･

The downloaded i-motion can
be operated in the same way as
the i-motion which is played
after entire data is downloaded.

After the entire i-motion data is
downloaded, it is played.

While the i-motion data is
downloaded, it is played.

･

After the i-motion data is played,
it is deleted.

Type

Distribution

method

Real-time
distribution

On-demand
distribution

Playing action

The movie is
distributed in real
time.

･

Pausing/
Resuming play/
Moving play
position are
unavailable.

Distribute movies
that are prepared in
advance.

Downloading i-motion/Movie

a

Select i-motion/Movie while site or
website is displayed

Playback starts while data is downloaded or
when the download is completed.

b

"Save"eMove the cursor to a folder to
save

eC

For streaming type i-motion, select "Back" to
return to the site screen.

Point

･

Note that communication of a large amount of data,
such as downloading a movie, requires high packet
communication charges.

[OK]

Playing moving picture/i­motion

a mee

Movie
moving picture/i-motion

The following operations are available during
playback.

Adjusting volume : j or
Rewinding/Fast forwarding : h (1 sec. or

Pausing/Playing/Playing from the beginning

Stopping :

Data Boxec i-motion/

e

Select a foldereSelect a

more)

(while stopping) :

g

I

SD

Osaifu-Keitai

Using Osaifu-Keitai

■

Osaifu-Keitai

You can use Osaifu-Keitai service which allows
you to pay money or to use coupon only by
holding the FOMA terminal over the IC card
reader in stores etc. and "

(Kazashite-Link compatible service)" which

ビス

allows you to access website information etc. by
holding the terminal over the IC card reader.
Also, you can check deposit or balance of
electronic money, check point value, and take
measures against theft or loss using Omakase
Lock or IC card lock. For details, refer to NTT
DOCOMO website.

･

The data (including electronic money, points,
etc.) in the IC card may be lost or modified
because of the malfunction of FOMA terminal
(When we take your Osaifu-Keitai for repair etc.,
as we cannot take it with data remained, you
are required to erase the data by yourself). For
support such as reissuance, restoration,
temporary preservation or transfer of data,
confirm with Osaifu-Keitai compatible service
provider. For important data, be sure to use an
Osaifu-Keitai compatible service with backup
service.

･

If the data in the IC card is lost, modified or
damaged by any means related to Osaifu-Keitai
compatible service such as malfunction or
model change, DOCOMO assumes no
responsibility for the loss of data.

･

If FOMA terminal is stolen or misplaced,
immediately contact Osaifu-Keitai compatible
service provider for an advice.

かざしてリンク対応サー

■

ToruCa

ToruCa is an electronic card that can be obtained
from the FOMA terminal. It can conveniently be
used as leaflet, restaurant card, coupon ticket,
etc. You can obtain ToruCa from a site or an IC
card reader. It can be exchanged via mail, infrared
communication, or iC communication. For
details, refer to NTT DOCOMO website.

Steps for using Osaifu-Keitai

You can start Osaifu-Keitai compatible i-αppli to
credit money or check the balance or usage. You
can use the Osaifu-Keitai services compatible with
Osaifu-Keitai Web plug-in from a site.

a

Download Osaifu-Keitai compatible
i-

α

ppli as necessary

b

Make the initial settings of the Osaifu­Keitai compatible service

c

Hold mark of the FOMA terminal
over IC card reader

At this time, starting Osaifu-Keitai compatible
i-

α

ppli is not required.

Point

･

If IC card is not detected successfully when you hold

mark of the FOMA terminal over IC card reader,
try moving the FOMA terminal back, forth and
around.

･

You can disable IC card functions using "IC card

⇒

P38

lock".

More Convenient

63

i-concier

Using i-concier

i-concier is a service that Machi-chara (a
character on the stand-by display) supports your
life like a butler or concierge. It stores your
information about area of residence, memos,
schedule, ToruCa, phonebook, etc. and offers you
information that suits content of memos or
schedules, your living area, preferences, and
interest at the right time. It can offer information
related to memos, schedules and ToDo saved in
the FOMA terminal, automatically update
schedules and ToruCa, etc., and automatically
add useful information such as shop hours to the
phonebook. (In Japanese only) The stored
schedules or images can be shared with group of
your friends, family, etc. You can print the stored
images easily.

More Convenient

･

i-concier is a charged service requiring
subscription (Subscription is required
subscription of i-mode).

･

If you do not subscribe Data Security Service,
when you subscribe i-concier, you subscribe
Data Security Service, too.

･

A packet communication fee is separately
required to receive information except for some
information.

･

A packet communication fee is separately
required to use detail information.

･

To use i-concier overseas, International service
settings require to be set. For using
international roaming services, a packet
communication fee is charged for both
receiving and viewing detail information (it
differs from the charge in Japan).

･

Information fee may be additionally required
for some contents besides i-concier monthly
service fee.

64

･

Automatic updating i-schedule/memo/ToruCa/
phonebook, etc. requires a packet
communication fee separately.

･

For details, refer to NTT DOCOMO website.

Receiving information

Information is sent automatically.

a

Information is received

lights on in the status area with light or

ring alert for notification.

"

ひつじのしつじくん

(Butler Sheep)"

NTT DOCOMO

©

b

On the stand-by display, select a popup
message

Some pieces of information may have a
memo of schedule or ToruCa attached or
contain a link to a site. To display details,
select the icon.

Point

Displaying detail of received information on the stand-

by display :

(Information list)"

®

<Information reception screen>

e

Select a piece of information

me*e"インフォメーション一覧

e

Select a piece of information

Convenient tools

Shabette-Kensaku

You can use i-mode search by speaking a
keyword. (In Japanese only)

･

A packet communication fee is charged for
using.

a U

(1 sec. or more)

The FOMA terminal vibrates.
For the first activation, check the guidance
screen and select "Use (default)" or "Use".

b

Speak search keyword within 10
seconds

eg

The i-mode site is connected and search
results appear.

Point

･

Speak clearly with natural conversation speed.

･

Depending on the environment or way of speaking,
recognition result may vary.

[Fix]

Convenient tools

Voice quick start

When you do not know a desired menu of function
or you want to activate the function quickly, the
function can be activated by voice sound input
from the stand-by display. (In Japanese only)

a n

(1 sec. or more)

For the first activation, on the guidance
screen, select "

b

When "

★★

(Please speak★★waiting for your

voice
name toward the microphone within 10

seconds.

When a message "
(Speak again)" appears, press g and speak
again.
When the voice input is recognized, the
function activates. If the function is not

identified, the keyword list of
(Guide) appears.

Point

･

Speak clearly with natural conversation speed.

･

Depending on the environment or way of speaking,
recognition result may vary.

･

You can speak function name (電卓 (Calculator),

(1Seg), etc.), keyword (計算 (calculation),

セグ

(TV),

アドレス交換

combination of keywords (

メール 問合せ

to Mr.

○○

* Name registered to the phonebook

利用する

(Use)" or press C.

それではどうぞ ★★音声受付中

★★

)" appears, speak a function

もう一度お話ください

使いかたガイド

(address exchange), etc.) or

(mail check),

), etc.) to activate the function.

写真 見る

○○さん*にメール

テレビ

(view photo),

(mail

ワン

More Convenient

65

Convenient tools

Schedule

Manage memos by Schedule or check a
downloaded i-schedule. (In Japanese only)
The view and function of schedule varies by the
schedule type. "Normal" in which you can manage
the schedules linking with i-concier or the memo
list is described here.

Registering note from the
schedule

a mef

[Submenu]

b

Set required items

Showing/Hiding hint : C [Hint ON/OFF]

You can select entry options from the hint

More Convenient

displayed in "
"

どこで？

whom?)", "
(Attachment)" field.

Point

Saving quickly from the stand-by display (Quick

schedule) :

and time to save a schedule (for 10:00 on June 27,
enter "06271000")

Checking a schedule

a mef

date

Toolee Schedule

ea

New entry

eI

[Save]

シール

(Seal)", "

(Where?)", "

共有設定

On the stand-by display, enter the date

ed

いつ？

だれと？

(Share setting)", "添付

(With

Toolee ScheduleeSelect

e

Select a memo

em

(When?)",

Convenient tools

Alarm

You can also set to activate 1Seg after sounding
alarm.

a mef

number
set required items

Point

･

In "Snooze (Snz)", set the sound intervals for 30
minutes.

･

Alarm stops or starts snooze if no operations are
made for approximately 1 minute, pressing a key
other than
FOMA terminal.

Toolec AlarmeSelect a

eh

to switch the screen to

eC

[Set]

f, T

and D, double-tapping the

Convenient tools

Bar code reader

You can read and use information of JAN code,
QR code, NW7 code, and CODE39 code.

a mef

Move the camera over a bar code

When scanning is completed, a confirmation
sound is heard and the scanned data appears.

Point

･

When a bar code is hard to read, press C to switch
to the shutter mode, or adjust the distance between
the code and camera, angle, or direction.

Toolea Bar code reader

e

66

Convenient tools

Bluetooth

You can establish a wireless connection between
FOMA terminal and a Bluetooth device. For
operations of the Bluetooth device, refer to the
operation manual of your Bluetooth device.

*

Wireless communication is not guaranteed for all
Bluetooth devices.

✜

Compatible version

Bluetooth standard Version 2.1+EDR

✜

Functions available with Bluetooth

･

Wireless communication using Bluetooth Headset
F01 (optional) or handsfree communication using
a Bluetooth compatible car navigation
(commercially available)

･

Wireless playback or remote control operation of
voice sounds or music using Wireless Earphone
Set 02 (optional) or a Bluetooth audio device
(commercially available)

･

Character entry using Bluetooth compatible
keyboard (commercially available)

･

Packet communication or 64K data transmission
using a Bluetooth compatible PC

･

Sending or receiving data such as profile,
phonebook entries, notes, mails, bookmarks,
ToruCa, LCS clients, image in JPEG format to or
from other Bluetooth devices

･

Receiving a versus game with other terminal or
measured data from a Bluetooth compatible
health check device (commercially available)

Registering Bluetooth devices

Set a Bluetooth device to registration stand-by
mode in advance.

a mef

Toole"Bluetooth"ee

Register new dev

After Bluetooth device is searched, the
registering new device screen appears.

b

Select a Bluetooth device to register
Enter the Bluetooth passkey

Point

･

For Bluetooth passkey, see the instruction manual of
the Bluetooth device. When registering Wireless
Earphone Set 02 or Bluetooth device compatible with
Bluetooth standards Ver.2.1, Bluetooth passkey is
not required (it is required for some Bluetooth
devices).

Connecting with registered
Bluetooth devices

a mef

cnnct/discnct
device to connect

Toole"Bluetooth"ed List/

e

Select a Bluetooth

e

More Convenient

67

Convenient tools

Wireless LAN

You can make Wireless LAN connection in Access
point mode (Base unit) or Client mode (Sub unit).

･

Note that using Wireless LAN makes battery
consumption faster.

Access point (main)

You can use the FOMA terminal as access point
(Base unit) of Wireless LAN.

Access point settings

Set the same security method as a Wireless LAN
device.

a mef

point (main)

More Convenient

b

Set required items

Setting Access point (APN)

Set an access point to use for external connection
in AP mode.
mopera U is registered by default.

a mef

point (main)

b

Select an access point (APN)
[Save]

Toole"WLAN"eb Access

ef

Access point settings

eC

[Save]

Toole"WLAN"eb Access

ec

Access points (APN)

eC

Setting access point

a mef

point (main)
local mode ON

When Notes on use appears, select "Use".

b

Set connection on the Wireless LAN

Toole"WLAN"eb Access

ea

AP m ode ON or b AP

e

"Yes"

device

c

Connect the FOMA terminal and
Wireless LAN

Client mode (Sub unit)

Connect to an access point for home network or
Public wireless LAN service as a client (Sub unit).

Setting a new network

Register access point information to the FOMA
terminal.

･

For information about an access point, see the
instruction manual of the access point etc.

a mef

mode (sub)

b

Select a method for registering access
point in the FOMA terminal

Connecting access point

a mef

mode (sub)

Toole"WLAN"ea Client

ec

Network setting

Toole"WLAN"ea Client

ea

WLAN mode ON

68

Data Management

Using microSD card

You can save still images, moving pictures,
melodies, etc. or backup data of phonebook,
schedule, etc. in microSD card.

･

The F-07F supports commercially available
microSD card of up to 2 GB, and microSDHC
card of up to 32 GB (As of April, 2014). For the
latest information on the operation check, see
the followings. The information shown is the
result of the operation check and actual
operations are not guaranteed for all microSD/
SDHC cards. For microSD card other than
shown here, contact each manufacturer of the
microSD card.

From i-mode :

⇒ ケータイ電話メーカー

manufacturer)
mobile phone supporters)

応情報

(In Japanese only)

From PC :

⇒ スマートフォン・タブレット・携帯電話

(Smartphone/Tablet/Mobile phone)

情報一覧
対応状況、

microSDHC support information) (In Japanese
only)

iMenu

⇒メニューリスト

(Mobile phone

⇒ ＠Fケータイ応援団

(Memory card support information)

QR code for site
access

FMWORLD (http://www.fmworld.net/)

(Support information list)⇒ microSD

microSDHC

対応状況

(Menu list)

(@F

⇒ メモリーカード対

⇒ サポート

(microSD/

*

The access method may be changed without
previous notice.

✜

Precautions on using microSD card

･

The data saved from another device such as a PC
may not be displayed or played in FOMA
terminal. And the data saved from FOMA terminal
may not be displayed or played in other device.

Installing

a

Turn FOMA terminal OFF and remove
the battery pack

b

Insert the microSD card slowly into the slot
with metal contacts side down (as shown
below), and insert it further until it clicks

*

To remove the microSD card, push it lightly to
pop it out, and then pull it out.

Formatting

Format microSD card with FOMA terminal before using.

a mef

[Format]

Point

･

Formatting microSD card deletes the data in the card.

Toole* microSD

e

Authenticatee"Yes"

eC

More Convenient

69

Data Management

Exchanging data between FOMA terminal and microSD card

b m

Copying images to microSD
card

a mee

Select a foldereMove the cursor to
data

When the folder list of microSD card appears,
select "

b m

c

method

Select image to copy selected item
authenticate to copy all data in a folder.

c

"Yes"

More Convenient

Move the cursor to a folder to copy an item
Press C.

Point

･

If you select "b Move → microSD" in Step 2, you can
move data to the microSD card.

･

You cannot move or copy the data that is inhibited to
output from FOMA terminal.

Data Boxea My picture

→

phone".

[Submenu]ee Move/Copy

Copy to microSDeSelect copying

Copying images to the FOMA
terminal

a mef

box
Move the cursor to data

70

Toole* microSDea Data

ea

My PictureeSelect a folder

e

eC

e

,

e

e

[Submenu]ee Move/Copy

c

Copy to the phoneeSelect copying

method

Select image to copy selected item
authenticate to copy all data in a folder.

c

Move to the cursor to a folder
[Confirm]

When copying one item, omit pressing "Yes".

Point

･

If you select "b Move to phone" in Step 2, you can
move data to the FOMA terminal.

e

"Yes"

Backing up at once

You can back up phonebook entries, notes, mails,
bookmarks, set item data all at once in the
microSD card. Data is overwritten for the second­time backup or later.

a mef

Backup/Restore
microSD

b

Authenticatee"Yes"

When phonebook is not saved, omit Step 3.

c

"Yes" or "No"

Point

･

Some restrictions apply, such as moving pictures
saved in phonebook or the part of the attachment
files in excess of 100 Kbytes are not backed up.

･

Select "b Restore to phone" at the end of Step 1 to
overwrite data in the FOMA terminal with data
collectively backed up in the microSD card.

Toole* microSDeg

ea

Backup to

e

eC

eC

,

Data Management

Infrared communication/iC transmission

You can send/receive data to/from devices such as
FOMA terminal supporting infrared
communication function or iC transmission
function.

Infrared

data port

15°

15°

Approx. 20 cm

or less

Infrared communication iC transmission

Face
marks to
each other
* Approx.

1

cm or less

in distance

Point

･

When sending/receiving all data items, the sender
and receiver need to determine a 4-digit
authentication password in advance. For infrared
communication, the receiver's terminal must be
ready for communication first.

･

When sending/receiving all data items, the data
saved in the receiver (included phonebook entries or
notes with secret attribute, protected mail) is deleted,
and the newly received data is saved. However, for
some receiving terminals, when sending all infrared
data, image, moving picture, melody, document
(PDF data) and Decome-Template are added.
Folder names or order of data may differ from the
ones of sender.

･

While charging, sending data by iC transmission is
unavailable.

To do Operation

Sending an item
via infrared
communication/
iC transmission

Move the cursor to a
phonebook entry
[Submenu]

ae

"Yes"
<Example>
Phonebook entry

Sending all items
via infrared
communication/
iC transmission

mefdeb

Select an item to send
AuthenticateeEnter an
authentication password
"Yes"

Receiving an
item via infrared
communication

Receiving an
item via iC
transmission

Receiving all
items via
infrared
communication

mefdaae

Send data from a sender
After receiving, "Yes"

With the stand-by display on a
receiver, place
to each other
sender

e

mefdabe

Authenticate
authentication password
"Yes"eSend data from a
sender

Receiving all
items via iC
transmission

With the stand-by display on a
receiver, place
to each other
sender

e

an authentication password
Place the marks close to
each other

e

em

or

or

ce

be

ehea

e

e

"Yes"

e

e

marks close

e

Send data from a

After receiving, "Yes"

e

Enter an

e

"Yes"

marks close

e

Send data from a

AuthenticateeEnter

e

"Yes"

More Convenient

e

71

Data Management

Connecting to a PC

You can connect FOMA terminal to a PC to
transfer WMA files or images in the microSD card.
Also, connecting to the Internet for data
communication is available.

･

FOMA USB Cable with Charge Function 02
(optional) or FOMA USB Cable (optional) is
required.

･

To perform data transfer using data
communication or DOCOMO keitai datalink,
install FOMA communication configuration
(driver) on a PC. For details, refer to "Manual for
PC Connection".
"FOMA communication configuration file
(driver)" and "Manual for PC Connection" can be
downloaded from NTT DOCOMO website.

More Convenient

https://www.nttdocomo.co.jp/support/
(In Japanese only)

USB mode

From a PC, you can operate data in a microSD card
in FOMA terminal.

･

When USB mode is set to "microSD mode" or "MTP
mode", installation of FOMA communication
configuration file (driver) is not necessary.

a meh

connection
mode

Communication mode :

72

Settingeh External

ea

USB modeeSelect a

communication, 64K data communication
or data transfer by connecting to a PC.

Set for packet

microSD mode :

microSD card in FOMA terminal as a drive
and operating the data by PC operation.

MTP mode :

microSD card using Windows Media Player.

b

"Yes"

Set for recognizing the

Set for music data transfer to

DOCOMO Connection Manager

DOCOMO Connection Manager is convenient
software to use DOCOMO's data communication.
You can easily make a PC setting according to
your subscription status and check an estimate of
data communication volume or usage fees by the
charge counter function. For details, refer to NTT
DOCOMO website.
https://www.nttdocomo.co.jp/support/utilization/
application/service/connection_manager/
(In Japanese only)

DOCOMO keitai datalink

DOCOMO keitai datalink is a software for backing up
phonebook, mail and other data in your mobile
phone to a PC and editing them. It can be
downloaded from NTT DOCOMO website. For details
and downloading, refer to the following website.
http://datalink.nttdocomo.co.jp/ (In Japanese
only)
For details including downloading procedures, data
that can be transferred, operating environments,
installing procedures and operations, refer to the
website above. For operations after installation, see
Help in the software.

Support

Troubleshooting

Check for the necessity of software update first, and update the software if necessary. ⇒P77
When checking the following items not to improve the state, contact "Repairs" on the last page of this
manual (in Japanese only) or DOCOMO-specified repair office.

✜

Power supply and charging

●

FOMA terminal cannot be turned ON.

･

Is the battery pack installed correctly?

･

Is the battery exhausted?

●

The FOMA terminal cannot be charged (the light
does not turn on while charging).

･

Is the battery pack installed correctly?

･

Are the adapter and FOMA terminal set correctly?

･

Is the AC adapter connector securely inserted to
FOMA terminal or the desktop holder that came with
the terminal when you use AC adapter (optional)?

･

Is AC adapters power plug or cigarette lighter plug
inserted to the outlet or cigarette lighter socket correctly?

･

Is the charging jack of FOMA terminal dirty when
you use desktop holder? If it is dirty, clean with a
dry cotton swab.

･

If you call or perform communication or operate
other function for a long time while charging, the
temperature of the FOMA terminal is raised and
the light may turn off. When temperature is high,
charging stops for safety. After using, wait until
the temperature of the FOMA terminal drops and
retry charging.

●

Charging cannot be completed (Battery level gets
low even while the battery is charged)

Charging may not be completed during a call or
communication. Or, if you start charging while
watching/recording 1Seg, playing moving picture/i­motion, activating Music player, or operating i­the battery level may get low depending on charging
adapter and charging may not be completed. It is not
abnormal condition of the FOMA terminal. To
complete charging, terminate terminal operations
and then charge the battery.

α

✜

Terminal operation

●

Turning the power off or restarting automatically
happens.

If the jack of battery pack is dirty, the contact may
become poor and the power may shut OFF. If it is
dirty, clean with a dry cotton swab.

●

No operations are performed by pressing keypad.

Have you activated All lock, Omakase Lock, Side key
hold, or Auto-key lock?

●

The operation time provided by the battery pack is
short.

･

Is your terminal left for a long time under the state
of out of service area? Out of service area, much
power is consumed to search available radio
waves.

･

The operation time provided by the battery pack
varies by the operating environment and battery
pack's deterioration.

･

The battery pack is a consumable part. Each time it
is charged, time available with each charging
reduces. Even the full charge state, when the
operation time is too short, purchase a new
battery pack of the specified type.

●

The docomo mini UIM card is not recognized.

Is the docomo mini UIM card installed in the right
direction?

●

FOMA terminal etc. become hot while operating/
charging.

ppli,

While operating or charging, or if you use i-αppli,
videophone call, 1Seg watching, etc. for a long time
while charging the battery, FOMA terminal, battery
pack and adapter may become hot. There is no
problem about operations and continue to use it.

Others

73

●

The clock is not on time.

The clock time may become wrong while turning on
the power for a long time. Set Auto time adjust of
Date and time setting to "ON" and turn the power off
and on in a place with strong radio wave conditions.

✜

Calls

●

Calls are not connected (Even when moving, "圏外
(out of service area)" does not disappear or
although radio waves are enough, making/
receiving calls is unavailable).

･

Turn the power off and on, or remove and attach
the battery pack or the docomo mini UIM card.

･

Even when the radio wave condition is "Not out of
service area"/" appears for radio wave
conditions", due to the type of radio waves,
making/receiving calls may be unavailable. Move
to call again.

･

Is Call rejection setting or 3G/GSM setting set?

･

Due to the crossing of radio waves, at the crowded
public places, calls/mails are crossed and the
connection status may not be good. In this case,
"Please wait for a while" appears and the caller
hears a busy tone. Move to other place or call
again at other time.

●

Calls cannot be made using the keypads.

Have you activated All lock, Omakase Lock, Self
mode, Keypad dial lock, Auto-key lock or Call/Mail of
Function lock under Kid-safe mode?

Others

✜

Camera

●

Still images or moving pictures taken with the
camera are blurry

･

Make sure that the camera lens is not obscured or
stained.

･

Use Auto for Shoot by scene.

･

Auto focus (Manual) or Tracking focus can also be
used to focus.

･

When shooting an object at a close range, set AF
mode to "Close-up", and when shooting people,
switch to "Face priority AF".

･

Set Fix camera shake and shoot.

✜

Osaifu-Keitai

●

Osaifu-Keitai function is unavailable.

･

When removing the battery pack, IC card functions
are unavailable regardless of the IC card lock
settings.

･

Have you activated Omakase Lock or IC card lock?

･

Do you place mark of FOMA terminal over IC
card reader?

74

Support

Warranty and After-Sales Service

Warranty

･

FOMA terminal is provided with a written
warranty. Make sure that you receive it. Check
the written contents and items such as "

名・お買い上げ日

purchase)" and keep it in a safe place. If it does
not contain the necessary information,
immediately contact the shop where you bought
it. The warranty is valid for a period of one year
from the date of purchase.

･

This product and all accessories are subject to
change, in part or whole, for the sake of
improvement without prior notice.

(Shop name/date of

販売店

After-Sales Service

✜

When problems occur

Before requesting repair, read the section on
"Troubleshooting" in this manual or in "

イド

(Guide)" installed in FOMA terminal (in
Japanese only). If the problem still persists, contact
"Repairs" on the last page of this manual (in
Japanese only).

✜

If the result of inquiries indicates that a
repair is required

Take your FOMA terminal to DOCOMO-specified
repair office. Be sure to check the opening hours of
the office before you go. Note that, repair may take
longer time depending on the state of damage.

使いかたガ

In the warranty period

･

FOMA terminal is repaired at no charge subject to
the conditions of the warranty.

･

The warranty must be presented to receive
warranty service. The subscriber is charged for
the repair of items not covered in the warranty or
repairs of defects resulting from misuse (damage
of the display/connector, etc.), accident, neglect,
etc. even during the warranty period.

･

The subscriber is charged even during the
warranty period for the repair of failures caused
by the use of devices or consumable items that
are not DOCOMO-specified.

Repairs may not be possible in the following cases.

･

When corrosion due to moisture, condensation,
perspiration, etc. is detected, or if any of the
internal boards are damaged or deformed
(repairs may not be possible if external
connection jack (earphone/microphone jack) or
display is damaged, or the terminal outer case is
lifted)

*

Even in case that a repair is possible, since those conditions
are outside the range of the warranty, a repair is charged.

After expiration of the warranty

All repairs that are requested are charged.

Replacement parts

Replacement parts (parts required to maintain the
product functions) are basically kept in stock for at
least 4 years after termination of production.
However, repair may not be possible due to lack of
repair parts etc.

Others

75

✜

Notes

･

Do not modify FOMA terminal or its accessories.

- Repair may be refused depending on the nature
of modification. The following cases may be
regarded as modifications.

- A sticker etc. is put on the display or keypad

part

- FOMA terminal is embellished with adhesive

material etc.

- Exteriors are replaced with other than

DOCOMO's genuine parts

- Repair of failures or damage caused by
modification is charged even during the
warranty period.

･

Do not remove any inscription stickers attached to
FOMA terminal.
The inscription sticker plays a role of certification
for specific technical standards. If confirmation of
the inscription sticker's content is impossible
because it is intentionally removed or changed,
determination of whether specific technical
standards are satisfied cannot be made.
Therefore, repair may be refused.

･

Function settings and information may be cleared
(reset) by malfunctions, repair or other handling
of FOMA terminal. Should that happen, set up the
functions again.

･

If repair is executed, MAC address for Wireless
LAN and Bluetooth address may be changed
regardless of malfunction part.

Others

･

Magnetic components are used in the earpiece,
speaker, etc. of the FOMA terminal. Do not allow
cash cards or other devices that are vulnerable to
magnetism to come into contact with the phone.

･

This FOMA terminal is waterproof. However, if
inside of the terminal gets wet or moist, turn the
power off, remove the battery pack immediately,
and bring the terminal to a repair office as soon
as possible. However, repair may not be possible
depending on the condition of FOMA terminal.

76

Support

Error info send set.

Make settings to send error information to
DOCOMO if an error occurs on your terminal.

･

Information is sent at night. Packet
communication fee is not charged.

･

Personally identifiable information is not
included.

･

Some types of errors may not be recorded.

a meh

f
a

Settingei Other setting
Error info send set.eAuthenticate
ON or b OFF

e

e

Support

Updating software

This function allows you to connect the network
and check if software in the FOMA terminal needs
to be updated, if software update is necessary,
download a part of software using packet
communication and update the software.
When software update is required, information is
posted in "
DOCOMO website or iMenu (in Japanese only).
Software may be updated in 3 methods: "Auto­update", "Immediate update" and "Reserved
update".

*

✜

･

･

･

･

お客様サポート

(user support)" on NTT

Software update can be done even when various
data, such as a phonebook registered in FOMA
terminal, camera images, downloaded data, are
remaining; note that data protection sometimes
cannot be secured according to the conditions of
your FOMA terminal (such as malfunction, damage,
or water leak). DOCOMO recommends backing up
necessary data. However some data such as
downloaded data may not be backed up.

When updating software

Do not remove the battery pack while updating
software. The update may fail.
Software update should be done with battery fully
charged.
Software update (downloading or rewriting) may
take time.
Making/Receiving calls, communications
functions and other functions are disabled during
software update (Only incoming voice calls can
be answered while downloading).

･

It is recommended that software update be
executed in good radio wave conditions with
three bars of the antenna icon displayed and the
terminal not moved. If radio wave conditions
become weaker during software download or the
download is stopped, retry software update in a
place with strong radio wave conditions.

･

When updating software, your private
information concerning FOMA terminal (model,
serial number, etc.) is automatically sent to the
server (the server for software update managed
by DOCOMO). DOCOMO does not use the sent
information for purposes except software update.

･

When software update has failed, "Rewrite failed"
appears and all operation becomes unavailable.
In that case, please bring the FOMA terminal to
DOCOMO-specified repair office.

Updating

From the stand-by display, select (update
notification icon), or start from the menu.

<Example> Starting from the update notification

a ge

b

<Example> Starting from the menu

a meh

icon

Select (update notification

icon)

e

"Yes"eAuthenticate

The check result appears

When update is necessary, "Update is needed"
appears. Select "Now update" or "Reserve".

Settingei Other setting

e

Software updateeAuthenticate

e

"Update"

Others

e

77

Support

Scanning function (Security Scan)

For the data or programs that are imported to
FOMA terminal, this function detects data and
deletes data or inhibits activation of applications
that may cause troubles.

･

The Scanning function provides a certain
countermeasure against invasion of data which
causes some trouble in the mobile phone, when
viewing website, receiving messages, etc. Note
that, if pattern definition corresponding to
specific troubles has not been downloaded to
the mobile phone or such pattern definition
does not exist, this function cannot prevent
those troubles from occurring.

●

Updating pattern definitions

Update pattern definition first, then keep the
pattern definition up-to-date.

Set auto-update

You can set FOMA terminal so that pattern
definitions can be automatically updated.

a meh

Others

f

update
"OK"

When the Auto-updating pattern definitions is
executed, or appears on the stand-by
display.

Settingef Lock/Security

Scanning functioneb Set auto-

e

"Enable"e"Yes"e"Yes"

e

Scan result

Warning level Actions

[0] Operation may
not run properly.

[1] Operation may
not run properly.
Cancel operation?

[2] Operation may
not run properly.
Canceling
operation.

[3] Operation may
not run properly.
Delete data?

[4] Operation may
not run properly.
Deleting data.

e

*

Selecting "Detail" on each screen displays a list of names
of the detected problem elements. When 6 or more
problem elements have been detected, the names of the
6th and subsequent problem names are omitted.

"OK" :

Continue processing of

the started application

"Yes" :

Stop processing of the
application that may cause
troubles

"No" :

Continue processing of

the started application

"OK" :

Stop processing of the
application that may cause
troubles

"Yes" :

Delete data that may

cause troubles

"No" :

Stop processing of the
application that may cause
troubles

"OK" :

Delete data that may

cause troubles

78

Support

Options and related devices

Combining FOMA terminal with optional
accessories supports a wide variety of uses from
personal use to business use. Some products are
unavailable depending on the area.
For details, contact a sales outlet such as docomo
Shop. For details about the optional devices, refer
to the instruction manual for each device.

･

Battery Pack F22

･

Back Cover F82

･

FOMA AC Adapter 01/02

･

Desktop Holder F33

･

Carry Case L 01

･

Carry Case 02

･

Flat-plug Stereo Earphone Set P01

･

Flat-plug Earphone/Microphone with Switch

*2

*2

P01

/P02

･

Earphone Plug Adapter for External connector
terminal 01

･

Earphone Plug Adapter 01

･

Stereo Earphone Set 01

･

Earphone/Microphone 01

･

FOMA USB Cable with Charge Function 02

･

In-Car Holder 01

･

FOMA DC Adapter 01/02

･

In-Car Hands-Free Kit 01

･

FOMA In-Car Hands-Free Cable 01

･

FOMA USB Cable

･

FOMA Dry Battery Adapter 01

･

FOMA Portable Charging Adapter 01/02/03

･

Earphone Plug Adapter P001

･

Earphone/Microphone with Switch P001*5/

*5

P002

･

Wireless Earphone Set P01

*1

*2

*4

*3

*2

･
･
･
･
･
･
･
･

*1

*2

*3

*4

*5

*3

*6

Wireless Earphone Set 02/03
Bluetooth Headset F01
AC adapter for Bluetooth Headset F01
FOMA AC Adapter 01 for Global use
FOMA Indoor Booster Antenna
FOMA Indoor Booster Antenna (Stand Type)
Bone conduction microphone/receiver 01*2/02
FOMA eco Solar Panel 01

*1

*6

When using FOMA terminal overseas, use the
adapter plug that is suitable for use in your travel
destination. Also, do not charge the battery with a
transformer for overseas travel.
Earphone Plug Adapter for External connector
terminal 01 is required to connect to F-07F.
If you use USB HUB, operations may not be
performed correctly.
FOMA In-Car Hands-Free Cable 01 is required
to charge F-07F.
Earphone Plug Adapter for External connector
terminal 01 and Earphone Plug Adapter P001 are
required to connect to F-07F.
Use this only in Japan.

*6

Others

79

Appendix

Specific Absorption Rate (SAR) of Mobile Phones

This model F-07F mobile phone complies with
Japanese technical regulations and international
guidelines regarding exposure to radio waves.
This mobile phone was designed in observance of
Japanese technical regulations regarding exposure to
radio waves (
recommended by a set of equivalent international
guidelines. This set of international guidelines was set
out by the International Commission on Non-Ionizing
Radiation Protection ( ICNIRP), which is in collaboration
with the World Health Organization (WHO), and the
permissible limits include a substantial safety margin
designed to assure the safety of all persons, regardless
of age and health condition.
The technical regulations and international guidelines
set out limits for radio waves as the Specific
Absorption Rate, or SAR, which is the value of
absorbed energy in any 10 grams of tissue over a 6­minute period. The SAR limit for mobile phones is 2.0
W/kg. The highest SAR value for this mobile phone
when tested for use at the ear is 0.878W/kg, when wor n
on the body, is 0.382W/kg
differences between the SAR levels for each product,
but they all satisfy the limit.
The actual SAR of this mobile phone while operating
can be well below that indicated above. This is due to
automatic changes to the power level of the device to
ensure it only uses the minimum required to reach the

Others

network. Therefore in general, the closer you are to a
base station, the lower the power output of the device.
This mobile phone can be used in positions other than
against your ear. Please keep the mobile phone farther
than 1.5 cm away from your body by using such as a
carrying case or a wearable accessory without
including any metals. This mobile phone satisfies the
technical regulations and international guidelines.
The World Health Organization has stated that "a large
number of studies have been performed over the last
two decades to assess whether mobile phones pose a

80

*1

) and limits to exposure to radio waves

*2

. There may be slight

potential health risk. To date, no adverse health effects
have been established as being caused by mobile
phone use."
Please refer to the WHO website if you wo uld like more
detailed information.
http://www.who.int/docstore/peh-emf/publications/
facts_press/fact_english.htm
Please refer to the websites listed below if you would
like more detailed information regarding SAR.
Ministry of Internal Affairs and Communications Website:
http://www.tele.soumu.go.jp/e/sys/ele/index.htm
Association of Radio Industries and Businesses
Website: http://www.arib-emf.org/index02.html
(In Japanese only)
NTT DOCOMO, INC. Website: https://
www.nttdocomo.co.jp/english/product/sar/
FUJITSU LIMITED Website: http://www.fmworld.net/
product/phone/sar/ (In Japanese only)

*1

Technical regulations are defined by the Ministerial Ordinance
Related to Radio Law (Article 14-2 of Radio Equipment
Regulations).

*2

Not including other radio systems that can be simultaneously
used with FOMA

Declaration of Conformity

The product "F-07F" is declared to conform with the
essential requirements of European Union Directive
1999/5/EC Radio and Telecommunications Terminal
Equipment Directive 3.1(a), 3.1(b) and 3.2. The
Declaration of Conformity can be found on http://
www.fmworld.net/product/phone/doc/ (In Japanese
only).

This mobile phone complies with the EU requirements
for exposure to radio waves.
Your mobile phone is a radio transceiver, designed and
manufactured not to exceed the SAR
exposure to radio-frequency(RF) energy, which SAR
value, when tested for compliance against the
standard was 0.56W/kg for HEAD and 0.446W/kg for
BODY. While there may be differences between the

*

levels of various phones and at various

SAR
positions, they all meet
exposure.

* The exposure standard for mobile phones

employs a unit of measurement known as the
Specific Absorption Rate, or SAR.

** The SAR limit for mobile phones used by the

public is 2.0 watts/kilogram (W/Kg) averaged over
ten grams of tissue, recommended by The
Council of the European Union. The limit
incorporates a substantial margin of safety to
give additional protection for the public and to
account for any variations in measurements.

*** Tests for SAR have been conducted using

standard operation positions with the phone
transmitting at its highest certified power level in
all tested frequency bands. Although the SAR is
determined at the highest certified power level,
the actual SAR level of the phone while operating
can be well below the maximum value. This is
because the phone is designed to operate at
multiple power levels so as to use only the power
required to reach the network. In general, the
closer you are to a base station antenna, the
lower the power output.

***

*

limits** for

the EU requirements for RF

Federal Communications
Commission (FCC) Notice

*

･

This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions :

a

this device may not cause harmful interference, and

b

this device must accept any interference received,
including interference that may cause undesired
operation.

･

Changes or modifications made in or to the radio
phone, not expressly approved by the manufacturer,
will void the user's authority to operate the equipment.

･

The device complies with 15.205 of the FCC Rules.

FCC RF Exposure Information

This model phone meets the U.S. Government's
requirements for exposure to radio waves.
This model phone contains a radio transmitter and
receiver. This model phone is designed and manufacture d
not to exceed the emission limits for exposure to radio
frequency (RF) energy as set by the FCC of the U.S.
Government. These limits are part of comprehensive
guidelines and establish permitted levels of RF energy for
the general population. The guidelines are based on
standards that were developed by independent scientific
organizations through periodic and thorough evaluat ion
of scientific studies.
The exposure standard for wireless mobile phones
employs a unit of measurement known as the Specific
Absorption Rate (SAR). The SAR limit set by the FCC is 1.6
W/kg. Tests for SAR are conducted using standard
operating positions as accepted by the FCC with the
phone transmitting at its highest certified power level in
all tested frequency bands. Although the SAR is
determined at the highest certified power level, the actual
SAR level of the phone while operating can be well below
the maximum value. This is because the phone is
designed to operate at multiple power levels so as to use
only the power required to reach the network. In general,
the closer you are to a wireless base station antenna, the
lower the power output level of the phone.

Others

81

Before a phone model is available for sale to the public,
it must be tested and certified to prove to the FCC that
it does not exceed the limit established by the U.S.
government-adopted requirement for safe exposure.
The tests are performed on position and locations (for
example, at the ear and worn on the body) as required
by FCC for each model. The highest SAR value for this
model phone as reported to the FCC, when tested for
use at the ear, is 0.57W/kg, and when worn on the
body, is 0.67W/kg. (Body-worn measurements differ
among phone models, depending upon available
accessories and FCC requirements).
While there may be differences between the SAR levels
of various phones and at various positions, they all
meet the U.S. government requirements.
The FCC has granted an Equipment Authorization for
this model phone with all reported SAR levels
evaluated as in compliance with the FCC RF exposure
guidelines. SAR information on this model phone is on
file with the FCC and can be found under the
Equipment Authorization Search section at http://
www.fcc.gov/oet/ea/fccid/ (please search on FCC ID
VQK-F07F).
For body worn operation, this phone has been tested
and meets the FCC RF exposure guidelines. Please use
an accessory designated for this product or an
accessory which contains no metal and which
positions the handset a minimum of 1.5 cm from the
body.

Others

*

In the United States, the SAR limit for wireless mobile phones
used by the general public is 1.6 Watts/kg (W/kg), averaged
over one gram of tissue. SAR values may vary depending upon
national reporting requirements and the network band.

This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can
radiate radio frequency en ergy and, if not installed and
used in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference will
not occur in a particular installation.
If this equipment does cause harmful interference to
radio or television reception, which can be determined
by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or
more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment
and receiver.

-

Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV
technician for help.

82

Important Safety Information

AIRCRAFT

Switch off your wireless device when boarding an
aircraft or whenever you are instructed to do so by
airline staff. If your device offers flight mode or similar
feature consult airline staff as to wheth er it can be used
on board.

DRIVING

Full attention should be given to driving at all times
and local laws and regulations restricting the use of
wireless devices while driving must be observed.

HOSPITALS

Mobile phones should be switched off wherever you
are requested to do so in hospitals, clinics or health
care facilities. These requests are designed to prevent
possible interference with sensitive medical
equipment.

PETROL STATIONS

Obey all posted signs with respect to the use of
wireless devices or other radio equipment in locations
with flammable material and chemicals. Switch off
your wireless device whenever you are instructed to do
so by authorized staff.

INTERFERENCE

Care must be taken when using the phone in close
proximity to personal medical devices, such as
pacemakers and hearing aids.

Pacemakers

Pacemaker manufacturers recommend that a
minimum separation of 15 cm be maintained between
a mobile phone and a pace maker to avoid potential
interference with the pacemaker. To achieve this use
the phone on the opposite ear to your pacemaker and
does not carry it in a breast pocket.

Hearing Aids

Some digital wireless phones may interfere with some
hearing aids. In the event of such interference, you
may want to consult your hearing aid manufacturer to
discuss alternatives.

For other Medical Devices :

Please consult your physician and the device
manufacturer to determine if operation of your phone
may interfere with the operation of your medical
device.

Warning

This device have been tested to comply with the Sound
Pressure Level requirement laid down in the applicable
EN 50332-1 and/or EN 50332-2 standards. Permanent
hearing loss may occur if earphones or headphones
are used at high volume for prolonged periods of time.
<Prevention of Hearing Loss>
Warning statement requirement under EN 60950­1:A12.

Warning: To prevent possible hearing damage, do not
listen to high volume levels for long periods.

Appendix

Export Administration Regulations

This product and its accessories may be under
coverage of the Export Administration
Regulations of Japan ("Foreign Exchange and
Foreign Trade Control Laws" and the related laws
and regulations). And, they are also under
coverage of Export Administration Regulations of
the U.S. When exporting and reexporting this
product and its accessories, take necessary
procedures on your responsibility and expense.
For details, contact Ministry of Economy, Trade
and Industry of Japan or US Department of
Commerce.

Others

83

Appendix

Intellectual Property Right

Copyrights and portrait
rights

Except for the case protected by copyrigh t laws such as
personal use, use of FOMA terminal to reproduce,
alter, or publicly transmit recorded pictures or sounds,
or copyrighted text, images, music or software
downloaded from websites without the copyright
holder's authorization is prohibited.
Note that taking photos or recordings at some
demonstrations, performances or exhibitions may be
prohibited even when only for personal use.
Avoid taking pictures of others with FOMA terminal
without their consent or disclosing recorded pictures
of others without their consent to general public
through Internet websites etc., because they may
infringe on portrait rights.

Trademarks

･

"FOMA", "ｉMenu", "i-mode", "i-αppli", "i-motion",
"Deco-mail", "Chara-den", "ToruCa", "mopera U",
"WORLD CALL", "WORLD WING", "2in1", "MyFace"
and logos of "i-mode", "i­trademarks or registered trademarks of NTT
DOCOMO.

･

"Catch Phone (Call waiting service)" is a registered

Others

trademark of Nippon Telegraph and Telephone
Corporation.

･

McAfee® is registered trademarks or trademarks of
McAfee, Inc. and/or its affiliates in the US and/or
other countries.

･

Rovi, G-GUIDE, G-GUIDE MOBILE and G­Guide related logos are trademarks or
registered trademarks of Rovi Corporation and/or its
subsidiaries in Japan.

･

Contains Adobe® Flash® Lite® and Adobe Reader®
Mobile technology by Adobe Systems Incorporated.

84

α

ppli", "iC", ".W" are

Adobe Flash Lite Copyright
Systems Incorporated. All rights reserved. Adobe
Reader Mobile Copyright
Systems Incorporated. All rights reserved. Adobe,
Adobe Reader and Flash Lite are either registered
trademarks or trademarks of Adobe Systems
Incorporated in the United States and/or other
countries.

･

This product contains
NetFront Browser,
NetFront Document
Viewer and NetFront Sync Client of ACCESS CO.,
LTD.
ACCESS, the ACCESS logo and NetFront are
registered trademarks or trademarks of ACCESS
CO., LTD. in the United States, Japan and/or other
countries.

©

Copyright
reserved.
This product contains a module developed by the
Independent JPEG Group.

･

Powered by JBlend™ Copyright 2002-2014
Aplix Corporation. All rights reserved.
JBlend and JBlend-related trademarks are
trademarks or registered trademarks of Aplix
Corporation in Japan and other countries.

･
･

FeliCa is a registered trademark of Sony Corporation.

･

QR code is a registered trademark of Denso Wave
Inc.

･

microSDHC Logo is a trademark of SD-3C,
LLC.

･

"Multitask" is a registered trademark of NEC
Corporation.

･

The Bluetooth word mark and logos are owned by
the Bluetooth SIG, INC. and any use of such marks by
NTT DOCOMO, INC. is under license. Other
trademarks and names are those of their respective
owners.

2014 ACCESS CO., LTD. All rights

is a registered trademark of FeliCa Networks, Inc.

©

2003-2014 Adobe

©

1993-2014 Adobe

･

"CROSS YOU" is a trademark of Sony Corporation.

･

iWnn© OMRON SOFTWARE Co., Ltd. 2008-2014 All
Rights Reserved.

･

"AXIS Font" is a trademark of AXIS Inc.,
and the "AXIS" font is a font developed by Type
Project Inc.

･

This product contains software licensed by Symbian
Foundation Limited.
Symbian is a registered trademark of Symbian
Foundation Limited.

･

"Uni-Type" is a universal designed font jointly­developed by LIM Corp., Ltd. and Faculty of
Engineering, Chiba University.
Uni-Type is a registered trademark of LIM Corp., Ltd.

･

"

丸ゴシック

"
& Company, Ltd. and the copyrights of these font

data belong to them. Names of "
and "

･

Wi-Fi Alliance® is a registered trademark of Wi-Fi
Alliance.

･

WPA™, WPA2™ and Wi-Fi Protected Setup™ are
trademarks of Wi-Fi Alliance.

･

Other company and product names mentioned in
this manual are trademarks or registered trademarks
of their respective holders.

･

Other trademarks are those of their respective
owners.

(Maru Gothic)", "

丸フォーク

(Maru Fork)" are provided by Morisawa

丸フォーク

(Maru Fork)" are their trademarks.

レイミン

レイミン

(Reimin)" and

(Reimin)"

Others

･

This product contains a module developed by the
Independent JPEG Group.

･

FeliCa is a contactless IC card technology developed
by Sony Corporation.

･

OMRON Corporation's Mobile OmCR is used for a
character recognition engine.

･

This product contains software licensed based on
Apache License V2.0. and altered as necessary by
NTT DOCOMO, INC.
This product contains software licensed complying
with GNU Lesser General Public License (LGPL),
Eclipse Public License (EPL), etc.
For more details, on the FOMA terminal,

6#1⇒"

ンソースライセンス

The source code of the used open source software is
disclosed according to the rules of LGPL (http://
www.gnu.org/licenses/), EPL (http://
www.eclipse.org/legal/epl-v10.html), MPL (http://
www.mozilla.org/MPL/MPL-1.1.html) and NPL (http:/
/www.mozilla.org/MPL/NPL-1.1.html). For more
details, refer to the information on this product in the
following site.
http://spf.fmworld.net/oss/oss_fp/ (In Japanese only)

･

This product is licensed based on MPEG-4 Visual
Patent Portfolio License. The use of MPEG-4 Video
Codec function i s allowed for personal and nonprof it
use only in the following cases.

- Recording moving pictures and i-motion that
conform to MPEG-4 Visual Standard (hereinafter
referred to as MPEG-4 Video)

- Playing MPEG-4 Videos recorded personally by
consumers not engaged in profit activities

- Playing MPEG-4 Video supplied from the provider
licensed from MPEG-LA
For further utilizing such as promotion, in-house
use or profit-making business, please contact
MPEG LA, LLC in U.S.

その他

(Others)" to see in "

(Open source license)".

m

オープ

⇒

Others

85

･

Content owners use Windows Media digital rights
management technology (WMDRM) to protect their
intellectual property, including copyrights. This
device uses WMDRM software to access WMDRM­protected content. If the WMDRM software fails to
protect the content, content owners may ask
Microsoft to revoke the software's ability to use
WMDRM to play or copy protected content.
Revocation does not affect unprotected content.
When downloading licenses for protected content,
you agree that Microsoft may include a "Revocation
List" with the licenses. Content owners may require
you to upgrade WMDRM to access their content. If
you decline an upgrade , you cannot access a content
that requires the upgrade.

･

The HMM-Based Speech Synthesis Engine
embedded in this product uses the Simplified BSD
License.

-------------------------------------------------------­TheHMM-BasedSpeechSynthesisSystem(HTS)
htsengineAPIdevelopedbyHTSWorkingGroup
http://hts-engine.sourceforge.net/

--------------------------------------------------------

Copyright

©

2001-2010NagoyaInstituteofTechnology,DepartmentofComputerScience
2001-2008TokyoInstituteofTechnology,InterdisciplinaryGraduateSchoolofScienceandEngineering
Allrightsreserved.

Redistribution and use in source and binary forms,
with or without modific ation, are permitted provided
that the following conditions are met:

- Redistributions of source code must retain the
above copyright notice, this list of conditions and

Others

the following disclaimer.

- Redistributions in binary form must reproduce the
above copyright notice, this list of conditions and
the following disclaimer in the documentation and/
or other materials provided with the distribution.

- Neither the name of the HTS working group nor t he
names of its contributors may be used to endorse
or promote products derived from this software
without specific prior written permission.

THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT
HOLDERS AND CONTRIBUTORS "AS IS" AND ANY
EXPRESS OR IMPLIED WARRANTIES, INCLUDING,
BUT NOT LIMITED TO, THE IMPLIED WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE ARE DISCLAIMED. IN NO
EVENT SHALL THE COPYRIGHT OWNER OR
CONTRIBUTORS BE LIABLE FOR ANY DIRECT,
INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR
CONSEQUENTIAL DAMAGES (INCLUDING, BUT
NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE
GOODS OR SERVICES; LOSS OF USE, DATA, OR
PROFITS; OR BUSINESS INTERRUPTION)
HOWEVER CAUSED AND ON ANY THEORY OF
LIABILITY, WHETHER IN CONTRACT, STRICT
LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR
OTHERWISE) ARISING IN ANY WAY OUT OF THE
USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE
POSSIBILITY OF SUCH DAMAGE.

･

By default, the following dictionaries are installed in
the terminal.

研究社

(KENKYUSYA)>

<

リーダーズ英和辞典 第2版（松田徳一郎編）

English-Japanese dictionary 2nd edition)

新和英中辞典 第5版（

Dutcher

、田辺宗一、金子稔編）

English-Chinese dictionary 5th edition)

Martin Collick、David P.

(New Japanese-

(Reader's

86

Appendix

SIM unlock

This FOMA terminal supports SIM unlock. If you
release SIM lock, you can use SIM by a carrier other
than NTT DOCOMO.

･

The SIM unlock service is provided at a docomo
Shop.

･

A SIM unlock charge is separately required.

･

If you use a SIM other than by DOCOMO, available
services and functions may be limited. DOCOMO is
not liable to any failures or malfunctions.

･

For details of SIM unlock, refer to NTT DOCOMO
website.

Others

87

Index

A

AC adapter .................................

Access point (main).. ..................

Adjust volume ............................

After-Sales Service................. ....

Alarm................ ..........................

Attachments..................... ..........

AUTO-GPS ..................................

B

Back Cover .................................

Backup at once....................... ....

Bar code reader ..........................

Battery pack ..................... ..........

Bluetooth function ........... ..........

Bookmark ......................... ..........

C

Call Forwarding Service .............

Call rejection setting...... ............

Call Waiting Service ............... ....

Caller ID notification..................

Camera ........... ............................

Channel list ................................

Character entry ..........................

Charging...... .............................. .

Checking new mail/message ......

Client mode (Sub unit) ...............

D

Deco-mail ...................................

Decome-Anime .......................... .

Delete all data ............................

Others

Desktop Holder ..........................

Display light ...............................

docomo mini UIM card ...............

docomo Palette UI.................. ....

E

Early warning "Area Mail" ..........

eco mode........ ............................

Emergency call .................... .......

Error info send set......................

F

Font size ................. ....................

88

Full Browser................................

25

G

68

GPS function ..............................

32

Guide ..........................................

75

Guide area ..................................

66
48

I

55

i-αppli .............................. ...........

iC transmission................ ...........

i-channel ............... ......................

24

Icon............ .............................. ...

70

i-concier......................................

66

i-mode password ........................

24

i-mode site/Website ....................

67

i-motion/Movie.............. ..............

53

Indicator light ............................ .

Infrared communication .............

Initial setting ..............................

44

Input mode .................................

39

International calls......... ..............

44

i-Widget ................................... ...

26
56

K

58

Kisekae Tool ................. ..............

31

Koe-no-Takuhaibin............. .........

25
50

L

68

Light alert ............. ......................

Listening volume ....... .................

Lock functions............................

49
49

M

39

Machi-chara setting....................

25

Making a call/videophone call ....

33

Map............... ............................. .

24

Menu operation ..........................

30

microSD card................ ..............

Moving picture display ...............

MUSIC Player............................. .

51

MyFACE

35
45
76

34

 .............................................

N

Navigation ..................................

Network security code ...............

Network service .........................

52

O

On hold .......................................

Options and related devices .......

54

Osaifu-Keitai ...............................

30

Overseas use....... ........................

29

P

PC connection ............................

61

Phonebook............. ...............

71

PIN1/PIN2 code. ..........................

53

Position location....................... ..

27

Privacy view ...............................

64

Profile ............ .............................

36

Public mode .............................. ..

52

PUK code ............... .....................

62
35

R

71

Received calls ........... ..................

26

Receiving a call/videophone call

31

......................................................

41

Receiving i-mode mail.................

61

Record message............. .............

Recording reservation.................

Redial ........................ ..................

34

Replying to mail..........................

41

Reset ...........................................

Ring tone .................................. ..

35

S

42

SAR ........................... ..................

38

Scanning function ......................

Schedule ............. ........................

Screen Memo. .............................

34

Security code......... .....................

40

Select startup menu ...................

54

Sending i-mode mails .................

29

Sending SMS ..............................

69

Set auto-update ..........................

57

Setting mail sort rule.......... ........

60

Shabette-Kensaku.......... .............

Shooting moving pictures ..........

30

Shooting still images ..................

Shortcuts ....................................

Silent mode......................... ........

54

Stand-by display setting ........... ..

36

Still image display ......................

44

System sound .............................

40, 51

42
79
63
46

72

36
54
33
26
43
37

40

42
50
43
59
40
50
39
32

80
78
66
53
36
34
48
48
78
50
65
56
56
30
33
33
57
33

T

Terminal security code... ............

Troubleshooting .......... ...............

U

Updating software .....................

USB mode....................... ............

V

Vibration mode.................... .......

Voice Mail Service............... .......

Voice quick start .................... ....

W

Warranty... ..................................

Watching reservation .................

Wireless LAN ..............................

z

1Seg .......................................... .

36
73

77
72

32
44
65

75
59
68

58

Others

89

Please ask checking/changing subscription detail, application of various services and request of
various information materials online.

From i-mode

⇒ お客様サポート

iMenu

(Support)

⇒ お申込・お手続き

(Application/Procedures)

⇒ ドコモオンライン手続き (DOCOMO online procedures)

No packet communication charges

From PCs

My docomo (https://www.nttdocomo.co.jp/mydocomo/) ⇒ ドコモオンライン手続き一覧
(DOCOMO online procedures list)

* You need your "Network security code" to use the site

from i-mode.

* No packet communication charge applies to access the

site from i-mode. Packet communication charge applies to
access from overseas.

*

You need "docomo ID/Password" to access the site from
your PC.

*

In Japanese only

*

In Japanese only

*

If you do not have or forget "Network security code" or

"docomo ID/Password", contact to the numbers for
"General Inquiries" on the last page of this manual.

*

You may not use the services depending on your

subscription.

*

There are cases where the site may not be available to

system maintenance, etc.

Using mobile phone with your manners!

When using your mobile phone in a public
place, don’t forget to show common courtesy
and consideration for others around you.

Always turn OFF your FOMA terminal in cases below

■ In a place where use of mobile phones is prohibited

・

Follow the instructions of each airline or medical
facility for the use of mobile phones on their premises.

Power off the terminal in a place where the use is
prohibited.

Always set Public mode in cases below

■

When driving

・

Using a mobile phone by holding it with the hand
while driving is subject to penalty. However,
absolutely necessary cases such as rescue of a sick
person or maintaining public's safety are exempted.

■

In public places such as a theater, movie

theater or art museum

Consider privacy

■ Please be considerate of the privacy of individuals

around you when taking and sending photos using
camera-equipped mobile phones.

Fewer pages in the instruction manual

In Japanese version, instruction manual covers
instructions only for basic
and paper usage.
For frequently-used functions and their details, see

使いかたガイド

terminal, in Japanese only) or visit NTT DOCOMO
website.

Recycle of mobile phones

DOCOMO’s environmental effort

functions to reduce pages

(Guide) (installed in this FOMA

To protect environment and recycle
the precious resources, mobile phone
and PHS enterprises collect phones,
batteries and chargers, regardless of
brands and manufacturers, at shops
labeled with the mark shown to the
left. Bring these devices to your
nearest docomo Shop.

General Inquiries

<docomo Information Center>

0120-005-250 (toll free)

* Service available in: English, Portuguese, Chinese, Spanish.
* Unavailable from part of IP phones.

(Business hours : 9:00 a.m. to 8:00 p.m.)

■From DOCOMO mobile phones (In Japanese only)

(No prefix) 151 (toll free)

* Unavailable from land-line phones, etc.

■From land-line phones (In Japanese only)

0120-800-000 (toll free)

* Unavailable from part of IP phones.

(Business hours : 9:00 a.m. to 8:00 p.m. (open all year round))

●



Please confirm the phone number before you dial.

●



For Applications or Repairs and After-Sales Service, please contact the above-mentioned information center or the docomo
Shop etc. near you on the NTT DOCOMO website or the i-mode site.

NTT DOCOMO website https://www.nttdocomo.co.jp/english/



i-mode site iMenu

⇒お客様サポート

(user support)

⇒ドコモショップ

■From DOCOMO mobile phones (In Japanese only)

(No prefix) 113 (toll free)

* Unavailable from land-line phones, etc.

■From land-line phones (In Japanese only)

0120-800-000 (toll free)

* Unavailable from part of IP phones.

(Business hours : 24 hours (open all year round))

(docomo Shop) * In Japanese only

Repairs

For loss, theft, malfunction, and inquiries while overseas (24-hour reception)

■From DOCOMO mobile phones

International call access code
for the country you stay

* You are charged a call fee to Japan when calling from a land-line phone, etc.
※ If you use F-07F, you should dial the number 81-3-6832-6600

■

From land-line phones <Universal number>

Universal number
international prefix

* You might be charged a domestic call fee according to the call rate for the country you stay.

※

For international call access codes for major countries and universal number international prefix, refer to DOCOMO International Services website.

●

If you lose your FOMA terminal or have it stolen, immediately take the steps necessary for suspending the use of the FOMA terminal.

●

If the FOMA terminal you purchased is damaged, bring your FOMA terminal to a repair counter specified by DOCOMO after returning to Japan.

Don't forget your mobile phone ･･･or your manners!

When using your mobile phone in a public place, don't forget to
show common courtesy and consideration for others around you.

-81-3-6832-6600*(toll free)

-8000120-0151

*

(to enter ' ', press and hold the '0' key for at least one second).

2014.5 (1st Edition)
CA92002-8494

Manual for PC Connection

Data Communication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Before use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Flow of setup for data transfer (OBEX™ communication) . . . . . . . . . . . . 4

Flow of setup for data communication . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Connecting up PC to the FOMA terminal . . . . . . . . . . . . . . . . . . . . . . . . . 5

Installing FOMA communication configuration file (driver) . . . . . . . . . . 6

Preparing for Bluetooth

Using DOCOMO Connection Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Setting communications without using DOCOMO Connection Manager 15

Connecting to a Wireless LAN compatible PC . . . . . . . . . . . . . . . . . . . . . 24

AT command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

®

connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

About Manual for PC Connection

This manual describes about data communications using F-07F and how
to install "FOMA communication configuration file" and "DOCOMO
Connection Manager".
Depending on the environment of your PC, some of operation procedures
and/or screens may be different.

'14.5 (Issue 1)

CA92002-8494

Data Communication

There are 3 communication modes available by connecting FOMA terminal and a PC : data
transfer (OBEX™ communication), packet communication and 64K data communication.

To make packet communications or 64K data communications or edit data such as the phonebook using

･

a PC connected, downloading the software from NTT DOCOMO website, installation and various settings
are required.

･ When performing packet communication overseas, use IP connection (packet communication is

unavailable with PPP connection). 64K data communication cannot be used overseas.

･ FOMA terminal does not support FAX communication or Remote Wakeup.

❖ Data transfer (OBEX™ communication)

You can send and receive data such as image, music, phonebook or mail etc. to/from other FOMA terminals
or PCs etc.

･ Transferable data varies depending on transfer method. For data that can be transferred by each transfer

method, see "Instruction manual (detailed version) (in Japanese only)" (in pdf format) of the FOMA
terminal.

Infrared communication

iC transmission

F-07F

F-07F

Bluetooth communication

USB cable connection

microSD card

DOCOMO keitai datalink

❖ Packet communication

You can connect to the Internet and perform data communication (packet communication).
Packet communication charges are based on the amount of data sent and received. No communication
charges are required when no data are exchanged even if you are connected to the network. Therefore,
sending/receiving data as needed while remaining connected to the network is possible.
High-speed packet communication can be performed at a maximum reception speed of 7.2Mbps and a
maximum transmission speed of 5.7Mbps by using access points that support FOMA packet
communication such as mopera U of DOCOMO's Internet connection service. Best effort method which the
actual communication speed varies with the environment and the rate of congestion offers.
Note that communications of large-size data such as viewing websites containing images and downloading
will require high charges.
* The communication speed may be slower when connecting out of FOMA HIGH-SPEED area, connecting to access points

incompatible with HIGH-SPEED, or using devices incompatible with HIGH-SPEED.

* For Bluetooth connection, though the communication speed of FOMA terminal is equal to HIGH-SPEED, communication

may not be performed by maximum speed because the communication speed between Bluetooth devices has limits.

* Maximum speed of reception 7.2Mbps and transmission 5.7Mbps are the values in technical standards, thus they are not

indicated actual communication speed. Actual communication speed varies by the network congestion or environment of
communication.

1

❖ 64K data communication

You can connect to the Internet and perform 64K data communication.
Communication charges are based on the duration of the connection to the network regardless of the
volume of data. Access points that support FOMA 64K data communication services such as mopera U of
DOCOMO's Internet connection service or ISDN synchronized 64K access points can be used.
Please be careful that a high cost will be charged for long-time communications.

Before use

◆ Operating environment

The operation environment for using data communication is as shown below. They may vary depending
on the PC system configurations.

Item Requirements

Computer PC/AT compatible computer

OS (Japanese
version)

Memory
requirements

Hard disk capacity 5MB (10MB

Web browser

Mailer software

* For operating environment of using DOCOMO Connection Manager.

*

･ For the latest information about operating environment, refer to NTT DOCOMO website.
･ DOCOMO will not guarantee operations on upgraded OS or added/changed operating environment.
･ Note that utilization may not be possible in certain operating environments. DOCOMO assumes no

responsibility for pertaining to operation under conditions other than that described above.

･ DOCOMO Connection Manager is not compatible with Windows 8.1. To make data communication with

a Windows 8.1 PC, refer to "Setting communications without using DOCOMO Connection Manager".→
P15

For USB cable connection : USB port (conform to USB specification 1.1/2.0)
For Bluetooth connection : Compatible with up to Bluetooth Standard Ver. 2.1 +

EDR (dialup networking profiles) supporting dialup networking profile

For Wireless LAN connection : Compatible with Wireless LAN Standard IEEE

802.11b, IEEE 802.11g or IEEE 802.11n
Recommended 800
or more

×600 dots or more (Recommended 1,024 ×768 dots or more))

（1,024

Windows Vista, Windows 7, Windows 8.1/8

Windows Vista : 512MB or more
Windows 7 : 1GB or more for 32-bit, 2GB or more for 64-bit
Windows 8.1/8 : 1GB or more for 32-bit, 2GB or more for 64-bit

Internet Explorer 8.0 or more

*

Windows Mail

×600 dots or more in display resolution and High Color 16 bits

*

) or more free disk space

*

◆ Devices required

For USB cable connection, the following devices and software are required in addition to FOMA terminal
and a PC.

･ FOMA USB Cable with Charge Function 02 (optional) or FOMA USB Cable (optional)
･ FOMA communication configuration file (driver)

* Download from NTT DOCOMO website.

*

✔INFORMATION

USB cable for PC is not available because the connector type is different.

･
･ When using USB HUB, it may not operate properly.

2

◆ Usage precautions

❖ Internet service provider usage charges

When using the Internet on a PC, usage charge to your Internet service provider (hereinafter referred to as
Provider) is required. This charge is paid directly to the Provider, and is separated from the FOMA service
charge. For details, contact your Provider.

･ DOCOMO's Internet connection service mopera U is available. mopera U is a charged service requiring

subscription.

❖ Dialup connection (Provider etc.)

Different dialup connections are required for packet communication and 64K data communication. When
performing packet communication, use the dialup connection for packet communication. When performing
64K data communication, use the dialup connection for FOMA 64K data communication or ISDN
synchronized 64K data communication.

❖ User authentication

Some dialup connections require user authentication before a connection can be established. If user
authentication is required, you must use your communication software or dialup network to enter your ID
and password and connect. Your ID and password will be assigned by the network administrator of the
connection destination such as your provider or corporate LAN. For details, contact your provider or
network administrator.

❖ Conditions of packet communication and 64K data communication

To perform data communication in Japan, the following conditions must be satisfied.

- You must be within the FOMA service area.

- Packet communication requires an access point that supports FOMA packet communications.

- 64K data communication requires a dialup connection that supports FOMA 64K data communications or ISDN
synchronized 64K.

- For Bluetooth connection, a PC requires compatible with up to Bluetooth Standard Ver. 2.1 + EDR (dialup networking
profiles) supporting dialup networking profile.

- For Wireless LAN connection, a PC requires compatible with Wireless LAN Standard IEEE 802.11b, IEEE 802.11g or IEEE

802.11n.

* Note that even when the above requirements are satisfied, you may not be able to perform data communication if base

station traffic is heavy or the radio wave conditions are poor.

◆ Introduction of DOCOMO keitai datalink

DOCOMO keitai datalink is software to back up and edit your phone information such as phonebook and
mail. It is provided on NTT DOCOMO website. For details and download of this software, refer to the
following website.
http://datalink.nttdocomo.co.jp/ (In Japanese only)

･ To use DOCOMO keitai datalink, installing FOMA communication configuration file (driver) in advance is

required.

･ For details of downloading procedure, data that can be transferred, operating environments, installing

procedure, operation procedure, etc., refer to the website above. For operations after installation, see
Help in the software.

･ To use DOCOMO keitai datalink, USB cable is required.

3

Flow of setup for data transfer (OBEX™
communication)

When using USB Cable, install FOMA communication configuration file (driver) in advance.

Downloading FOMA communication configuration file (driver) from NTT DOCOMO website
and installing

Data transfer

Flow of setup for data communication

This section describes the setup work for performing packet communication or 64K data
communication.

For USB cable connection

For Bluetooth connection

a Downloading FOMA communication

configuration file (driver) from NTT
DOCOMO website and installing→P6

b

Connecting FOMA terminal to a PC

c Confirming FOMA communication

ޓ configuration file (driver)

Downloading DOCOMO Connection Manager from NTT DOCOMO website and
installing

→P11

Setting data communication by DOCOMO Connection Manager

→

P5

→

P7

Setting communications without using
DOCOMO Connection Manager→P15

Performing communication

a Preparing for Bluetooth

connection

b Checking modem→P9

→

P8

4

Wireless LAN connection (packet communication only)

Setting the FOMA terminal to the AP mode

For AP mode, see “Instruction manual (detail version)

࡮



(In Japanese only)” (PDF file) of the FOMA terminal.

Setting the connection→P24

Performing communication

◆ Precautions for installation/uninstallation

･ Before starting operation, make sure that no other program is running and exit the program if any.

* Exit any resident programs on Windows including antivirus software.

Example : Right-click the icon displayed in the task bar, click " 閉じる (Close)" or "終了 (End)".

･ For installing/uninstalling FOMA communication configuration file (driver) or DOCOMO Connection

Manager, make sure that a user with administrator's privilege performs the operation. Installing/
uninstalling the software by other users may produce an error. For details on PC administrator privileges,
refer to the PC manual or contact your PC manufacturer or Microsoft Corporation.

･ When "ユーザーアカウント制御 (User account control)" screen appears, perform the following

operations.

- Windows 8.1/8 and Windows 7 : Click "はい (Yes)"

- Windows Vista : Click "続行 (Continue)"

Connecting up PC to the FOMA terminal

Connecting/disconnecting to PC is explained here. Installing FOMA communication
configuration file (driver) is described separately.→P6

･

If you connect FOMA terminal to a PC before installing FOMA communication configuration file (driver),
Windows may automatically detect that USB cable has been inserted, and may request the driver. In such
a case, click "キャンセル (Cancel)" on the displayed screen to end.

･ The connection should be made with a PC and FOMA terminal both turned ON.
･ Location of external connection jack or connecting/disconnecting to a USB cable may vary depending on

the model. Refer to "Instruction manual (detailed version) (in Japanese only)" (in pdf format) of your
FOMA terminal.

5

◆ Inserting USB cable

Insert the connector of the USB cable with engraved side up into FOMA

1

terminal's external connection jack horizontally.

Insert the other end of the USB cable connector into the PC USB port.

2

･ When a PC and FOMA terminal are connected, appears on the stand-by display of FOMA

terminal.

❖ Removing USB cable

Press the USB cable's release buttons on both sides of the connector and

1

remove the connector from FOMA terminal horizontally.

Remove the USB cable out from the PC.

2

✔INFORMATION

Be careful not to give excessive force to the connecter of the USB cable when connecting/disconnecting the cable

･

to/from FOMA terminal.
When disconnecting the connector, be sure to pull it straight while pressing the release button. Applying an
excessive force to disconnect the connector may give damage to it.

･ Do not remove the USB cable during data communication. The data communication is disconnected and it may

cause data loss or malfunction.

Installing FOMA communication configuration file (driver)

To make data communication by connecting FOMA terminal and a PC with USB cable, FOMA
communication configuration file (driver) is required. Install the file before connecting FOMA
terminal for the first time to the PC.

Before operating, refer to "Precautions for installation/uninstallation".→P5

･
･ For without using USB cable, installing FOMA communication configuration file (driver) is not required.
･ Do not connect FOMA terminal until a message that instructs you to connect FOMA terminal to a PC

appears in Step 5.

Download FOMA communication configuration file (driver) from NTT

1

DOCOMO website and decompress.

https://www.nttdocomo.co.jp/support/utilization/application/foma/com_set/driver/index.html (In
Japanese only)

･ Before downloading, check model name of FOMA terminal.

Double-click the decompressed file →Select a file which your PC is applied to.

2

･ Select "f-07f_driver_32" for 32-bit OS, or select "f-07f_driver_64" for 64-bit OS.

In the window displayed, double-click the "F07Fst.exe" icon.

3

Click "インストール開始 (Start installation)".

4

When a message indicating to connect FOMA terminal to the PC appears,

5

connect FOMA terminal to the PC.

･ Connect FOMA terminal while the power is ON.

On the Installation completion screen, click "OK".

6

6
