DL3750+
DOT MATRIX PRINTER
PARTS CATALOGUE
FUJITSU ISOTEC LIMITED
REVISION RECORD
Edition Date published Page Revised contents
01 February 2004 First issue
Specification No. P3KA02008-B001/E
The contents of this manual may be revised without prior notice.
All Rights Reserved, Copyright © 2004 FUJITSU ISOTEC LIMITED.
Address your comments and inquiries on this manual to:
This document is used for maintenance purpose only.
The illustration of the part does not guarantee its availability.
This is parts catalogue for the DL3750+ DOT MATRIX PRINTER.
This manual is for service engineers.
There are several models of DL3750+ DOT MATRIX PRINTER.
This manual covers all models.
This manual consists of two parts : Parts List and Parts Drawings.
Parts list has layer structure .You can find assembly levels.
Parts drawing does not have the layer structure.
You can see the model difference from the parts list easily.
There are other manuals for service engineers as follows.
Especially the maintenance manual has close relationship to this manual.
DL3750+ DOT MATRIX PRINTER MAINTENANCE MANUAL
DL3750+ DOT MATRIX PRINTER SCHEMATIC DIAGRAMS
DL3750+ DOT MATRIX PRINTER PRINTER USER’S MANUAL
DL3750+ DOT MATRIX PRINTER PRODUCT DESCRIPTION
This document contains technology relating to strategic products controlled by export control laws
of the producing and/or exporting countries.This document or a portion there of should not be
exported (or reexported) without authorization from the appropriate governmental authorities
in accordance with such laws.
FUJITSU ISOTEC LIMITED
CONTENTS
1. HOW TO REFER TO THIS MANUAL………………………………………………………………1-1
2. SPECIFICATIONS……………………………………………………………………………………..2-1
3. PARTS LIST AND PARTS DRAWING OF PRINTER MECHANISM…………………………….3-1
3.1 DL3750+ Printer…………………………………………………………………………………….3-1
3.2 Upper Cover Assembly……………………………………………………………………………..3-5
3.3 Lower Cover Assembly……………………………………………………………………………..3-7
3.4 Mechanism Assembly……………………………………………………………………………….3-9
3.5 Paper Unit Assembly……………………………………………………………………………….3-11
3.6 Carrier Unit Assembly……………………………………………………………………………..3-13
1. HOW TO REFER TO THIS MANUAL
Example:
1
3
No.
1-9
1
2
3
4
5
6
7
8
9
10-12
10
11
12
13-16
13
14
15
16
Composition
& Quantity
2
KA02004-G125
1
1
1
1
1
1
1
6
1
4
1
1
1
1
1
1
3
1
1
Specification
KA02004-Y120
KA02004-Y161
KA02004-Y529
KA02004-Y122
KA02004-Y123
KA02004-Y128
KA02004-Y125
KA02004-Y126
KA02004-Y127
KA02004-G130
KA02004-Y130
KA02004-Y162
KA02004-Y131
KA02004-G132
KA02004-Y132
KA02004-Y133
KA02004-Y163
KA02004-Y166
Parts name
(Description)
UPPER COVER ASSEMBLY
UPPER COVER
SOUND PROOF A
U SHEET
INTER LOCK SWITCH LEVER
KNOB
OP SHEET
LED LENS
OP SWITCH A
OP SWITCH B
FRONT COVER ASSEMBLY
FRONT COVER
SOUND PROOF B
CLEAR COVER
SOUND PROOF COVER ASSEMBLY
SOUND PROOF COVER
RIB UNIT
SOUND PROOF C
SOUND PROOF F
5
Spare
Part
Number
KA02008-D965
KA02008-D958
KA02008-D960
Remarks
4
• This figure shows the item number of part in the drawing.
• These columns show the construction levels. A higher level part consists of the following lower level parts listed
until the quantity of the next part appears at the same level. See example.
• m-n shows an assembly or unit consisting of more than one part. The front cover sub assembly of DL3750+
consists of a front cover ,a sound proof B ,a clear cover.
• These parts are at the same level and belong to the same upper level part.
• The spare part number shows recommended spare part.
1-1
2. SPECIFICATION
The table below lists standard models of the DL3750+ printer.
Voltage Interface
No. Specification
100V 200V Centro RS USB
Area Remarks
1 KA02008-B103
2 KA02008-B108
3 KA02008-B111
4 KA02008-B136
5 KA02008-B203
6 KA02008-B219
7 KA02008-B251
8 KA02008-B303
9
9
9
9
9 9
9 9
9 9 9
9 9 9
9
9
9 9
9
For FCI
9
9
9
9
For FCI
For FTL
For FEL COUNTRY KIT
For FSBT
For FCI
For ASIA
For FAL
9 KA02008-B308
10 KA02008-B311
9
9 9
9
For FTL
For FEL COUNTRY KIT
2-1
2.1 UNIT CONSTRUCTION TABLE
The table below lists standard models of the DL3750+ printer.
No. Specification AC Cord
1 KA02008-B103 CA98001-5982
2 KA02008-B108 CA98001-5982
3 KA02008-B111 ―
4 KA02008-B136 ―
5 KA02008-B203 CA98001-5982
6 KA02008-B219
CA98001-4319
CA98001-4428
User’s
manual
C147-E046-****
C147-E046-****
C147-E046-****
C147-E046-****
C147-E046-****
C147-E046-****
Ribbon
Cassette
CA02374-
Lower C.
Assembly
KA02008-
Upper C.
Assembly
KA02004-
ROM
Board
KA02004-
D101 D103 G125 J101
D101 D108 G125 J101
D101 D111 G125 J101
D101 D136 G125 J136
D101 D203 G125 J201
D101 D219 G125 J201
7 KA02008-B251 CA98001-5983
8 KA02008-B303 CA98001-5982
9 KA02008-B308 ―
10 KA02008-B311 ―
C147-E046-****
C147-E046-****
C147-E046-****
C147-E046-****
D101 D251 G125 J201
D101 D303 G125 J201
D101 D308 G125 J201
D101 D311 G125 J201
2-2
