Fujitsu LifeBook

B Series

BIOS Guide

LifeBook B Series Model:

B3000

Document Date: 05/20/2004

Document Part Number: FPC58-1148-01

FUJITSU COMPUTER SYSTEMS

LifeBook B Series Notebook BIOS

B Series BIOS

BIOS SETUP UTILITY

The BIOS Setup Utility is a program that sets up the operating environment for your notebook. Your BIOS is set at the factory for normal operating conditions, therefore there is normally no need to set or change the BIOS environment to operate your notebook.

The BIOS Setup Utility configures:

• Device control feature parameters, such as changing I/O addresses and boot devices.

• System Data Security feature parameters, such as passwords.

Entering the BIOS Setup Utility

To enter the BIOS Setup Utility do the following:

1. Turn on or restart your notebook.

2. Press the [ on the screen. This will open the main menu of the BIOS Setup Utility with the current settings displayed.

3. Press the arrow keys to scroll through the other setup menus to review or alter the current settings.

Navigating through the Setup Utility

The BIOS setup utility consists of six menus; Main, Advanced, Security, Boot, Info and Exit. This document explains each menu, including all submenus and setup items.

The following procedures allow you to navigate the setup utility menus:

1. To select a menu, use the cursor keys: [ ],[ ].

2. To select a field within a menu or a submenu, use the cursor keys: [ ], [ ].

3. To select the different values for each field, press the

Spacebar] or [+] to change to the next higher selec-

[ tion and [

4. To activate a submenu press the [Enter] key.

5. To return to a menu from a submenu, press the [

6. To go to the Exit menu from any other menu, press the [

F2] key once the Fujitsu logo appears

F5] or [-] to go to the next lower selection.

Esc] key.

• Selecting a field causes a help message about the field to be displayed on the right-hand side of the screen.

• Pressing the Enter key with the highlight on a selection that is not a submenu or auto selection will cause a list of all options for that item to be displayed. Pressing the Enter key again will select the highlighted choice.

7. Pressing the [

F9] key resets all items in the BIOS to

the default values.

8. Pressing the [

F10] key saves the current configura-

tion and exits the BIOS Setup Utility. You will be asked to verify this selection before it is executed.

9. Pressing the [

F1] key gives you a general help screen.

Entering the Setup Utility After a Configuration Change or System Failure

If there has been a change in the system configuration that does not match the parameter settings stored in your BIOS memory, or there is a failure in the system, the system beeps and/or displays an error message after the Power On Self Test (POST). If the failure is not too severe, it will give you the opportunity to modify the settings of the setup utility, as described in the following steps:

1. When you turn on or restart the computer there is a beep and/or the following message appears on the screen:

Error message - please run SETUP program Press <F1> key to continue, <F2> to run SETUP

2. If an error message is displayed on the screen, and you want to continue with the boot process and start the operating system anyway, press the [

• If your notebook emits a series of beeps that sounds like a code and the display is blank, refer to the Troubleshooting Section of your system User’s Guide. The Troubleshooting Section includes a list of error messages and their meanings.

• If your data security settings require it, you may be asked for a password before the operating system will be loaded.

F1] key.

3. If an error message is displayed on the screen, and you want to enter the setup utility, press the [

F2] key.

4. When the setup utility starts with a fault present, the system displays the following message:

Warning!

Error message

[Continue]

5. Press any key to enter the setup utility. The system will then display the Main Menu with current parameters values.

B Series BIOS

LifeBook B Series Notebook BIOS

MAIN MENU – SETTING STANDARD SYSTEM PARAMETERS

The Main Menu allows you to set or view the current system parameters. Follow the instructions for

Navigating through the Setup Utility to make any

changes.

The following tables show the names of the menu fields for the Main menu and its submenus, all of the options for each field, the default settings and a description of

Figure 1. Main Menu

PhoenixBIOS Setup Utility

Main Advanced Security Boot Info Exit

System Time: [14:57:01] System Date: [05/21/2004]

▲

Primary Master [TOSHIBA MK4025GAS-(PM)]

Language: [English (US)]

the field’s function and any special information needed to help understand the field’s use

System Time and System Date can also be set from your operating system without using the setup utility. Use the calendar and time icon on your Windows Control Panel.

Item Specific Help

Adjust calendar clock.

<Tab>, <Shift-Tab>, or <Enter> selects field.

F1 Help ESC Exit

Select Item Select Menu

-/Space Change Values Enter Select Sub-Menu

▲

F9 Setup Defaults F10 Save and Exit

Table 1: Fields, Options and Defaults for the Main Menu

Menu Field Options Default Description

System Time: –— –— Sets and displays the current time. Time is in a 24 hour

format of hours:minutes:seconds with 2 digits for each. (HH:MM:SS). Example: 16:45:57. You may change each segment of the time separately. Move between the segments with the [Tab] key and/or [Shift] + [Tab] keys.

Main Menu

Table 1: Fields, Options and Defaults for the Main Menu

Menu Field Options Default Description

System Date: –— –— Sets and displays the current date. Date is in a month/

day/year numeric format with 2 digits each for month and day and 4 digits for year. (MM/DD/YYYY) for example: 03/20/1998. You may change each segment of the date separately. Move between the segments with the [Tab] key and/or [Shift] + [Tab] keys.

Primary Master: • Selects Primary

Master submenu

Language: • English (US)

• Japanese (JP)

___ Displays the type of device on this ATA/ ATAPI inter-

face, if there is one. Pressing the Enter key selects the Primary Master submenu allowing additional device configuration options for this interface.

[English (US)] The default setting differs between the US/European

and the Japanese model. Selects the display language for the BIOS.

LifeBook B Series Notebook BIOS

Primary Master Submenu of the Main Menu

The Primary Master submenu identifies what ATA/ ATAPI devices are installed.

PhoenixBIOS Setup Utility

Main Advanced Security Power Boot Info Exit

Primary Master [TOSHIBA MK4025GAS-(PM)]

Type: [Auto] LBA Format Total Sectors:: 78140160 Maximum Capacity: 40008MB

Multi-Sector Transfers: [16 Sectors] LBA Mode Control: [Enabled] Transfer Mode: [Multiword DMA 2] Ultra DMA Mode: [Disabled]

F1 Help ESC Exit

Select Item Select Menu

-/Space Change Values Enter Select Sub-Menu

Note: Actual hard drive label shown may vary. Depending on the drive type, information such as cylinders, heads and sectors may or may not be displayed.

Item Specific Help

Select ATA/ATAPI drive installed here.

[Auto] The BIOS auto-types the drive on boot time.

Except [Auto] You enter parameters of the drive.

[None] The drive is disabled.

▲

F9 Setup Defaults F10 Save and Exit

Figure 2. Primary Master Submenu

Table 2: Fields, Options and Defaults for the Primary Master Submenu of the Main Menu

Menu Field Options Default Description

Typ e:

LBA Format Logical Block Addressing (LBA)

Total Sectors:

Maximum Capacity:

CHS Format Cylinders/Heads/Sectors

Cylinders:

Auto

None

CD-ROM

Hard Disk

___

A number between 0 and 65,535

[Auto] Selects the ATA/ATAPI device type. Select Auto to have the type auto-

___ The total number of sectors on your hard disk

___ The maximum capacity of your hard disk

–— This item is active only when Hard Disk is selected as the type. This

matically identified by the BIOS at POST. If None is selected, all of the following Set-up items do not appear. Select CD-ROM if a CD-ROM drive is installed at this connection. If Hard Disk is selected, you must specify the number of Cylinders, Heads, and Sectors for the drive.

field is changed by incrementing (pressing the [Spacebar]), by typing in the number, or using the “+” and “-” keys.

Main Menu

Table 2: Fields, Options and Defaults for the Primary Master Submenu of the Main Menu

Menu Field Options Default Description

Heads:

Sectors:

Maximum Capacity:

Multi-Sector Transfers:

LBA Mode Control:

Transfer Mode:

Ultra DMA Mode:

A number between 1 and 16

–— This item is active only when Hard Disk is selected as type. You can

change the value by incrementing (pressing the [Spacebar]), by typing in the number, or using the “+” and “-” keys.

A number between 0 and 63

Display only –— Displays the maximum capacity of the drive calculated from the

Disabled

2 Sectors

4 Sectors

8 Sectors

16 Sectors

Disabled

Enabled

Standard

Fast PIO 1

Fast PIO 2

Fast PIO 3

Fast PIO 4

Multiword DMA 1

Multiword DMA 2

Disabled

Mode 0

Mode 1

Mode 2

Mode 3

Mode 4

Mode 5

–— This item is active only when Hard Disk is selected as type. You can

change the value by incrementing (pressing the [Spacebar]), by typing in the number, or using the “+” and “-” keys.

parameters of the hard disk when Auto is selected and the type is identified as hard disk.

[16 Sectors] This option cannot be changed when Auto is selected. Specify the

[Enabled] Enables or disables logical Block Addressing in place of Cylinder, Head,

[Multiword DMA 2]

number of sectors per block for multiple sector transfer.

Sector addressing. This option cannot be changed when Auto is selected.

Selects the method for moving data to/from the drive. Autotype the drive to select the optimum transfer mode. This option cannot be changed when Auto is selected.

[Mode 5] Selects the method for moving data to/from the drive. Autotype the

drive to select the optimum transfer mode. This option cannot be changed when Auto is selected.

Exiting from Main Menu

When you have finished setting the parameters on this menu, you can either exit from the setup utility, or move to another menu. If you wish to exit from the setup utility, press the [ press [F10] to exit and save. If you wish to move to another menu, use the cursor keys.

Esc] key, use the cursor keys to go to the Exit menu, or

LifeBook B Series Notebook BIOS

ADVANCED MENU – SETTING DEVICE FEATURE CONTROLS

The Advanced Menu allows you to:

• Set the I/O addresses for the serial and parallel ports.

• Set the communication mode for the parallel port and

infrared port.

• Select between the display panel and an external

CRT display.

• Enable or disable compensation for your display.

• Configure CPU features.

• Configure USB features.

PhoenixBIOS Setup Utility

Main Advanced Security Boot Info Exit

▲ ▲ ▲ ▲

Serial/Parallel Port Configurations Keyboard/Mouse Features Video Features Internal Device Configurations

▲

CPU Features

▲

USB Features

▲ ▲

Miscellaneous Configurations

Event Logging

• Configure miscellaneous features of the system.

• View the event logging information.

Follow the instructions for Navigating through the Setup

Utility to make any changes.

The following tables show the names of the menu fields for the Advanced Menu and its submenus, all of the options for each field, the default settings and a description of the field’s function and any special information needed to help understand the field’s use.

Item Specific Help

Configures serial ports and parallel ports.

F1 Help ESC Exit

Select Item Select Menu

-/Space Enter

Figure 3. Advanced Menu

Change Values

▲

Select Sub-Menu

F9 Setup Defaults F10 Save and Exit

Table 3: Fields, Options and Defaults for the Advanced Menu

Menu Field Description

Serial/Parallel Port Configurations

Keyboard/Mouse Features When selected, opens the Keyboard/Mouse Features submenu, which allows setting

Video Features When selected, opens the Video Features submenu, which allows setting of the display

When selected, opens the Serial/Parallel Port Configurations submenu which allows the user to modify settings for serial, infrared and parallel ports.

external and internal keyboard and mouse parameters.

parameters, including routing of video signals to different displays.

Table 3: Fields, Options and Defaults for the Advanced Menu

Menu Field Description

Advanced Menu

Internal Device Configurations

When selected, opens the Internal Device Configurations submenu, which allows enabling or disabling the IDE and LAN Controllers.

CPU Features When selected, opens the CPU Features submenu, which allows setting of Intel Speed-

Step features. Also allows you to enable and disable the On Battery/AC Optimization.

USB Features When selected, opens the USB Features submenu, which allows enabling or disabling

USB and SCSI SubClass support.

Miscellaneous Configurations

When selected, opens the Miscellaneous Features submenu, which allows enabling or disabling the power button and Wake Up On LAN, and configuring the volume settings.

Event Logging When selected, opens the event logging submenu.

LifeBook B Series Notebook BIOS

Serial/Parallel Port Configurations Submenu of the Advanced Menu

The Serial/Parallel Port Configurations submenu allows you to set the I/O addresses and interrupt levels for the serial, touch panel, and parallel ports of your notebook.

I/O addresses, DMA channels and Interrupt levels can be entered in various ways, including via the BIOS setup utility, the control software for the I/O device, or the hardware. If any two ports or devices, serial or parallel, have the same I/O address assigned, your notebook will not function normally. Please keep a record of original settings before making any changes in the event that a restoration is required. See your hardware and software documentation as well as the setup utility to determine settings, limitations, etc.

PhoenixBIOS Setup Utility

Advanced

All I/O addresses in Table 4 are in hexadecimal.

• To prevent IRQ and address conflicts, avoid changing the default settings. If you must change the settings, you can call 1-800-8FUJITSU for technical assistance.

• The BIOS will warn you of a resource conflict by placing a yellow asterisk next to each device that is in conflict.

Serial/Parallel Port Configurations

Serial Port: [Enabled] I/O Address: [3F8 - 3FF] Interrupt: [IRQ 4] Touch Panel: [Enabled] I/O Address: [2E8 - 2EF] Interrupt: [IRQ 3] Parallel Port: [Enabled] Mode: [Bi-directional] I/O Address: [378 - 37F] Interrupt: [IRQ 7]

F1 Help ESC Exit

Select Item Select Menu

Figure 4. Serial/Parallel Port Configurations Submenu

-/Space Enter

Change Values Select Sub-Menu

Item Specific Help

[Disabled] The port is disabled.

[Enabled] The port is enabled with user configuration.

[Auto] Plug & Play OS configure the port.

▲

F9 Setup Defaults F10 Save and Exit

Advanced Menu

Table 4: Fields, Options and Defaults for the Serial/Parallel Port Configurations Submenu of Advanced Menu

Menu Field

Options Default Description

Serial Port: • Disabled

• Enabled

• Auto

I/O Address:

• 3F8 - 3FF

• 2F8 - 2FF

• 3E8 - 3EF

• 2E8 - 2EF

Interrupt: • IRQ 3

• IRQ 4

• IRQ 10

• IRQ 11

Touch Panel:

• Disabled

• Enabled

• Auto

I/O Address:

• 3F8-3FF

• 2F8-2FF

• 3E8 - 3EF

• 2E8 - 2EF

Interrupt: • IRQ 3

• IRQ 4

• IRQ 10

• IRQ 11

[Enabled] Configures the serial port using either no configuration (Disabled),

a user defined configuration (Enabled), or by allowing the BIOS or OS to choose the configuration (Auto).

[3F8 - 3FF] Allows user to set the serial port base I/O address when serial port

is Enabled.

[IRQ 4] Allows user to set the serial port interrupt when serial port is

Enabled.

[Enabled] Enables or disables the Touch Panel, or allows the Plug & Play

operating system to choose the configuration (Auto).

[2E8 - 2EF] Allows user to set the touch panel I/O address when the touch

panel is Enabled.

[IRQ 3] Allows user to set the touch panel interrupt when the touch panel

is Enabled.

Parallel Port:

• Disabled

• Enabled

• Auto

Mode: • Output Only

• Bi-directional

• ECP

I/O address:

• 378 - 37F

• 278 - 27F

• 3BC - 3BF

Interrupt: • IRQ 5

• IRQ 7

DMA Channel

• DMA 1

• DMA 3

[Enabled] Configures the parallel port using either no configuration (Dis-

abled), a user defined configuration (Enabled), or by allowing the BIOS or OS to choose the configuration (Auto).

[Bi-directional] When the parallel port is enabled this option is available allowing

the user to set the mode for the parallel port. Bi-directional allows two-way transfer of information between your notebook and a connected parallel device. Output Only (Half Duplex) allows information to be transferred in only one direction, from your notebook to the printer or similar device. ECP Mode allows communication with the ECP class of parallel I/O devices.

[378 - 37F] Allows user to set the parallel port base I/O address when the

parallel port is Enabled.

[IRQ 7] Allows user to set the parallel port interrupt when the parallel port

is Enabled.

[DMA 1] This appears when parallel port is Enabled and Mode is set to ECP.

Selects the direct memory access channel for the parallel port.

LifeBook B Series Notebook BIOS

Keyboard/Mouse Features Submenu of the Advanced Menu

Keyboard/Mouse Features submenu is for setting parameters of the integrated and external mouse and keyboard.

Main Advanced Security Power Savings Exit

Keyboard/Mouse Features

Numlock: Hot Plug: Internal Pointing Device: Initialization on Resume:

F1 Help ESC Exit

Select Item Select Menu

Figure 5. Keyboard/Mouse Features Submenu

PhoenixBIOS Setup Utility

[Auto]

[Enabled] [Auto Disabled] [Fast]

-/Space

Change Values

Enter

▲

Select Sub-Menu

Select power-on state for Numlock.

Item Specific Help

F9 Setup Defaults F10 Save and Exit

Table 5: Fields, Options and Defaults for the Keyboard/Mouse Features Submenu of the Advanced Menu

Menu Field Options Default Description

Numlock: • Auto

• On

• Off

• On/Padlock Off

[Auto] Sets the NumLock function state when the computer

completes booting.

Hot Plug: • Disabled

• Enabled

Internal Pointing Device:

• Auto Disabled

• Manual Setting

• Always Enabled

• Always Disabled

Initialization on Resume:

• Fast

• Normal

[Enabled] Enables and disables the ability to plug in a device and have

it immediately recognized and active.

[Auto Disabled]

Selects pointing device configurations. Auto Disabled: The internal pointing device is disabled when a PS/2 external pointing device is connected. Manual Setting: When selected, allows you to enable or disable the internal pointing device with a Hot key. Always Enabled/Always Disabled: The internal pointing device is always enabled or disabled.

[Fast] When Fast is selected, the initialization of external PS/2

devices is optimized to speed up on resume. When Normal is selected, initialization is not optimized. Note that this feature is designed for Windows XP systems only. When external PS/2 devices don’t function after resume, set to Normal.

Video Features Submenu of the Advanced Menu

The Video Features Submenu is for setting the display parameters.

PhoenixBIOS Setup Utility

Main Advanced Security Power Savings Exit

Advanced Menu

Video Features

Display [Auto]

Item Specific Help

Select display terminal.

Compensation: [Enabled]

F1 Help ESC Exit

Select Item Select Menu

Figure 6. Video Features Submenu

-/Space Enter

Change Values

▲

Select Sub-Menu

F9 Setup Defaults F10 Save and Exit

Table 6: Fields, Options and Defaults for the Video Features Submenu of the Advanced Menu

Menu Field Options Default Description

Display: • Internal Flat-Panel

• External

• Auto

[Auto] Selects where the video signal will be routed.

Compensation: • Disabled

• Enabled

[Enabled] Enables or disables compensation which controls spacing

on the display. When enabled, displays with less than pixel resolution 800 x 600 will still cover the entire screen.

LifeBook B Series Notebook BIOS

Internal Device Configurations Submenu of the Advanced Menu

The Internal Device Configurations submenu allows the user to configure other internal devices.

PhoenixBIOS Setup Utility

Main Advanced Security Power Savings Exit

Internal Device Configurations

IDE Controller: [Enabled] Modem Controller: [Enabled] LAN Controller: [Auto] Wireless LAN: [Enabled]

Item Specific Help

[Disabled] IDE port is disabled.

[Enabled] IDE port is enabled.

F1 Help ESC Exit

Select Item Select Menu

Figure 7. Internal Device Configurations Submenu

-/Space Enter

Change Values

▲

Select Sub-Menu

F9 Setup Defaults F10 Save and Exit

Table 7: Fields, Options and Defaults for Internal Device Configurations Submenu of Advanced Menu

Menu Field Options Default Description

IDE Controller: • Disabled

• Enabled

[Enabled] Enables or disables selected IDE devices.

Modem Controller:

LAN Controller: • Enabled

Wireless LAN: • Disabled

• Disabled

• Enabled

• Disabled

• Auto

• Enabled

[Enabled] Enables or disables the modem device.

[Auto] LAN controller is enabled or disabled automatically, based

upon system detection of the presence of a LAN cable. NOTE: This field may not be present if you have a wireless LAN installed.

[Enabled] Enables or disables the Wireless LAN device.

CPU Features Submenu of the Advanced Menu

The CPU Features submenu configures certain features of the CPU in the system.

PhoenixBIOS Setup Utility

Main Advanced Security Power Savings Exit

Advanced Menu

Item Specific HelpCPU Features

SpeedStep(R) Technology: [Enabled]

On Battery: [Battery Optimized]

On AC: [Maximum Performance]

F1 Help ESC Exit

Select Item Select Menu

Figure 8. CPU Features Submenu

-/Space Enter

Change Values

▲

Select Sub-Menu

Select Enhanced Intel(R) SpeedStep(R) Technology enabled or disabled.

F9 Setup Defaults F10 Save and Exit

Table 8: Fields, Options and Defaults for the CPU Features Submenu of the Advanced Menu

Menu Field Options Default Description

SpeedStep(R) Technology:

On Battery: • Maximum Performance

• Disabled

• Enabled

• Battery Optimized

• Automatic

[Enabled] Enables or disables the SpeedStep

Technology features.

[Battery Optimized] Allows the user to select the CPU

operational mode when the system is running on battery power.

On AC: • Maximum Performance

• Battery Optimized

• Automatic

[Maximum Performance] Allows the user to select the CPU

operational mode when the system is running on AC power.

LifeBook B Series Notebook BIOS

USB Features Submenu of the Advanced Menu

The USB Features submenu configures the USB capabilities of the system.

PhoenixBIOS Setup Utility

Main Advanced Security Power Savings Exit

USB Features

Legacy USB Support: [Enabled]

SCSI SubClass Support: [Enabled]

Item Specific Help

[Disabled] The feature is disabled.

[Enabled] Legacy USB Emulation is enabled and USB devices are available without USB aware OS.

F1 Help ESC Exit

Select Item Select Menu

Figure 9. USB Features Submenu

-/Space Enter

Change Values

▲

Select Sub-Menu

F9 Setup Defaults F10 Save and Exit

Table 9: Fields, Options and Defaults for the USB Features Submenu of the Advanced Menu

Menu Field Options Default Description

Legacy USB Support:

Disabled

Enabled

[Enabled] When Disabled is selected, legacy USB emulation is dis-

abled. When Enabled is selected, legacy USB emulation is enabled and USB devices are available without USB-aware OS.

SCSI SubClass Support:

Disabled

Enabled

[Enabled] When Enabled is selected, USB devices that belong to the

SCSI subclass in the mass storage class (e.g., USB Memory Key) are enabled. Note that enabling this feature may cause the system to hang during POST, depending on the device that is connected.

Advanced Menu

Miscellaneous Features Submenu of the Advanced Menu

The Miscellaneous Features submenu configures the power button and performance control features of the system.

PhoenixBIOS Setup Utility

Main Advanced Security Power Savings Exit

Miscellaneous Configurations

Power Button: [Disabled] Wake up on LAN: [Disabled]

Volume Setting: [Middle]

Item Specific Help

Configures the power button.

*ACPI OS ignores this setting.

F1 Help ESC Exit

Select Item Select Menu

-/Space

Figure 10. Miscellaneous Features Submenu

Change Values

Enter

Select Sub-Menu

▲

F9 Setup Defaults F10 Save and Exit

Table 10: Fields, Options and Defaults for the Miscellaneous Features Submenu of the Advanced Menu

Menu Field Options Default Description

Power Button: • Disabled

• Power Off

[Disabled] Allows you to enable the power button to power off the

system, or to have no effect when pressed.

Wake up on LAN:

Volume Setting:

• Disabled

• Enabled

Off

Minimum

Middle

Maximum

[Disabled] When Enabled is selected, the system will wake up when

the internal LAN receives a Magic Packet while it is powered off.

[Middle] Allows you to set or disable the system volume level.

LifeBook B Series Notebook BIOS

Event Logging Submenu of the Advanced Menu

The Event Logging submenu is for setting up the logs for DMI event logging.

PhoenixBIOS Setup Utility

Main Advanced Security Power Savings Exit

Event Logging

Event Log Capacity: Space Available Event Log Validity: Valid

View Event Log: [Enter]

Item Specific Help

Press <Enter> key to view the contents of the event log.

Event Logging: [Enabled] System Boot Event: [Disabled]

Clear All Event Logs: [No]

Mark Events as Read: [Enter]

F1 Help ESC Exit

Select Item Select Menu

Figure 11. Event Logging Submenu

-/Space Enter

Change Values

▲

Select Sub-Menu

F9 Setup Defaults F10 Save and Exit

Table 11: Fields, Options and Defaults for the Event Logging Submenu of the Advanced Menu

Menu Field Options Default Description

Event Log Capacity: Space

Available

Display only

Event Log Validity: Valid Display only

View Event Log: • Enter [Enter] Allows you to view content of event log.

Event Logging: • Disabled

• Enabled

System Boot Event: • Disabled

• Enabled

Clear All Event Logs: • No

• Yes

Mark Events as Read: • Enter [Enter] Allows you to select all events currently in the event log as read.

[Enabled] Turns event logging on and off for all DMI events.

[Disabled] Turns event logging on and off for DMI system boot events.

[No] When set to [Yes] all event logs will be cleared at next boot.

Security Menu

SECURITY MENU – SETTING THE SECURITY FEATURES

The Security menu allows you to set up the data security features of your notebook to fit your operating needs and to view the current data security configuration. Follow the instructions for Navigating through the Setup Utility

to make any changes.

• If you set a password, write it down and keep it in a safe place. If you forget the password you will have to contact your support representative to regain access to your secured functions and data.

• If you make an error when re-entering the password a [Warning] will be displayed on the screen. To try again, press the Enter key and then retype the password. Press the Esc key to abort the password setting process.

• Boot sector protection must be set to [Normal] to install or upgrade an operating system.

PhoenixBIOS Setup Utility

Main Advanced Security Boot Info Exit

Supervisor Password Is: Clear User Password Is: Clear

Set Supervisor Password [Enter] Set User Password [Enter] Minimum User Password Length [0] Password on Boot: [Disabled]

On Automatic Wake up: [Disabled]

KB Lock on Resume: [Disabled] Boot from Removable Media: [All] Flash Write [Enabled] Hard Disk Security

▲▲

Owner Information

• Entering a password incorrectly three times in a row will cause the keyboard and mouse to be locked out and the warning [System Disabled] to be displayed. If this happens, restart the computer by turning off and on the power with the power switch and use the correct password on reboot.

• If the Password on Resume is Enabled and the Password on Boot is Disabled you will not have to type your password upon resuming the system from the Suspend or Save-to-Disk modes. Power Management Security will work only if Password on Boot is enabled.

The following tables show the names of the menu fields for the Security menu and submenus, all of the options for each field, the default settings and a description of the field's function and any special information needed to help understand the field's use. The default condition is no passwords required and no write protection.

Item Specific Help

Press <Enter> key to set Supervisor password to enable any password features.

Then password entry is required to enter BIOS Setup.

Security Panel on Resume: [Enabled]

F1 Help ESC Exit

Select Item Select Menu

-/Space

Figure 12. Security Menu

Change Values

Enter

Select Sub-Menu

▲

F9 Setup Defaults F10 Save and Exit

LifeBook B Series Notebook BIOS

Table 12: Fields, Options and Defaults for the Security Menu

Menu Field Options Default Description

Supervisor Password is:

–— Clear A display-only field. Set is displayed when the system supervisor

password is set and Clear when it is not.

User Password is: –— Clear A display-only field. Set is displayed when the general user pass-

word is set, and Clear when it is not.

Set Supervisor Password

–— [Enter] Sets, changes or cancels Supervisor Password. Supervisor Pass-

word may be up to seven characters long and must include only letters or numbers (no symbols). Passwords are NOT casesensitive. To cancel a password press [Enter] instead of entering characters in the Enter New Password field and in the Re-enter New Password field. When a Supervisor Password is set it must be used to access BIOS setup utility.

Set User Password –— [Enter] This field can only be accessed if the Supervisor Password is set.

Sets, changes or cancels the User Password. A User Password may be up to seven characters long and must include only letters or numbers (no symbols). Passwords are NOT case-sensitive. To cancel a password press the Enter key instead of entering characters in the Enter New Password field and in the Re-enter New Password field. When a User Password is set it must be used to access the setup utility.

Minimum User

–— [0] –—

Password Length:

Password on Boot: • Disabled

• First Boot

• Every Boot

[Disabled] When set to Disabled, no password is required. When set to First

Boot, password entry is required only before first boot. When Every Boot is selected, password is required every time the system is booted.

On Automatic Wake up:

• Disabled

• Enabled

[Disabled] When Disabled, a password is not required on LAN or RTC

automatic wake up. When Enabled, password is required on automatic wake up.

KB Lock on Resume:

Boot from Removable Media:

• Disabled

• Enabled

• All

• Supervisor

only

[Disabled] When Enabled, PS/2 keyboard or mouse inputs are locked out at

Resume From Suspend or Save-to-Disk until entering password.

[All] When Supervisor Only is selected, only the Supervisor can boot

from removable media. Only the user who enters the Supervisor Password before OS boot is treated as the Supervisor. When All is selected, booting from removable media is not restricted.

Flash Write: • Disabled

• Enabled

[Enabled] When disabled, the BIOS Flash memory is write-protected. When

enabled, the BIOS Flash memory is not write-protected.

Hard Disk Security: –— –— Configures hard disk security features.

Table 12: Fields, Options and Defaults for the Security Menu

Menu Field Options Default Description

Security Menu

Owner Information:

Security Panel on Resume:

–— –— Sets Owner information.

• Disabled

• Enabled

[Enabled] Allows you to enable or disable the Security Panel feature upon

Resume from Suspend.

Exiting from the Security Menu

When you have finished setting the parameters on the Security Menu, you can either exit from setup utility or move to another menu. If you wish to exit from setup utility, press the [ another menu, use the cursor keys.

Esc] key to go to the Exit Menu. If you wish to move to

LifeBook B Series Notebook BIOS

Hard Disk Security Submenu of the Security Menu

The Hard Disk Security submenu is for configuring hard disk security features.

PhoenixBIOS Setup Utility

Main Advanced Security Power Savings Exit

Hard Disk Security

Primary Master Password Is: Clear

Item Specific Help

Press <Enter> key to set Hard Disk Password.

Set Primary Master Password: [Enter]

The hard disk is locked with the password. Data

Password Entry on Boot: [Enabled]

in the locked disk can not be read on other systems.

F1 Help ESC Exit

Select Item Select Menu

-/Space Enter

Figure 13. Hard Disk Security Submenu

Change Values

▲

Select Sub-Menu

F9 Setup Defaults F10 Save and Exit

Table 13: Fields, Options and Defaults for the Hard Disk Security Submenu of the Security Menu

Menu Field Options Default Description

Primary Master Password Is:

___ Clear A display-only field. Set is displayed when the Master Password is

set and Clear when it is not.

Set Primary Master Password

Password Entry on Boot:

___ [Enter] Sets, changes or cancels Primary Master Password. The Primary

• Disabled

• Enabled

[Enabled] When set to Disabled, it is not necessary to enter a hard disk pass-

Master Password may be up to seven characters long and include only letters or numbers (no symbols). Passwords are NOT case- sensitive. To cancel a password press the Enter key instead of entering characters in the Enter New Password field and in the Re-enter New Password field. When a Primary Master Password is set it must be used to access the hard disk. Data on the hard disk cannot be read on other systems.

word before booting. The hard disk is still password-protected without password entry.

Owner Information Submenu of the Security Menu

The Owner Information submenu is for setting owner information.

PhoenixBIOS Setup Utility

Security

Boot Menu

Owner Information Is: Clear

Set Owner Information [Enter]

Foreground Color: [Gray] Background Color: [Black]

F1 Help ESC Exit

Select Item Select Menu

-/Space Change Values Enter Select Sub-Menu

Figure 14. Owner Information Submenu

▲

Item Specific Help

F9 Setup Defaults F10 Save and Exit

Table 14: Fields, Options and Defaults for the Owner Information Submenu of the Security Menu

Menu Field Options Default Description

Owner Information Is:

–— Clear Display only.

Set Owner

–— [Enter] Field to write owner

Information:

Foreground Color: • Black

• Blue

• Green

• Cyan

• Red

• Magenta

Background Color: • Black

• Blue

• Green

• Cyan

• Red

• Magenta

• Brown

• White

• Gray

• Light Blue

• Light

Green

• Brown

• White

• Gray

• Light Blue

• Light

Green

• Light Cyan

• Light Red

• Light Magenta

• Light Yellow

• Bright White

• Light Cyan

• Light Red

• Light Magenta

• Light Yellow

• Bright White

information (i.e., name).

[Gray]

[Black]

LifeBook B Series Notebook BIOS

BOOT MENU – SELECTING THE OPERATING SYSTEM SOURCE

The Boot Menu is used to select the order in which the BIOS searches sources for the operating system. Follow the instructions for Navigating through the Setup Utility to make any changes.

PhoenixBIOS Setup Utility

Main Advanced Security Power Savings Boot

Quick Boot: [Enabled] Boot Time Diagnostic Screen: [Disabled] Boot Menu: Preboot Execution Environment: [Disabled]

▲

Boot Device Priority

F1 Help ESC Exit

Select Item Select Menu

-/Space Enter

Figure 15. Boot Menu

The following tables show the names of the menu fields for the Boot menu and its submenu, all of the options for each field, the default settings and a description of the field's function and any special information needed to help understand the field's use.

Item Specific Help

[Enabled]

Change Values

▲

Select Sub-Menu

[Disabled] All diagnostic tests will be done.

[Enabled] Some diagnostic tests may be skipped while booting to speed up.

F9 Setup Defaults F10 Save and Exit

Table 15: Fields, Options and Defaults for the Boot Menu

Menu Field Options Default Description

QuickBoot: • Disabled

• Enabled

Boot-time Diagnostic Screen:

Boot Menu: • Disabled

Preboot Execution Environment:

Boot Device Priority

• Disabled

• Enabled

• Disabled

• Enabled

• Selects the Boot

Device Priority submenu

[Enabled] Turns on and off booting with a truncated set of Power On

Self Test. (Fewer tests mean faster turn on.)

[Disabled] Turns on and off display of test results instead of Fujitsu

logo screen during Power On Self Test.

[Enabled] When disabled, BOOT menu is disabled and the F12 key is

ignored; when enable, BOOT Menu is enabled. This is only active when a Supervisor Password has been set.

[Disabled] When enabled, booting from a network server (Preboot

Execution Environment) is enabled.

— This menu allows setting up the source for the operating

system.

Info Menu

Boot Device Priority Submenu of the Boot Menu

The Boot Device Priority submenu is for setting the order of checking of sources for the operating system.

PhoenixBIOS Setup Utility

Main Advanced Security Power Savings Boot

Boot Device Priority

+Floppy Disk Drive +Hard Disk Drive CD-ROM Drive

F1 Help ESC Exit

Select Item Select Menu

-/Space

Figure 16. Boot Device Priority Submenu

Change Values

Enter

▲

Select Sub-Menu

Item Specific Help

Keys used to view or configure devices:

<Enter> expands or collapses devices with a + or -. <Ctrl+Enter> expands all. <Shift+1> enables or disables a device. <+>/<Space> or <-> moves the device up or down. <d> removes a device that is not installed.

F9 Setup Defaults F10 Save and Exit

Table 16: Fields, Options and Defaults for the Boot Device Priority Submenu of the Boot Menu

Menu Field Description

+Floppy Disk Drive +Hard Disk Drive CD-ROM Drive

The boot selections determine the order in which the BIOS searches for the operating system during a startup sequence. To change the order highlight one source by using the [up] or [down] cursor keys and then press the [+] or [-] key to change the order number for that source. Be sure to save your changed order when you exit the BIOS setup utility.

Exiting from Boot Menu

When you have finished setting the boot parameters with the Boot menu, you can either exit from the setup utility or move to another menu. If you wish to exit from the setup utility press the [ move to another menu, use the cursor keys.

Esc] key to go to the Exit menu. If you wish to

LifeBook B Series Notebook BIOS

INFO MENU - DISPLAYS BASIC SYSTEM INFORMATION

The Info menu is a display-only screen that provides the configuration information for your notebook.

The following table shows the names of the menu fields for the Info menu and the information displayed in those fields. These fields are for information purposes only, and are not editable.

PhoenixBIOS Setup Utility

Main Advanced Security Power Savings Boot Info

BIOS Version: 1.03 BIOS Date: 05/07/2004 BIOS Area: E000h - FFFFh

CPU Type: ULV Intel(R) Pentium(R) M CPU Speed: 1.10 GHz L1 Cache: 64 KB L2 Cache: 1024 KB

Total Memory: 512 MB Memory Slot: 512 MB DDR SDRAM

The information displayed on this screen is variable according to the unit you purchased.

Item Specific Help

F1 Help ESC Exit

Select Item Select Menu

-/Space Change Values

Enter Select Sub-Menu

Figure 17. Info Menu

▲

F9 Setup Defaults F10 Save and Exit

Table 17: Fields, Options and Defaults for the Info Menu

Menu Field Default Menu Field Default

BIOS Version: 1.03 L1 Cache: 64 KB

BIOS Date: 05/07/2004 L2 Cache: 1024 KB

BIOS Area: E000h – FFFFh Total Memory: 512 MB

CPU Type: ULV Intel(R) Pentium(R) M Memory Slot: 512 MB DDR SDRAM

CPU Speed: 1.10 GHz

Exit Menu

EXIT MENU – LEAVING THE SETUP UTILITY

The Exit Menu is used to leave the setup utility. Follow the instructions for Navigating through the Setup Utility to make any changes.

PhoenixBIOS Setup Utility

Main Advanced Security Power Savings Boot Exit

Exit Saving Changes Exit Discarding Changes Load Setup Defaults Discard Changes Save Changes

F1 Help ESC Exit

Select Item Select Menu

-/Space Change Values

Enter Select Sub-Menu

Figure 18. Exit Menu

▲

Item Specific Help

Exit System Setup and save your changes to CMOS.

F9 Setup Defaults F10 Save and Exit

The following table shows the names of the menu fields for the Exit menu, the default settings and a description of the field's function and any special information needed to help understand the field's use.

Table 18: Fields, Options and Defaults for the Exit Menu

Menu Field

Optional Keyboard Shortcut

Description

Exit Saving Changes

Exit Discarding Changes

Load Setup Defaults

Press the F10 key Exit Saving Changes and Exit will store all the entries on every menu of the setup

–— Selecting Exit Discarding Changes and Exit will exit the setup utility with out writ-

Press the F9 key Selecting Load Setup Defaults will load the factory preset default values for all

utility to the BIOS memory and then exit the setup utility. A confirmation message Save Configuration changes and exit now? [Yes] [No] will be displayed.

ing to the BIOS memory. When the BIOS recognizes this selection it will load the operating system and begin operation.

menu fields, then display the message Load default configuration now? [Yes] [No]. When confirmed the setup utility will return to the Exit Menu. To return to another menu follow the directions in the

Setup Utility

section.

Navigating through the

LifeBook B Series Notebook BIOS

Table 18: Fields, Options and Defaults for the Exit Menu

Menu Field

Discard Changes

Save Changes

Optional Keyboard Shortcut

Description

–— Selecting Discard Changes loads the previous values in BIOS memory for all menu

fields. The message Load previous now? [Yes] [No] will be displayed. When confirmed the setup utility will return to the Exit menu. To go to another menu, follow the directions in the

Navigating through the Setup Utility section.

–— Selecting Save Changes will cause the new settings in all menus to be written to

the BIOS memory. The message Save configuration changes now? [Yes] [No] will be displayed. When confirmed, the setup utility will return to the Exit menu. To return to another menu, follow the directions in the

through the Setup Utility

section.

Navigating

Fujitsu B3000 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Entering the BIOS Setup Utility

Navigating through the Setup Utility

Entering the Setup Utility After a Configuration Change or System Failure
