Data Sheet FUJITSU Display B27-9 TS QHD
Data Sheet
FUJITSU Display B27-9 TS QHD
Advanced 68.5 cm (27-inch) widescreen display The ideal solution for document management and demanding CAD applications.
The Fujitsu Display B27-9 TS QHD is a QHD (2560x1440 resolution) widescreen monitor optimized for pixel, color and performance-hungry professionals. Elaborate down to the last details, it’s the right tool for all professionals.
With its stylish matt black housing, 5-in-1 adjustable stand base and outstanding picture performance, it’s satisfying all needs of demanding applications.
Almost bezel-free housing for fashionably or seamless multi-monitor workplace offering you a visual delight.
Adjust monitor into most comfortable position with 5-in-1 stand (150mm height adjust, starting with 40mm picture over desk level, 35° backward tilt, 345° swivel and 90° pivot function)
Build-In accessories like speakers, USB 3.1 Gen 1 hub (3x downstream type A, 1x connector type C) and cable guide save costs and clean desk space
Easy congure monitor with DisplayView™ per mouse click. Optimize workspace
using desktop partioning function.
Multi-generation compatibility with DisplayPort™, HDMI and DVI (dual-link)
interface
In-Plane-Switching (IPS) monitor with vivid colors and generous 27 inch diagonal that offers ideal picture quality for fatigue-proof work. Robust design released for 24h/7 days permanent operation.
Page 1 / 5 www.fujitsu.com/emeia/products/computing/peripheral/displays
Data Sheet FUJITSU Display B27-9 TS QHD
Technical details
In-Plane Switching (IPS) technology, Eco button for Eco mode and 3-coloured Eco status LED, 5-in-1 Stand, Always
available USB (in operating and standby mode), DisplayView™ Software, 24/7 usage, Cable guide, Integrated
speakers
Stand 5-in-1 Stand Height adjust range 150 mm Picture height over desk (min) 40 mm Rotation to portrait 90° Tilt angle -5° / +35° Swivel angle 345° Panel and backlit In-Plane Switching (IPS) technology/LED Screen Surface Treatment 3H hard coating, Anti-glare Contrast - typical 1,000:1 Contrast - advanced 20,000,000:1 Response time gray to gray typical 5 ms (in Video mode) Viewing angle (h/v) - typical 178°/178° CR10:1 Color performance 16.7 million colors (8-bit) High color gamut - typical 100% sRGB color space Brightness - typical 350 cd/m² Aspect ratio 16:9 Diagonal Size 68.5 cm (27-inch) Resolution (native) 2,560 x 1,440 pixel Resolution (interpolated) 1,920 x 1,200 pixel, 1,920 x 1,080 pixel, 1,680 x 1,050 pixel, 1,600 x 900 pixel, 1,440 x 900 pixel, 1,280 x 1,024
pixel, 1,280 x 720 pixel, 1,024 x 768 pixel, 800 x 600 pixel, 640 x 480 pixel
Picture size 597 x 336 mm Pixel Pitch 0.233 mm Horizontal 30 - 100 kHz Vertical 48 - 76 Hz Frequencies - bandwidth 360 MHz (DisplayPort) DisplayPort 1 x DisplayPort 1.2 HDMI 1 x HDMI 1.4 DVI 1 x DualLink DVI Audio signal output 3.5 mm stereo phone jack for head phone Audio signal input 3.5 mm stereo phone jack Audio sound output 2 x 2 W USB downstream 4 x USB 3.1 Gen1 (2 side USB: 1x Type A + 1x Type C ; 2 bottom USB: Type A) USB upstream 1 x USB 3.1 Gen1 Notes 6 tactile keys on front side Direct Access Keys Brightness, ECO, Input, Mode, Audio, Menu Languages Arabic, Czech, Danish, Dutch, English, Finnish, French, German, Italian, Norwegian, Polish, Portuguese, Russian,
Spanish, Swedish, Turkish, Japanese, Chinese traditional, Chinese simply
Brightness / Contrast Brightness, Contrast, Black level, ACR Mode sRGB, Low Blue Light, Ofce, Photo, Video, Custom Color 5000K, 6500K, 7500K, Native, RGB Adjust OSD Language, OSD-Timeout, OSD rotation Image adjust Expansion, Saturation, Sharpness Audio Mute, Volume, Input for HDMI and DP interface Information Model name, Serial number, Signal input, Resolution/mode, Display mode , Color Temperature, ACR Status Advanced settings Overdrive, DDC/CI, Factory Recall
Page 2 / 5 www.fujitsu.com/emeia/products/computing/peripheral/displays
Data Sheet FUJITSU Display B27-9 TS QHD
Power consumption (typical)
Soft switch off 0.16 W Power save mode 0.17 W Operating with EPA settings 16.5 W Total Energy Consumption (ETEC) 51.81 kWh/year Operating maximum brightness 27 W Power supply integrated Power notes Speakers off, USB not connected
ETEC and EPA refer to ENERGY STAR® 8.0 Power save mode according to EEI test conditions
Electrical values
Rated voltage range 100 V - 240 V Rated frequency range 50 Hz - 60 Hz Protection class 1
Compliance
Model B27-9TQ Global ENERGY STAR® 8.0, TCO Certied Displays 8.0, EPEAT® Bronze (dedicated regions), Zero bright and dark pixel faults,
Subpixel faults according to ISO9241-307 (Pixel fault class I), TÜV Flicker Free Certied, TÜV Low Blue Light Certied
Europe Energy Efciency Class: A+, EN 60950, CE certication according to EC Directive 2004/108/EEC, RoHS, WEEE, IT-Eco-
Declaration
Australia/New Zealand RCM China CCC Germany TÜV GS Russia EAC South Korea KC (planned), E-Standby Taiwan BSMI USA/Canada FCC Class B, cUL Compliance link https://sp.ts.fujitsu.com/sites/certicates
Dimensions / Weight / Environmental
Dimension without stand (W x D x H) 612.7 x 63.5 x 363.6
24.12 x 2.50 x 14.31 inch
Dimension with stand (W x D x H) 612.7 x 275 x 385.6
24.12 inch x 10.83 x 15.18 inch
Weight (unpacked) 7.60 kg
16.75 lbs
Weight (Monitor only) 5.04 kg
11.11 lbs
Operating ambient temperature 5 - 35 °C Operating relative humidity 10 - 85 % (non condensing)
Miscellaneous
Miscellaneous VESA DDC/ CI, Flat Display Mounting Interface VESA MIS-D 100 C, Kensington lock prepared Color Matt black
Package content
Display delivered accessories DisplayPort data cable 1.8 m
USB-cable 1.8 m (USB-A to USB-B) Power cable for wall socket (Euro-Schuko-Type CEE7) 1.8 m
Quickstart yer
Safety notes
Display delivered accessories notes Power cable with IEC-60320-C13, 3-pin connector on display side
Data cables and USB cable detachable on display
User manual and DisplayView Software is available via download
Packaging information
Packaging dimension (mm) 735 x 228 x 470 mm
Page 3 / 5 www.fujitsu.com/emeia/products/computing/peripheral/displays
Data Sheet FUJITSU Display B27-9 TS QHD
Packaging information
Packaging dimension (inch) 28.94 x 8.98 x 18.5 inch Weight (packed) 9.65 kg Weight (packed) (lbs) 21.27 lbs
Order information
Order Code S26361-K1694-V160 EAN Code 4059595827062
Warranty
Warranty period 3 years (depending on country) Warranty type Collect & Return Service (depending on country specic requirements) Warranty Terms & Conditions http://www.fujitsu.com/warranty Spare Parts availability 5 years after end of product life Service Weblink http://www.fujitsu.com/emeia/products/product-support-services/
