User’s Guide

Learn how to use your Fujitsu LIFEBOOK AH532 notebook



Guide

d’utilisation

Découvrez comment utiliser votre ordinateur portable Fujitsu LIFEBOOK AH532

User’s

Guide

Learn how to use

your Fujitsu LIFEBOOK AH532 notebook

Fujitsu America has made every effort to ensure the accuracy and completeness of this document; however, as ongoing efforts are continually improving the capabilities of our products, we cannot guarantee the accuracy of the contents of this document. We disclaim liability for errors, omissions, or future changes.

Fujitsu, the Fujitsu logo, and LIFEBOOK are registered trademarks of Fujitsu Limited. Intel, Intel Core, and Centrino are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. The ExpressCard word mark and logo are owned by the Personal Computer Memory Card International Association (PCMCIA) and any use of such marks by Fujitsu

America is under license. Roxio is a trademark of Roxio, a division of Sonic Solutions. Omnipass is a trademark of Softex Inc. PowerDVD, PowerDirector, and YouCam are trademarks of CyberLink Corp. Adobe, Acrobat, and Adobe Reader are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries. Energy Star and the Energy Star mark are registered U.S. marks. Skype is a trademark of Skype Limited. Norton and Norton Internet Security are trademarks or registered trademarks of Symantec Corp. in the United States and other countries. The optical player found in some models of the LIFEBOOK notebook incorporates copyright protection technology that is protected by method claims of certain U.S.

patents and other intellectual property rights owned by Macrovision Corporation and other rights users. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.

Manufactured under license from DTS Licensing Limited. DTS, the Symbol, and DTS and the Symbol together are registered trademarks, and DTS Boost is a trademark of DTS (BVI) Limited (in Hong Kong and China) and DTS, Inc. (outside of Hong Kong and China). © DTS, Inc. All Rights Reserved.

All other trademarks mentioned herein are the property of their respective owners. © Copyright 2012 Fujitsu America, Inc. All rights reserved. No part of this publication may be copied, reproduced, or translated, without prior written consent of Fujitsu. No part of this publication may be stored or transmitted

in any electronic form without the written consent of Fujitsu. B5FK-0081-01ENZ0-00

DECLARATION OF CONFORMITY

according to FCC Part 15

Responsible Party Name: Fujitsu America, Inc.

Address: 1250 E. Arques Avenue

Sunnyvale, CA 94085

Telephone: (408) 746-6000

Declares that product: Base Model Configuration: LIFEBOOK AH532 notebook

Complies with Part 15 of the FCC Rules.

This device complies with Part 15 of the FCC rules. Operations are subject to the following two conditions: (1) This device may not cause harmful interference, (2) This device must accept any interference received, including interference that may cause undesired operation.

IMPORTANT SAFETY INSTRUCTIONS

AC adapter output polarity:

This unit requires an AC adapter to operate. Use only UL Listed I.T.E. Class II Adapters with an output rating of 19 VDC, with a current of 3.42 A (65 W).

When using your notebook equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following:

• Do not use this product near water for example, near a bathtub, washbowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

• Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may explode. Check with local codes for

possible special disposal instructions.

SAVE THESE INSTRUCTIONS

For Authorized Repair Technicians Only

DANGER OF EXPLOSION IF LITHIUM (CLOCK) BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE

RECOMMENDED BY THE MANUFACTURER. DISPOSE OF USED BATTERIES ACCORDING TO THE MANUFACTURER’S INSTRUCTION.

OR CONTINUED PROTECTION AGAINST RISK OF FIRE, REPLACE ONLY WITH THE SAME TYPE AND RATING FUSE.

Recycling your battery

Over time, the batteries that run your mobile computer will begin to hold a charge for a shorter amount of time; this is a natural occurrence for all batteries. When this occurs, you may want to replace the battery with a fresh one*. If you replace it, it is important that you dispose of the old battery properly because batteries contain materials that could cause environmental damage if disposed of improperly.

Fujitsu is very concerned with environmental protection, and has enlisted the services of the Rechargeable Battery Recycling Corporation (RBRC)**, a non-profit public service organization dedicated to protecting our environment by recycling old batteries at no cost to you.

RBRC has drop-off points at tens of thousands of locations throughout the United States and Canada. To find the location nearest you, go to www.RBRC.org

or call 1-800-822-8837.

If there are no convenient RBRC locations near you, you can also go to the EIA Consumer Education Initiative website (http://EIAE.org/ convenient disposal location.

Remember – protecting the environment is a cooperative effort, and you should make every effort to protect it for current and future generations. * To order a new battery for your Fujitsu mobile computer, go to the Fujitsu shopping site at www.shopfujitsu.com

www.fujitsu.ca/products/notebooks

** RBRC is an independent third party to which Fujitsu provides funding for battery recycling; RBRC is in no way affiliated with Fujitsu.

in Canada.

in the US or

) and search for a

Table of Contents

About This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Conventions Used in the Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Fujitsu Contact Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Chapter 1 Getting to Know Your LIFEBOOK

Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Locating the Controls and Connectors. . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Top Components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Left-Side Panel Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Right-Side Panel Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Back Panel Components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Bottom Components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Status Indicator Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Wireless Status Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Power Status Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Battery Level Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Hard Drive/Optical Drive Access Indicator . . . . . . . . . . . . . . . . . . . . . . . . 22

NumLk Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

CapsLock Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Keyboard. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Using the Keyboard. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Touchpad Pointing Device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Double-Clicking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Navigating Using Gestures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Touchpad Control Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Volume Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Controlling the Volume. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Chapter 2 Getting Started with Your LIFEBOOK

Power Sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Connecting the Power Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Display Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Opening the Display Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Adjusting Display Panel Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Using the Keyboard. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Using the Power Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Using the PC Settings Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Using the Windows Mobility Center . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Starting Your LIFEBOOK Notebook. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Power On . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Boot Sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Hard Disk Drive Passwords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

BIOS Setup Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Booting the System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Starting Windows the First Time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Power Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Power/Suspend/Resume Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Sleep Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Hibernation (Save-to-Disk) Feature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Windows Power Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Restarting the System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Powering Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

ENERGY STAR® Compliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Chapter 3 User-Installable Features

Lithium ion Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Recharging the Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Replacing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Optical Drive. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Media Player Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Loading Media on Your Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Removing Media . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Emergency Optical Drive Tray Release . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Using the Media Player Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Using Media Player on Battery Power . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Using ExpressCards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Installing ExpressCards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Removing ExpressCards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Secure Digital Cards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Installing SD Cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Removing an SD Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Memory Upgrade Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Installing Memory Upgrade Modules. . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Removing a Memory Upgrade Module . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Checking the Memory Capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Device Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Internal LAN (RJ-45) Jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Universal Serial Bus Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Headphone/Line-Out Jack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Microphone/Line-In Jack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

External Video Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

HDMI Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Chapter 4 Troubleshooting Your LIFEBOOK

Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Identifying the Problem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Specific Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Power On Self Test Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Restoring Your System Image and Software. . . . . . . . . . . . . . . . . . . . . . . 77

Saving and Recovering Your Factory and System Images . . . . . . . . . . . . 77

Backing Up a System Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Recovery and Utility tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

Recovering your Factory Image using Recovery and Utility. . . . . . . . . . . 85

Downloading Driver Updates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

Chapter 5 Care and Maintenance

Caring for your LIFEBOOK Notebook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

Cleaning your LIFEBOOK notebook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Storing your LIFEBOOK notebook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

Traveling with your LIFEBOOK notebook . . . . . . . . . . . . . . . . . . . . . . . . . 90

Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

Media Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

ExpressCards/SD Cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

Chapter 6 System Specifications

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94

Microprocessor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94

Chipset. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94

Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94

Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

Mass Storage Device Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

Device Ports. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

Keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

Power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

Dimensions and Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

Environmental Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

Popular Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

Included Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

Learning About Your Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99

Glossary/Regulatory

Glossary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101

Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113

Appendix A: WLAN User’s Guide

Before Using the Wireless LAN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

Wireless LAN Devices Covered by this Document . . . . . . . . . . . . . . . . . . 117

Characteristics of the WLAN Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

Wireless LAN Modes Using this Device. . . . . . . . . . . . . . . . . . . . . . . . . . . 118

Wireless Network Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

Disconnecting the WLAN Device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

Activating the WLAN Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

Configuration of the WLAN Device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

Configuring the WLAN Using Windows . . . . . . . . . . . . . . . . . . . . . . . . . . 121

Connection to the network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

Troubleshooting the WLAN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122

Troubleshooting Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122

WLAN Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124

Using the Bluetooth Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125

What is Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125

Where to Find Information About Bluetooth . . . . . . . . . . . . . . . . . . . . . . 125

Appendix B: Using Intel® Wireless Display

Using the Wireless Display technology . . . . . . . . . . . . . . . . . . . . . . . . . . . 127

Starting the WiDi application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129

Preface

About This Guide

The LIFEBOOK AH532 notebook from Fujitsu America provides desktop performance with the 3rd Generation Intel® Core™ processor family. Your notebook has a built-in 15.6” WXGA high-definition color display. This system brings the computing power of a desktop personal computer to a portable environment.

Your computer comes with Microsoft Windows® 8 64-Bit operating system pre-installed. This manual explains how to operate your LIFEBOOK notebook’s hardware and built-in system software.

Conventions Used in the Guide

Keyboard and on-screen keys appear in brackets. Example: [Fn], [F1], [ESC], [ENTER] and [CTRL]. Pages with additional information about a specific topic are cross-referenced within the text.

For example: (“See Installation Procedure on page 43”.) On screen menu items appear in bold. Example: “Click Fujitsu Menu, and select your choice”.

THE INFORMATION ICON HIGHLIGHTS INFORMATION THAT WILL ENHANCE YOUR UNDERSTANDING OF THE SUBJECT MATERIAL.

THE CAUTION ICON HIGHLIGHTS INFORMATION THAT IS IMPORTANT TO THE SAFE OPERATION OF YOUR COMPUTER, OR TO THE INTEGRITY OF YOUR

FILES. PLEASE READ ALL CAUTION INFORMATION CAREFULLY.

HE WARNING ICON HIGHLIGHTS INFORMATION THAT CAN BE HAZARDOUS TO EITHER YOU, YOUR LIFEBOOK NOTEBOOK, OR YOUR FILES. PLEASE

READ ALL WARNING INFORMATION CAREFULLY.

Fujitsu Contact Information

Service and Support

You can contact Fujitsu Service and Support in the following ways:

• Toll free: 1-800-8Fujitsu (1-800-838-5487)

• Website:

USA: us.fujitsu.com/solutions Canada: www.fujitsu.ca

Before you place the call, you should have the following information ready so that the customer support representative can provide you with the fastest possible solution:

• Product name

• Product configuration number

• Product serial number

• Purchase date

• Conditions under which the problem occurred

• Any error messages that have occurred

• Type of device connected, if any

- About This Guide

Fujitsu Shopping Online

You can go directly to the online store by visiting the website at: www.shopfujitsu.com.

YOU MUST HAVE AN ACTIVE INTERNET CONNECTION TO USE THE ONLINE URL LINKS.

Maintaining Latest Configuration

To ensure that you always have the most current driver updates related to your system, you should occasionally access the Fujitsu Software Download Manager (FSDM) utility. The FSDM utility is available to allow you to download the latest drivers, utilities, and applications from the Fujitsu Support site. If you have a Windows 7 or Windows 8 operating system, you will need to go to the Support Site (http://support.fujitsupc.com/CS/Portal/support.do?srch=DOWNLOADS).

Limited Warranty

Your LIFEBOOK notebook is backed by a Fujitsu International Limited Warranty. Check the service kit that came with your notebook for the Limited Warranty period and terms and conditions.

- About This Guide

Chapter 1

Getting to Know Your LIFEBOOK

Overview

This section describes the components of your Fujitsu LIFEBOOK AH532 notebook. We strongly recommend that you read it before using your notebook – even if you are already familiar with notebook computers.

Figure 1. Fujitsu LIFEBOOK AH532 notebook

Locating the Controls and Connectors

Display Panel

Status

Touchpa d

Power/Suspend/ Resume Button

Digital Microphone

Keyboard

HD Web Camera

Indicator

Panel

Pointing

Device

Headphone

Microphone

SD Card Slot

Jack

Stereo Speaker

Figure 2. LIFEBOOK AH532 notebook with display open

- Locating the Controls and Connectors

Top Components

The following is a brief description of your LIFEBOOK notebook’s top components.

Display Panel

The display panel is a color LCD panel with back lighting for the display of text and graphics.

HD Web Camera

The HD web camera (1200x768 pixel) allows you to t ake pictures of yourself to send over the internet. For information on using the microphone and web cam, see the documentation associated with the CyberLink YouCam application.

Digital Microphone

The digital microphone is used in conjunction with the web camera. For information on using the microphone and web cam, see the documentation associated with the CyberLink YouCam application.

Power/Suspend/Resume Button

The Power/Suspend/Resume button allows you to suspend notebook activity without powering off, resume your LIFEBOOK notebook from suspend mode, power off your notebook, and power on your notebook when it has been shut down from Windows. See “Power/Suspend/Resume Button” on page 40.

Stereo Speakers

The built-in dual speakers allow for stereo sound.

Keyboard

A full-size keyboard with dedicated Windows keys. See “Keyboard” on page 23.

Microphone/Line-In Jack

The microphone/line-in jack allows you to connect an external stereo microphone. See “Microphone/Line-In Jack” on page 63.

Headphone/Line-Out Jack

The headphone/line-out jack allows you to connect headphones or external speakers. See “Headphone/Line-Out Jack” on page 62.

- Locating the Controls and Connectors

Secure Digital (SD) Card Slot

The Secure Digital (SD) card slot allows you to install a media card for data storage. This media allows you to transfer data from a variety of different digital devices. See “Secure Digital Cards” on page 56.

Status Indicator Panel

The Status Indicator Panel displays symbols that correspond with a specific component of your LIFEBOOK notebook. See “Status Indicator Panel” on page 20.

Touchpad Pointing Device

The Touchpad pointing device is a mouse-like cursor control with a right button, a left button, and a cursor control pad. See “Touchpad Pointing Device” on page 26.

- Locating the Controls and Connectors

Figure 3. LIFEBOOK notebook left-side panel

ExpressCard Slot

USB 3.0 Ports*

External Video Jack

HDMI Jack

* The USB port on the right above provides Anytime USB Charge capability.

Air Vents

Left-Side Panel Components

The following is a brief description of your LIFEBOOK notebook’s left-side components.

Air Vents

The air vents allow air to circulate through the system to cool down the components.

TO PROTECT YOUR NOTEBOOK FROM DAMAGE AND TO OPTIMIZE PERFORMANCE, BE SURE TO KEEP ALL AIR VENTS UNOBSTRUCTED, CLEAN, AND

CLEAR OF DEBRIS. THIS MAY REQUIRE PERIODIC CLEANING, DEPENDING UPON THE ENVIRONMENT IN WHICH THE SYSTEM IS USED.

O NOT OPERATE THE NOTEBOOK IN AREAS WHERE THE AIR VENTS CAN BE OBSTRUCTED, SUCH AS IN TIGHT ENCLOSURES OR ON SOFT SURFACES LIKE

A BED OR CUSHION.

External Video Port

The external video port allows you to connect an external monitor or LCD projector. See “External Video Port” on page 63.

- Locating the Controls and Connectors

ExpressCard Slot

The ExpressCard Slot allows you to install an ExpressCard. See “Using ExpressCards” on page 54.

USB 2.0 / 3.0 Ports

The USB ports allow you to connect Universal Serial Bus devices. There are three USB 3.0 ports on the left side of the system and one USB 2.0 port on the right. USB 3.0 transfers data at up to 5 Gbps and is backward-compatible with USB 2.0 devices, which transfer data at up to 480 Mbps. See “Universal Serial Bus Ports” on page 61. Note that the front USB 3.0 port on the left side has Anytime USB Charge capability, meaning that even when your system is shut down, this port can still be used to provide power to external devices (for example, when charging a cell phone). For more information, refer to “Universal Serial Bus Ports” on page 61.

HDMI Port

The HDMI port is used to connect compatible digital devices with your computer (such as a high-definition television or AV receiver). See “HDMI Port” on page 64.

- Locating the Controls and Connectors

Figure 4. LIFEBOOK notebook right-side panel

DC-In Jack

Optical DriveUSB 2.0 Port Optical Drive Release Button

Emergency Tray Release

Right-Side Panel Components

The following is a brief description of your LIFEBOOK notebook’s right-side components.

USB 2.0 / 3.0 Ports

Optical Drive

The optical drive bay contains a Dual-Layer Multi-Format DVD Writer. See “Optical Drive” on page 49.

Emergency Tray Release

The emergency tray release is used in the event you want to open the tray when power is not available. See “Emergency Optical Drive Tray Release” on page 51.

- Locating the Controls and Connectors

DC Power Jack

Anti-Theft Lock Slot

LAN (RJ-45) Jack

The DC power jack allows you to plug in the AC adapter to power your LIFEBOOK notebook and charge the internal Lithium ion battery.

Optical Drive Release Button

The optical drive release button opens the optical drive.

Figure 5. LIFEBOOK notebook back panel

Back Panel Components

The following is a brief description of your LIFEBOOK notebook’s back panel components.

LAN (RJ-45) Jack

The internal LAN (RJ-45) jack is used for an internal wired 10/100/1000 Gigabit Ethernet LAN connection. See “Internal LAN (RJ-45) Jack” on page 61.

Anti-theft Lock Slot

The anti-theft lock slot allows you to attach an optional physical lock down device.

- Locating the Controls and Connectors

Lithium ion

Air Vents

(multiple locations)

Memory

Upgrade

Compartment

Battery Bay

Battery Latch

Hard Disk Drive Cover

Figure 6. LIFEBOOK notebook bottom panel

Bottom Components

The following is a brief description of your LIFEBOOK notebook’s bottom panel components.

Memory Upgrade Compartment

Your notebook comes with high speed Double Data Rate 3 Synchronous Dynamic RAM (DDR3 SDRAM). The memory upgrade compartment allows you to expand the system memory capacity of your notebook, thus improving overall performance. See “Memory Upgrade Module” on page 58. Under normal circumstances, it should not be necessary to open this compartment.

- Locating the Controls and Connectors

Hard Disk Drive Cover

The hard disk drive cover is secured over the system hard disk drive. Under normal circumstances, you should not open this compartment

Lithium ion Battery Bay

The battery bay contains the internal Lithium ion battery. It can be opened for the removal of the battery when stored over a long period of time or for swapping a discharged battery with a charged Lithium ion battery. See “Lithium ion Battery” on page 44.

Battery Latches

The battery latches are used to secure the battery in the battery bay. See “Lithium ion Battery” on page 44.

Air Vents

The air vents allow air to circulate through the system to cool down the components.

TO PROTECT YOUR NOTEBOOK FROM DAMAGE AND TO OPTIMIZE SYSTEM PERFORMANCE, BE SURE TO KEEP ALL AIR VENTS UNOBSTRUCTED, CLEAN,

AND CLEAR OF DEBRIS. THIS MAY REQUIRE PERIODIC CLEANING, DEPENDING UPON THE ENVIRONMENT IN WHICH THE SYSTEM IS USED.

O NOT OPERATE THE NOTEBOOK IN AREAS WHERE THE AIR VENTS CAN BE OBSTRUCTED, SUCH AS IN TIGHT ENCLOSURES OR ON SOFT SURFACES LIKE

A BED OR CUSHION.

- Locating the Controls and Connectors

Figure 7. Status Indicator Panel

NumLk

CapsLk

Battery Level

Power Status

Hard Drive/Optical Drive Access

Wireless Status

Status Indicator Panel

The Status Indicators display symbols that correspond to specific components of your Fujitsu LIFEBOOK notebook. The LEDs below each symbol tell you how each of those components is operating.

Wireless Status Indicator

• Blue, solid: Wireless devices have been switched on (using the [Fn]+[F5] key combination).

• Off: Wireless devices are off.

- Status Indicator Panel

Power Status Indicator

• Blue, solid: AC adapter and battery are available and system is fully charged, or AC adapter is plugged in but

battery is not installed.

• Blue, blinking: AC adapter and battery are available and the system is in sleep mode.

• Off: AC adapter is not plugged in.

Battery Level Indicator

The Battery Level indicator displays the charge level of the battery pack, as follows.

With AC Adapter connected:

• Blue, solid: AC adapter is connected and battery is charged.

• Orange, solid: AC adapter is connected and battery is charging.

Without AC Adapter connected:

• Purple, blinking: There is a problem with the battery.

• Off: There is no AC Adapter connected and/or the battery charge level is between 13% and 100%

• If the battery pack is installed while the power is turned off, the battery level indicator will display the charge level for

five seconds after it blinks orange.

• If the AC adapter is not connected or the battery pack is not fully charged when the computer is switched to standby

mode, the indicator will blink. The LED blinks at the rate of one second on/six seconds off.

• Batteries subjected to shocks, vibration or extreme temperatures can be permanently damaged.

• A shorted battery is damaged and must be replaced.

- Status Indicator Panel

Hard Drive/Optical Drive Access Indicator

The Hard Drive/Optical Drive Access indicator glows green when your internal hard drive is being accessed. Note that flickering is normal.

NumLk Indicator

The NumLk indicator glows when the integral keyboard is set in ten-key numeric keypad mode.

CapsLock Indicator

The CapsLock indicator glows when your keyboard is set to type in all capital letters.

- Status Indicator Panel

Keyboard

Fn Key

Function Keys

Numeric Keypad

Application Key

Cursor Keys

Start Key

Figure 8. Keyboard

Using the Keyboard

Your Fujitsu LIFEBOOK notebook has an integral 103-key keyboard, including Windows keys, special function keys, and an integrated numeric keypad. This section describes the following keys.

• Numeric keypad: Your notebook has an integrated numeric keypad which allows you to perform

numeric/mathematical and navigational functions. The ability to toggle between the numerical keys and navigation keys is controlled through the [NumLk] key.

• Cursor keys: Your keyboard contains four arrow keys for moving the cursor or insertion point to the right, left,

up, or down within windows, applications and documents.

- Keyboard

• Function keys: The keys labeled [F1] through [F12], are used in conjunction with the [Fn] key to produce

special actions that vary depending on what program is running.

• Windows keys: These keys work with your Windows operating system. These keys switch between desktop and

Modern Start screen modes and open the Application bar on the bottom of the screen.

Numeric Keypad

The right-hand section of the keyboard serves as a numeric keypad. To activate the keypad functions, press the [NumLk] button. Using the keypad keys, you can enter numerals 0 through 9, perform addition ( + ), subtraction ( - ), multiplication ( * ), or division ( / ), and enter decimal points ( . ) using the keys designated as numeric function key keys. When [NumLk] is not active, you can use the numeric keypad to navigate (Del, Ins, left, right, up, down).

Windows Keys

Your LIFEBOOK notebook has two Windows keys, consisting of a Windows key and an Application key. The Windows key switches between the Modern Start screen and desktop. This button functions the same as your onscreen Start menu button. The Application key opens the Application bar located at the bottom of the screen. (Please refer to your Windows documentation for additional information regarding the Windows keys.)

Cursor Keys

The cursor keys are the four arrow keys on the keyboard which allow you to move the cursor up, down, left and right in applications. In programs such as Windows/File Explorer, it moves the “focus” (selects the next item up, down, left, or right).

Function Keys

Your LIFEBOOK notebook has 12 function keys, F1 through F12. The functions assigned to these keys differ for each application. You should refer to your software documentation to find out how these keys are used.

• The [Fn] key provides extended functions for the notebook and is always used in conjunction with another key.

• [Fn+F3]: Pressing [F3] while holding [Fn] will toggle the Audio Mute on and off.

• [Fn+F4]: Pressing [F4] while holding [Fn] will toggle the Touchpad on and off. Note that the [Fn+F4]

combination only works if Manual Setting is selected in the BIOS. (See “BIOS Setup Utility” on page 38)

• [Fn+F5]: Pressing [F5] while holding [Fn] will toggle the wireless device(s) on and off.

- Keyboard

• [Fn+F6]: Pressing [F6] repeatedly while holding [Fn] will lower the brightness of your display.

• [Fn+F7]: Pressing [F7] repeatedly while holding [Fn] will increase the brightness of the display.

• [Fn+F8]: Pressing [F8] repeatedly while holding [Fn] will decrease the volume of your LIFEBOOK notebook.

• [Fn+F9]: Pressing [F9] repeatedly while holding [Fn] will increase the volume of your LIFEBOOK notebook.

• [Fn+F10]: Pressing the [Fn] + [F10] keys allows you to change your selection of where to send your display

video. Each time you press the key combination, you will step to the next choice, as follows:

•If you only have an external CRT connected, the order is internal -> external CRT -> simultaneous display >

internal display.

•If you only have an HDMI device connected, the order is: internal display -> HDMI display -> simultaneous

display -> internal display.

•If you have external CRT and HDMI devices connected, the order is: internal display -> external CRT ->

simultaneous internal and external CRT -> HDMI display - simultaneous internal and HDMI display -> internal display.

• [Fn+F11]: Pressing [F11] while holding [Fn] will enable and disable ECO mode. ECO mode is designed to

minimize notebook power consumption by reducing the LCD brightness, shutting down the optical drive and ExpressCard functionality and enabling the hard disk drive’s auto power off mode.

- Keyboard

Touchpad Pointing Device

Left Button

Right button

Cursor Control

Figure 9. Touchpad pointing device

The Touchpad pointing device comes built into your Fujitsu LIFEBOOK notebook. It is used to control the movement of the pointer to select items on your display panel. The Touchpad is composed of a cursor control, a left button and a right button. The cursor control works the same way a mouse does, and moves the cursor around the display. It only requires light pressure with the tip of your finger. The left and right buttons function the same as mouse buttons. The actual functionality of the buttons may vary depending on the application that is being used.

- Touchpad Pointing Device

AN EXTERNAL MOUSE CAN BE CONNECTED TO THE USB PORTS ON YOUR LIFEBOOK NOTEBOOK AND USED SIMULTANEOUSLY WITH THE TOUCHPAD. H

OWEVER, IF YOU BOOT THE SYSTEM WITH AN EXTERNAL MOUSE CONNECTED THE TOUCHPAD WILL BE DISABLED OR ENABLED DEPENDING ON THE

SPECIFICATIONS IN YOUR BIOS SETTINGS.

See “BIOS Setup Utility” on page 38.

Clicking

Clicking means pushing and releasing a button. To left-click, move the cursor to the item you wish to select, press the left button once, and then immediately release it. To right-click, move the mouse cursor to the item you wish to select, press the right button once, and then immediately release it (Figure 10). You also have the option to perform the clicking operation by tapping lightly on the Touchpad once (Figure 11).

Figure 10. Clicking with button Figure 11. Clicking with Touchpad

Double-Clicking

Double-clicking means pushing and releasing the left button twice in rapid succession. This procedure does not function with the right button. To double-click, move the cursor to the item you wish to select, press the left button twice, and immediately release it (Figure 12). You can also perform the double-click operation by tapping lightly on the Touchpad twice (Figure 13).

- Touchpad Pointing Device

Figure 12. Double-clicking with button Figure 13. Double-clicking with Touchpad

Dragging

Dragging means pressing and holding the left button, while moving the cursor. To drag, move the cursor to the item you wish to move. Press and hold the left button while moving the item to its new location and then release it (Figure 14). Dragging can also be done using the Touchpad. First, tap the Touchpad twice over the item you wish to move making sure to leave your finger on the pad after the final tap. Next, move the object to its new location by moving your finger across the Touchpad, and then release your finger (Figure 15).

Figure 14. Dragging with button Figure 15. Dragging with Touchpad

- Touchpad Pointing Device

Navigating Using Gestures

The touchpad allows you to use gestures to zoom in or out on a page, scroll quickly through large documents, toggle the charms, toggle the application commands bar, and switch to last application.

Scrolling Up/Down:

To scroll up or down, slide two fingers up or down (Figure 16).

Scrolling Right/Left:

To scroll right or left, slide two fingers right or left (Figure 16).

Zooming In/Out:

To zoom in or out on a page using the touchpad, place two fingers in a pinch position and open the pinch to zoom in, or close to zoom out (Figure 17).

Toggling the charms

To toggle the charm swipe one finger from the right edge of touch pad (Figure 18).

Toggling the application commands bar

To toggle the application commands bar swipe one finger down from the top edge of the touchpad (Figure 19).

Switching to last application

To switch to last application swipe in one finger from the left edge (Figure 20).

- Touchpad Pointing Device

Figure 16. Scroll Figure 17. Zoom Figure 18. Toggle charms Figure 19. Toggle apps Figure 20. Last app

Touchpad Control Adjustment

The Control Panel allows you to customize your Touchpad with selections made from within the Mouse Properties dialog box. To change the settings or actions for the touchpad:

From the Modern Start screen, press [Windows}+[X], then select Control Panel from the menu. Select Mouse Properties, then the Gestures tab.

Inside the Gestures tab you can modify your gesture behavior and assign new gesture actions to left and right corner swipes.

- Touchpad Pointing Device

Volume Control

Your Fujitsu LIFEBOOK notebook has multiple volume controls which interact with each other.

ANY SOFTWARE THAT CONTAINS AUDIO FILES WILL ALSO CONTAIN A VOLUME CONTROL OF ITS OWN. IF YOU INSTALL AN EXTERNAL AUDIO DEVICE THAT

HAS AN INDEPENDENT VOLUME CONTROL, THE HARDWARE VOLUME CONTROL AND THE SOFTWARE VOLUME CONTROL WILL INTERACT WITH EACH OTHER. IT SHOULD BE NOTED THAT IF YOU SET YOUR SOFTWARE VOLUME TO OFF, YOU WILL OVERRIDE THE EXTERNAL VOLUME CONTROL SETTING.

Controlling the Volume

The volume can be controlled in several different ways:

• Volume can be changed or muted from within the Volume Control in the Change PC Settings window. Click at

the bottom right corner of the screen so that vertical menu appears, then click the Settings icon. Click the Volume icon and drag the volume bar up to increase the volume, or down to decrease it.

• Volume can be controlled with the F8 and F9 functions keys. Pressing [F8] repeatedly while holding [Fn] will

decrease the volume of your notebook. Pressing [F9] repeatedly while holding [Fn] will increase the volume of your notebook.

• Volume can be changed by opening the Control Panel, selecting one of the icon sizes in the View by: field, then

selecting Windows Mobility Center. From there, you can either mute or adjust the sound in the Volume area.

• Volume can be muted by pressing the [F3] key while holding down the [Fn] key. To restore audio, repeat the

[Fn+F3] procedure.

• Volume can be controlled by many volume controls that are set within individual applications.

• Certain external audio devices you might connect to your system may have hardware volume controls.

Each source discussed above puts an upper limit on the volume level that must then be followed by the other sources. We recommend that you experiment with the various volume controls to discover the optimal sound level.

- Volume Control

Chapter 2

AC Adapter

AC Cable

DC In

Getting Started with Your LIFEBOOK

Figure 21. Connecting the AC Adapter

Power Sources

Your Fujitsu LIFEBOOK notebook has three possible power sources: a primary Lithium ion battery, an AC adapter or an optional Auto/Airline adapter.

Connecting the Power Adapters

The AC adapter or optional Auto/Airline adapter provides power for operating your notebook and charging the batteries.

Connecting the AC Adapter

1 Plug the DC output cable into the DC power jack of your LIFEBOOK notebook. 2 Plug the AC adapter into an AC electrical outlet.

Connecting the Optional Auto/Airline Adapter

1 Plug the DC output cable into the DC power jack on your notebook. 2 Plug the Auto/Airline adapter into the cigarette lighter of an automobile with the ignition key in the On or Access,

OR,

3 Plug the Auto/Airline adapter into the DC power jack on an airplane seat.

Switching from AC Adapter Power or the Auto/Airline Adapter to Battery Power

1 Be sure that you have at least one charged battery installed. 2 Remove the AC adapter or the Auto/Airline adapter.

THE LITHIUM ION BATTERY IS NOT CHARGED UPON PURCHASE. INITIALLY, YOU WILL NEED TO CONNECT EITHER THE AC ADAPTER OR THE A

UTO/AIRLINE ADAPTER TO USE YOUR NOTEBOOK.

- Power Sources

Figure 22. Opening the Display Panel

Display Panel

Your Fujitsu LIFEBOOK notebook contains a display panel that is backlit for easier viewing in bright environments and maintains top resolution through the use of active-matrix technology.

Opening the Display Panel

To open the display, simply lift the display backwards, being careful not to touch the screen, until it is at a comfortable viewing angle.

Adjusting Display Panel Brightness

Once you have turned on your LIFEBOOK notebook, you may want to adjust the brightness level of the screen to a more comfortable viewing level. There are four ways to adjust the brightness: by using the keyboard, the Power Options, the PC Settings window, or the Windows Mobility Center.

- Display Panel

Using the Keyboard

• [Fn+F6]: Pressing repeatedly will lower the brightness of your display.

• [Fn+F7]: Pressing repeatedly will increase the brightness of the display.

Using the Power Options

To change the brightness using the Power Options utility, open the Control Panel and select either Large icons or Small icons in the View by: Double-click Power Options. At the bottom of the window, drag the brightness bar to the

desired level. Note that the settings you make via this utility become permanent until you decide to change them again.

Using the PC Settings Window

To change the brightness using the PC Settings window, click at the bottom right corner of the screen so that vertical menu appears, then click the Settings icon. Click the Brightness icon and drag the brightness bar up to increase the brightness, or down to decrease it.

Using the Windows Mobility Center

To change the brightness using the Windows Mobility Center, open the Control Panel and select either Large icons or Small icons in the View by: Double-click Windows Mobility Center. In the Display Brightness area, drag the brightness bar to the desired level.

• ALWAYS POWER OFF THE COMPUTER BEFORE TRANSPORTING OR PACKAGING IT. AFTER SHUTTING THE SYSTEM DOWN, WAIT UNTIL NO LIGHTS ARE

ILLUMINATED IN THE STATUS INDICATOR PANEL.

• IT IS POSSIBLE THAT THE UNIT MAY NOT AUTOMATICALLY GO TO POWER OFF OR HIBERNATE MODE WHEN YOU CLOSE THE LID. THIS SITUATION MAY

OCCUR DUE TO PRE-OS BOOT PASSWORD SECURITY SETTINGS OR SOME OTHER APPLICATION RUNNING ON THE COMPUTER.

• ATTEMPTING TO TRANSPORT THE COMPUTER WHILE POWER IS ON MAY DAMAGE THE NOTEBOOK DUE TO SHOCK OR OVERHEATING SINCE THE AIR

VENTS MAY BE BLOCKED OR RESTRICTED.

• WHEN USING AC POWER YOUR BRIGHTNESS SETTING IS SET TO ITS HIGHEST LEVEL BY DEFAULT. WHEN USING BATTERY POWER YOUR BRIGHTNESS

SETTING IS SET TO APPROXIMATELY MID-LEVEL BY DEFAULT.

• THE HIGHER THE BRIGHTNESS, THE MORE POWER THE NOTEBOOK WILL CONSUME AND THE FASTER THE BATTERY WILL DISCHARGE. FOR MAXIMUM

BATTERY LIFE, BE SURE THE BRIGHTNESS IS SET AS LOW AS POSSIBLE.

- Display Panel

Starting Your LIFEBOOK Notebook

Power On

Power/Suspend/Resume Button

The Power/Suspend/Resume button is used to turn on your LIFEBOOK notebook from its off state. Once you have connected your AC adapter or charged the internal Lithium ion battery, you can power on your LIFEBOOK notebook.

WHEN YOU TURN ON YOUR LIFEBOOK NOTEBOOK, BE SURE YOU HAVE A POWER SOURCE. THIS MEANS THAT A BATTERY IS INSTALLED AND

CHARGED, OR THAT THE AC OR AUTO/AIRLINE ADAPTER IS CONNECTED AND HAS POWER.

To turn on your LIFEBOOK notebook from its off state, press the Power/Suspend/Resume button, located above the keyboard to the right. When you are done working you can either leave your notebook in Suspend mode (see “Sleep Mode” on page 40), or you can turn it off (see “Powering Off” on page 42).

O NOT CARRY YOUR LIFEBOOK NOTEBOOK AROUND WITH THE POWER ON OR SUBJECT IT TO SHOCKS OR VIBRATION, AS YOU RISK DAMAGING YOUR

NOTEBOOK.

When you power on your LIFEBOOK, it will perform a Power On Self Test (POST) to check the internal parts and configuration for correct functionality. If a fault is found, your LIFEBOOK notebook will emit an audio warning and/or an error message will be displayed. See “Power On Self Test Messages” on page 76. Depending on the nature of the problem, you may be able to continue by starting the operating system or by entering the BIOS setup utility and revising the settings.

After satisfactory completion of the POST, your notebook will load your operating system.

- Starting Your LIFEBOOK Notebook

NEVER TURN OFF YOUR LIFEBOOK NOTEBOOK DURING THE POWER ON SELF TEST (POST) OR IT WILL CAUSE AN ERROR MESSAGE TO BE

DISPLAYED WHEN YOU TURN YOUR LIFEBOOK NOTEBOOK ON THE NEXT TIME.

See “Power On Self Test Messages” on page 76.

Boot Sequence

The procedure for starting-up your notebook is termed the Bootup sequence and involves your notebook’s BIOS. When your LIFEBOOK notebook is first turned on, the main system memory is empty, and it needs to find instructions to start up your notebook. This information is in the BIOS program. Each time you power up or restart your notebook, it goes through a boot sequence which displays a Fujitsu logo until your operating system is found. During booting, your notebook is performing a standard boot sequence including a Power On Self Test (POST). When the boot sequence is completed without a failure and without a request for the BIOS Setup Utility, the system displays the operating system’s opening screen.

The boot sequence is executed when:

• You turn on the power to your LIFEBOOK notebook.

• You restart your notebook from the Windows Shut Down dialog box.

• The software initiates a system restart. Example: When you install a new application.

Hard Disk Drive Passwords

To provide additional security for your data, you can assign passwords to your hard disk drive(s). This feature is managed in the system BIOS Setup Utility. See

BIOS Setup Utility

below for information about accessing the utility.

REMEMBER YOUR PASSWORDS. IF YOU SET AND FORGET YOUR USER AND MASTER HARD DISK PASSWORDS, FUJITSU AMERICA WILL NOT BE ABLE TO

RESET IT. YOU MAY LOSE DATA AND HAVE TO REPLACE YOUR SYSTEM BOARD OR HARD DISK DRIVE.

- Starting Your LIFEBOOK Notebook

BIOS Setup Utility

The BIOS Setup Utility is a program that sets up the operating environment for your LIFEBOOK notebook. Your BIOS is set at the factory for normal operating conditions, therefore there is no need to set or change the BIOS’ environment to operate your notebook.

The BIOS Setup Utility configures:

• Device control feature parameters, such as changing I/O addresses and boot devices.

• System Data Security feature parameters, such as passwords.

Entering the BIOS Setup Utility

To enter the BIOS Setup Utility do the following:

1 Turn on or restart your LIFEBOOK notebook. 2 To enter the BIOS Setup Utility, press the [F2] key once the Fujitsu logo appears on the screen. This will open the

main menu of the BIOS Setup Utility with the current settings displayed.

3 Press the [RIGHT ARROW] or [LEFT ARROW] key to scroll through the other setup menus to review or alter the

current settings.

BIOS Guide

A guide to your notebook’s BIOS is available online. Please visit our service and support website at

http://solutions.us.fujitsu.com/www/content/support/contact/index.php, then select User’s Guides under Online

Support. Select your Product, Series, and Model, then click [Go]. Under the Manuals tab, select the BIOS Guide.

Booting the System

We strongly recommend that you not attach any external devices and do not put a DVD/CD in your drive until you have gone through the initial power on sequence.

When you turn on your notebook for the first time, it will display a Fujitsu logo on the screen. If you do nothing the system will load the operating system, and then the Windows Welcome will begin.

- Starting Your LIFEBOOK Notebook

Starting Windows the First Time

After you boot up the system the first time and follow the instructions on the screen, you will eventually come to the Sign-In screen which prompts you for your user name. After sign-in, it takes less than a minute for the computer to boot to Windows and during that time a progress bar and interactive messages are displayed on the screen.

During the course of the first start up, you will need to read and accept the End User License Agreements (EULAs) for Microsoft and Fujitsu.

YOU CANNOT USE YOUR NOTEBOOK UNTIL YOU HAVE ACCEPTED THE LICENSE AGREEMENT. IF YOU STOP THE PROCESS YOUR NOTEBOOK WILL RETURN

TO THE BEGINNING OF THE WINDOWS WELCOME PROCESS, EVEN IF YOU SHUT YOUR NOTEBOOK DOWN AND START IT UP AGAIN.

Following first boot, you will arrive at the Modern start screen. Some useful shortcuts for your reference: Press the Windows + D key to go to traditional Windows desktop. Press Windows + M key to load the traditional Windows desktop and minimize all applications.

Installing Bonus Apps

After you have started your system the first time, you will see a Bonus Apps icon on your desktop. Click on

the icon to see which additional applications are available for you to install. Alternatively, you can access Bonus Apps by opening the Charms panel from Modern Start screen and searching for "Bonus Apps". Applications that are already installed appear in grey; those that are available for installation appear in blue.

Select the applications you wish to install by selecting the checkbox adjacent to your selection, or click [Select All] if you would like to install all available applications. Once you have made your selections, click [Install].

Note that in some cases (depending upon which application was selected for installation) after installation completes, the system will prompt you to reboot. There are also cases in which if multiple applications are selected to install but one of them needs a reboot, the system will reboot and continue installing the rest of the selected applications.

Registering your LIFEBOOK with Fujitsu

You can register your notebook by going to our website at: http://www.us.fujitsu.com/computers. You will need to be set up with an Internet Service Provider (ISP) to register online.

- Starting Your LIFEBOOK Notebook

Power Management

Your notebook has many options and features for conserving battery power. Some are automatic and need no user intervention. However, others depend on parameters you set to best suit your operating conditions, such as those for the display brightness. Internal power management can be controlled by settings made in the operating system, power management application, or settings made in BIOS setup utility.

Besides the options available for conserving battery power, there are also some things that you can do to prevent your battery from running down as quickly. For example, you can create an appropriate power saving profile, put your notebook into Sleep mode when it is not performing an operation, and you can limit the use of high power devices. As with all mobile, battery powered computers, there is a trade-off between performance and power savings.

Power/Suspend/Resume Button

When your notebook is active, the Power/Suspend/Resume button can be used to manually put the notebook into Sleep mode. Push the Power/Suspend/Resume button when the notebook is active, but not actively accessing anything, and immediately release the button. Note that if you press the button continuously for four seconds or longer, your notebook will shut down.

If your notebook is suspended, pushing the Power/Suspend/Resume button returns your notebook to active operation. You can tell whether the system is Suspended by looking at the Power indicator. If the indicator is visible and not flashing, your notebook is fully operational. If the indicator is visible mode. If the indicator is not visible, the power is off or your notebook is in Hibernation mode.

Feature)

and

flashing, your notebook is in Sleep

(See Hibernation

Sleep Mode

Sleep mode in Windows saves the contents of your system memory during periods of inactivity by maintaining power to critical parts. This mode turns off the CPU, display, hard drive, and all other internal components except those necessary to maintain system memory and for restarting.

Your notebook will go into Sleep mode due to one of the following actions or conditions:

• Pressing the Power/Suspend/Resume button when your system is turned on.

• Selecting Sleep from the Windows Shut Down menu.

• Timing out from lack of activity.

- Power Management

• Allowing the battery to reach the Dead Battery Warning condition.

System memory typically stores the files on which you are working, open application information, and any other data required to support operations in progress. When you resume operation from Sleep, your system will return to where it left off. You must use the Power/Suspend/Resume button to resume operation, and there must be an adequate power source available, or your notebook will not resume.

• IF RUNNING YOUR NOTEBOOK ON BATTERY POWER, BE AWARE THAT THE BATTERY CONTINUES TO DISCHARGE WHILE YOUR NOTEBOOK IS IN SLEEP

MODE, THOUGH NOT AS FAST AS WHEN FULLY OPERATIONAL.

• DISABLING THE POWER/SUSPEND/RESUME BUTTON PREVENTS IT FROM BEING USED TO PUT THE NOTEBOOK INTO SLEEP OR HIBERNATION (SAVE-

TO-DISK) MODE. THE BUTTON RESUME FUNCTION CAN’T BE DISABLED.

• IF YOUR NOTEBOOK IS ACCESSING INFORMATION WHEN YOU ENTER THE SLEEP OR HIBERNATION MODE, CHANGES TO OPEN FILES ARE NOT LOST.

HE FILES ARE LEFT OPEN AND MEMORY IS KEPT ACTIVE DURING SLEEP MODE OR THE MEMORY IS TRANSFERRED TO THE INTERNAL HARD DRIVE

DURING HIBERNATION MODE.

• THE MAIN ADVANTAGE OF USING HIBERNATION (SAVE-TO-DISK) IS THAT POWER IS NOT REQUIRED TO MAINTAIN YOUR DATA. THIS IS PARTICULARLY

IMPORTANT IF YOU WILL BE LEAVING YOUR NOTEBOOK IN A SUSPENDED STATE FOR A PROLONGED PERIOD OF TIME. THE DRAWBACK OF USING

IBERNATION MODE IS THAT IT LENGTHENS THE POWER DOWN AND POWER UP SEQUENCES AND RESETS PERIPHERAL DEVICES.

Hibernation (Save-to-Disk) Feature

The Hibernation feature saves the contents of your notebook’s system memory to the hard drive as a part of the Power/Suspend/Resume mode. You can enable or disable this feature.

Enable or Disable the Hibernation Feature

The default settings are not enabled. To enable or disable the Hibernation feature, follow these steps:

1 From the Modern Start screen, press [Windows]+[X]. Select Control Panel from the menu, then select Power

Options.

2 Select Choose what the power button does or Choose what closing the lid does, then make your selection (Do

Nothing, Sleep, Hibernate, or Shut Down).

- Power Management

Windows Power Management

The Power Options icon in the Control Panel allows you to configure some of the power management settings. For example, you can use Power Options to set the timeout values for turning off the display and hard disks whether you are running the notebook on battery or one of the adapters.

Restarting the System

If your system is on and you need to restart it, be sure that you use the following procedure.

1 From the Modern Start screen, open Charms ([Windows]+C) or mouse over [-] in the bottom right corner of the

screen). Click [Settings]->[Power].

2 Select Restart from the list.

TURNING OFF YOUR LIFEBOOK NOTEBOOK WITHOUT EXITING WINDOWS OR TURNING ON YOUR NOTEBOOK WITHIN 10 SECONDS OF THE NOTEBOOK

BEING SHUT OFF MAY CAUSE AN ERROR WHEN YOU START THE NEXT TIME.

Powering Off

Before turning off the power, check that the hard drive/optical drive access indicator is off. If you turn off the power while accessing a disk there is a risk of data loss. To ensure that your notebook shuts down without error, use the Windows shutdown procedure.

E SURE TO CLOSE ALL FILES AND EXIT ALL APPLICATIONS PRIOR TO TURNING OFF THE POWER. IF FILES ARE OPEN WHEN YOU TURN THE POWER OFF,

YOU WILL LOSE ANY CHANGES THAT HAVE NOT BEEN SAVED, AND MAY CAUSE DISK ERRORS.

Using the correct procedure to shut down from Windows allows your notebook to complete its operations and turn off power in the proper sequence to avoid errors. The proper sequence is:

From the Modern Start screen, open Charms ([Windows]+C) or mouse over [-] in the bottom right corner of the screen), click [Settings]->[Power]. Select Shut down from the list

- Power Management

ENERGY STAR® Compliance

Your Fujitsu system is an ENERGY STAR® qualified mobile PC. By choosing a computer with the latest energy-saving technology, you’re helping to preserve our environment for future generations.

ENERGY STAR is a joint program of the U.S. Environmental Protection Agency, U.S. Department of

Energy, Natural Resources Canada, and other governments around the world helping us save money while protecting the environment through energy efficient products and practices. With energy costs and global warming top-of-mind for consumers, Fujitsu is committed to offering solutions that help consumers conserve energy and improve the quality of our environment.

Sleep Mode:

If you are powering your system with a power adapter, you will notice that your computer is initially set so that the display turns off after 15 minutes of user inactivity, and the computer goes into Sleep mode after 20 minutes of user inactivity. If you are powering your system with the battery, your computer is initially set so that the display turns off after 10 minutes of user inactivity, and the computer goes into Sleep mode after 20 minutes of user inactivity. When going into Sleep mode, the computer also reduces the speed of any active Ethernet network links. To “wake” the computer from Sleep mode, press the Suspend/Resume Button.

Energy saving benefits:

Fujitsu ENERGY STAR qualified mobile PCs use about half as much electricity as standard equipment – saving half in utility costs. But more than that, ENERGY STAR also makes a difference for the environment. Did you know that the average house can be responsible for twice the greenhouse gas emissions as the average car? That’s because every time you flip on a light switch, run your dishwasher, or turn on your PC, you use energy, which means more greenhouse gas emissions from power plants. So the more energy we can save through energy efficiency, the more we help to reduce greenhouse gases and the risks of global warming.

To learn more about the important ENERGY STAR program, visit: www.energystar.gov. To read about how Fujitsu is supporting Sustainable Management along with several other environmental activities,

visit the Fujitsu Corporate Citizenship page at:

http://www.computers.us.fujitsu.com/www/content/aboutus/environmental/environment.php

- Power Management

Chapter 3

User-Installable Features

Lithium ion Battery

Your LIFEBOOK notebook has a Lithium ion battery that provides power for operating your notebook when no external power source is available. The battery is durable and long lasting, but should not be exposed to extreme temperatures, high voltages, chemicals or other hazards.

The Lithium ion battery operating time may become shorter if it is used under the following conditions:

• When used at temperatures that exceed a low of 5°C or a high of 35°C. Extreme temperatures not only reduce

charging efficiency, but can also cause battery deterioration. The Charging icon on the Status Indicator panel will flash when you try to charge a battery that is outside its operating temperature range. See “Status Indicator Panel” on page 20.

• When using a high current device such as a Multi-Format DVD Writer, optical drive, or the hard drive, using the

AC adapter will conserve your battery life.

DO NOT LEAVE A FAULTY BATTERY IN YOUR NOTEBOOK. IT MAY DAMAGE YOUR AC ADAPTER, OPTIONAL AUTO/AIRLINE ADAPTER, ANOTHER BATTERY

OR YOUR NOTEBOOK ITSELF. IT MAY ALSO PREVENT OPERATION OF YOUR NOTEBOOK BY DRAINING ALL AVAILABLE CURRENT INTO THE BAD BATTERY.

• ACTUAL BATTERY LIFE WILL VARY BASED ON SCREEN BRIGHTNESS, APPLICATIONS, FEATURES, POWER MANAGEMENT SETTINGS, BATTERY CONDITION

AND OTHER CUSTOMER PREFERENCES. CD-ROM DRIVE, MULTI-FORMAT DVD WRITER, OR HARD DRIVE USAGE MAY ALSO HAVE A SIGNIFICANT IMPACT ON BATTERY LIFE. THE BATTERY CHARGING CAPACITY IS REDUCED AS THE BATTERY AGES. IF YOUR BATTERY IS RUNNING LOW QUICKLY, YOU SHOULD REPLACE IT WITH A NEW ONE.

• UNDER FEDERAL, STATE, OR LOCAL LAW IT MAY BE ILLEGAL TO DISPOSE OF BATTERIES BY PUTTING THEM IN THE TRASH. PLEASE TAKE CARE OF OUR

ENVIRONMENT AND DISPOSE OF BATTERIES PROPERLY. CHECK WITH YOUR LOCAL GOVERNMENT AUTHORITY FOR DETAILS REGARDING RECYCLING OR DISPOSING OF OLD BATTERIES. IF YOU CANNOT FIND THIS INFORMATION ELSEWHERE, CONTACT YOUR SUPPORT REPRESENTATIVE AT 1-800-

8FUJITSU (1-800-838-5487)

Recharging the Batteries

If you want to know the condition of the primary Lithium ion battery, check the Battery Level indicator located on the Status Indicator panel. The indicator changes as the battery level changes.

The Lithium ion battery is recharged internally using the AC adapter or Auto/Airline adapter. To recharge the battery make sure the battery that needs to be charged is installed in your LIFEBOOK notebook and connect the AC or Auto/Airline adapter.

AKE SURE THAT THE BATTERY CHARGING INDICATOR AND THE PERCENTAGE CHARGE IS DISPLAYED BY THE BATTERY STATUS INDICATOR ON THE

TATUS INDICATOR PANEL.

There is no memory effect on the Lithium ion battery therefore you do not need to discharge the battery completely before recharging. The charge times will be significantly longer if your notebook is in use while the battery is charging. If you want to charge the battery more quickly, put your notebook into Standby mode, or turn it off while the adapter is charging the battery See “Power Management” on page 40.

- Lithium ion Battery

USING HEAVY CURRENT DEVICES OR FREQUENT DVD/CD-RW/CD-ROM ACCESSES MAY PREVENT CHARGING COMPLETELY.

Low Battery State

When the battery is running low, a low battery notification message will appear. If you do not respond to the low battery message, the batteries will continue to discharge until they are too low to operate. When this happens, your notebook will go into Standby mode. There is no guarantee that your data will be saved once the notebook reaches this point.

• ONCE THE LOW BATTERY NOTIFICATION MESSAGE APPEARS, YOU NEED TO SAVE ALL YOUR ACTIVE DATA AND PUT YOUR LIFEBOOK NOTEBOOK INTO

TANDBY MODE UNTIL YOU CAN PROVIDE A NEW POWER SOURCE. YOU SHOULD PROVIDE A CHARGED BATTERY, AN AC POWER ADAPTER, OR

UTO/AIRLINE ADAPTER AS SOON AS POSSIBLE.

• WHEN YOU ARE IN STANDBY MODE THERE MUST ALWAYS BE AT LEAST ONE POWER SOURCE ACTIVE. IF YOU REMOVE ALL POWER SOURCES WHILE

YOUR LIFEBOOK NOTEBOOK IS IN STANDBY MODE, ANY DATA THAT HAS NOT BEEN SAVED TO THE HARD DRIVE WILL BE LOST.

Once your notebook goes into Dead Battery Suspend mode you will be unable to resume operation until you provide a source of power either from an adapter, or a charged battery. Once you have provided power, you will need to press the Power/Suspend/Resume button to resume operation.

In the Dead Battery Suspend mode, your data can be maintained for some time, but if a power source is not provided promptly, the Power indicator will stop flashing and go out, meaning that you have lost the data that was not stored. Once you provide power, you can continue to use your notebook while an adapter is charging the battery.

Shorted Batteries

The Status Indicator panel uses an LED below the battery outline of the Battery Level indicator to display the operating level available in that battery. If this display shows a Shorted Battery, it means the battery is damaged and must be replaced so it does not damage other parts of your LIFEBOOK notebook.

- Lithium ion Battery

Replacing the Battery

With the purchase of an additional battery, you can have a fully charged spare to swap with one that is not charged. There are two ways to swap batteries, cold-swapping and hot-swapping:

Cold-swapping Batteries

To cold-swap batteries in your battery bay follow these easy steps:

1 Have a charged battery ready to install. 2 Shut down your notebook and disconnect the AC adapter. 3 Turn the system over so the bottom is facing up, oriented as in Figure 23. 4 While pressing the battery lock (1), slide the battery bay release latch (2) to the right to unlatch it. Lift the battery

out of the bay (Figure 24).

5 Insert a new battery into the bay, and press it down so that the latches click into place. 6 Plug in the AC adapter and turn the power on.

Hot-swapping Batteries

To hot-swap batteries in your battery bay follow these easy steps:

BE SURE TO PLUG IN AN AC ADAPTER PRIOR TO REMOVING THE BATTERY. THERE IS NO BRIDGE BATTERY PRESENT TO SUPPORT THE SYSTEM WHILE

THE BATTERY IS BEING REPLACED. IF YOU DO NOT USE AN AC ADAPTER YOU WILL LOSE ANY UNSAVED FILES.

1 Plug an AC Adapter into the system and connect it to a power outlet. 2 Follow steps 3 and 4 in “Cold Swapping Batteries”.

F THE LITHIUM ION BATTERY CONNECTOR IS NOT FULLY SEATED, YOU MAY NOT BE ABLE TO USE YOUR NOTEBOOK OR CHARGE YOUR BATTERY.

- Lithium ion Battery

Figure 23. Battery lock and latch Figure 24. Removing the battery

- Lithium ion Battery

Figure 25. Optical Drive

Media Holder Tray

Media Tray Eject Button

Emergency Tray Release

Optical Drive

Your system contains a Dual-Layer Multi-Format DVD Writer. This drive lets you access movies, audio DVD/CDs, and software, and read and write to CD-R, CD-RW, DVD-R, DVD+R, DVD-RW, DVD+RW, and DVD RAM discs. The dual-layer architecture allows you to record up to 8.5 GB of data on DVD+R discs.

Media Player Software

With the optical drive and media player software you can play movies and music on your notebook. The media player includes controls which allow you to take full advantage of the features of a digital movie, as well as standard features such as fast forward, fast reverse, pause, etc. With this drive you can also burn onto recordable discs.

• DO NOT OPERATE YOUR OPTICAL DRIVE UNLESS YOUR LIFEBOOK NOTEBOOK IS SITTING ON A FLAT SURFACE. USING A DRIVE WHEN THE SYSTEM

IS NOT LEVEL MAY DAMAGE THE DRIVE OR PREVENT PROPER OPERATION.

• PROLONGED USE OF THE OPTICAL DRIVE, SUCH AS WATCHING A DVD MOVIE, WILL SUBSTANTIALLY REDUCE YOUR BATTERY LIFE IF NO EXTERNAL

POWER SOURCE IS ATTACHED.

Loading Media on Your Drive

To load a disc into your optical drive:

- Optical Drive

1 Be sure the notebook is running, then push and release the eject button on the front of the optical drive to open

the holder tray. The tray will come out of the LIFEBOOK notebook a short distance.

2 Gently pull the tray out until a media disc can easily be placed in the tray.

• YOU SHOULD PERIODICALLY CHECK THE FUJITSU WEBSITE AT US.FUJITSU.COM/COMPUTERS FOR THE MOST CURRENT DRIVERS.

• ALL LIFEBOOK DVD PLAYERS ARE SET TO PLAY DVD TITLES WITH REGION CODE NUMBER 1 WHICH IS SPECIFIED FOR THE NORTH AMERICAN

MARKET. THE REGION NUMBER IS A REGIONAL RESTRICTION CODE DEFINED BY THE DVD FORUM ACTING ON HOLLYWOOD REQUIREMENTS.

IFFERENT REGION CODES ARE RECORDED ON VIDEO DVD TITLES FOR PUBLICATION IN DIFFERENT AREAS OF THE WORLD. IF THE REGIONAL CODE

OF THE DVD PLAYER DOES NOT MATCH THE REGIONAL CODES ON THE TITLES, THEN PLAYBACK IS IMPOSSIBLE.

• THE REGION CODE ON THE DVD PLAYER CAN BE CHANGED USING THE PROPERTIES MENU OF THE DVD SOFTWARE. NOTE: YOU CAN ONLY CHANGE

THE REGION CODE UP TO FOUR TIMES. AFTER THE 4TH CHANGE, THE LAST CODE ENTERED BECOMES PERMANENT, AND CANNOT BE CHANGED.

3 Place the media into the tray, label side up, with the hole in the center of the disc. Snap the disc onto the raised circle

in the center of the tray.

4 Gently push the holder tray back in until you hear a click.

F YOU HAVE DISABLED THE AUTO INSERT NOTIFICATION FUNCTION, YOU WILL HAVE TO START THE DRIVE EITHER BY USING MY COMPUTER OR FROM

WITHIN WINDOWS/FILE EXPLORER, SINCE YOUR NOTEBOOK WILL NOT AUTOMATICALLY RECOGNIZE THAT MEDIA HAS BEEN LOADED.

Figure 26. Loading/Ejecting Media

- Optical Drive

Removing Media

1 Push and release the eject button on the front of the optical drive. This will stop the drive and the holder tray will

come out of the LIFEBOOK notebook a short distance.

2 Gently pull the tray out until the disc can easily be removed from the tray. 3 Carefully remove the media disc from the holder tray. 4 Gently push the holder tray back in until you hear a click.

Emergency Optical Drive Tray Release

If for some reason the eject button fails, you can open the media tray with a paper clip or similar tool inserted into the eject hole in the right side of the front of the tray. Straighten one side of a paper clip and push it gently into the hole. The tray will pop out.

Figure 27. Emergency Tray Release

Using the Media Player Software

EPENDING UPON ITS CONFIGURATION, YOUR SYSTEM MAY NOT HAVE THE MEDIA PLAYER SOFTWARE PRE-INSTALLED. IF IT IS NOT INSTALLED,

REFERENCE THE DOCUMENTATION THAT ACCOMPANIES THE MEDIA APPLICATION.

Starting a Movie

1 Insert the disc into the optical drive of the notebook. If the CD/DVD AutoRun feature activates, skip Step 2. 2 The first time you insert a movie into the media tray, you will be prompted to select what you want the system to

do when discs are inserted (e.g., start automatically or wait for a prompt). Until you make a selection, you will receive the same prompt whenever you insert a disc.

3 Click OK to close the About DVD Player Performance dialog box and the movie will begin.

- Optical Drive

Opening the Media Player Control Panel

With most DVD-ROMs, you have the option of altering how the movie should play and what you wish to view. You can do this by using the media player control panel and the mouse.

1 Right-click on the movie screen to open a dropdown menu for options. 2 Select View, then Player for all controls available. This will open the control panel at the bottom of the screen.

Using the Media Player Control Panel

The media player software allows you to watch the movie much like a VCR player. You can pause, rewind, fast-forward and stop the movie at any point.

1 To pause the movie, click the on-screen button. 2 To rewind the movie, click the  button to rewind to a specific portion of the movie, or the  button to return to

the opening screen.

3 To fast-forward the movie, click the  but ton to for ward to a specific portion of the movie, or the button to jump

to the ending credits.

4 To stop the movie, click the  button.

Exiting the Media Player

1 Click the  located in the upper right corner of the title bar. This will open a media player dialog box. 2 Click Yes to stop and exit the movie, or No to close the media player dialog box and return to the movie.

Using Media Player on Battery Power

Since optical drives consume a lot of power, your overall battery life will be significantly shorter when operating the optical drive continuously (such as watching a DVD movie) than during standard operation.

• MANY MOVIE RUN-TIMES ARE LONGER THAN YOUR SYSTEM CAN SUPPORT ON A SINGLE BATTERY. IF YOU ARE WATCHING A DVD MOVIE ON BATTERY

POWER YOU MAY NEED TO SWAP IN AN ADDITIONAL, CHARGED BATTERY OR ATTACH AC POWER DURING THE MOVIE TO VIEW IT IN ITS ENTIRETY.

• AN ADDITIONAL CHARGED BATTERY IS HIGHLY RECOMMENDED IF YOU WILL BE WATCHING DVD MOVIES ON BATTERY POWER. IF YOU DON’T HAVE

AN ADDITIONAL BATTERY, YOU MAY PURCHASE ONE ONLINE AT: HTTP://WWW.COMPUTERS.US.FUJITSU.COM OR BY CALLING 1-800-8FUJITSU.

- Optical Drive

To Watch a Movie on Battery Power:

1 Have an additional full-charged battery or your AC adapter ready for use. 2 Start watching your DVD movie. 3 When the low battery warning occurs, immediately stop the movie and exit the media player.

IF YOU DO NOT STOP THE MEDIA PLAYER QUICKLY AND THE LIFEBOOK NOTEBOOK ATTEMPTS TO AUTO-SUSPEND (CRITICAL BATTERY LOW STATE)

THE LIFEBOOK NOTEBOOK WILL SHUT DOWN IMPROPERLY. IF THIS OCCURS, YOU MAY NEED TO PERFORM A HARD RESET AND FOLLOW THE INSTRUCTIONS, IF ANY, PRESENTED TO YOU BEFORE THE SYSTEM WILL REBOOT.

4 Power down your notebook and replace the discharged battery with an additional fully-charged battery. If you do

not have an additional battery, you may attach AC power as soon as you see the low battery warning.

5 Resume operation by pressing the Suspend button again. This is not required if you attached AC power without

entering standby mode.

6 Restart your media player, locate and skip to the chapter of the movie you were last watching, then continue

watching your DVD movie.

OME SHORTER DVD MOVIES MAY NOT REQUIRE YOU TO SWAP BATTERIES OR ATTACH AC POWER TO COMPLETE THEM. HOWEVER, IT IS BEST TO BE

PREPARED SINCE ACTUAL BATTERY LIFE WHILE OPERATING THE OPTICAL DRIVE CANNOT BE GUARANTEED.

- Optical Drive

Figure 28. Installing/Removing ExpressCard

ExpressCard Slot

ExpressCard (34 mm)

Using ExpressCards

Your LIFEBOOK notebook supports 34 mm ExpressCardsTM, which can perform a variety of functions depending on which type of card you install. Some available ExpressCards:

• Gigabit Ethernet Local area network (LAN) cards

• IEEE1394 cards

• S-ATA II cards

For further information, refer to the instructions supplied with your card(s).

Installing ExpressCards

There are two different width ExpressCards: 34 mm and 54 mm. This system supports 34 mm ExpressCards only.

• INSTALLING OR REMOVING AN EXPRESSCARD DURING YOUR NOTEBOOK’S SHUTDOWN OR BOOTUP PROCESS MAY DAMAGE THE CARD AND/OR YOUR

NOTEBOOK.

• DO NOT INSERT AN EXPRESSCARD INTO A SLOT IF THERE IS WATER OR ANY OTHER SUBSTANCE ON THE CARD AS YOU MAY PERMANENTLY DAMAGE

THE CARD, YOUR NOTEBOOK, OR BOTH.

- Using ExpressCards

YOU MAY BE REQUIRED TO LOG ON AS ADMINISTRATOR OR A MEMBER OF THE ADMINISTRATOR’S GROUP TO COMPLETE THIS PROCEDURE. IF YOUR

COMPUTER IS CONNECTED TO A NETWORK, NETWORK POLICY SETTINGS MAY ALSO PREVENT YOU FROM COMPLETING THIS PROCEDURE.

See your ExpressCard manual for instructions on the installation of your card. Some cards may require that your notebook is off while installing them.

To install an ExpressCard, follow these steps:

1 When not in use, you should keep the ExpressCard plug inserted in the slot to help prevent system contamination. 2 Make sure there is no ExpressCard or ExpressCard plug currently in the slot. If there is, see Removing ExpressCards. 3 If the eject button is extended, press it in until it clicks. 4 Insert your ExpressCard into the slot with the product label facing up. 5 Push the card firmly into the slot until it is seated in the connector.

Removing ExpressCards

See your ExpressCard manual for specific instructions on removing your card. Some cards may require your notebook to be in Standby Mode or Off during removal.

• WINDOWS HAS A SHUTDOWN PROCEDURE FOR EXPRESSCARDS THAT MUST BE FOLLOWED BEFORE REMOVING A CARD. (REVIEW YOUR OPERATING

SYSTEM MANUAL FOR THE CORRECT PROCEDURE.) IT IS GOOD PRACTICE TO REMOVE DEVICES USING THE SAFELY REMOVE HARDWARE ICON IN THE SYSTEM TRAY.

• IF THE DIALOG BOX STATES THAT THE DEVICE CANNOT BE REMOVED, YOU MUST SAVE ALL OF YOUR OPEN FILES, CLOSE ANY OPEN APPLICATIONS

AND SHUT DOWN YOUR NOTEBOOK.

To remove an ExpressCard, unlock the card or card plug from the slot by pressing it in, then releasing it. This will eject the card slightly out of the slot, allowing you to remove it.

- Using ExpressCards

Figure 29. Installing a Secure Digital Card

SD Card

SD Card Slot

Secure Digital Cards

Your LIFEBOOK notebook supports Secure Digital (SD), Secure Digital High Capacity (SDHC), and Secure Digital eXtended Capacity (SDXC) cards on which you can store and transfer data to and from a variety of digital devices. These cards use flash memory architecture, which means they don’t need a power source to retain data.

You can use Secure Digital (SD) cards to store and transfer data such as digital pictures, movies, music, voice, and computer data and applications to and from a variety of digital devices.

- Secure Digital Cards

Installing SD Cards

SD Cards are installed in the SD Card slot located on the front of the system to the left of the headphone jack (Figure

29). To install a card, follow these steps:

INSTALLING OR REMOVING AN SD CARD DURING YOUR LIFEBOOK NOTEBOOK’S SHUTDOWN OR BOOTUP PROCESS MAY DAMAGE THE CARD AND/OR

YOUR LIFEBOOK NOTEBOOK.

O NOT INSERT A CARD INTO A SLOT IF THERE IS WATER OR ANY OTHER SUBSTANCE ON THE CARD AS YOU MAY PERMANENTLY DAMAGE THE CARD,

YOUR LIFEBOOK NOTEBOOK, OR BOTH.

1 See your specific card manual for instructions on the installation of your card. Some cards may require that your

notebook is off while installing them.

2 Make sure there is no card currently in the slot. If there is, see Removing an SD Card. 3 Insert your card into the slot with the product label facing up. 4 Push the card firmly into the slot until it is seated in the connector.

Removing an SD Card

To remove an SD Card, simply pull the card out of the slot.

EE YOUR CARD MANUAL FOR SPECIFIC INSTRUCTIONS ON THE REMOVAL OF YOUR CARD. SOME CARDS MAY REQUIRE YOUR NOTEBOOK TO BE IN SLEEP

ODE OR OFF WHILE REMOVING THEM.

- Secure Digital Cards

Memory Upgrade Module

Your LIFEBOOK notebook comes with a minimum of 6 GB (4 GB + 2 GB) of high speed Double Data Rate Synchronous Dynamic RAM (DDR3-1600 SDRAM factory installed. To increase your notebook’s memory capacity, you may install an additional or larger memory upgrade modules. The memory upgrade must be a dual-in-line (DIMM) SDRAM module. To ensure 100% compatibility, purchase the SDRAM module only from the Fujitsu web store at www.shopfujitsu.com.

• DO NOT REMOVE ANY SCREWS FROM THE MEMORY UPGRADE MODULE COMPARTMENT EXCEPT THE ONES SPECIFICALLY SHOWN IN THE DIRECTIONS

FOR INSTALLING AND REMOVING THE MEMORY UPGRADE MODULE.

• THE MEMORY UPGRADE MODULE CAN BE SEVERELY DAMAGED BY ELECTROSTATIC DISCHARGE (ESD). TO MINIMIZE RISK TO THE MODULE, OBSERVE

THE FOLLOWING PRECAUTIONS:

• BEFORE HANDLING A MEMORY MODULE, TOUCH A GROUNDED METAL OBJECT TO DISCHARGE STATIC ELECTRICITY BUILT UP IN YOUR BODY.

• WHEN INSTALLING OR REMOVING A MEMORY MODULE, HOLD IT BY THE EDGE SO AS NOT TO TOUCH ANY CONTACTS OR CHIPS. BE CAREFUL NOT

TO TOUCH ANY INTERNAL COMPUTER TERMINALS OR COMPONENTS; THE OIL FROM YOUR FINGERS COULD CAUSE A SHORT TO THE COMPONENTS.

• BE SURE TO POWER DOWN YOUR SYSTEM BEFORE ADDING OR REMOVING MEMORY MODULES. EVEN IF THE SYSTEM IS IN HIBERNATE OR STANDBY

STATES, DATA COULD BE LOST OR THE MEMORY COULD BE DAMAGED IF POWER IS STILL AVAILABLE TO THE SYSTEM.

Installing Memory Upgrade Modules

THE MEMORY UPGRADE MODULE IS NOT SOMETHING YOU ROUTINELY REMOVE FROM YOUR NOTEBOOK. ONCE IT IS INSTALLED, YOU SHOULD LEAVE IT

IN PLACE UNLESS YOU WANT TO CHANGE SYSTEM MEMORY CAPACITY.

1 Turn off power to your notebook, remove any power adapter (AC or auto/airline). Remove the battery. 2 Turn the notebook bottom side up, and remove the five screws from the large memory upgrade module

compartment (Figure 30). Remove the cover (Figure 31).

3 Remove the new memory upgrade module from the static guarded sleeve. 4 Align the memory upgrade module with component side up (Figure 32). Align the connector edge of the upgrade

module with the connector slot in the compartment. Be sure the alignment keys line up with those in the slot.

- Memory Upgrade Module

Figure 30. Removing the Memory Cover Screws Figure 31. Removing the Memory Cover

Alignment Keys

Retaining Clips

Retaining Clip

5 Insert the memory upgrade module at a 45° angle. Press the connector edge of the module firmly down and into

the connector until it lodges under the retaining clip. You’ll hear a click when it is properly in place.

6 Replace the cover and reinstall the screws.

Figure 32. Installing memory module Figure 33. Removing memory module

- Memory Upgrade Module

Removing a Memory Upgrade Module

1 Perform steps 1 through 4 of Installing a Memory Upgrade Module. 2 Pull the clips sideways away from each side of the memory upgrade module at the same time. 3 While holding the clips out, remove the module from the slot by lifting it up and pulling it away from your

notebook. (Figure 33)

4 Store the memory upgrade module in a static guarded sleeve. 5 Replace the cover and reinstall the screws.

Checking the Memory Capacity

Once you have changed the system memory capacity by replacing the installed module with a larger one, be sure to check that your notebook has recognized the change.

To check the memory capacity, from the Modern Start screen press [Windows]+[X]. Select Control Panel from the menu, then select Power Options. The amount of memory is displayed next to “Installed memory (RAM):”

There may be a variation between the actual memory size and what is displayed. This is possible if your system is configured with an integrated Intel Graphics Media Accelerator which dynamically allocates system memory to accelerate graphics performance.

IF THE TOTAL MEMORY DISPLAYED IS INCORRECT, CHECK THAT YOUR MEMORY UPGRADE MODULE IS PROPERLY INSTALLED. (IF THE MODULE IS

PROPERLY INSTALLED AND THE CAPACITY IS STILL NOT CORRECTLY RECOGNIZED, SEE TROUBLESHOOTING ON PAGE 65

- Memory Upgrade Module

Device Ports

LAN Port

Your Fujitsu LIFEBOOK notebook comes equipped with multiple ports to which you can connect external devices including: disk drives, keyboards, printers, etc.

Internal LAN (RJ-45) Jack

The internal LAN (RJ-45) jack is used for a 10/100/1000 Gigabit Ethernet LAN connection. You may need to configure your notebook to work with your particular network. (Please refer to your network administrator for information on your network configuration.) To connect the LAN cable follow these easy steps:

1 Align the connector with the port opening. 2 Push the connector into the port until it is seated. 3 Plug the other end of the cable into a LAN outlet.

Figure 34. Connecting LAN Device

Universal Serial Bus Ports

USB 2.0 / 3.0 Ports

The USB ports allow you to connect Universal Serial Bus devices. There are three USB 3.0 ports on the left side of the system and one USB 2.0 port on the right. USB 3.0 transfers data at up to 5 Gbps and is backward-compatible with USB 2.0 devices, which transfer data at up to 480 Mbps. Note that the front USB 3.0 port on the left side has Anytime USB Charge capability, meaning that even when your system is shut down, this port can still be used to provide power to external devices (for example, when charging a cell phone).

In order to connect a USB device, align the connector with the port opening, then push the connector into the port until it is seated.

- Device Ports

DUE TO THE ONGOING CHANGES IN USB TECHNOLOGY AND STANDARDS, NOT ALL USB DEVICES AND/OR DRIVERS ARE GUARANTEED TO WORK.

USB 3.0 Ports

USB 3.0 Port with Anytime USB Charge capability*

* The Anytime USB Charge feature can be enabled and disabled from the BIOS Setup Utility (

See “BIOS Setup Utility” on page 38.) There are three possible settings for this feature: “Disable Anytime USB Charge function”, “Only enable Anytime USB Charge function with AC Adapter”, and “Enable Anytime USB Charge function with AC Adapter or battery”. Note that if the setting is selected, the function will eventually drain the battery if the AC Adapter is not plugged in.

Figure 35. Connecting a USB Device

Headphone/Line-Out Jack

The headphone/line-out jack allows you to connect headphones or powered external speakers to your notebook. Your headphones or speakers must be equipped with a 1/8” (3.5 mm) stereo mini-plug. In order to connect headphones or speakers align the connector with the port opening on the front of the system, then push the connector into the port until it is seated.

IF YOU PLUG HEADPHONES INTO THE HEADPHONE JACK, BUILT-IN STEREO SPEAKERS WILL BE DISABLED.

- Device Ports

Microphone/Line-In Jack

External video port

The microphone/line-in jack lets you connect an external mono microphone. The microphone must be equipped with a 1/8”(3.5 mm) stereo mini-plug to fit into the microphone jack of your notebook. To connect a microphone, align the connector with the port and push the connector into the port until it is seated.

External Video Port

The external video port allows you to connect an external monitor or LCD projector. In order to connect an external video device, follow these easy steps:

1 Align the connector with the port opening. 2 Push the connector into the port until it is

seated.

Figure 36. Connecting an External Video Device

PRESSING THE [FN] + [F10] KEYS ALLOWS YOU TO CHANGE YOUR SELECTION OF WHERE TO SEND YOUR DISPLAY VIDEO. EACH TIME YOU PRESS THE

KEY COMBINATION, YOU WILL STEP TO THE NEXT CHOICE. IF YOU ONLY HAVE AN EXTERNAL CRT CONNECTED, THE ORDER IS INTERNAL -> EXTERNAL

CRT ->

SIMULTANEOUS DISPLAY > INTERNAL DISPLAY.

F YOU ONLY HAVE AN HDMI DEVICE CONNECTED, THE ORDER IS: INTERNAL DISPLAY -> HDMI DISPLAY -> SIMULTANEOUS DISPLAY -> INTERNAL

DISPLAY.

F YOU HAVE EXTERNAL CRT AND HDMI DEVICES CONNECTED, THE ORDER IS: INTERNAL DISPLAY -> EXTERNAL CRT -> SIMULTANEOUS INTERNAL

AND EXTERNAL CRT -> HDMI DISPLAY - SIMULTANEOUS INTERNAL AND HDMI DISPLAY -> INTERNAL DISPLAY.

- Device Ports

HDMI Port

The High-Definition Multimedia Interface (HDMI) port is a digital audio/video interface over which uncompressed streams can be transmitted. HDMI is used to connect compatible digital devices with your computer (such as bigscreen TVs and video recorders).

To connect an HDMI device:

1 Align the connector with the port opening. 2 Push the connector into the port until it is seated.

Figure 37. Connecting an HDMI device

- Device Ports

Chapter 4

Troubleshooting Your LIFEBOOK

Troubleshooting

There may be occasions when you encounter simple setup or operating problems that you can solve on the spot, or problems with peripheral devices that can be solved by replacing the device. The information in this section helps you isolate and resolve some of these straightforward issues and identify failures that require service.

Identifying the Problem

If you encounter a problem, go through the following procedure before pursuing complex troubleshooting:

1 Turn off your LIFEBOOK notebook. 2 Make sure the AC adapter is plugged into your notebook and to an active AC power source. 3 Make sure that any card installed in the ExpressCard slot is seated properly. You can also remove the card from the

slot, thus eliminating it as a possible cause of failure.

4 Make sure that any devices connected to the external connectors are plugged in properly. You can also disconnect

such devices, thus eliminating them as possible causes of failure.

5 Turn on your notebook. Make sure it has been off at least 10 seconds before you turn it back on. 6 Go through the boot sequence. 7 If the problem has not been resolved, refer to the Troubleshooting Table that follows for more detailed

troubleshooting information.

IF YOU KEEP NOTES ABOUT WHAT YOU HAVE TRIED, YOUR SUPPORT REPRESENTATIVE MAY BE ABLE TO HELP YOU MORE QUICKLY BY GIVING

ADDITIONAL SUGGESTIONS OVER THE PHONE.

8 If you have tried the solutions suggested in the Troubleshooting Table without success, contact your support

representative:

Toll free: 1-800-8Fujitsu (1-800-838-5487) Web site: http://solutions.us.fujitsu.com/www/content/support/contact/index.php.

Before you place the call, you should have the following information ready so that the customer support representative can provide you with the fastest possible solution:

• Product name

• Product configuration number

• Product serial number

• Purchase date

• Conditions under which the problem occurred

• Any error messages that have occurred

• Type of device connected, if any

See the Configuration Label on the bottom of your notebook for configuration and serial numbers.

- Troubleshooting

Specific Problems

Using the Troubleshooting Table

When you have problems with your LIFEBOOK notebook, try to find the symptoms under the Problem column of the troubleshooting table for the feature giving you difficulty. You will find a description of common causes for that symptom under the column Possible Cause and what, if anything, you can do to correct the condition under Possible Solutions. All possible causes or solutions may not apply to your notebook.

Troubleshooting Table

Problem Page

Audio Problems . . . . . . . . . . . . . . . . . . . .page 68

Optical Drive Problems . . . . . . . . . . . . . .page 68

Hard Drive Problems . . . . . . . . . . . . . . . .page 69

Keyboard or Mouse Problems . . . . . . . . .page 69

Memory Problems . . . . . . . . . . . . . . . . . .page 69

USB Device Problems . . . . . . . . . . . . . . .page 70

Problem Page

ExpressCard Problems . . . . . . . . . page 70

Power Failures . . . . . . . . . . . . . . . page 70

Shutdown and Startup Problems. . page 72

Video Problems. . . . . . . . . . . . . . . page 73

Connectivity Problems. . . . . . . . . . page 75

Miscellaneous Problems . . . . . . . . page 75

- Troubleshooting

Problem Possible Cause Possible Solutions Audio Problems

There is no sound coming from the built-in speakers.

The volume is turned too low. Adjust the volume control on your notebook and operating system. Use the [Fn+F9]

key combination on your keyboard. Pressing [F9] repeatedly while holding [Fn] increases your notebook volume.

Optical Drive Problems

LIFEBOOK notebook fails to recognize optical discs.

The software volume control is set too low.

Headphones are plugged in. Plugging in headphones disables the built-in speakers, remove the headphones.

Software driver is not configured correctly.

Speakers have been muted using Volume icon in the system tray.

The disc is not pushed down onto raised circle of the drive.

Optical drive tray is not latched shut.

Incorrect DVD Player or no DVD Player software is installed.

DVD/CD-RW/CD-ROM is dirty or defective.

Manually adjusting the volume should dynamically adjust the volume of the operating (see above). If that doesn’t work, adjust the sound volume control settings in your software or application.

The Audio Driver may be installed or reinstalled by using the Drivers and Applications CD that came with your LIFEBOOK. Refer to your application and operating system documentation for help.

Click on the Volume icon in the tool tray on the bottom right of the screen. If Mute is checked, click on it to uncheck it. You can also use the [Fn+F3] key combination to toggle the volume on and off.

Open optical drive tray and re-install the disc properly.

Push on the front of the optical drive tray until it latches. If that doesn’t work, pull out the modular drive latch to remove the device from the bay, then re-insert the drive until it latched; this ensures that the drive is properly seated.

Install DVD Player software.

(See “Media Player Software” on page 49 for more infor-

mation.)

Wipe the disc with a non-abrasive CD cleaning cloth and reinsert. If it still will not work try another disc in the drive.

Wrong drive designator was used for the disc in the application.

Verify the drive designator used by the application is the same as the one used by the operating system. When the operating system is booted from a DVD/CD, drive designations are automatically adjusted. Note that the drive designation can be changed with the Disk Management tool located at Administrative Tools -> Computer Management.

- Troubleshooting

Problem Possible Cause Possible Solutions

Drive access indicator on the Status Indicator Panel blinks at regular intervals with no disc in the tray or the drive is not installed.

The Windows auto insertion function is active and is checking to see if a disc is ready to run.

This is normal. However, you may disable this feature.

Hard Drive Problems

You cannot access your hard drive.

The wrong drive designator was used by an application when a bootable disc was used to start the notebook.

Verify drive designator used by application is in use by the operating system. When the operating system is booted from a CD, drive designations are automatically adjusted.

Keyboard or Mouse Problems

The built-in keyboard does not seem to work.

You installed an external keyboard or mouse, and it does not seem to work.

You have connected an external keyboard or a mouse and it seems to be locking up the system.

Memory Problems

System Properties screen doesn’t show correct installed memory amount.

Security is set so your OS can’t be started without a password.

LIFEBOOK is in Standby mode. Push the Power/Suspend/Resume button.

Application locked out the keyboard.

Your operating system software is not set up with correct software driver for that device.

Your external device is not properly installed.

Your operating system software is not setup with correct software driver for that device.

Your system crashed. Try to restart your notebook.

Your memory module is not properly installed.

Verify your password and security settings.

Try to use your integrated pointing device to restart your system.

Check your device and operating system documentation and activate the proper driver.

Re-install your device.

Check your device and operating system documentation and activate the proper driver.

Remove and re-install your memory upgrade module.

See “Device Ports” on page 61.

on page 58.

- Troubleshooting

See “Memory Upgrade Module”

Problem Possible Cause Possible Solutions

System Properties screen doesn’t show correct installed memory amount. (continued)

You have a memory failure. Check for Power On Self Test (POST) messages.

page 76.

USB Device Problems

You have installed a USB device, but the notebook does not recognize the device, or the device does not seem to work properly.

The device is not properly installed.

The device may have been installed while an application was running, so your notebook is not aware of its installation.

Remove and re-install the device.

Close the application and restart your notebook.

See “Power On Self Test Messages” on

See “Device Ports” on page 61.

ExpressCard Problems

An ExpressCard is inserted but does not work or is locking up the system.

Power Failures

You turn on your LIFEBOOK notebook and nothing seems to happen.

Your device doesn’t have the correct driver.

You have the wrong I/O address selected for your card device.

The card is not properly installed.

The card may have been installed while an application was running, so your notebook is not aware of its installation.

You don’t have the correct driver active.

The battery is installed but is faulty.

See your software documentation and activate the correct driver.

See your ExpressCard documentation to determine the required I/O address. Change the settings in the Device Manager

Remove and re-install the card.

Close the application and restart your notebook.

See your software documentation and activate the correct driver.

Use the Status Indicator panel to verify the presence and condition of the battery. See “Status Indicator Panel” on page 20. If a battery is indicating a short, remove that battery and operate from another power source or replace that battery.

- Troubleshooting

See “Using ExpressCards” on page 54.

Problem Possible Cause Possible Solutions

You turn on your LIFEBOOK notebook and nothing seems to happen. (continued)

The battery is completely discharged or there is no power adapter installed.

The battery is low. Check the battery indicator to ensure the presence and condition of the battery.

The power adapter is faulty. Try a different Power adapter.

Check Status Indicator Panel to determine the presence and condition of the battery. See “Status Indicator Panel” on page 20. Install a charged battery or a power adapter.

“Status Indicator Panel” on page 20. Use an AC adapter to operate until a battery is charged or install a charged battery.

See

Your LIFEBOOK notebook turns off all by itself.

Your LIFEBOOK notebook will not work on battery alone.

The power adapter is not plugged in properly.

The power adapter has no power from the AC outlet, airplane jack, or cigarette lighter.

The power management parameters are set for auto timeouts which are too short for your operating needs.

You have a battery failure. Verify battery condition using the Status Indicator panel. Replace a shorted battery.

Verify that your adapter is connected correctly.

Move the AC cord to a different outlet, check for a line switch or tripped circuit breaker for the AC outlet. If you are using an auto/airline adapter in a car make sure the ignition switch is in the On or Accessories position.

Press any button on the keyboard, or move the mouse to restore operation. If that fails, push the Power/Suspend/Resume button. Check your power management settings, or close your applications and go to the Power Options Properties located in the Control Panel to adjust the timeout values to better suit your needs.

See “Power Sources” on page 33.

See “Status Indicator Panel” on page 20.

Power adapter failed or lost its power source.

You ignored a low battery alarm until the battery is dead state and system has gone into Dead Battery Suspend mode.

The installed battery is dead. Replace the battery with a charged one or install a power adapter.

No battery is installed. Install a charged battery.

Battery is improperly installed. Verify that the battery is properly connected by re-installing it.

Make sure the adapter is plugged in and the outlet has power.

Install a power adapter and then push the Power/Suspend/Resume button.

Sources” on page 33.

See “Power

- Troubleshooting

Problem Possible Cause Possible Solutions

Your LIFEBOOK notebook will not work on battery alone. (continued)

Your installed battery is faulty. Verify the condition of the battery using the Status Indicator panel and replace or

remove any shorted battery.

See “Status Indicator Panel” on page 20.

The battery seems to discharge too quickly.

Shutdown and Startup Problems

The Suspend/Resume button does not work.

The system powers up, and displays power on information, but fails to load the operating system.

You re running an application that uses a lot of power due to frequent hard drive, optical drive, or Wireless LAN use.

The power savings features may be disabled.

The brightness is turned all the way up.

The battery is very old. Replace the battery.

Battery was exposed to high temperatures.

The battery is too hot or too cold.

Suspend/Resume button is disabled.

There may be application software. conflict

The boot sequence settings of the setup utility are not compatible with your configuration.

Use both the primary battery and an optional second battery and/or use a power adapter for this application when at all possible.

Check the Power Options menu settings and adjust according to your operating needs.

Turn down the brightness adjustment. The higher the brightness the more power your display uses.

Replace the battery.

Restore the notebook to normal operating temperature. Charging icon on the Status Indicator panel will flash when battery is outside of operating range.

Select the “Choose what the power button does” option.

Close all applications and try the button again.

Set the operating source by pressing the [ESC] key while the Fujitsu logo is on screen or use the [F2] key and enter the setup utility and adjust the source settings from the Boot menu.

See “BIOS Setup Utility” on page 38.

Internal hard drive was not detected.

Use the BIOS setup utility or Primary Master submenu, located within the Main menu, to try to auto detect the internal hard drive.

- Troubleshooting

Problem Possible Cause Possible Solutions

The system powers up, and displays power on information, but fails to load the operating system. (continued)

You have a secured system requiring a password to load your operating system.

Make sure you have the right password. Enter the setup utility and verify the Security settings and modify them as accordingly.

See “BIOS Setup Utility” on page 38.

Error message is displayed on the screen during the notebook (boot) sequence.

Your notebook appears to change setup parameters when you start it.

Video Problems

The built-in display is blank when you turn on your LIFEBOOK notebook.

The notebook turned on with a series of beeps and the built-in display is blank.

Power On Self Test (POST) has detected a problem.

BIOS setup changes were not saved before you exited the utility.

The BIOS CMOS hold-up battery has failed.

The notebook is set for an external monitor only.

The display angle and brightness settings are not adequate for your lighting conditions.

Power management timeouts may be set for short intervals and you didn’t see the display come on and go off.

Power On Self Test has detected a failure which does not allow the display to operate.

See the Power On Self Test (POST) messages to determine the meaning and severity of the problem. Not all messages are errors; some are simply status indicators. LIFEBOOK

Make sure you select Save Changes And Exit when exiting the BIOS setup utility.

Contact your support representative for repairs. This is not a user serviceable part but has a normal life of 3 to 5 years.

Pressing [F10] while holding down the [Fn] key allows you to change your selection of where to send your display video. Each time you press the keys you will step to the next choice. The choices, in order are: built-in display only, external monitor only, both built-in display and external monitor.

Move the display and the brightness control until you have adequate visibility. Pressing either the [F6] or [F7] keys while holding down the [Fn] key also allows you to change the brightness level of the display.

Press a keyboard button or move the mouse to restore operation. If that fails, push the Power/Suspend/Resume button. (The display may be shut off by Standby mode, Auto Suspend or Video Timeout)

Contact your support representative.

- Troubleshooting

Problem Possible Cause Possible Solutions

The display goes blank by itself after you have been using it.

The notebook has gone into Video timeout, Standby, or Save-to-Disk mode because you have not used it for a period of time.

Press any button on the keyboard, or move the mouse to restore operation. If that fails, push the Power/Suspend/Resume button. Check your power management settings, or close your applications and go to the Power Savings menu of the setup utility to adjust the timeout values to better suit your operation needs.

page 38.

See “BIOS Setup Utility” on

Power management timeouts may be set for short intervals and you didn’t notice the display come on and go off.

Your display won’t turn on when the system is turned

The system may be passwordprotected.

on or when it has resumed.

The display does not close. A small object such as a paper

clip is stuck between the display and keyboard.

The display has bright or dark spots.

If the spots are tiny and few, this is normal for a large LCD display.

If the spots are numerous or large enough to interfere with your operation needs.

The application display uses only a portion of your screen and is surrounded by a dark frame.

You’re running an application that doesn’t support the system’s native pixel resolution and display compression is enabled.

The Display is dark when on battery power.

Power Management default is set on low to conserve power.

Press any button on the keyboard, or move the mouse to restore operation. If that fails, push the Power/Suspend/Resume button. (The display may be shut off by Standby Mode, Auto Suspend or Video Timeout)

Check the status indicator panel to verify that the Security icon is blinking. If it is blinking, enter your password.

Remove all foreign objects from the keyboard.

This is normal; do nothing.

Display is faulty; contact your support representative.

Display compression gives a clearer but smaller display for applications that do not support the system’s native pixel resolution. You can fill the screen but have less resolution by changing display compression settings. These settings can be changed in the Intel GMA control panel.

Press [Fn] + [F7] to increase brightness or double-click on the battery gauge and adjust Power Control under battery settings.

- Troubleshooting

Problem Possible Cause Possible Solutions

You have connected an external monitor and it does not display any information.

Your external monitor is not properly installed.

Your operating system is not setup with the correct software driver for that device.

Reinstall your device.

Check your device and operating system documentation and activate the proper driver.

See “External Video Port” on page 63.

You have connected an external monitor and it does not come on.

Connectivity Problems

You are attempting to connect to the Internet, but you do not appear to have power to the WLAN.

Miscellaneous Problems

Error message is displayed on the screen during the operation of an application.

Your external monitor is not compatible with your LIFEBOOK notebook.

The wireless device functions have been turned off.

Application software often has its own set of error message displays.

See your monitor documentation and the External Monitor Support portions of the Specifications section.

To activate the wireless LAN devices, press the [Fn] and [F5] keys at the same time. When active, the wireless LAN indicator in the status indicator panel will glow. To turn the devices off, repeat the same step.

See your application manual and help displays screens for more information. Not all messages are errors some may simply be status.

See “Specifications” on page 94.

- Troubleshooting

Power On Self Test Messages

The following is a list of error-and-status messages that the Phoenix BIOS and/or your operating system can generate and an explanation of each message. Error messages are marked with an *. If an error message is displayed that is not in this list, write it down and check the operating system documentation on screen and in the manual. If you can find no reference to the message, contact a support representative.

*Invalid NVRAM Data

Problem with NVRAM access. In the unlikely case that you see this message you may have a display problem. You can continue operating but should contact your support representative for more information.

*Keyboard controller error

The keyboard controller test failed. You may have to replace your keyboard or keyboard controller but may be able to use an external keyboard until then. Contact your support representative.

*Keyboard not detected

Keyboard not working. You may have to replace your keyboard or keyboard controller but may be able to use an external keyboard until then. Contact your support representative.

*Operating system not found

Operating system cannot be located on either drive A: or drive C: Enter the setup utility and see if both the fixed disk, and drive A: are properly identified and that the boot sequence is set correctly. Unless you have changed your installation greatly, the operating system should be on drive C:. If the setup utility is correctly set, your hard drive may be corrupted.

*Press <F1> to resume, <F2> to SETUP

Displayed after any recoverable error message. Press [F1] key to Continue or [F2] key to Enter Setup.

*Real time clock error - Check date and time settings

Real-time clock fails BIOS test. May require board repair. Contact your support representative.

*Fan error, system shutdown in 30s. Contact Fujitsu tech support

Fan error occurred. Please contact your sales representative.

*Fan error occurred during previous boot.

Fan error occurred during previous boot. Please contact your sales representative.

- Troubleshooting

Restoring Your System Image and Software

It is very important that you create DVD copies of your Factory Image and Bootable Disc before beginning to use your system. To do so, follow the instructions in the “Saving Your Factory Image” and “Creating Backup Images of Factory Image and Discs” sections of this chapter.

Saving and Recovering Your Factory and System Images

Along with instructions on saving your Factory Image, this document outlines several other important procedures, such as making a system image, restoring your Factory Image and system images, managing your images, and restoring the partitions on a hard drive.

• IN ORDER TO MAKE COPIES OF FACTORY AND SYSTEM IMAGES AND BURN BOOTABLE DISCS YOU MUST HAVE AN INTERNAL OR EXTERNALLY

CONNECTED WRITABLE DVD DRIVE.

• IT IS EXTREMELY IMPORTANT THAT YOU COPY YOUR FACTORY IMAGE TO REMOVABLE MEDIA (E.G., DVD DISCS). FAILURE TO DO SO COULD RESULT

IN AN INABILITY TO RESTORE THE IMAGE AT A FUTURE DATE.

• WE RECOMMEND THAT YOU USE DVD-R OR DVD+R DISCS FOR YOUR BACKUP, BUT SUPPORTED MEDIA* FOR IMAGE BACKUPS INCLUDE:

FOR FACTORY IMAGE, APPLICATION DATA, AND BOOTABLE DISC: DVD-R/+R. FOR USER-CREATED BACKUP IMAGE: DVD-R/+R, DVD-RW/+RW, DVD-DL.

* DEPENDING UPON YOUR OPTICAL DRIVE AND MEDIA FORMAT USED, SOME MEDIA TYPES MAY BE INCOMPATIBLE FOR CREATING IMAGE BACKUPS.

DUE TO CERTAIN LICENSING REQUIREMENTS, SOME THIRD-PARTY APPLICATIONS WILL NEED TO BE INSTALLED SEPARATELY.

Saving your Factory Image

When you purchased your new system, a copy of the pre-installed Factory Image was loaded into a hidden partition on your hard disk drive. Having a copy of the original Factory Image available to you means that in the event of system failure, you will be able to restore it to its original state.

- Restoring Your System Image and Software

To make a copy of the Factory Image to DVD discs, you will need four or five blank discs (DVD-R or DVD+R discs are recommended) to create the copy. After creating the copy, be sure to label the discs and keep them in a safe place to ensure they do not get damaged.

Creating Backup Images of Factory Image and Bootable Disc

Using the [Manage/Change] button, you can create backup images of the Factory Image and/or Bootable Disc.

ALL USER-CREATED DATA WILL BE DELETED FROM YOUR SYSTEM WHEN THE FACTORY IMAGE IS RESTORED.

1 Launch System Backup and Restore from the desktop icon and click [Yes] on the User Account Control dialog. 2 Click [Next] on the Backup Your Data screen. 3 Select the [Manage/Create] tab, then click [Make Recovery Disc set] to burn your factory image to DVD. 4 On “Step 1: Please select a media type for Recovery Disc” screen select Media Type from the drop down box, then

click [Next]. (Note: This screen shows the number of discs required for backup.)

5 On “Step 2: Confirm your Recovery Disc” both the Bootable Disc and Recovery disks are selected by default under

“List of Recovery Discs”. When the backup is created for the first time, these options should stay selected. Click [Next].

6 Click [OK] on the “Attention about media” confirmation screen.

DURING THE FOLLOWING PROCESS, YOU SHOULD CONNECT AN AC ADAPTER SINCE THE PROCESS MAY TAKE A LONG TIME.

7 Click [Start] on “Step 3: Making Recovery Disc” . 8 The process will prompt you to insert your discs. 9 Once the process completes successfully, click [Finish] on “Step 4: Making Recovery Disc process has been

completed” screen.

- Restoring Your System Image and Software

Recovering Your Factory Image.

In the event you need to restore your original Factory Image, perform the following steps.

ALL USER-CREATED DATA WILL BE DELETED FROM YOUR SYSTEM WHEN THE FACTORY IMAGE IS RESTORED.

In order to recover your Factory Image, perform the steps outlined in “Running Recovery and Utility from hard disk”.

Backing Up a System Image

Optional Step: Launch the Fujitsu Bonus Apps utility from your desktop, and select the components you wish to

install. (Alternatively, you can access Bonus Apps by opening Charms panel from Modern Start screen and searching for "Fujitsu BonusApps".)

User-Configured System Backups: On your desktop, there is a [System Backup and Restore] icon that allows you to make backups of your current system image either to another location on your hard drive or on removable media. A system image is the configuration of your C: drive at a particular point of time. You may want to make system image backups occasionally in order to have points to which you can return without having to go all the way back to the Factory Image.

By default, system images are saved in the D: drive in the System Backup and Restore folder. You can also elect to save the image to an external hard drive.

1 Launch System Backup and Restore from the desktop icon and click [Yes] on User Account Control dialog 2 Click [Next] on Backup Your Data screen 3 Select the [Backup] tab on System Backup and Restore screen. 4 Click the [Backup User System] button. 5 On the “Step 1: Select a backup destination” screen select your destination drive. By default the Destination is set

to D: drive. You can also select the [Other drive] option to back up to an external drive. Select whether you would like the system to [Shutdown] or [Restart] after the process is completed.

- Restoring Your System Image and Software

6 On the “Step 2: Name your backup images” screen that appears, you can enter up to 300 characters of information

about the backup file. This information will help you to identify the image at a later date.

7 On “Step 3: Backup the entire C: drive image” verify your backup settings and click [Next]. 8 Click [OK] on “Step 4: Please confirm the following before starting your backup” to restart you computer and begin

backup.

9 After backup completes and the system restarts, “Step 5: Backup Completed. Confirm the results” screen should

appear on your desktop confirming that backup image has been created successfully. Click [Close] to close System Backup and Restore dialog.

10 Click [OK] to quit the System Backup and Restore utility.

Managing Your Backup Images

With the System Backup and Restore tool you can also make copies of backup images, archive them on DVD, or delete them from your hard drive.

1 Launch System Backup and Restore from the desktop icon and click [Yes] on User Account Control dialog. 2 Click [Next] on the Backup Your Data screen. 3 Select the [Create/Manage] tab and click on [Manage User System Backup]. 4 In the next window there are three options allowing you to [Copy], [Delete], or [Add Comment] to your images.

Click the action button you would like to perform:

Selecting [Copy] option (Note that you must have an external disk drive connected for the [Copy] button to work, otherwise an attempt to copy will result in an error.)

a. On “Step 1: Select a backup file that you wish to copy”, select the location of a backup file. A list of backup

files will appear. Select the file you wish to copy from the list and click [Next].

b. On “Step 2: Select a drive to copy a backup file”, select the destination drive and click [Next]. c. On “Step 3: Start to copy the following information” confirm the information and click [Start]. d. “Step 4: Processing backup data copying” screen displays the progress bar.

- Restoring Your System Image and Software

e. Click [Finish] on “Step 5: Copy completed. Confirm the results” screen.

Selecting “Delete” option

a. On “Step 1: Please select your target data” screen select location of a backup file. A list of backup files will

appear. Select the file(s) you wish to delete and click [Next].

b. Click [Start] on “Step 2: Delete backup data” screen. c. Click [OK] to the confirmation message. d. Click [Finish] on “Step 4: Delete process has been completed” screen.

Selecting “Add Comment” option

a. On the “Step 1: Select target data” screen select location of a backup file. A list of backup files will appear.

Select the file you wish to add comments to and click [Next].

b. On the “Step 2: Add comment” screen, type in a maximum of 300 characters in “Comment” text area and

click [Add].

c. Click [Finish] on the “Step 3: Adding comment has been completed” screen.

Restoring your backup images

1 Launch System Backup and Restore from the desktop icon and click [Yes] on the User Account Control dialog 2 Click [Next] on the Backup Your Data screen 3 Select the Restore tab and click on “Restore User System Backup” 4 On “Step 1: Please confirm the following before starting restore process”, confirm information and click [OK]. The

system will restart to begin restoring your backup.

5 After the system restarts, the “Explanation about Restore User System Backup” screen is shown. Once you read the

EULA, select [Agree] choice and click [Next].

6 Select an image to restore from the Backup data list and click [Next]

- Restoring Your System Image and Software

7 Click [Start] on “Confirm before restoration” screen 8 Once restoration finishes, click [Close] in “Finished restoration” screen, the computer will restart to Windows.

Using the Recovery and Utility Tools

The Recovery and Utility tools consist of a variety of tools that will help you recover your Factory Image, recover system images, and delete the data from your hard disk.

Methods for accessing the utilities

Recovery and Utility Tools are preinstalled in a hidden partition by the factory, or they can be accessed by using the bootable disc. Please note that you can delete Recovery and Utility tools from your hard disk drive if you modify the partitions. In this case you will not be able to use the hidden partition for booting to Recovery and Utility Tools, but you will still be able to boot from the Bootable Disc.

Determining whether Recovery and Utility is pre-loaded

1 Turn on or reboot your system. When the Fujitsu logo appears, press [F12] key. 2 From the Boot Menu that appears, check whether the <Recovery and Utility> option is present. If it is not present,

it means that the utility must be used from the disc. Proceed to “Running Recovery and Utility from the Bootable Disc” if <Recovery and Utility> is unavailable.

Running Recovery and Utility from hard disk

1 Turn on or reboot your system. When the Fujitsu logo appears, press the [F12] key. 2 Cursor down to <Recovery and Utility> and press the [Enter] key. 3 Choose your Language (English or French). 4 Three tool options appear: Diagnostics, Recovery and Utility (Please see Recovery and Utility tools section below

for instructions on how to use these tools).

- Restoring Your System Image and Software

Running Recovery and Utility from the Bootable disc

To verify/change the boot-up priority (rather than booting-up from the hard drive or an external floppy disk drive), perform the following steps:

1 Power on your system. When the Fujitsu logo appears on the screen. press the [F12] key. 2 Highlight the CD/DVD option from the Boot menu, then press [Enter].

3 Insert the bootable disc into the drive tray. 4 Click [OK]. 5 Select CD/DVD boot mode: UEFI Mode) and press [Enter]. While the files are being loaded from the disc, the

Fujitsu logo screen will appear followed by a progress bar screen at the bottom of the screen.

Recovery and Utility tools

Diagnostics tool: The Diagnostics tool is designed for use by IT professionals. It is not likely you will need to use this

tool. If you should need to use this tool, perform the following steps:

1 Press the “Diagnostics Tool” button to start the Diagnostics tool. A progress bar appears while the Diagnostics tool

is starting up.

2 Read the note, then click [OK]. 3 Choose one or more of the following options for diagnostics on the “Fujitsu Hardware Diagnostics Tool window”:

CPU, Memory, Display, Hard Disk, CD/DVD/BD, Floppy Disk, Keyboard, and Mouse. Click the [Option] button to specify how many times the tool should run diagnostics on each selected component. Press [Execute] to start the Diagnostics tool.

4 After the execution is completed, the selected components are circled in red to indicated that they have been

diagnosed and the result dialog window is opened.

5 Click [End] to close the Diagnostics tool, then click [Yes] to confirm the end of diagnostics session.

Recovery tool: The Recovery tool contains three options. User System Backups: Recovering C: Drive from D: Drive or external storage device), Restore C: Drive: Restore factory image (only C: drive), and Restore Full Hard Drive: Restore factory image (full hard drive).You can use these tools to restore the Factory Image from the hidden

- Restoring Your System Image and Software

partition, restore backup image(s) created by you or images stored on DVD discs, and perform a full hard drive recovery. Please refer to instructions above for details on how to create Factory Image Recovery DVDs, user backup DVDs and system image backup.

To recover from D: drive or external storage device:

1 Click [User System Backups] 2 The progress bar screen is followed by EULA screen. Click [Agree] to accept the EULA. 3 On “Select an image to restore” screen select the image to restore from the list of images and click [Next]. 4 Click [Start] on the “Confirm before restoration” screen to begin the restoration process. 5 Once restoration finishes, click [Close] in the “Finished restoration” screen; the computer will restart to Windows.

To restore from the Factory Image (hidden partition):

1 Click [Restore C: drive]. 2 The progress bar screen is followed by “Restore Factory Image (only C: drive) screen confirming that the Factory

Image will be restored to the C: drive and D: drive data will remain. Click [Next].

3 Read the instruction screen and select [Agree], then [Next]. 4 Click [OK] to the warning message to restore factory image to the C: drive. 5 When the progress bar screen, wait for the process to complete. 6 Click [Finish] when the process completes; the computer will restart to Windows.

To restore full hard drive: Follow the steps in section “Recovering your Factory Image using Recovery and Utility (for new hard drive or

non-bootable hard drive)”

Utility tool: The Utility tool contains two options: Hard Disk Data Delete and Partition Creation.

- Restoring Your System Image and Software

• The Hard Disk Data Delete utility is used to delete all data on the hard disk and prevent the data from being

reused. NOTE: Do not use the Hard Disk Data Delete utility unless you are absolutely certain that you want to erase your entire hard disk, including all partitions. To delete hard disk data:

a. Click the [Hard Disk Data Delete] button b. The progress bar appears, followed by the EULA screen. c. Agree to the EULA and click [Next]. d. Choose the hard disk from which the data should be deleted in the list of hard disks and click [Next].

• The Partition Creation utility is used to change the C: and D: drive partition sizes. To run this utility:

a. Click the [Partition Creation] button. b. A progress bar screen appears, followed by the EULA screen. Agree to the EULA. c. On the Recovery Tool - Partition Creation screen move the slider to set disk size, then click [OK]. d. Click YES in the Partition Creation confirmation dialog.

Recovering your Factory Image using Recovery and Utility (for new hard drive or non-bootable hard drive)

If you have installed a new hard drive or your hard drive is not bootable, perform the following steps.

1 Power on your system. When the Fujitsu logo appears on the screen, press the [Enter] key. 2 Highlight the CD/DVD option from the Boot Menu and press [Enter]. 3 Insert the bootable disc in your DVD drive, then click [OK]. 4 Select CD/DVD boot mode: UEFI Mode and press [Enter]. While the files are being loaded from the disc, Fujitsu

logo screen will appear followed by a progress bar screen at the bottom of the screen.

5 Choose your language ([English or French). 6 Three tool options appear: Diagnostics, Recovery and Utility. Select [Recovery]. 7 Select [Restore full hard drive]. 8 Click [Next] to confirm full hard drive restoration. (All data on HDD will be deleted). 9 Agree to EULA by selecting [Agree] option and clicking [Next].

- Restoring Your System Image and Software

10 Click [Next] on the Recovery Disk Check screen to verify that the bootable disk has been inserted into the optical

drive.

11 The Checking for Recovery Disk screen appears followed by the prompt to insert the first disk. Click [OK] to

continue. Repeat this step for all disks. After all recovery disks have been checked and the check has been completed, click [Next]

12 Reinsert the first recovery disk and click [Next] 13 Click [OK] when you receive the final warning informing you that all data on drives C: and D: will be lost. This starts

the recovery process.

14 Follow the prompts to insert the next recovery disks and click [OK]. 15 After the copying of the factory image to the HDD completes and the factory image is restored, follow the prompt

to insert bootable disk.

16 After the restore process is complete, click [Finish] to restart the system. The computer will restart automatically

and then go through the first boot process.

Downloading Driver Updates

The Fujitsu Software Download Manager (FSDM) utility is available to allow you to download the latest drivers, utilities, and applications from the Fujitsu Support site. If you have a Windows 8 or Windows 7 operating system, you will need to go to the Support Site (http://support.fujitsupc.com/CS/Portal/support.do?srch=DOWNLOADS).

- Restoring Your System Image and Software

Chapter 5

Care and Maintenance

Caring for your LIFEBOOK Notebook

If you use your Fujitsu LIFEBOOK notebook carefully, you will increase its life and reliability. This section provides some tips for looking after the notebook and its devices.

• THE SYSTEM CONTAINS COMPONENTS THAT CAN BE SEVERELY DAMAGED BY ELECTROSTATIC DISCHARGE (ESD). TO MINIMIZE RISK TO THE

COMPONENTS, OBSERVE THE FOLLOWING PRECAUTIONS:

• BEFORE DOCKING OR UNDOCKING YOUR LIFEBOOK NOTEBOOK (WHEN USING A PORT REPLICATOR), IT IS A GOOD PRACTICE TO ALWAYS TOUCH

A GROUNDED METAL OBJECT TO DISCHARGE STATIC ELECTRICITY BUILT UP IN YOUR BODY.

• BE SURE TO POWER DOWN YOUR SYSTEM BEFORE ADDING OR REMOVING SYSTEM COMPONENTS. EVEN IF THE SYSTEM IS IN HIBERNATE OR SLEEP

MODE, DATA COULD BE LOST OR MEMORY COULD BE DAMAGED IF POWER IS STILL AVAILABLE TO THE SYSTEM.

• WHEN INSTALLING OR REMOVING A MEMORY MODULE, HOLD IT BY THE EDGE SO AS NOT TO TOUCH ANY CONTACTS OR CHIPS. BE CAREFUL NOT

TO TOUCH ANY INTERNAL COMPUTER TERMINALS OR COMPONENTS; THE OIL FROM YOUR FINGERS COULD CAUSE A SHORT TO THE COMPONENTS.

• ELECTRICAL EQUIPMENT MAY BE HAZARDOUS IF MISUSED. OPERATIONS OF THIS PRODUCT OR SIMILAR PRODUCTS, MUST ALWAYS BE SUPERVISED BY AN

ADULT. DO NOT ALLOW CHILDREN ACCESS TO THE INTERIOR OF ANY ELECTRICAL PRODUCTS AND DO NOT PERMIT THEM TO HANDLE ANY CABLES.

• Your notebook is a durable but sensitive electronic device. Treat it with respect and care.

• Make a habit of transporting it in a suitable carrying case.

• Do not attempt to service the computer yourself. Always follow installation instructions closely.

• Keep it away from food and beverages.

• To protect your notebook from damage and to optimize system performance, be sure to keep all air vents

unobstructed, clean, and clear of debris. This may require periodic cleaning, depending upon the

environment in which the system is used.

• Do not operate the notebook in areas where the air vents can be obstructed, such as in tight enclosures or on

soft surfaces like a bed or cushion.

• If you accidentally spill liquid on your LIFEBOOK notebook:

1 Turn it off.

2 Position it so that the liquid can run out.

3 Let it dry out for 24 hours, or longer if needed.

4 If your notebook will not boot after it has dried out, call your support representative.

• Do not use your Fujitsu LIFEBOOK notebook in a wet environment (near a bathtub, swimming pool).

• Always use the AC adapter and batteries that are approved for your notebook.

• Avoid exposure to sand, dust and other environmental hazards.

• Do not expose your notebook to direct sunlight for long periods of time as temperatures above 140° F (60° C)

may damage your notebook.

• Keep the covers closed on the connectors and slots when they are not in use.

• Do not put heavy or sharp objects on the computer.

• If you are carrying your LIFEBOOK notebook in a briefcase, or any other carrying case, make sure that there are

no objects in the case pressing on the lid.

• Never position your notebook such that the optical drive is supporting the weight of the notebook.

Cleaning your LIFEBOOK notebook

• Always disconnect the power plug. (Pull the plug, not the cord.)

• Clean your LIFEBOOK notebook with a damp, lint-free cloth. Do not use abrasives or solvents.

• Use a soft cloth to remove dust from the screen. Never use glass cleaners.

• Always shut down the computer, unplug the power adapter, and remove the battery when

cleaning or disinfecting the computer exterior, keyboard or LCD display.

- Caring for your LIFEBOOK Notebook

Cleaning guidelines using recommended off-the-shelf cleaners Computer exterior, computer keyboard

To clean the exterior and keyboard, use one of the following off-the-shelf products:

• Office Depot® #154-616 Notebook Cleaning Kit

• Meridrew Enterprises Klear_Screen® Wipes

• 3M CL563 Cleaner Wipes

Note: After cleaning with one of these products, polish with a dry, soft, lint-free cloth until solution is no longer visible.

LCD display

To clean the LCD display, use one of the following off-the-shelf products:

• Office Depot® #154-616 Notebook Cleaning Kit

• Meridrew Enterprises Klear_Screen® Wipes

* Applies to Tablet PC, convertible PC with LCD shield, and standard notebook LCD displays. Wipe the LCD surface gently, allowing it to dry before turning on the computer.

Disinfecting LIFEBOOK computers

Wipe the surface with a soft cloth wipe and a 50% ethanol solution or use another ethanol-based germicide which has been registered as a hospital disinfectant by the EPA.

• USE OF INCORRECT CLEANERS CAN RESULT IN OPTICAL IMPAIRMENT OF THE LCD AND/OR DAMAGE TO THE COMPUTER. ALWAYS REFER TO THE

CLEANER MANUFACTURER'S GUIDELINES AND MATERIAL SAFETY DATA SHEETS FOR PROPER HANDLING AND USE OF THE PRODUCTS.

• NEVER USE AMMONIA, ACIDIC, OR ALKALINE CLEANERS OR ORGANIC CHEMICALS SUCH AS PAINT THINNER, ACETONE, PROPYL OR ISOPROPYL

ALCOHOL, OR KEROSENE. IT MAY DAMAGE SURFACE FINISHES AND THE COATING OF THE LCD SCREEN.

• NEVER USE COMPRESSED AIR FOR CLEANING STYLISTIC AND LIFEBOOK PCS.

Storing your LIFEBOOK notebook

• If storing your notebook for a month or longer, turn your LIFEBOOK notebook off, fully charge the battery, then

remove and store all Lithium ion batteries.

- Caring for your LIFEBOOK Notebook

• Store your notebook and batteries separately. If you store your LIFEBOOK with a battery installed, the battery

will discharge, and battery life will be reduced. In addition, a faulty battery might damage your LIFEBOOK.

• Store your Fujitsu LIFEBOOK in a cool, dry location. Temperatures should remain between 13ºF (-25ºC) and

140ºF (60ºC).

• ALWAYS POWER OFF THE COMPUTER BEFORE TRANSPORTING AND/OR PACKAGING IT. AFTER SHUTTING DOWN THE SYSTEM, WAIT UNTIL THE STATUS

LED

PANEL INDICATES POWER OFF CONDITION (I.E., NO LIGHTS ARE ILLUMINATED).

• IT IS POSSIBLE THAT THE UNIT MAY NOT AUTOMATICALLY GO TO POWER OFF OR HIBERNATE MODE WHEN YOU CLOSE THE LID. THIS SITUATION MAY

OCCUR DUE TO PRE-OS BOOT PASSWORD SECURITY SETTINGS OR SOME OTHER APPLICATION RUNNING ON THE COMPUTER.

• ATTEMPTING TO TRANSPORT THE COMPUTER WHILE POWER IS ON MAY DAMAGE THE NOTEBOOK DUE TO SHOCK OR OVERHEATING SINCE THE AIR

VENTS MAY BE BLOCKED OR RESTRICTED.

Traveling with your LIFEBOOK notebook

• Do not transport your notebook while it is turned on.

• Always bring your System Recovery disc when you travel. If you experience system software problems while

traveling, you may need it to correct any problems. Take the necessary plug adapters if you're traveling overseas. Check the following diagram to determine which plug adapter you'll need or ask your travel agent.

Outlet Type Location Outlet Type Location

United States, Canada, parts of Latin America, Mexico, Japan, Korea, the Philippines, Taiwan

Russia and the Commonwealth of Independent

States (CIS), most of Europe, parts of Latin America,

the Middle East, parts of Africa, Hong Kong, India,

most of South Asia

- Caring for your LIFEBOOK Notebook

United Kingdom, Ireland, Malaysia, Singapore,

parts of Africa

China, Australia, New Zealand

• It is recommended that you carry your notebook with you while traveling, rather than checking it in as

baggage.

• Never put your notebook through a metal detector. Have your notebook hand-inspected by security personnel.

You can however, put your notebook through a properly tuned X-ray machine. To avoid problems, place your notebook close to the entrance of the machine and remove it as soon as possible or have your notebook handinspected by security personnel. Security officials may require you to turn your notebook on, so make sure you have a charged battery on hand.

Batteries

Caring for your Batteries

• Always handle batteries carefully.

• Do not short-circuit the battery terminals (that is, do not touch both terminals with a metal object). Do not

carry loose batteries in a pocket or purse where they may mix with coins, keys, or other metal objects. Doing so may cause an explosion or fire.

• Do not drop, puncture, disassemble, mutilate or incinerate the battery.

• Recharge batteries only as described in this manual and only in ventilated areas.

• Do not leave batteries in hot locations for more than a day or two; intense heat can shorten the battery life.

• Do not leave a battery in storage for longer than 6 months without recharging it.

Increasing Battery Life

• Power your LIFEBOOK notebook through the AC or optional auto/airline adapter whenever possible.

• If your notebook is running on battery power all day, connect it to the AC adapter overnight.

• Keep brightness to the lowest level comfortable.

• Turn off the Wireless LAN/Bluetooth devices when not in use by clicking the [Fn]+[F5] key combination.

• Set the power management for maximum battery life.

• Put your notebook in Standby mode when it is turned on and you are not actually using it.

• Limit your media drive access.

• Disable the Media Player auto insert notification function.

• Always use fully charged batteries.

• Eject ExpressCards when not in use.

- Caring for your LIFEBOOK Notebook

Media Care

Caring for your Media (DVD/CD/CD-R)

Media discs are precision devices and will function reliably if given reasonable care.

• Always store your media disc in its case when it is not in use.

• Always handle discs by the edges and avoid touching the surface.

• Avoid storing any media discs in extreme temperatures.

• Do not bend media discs or set heavy objects on them.

• Do not spill liquids or get dust on media discs.

• Do not scratch media discs.

• If a media disc is subjected to a sudden change in temperature, cold to warm condensation may form on the

surface. Wipe the moisture off with a clean, soft, lint free cloth and let it dry at room temperature. DO NOT use a hair dryer or heater to dry media discs.

• Never write on the label surface with a ballpoint pen or pencil. Always use a felt pen.

• If a disc is dirty, use only a DVD/CD cleaner or wipe it with a clean, soft, lint free cloth starting from the inner

edge and wiping to the outer edge.

Caring for your Optical Drive

Your optical drive is durable but you must treat it with care. Please pay attention to the following points:

• The drive rotates the compact disc at a very high speed. Do not carry it around or subject it to shock or vibration

with the power on.

• Avoid using or storing the drive where it will be exposed to extreme temperatures or a damp or dusty

environment.

• Avoid using or storing the drive near magnets or devices that generate strong magnetic fields.

• Avoid using or storing the drive where it will be subjected to shock or vibration.

• Do not disassemble or dismantle the optical drive.

• Use of a commercially available lens cleaner is recommended for regular maintenance of the drive.

- Caring for your LIFEBOOK Notebook

ExpressCards/SD Cards

Caring for your Cards

Media are durable, but you must treat them with care. The documentation supplied with your card will provide specific information, but you should pay attention to the following points:

• To keep out dust and dirt, store cards in their protective sleeves when they are not installed.

• Avoid prolonged exposure to direct sunlight or excessive heat.

• Keep the cards dry.

• Do not flex or bend the cards, and do not place heavy objects on top of them.

• Do not force cards into the slot.

• Avoid dropping cards, or subjecting them to excessive vibration.

- Caring for your LIFEBOOK Notebook

Chapter 6

System Specifications

Specifications

This section provides the hardware and environmental specifications for your Fujitsu LIFEBOOK notebook. Specifications of particular configurations will vary.

Microprocessor
