AIR CONDITIONER
CEILING TYPE
OPERATING MANUAL
BEDIENUNGSANLEITUNG
MODE D’EMPLOI
MANUAL DE FUNCIONAMIENTO
MANUALE DI ISTRUZIONI
ΕΓΧΕΙΡΙΔΙΟ ΛΕΙΤΟΥΡΓΙΑΣ
MANUAL DE FUNCIONAMENTO
РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ
KULLANIM KILAVUZU
KEEP THIS MANUAL FOR FUTURE REFERENCE
BEWAHREN SIE DIESES HANDBUCH ZUM SPÄTEREN NACHSCHLAGEN AUF
CONSERVEZ CE MANUEL POUR RÉFÉRENCE ULTÉRIEURE
CONSERVE ESTE MANUAL PARA FUTURA REFERENCIA
CONSERVARE IL PRESENTE MANUALE PER FUTURE CONSULTAZIONI
ΦΥΛΑΞΤΕ ΤΟ ΕΓΧΕΙΡΙΔΙΟ ΓΙΑ ΜΕΛΛΟΝΤΙΚΗ ΑΝΑΦΟΡΑ
GUARDE ESTE MANUAL PARA REFERÊNCIA FUTURA
ХРАНИТЕ РУКОВОДСТВО ДЛЯ СПРАВОК В БУДУЩЕМ
BU KILAVUZU İLERİDE BAŞVURMAK ÜZERE SAKLAYIN
[Original instructions]
Italiano Español Français Deutsch English
EλληvIkά
Português
РусскийTürkçe
PART No. 9374379736-03
OPERATING MANUAL
AIR CONDITIONER (CEILING TYPE)
CONTENTS
PART No. 9374379736-03
SAFETY PRECAUTIONS ......................................1
FEATURES AND FUNCTIONS ............................. 2
NAME OF PARTS .................................................3
PREPARATION ..................................................... 5
OPERATION ..........................................................6
TIMER OPERATION ............................................. 8
SLEEP TIMER OPERATION .................................9
MANUAL AUTO OPERATION ............................... 9
ADJUSTING THE DIRECTION OF AIR CIRCULATION
... 10
SWING OPERATION .......................................... 11
ECONOMY OPERATION .................................... 11
10 °C HEAT OPERATION ................................... 12
REMOTE CONTROLLER CUSTOM CODE
SETTING .............................................................12
CLEANING AND CARE .......................................13
TROUBLESHOOTING ........................................14
OPERATING TIPS ............................................... 15
SAFETY PRECAUTIONS
● To prevent personal injury, or property damage, read this section carefully before you use this product, and be sure
to comply with the following safety precautions.
● Incorrect operation due to failure to follow the instructions may cause harm or damage, the seriousness of which is
classifi ed as follows:
WARNING
CAUTION
● This product contains no user-serviceable parts. Always
consult authorized service personnel for repairing,
installation, and relocation of this product.
Improper installation or handling will cause leakage,
electric shock, or fi re.
● In the event of a malfunction such as burning smell,
immediately stop operation of the air conditioner, and
disconnect all the power supply by turning off the electrical
breaker or disconnecting the power plug. Then consult
authorized service personnel.
● Take care not to damage the power supply cable.
If it is damaged, it should only be replaced by authorized
service personnel.
● In the event of refrigerant leakage, be sure to keep away
from fi re or any fl ammables, and consult authorized service
personnel.
● In the event of a thunder storm or any prior sign of a
lightning strike, turn off the air conditioner via the remote
controller, and refrain from touching the product or the
power source to prevent any electrical hazards.
This mark indicates procedures which, if improperly performed, might lead to the death or
serious injury of the user or service personnel.
This mark indicates procedures which, if improperly performed, might possibly result in
personal harm to the user, or damage to property.
WARNING
● This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety. Children should be supervised to ensure
that they do not play with the appliance.
● Do not start or stop the operation of this product by
inserting or pulling out the power plug, or by turning on or
off the circuit breaker.
● Do not use fl ammable gases near this product.
● Do not expose yourself directly to the cooling airfl ow for
many hours.
● Do not insert your fi ngers or any other objects into outlet
port, open panel, or intake grille.
● Do not operate with wet hands.
● Provide occasional ventilation during use.
● Always operate this product with air filters installed.
● Ensure that any electronic equipment is at least 1 m (40 in)
away from either the indoor unit or outdoor unit.
● Disconnect all the power supply when you are not using
this product for extended periods.
● After a long period of use, ensure to get the mounting of
the indoor unit checked to prevent this product from falling
down.
● The airflow direction and the room temperature should be
carefully considered when you use this product in a room
with infants, children, elderly or sick persons.
● Do not direct the airflow at fireplaces or heating apparatus.
● Do not block or cover the intake grille and the outlet port.
● Do not apply any heavy pressure to radiator fins.
● Do not climb on, place objects on, or hang objects from
this product.
En-1
CAUTION
● Do not place any other electrical products or household
belongings under this product.
Dripping condensation from this product might get them
wet, and may cause damage or malfunction of your
property.
● Do not expose this product directly to water.
● Do not use this product for preservation of food, plants,
animals, precision equipment, art work, or other objects.
This may cause quality deterioration of those items.
● Do not expose animals or plants to the direct airflow.
● Do not drink the drainage from the air conditioner.
● Do not pull the power supply cable.
● Do not touch the aluminum fins of heat exchanger built-in
this product to avoid personal injury when you maintain the
unit.
FEATURES AND FUNCTIONS
■
Energy saving and comfortable function
INVERTER
At the start of operation, large amount of power is used to
bring the room quickly to the desired temperature. Afterwards,
the unit automatically switches to a low power setting for
economic and comfortable operation.
ECONOMY OPERATION
When the Economy operation is operated, the room
temperature will be little higher than the set-temp under the
Cooling mode and lower than set-temp under the Heating
mode. Therefore, the Economy operation is able to save more
energy than other normal operation.
OMNI-DIRECTIONAL AIRFLOW
(SWING OPERATION)
3-dimensional control over air direction swing is possible
through dual use of both the Up/down Swing operation and the
Left/right Swing operation. Since up/down air direction louvers
operate automatically according to the operating mode of the
unit, it is possible to set air direction based on the operating
mode.
SUPER QUIET OPERATION
When the “FAN” button is used to select [QUIET], the indoor
unit begins the Super Quiet operation; the indoor unit’s airfl ow
is reduced to produce quieter operation.
10 °C HEAT OPERATION
The room temperature can be maintained at 10°C so as to
prevent the room temperature from falling too far.
■
Convenient function
PROGRAM TIMER
The Program Timer allows you to integrate the Off Timer and
the On Timer operations in a single sequence. The sequence
can involve 1 transition from the Off Timer to the On Timer, or
from the On Timer to the Off Timer, within a 24 hour period.
SLEEP TIMER
When the “SLEEP” button is pressed during the Heating
mode, the air conditioner’s temperature setting is gradually
lowered during the period of operation; during the Cooling
or the Dry mode, the temperature setting is gradually raised
during the period of operation. When the set time is reached,
the unit automatically turns off .
■
Clean function
REMOVABLE AIR FILTER
The indoor unit’s air fi lter can be removed for easy cleaning
and maintenance.
This product contains fl uorinated greenhouse gases.
AUTO CHANGEOVER
The operation mode (Cooling mode, Dry mode, Heating mode)
is switched auto matically to maintain the set temperature, and
the temperature is kept constant at all times.
En-2
FEATURES AND FUNCTIONS
3 2
1
9
8
7
456
■
Remote controller
WIRELESS REMOTE CONTROLLER
The wireless remote controller allows convenient control of air
conditioner operation.
WIRED REMOTE CONTROLLER (OPTIONAL)
The optional wired remote controller can be used.
When you use the wired remote controller, there are following
different points as compared with using wireless remote
controller.
NAME OF PARTS
Indoor unit
[The additional functions for wired remote controller]
• Weekly Timer
• Temperature Set Back Timer
And you can use both wired remote controller and wireless
remote controller simultaneously.
(But function is limited)
When the restricted functions on the remote controller are
used, beeping sound will be heard, the Operation indicator
lamp, the Timer indicator lamp and the Economy indicator
lamp of the indoor unit will blink.
[The restricted functions for wireless remote controller]
• Sleep Timer
• Timer operation (On Timer, Off Timer and Program Timer)
• 10 °C Heat operation
1 Control panel
2 Manual Auto button
● When the Manual Auto button is pressed in for more than
10 seconds, the Forced Cooling operation will start.
● The Forced Cooling operation is used at the time of
installation.
Only for authorized service personnel’s use.
● When the Forced Cooling operation starts by any chance,
press the “START/STOP” button to stop the operation.
● Please press the button to reset the fi lter indicator.
3 Remote controller signal receiver
4 Operation indicator lamp (green)
5 Timer indicator lamp (orange)
● Timer indicator lamp lights when the timer is set from
wireless remote controller.
● If the Timer indicator lamp blinks when the timer is
operating, it indicates that a fault has occurred with the
timer setting (see “Auto restart” on page 16.)
6 Economy indicator lamp (green)
● Economy indicator lamp lights in the following operations:
• Economy operation
• 10 ºC Heat operation (controlled by wireless remote
controller)
En-3
7 Intake grille
8 Up/down air direction louvers
9 Left/right air direction louvers
(behind up/down air direction louvers)
NAME OF PARTS
Remote controller
Display panel
Display panel
To facilitate explanation, the accompanying illustration
has been drawn to show all possible indicators; in actual
operation, however, the display will only show those
indicators appropriate to the current operation.
“MODE” button
1
“10 °C HEAT” button
2
“SET TEMP.” button (
3
“ECONOMY” button
4
“SLEEP” button
5
“FAN” button
6
“START/STOP” button
7
“SET” button (Vertical)
8
“SET” button (Horizontal)
9
“SWING” button
0
“TIMER MODE” button
A
“TIMER” Set ( / ) button
B
“CLOCK ADJUST” button
C
“RESET” button
D
“TEST RUN” button
E
●
This button is used when installing the air
conditioner, and should not be used under
normal conditions, as it will cause the air
conditioner’s thermostat function to operate
incorrectly.
●
If this button is pressed during normal
operation, the unit will switch to the Test
Run mode, and the indoor unit’s Operation
indicator lamp and Timer indicator lamp will
begin to blink simultaneously.
●
To stop the Test Run mode, press the
“START/STOP” button to stop the air
conditioner.
/
Signal transmitter
F
Temperature set indicator
G
)
Operating mode indicator
H
[SLEEP] indicator
I
Transmit indicator
J
Fan speed indicator
K
Swing indicator
L
Timer mode indicator
M
Clock indicator
N
Some indoor units may not be equipped with the functions
corresponding to all of the buttons on this remote
controller. The indoor unit will beep and the Operation
indicator lamp, Timer indicator lamp and Economy
indicator lamp blink when a remote controller button is
pressed if the function is not available.
En-4
PREPARATION
Turn on the power
Turn on the circuit breaker.
1
Load batteries (AAA/R03/LR03 2)
Press and slide the battery compartment lid on the
1
reverse side to open it.
Slide the lid while pressing the mark.
Insert batteries.
2
Be sure to align the battery polarities ( ) correctly.
Close the battery compartment lid.
3
Set the current time
Press the “CLOCK ADJUST” button.
1
Use the tip of a ball-point pen or other small object to press the button.
Use the “TIMER” Set ( / ) buttons to adjust the
2
clock to the current time.
button:
(Each time the buttons are pressed, the time will be advanced/reversed in
button:
1-minute increments; hold the buttons depressed to change the time quickly
in 10-minute increments.)
Press to advance the time.
Press to reverse the time.
WARNING
●
Take care to prevent infants and young
children from accidentally swallowing the
batteries.
CAUTION
●
To prevent malfunction or damage of the
remote controller:
- Place remote controller at where will not
be exposed to direct sunlight or excessive
heat.
- Remove batteries if the product is not
going to be used for an extended period.
- Exhausted batteries must be removed
immediately, and be disposed according
to the local laws and regulations of your
region.
●
If leaking battery fl uid comes in contact with
your skin, eyes, or mouth, immediately rinse
with plenty of clean water, and consult your
physician.
●
Obstacles such as a curtain or wall between
the remote controller and the indoor
unit may affect the appropriate signal
transmission.
●
Do not apply strong shocks to the remote
controller.
●
Do not pour water on the remote controller.
●
Do not attempt to recharge dry batteries.
●
Do not use dry batteries that has been
recharged.
Use specifi ed type of batteries only.
Do not mix different types or new and
used batteries together.
Batteries can be used about 1 year
in ordinary use. If the remote control
range noticeably shortens, replace the
batteries, and press the “RESET” button
with the tip of a ball point pen or other
small object.
Press the “CLOCK ADJUST” button again.
3
This completes the time setting and starts the clock.
To use the remote controller
●
The remote controller must be pointed at signal receiver to operate correctly.
●
Operating range: About 7 meters.
●
When a signal is properly received by the air conditioner, a beeping sound will be
heard.
●
If no beep is heard, press the button of the remote controller again.
Remote controller holder
Screws
Mount the remote
1
controller holder.
Insert
Press in
Set the remote controller.
2
Slide up
Pull out
To remove the remote
3
controller (when use at
hand).
En-5
OPERATION
To select the operating mode
Press the “START/STOP” button.
1
The indoor unit’s Operation indicator lamp (green) will light.
The air conditioner will start operating.
Press the “MODE” button to select the desired mode.
2
Each time the button is pressed, the mode will change in the following order.
[AUTO] [COOL] [DRY]
[HEAT] [FAN]
About 3 seconds later, the entire display will reappear.
To set the room temperature
Press the “SET TEMP.” button.
button: Press to raise the temperature setting.
button: Press to lower the temperature setting.
● Temperature setting range:
Auto mode .............................18-30 °C
Heating mode ........................16-30 °C
Cooling mode/Dry mode .......18-30 °C
The temperature cannot be set during the Fan mode (the temperature will not appear on
the remote controller display).
Example: When set to [COOL].
About 3 seconds later, the entire display will reappear.
The temperature setting should be considered a standard value, and may diff er
somewhat from the actual room temperature.
To set the fan speed
Press the “FAN” button.
Each time the button is pressed, the fan speed changes in the following order:
[AUTO] [HIGH] [MED] [LOW] [QUIET]
About 3 seconds later, the entire display will reappear.
When set to [AUTO]:
Heating mode: Fan operates so as to optimally circulate warmed air.
However, the fan will operate at very low speed when the temperature
of the air issued from the indoor unit is low.
Cooling mode: As the room temperature approaches that of the temperature setting,
the fan speed becomes slower.
Fan mode: The fan runs at the low fan speed.
The fan will operate at a very low setting during the Monitor operation and at the start of
the Heating mode.
Super Quiet operation
When set to [QUIET]:
The Super Quiet operation begins. The indoor unit’s airfl ow will be reduced for quieter
operation.
● The Super Quiet operation cannot be used during the Dry mode. (The same is true
when the Dry mode is selected during the Auto mode operation.)
● During the Super Quiet operation, heating and cooling performance will be reduced
somewhat. If the room does not warm up/cool down when using the Super Quiet
operation, please adjust the air conditioner’s fan speed.
Example: When set to 26 °C.
Example: When set to [AUTO].
En-6
OPERATION
Instructions relating to heating (*) are applicable only to Heating and Cooling model (Reverse Cycle).
To stop operation
Press the “START/STOP” button.
The Operation indicator lamp (green) will go out.
Operating mode
[AUTO] (in Cooling model):
Room temperature is higher than the defi ned temperature in temperature
Room temperature is close to or lower than the defined temperature in
[AUTO] [in Heating and Cooling model (Reverse Cycle)]:
●
●
When the Auto mode (automatic changeover) operation is selected, the fan will operate at very low speed for about a few
minutes, during which time the indoor unit detects the room conditions and selects the proper mode.
setting → Cooling mode or Dry mode
temperature setting → Monitor operation
●
When the indoor unit has adjusted your room’s temperature to near the temperature setting, it will begin the Monitor
operation. In the Monitor operation, the fan will operate at low speed. If the room temperature subsequently changes,
the indoor unit will once again select the appropriate operation (Cooling mode) to adjust the temperature to the value
set in the temperature setting.
●
If the mode automatically selected by the unit is not what you wish, select one of the operating mode ([COOL], [DRY], [FAN]).
●
When Auto mode (automatic changeover) is selected, the air conditioner selects the appropriate operation (Cooling
Defi ned
temperature in
temperature
setting
mode or Heating mode) according to your room’s present temperature.
When the Auto mode is selected, the fan will operate at low speed for about a few minute, during which time the indoor
unit detects the room conditions and selects the proper operating mode.
Cooling mode
or Dry mode
Monitor operation
Room temperature is higher than the defi ned temperature in temperature
setting → Cooling mode or Dry mode
Room temperature is close to the defined temperature in temperature
setting → Determined by outdoor temperature
Room temperature is lower than the defined temperature in temperature
setting → Heating mode
●
[HEAT]*:
When the air conditioner has adjusted your room’s temperature to near the temperature setting, it will begin the Monitor
operation. In the Monitor operation, the fan will operate at low speed. If the room temperature subsequently changes,
the air conditioner will once again select the appropriate operation (Heating mode, Cooling mode) to adjust the
temperature to the value set in the thermostat.
●
If the mode automatically selected by the unit is not what you wish, select one of the operating mode ([HEAT], [COOL],
[DRY], [FAN]).
●
Use to warm your room.
●
When the Heating mode is selected, the air conditioner will operate at
very low fan speed for about 3 to 5 minutes, after which it will switch to the
selected fan setting. This period of time is provided to allow the indoor unit
to warm up before beginning full operation.
●
When the room temperature is very low, frost may form on the outside
unit, and its performance may be reduced. In order to remove such frost,
the unit will automatically enter the defrost cycle from time to time. During
the Automatic Defrosting operation, the Operation indicator lamp will blink,
and the Heating mode operation will be interrupted.
●
After the start of the Heating mode operation, it takes some time before
the room gets warmer.
[COOL]:
[DRY]:
●
Use to cool your room.
●
Use for gently cooling while dehumidifying your room.
●
You cannot heat the room during the Dry mode.
●
During the Dry mode, the unit will operate at low speed; in order to adjust
room humidity, the indoor unit’s fan may stop from time to time. Also, the
fan may operate at very low speed when adjusting room humidity.
●
The fan speed cannot be changed manually when the Dry mode has been
selected.
[FAN]:
●
Use to circulate the air throughout your room.
En-7
Cooling mode or
Defi ned
temperature in
temperature
setting
During Heating mode*:
Set the temperature higher than the current
room temperature. The Heating mode will
not operate if the set temperature is lower
than the actual room temperature.
During Cooling mode/Dry mode:
Set the temperature lower than the current
room temperature. The Cooling mode and
the Dry mode will not operate if the set
temperature is higher than the actual room
temperature (in the Cooling mode, the fan
alone will operate).
During Fan mode:
You cannot use the unit to heat and cool
your room.
Dry mode
Determined by
outdoor temperature
Heating mode
TIMER OPERATION
Before using the timer operation, be sure that the remote controller is set to the correct current time (
If the indoor unit is connected to a wired remote controller, the wireless remote controller cannot be used to set the timer.
NOTES:
In simultaneous multi connection, this function by using the wireless remote controller cannot be used.
☞
P. 5).
To use On Timer or Off Timer
Press the “START/STOP” button
1
(if the unit is already operating, proceed to step 2).
The indoor unit’s Operation indicator lamp (green) will light.
Press the “TIMER MODE” button to select the Off
2
Timer or the On Timer operation.
Each time the button is pressed the timer function changes in the following
order:
[CANCEL] [OFF] [ON]
PROGRAM ([OFF → ON], [OFF ← ON])
The indoor unit’s Timer indicator lamp (orange) will light.
Use the “TIMER” Set buttons to adjust the desired Off
3
time or On time.
Set the time while the clock indicator is blinking (the blinking will continue for
about 5 seconds).
button:
button:
About 5 seconds later, the entire display will reappear.
▲
Press to advance the time
Press to reverse the time.
▲
▲
▲
.
To Cancel the timer
Use the “TIMER MODE” button to select
[CANCEL].
The air conditioner will return to normal
operation.
To change the timer settings
Perform steps 2 and 3.
To stop air conditioner operation while
the timer is operating
Press the “START/STOP” button.
To change operating conditions
If you wish to change operating conditions
(mode, fan speed, temperature setting, Super
Quiet operation), after making the timer setting
wait until the entire display reappears, then
press the appropriate buttons to change the
operating condition desired.
To use Program Timer
Press the “START/STOP” button
1
(if the unit is already operating, proceed to step 2).
The indoor unit’s Operation indicator lamp (green) will light.
Set the desired times for Off Timer and On Timer.
2
See the section “To use On Timer or Off Timer” to set the desired mode and
times.
About 3 seconds later, the entire display will reappear.
The indoor unit’s Timer indicator lamp (orange) will light.
Press the “TIMER MODE” button to select the Program
3
Timer operation ([OFF → ON] or [OFF ← ON] will
display).
The display will alternately show [OFF] and [ON], then change to show the
time setting for the operation to occur fi rst.
●
The Program Timer will begin operation. (If the On Timer has been
selected to operate fi rst, the unit will stop operating at this point.)
About 5 seconds later, the entire display will reappear.
About Program Timer
●
The Program Timer allows you to integrate the Off Timer and the On Timer
operations in a single sequence. The sequence can involve 1 transition from Off
Timer to On Timer, or from On Timer to Off Timer, within a 24 hour period.
●
The first timer function to operate will be the 1 set nearest to the current time.
The order of operation is indicated by the arrow in the remote controller display
([OFF → ON] or [OFF ← ON]).
●
An example of the Program Timer use might be to have the air conditioner
automatically stop (Off Timer) after you go to sleep, then start (On Tim er )
automatically in the morning before you arise.
To cancel the timer
Use the “TIMER MODE” button to select
[CANCEL].
The air conditioner will return to normal
operation.
To change the timer settings
1. Follow the instructions given in the section
“To use On Timer or Off Timer” to select the
timer setting you wish to change.
2. Press the “TIMER MODE” button to select
either [OFF → ON] or [OFF ← ON].
To stop air conditioner operation while
the timer is operating
Press the “START/STOP” button.
To change operating conditions
If you wish to change operating conditions
(mode, fan speed, temperature setting, Super
Quiet operation), after making the timer setting
wait until the entire display reappears, then
press the appropriate buttons to change the
operating condition desired.
En-8
SLEEP TIMER OPERATION
Unlike other timer functions, the Sleep Timer is used to set the length of time until air conditioner operate is stopped.
If the indoor unit is connected to a wired remote controller, the wireless remote controller cannot be used to set the Sleep Timer.
NOTES:
In simultaneous multi connection, this function by using the wireless remote controller cannot be used.
To use Sleep Timer
While the air conditioner is operating or stopped, press the
“SLEEP” button.
The indoor unit’s Operation indicator lamp (green) lights and the Timer indicator lamp
(orange) light.
To change timer settings
Press the “SLEEP” button once again and set the time using
the “TIMER” Set (
button:
button:
About 5 seconds later, the entire display will reappear.
About Sleep Timer
To prevent excessive warming or cooling during sleep, the Sleep Timer function automatically modifi es the temperature setting in
accordance with the set time setting. When the set time has elapsed, the air conditioner completely stops.
During Heating mode:
When the Sleep Timer is set, the temperature setting is
automatically lowered 1 °C every 30 minutes. When the
temperature has been lowered a total of 4 °C, the temperature
setting at that time is maintained until the set time has elapsed,
at which time the air conditioner automatically turns off .
Sleep Timer setting
/ ) buttons.
Press to advance the time.
Press to reverse the time.
1 °C
2 °C
3 °C
4 °C
30
minutes
During Cooling mode / Dry mode:
When the Sleep Timer is set, the temperature setting is
automatically raised 1 °C every 1 hour. When the temperature
has been raised a total of 2 °C, the temperature setting at that
time is maintained until the set time has elapsed, at which time
the air conditioner automatically turns off .
Sleep Timer setting
1 hour
To cancel the timer
Use the “TIMER MODE” button to select
[CANCEL].
The air conditioner will return to normal
operation.
To stop the air conditioner during timer
operation
Press the “START/STOP” button.
Set time
1 hour
1 hour
30 minutes
1 °C
Set time
2 °C
MANUAL AUTO OPERATION
Perform the Manual Auto operation if you have lost the remote controller or encounter remote control malfunction.
How to control the indoor unit without remote controller
Press the Manual Auto button on the indoor unit more than 3
seconds and less than 10 seconds.
To stop the operation, press the Manual Auto button once again.
●
When the air conditioner is operated
with the Manual Auto button on the
indoor unit, it will perform the same
mode as the Auto mode selected on the
remote controller.
●
The fan speed will be set to [AUTO] and
the temperature setting will be at the
standard value. (24
°C
)
En-9
1
2
3
4
5
1
2
3
4
5
ADJUSTING THE DIRECTION OF AIR CIRCULATION
Instructions relating to heating (*) are applicable only to Heating and Cooling model (Reverse Cycle).
● Adjust the up, down, left and right air directions with the “SET” buttons on the remote controller.
● Use the “SET” buttons after the indoor unit has started operating and the air direction louvers have stopped moving.
Vertical air direction adjustment
Press the “SET” button (Vertical).
Each time the button is pressed, the air direction range will change as follows:
1
2 3 4 5
Types of Airfl ow Direction Setting:
1, 2, 3 : During Cooling mode/Dry mode
1, 2, 3, 4, 5 : During Heating mode*
The remote controller display does
not change.
● Use the air direction adjustments within the ranges shown above.
● The vertical airfl ow direction is set automatically as shown, in accordance with the
operating mode selected.
Horizontal fl ow 1 : During Cooling mode/Dry mode
Downward fl ow 5 : During Heating mode*
● During the Auto mode operation, for the fi rst minute after beginning operation, airfl ow
will be horizontal 1; the air direction cannot be adjusted during this period.
Horizontal air direction adjustment
Press the “SET” button (Horizontal).
Each time the button is pressed, the air direction range will change as follows:
WARNING
Never place fi ngers or foreign objects inside
the outlet ports, since the internal fan operates
at high speed and could cause personal injury.
● Attempting to move up/down air direction
louvers or left/right air direction louvers
manually could result in improper
operation; in this case, stop operation
and restart. The louvers should begin to
operate properly again.
● During use of the Cooling mode and the
Dry mode, do not set the up/down air
direction louvers in the Heating mode
range (4 to 5) for long periods of time,
since water vapor may condense near
the outlet louvers and drops of water may
drip from the air conditioner. During the
Cooling mode and the Dry mode, if the
air direction louvers are left in the Heating
mode range for more than 30 minutes,
they will automatically return to position
3.
● When used in a room with infants,
children, elderly or sick persons, the air
direction and room temperature should
be considered carefully when making
settings.
1
2 3 4 5
The remote controller display does not change.
Left/right air direction louvers
● Use the air direction adjustments within the ranges shown below.
En-10
SWING OPERATION
Begin air conditioner operation before performing this procedure.
To select Swing operation
Press the “SWING” button.
Each time the “SWING” button is pressed, the Swing operation will change in the following
order.
Up/down Swing operation
Swing operation stops Up/down/left/right Swing operation
To stop Swing operation
Press the “SWING” button and select stop.
Airfl ow direction will return to the setting before the Swing operation was begun.
About Swing operation
● To select the Up/down Swing operation
Operating mode
Cooling mode/Dry mode
Heating mode
Fan mode
● To select the Left/right Swing operation
Operating mode
Cooling mode/Dry mode
Heating mode
Fan mode
Range of swing
Range of swing
1 to 5 (All range)
1 to 5 (All range)
1 to 5 (All range)
Left/right Swing operation
1 to 4
3 to 5
1 to 5
The Swing operation may stop temporarily when the air conditioner’s
fan is not operating, or when operating at very low speeds.
The Swing operation may stop temporarily when the air conditioner’s
fan is not operating, or when operating at very low speeds.
ECONOMY OPERATION
Begin air conditioner operation before performing this procedure.
To use Economy operation
Press the “ECONOMY” button.
The Economy indicator lamp (green) will light.
The Economy operation begins.
To stop Economy operation
Press the “ECONOMY” button again.
The Economy indicator lamp (green) will go out.
Normal operation begins.
About Economy operation
At the maximum output, the Economy operation is approximately 70% of normal operation for cooling and heating.
●
If the room is not cooled (or heated) well during the Economy operation, select normal operation.
●
During the Monitor operation in the Auto mode, the air conditioner operation will not change to the Economy operation even if the
Economy operation is selected by pressing the “ECONOMY” button.
●
When the Economy operation is operated, the room temperature will be little higher than the set-temp under the Cooling mode
and lower than the set-temp under the Heating mode. Therefore, the Economy operation is able to save more energy than other
normal operation.
En-11
10 °C HEAT OPERATION
NOTES: In simultaneous multi connection, this function by using the wireless remote controller cannot be used.
To use 10 °C Heat operation
Press the “10 °C HEAT” button.
The Operation indicator lamp (green) will go out, and the Economy indicator lamp (green)
will light.
While the 10 °C Heat operation is in
progress, only the following
operation can be used.
•
Swing operation
To stop 10 °C Heat operation
Press the “START/STOP” button.
Then the operation stops and the Economy indicator lamp (green) will go out.
About 10 °C Heat operation
• The Heating mode will not operate if the room temperature is high enough.
• The room temperature can be maintained at 10 °C by pressing the “10 °C HEAT” button so as to prevent the room temperature from
falling too far.
REMOTE CONTROLLER CUSTOM CODE SETTING
When two or more air conditioners are installed in a room and the remote controller is operating an air conditioner other than the
one you wish to set, change the custom code of the remote controller to operate only the air conditioner you wish to set (4 selections
possible).
When two or more air conditioners are installed in a room, please contact your retailer to set the individual air conditioner custom
codes.
Use the following steps to select the custom code of the remote controller. (Note that the air conditioner cannot receive a signal if it
has not been set for the matching custom code.)
Press the “START/STOP” button until only the clock
1
indicator is displayed on the remote controller
display panel.
Press the “MODE” button for at least fi ve seconds to
2
display the current custom code (initially set to A).
Press the “SET TEMP.” buttons
3
custom code between
ABC
( / )
D
to change the
. Match the code on
the display panel to the air conditioner custom code.
Press the “MODE” button again to return to the clock
4
indicator display. The custom code will be changed.
●
If no buttons are pressed within 30 seconds after the custom code is displayed, the system returns to the original clock
indicator display. In this case, start again from step 1.
●
The air conditioner custom code is set to “A” prior to shipment. Contact your retailer to change the custom code.
●
The remote controller resets to custom code “A” when the batteries in the remote controller are replaced. If you use a
custom code other than “A”, reset the custom code after replacing the batteries.
If you do not know the air conditioner custom code setting, try each of the custom codes (A → B → C → D) until you fi nd the
code which operates the air conditioner.
En-12
CLEANING AND CARE
● Before cleaning this product, be sure to turn it off and disconnect all the power supply.
CAUTION
● When used for extended periods, the unit may accumulate dirt inside, reducing its performance. We recommend that the unit be
inspected regularly, in addition to your own cleaning and care. For more information, consult authorized service personnel.
● When cleaning the unit’s body, do not use water hotter than 40 °C, harsh abrasive cleansers, or volatile agents like benzene or
thinner.
● If the unit will not be operated for a period of 1 month or more, be sure to allow the inner parts of the unit to dry thoroughly, in
advance, by operating the unit in the Fan mode for half a day.
Cleaning air fi lter
● The fan operates at high speed inside the unit, and could result in personal injury.
● Be careful not to drop the intake grille.
● As fi lter cleaning involves work in high places, please consult authorized service personnel.
● Do not expose the unit body to liquid insecticides or hairsprays.
1. Pull the air fi lters upward to remove them.
Remove the air fi lters by raising its handle while pulling it out
towards you.
Air fi lter
2. Clean the air fi lters.
Remove the dust from the air fi lters by vacuuming or washing
them. After washing, allow the air fi lters to dry thoroughly in
an area protected from sunlight.
Filter indicator reset (special setting)
• This function can be used if set correctly during installation.
Please consult authorized service personnel in order to use this function.
• Clean the air fi lter when the indicator lamp show the following;
Economy indicator lamp Blinks 3 times, at intervals of 21 seconds
3. Re-attach the air fi lters to the intake grille.
The air fi lters fi t onto the inside of the intake grille.
● Dust can be cleaned from the air fi lter either with a vacuum
cleaner, or by washing the air fi lter in a solution of mild
detergent and warm water. If you wash the air fi lter, be
sure to allow it to dry thoroughly in a shady place before
reinstalling.
● If dirt is allowed to accumulate on the air fi lter, airfl ow will
be reduced, lowering operating effi ciency and increasing
noise.
After cleaning, reset the fi lter indicator by pushing the Manual Auto button on the indoor unit for 3 seconds or less.
En-13
TROUBLESHOOTING
Instructions relating to heating (*) are applicable only to Heating and Cooling model (Reverse Cycle).
WARNING
• Unit smells of something burning or emits smoke
• Water leaks from the unit
Before requesting service, perform the following checks:
Normal function Does not operate imme-
diately:
Noise is heard:
Smells:
Mist or steam are
emitted:
Airfl ow is weak or stops: *
Water is produced from the
outdoor unit:
The Economy indicator
lamp is blinking:
In following events, immediately stop operation of the air conditioner, and disconnect all the power
supply by turning off the electrical breaker or disconnecting the power plug. Then consult your
dealer or authorized service personnel.
As long as the unit is connected to the power supply, it is not insulated from the power supply
even if the unit is turned off .
Symptom Problem
●
If the unit is stopped and then immediately started again, the
compressor will not operate for about 3 minutes, in order to
prevent fuse blowouts.
●
Whenever the power supply plug is disconnected and then
reconnected to a power outlet, the protection circuit will operate
for about 3 minutes, preventing unit operation during that
period.
●
During operation and immediately after stopping the unit, the
sound of water fl owing in the air conditioner’s piping may be
heard. Also, noise may be particularly noticeable for about
2 to 3 minutes after starting operation (sound of coolant
fl owing).
●
During operation, a slight squeaking sound may be heard.
This is the result of minute expansion and contraction of the
front cover due to temperature changes.
●
*
During the Heating mode operation, a sizzling sound may be
heard occasionally. This sound is produced by the Automatic
Defrosting operation.
●
Some smell may be emitted from the indoor unit. This smell is
the result of room smells (furniture, tobacco, etc.) which have
been taken into the air conditioner.
●
During the Cooling mode or the Dry mode operation, a thin
mist may be seen emitted from the indoor unit. This results
from the sudden cooling of room air by the air emitted from
the air conditioner, resulting in condensation and misting.
●
*
During the Heating mode operation, the outdoor unit’s fan
may stop, and steam may be seen rising from the unit. This is
due to the Automatic Defrosting operation.
●
When the Heating mode operation is started, fan speed is
temporarily very low, to allow internal parts to warm up.
●
*
During the Heating mode operation, if the room temperature
rises above the temperature setting, the outdoor unit will stop,
and the indoor unit will operate at very low fan speed. If you
wish to warm the room further, set the temperature to a higher
setting.
●
*
In the Heating mode, the indoor unit temporarily stops for
maximum of 15 minutes to perform the Automatic Defrosting
operation while the Operation indicator lamp is blinking.
●
The fan may operate at very low speed during the Dry
mode operation or when the unit is monitoring the room’s
temperature.
●
During the Super Quiet operation, the fan will operate at very
low speed.
●
When the Monitor operation is performed in the Auto mode,
the fan rotates at very low speed.
●
During the Heating mode operation, water may be produced
*
from the outdoor unit due to the Automatic Defrosting
operation.
●
Clean the air filter. Afterwards, turn the Economy indicator
lamp off .
See page
—
—
15
—
—
15
—
15
—
—
—
15
13
En-14
TROUBLESHOOTING
Symptom Problem
Check once
more
If the problem persists after performing these checks, or if you notice burning smells, or the Operation indicator lamp and the Timer
indicator lamp blink, and Economy indicator lamp blinks fast. Immediately stop operation, turn off the electrical breaker and consult
authorized service personnel.
Does not operate at all:
Poor cooling (or heating*)
performance:
The unit operates
diff erently from the remote
controller setting:
●
Has the circuit breaker been turned off ?
●
Has there been a power failure?
●
Has a fuse blown out, or a circuit breaker been tripped?
●
Is the timer operating? 8 to 9
●
Is the air fi lter dirty?
●
Are the air conditioner’s intake grille or outlet port blocked?
●
Did you adjust the room temperature settings correctly?
●
Is there a window or door open?
●
In the case of the Cooling mode operation, is a window
allowing bright sunlight to enter? (Close the curtains.)
●
In the case of the Cooling mode operation, are there heating
apparatus and computers inside the room, or are there too
many people in the room?
●
Is the unit set for the Super Quiet operation? —
●
Are the remote controller’s batteries exhausted?
●
Are the remote controller’s batteries loaded properly? 5
See page
—
—
OPERATING TIPS
Instructions relating to heating (*) are applicable only to Heating and Cooling model (Reverse Cycle).
Heating performance*
● This air conditioner operates on the heat-pump principle,
absorbing heat from air outdoors and transferring that heat
to the indoor unit. As a result, the operating performance is
reduced as outdoor air temperature drops. If you feel that the
heating performance is insuffi cient, we recommend you to use
this air conditioner in conjunction with other kinds of heating
appliance.
● Heat-pump air conditioners heat your entire room by
recirculating air throughout the room, with the result that some
time may be required after fi rst starting the air conditioner until
the room is heated.
When indoor and outdoor temperatures are high
When both indoor and outdoor temperatures are high during use
of the Heating mode, the outdoor unit’s fan may stop at times.
*
Automatic Defrosting operation*
● When using the Heating mode under conditions of low outdoor
temperature and high humidity, frost may form on the outdoor
unit, resulting in reduced operating performance.
In order to prevent this kind of reduced performance, this
unit is equipped with a microcomputer-controlled Automatic
Defrosting operation. If frost forms, the air conditioner will
temporarily stop, and the defrosting circuit will operate briefl y
(for about 4 to 15 minutes).
During the Automatic Defrosting operation, the Operation
indicator lamp (green) will blink.
● After the Heating mode operation stops, if frost forms on
the outdoor unit, the unit will start the Automatic Defrosting
operation. At this time, the outdoor unit will automatically stop
after operating for a few minutes.
Low ambient cooling*
When the outdoor temperature drops, the outdoor unit’s fans
may switch to low speed.
En-15
Hot start (for Heating mode)*
The indoor unit prevents cold drafts when the Heating mode
operation begins.
The indoor unit fan will not operate or it will operate at a very low
speed until the heat exchanger reaches the set temperature.
OPERATING TIPS
The wired remote controller option is required to use the following function (**).
**Dual remote controllers (optional)
An additional remote controller can be added up to the maximum of 2 remote controllers. Either remote controller can control the air
conditioner. However, the timer functions cannot be used at the secondary unit.
**Group control
1 remote controller can control up to 16 air conditioners. All of the air conditioners will be operated with the same settings.
Instructions relating to heating (*) are applicable only to Heating and Cooling model (Reverse Cycle).
Auto restart
In event of power interruption
●
Should the power supply to the air conditioner be
interrupted by a power failure, the air conditioner will restart
automatically in the previously selected mode once the
power is restored.
●
Should a power failure occur during the Timer operation,
the timer will be reset and the unit will begin (or stop)
operating under the new timer setting. In this event, the
Timer indicator lamp (orange) will blink.
●
Use of other electrical appliances (electric shaver, etc.) or
nearby use of a wireless radio transmitter may cause the
air conditioner to malfunction. In this event, temporarily
disconnect the power supply plug, reconnect it, and then
use the remote controller to resume operation.
Simultaneous multi air conditioner
This indoor unit can also be connected to a simultaneous multi connection that enables simultaneous operation of multiple indoor
units by connecting the outdoor unit using a separation tube.
NOTES:
The number of connectable indoor units and connectable type of the separation tube vary by model.
In simultaneous multi connection, all indoor units can be operated simultaneously, from one remote controller connected to the
primary indoor unit.
For this unique characteristic of the simultaneous multi connection, the functions of other indoor units may be restricted.
Notices
●
*
During use of the Heating mode, the outdoor unit will
occasionally commence the Automatic Defrosting
operation for brief periods. During the Automatic Defrosting
operation, if the user sets the indoor unit for the Heating
mode again, the Automatic Defrosting operation will
continue, and the Heating mode operation will begin after
completion of defrosting, with the result that some time
may be required before warm air is emitted.
*● During use of the Heating mode, the top of the indoor
unit may become warm, but this is due to the fact that
coolant is circulated through the indoor unit even when it is
stopped; it is not a malfunction.
En-16
Loading...
