BIOS Guide

LifeBook A Series Model:

A3110

Document Date: 09/27/2006

Document Part Number: FPC58-1569-01

FUJITSU COMPUTER SYSTEMS CORPORATION

LifeBook A Series BIOS

A Series BIOS

BIOS SETUP UTILITY

The BIOS Setup Utility is a program that sets up the operating environment for your notebook. Your BIOS is set at the factory for normal operating conditions, therefore there is no need to set or change the BIOS environment to operate your notebook.

The BIOS Setup Utility configures:

■

Device control feature parameters, such as changing I/O addresses and boot devices.

■

System Data Security feature parameters, such as passwords.

Entering the BIOS Setup Utility

To enter the BIOS Setup Utility, do the following:

1. Turn on or restart your notebook.

2. Press [F2] once the Fujitsu logo appears on the screen. This will open the main menu of the BIOS Setup Utility with the current settings displayed.

3. Press the [RIGHT ARROW] or [LEFT ARROW] key to scroll through the other setup menus to review or alter the current settings.

The Boot Menu can also be invoked by pressing the [F12] key when the Fujitsu logo appears on the screen.

Navigating through the Setup Utility

The BIOS setup utility consists of six menus: Main, Advanced, Security, Boot, Info, and Exit. This document explains each menu in turn, including all submenus and setup items.

The following procedures allow you to navigate the setup utility menus:

1. To select a menu, use the cursor keys:

2. To select a field within a menu or a submenu, use the

cursor keys:

[ ], [ ].

3. To select the different values for each field, press the [Spacebar] or [+] to change to the next lower selection and [F5] or [-] to go to the next higher selection.

4. To activate a submenu press the [Enter] key.

5. To return to a menu from a submenu, press [Esc].

[ ], [ ]

6. To go to the Exit menu from any other menu, press the [Esc] key.

■

Selecting a field causes a help message about that field to be displayed on the right-hand side of the screen.

■

Pressing the Enter key with the highlight on a selection that is not a submenu or auto selection will cause a list of all options for that item to be displayed. Pressing the Enter key again will select the highlighted choice.

7. Pressing the [F9] key resets all items in the BIOS to the default values.

8. Pressing the [F10] key saves the current configuration and exits the BIOS Setup Utility. You will be asked to verify this selection before it is executed.

9. Pressing the [F1] key gives you a general help screen.

Entering the Setup Utility After a Configuration Change or System Failure

If there has been a change in the system configuration that does not agree with the parameter settings stored in your BIOS memory, or there is a failure in the system, the system beeps and/or displays an error message after the Power On Self Test (POST). If the failure is not too severe, it will give you an opportunity to modify the setup utility settings, as described in the following steps:

1. When you turn on or restart the computer there is a beep or the following message appears on the screen:

Error message - please run SETUP program Press <F1> key to continue, <F2> to run SETUP

2. If an error message is displayed on the screen, and you want to continue with the boot process and start

the operating system anyway, press the [F1] key.

■

If your notebook emits a series of beeps that sounds like a code and the display is blank, please refer to the Troubleshooting Section in the system User’s Guide. The Troubleshooting Section includes a list of error messages and their meanings.

■

If your data security settings require it, you may be asked for a password before the operating system will be opened.

3. If an error message is displayed on the screen, and you want to enter the setup utility, press the [F2] key.

4. When the setup utility starts with a fault present, the system displays the following message:

Warning!

Error message

[Continue]

5. Press any key to enter the setup utility. The system will then display the Main Menu with current parameters values.

Main Menu

LifeBook A Series BIOS

MAIN MENU – SETTING STANDARD SYSTEM PARAMETERS

The Main Menu allows you to set or view the current system parameters. (See Navigating through the Setup

Utility on page 2 for more information.)

The following tables show the names of the menu fields for the Main menu and its submenus, all of the options for each field, the default settings and a description of

BIOS Setup Utility

Main Advanced Security Boot Info Exit

System Time: [14:57:01]

System Date: [09/15/2006]

▲▲

Drive0 [FUJITSU MHV2120A] Drive1 [_NEC DVD_RW NC_7]

Language: [English (US)]

the field’s function and any special information needed to help understand the field’s use.

System Time and System Date can also be set from your operating system without using the setup utility. Use the Date and Time icon on your Windows Control panel or type time or date from the MS-DOS prompt.

Adjust calendar clock.

<Tab>, <Shift-Tab>, or <Enter> selects field.

F1: Help Esc: Exit

Figure 1. Main Menu

Table 1: Fields, Options and Defaults for the Main Menu

Note that the parameters listed in the following table may vary depending upon your system’s configuration.

Menu Field Options Default Description

System Time: –— –— Sets and displays the current time. Time is in a 24 hour for-

mat of hours:minutes:seconds with 2 digits for each. (HH:MM:SS). Example: 16:45:57. You may change each segment of the time separately. Move between the segments with the [Tab] key and/or [Shift] + [Tab] keys.

Main Menu

Table 1: Fields, Options and Defaults for the Main Menu

Note that the parameters listed in the following table may vary depending upon your system’s configuration.

Menu Field Options Default Description

System Date: –— –— Sets and displays the current date. Date is in a month/day/

year numeric format with 2 digits each for month and day and 4 digits for year. (MM/DD/YYYY) for example: 03/20/

2006. You may change each segment of the date separately. Move between the segments with the [Tab] key and/ or [Shift] + [Tab] keys.

Drive0 Selects the

Drive0 Serial ATA drive submenu

The product number of the hard drive.

Display the type of device on this ATA/IDE interface. Pressing the Enter key selects the Serial ATA Drive0 submenu which displays the default values and settings for this interface.

Drive1: Selects the

Drive1 Serial ATA drive submenu

The product number of the CD-ROM drive.

Display the type of device on this ATA/IDE interface, if there is one. Pressing the Enter key selects the Serial ATA Drive1 submenu which displays the default values and settings for this interface.

Language:

■

English (US)

■

Japanese (JP)

[English (US)] The default setting differs between the US/European and

the Japanese model. Selects the display language for the BIOS.

LifeBook A Series BIOS

Drive0 Submenu of the Main Menu

The Drive0 submenu identifies what ATA devices are installed and the default values and settings of the devices.

BIOS Setup Utility

Main Advanced Security Boot Info Exit

Drive0:

Device :Hard Disk Vendor :FUJITSU MHV2120AT PL Maximum Capacity :120.0GB LBA Mode :Supported Block Mode :16Sectors PIO Mode :4 Async DMA :MultiWord DMA-2 Ultra DMA :Ultra DMA-5 S.M.A.R.T. :Supported

Type [Auto]

Figure 2. Drive0 Master Submenu

Select Serial ATA/IDE drive installed here.

[Auto] The BIOS auto-types the drive on boot time.

[None] The drive is disabled.

F1: Help Esc: Exit

Table 2: Fields, Options and Defaults for the Drive0 Submenu of the Main Menu

Note that the information displayed on this screen may differ from that which appears on your screen, depending upon your system configuration.

Menu Field Options Default Description

The fields that appear on this screen are for display only, and reflect the default settings for the Drive0 device.

Device --- Hard Disk Displays the type of Drive0 ATA/IDE drive.

Vendor --- (Device Name) Displays the maker of the Drive0 device.

Maximum Capacity:

LBA Mode --- Supported Displays whether Logical Block Addressing is supported by the

Block Mode --- 16 Sectors Displays the number of sectors per block.

PIO Mode --- 4 Displays the method for moving data to/from the Drive0 device.

Async DMA --- Multiword

--- (HDD Size) The maximum capacity of your hard disk

device.

Displays the Multiword DMA method for moving data to/from the

DMA-2

Drive0 device.

Main Menu

Table 2: Fields, Options and Defaults for the Drive0 Submenu of the Main Menu

Note that the information displayed on this screen may differ from that which appears on your screen, depending upon your system configuration.

Menu Field Options Default Description

Ultra DMA --- Ultra DMA-5 Displays the Ultra DMA method for moving data to/from the Drive0

device.

S.M.A.R.T. --- Supported Displays whether Self-Monitoring Analysis Reporting Technology is

supported. (MSART is a hard drive feature; warns of problems before total failure).

Typ e:

■

Auto None

[Auto] Selects the hard drive device type. Select Auto to have the type

automatically identified by the BIOS at POST. If None is selected, all of the Setup items above do not appear.

LifeBook A Series BIOS

Drive1 Submenu of the Main Menu

The Drive1 submenu allows you to configure secondary ATA devices.

BIOS Setup Utility

Main Advanced Security Boot Info Exit

Drive1:

Select Serial ATA/IDE

drive installed here. Device :ATAPI CDROM Vendor :_NEC DVD_RW ND-7550A LBA Mode :Supported PIO Mode :4

[Auto]

The BIOS auto-types the

drive on boot time. Async DMA :MultiWord DMA-2 Ultra DMA :Ultra DMA-2

[None]

The drive is disabled.

Type [Auto]

F1: Help Esc: Exit

Figure 3. Drive1 Submenu

Table 3: Fields, Options and Defaults for the Drive1 Submenu of the Main Menu

Menu Field Options Default Description

The fields that appear on this screen are for display only, and reflect the default settings for the Drive1 device.

Device --- Hard Disk Displays the type of Drive1 ATA/IDE drive.

Vendor --- (Device Name) Displays the maker of the Drive1 device.

LBA Mode --- Supported Displays whether Logical Block Addressing is supported by the

PIO Mode --- 4 Displays the method for moving data to/from the Drive1

Async DMA --- Multiword DMA-2 Displays the Multiword DMA method for moving data to/from

Ultra DMA --- Ultra DMA-5 Displays the Ultra DMA method for moving data to/from the

device.

the Drive1 device.

Drive1 device.

Advanced Menu

Table 3: Fields, Options and Defaults for the Drive1 Submenu of the Main Menu

Menu Field Options Default Description

Typ e:

■

Auto None

[Auto] Selects the hard drive device type. Select Auto to have the type

automatically identified by the BIOS at POST. If None is selected, all of the Setup items above do not appear.

Exiting from Main Menu

When you have finished setting the parameters on this menu, you can either exit from the setup utility, or move to another menu. If you wish to exit from the setup utility, press the [Esc] key or use the cursor keys to go to the Exit menu. If you wish to move to another menu, use the cursor keys.

LifeBook A Series BIOS

ADVANCED MENU – SETTING DEVICE FEATURE CONTROLS

The Advanced Menu allows you to:

■

Set the keyboard and mouse features.

■

Select between the display panel and an external CRT or flat panel display.

■

Enable or disable compensation for your display.

■

Enable or disable the IDE, Bluetooth, and LAN controllers.

BIOS Setup Utility

Main Advanced Security Boot Info Exit

■

Configure CPU and USB features in your system.

The following tables show the names of the menu fields for the Advanced Menu and its submenus, all of the options for each field, the default settings and a description of the field’s function and any special information needed to help understand the field’s use.

▲ ▲ ▲ ▲ ▲

Keyboard/Mouse Features Video Features

Configures keyboard/ mouse features.

Internal Device Configurations CPU Features USB Features

▲ ▲

Miscellaneous Configurations

Event Logging

F1: Help Esc: Exit

Figure 4. Advanced Menu

Table 4: Fields, Options and Defaults for the Advanced Menu

Menu Field Description

Keyboard/ Mouse Features

Video Features Opens the Video Features submenu, which allows setting of the display parameters, including routing

Opens the Keyboard/Mouse Features submenu, which allows setting external and internal keyboard and mouse parameters.

of video signals to different displays.

Internal Device Configurations

Opens the Internal Device Configuration submenu, which allows enabling or disabling the IDE, Bluetooth, and LAN Controllers.

CPU Features Opens the CPU Features submenu to allow you to enable or disable AMD Virtualization™.

USB Features Opens the USB Features submenu to allow you to enable or disable legacy USB devices and SCSI Sub-

Class support.

Table 4: Fields, Options and Defaults for the Advanced Menu

Menu Field Description

Advanced Menu

Miscellaneous Configurations

Opens the Miscellaneous Configurations submenu to allow you to enable or disable the power button, Wake Up On LAN, control volume settings, and adjust UMA video memory size.

Event Logging Opens the event logging submenu.

LifeBook A Series BIOS

Keyboard/Mouse Features Submenu of the Advanced Menu

The Keyboard/Mouse Features submenu is for setting the parameters of the integrated and external mouse and keyboard.

BIOS Setup Utility

Main Advanced Security Boot Info Exit

Keyboard/Mouse Features

[On] or [Off] Numlock is On or Off.

Numlock: [Off]

[On/Padlock Off] Numlock is On, but use with [Fn] for 10-key input.

* Windows XP preserves Numlock state when the user logs off.

F1: Help Esc: Exit

Figure 5. Keyboard/Mouse Features Submenu

Table 5: Fields, Options and Defaults for the Keyboard/Mouse Submenu of the Advanced Menu

Menu Field Options Default Description

Numlock:

■

Off

■

On/Padlock Off

[Off] Sets the NumLock function state when the computer com-

pletes booting. When [On] or [Off], Numlock is on or off. When [On/Padlock Off] is selected, Numlock is on, but [Fn] key must be pressed used for 10-key input. Windows XP preserves Numlock state when the user logs off.

Video Features Submenu of the Advanced Menu

The Video Features submenu is for setting the display parameters.

BIOS Setup Utility

Main Advanced Security Boot Info Exit

Advanced Menu

Video Features

Display: [Auto] Compensation: [Enabled]

Select display terminal.

* This setting is not effective after operating system starts up.

F1: Help Esc: Exit

Figure 6. Video Features Submenu

Table 6: Fields, Options and Defaults for the Video Features Submenu of the Advanced Menu

Menu Field Options Default Description

Display:

Compensation:

■

LCD Panel

■

External

■

Auto

■

Disabled

■

Enabled

[Auto] Selects where the video signal will be routed. Note that this setting is

overridden after Windows starts up.

[Enabled] Enables or disables compensation which controls spacing on the dis-

play. When enabled, displays with less than pixel resolutions of 1024 x 768 or 800 x 600 will still cover the entire screen. A resolution below 800 x 600 will fill the screen, but due to the low resolution, will appear blocky and may not be acceptable. Note that this setting is overridden after Windows starts up.

LifeBook A Series BIOS

Internal Device Configurations Submenu of the Advanced Menu

The Internal Device Configuration submenu allows the user to enable or disable IDE, Bluetooth, and LAN Controllers.

BIOS Setup Utility

Main Advanced Security Boot Info Exit

Internal Device Configurations

[Disabled] No IDE ports are

IDE Controller: [Both]]

enabled. Bluetooth(R): [Enabled] LAN Controller: [Enabled]

[Primary]

Only primary IDE port

is enabled.

[Secondary]

Only secondary IDE port

is enabled.

[Both]

Both primasry and

secondary IDE ports

are enabled.

F1: Help Esc: Exit

Figure 7. Internal Device Configuration Submenu

Table 7: Fields, Options and Defaults for the Internal Device Configuration Submenu of the Advanced Menu

Menu Field Options Default Description

IDE Controller

Bluetooth(R)

LAN Controller:

■

Disabled

■

Primary

■

Secondary

■

Both

■

Disabled

■

Enabled

■

Disabled

■

Enabled

[Both] When Disabled, none of the IDE ports are enabled. When Primary

is selected, only the primary IDE port is enabled. When Secondary is selected, only the secondary IDE port is enabled. When Both is selected, both the primary and secondary IDE ports are enabled.

[Enabled] Enables or disables the Bluetooth device.

[Enabled] Enables or disables the LAN controller.

Advanced Menu

CPU Features Submenu of the Advanced Menu

The CPU Features submenu provides options for configuring the AMD Virtualization™ features of the CPU.

BIOS Setup Utility

Main Advanced Security Boot Info Exit

CPU Features

Select AMD Virstualization(TM)

AMD Virtualization(TM) [Disabled]

enabled or disabled.

F1: Help Esc: Exit

Figure 8. CPU Features Submenu

Table 8: Fields, Options and Defaults for the CPU Features Submenu of the Advanced Menu

Menu Field Options Default Description

AMD Virtualization(TM)

■

Disabled

■

Enabled

[Disabled] Enables or disables the AMD Virtualization(TM) feature.

AMD Virtualization(TM) allows multiple operating systems and applications to be run simultaneously. The result is smoother multi-tasking and a more efficient use of system resources.

LifeBook A Series BIOS

USB Features Submenu of the Advanced Menu

The USB Features submenu provides options for enabling or disabling the USB Floppy Disk Drive.

BIOS Setup Utility

Main Advanced Security Boot Info Exit

USB Features

Legacy USB Support

[Enabled]

SCSI SubClass Support: [Enabled]

[Disabled] The feature is disabled.

[Enabled] Legacy USB Emulation is enabled and USB devices are available without USB aware OS.

F1: Help Esc: Exit

Figure 9. USB Features Submenu

Table 9: Fields, Options and Defaults for the USB Features Submenu of the Advanced Menu

Menu Field Options Default Description

Legacy USB Support:

SCSI SubClass Support:

■

Disabled

■

Enabled

■

Disabled

■

Enabled

[Enabled] When Enabled is selected, Legacy USB Emulation is enabled

and the USB devices are available without a USB-aware OS. When Disabled is selected, Legacy USB support is disabled.

[Disabled] When Enabled is selected, USB devices that belong to the

SCSI subclass in the mass storage class (e.g., USB Memory Key) are enabled. Note that enabling this feature may cause the system to hang during POST, depending on the device that is connected.

Security Menu

Miscellaneous Configurations Submenu of the Advanced Menu

The Miscellaneous Configurations submenu provides options for enabling or disabling the power button and the Wake Up On LAN feature, and setting the volume and video memory size.

BIOS Setup Utility

Main Advanced Security Boot Info Exit

Miscellaneous Configurations

Power Button: Wake up on LAN: Force LAN Boot: Volume Setting: UMA Video Memory Size:

[Disabled]

[Disabled] [Disabled] [Middle] [64MB]

Configures the power button.

*ACPI OS ignores this setting.

F1: Help Esc: Exit

Figure 10. Miscellaneous Configurations Submenu

Table 10: Fields, Options and Defaults for the Miscellaneous Configurations Submenu of Advanced Menu

Menu Field Options Default Description

Power Button:

Wake up on LAN:

Force LAN Boot:

■

Disabled

■

Power Off

■

Disabled

■

Enabled

■

Disabled

■

Enabled

[Disabled] Selecting Disabled disables the power button. Selecting

Power Off allows you to turn off system power with the power button.

[Disabled] Selecting Enabled allows the system to wake up when the

internal LAN device receives a specific signal while in poweroff state. Selecting Disabled disables this feature.

[Disabled] This feature is active only when “Wake up on LAN” is

enabled. When enabled, in the event of a system wake-up on LAN, the system will try to first boot from the LAN before attempting to boot from any other device, regardless of the BIOS boot priority settings or disabling of the Preboot Execution Environment.

LifeBook A Series BIOS

Table 10: Fields, Options and Defaults for the Miscellaneous Configurations Submenu of Advanced Menu

Menu Field Options Default Description

Vol ume S ettin g:

UMA Video Memory Size:

■

Off

■

Minimum

■

Middle

■

Maximum

■

32MB

■

64MB

■

128MB

■

224MB

[Middle] Selects the initial volume setting for the system.

[64MB] Allows you to select the maximum shared video memory

size. Video memory is dynamically allocated as needed for running applications by Dynamic Video Memory Technology (DVMT).

Event Logging Submenu of the Advanced Menu

The Event Logging submenu configures event logging features for DMI events.

BIOS Setup Utility

Main Advanced Security Boot Info Exit

Event Logging

Event Log Capacity: Space Available Event Log Validity: Valid

View Event Log: [Enter]

Event Logging: [Enabled] System Boot Event: [Disabled]

Clear All Event Logs: [Enter]

Mark Events as Read: [Enter]

Security Menu

Press <Enter> key to view the contents of the event log.

F1: Help Esc: Exit

Figure 11. Event Logging Submenu

Table 11: Fields, Options and Defaults for the Event Logging Submenu of the Advanced Menu

Menu Field Options Default Description

Event Log Capacity: Space Avail-

able

Event Log Validity: Valid Display only

View Event Log:

Event Logging:

System Boot Event:

Clear All Event

■

Enter [Enter] Allows you to view content of event log

■

Disabled

■

Enabled

■

Disabled

■

Enabled

■

Enter [Enter] Allows you to clear the Event Log.

[Enabled] Turns event logging on and off for all DMI events.

[Disabled] Turns event logging on and off for DMI system boot events.

Logs:

■

Mark Events as

Enter [Enter] Lets you mark all events currently in the event log as having

Read:

Display only

been read.

LifeBook A Series BIOS

SECURITY MENU – SETTING THE SECURITY FEATURES

The Security menu allows you to set up the data security features of your notebook to fit your operating needs and to view the current data security configuration. (See

Navigating through the Setup Utility on page 2 for more information.)

The following tables show the names of the menu fields for the Security Menu and its submenus, all the options for each field, the default settings and a description of the field's function and any special information needed to help understand the field's use. The default condition is no passwords required and no write protection.

Remember your passwords! If you set and forget your User and Master hard disk passwords, Fujitsu Computer Systems Corporation will not be able to reset it. You may lose data and have to replace your system board or hard disk drive. For more information, call Fujitsu Service and Support at 1-800-8FUJITSU.

BIOS Setup Utility

Main Advanced Security Boot Info Exit

Supervisor Password Is: Clear User Password Is : Clear

Set Supervisor Password [Enter] Set User Password [Enter] Minimum User Password Length: [0] Password on Boot: [Disabled] On Automatic Wake up: [Disabled] KB Lock on Resume: [Disabled] Boot from Removable Media: [All] Flash Write: [Enabled]

▲ ▲

Hard Disk Security Owner Information

■

Entering a password incorrectly 3 times in a row causes the keyboard and mouse to be locked out and the warning [System Disabled] to be displayed. If this happens, restart the computer by turning off and on the power with the power switch and use the correct password on reboot.

■

If you make an error when re-entering the password a Warning will display on the screen. To try again press [Enter], then retype the password. Press [Esc] to abort the password setting process.

■

Boot sector protection must be set to [Normal] to install or upgrade an

operating system.

Press <Enter> key to set Supervisor Password to enable any password features.

Then password entry is required to enter BIOS Setup.

F1: Help Esc: Exit

Figure 12. Security Menu

Table 12: Fields, Options and Defaults for the Security Menu

Menu Field Options Default Description

Boot Menu

Supervisor Password is:

–— Clear A display-only field. Set is displayed when the system

supervisor password is set and Clear when it is not.

User Password is: –— Clear A display-only field. Set is displayed when the general user

password is set, and Clear when it is not.

Set Supervisor Password

–— [Enter] Sets, changes or cancels the Supervisor Password. The

Supervisor Password may be up to seven characters long and must include only letters or numbers (no symbols). Passwords are NOT case-sensitive. To cancel a password press the Enter key instead of entering characters in the Enter New Password field and in the Re-enter New Password field. When a Supervisor Password is set it must be used to access the BIOS setup utility.

Set User Password –— [Enter] This field can only be accessed if the Supervisor Password is

set. Sets, changes or cancels the User Password. A User Password may be up to seven characters long and must include only letters or numbers (no symbols). Passwords are NOT case-sensitive. To cancel a password press [Enter] key instead of entering characters in the Enter New Password field and in the Re-enter New Password field. When a User Password is set it must be used to access the BIOS setup utility.

Minimum User Password Length:

–— [0] Supervisor can set password length (0 to 8) for user pass-

word. User cannot set a password shorter than the minimum length.

Password on Boot:

■

Disabled

■

First Boot

■

Every Boot

[Disabled] When set to First Boot, a password (User or Supervisor) is

required just once after the Power On Self Test (POST) before the operating system will be read from a disk. When set to Every Boot, a password (User or Supervisor) is required every time after the Power On Self Test (POST) before the operating system will be read from a disk. When set to Disabled no password is required.

On Automatic Wake up:

■

Disabled

■

Enabled

[Disabled] When disabled, password entry is not required when the

system wakes up automatically. When enabled, password entry is required upon wake up.

KB Lock on Resume:

■

Disabled

■

Enabled

[Disabled] When set to Enabled, the PS/2 mouse and keyboard inputs

are locked out upon Resume from Standby and Hibernate mode until you enter the password. When set to Disabled no password is required. If no Supervisor Password is set, this feature is not available and no password is required.

Boot from Removable Media:

■

All

■

Supervisor only

[All] Supervisor only allows access to boot the computer to

removable media after the Supervisor Password is entered.

LifeBook A Series BIOS

Table 12: Fields, Options and Defaults for the Security Menu

Menu Field Options Default Description

Flash Write:

■

Disabled

■

Enabled

[Enabled] When disabled, the BIOS Flash memory will be write pro-

tected.

Hard Disk Security: –— –— Configures hard disk security features

Owner Information: –— –— Sets Owner information.

Exiting from the Security Menu

When you have finished setting the parameters on the Security Menu, you can either exit from setup utility or move to another menu. If you wish to exit from setup utility, press the [Esc] key to go to the Exit Menu. If you wish to move to another menu, use the cursor keys.

Hard Disk Security Submenu of the Security Menu

The Hard Disk Security submenu is for configuring hard disk security features.

BIOS Setup Utility

Main Advanced Security Boot Info Exit

Hard Disk Security

Drive0 Password Is: Clear

Set Drive0 Password [Enter]

Password Entry on Boot: [Enabled]

Info Menu

F1: Help Esc: Exit

Figure 13. Hard Disk Security Submenu

Table 13: Fields, Options and Defaults for the Hard Disk Security Submenu of the Security Menu

Menu Field Options Default Description

Drive0 Password Is: ___ Clear Display-only. Default is Clear. When the Drive0 Password has

Set Drive0 Password

Password Entry on Boot:

___ [Enter] Sets, changes or cancels the Drive0 Master Password. The Drive0

■

Disabled

■

Enabled

[Enabled] When set to disabled, entry of a Hard Disk Password is not

been set, the field changes to Set. When this password is set, the primary hard disk drive cannot be used in another system unless the password is entered.

Master Password may be up to seven characters long and must include only letters or numbers (no symbols). Passwords are NOT case-sensitive. When a Drive0 Master Password is set, it must be used to access the hard drive if it is used in another system. Note that the password will not take effect until the system has been rebooted.

required before OS boot. (The hard disk is still password-protected without password entry.)

LifeBook A Series BIOS

Owner Information Submenu of the Security Menu

The Owner Information submenu is for setting owner information. Note that the owner information cannot be set without having entered a Supervisor Password.

BIOS Setup Utility

Main Advanced Security Boot Info Exit

Owner Information

Owner Information Is: Clear

Set Owner Information [Enter]

Foreground Color: [Gray] Background Color: [Black]

F1: Help Esc: Exit

Figure 14. Owner Information Submenu

Table 14: Fields, Options and Defaults for the Owner Information Submenu of the Security Menu

Menu Field Options Default Description

Owner Information Is: –— Clear Display only.

Set Owner Information:

–— [Enter] Field to write owner

information, (i.e., name).

Foreground Color:

Background Color:

■

Black

■

Blue

■

Green

■

Cyan

■

Red

■

Magenta

■

Black

■

Blue

■

Green

■

Cyan

■

Red

■

Magenta

■

Brown

■

White

■

Gray

■

Light Blue

■

Light Green

■

Brown

■

White

■

Gray

■

Light Blue

■

Light Green

■

Light Cyan

■

Light Red

■

Light Magenta

■

Yellow

■

Bright White

■

Light Cyan

■

Light Red

■

Light Magenta

■

Yellow

■

Bright White

[Gray] Set foreground color.

[Black] Set background color.

BOOT MENU – SELECTING THE OPERATING SYSTEM SOURCE

The Boot Menu is used to select the order in which the BIOS searches sources for the operating system. Follow the instructions for Navigating Through the Setup Utility to make any changes. (See Navigating through the

Setup Utility on page 2 for more information.)

BIOS Setup Utility

Main Advanced Security Boot Info Exit

Quick Boot: Boot Time Diagnostic Screen: [Disabled] Boot Menu: [Enabled] Preboot Execution Environment: [Disabled]

▲

Boot Device Priority

▲

Hard Disk Drives Priority

▲

CD/DVD Drives Priority

The following tables show the names of the menu fields for the Boot menu and its submenu, all of the options for each field, the default settings and a description of the field's function and any special information needed to help understand the field's use.

[Enabled]

[Disabled] All diagnostic tests will be done.

[Enabled] Some diagnostic tests may be skipped while booting to speed up.

F1: Help Esc: Exit

Figure 15. Boot Menu

Table 15: Fields, Options and Defaults for the Boot Menu

Menu Field Options Default Description

Quick Boot:

Boot-time Diagnostic

■

Disabled

■

Enabled

■

Disabled

■

Enabled

[Enabled] Turns on and off booting with a truncated set of Power On Self Test.

(Fewer tests mean faster startup.)

[Disabled] Turns on and off display of test results instead of Fujitsu logo screen

during Power On Self Test.

Screen:

■

Boot Menu:

Disabled

■

Enabled

[Enabled] When Disabled, the Boot Menu is disabled and the [F12] key is

ignored. When Enabled, the Boot Menu is enabled. This option is active only when a supervisor password is set.

Preboot Execution

■

Disabled

■

Enabled

[Disabled] Turns on and off the preboot execution environment feature.

Environment:

LifeBook A Series BIOS

Table 15: Fields, Options and Defaults for the Boot Menu

Menu Field Options Default Description

Boot Device Priority

Hard Disk Drives Priority

CD/DVD Drives Priority

— — This menu allows setting up the source for the operating system.

See “The Boot Device Priority Submenu” in the following section.

__ __ This menu allows selecting the priority with which the hard disk drives

will be selected for Boot. See “The Boot Device Priority Submenu” below.

__ __ This menu allows selecting the priority with which the CD/DVD drives

will be selected for Boot. See “The Boot Device Priority Submenu” below.

Boot Device Priority Submenu of the Boot Menu

The Boot Device Priority submenu is for setting the order of checking of sources for the operating system.

■

Be aware of the operating environment when booting from a CD or you may overwrite files by mistake.

■

A bootable CD-ROM has either a floppy disk format or a hard drive format. When a bootable CD-ROM is used, drive allocations change automatically without changing the BIOS setup. If a floppy disk format is used, the CD-ROM becomes Drive A. The CD-ROM will only take drive C: (hard drive format) if internal hard drive is not present or is disabled. A bootable CD-ROM can never use a C: designation if a formatted internal hard drive is present since the C: designator is always reserved for the internal hard drive.The boot sequence ignores the new drive designations, but your application software will use the new designations.

BIOS Setup Utility

Main Advanced Security Boot Info Exit

1st Boot Device

[! Removable Drvs]

2nd Boot Device [Hard Disk Drives] 3rd Boot Device [CD/DVD Drives] 4th Boot Device [Network Boot]

Specifies the boot sequence from the available devices.

A device with an exclamation mark (!) has been disabled in the corresponding type menu.

F1: Help Esc: Exit

Figure 16. Boot Device Priority Submenu

Table 16: Fields, Options and Defaults for the Boot Device Priority Submenu of the Boot Menu

Menu Field Options Default Description

Boot Device Priority: 1st Boot Device 2nd Boot Device 3rd Boot Device 4th Boot Device

Hard Disk Drives Priority

Boot selections determine the order the BIOS searches for the operating system during a startup sequence. To change the order, highlight one source by using the [up] or [down] cursor keys and then press the [+] or [-] key to change the order number. Be sure to save your changed order when you exit the BIOS setup utility. NOTE: Be aware that if you use the CD-ROM drive as the first boot device, certain files may be overwritten, depending upon your operating environment.

■

(Installed HDD)

■

Disabled

[Installed HDD] Select the boot sequence or disable the hard disk

drive(s) from the boot sequence.

LifeBook A Series BIOS

Table 16: Fields, Options and Defaults for the Boot Device Priority Submenu of the Boot Menu

Menu Field Options Default Description

CD/DVD Drives Priority

■

(Installed CD/DVD Drive)

■

Disabled

[Installed CD/ DVD Drive]

Select the boot sequence or disable the CD/DVD drive(s) from the boot sequence.

Exiting from Boot Menu

When you have finished setting the boot parameters with the Boot Menu, you can either exit from the setup utility or move to another menu. If you wish to exit from the setup utility press the [Esc] key to go to the Exit Menu. If you wish to move to another menu, use the cursor keys.

INFO MENU - DISPLAYS BASIC SYSTEM INFORMATION

The Info Menu is a display only screen that provides the configuration information for your notebook.

The following table shows the names of the menu fields for the Info menu and the information displayed in

BIOS Setup Utility

Main Advanced Security Boot Info Exit

BIOS Version : 1.07 BIOS Date : 08/31/2006 BIOS Area : E000h - FFFh

CPU Type : AMD Turion(tm) 64 X2 Mobile Technology TL-52 L1 Cache : 128KB L2 Cache : 1024KB

Total Memory : 1024MB Memory Slot 1 : 1024MB DDR2 SDRAM Memory Slot 2 : None

those fields. These fields are for information purposes only, and cannot be modified by the user.

The information, including CPU type and

speed, and total memory, displayed on this

screen varies according to the unit you

purchased.

Figure 17. Info Menu

Table 17: Fields, Options and Defaults for the Info Menu

Note that the parameters listed in the following table may be different, depending upon the system configuration.

Menu Field Default Menu Field Default

BIOS Version: 1.07 L2 Cache: 1024KB

BIOS Date: 08/31/2006 Total Memory: 1024MB

BIOS Area: E000h – FFFFh Memory Slot 1: 1024MB DDR2 SDRAM

CPU Type: AMD Turion™ 64 X2

Mobile Technology TL-52

L1 Cache: 128KB

Memory Slot 2: None

LifeBook A Series BIOS

EXIT MENU – LEAVING THE SETUP UTILITY

The Exit Menu is used to leave the setup utility. Follow the instructions for Navigating Through the Setup Utility to make any changes. (See Navigating through the

Setup Utility on page 2 for more information.)

BIOS Setup Utility

Main Advanced Security Boot Info Exit

Exit Saving Changes Exit Discarding Changes Load Setup Defaults Discard Changes Save Changes Save Changes and Power Off

The following table shows the names of the menu fields for the Exit menu, the default settings and a description of the field's function and any special information needed to help understand the field's use.

Exit System Setup and save your changes to CMOS.

Figure 18. Exit Menu

Table 18: Fields, Options and Defaults for the Exit Menu

Menu Field Description

Exit Saving Changes

Exit Discarding Changes

Load Setup Defaults

Exit Saving Changes and Exit will store all the entries on every menu of the setup utility to the BIOS memory, then exit the utility. A confirmation message Save Configuration changes and exit now? [Yes][No] is displayed.

Selecting Exit Discarding Changes and Exit will exit the setup utility with out writing to the BIOS memory. When the BIOS recognizes this selection it will load the operating system and begin operation.

Selecting Load Setup Defaults will load the factory preset default values for all menu fields, then display the message Load default configuration now? [Yes] [No]. When confirmed the setup utility will return to the Exit Menu. To return to another menu follow the directions in the Navigating Through the Setup Utility Section.

Table 18: Fields, Options and Defaults for the Exit Menu

Menu Field Description

Discard Changes

Save Changes Selecting Save Changes will cause the new settings in all menus to be written to the BIOS memory.

Save Changes and Power Off

Selecting Discard Changes will load the previous values in BIOS memory for all menu fields. The message Load previous configuration now? [Yes] [No] will be displayed. When confirmed the setup utility will return to the Exit menu. To return to another menu, follow the directions in the Navigating Through the Setup Utility Section.

The message Save configuration changes now? [Yes] [No] will be displayed. When confirmed, the setup utility will return to the Exit menu. To return to another menu, follow the directions in the Navigating Through the Setup Utility section.

Selecting Save Changes and Power Off will cause the new settings in all menus to be written to the BIOS memory. The message Save configuration changes and power off now? [Yes] [No] will be displayed. When confirmed, the system will shut down. If No is selected, the system will return to the Exit menu. To return to another menu, follow the directions in the Navigating Through the Setup Utility section.

Fujitsu A3110 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

A Series BIOS

BIOS SETUP UTILITY

Entering the BIOS Setup Utility

Navigating through the Setup Utility

Entering the Setup Utility After a Configuration Change or System Failure

Drive0 Submenu of the Main Menu

Drive1 Submenu of the Main Menu

Keyboard/Mouse Features Submenu of the Advanced Menu

Video Features Submenu of the Advanced Menu

Internal Device Configurations Submenu of the Advanced Menu

CPU Features Submenu of the Advanced Menu

USB Features Submenu of the Advanced Menu

Miscellaneous Configurations Submenu of the Advanced Menu

Event Logging Submenu of the Advanced Menu

Exiting from the Security Menu

Hard Disk Security Submenu of the Security Menu

Owner Information Submenu of the Security Menu

Boot Device Priority Submenu of the Boot Menu

INFO MENU - DISPLAYS BASIC SYSTEM INFORMATION
