Fujitsu 2012 001 SNB User Manual

User manual
User manual
User manualUser manual
Ver 1.3
User manual
1/10
revision Updated date
1.0 Aug 1 2012 First edition Modification
Page 6(DSSS/CCK->DSSS/BPSK),7(modification of consumption), 8(addition of following sentence)
1.1 Aug 6 2012
1.2 August 15 2012
1.3 August 28 2012 - Fixing of 4.3
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
-Fixing of 3.1(delete comments of remarks)
- addition of 5.6 Indicating compliance with ICES-003
CCCChange history
hange history
hange historyhange history
User manual
summary
2/10
Table of contents
Table of contents
Table of contentsTable of contents
User manual
1. Apprication ..................................................................................................................................... 4
2. System Configuration ..................................................................................................................... 4
3. Description of Meter (Host) ............................................................................................................ 5
3.1 Overview .................................................................................................................................... 5
3.2 Operating Range ........................................................................................................................ 5
4. Description of Module ( Module) .................................................................................................... 6
4.1 Overview .................................................................................................................................... 6
4.2 Operating Range ........................................................................................................................ 6
4.3 Major element ............................................................................................................................ 6
4.4 Basic specificationmodule .................................................................................................... 7
5. Required FCC and IC statement ( Host ) ....................................................................................... 8
5.1 FCC §15.21 ................................................................................................................................ 8
5.2 FCC §15.105 .............................................................................................................................. 8
5.3 RSS-Gen §7.1.2. ........................................................................................................................ 8
5.4 RSS-Gen §7.1.3. ........................................................................................................................ 8
5.5 Indicating safe separation distance warning .............................................................................. 9
6. Required FCC and IC statement (Module)...................................................................................10
6.1 FCC §15.21 ..............................................................................................................................10
6.2 FCC §15.105 ............................................................................................................................10
6.3 RSS-Gen §7.1.2. ......................................................................................................................10
6.4 RSS-Gen §7.1.3. ......................................................................................................................10
3/10
User manual
Substation
Center
DHCP Server
Router
Switch
Meters
Gateway
1. Apprication
This document shows the description of wattmeterhereinafter called meterand mounted communication boardhereinafter called module.
- target meters : GE I210+ Meter FM1S / FM2S / FM12S / FM25S
- Module : Fujitsu YAA75-0402
2. System Configuration
Fig2-1 is general system configuration of using meter. Installed meters in each house is communicated to Center via Repeaters and Gateways and control the meter-reading value etc.automatically.
Red line of Fig.2-1 is the applicable scope of this document.
Repeaters
Server
Fiber-opt
network
Router
…..
-
Fig2-1 System configuration
Poles
Houses
4/10
3. Description of Meter (Host)
Category
Meter form
Remark
FM1S FM2S FM
12S FM
25S
Input voltage
enclosure
Meter panel
Meter socket
Mouted module
meter panel
AC power
3.1 Overview
Form and overview of meter are as follows.
User manual
120VAC 240VAC 120VAC
or 240VAC
Same form
Same board
board
Different type
type
Same module
Same interface
interface
Same cable
cable
3.2 Operating Range
• Voltage : + - 20% (or ±20%)
• Temperature : -40°C through +85°C
• Typical Starting Watts : <=5.0 Watts (Form 2S 240V CL200)
• Typical Watts Loss : 0.7 Watts
• Typical Accuracy : Within +/- 0.2%
120VAC or 240VAC
5/10
4. Description of Module ( Module)
1
3
4
5
+3.3VDC
4.1 Overview
The module mounted to each meter in paragraph 3 collects the meter-reading values etc. with controlling Center.
4.2 Operating Range
Same as chapter 3.2.
4.3 Major element
Major elements of module are as follows.
No.
22
component summary remark
Radio element IEEE802. 11b
Transmission power:100mW ModulationDSSS / BPSK
Data rate 1Mbps Antenna This antenna made by printed-circuit in the module. Meter panel
interface
Communication between Meter panel.
Signals:refer to chapter 3.2 element Power element *AC cable(with ferrite bead) is connected to
this element.
*This element steps down AC input(120V/240V) to
+3.3VDC.
Dispray element extinction power off or normal operation LED(green)
blinking No operation ( start-up firmware)
lighting No operation(reset / no service)
extinction normal LED(red)
blinking fault
lighting reset
Meter
User manual
From electric pole
120/ 240VAC
Meter
Socket
Meter panel
*Display *Meter
information collection
AC cable with
120VAC / 240VAC
UART/ Control signal
ferrite bead
module
Meter panel
Radio
element
antenna element
Interface
element
Power
element
6/10
4.4 Basic specification
module】】】】
【【
User manual
No
1 External
interface
2 Debug
interface
3 Display LED
4 Security Tamper Program Deletion 5 Power Input
6 Condition Operating
7 Cooling method Air cooling without blower 8 Thunder surge
Protection fuse
Item
Wireless IEEE802. 11b
Meter Panel
Power
RESET FRES1/2 Short-circuit MB86C90 JTAG:×1 AR2315 JTAG:×1
Frequency 50/60Hz consumption Input : Less than 8.49W(AC:120V/240V)
temperature
Connector10pin
Input : AC85264V
Status GREEN Alarm AMBER
AC-DC Conversion 120V/240V3.3V
Output : Less than 5.94W(DC:+3.3V)
-2040
varistor fuse
specification
7/10
User manual
5. Required FCC and IC statement ( Host )
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
5.1 FCC §15.21
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
5.2 FCC §15.105
For class B equipment: NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: — Reorient or relocate the receiving antenna. — Increase the separation between the equipment and receiver. — Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. — Consult the dealer or an experienced radio/TV technician for help.
5.3 RSS-Gen §7.1.2.
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication.
Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une communication satisfaisante.
5.4 RSS-Gen §7.1.3.
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation
of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d'en compromettre le fonctionnement.
8/10
User manual
5.5 Indicating safe separation distance warning
This equipment complies with radio frequency exposure limits set forth by the FCC and Industry Canada for an uncontrolled environment. This equipment should be installed and operated with a Minimum distance of 20cm between the device and the user or bystanders. This device must Not be co-located or operating in conjunction with any other antenna or transmitter.
Cet équipement est conforme aux limites d'exposition aux radiofréquences définies par la FCC et Industrie Canada pour un environnement non contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 20 cm de distance entre le dispositif et l'utilisateur ou des tiers. Ce dispositif ne doit pas être utilisé a proximité d’une autre antenne ou d’un autre émetteur.
5.6 Indicating compliance with ICES-003
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe or B est conforme à la norme NMB-003 du Canada
9/10
User manual
6. Required FCC and IC statement (Module)
6.1 FCC §15.21
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
6.2 FCC §15.105
For class B equipment: NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: — Reorient or relocate the receiving antenna. — Increase the separation between the equipment and receiver. — Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. — Consult the dealer or an experienced radio/TV technician for help.
6.3 RSS-Gen §7.1.2.
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication.
Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une communication satisfaisante.
6.4 RSS-Gen §7.1.3.
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation
of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d'en compromettre le fonctionnement.
10/10
