Fujitsu Eternus2000, 100, 200 User Manual

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

Preface

Fujitsu would like to thank you for purchasing our ETERNUS2000 disk storage system. The ETERNUS2000 disk storage system is designed to be connected by a Fibre Channel interface, iSCSI interface, or SAS interface to a Fujitsu (PRIMEQUEST, PRIMERGY, SPARC Enterprise, or PRIMEPOWER) or other server. This guide introduces the user to the ETERNUS2000 disk storage system (referred to as just "ETERNUS2000" in the remainder of this manual), and explains the regular checks and maintenance required. Please carefully review the information outlined in this manual.

Third Edition January 2009

Applicable Environment

The ETERNUS2000 was designed and manufactured with user safety in mind. When using the ETERNUS2000, follow the handling instructions, placement and cautionary notes listed in this guide. If used beyond the limits described, the users may be at risk of personal injury and/or material damage.

Using this Manual

The manuals provided with the ETERNUS2000 contain important information regarding safe usage. Please read these manuals carefully before using the ETERNUS2000. Pay special attention to "ETERNUS2000 models 100 and 200 disk storage system Safety Precautions", and understand the contents thoroughly before connecting. Keep these manuals in a safe place for future reference. Fujitsu pays careful attention to the safe use of its products to prevent user injury and/or material damage. To use the ETERNUS2000 properly, please follow the instructions in this manual.

Preface

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

UNIX is a registered trademark of The Open Group in the United States and other countries. Microsoft, Windows, and Windows Server are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. Sun, Sun Microsystems, the Sun Logo, Solaris and all Solaris based marks and logos are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries, and are used under license. All SPARC marks are trademarks or registered trademarks of SPARC International, Inc. in the U.S. and other countries, and are used under license. Products with a SPARC mark are based on the architecture developed by Sun Microsystems, Inc. HP-UX is a trademark of Hewlett-Packard in the U.S. and other countries. Linux is a trademark or registered trademark of Linus Torvalds in the U.S. and other countries. AIX is a trademark of IBM Corp. VMware, VMware logos, Virtual SMP, and VMotion are either registered trademarks or trademarks of VMware, Inc. in the U.S. and/or other countries. Java and all Java based marks are trademarks or registered trademarks of Sun Microsystems, Inc. in the United States and other countries. The company names, product names and service names mentioned in this document are registered trademarks or trademarks of their respective companies.

Screen shot(s) reprinted with permission from Microsoft Corporation.

The ETERNUS2000 is designed, developed and manufactured as contemplated for general use, including without limitation, general office use, personal use, household use, and ordinary industrial use, but is not designed, developed and manufactured for use in situations with accompanying fatal risks or dangers that, unless extremely high safety is secured, could lead directly to death, personal injury, severe physical damage or other loss (hereinafter "High Safety Required Use"), including without limitation, nuclear reaction control in nuclear facility, aircraft flight control, air traffic control, mass transport control, medical life support system, and missile launch control in weapon systems. Do not use the ETERNUS2000 for High Safety Required Use without securing the sufficient safety level required. If you wish to use the ETERNUS2000 for High Safety Required Use, please consult with our sales representative before such use.

Electromagnetic compatibility Emissions: FCC Class A, EN55022 Class A and CNS 13438 Class A Immunity: EN55024

Safety CAN/CSA C22.2 No. 60950, UL60950 and EN60950

Class 1 laser product

Preface

iii

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

Preface

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

This page is intentionally left blank.

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

About this Manual

This guide introduces the ETERNUS2000 to the user and explains how to check and maintain the ETERNUS2000 on a regular basis. Refer to the manuals for each peripheral concerning details not included in this manual.

Organization

This manual is organized as follows:

• Chapter 1 Overview

This chapter provides an external view of the ETERNUS2000, and explains the special features, data configurations of RAID groups, and specifications of the ETERNUS2000.

• Chapter 2 Hardware

This chapter describes the hardware components of the ETERNUS2000 and details of the basic operation methods of the ETERNUS2000, such as how to turn the power on and off.

• Chapter 3 Installation

This chapter describes the ETERNUS2000 installation.

• Chapter 4 Setup

This chapter describes how to connect and setup the ETERNUS2000 for operation.

• Chapter 5 Installing Optional Products

This chapter describes how to attach optional products.

• Chapter 6 Operation and Troubleshooting

This chapter describes points to note when operating and performing maintenance for the ETERNUS2000. Also, this chapter describes how to respond to any problems which may occur. Read this chapter when operating or performing maintenance on the ETERNUS2000, or if an error

"Specifications" and "Events detected by ServerView" are described as appendixes.

Refer to the manuals for each peripheral concerning details not included in this manual.

About this Manual

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

Warning Notations

Warning signs are shown throughout this manual in order to prevent injury to the user and/or material damage. These signs are composed of a symbol and a message describing the recommended level of caution. The following explains the symbols, their levels of caution, and their meanings as used in this manual.

The following symbols are used to indicate the type of warnings or cautions being described.

WARNING

This symbol indicates the possibility of serious or fatal injury if the ETERNUS2000 is not used properly.

CAUTIO

This symbol indicates the possibility of minor or moderate personal injury, as well as damage to the ETERNUS2000 and/or to other users and their property, if the ETERNUS2000 is not used properly.

MPORTAN

This symbol indicates IMPORTANT information for the user to note when using the ETERNUS2000.

Electrical Shock

The triangle emphasizes the urgency of the WARNING and CAU-

TION contents. Inside the triangle and above it are details concerning the symbol (e.g. Electrical Shock).

o Disassemb

The barred "Do Not..." circle warns against certain actions. The

action which should be avoided is both illustrated inside the barred circle and written above it (e.g. No Disassembly).

Unplu

The black "Must Do..." disk indicates actions that must be taken. The

required action is both illustrated inside the black disk and written above it (e.g. Unplug).

About this Manual

vii

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

How Warnings are Presented in this Manual

A message is written beside the symbol indicating the caution level. This message is marked with a vertical ribbon in the left margin, to distinguish this warning from ordinary descriptions. An example is shown here.

Warning Level Indicator

Warning Type Indicator

Warning Details

To avoid damaging the ETERNUS2000, pay attention to the following points when cleaning the ETERNUS2000:

- Make sure to disconnect the power when cleaning.

- Be careful that no liquid seeps into the ETERNUS2000 when using cleaners, etc.

- Do not use alcohol or other solvents to clean the ETERNUS2000.

Warning Layout Ribbon

xample Warning

viii

About this Manual

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

Additional Information

■ Expressions and abbreviations

The following are expressions and abbreviations used throughout this manual:

Note:

This notation indicates there is supplementary information in addition to the explanation already provided.

Product names and abbreviations

• "Windows®" represents the following products.

- Microsoft® Windows® 2000 operating system

- Microsoft® Windows Server® 2003 operating system

- Microsoft® Windows Server® 2008 operating system

• "Solaris OS" represents a Solaris™ Operating System.

- "Solaris 8 OS" represents a Solaris™ 8 Operating System

- "Solaris 9 OS" represents a Solaris™ 9 Operating System

- "Solaris 10 OS" represents a Solaris™ 10 Operating System

Latest Information

The information in this document is subject to change without notice for functionality expansion of

ETERNUS2000 and improvement. The latest version of this document and the latest information about the

ETERNUS2000 is released in the following web-site. Access the following address if needed.

http://www.fujitsu.com/global/services/computing/storage/system/eternus2000/

Point

Functions and know how which can be useful when setting up or operating the ETERNUS2000.

Refer

This notation indicates related reference manuals.

About this Manual

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

Related Manuals

Refer to the following related manuals in addition to this manual.

Manuals Code Description

ETERNUS2000 models 100 and 200 disk storage system Setup Guide (Fibre Channel type)

P3AM-2542

This manual describes how to ready Fibre Channel type devices for operation.

ETERNUS2000 models 100 and 200 disk storage system Setup Guide (iSCSI type)

P3AM-2552

This manual describes how to ready iSCSI type devices for operation.

ETERNUS2000 models 100 and 200 disk storage system Setup Guide (SAS type)

P3AM-2562

This manual describes how to ready SAS type devices for operation.

ETERNUS2000 models 100 and 200 disk storage system Safety Precautions

P3AM-1972

This manual describes the points to note when installing and operating the device.

ETERNUS2000 models 100 and 200 disk storage system Package Contents

P3AM-1982

This is the list of package contents for the device and optional products.

ETERNUS2000 models 100 and 200 disk storage system Using Optional Products

P3AM-1992

This manual describes the points to note when using optional products.

ETERNUS8000, ETERNUS4000, ETERNUS2000 disk storage system

Server Connection Guide (Fibre Channel)

(*1)

This manual describes how to connect the ETERNUS2000 (Fibre Channel type) to a server.

For Solaris Operating System P3AM-1532

For HP-UX P3AM-1542

For AIX P3AM-1552

For Windows® P3AM-1562

For Linux P3AM-1572

For Fibre Channel Switch Settings P3AM-1582

For VMware® ESX P3AM-1592

ETERNUS8000, ETERNUS4000, ETERNUS2000 disk storage system

Server Connection Guide (iSCSI)

(*1)

P3AM-1672

This manual describes how to connect the ETERNUS2000 (iSCSI type) to a server.

ETERNUS disk storage systems ETERNUSmgr Install Guide

This manual describes how to install the ETERNUSmgr.

For Solaris™ Operating System P2S0-0081

For Windows® P2WW-1631

For Linux P2U3-0021

For HP-UX P2S0-0092

For AIX P2S0-0102

ETERNUS disk storage systems ETERNUSmgr User Guide -Introduction-

P2X0-0201

This manual describes the outlines of basic operations for the ETERNUSmgr.

About this Manual

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

*1: Manuals are supplied in the product CD. *2: Manuals are supplied in the ETERNUSmgr product CD. *3: Online Help is also available.

ETERNUS2000 ETERNUSmgr User Guide

-Settings/Maintenance-

(*2)(*3)

P2X0-0620

This manual describes how to monitor and set the ETERNUS2000 with the ETERNUSmgr.

ETERNUS Multipath Driver V2.0 User's Guide

This manual describes how to use the optional ETERNUS Multipath Driver.

For Solaris™ Operating System P2S0-0061

(For Windows®) P2WW-1451

(For Linux) P2U3-0031

ETERNUS Multipath Driver V3.0 User's Guide

For Solaris™ Operating System P2S0-0062

ETERNUS MPIO for IBM AIX V2.0.1 Installation & Configuration Guide for AIX

P2U3-0150

Manuals Code Description

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

Labels

Warning labels and manufacturer's labels are found in various places of the ETERNUS2000, as shown in the example below. Do not remove these labels.

■ Controller Enclosure

Manufacturer’s label The label with the model, serial #, etc. is located here.

xii

Labels

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

■ Drive Enclosure

Labels

xiii

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

■ AC Outlet Box

For 1U

For 4U

Manufacturer’s label The label with the model, serial #, etc. is located here.

Manufacturer’s label

The label with the model, serial #, etc. is located here.

xiv

Labels

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

This page is intentionally left blank.

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

Contents

Chapter 1 Overview .................................................................1

1.1 System Features ...........................................................................1

1.2 Configuration .................................................................................4

1.2.1 RAID Level ........................................................................................................................4

1.2.2 RAID Groups and Volumes ...............................................................................................8

1.2.3 System Disks ..................................................................................................................10

1.2.4 Hot Spare Disks ..............................................................................................................11

1.2.5 Disk Drives ......................................................................................................................11

1.2.6 Host Interface ..................................................................................................................12

1.3 Functions .....................................................................................13

1.3.1 Rebuild/Copyback ...........................................................................................................13

1.3.2 Redundant Copy .............................................................................................................15

1.3.3 Advanced Copy ...............................................................................................................16

1.3.4 RAID Migration ................................................................................................................17

1.3.5 Logical Device Expansion (LDE) .....................................................................................19

1.3.6 LUN Concatenation .........................................................................................................20

1.3.7 Security Functions ...........................................................................................................21

1.3.8 ECO mode ......................................................................................................................23

Chapter 2 Hardware...............................................................25

2.1 Components ................................................................................25

2.1.1 Controller Enclosure ........................................................................................................25

2.1.2 Drive Enclosure ...............................................................................................................32

2.1.3 AC outlet box ...................................................................................................................36

2.2 Standard Operations ...................................................................37

2.2.1 Power ON Control ...........................................................................................................37

2.2.2 Power OFF Control .........................................................................................................39

2.2.3 Attaching and Removing the Front Cover .......................................................................40

2.3 Flow from Installation to Operation ..............................................42

Chapter 3 Installation ............................................................45

3.1 Preparation ..................................................................................45

3.1.1 Placement Area ...............................................................................................................45

3.1.2 Check the number of wall outlets ....................................................................................46

3.2 Rack Installation ..........................................................................48

3.2.1 Installing Controller Enclosure ........................................................................................49

3.2.2 Installing Drive Enclosure ................................................................................................52

3.2.3 Installing AC Outlet Box ..................................................................................................55

xvi

Contents

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

Chapter 4 Setup .....................................................................59

4.1 Prior Preparation .........................................................................59

4.2 Cable Connection ........................................................................62

4.2.1 LAN Cable Connection (Twist Pair Cable Compatible with Category 5)

(for Operation Management) ..........................................................................................62

4.2.2 Fibre Channel Cable Connection (Fibre Channel Type) .................................................65

4.2.3 LAN Cable Connection (Twisted Pair Cable Compatible with Enhanced Category 5)

(iSCSI Type) ....................................................................................................................67

4.2.4 MiniSAS Cable Connection (SAS Type) .........................................................................69

4.2.5 MiniSAS Cable Connection (For Drive Enclosures) ........................................................71

4.2.6 Power Cord Connection ..................................................................................................76

4.3 ETERNUS2000 Setup .................................................................87

4.3.1 Basic setup ......................................................................................................................89

4.3.2 Advanced Copy Setup ..................................................................................................103

4.3.3 AC Automatic Linkage Mode Setup ..............................................................................106

4.4 Installing and Setting up ETERNUSmgr ....................................107

4.5 Maintenance Setup ....................................................................108

4.5.1 Setting up the ETERNUS2000 monitoring ....................................................................108

4.5.2 Remote Support Setup ..................................................................................................112

4.6 Setting up the Server Connection ..............................................115

4.7 System Status Check ................................................................116

Chapter 5 Installing Optional Products .............................119

5.1 Disk Drive Installation ................................................................119

5.1.1 Disk Drive Handling Instructions ...................................................................................119

5.1.2 Installable Disk Drives ...................................................................................................120

5.1.3 Disk Drive Installation Positions ....................................................................................121

5.1.4 Additional Disk Drive Installation Procedure .................................................................121

5.2 Drive Enclosure Installation .......................................................127

5.2.1 Drive Enclosure Handling Instructions ..........................................................................127

5.2.2 Installable Drive Enclosures ..........................................................................................128

5.2.3 Drive Enclosure Rack Mounting Procedure ..................................................................128

5.2.4 Additional Drive Enclosure Installation ..........................................................................131

5.3 Battery Unit Installation ..............................................................139

5.3.1 Battery Unit Handling Instructions .................................................................................139

5.3.2 Installable Battery Unit ..................................................................................................140

5.3.3 Battery Unit Installation Position ...................................................................................140

5.3.4 Additional Battery Unit Installation Procedure ...............................................................140

Chapter 6 Operation and Troubleshooting .......................147

6.1 Checking the ETERNUS2000 Status ........................................147

6.2 Backing up Data ........................................................................147

Contents

xvii

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

6.3 Maintenance Service .................................................................148

6.3.1 Maintenance Support Period .........................................................................................148

6.3.2 Periodical Component Replacement .............................................................................148

6.4 Post Start-of-Operation Changes to the Configuration ..............150

6.4.1 When Replacing the Fibre Channel Card .....................................................................150

6.4.2 When Replacing the LAN Card / iSCSI HBA ................................................................151

6.4.3 When Replacing the SAS Card .....................................................................................151

6.5 Troubleshooting .........................................................................153

6.5.1 Check List .....................................................................................................................153

6.5.2 Trouble Record .............................................................................................................158

Appendix A Specifications.....................................................161

A.1 Base Device Specifications ........................................................161

A.1.1 ETERNUS2000 model 100 specification ...................................................................... 161

A.1.2 ETERNUS2000 model 200 specification ...................................................................... 165

A.2 Optional Products Specification..................................................168

A.2.1 Disk Drive...................................................................................................................... 168

A.2.2 Drive Enclosure............................................................................................................. 171

A.2.3 Additional Battery Unit Option....................................................................................... 171

A.2.4 AC Outlet Box ............................................................................................................... 172

Appendix B Events detected by ServerView........................173

Index ....................................................................................175

xviii

Contents

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

This page is intentionally left blank.

xix

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

Figure of Contents

Figure 1.1 RAID0 Concept ................................................................................................................. 5

Figure 1.2 RAID1 Concept ................................................................................................................. 5

Figure 1.3 RAID1+0 Concept ............................................................................................................. 6

Figure 1.4 RAID5 Concept ................................................................................................................. 6

Figure 1.5 RAID6 Concept ................................................................................................................. 7

Figure 1.6 Example of a RAID group ................................................................................................. 8

Figure 1.7 RAID group concept.......................................................................................................... 9

Figure 1.8 System disk and user disk .............................................................................................. 10

Figure 1.9 Hot Spare Disks .............................................................................................................. 11

Figure 1.10 Rebuild/Copyback function ............................................................................................. 13

Figure 1.11 Redundant Copy Function .............................................................................................. 15

Figure 1.12 Example for use Advanced Copy function ...................................................................... 16

Figure 1.13 Example for use RAID Migration 1.................................................................................. 18

Figure 1.14 Example for use RAID Migration 2.................................................................................. 18

Figure 1.15 Example for use Logical Device Expansion .................................................................... 19

Figure 1.16 Example for use LUN Concatenation.............................................................................. 20

Figure 1.17 LUN Mapping function..................................................................................................... 21

Figure 1.18 Host Affinity function ....................................................................................................... 22

Figure 1.19 Setting example for ECO mode schedule ....................................................................... 23

Figure 2.1 Front view of controller enclosure (with front cover) ....................................................... 25

Figure 2.2 Front view of controller enclosure (without front cover) .................................................. 26

Figure 2.3 Disk drive slot numbers (controller enclosure)................................................................ 26

Figure 2.4 Rear view of controller enclosure.................................................................................... 27

Figure 2.5 Fibre Channel type controller (rear view closeup)........................................................... 27

Figure 2.6 iSCSI type controller (rear view closeup)........................................................................ 28

Figure 2.7 SAS type controller (rear view closeup).......................................................................... 29

Figure 2.8 Other controller LEDs (rear view closeup) ...................................................................... 30

Figure 2.9 Front view of drive enclosure (with front cover) .............................................................. 32

Figure 2.10 Front view of drive enclosure (without front cover) ......................................................... 33

Figure 2.11 Slot number of disk drives (drive enclosure)................................................................... 33

Figure 2.12 Rear view of drive enclosure........................................................................................... 34

Figure 2.13 Expander (Closeup) ........................................................................................................ 34

Figure 2.14 LEDs in the rear side of the controller enclosure ............................................................ 35

Figure 2.15 AC outlet box (1U)........................................................................................................... 36

Figure 2.16 AC outlet box (4U)........................................................................................................... 36

Figure 4.1 MiniSAS cable connection

(between the Controller Enclosure and Drive Enclosure) ............................................... 74

Figure 4.2 MiniSAS cable connection

(When two or more Drive Enclosures are added) ........................................................... 75

Figure 4.3 Connection of AC output cables (1U).............................................................................. 80

Figure 4.4 Connection of AC output cables (4U).............................................................................. 84

Figure 4.5 Network Settings label .................................................................................................... 87

Figure 4.6 Tutorial wizard [GUIDE] screen....................................................................................... 89

Figure 4.7 Network environment setting screen............................................................................... 90

Figure 4.8 Date and time setting screen .......................................................................................... 91

Figure 4.9 Port settings (topology settings) screen (for Fibre Channel)........................................... 92

Figure 4.10 Port settings screen (for iSCSI type)............................................................................... 93

Figure 4.11 Port settings screen (for SAS)......................................................................................... 94

Figure 4.12 Hot Spare disk registration screen.................................................................................. 96

Figure 4.13 RAID group registration screen....................................................................................... 98

Figure 4.14 Volume creation screen ................................................................................................ 100

Figure 4.15 Volume creation confirmation screen............................................................................ 100

Figure of Contents

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

Figure 4.16 Assignment of volumes to the Host Affinity group screen............................................. 101

Figure 4.17 Host LUN number setting screen.................................................................................. 102

Figure 4.18 Host Affinity group setting confirmation screen............................................................. 103

Figure 4.19 License registration screen ........................................................................................... 104

Figure 4.20 Network environment settings screen (when the ServerView is used) ......................... 109

Figure 4.21 SNMP agent screen (Trap Destination screen) ............................................................ 109

Figure 4.22 MIB definition extraction for ServerView monitoring screen.......................................... 110

Figure 4.23 SNMP Trap test screen example .................................................................................. 111

Figure 4.24 General status lamp...................................................................................................... 116

Figure 4.25 RAID group list screen .................................................................................................. 117

Figure 4.26 Volume list screen......................................................................................................... 117

Figure 5.1 Position of disk drive slots............................................................................................. 121

Figure 5.2 Position of Battery Unit.................................................................................................. 140

Figure 6.1 Battery unit status display window ................................................................................ 149

Figure 6.2 Battery unit expansion failure screen............................................................................ 155

Figure 6.3 ETERNUS Multipath Manager Window ........................................................................ 156

Figure 6.4 Trouble record (1/2) ...................................................................................................... 158

Figure 6.5 Trouble record (2/2) ...................................................................................................... 159

xxi

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

Table of Contents

Table 1.1 User Capacity for each RAID Level .................................................................................. 7

Table 1.2 User Capacity for each RAID Level .................................................................................. 8

Table 1.3 Recommended number of disk drives per RAID group..................................................... 9

Table 1.4 The maximum number of volumes that can be set ........................................................... 9

Table 1.5 Volume formatting time ................................................................................................... 10

Table 1.6 Rebuild process times (for 100GB volumes)................................................................... 14

Table 1.7 Copyback process times (for 100GB volumes) ............................................................... 14

Table 3.1 Wall outlets and cable lengths ........................................................................................ 46

Table 3.2 Required number of Power Outlets (ETERNUS2000 model 100) .................................. 46

Table 3.3 Required number of power outlets

(ETERNUS2000 model 200 when AC outlet boxes are not connected) ......................... 47

Table 3.4 Required number of power outlets

(ETERNUS2000 model 200 when AC outlet boxes are connected) ............................... 47

Table 4.1 Connection path of a power cord (AC output cable) (AC outlet box (1U)) ...................... 79

Table 4.2 Connection path of a power cord (AC output cable) (AC outlet box (4U)) ...................... 83

Table 4.3 Network Settings label fields........................................................................................... 87

Table A.1 Specification (ETERNUS2000 model 100 Fibre Channel type) .................................... 161

Table A.2 Specification (ETERNUS2000 model 100 iSCSI type) ................................................. 162

Table A.3 Specification (ETERNUS2000 model 100 SAS type) ................................................... 163

Table A.4 Specification (ETERNUS2000 model 200 Fibre Channel type) .................................... 165

Table A.5 Specification (ETERNUS2000 model 200 iSCSI type) ................................................. 166

Table A.6 Specification (ETERNUS2000 model 200 SAS type) ................................................... 167

Table A.7 Disk drive specification (146GB/15krpm SAS disk drive).............................................. 168

Table A.8 Disk drive specification (300GB/15krpm SAS disk drive).............................................. 168

Table A.9 Disk drive specification (450GB/15krpm SAS disk drive).............................................. 169

Table A.10 Disk drive specification (400GB/10krpm SAS disk drive).............................................. 169

Table A.11 Disk drive specification (500GB/7.2krpm Nearline SAS disk drive) .............................. 169

Table A.12 Disk drive specification (750GB/7.2krpm Nearline SAS disk drive) .............................. 170

Table A.13 Disk drive specification (1TB/7.2krpm Nearline SAS disk drive)................................... 170

Table A.14 Drive Enclosure specification ........................................................................................ 171

Table A.15 AC outlet box (1U) specification.................................................................................... 172

Table A.16 AC outlet box (4U) specification.................................................................................... 172

Table B.1 ServerView event list..................................................................................................... 173

xxii

Table of Contents

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

This page is intentionally left blank.

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

Chapter 1

Overview

This chapter provides an overview of the ETERNUS2000 features, and specifications.

1.1 System Features

Special features of the ETERNUS2000 are shown below:

■ Space and Energy Savings

• Compact design to make effective use of rack space

• There are two models available; ETERNUS2000 model 100 and ETERNUS2000 model

200. Both models are designed to be 2U size at the minimum

(*1)

. Up to 12 disk drives and

up to 12TB disk capacity

(*2)

can be installed.

•2U

(*1)

of drive enclosure can be expanded in the ETERNUS2000 models 100 and 200.

ETERNUS2000 model 200 allows up to 120 disk drives and 120TB as the disk capacity

(*2)

*1: 2U indicates the device height that can be installed in two units of 19-inch rack (88mm). *2: Physical capacity is calculated based on the assumption 1,000GB = 1TB (including Hot Spare Disks).

• Energy savings by the latest technology

Using the latest 1-chip RAID controller that is configured by multiple chips and reducing number of components allows energy savings.

• ECO mode to reduce environmental load

Using the ECO mode function to start and stop the spindle rotation in the disk drive for each RAID group during the specified hour. Stop the spindle rotation when there is no access to the disk drive to reduce power consumption and decreases environmental load.

■ Easy Installation

• Easy setup

The ETERNUS2000 can be configured easily using a web browser. When installing the ETERNUS2000, follow the setup wizard and just input parameters for displayed setting items to create RAID groups and volumes, and assign to the server.

1.1 System Features

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

■ High scalability and versatile connectivity

• Utilizes the latest disk technology

ETERNUS2000 utilizes the SAS disk drives

(*1)

(450GB/300GB/146GB (15,000rpm), 400GB

(10,000rpm)).

Also, ETERNUS2000 supports large capacity / cost effective Nearline SAS disk drives

(*1)

(1TB/

750GB/500GB (7,200rpm)) for data backup and archiving.

*1: SAS: Serial Attached SCSI

• Supports capacity expansion during system operation

• Disk drives and drive enclosures can be added during the system operation.

• RAID group capacity can be expanded by adding disk drive from the unit of one.

• Volume can be expanded during the system operation. Even when the work load increased rapidly, ETERNUS2000 flexibly expand the volume capacity with no interruption of the operation.

• High connectivity supports the multi-platform environment

• ETERNUS2000 supports FC-SAN, IP-SAN, or DAS environment by utilizing the Fibre Channel interface (maximum transfer speed: 4Gbps), iSCSI interface (maximum transfer speed: 1Gbps), or SAS interface (maximum transfer speed: 3Gbps) as the host interface.

• ETERNUS2000 supports multiple Operating Systems such as UNIX, Linux, and Windows®, and can be connected as a storage system for PRIMEQUEST, SPARC Enterprise, and PRIMERGY servers as well as for UNIX/IA servers of other companies. Also the RAID aggregation using SAN (Storage Area Network) is available.

■ Data integrity with high-speed backup

• Nearline SAS disk drives for data backup and archiving

• Using large capacity / cost effective Nearline SAS disk drives allows low cost D2D (Disk to Disk) backup and high-speed recovery in the case of unexpected failure.

• Storing the less frequently accessed data such as archive data in the Nearline SAS disk drives allows easy reading. Nearline SAS disk drives and SAS disk drives can be installed in the same drive enclosure.

• Various backup function

Cooperation between the Advanced Copy function for ETERNUS2000 models 100 and 200 (Optional), and the high-speed backup replication software "ETERNUS SF AdvancedCopy Manager" allows OPC (One Point Copy), the high-speed copying of disk volumes at specified times.

Chapter 1 Overview

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

■ High reliability supports 24/7/365 operation

• Duplication of important components

Important components such as controllers, power supply units, and fans are duplicated to continue the operation in the case of unexpected failure. Also this allows the hot swapping of failed components with the device power on. In addition, the latest firmware can be applied during system operation.

• RAID6 responds to the double failure of disk drives

ETERNUS2000 supports RAID6, using two parity disks in one RAID group. RAID6 ensures the data safety in the unlikely case of a fatal second malfunction within a single RAID group. Also the ETERNUS2000 supports RAID1, RAID1+0, and RAID5 to realize the flexible RAID configuration.

• Redundant copy ensures disk drive redundancy

ETERNUS2000 diagnoses the disk drives to detect the failure prediction. When the disk drive requires preventive maintenance, ETERNUS2000 automatically copies the data in the target disk drive to ensure data redundancy.

• Block Guard ensures data integrity

ETERNUS2000 adds check codes and check them at multiple checkpoints on data transfer path to ensure the data integrity.

1.2 Configuration

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

1.2 Configuration

This chapter describes items to be noted before configuring the ETERNUS2000 systems.

1.2.1 RAID Level

This section describes the supported RAID level and usage (RAID level selection criteria), and RAID group configuration.

■ Supported RAID levels and mechanism

ETERNUS2000 supports the following RAID levels.

• RAID0 (striping)

• RAID1 (mirroring)

• RAID1+0 (striping of pairs of disks for mirroring)

• RAID5 (striping with distributed parity blocks)

• RAID6 (striping with distributed double parity blocks) (*1)

*1: RAID6 ensures data safety and continues system operation in the case of a second malfunction within a

single RAID group. RAID6 redundancy allows high availability system operation.

Each RAID level description is shown below.

CAUTIO

Remember that a RAID0 configuration is not redundant. This means that if a RAID0 disk drive fails, the data will not be recoverable. Therefore, using RAID1, RAID1+0, RAID5, or RAID6 configuration is recommended.

Chapter 1 Overview

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

• RAID0 (striping)

Data is split in unit of blocks and stored across multiple disks.

Figure 1.1 RAID0 Concept

• RAID1 (mirroring)

RAID1 stores the same data on two duplicated disks at the same time. If one disk drive fails, other disk drive continues operation.

Figure 1.2 RAID1 Concept

Data writing request

Data is stored in multiple disks.

HDD0 HDD1

ABCD

Data writing request

Data is stored on two disks at the same time.

HDD0 HDD1

1.2 Configuration

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

• RAID1+0 (striping of pairs of disks for mirroring)

RAID1+0 combines the performance of RAID0 (striping) with the reliability of RAID1 (mirroring).

Figure 1.3 RAID1+0 Concept

• RAID5 (striping with distributed parity)

Data is allocated in units of blocks across multiple disks to duplicate data.

Figure 1.4 RAID5 Concept

HDD3

HDD7

D’

HDD2

HDD6

C’

HDD1

HDD5

B’

HDD0

HDD4

A’

Striping (RAID0)

Mirroring (RAID1)

Data writing request

ABCD

Mirroring

ABCD

Data writing request

M, N, O, P

I, J, K, L

E, F, G, H

Create Parity Data

A, B, C, D

A B DC

HDD0 HDD1 HDD2 HDD3 HDD4

Paruty for data A to D Paruty for data E to H Paruty for data I to L: Paruty for data M to P

Parity M, N, O, P

Parity I, J, K, L

Parity E, F, G, H

Parity A, B, C, D

Chapter 1 Overview

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

• RAID6 (striping with distributed double parities)

Store two different parities on different disk drives (double parities) to recover from up to two disk drive failures.

Figure 1.5 RAID6 Concept

■ User Capacity for each RAID Level

User capacity varies according to the RAID level.

Table 1.1 shows the formula for user capacity computation.

Table 1.1 User Capacity for each RAID Level

1. Actual number of disk drives can be installed depend on the ETERNUS2000 models.

M, N, O, P

I, J, K, L

ABCD

Data writing request

M, N, O, P

I, J, K, L

E, F, G, H

A, B, C, D

A B DC

Create parity data

HDD0 HDD1 HDD2 HDD3 HDD4 HDD5

Parity for data A to D: Parity1

A, B, C, D and Parity2 A, B, C, D

Parity for data E to H: Parity1 E, F, G, H and Parity2 E, F, G, H Parity for data I to L: Parity1 I, J, K, L and Parity2 I, J, K, L Parity for data M to P: Parity1 M, N, O, P and Parity2 M, N, O, P

RAID level Number of disk drives (*1) Formula for user capacity computation

RAID0 2 to 16 Disk drive capacity x Number of disk drives

RAID1 2 Disk drive capacity x Number of disk drives/2

RAID1+0 4 to 32 Disk drive capacity x Number of disk drives/2

RAID5 3 to 16

Disk drive capacity x (Number of disk drives - 1)

RAID6 5 to 16

Disk drive capacity x (Number of disk drives - 2)

1.2 Configuration

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

■ Reliability, performance, capacity for each RAID level

Table 1.2 shows the comparison result of reliability, performance, capacity for each RAID level.

Table 1.2 User Capacity for each RAID Level

■ Recommended RAID level

Select the appropriate RAID level according to the usage.

• Recommended RAID level is RAID1, RAID1+0, RAID5 and RAID6.

• For read and write performance, RAID1+0 configuration is recommended.

• For read only file servers and backup servers, RAID5 or RAID6 can also be used. However, if the disk drive fails, note that it may affect the operation I/O for a rebuilding (writing) operation.

1.2.2 RAID Groups and Volumes

■ RAID group

In an ETERNUS2000 disk storage system, you can setup the RAID groups to all use the same RAID level or a mixture of different RAID levels.

Figure 1.6 Example of a RAID group

RAID level Reliability Performance

(Writing speed)

Capacity

RAID0 Bad Good Very Good

RAID1 Very Good Good Not Bad

RAID1+0 Very Good Good Not Bad

RAID5 Good Not Bad Good

RAID6 Very Good Not Bad Good

RAID Group 1

RAID Group 2

Chapter 1 Overview

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

Table 1.3 show the recommended number of disk drives that configures a RAID group.

Table 1.3 Recommended number of disk drives per RAID group

Note:

• Adding more disk drives to a RAID group improves performance.

• Use of higher capacity disk drives in a RAID group will increase the time required for the drive rebuild process to complete.

• Similarly, the more disk drives per RAID5 or RAID6 group, the longer the drive rebuild process will take following a disk drive failure.

■ Volume

Logical disk drive areas in RAID groups are called volumes. A volume is the basic RAID unit, that can be recognized by the server.

Figure 1.7 RAID group concept

• Table 1.4

shows the maximum number of volumes that can be set.

Table 1.4 The maximum number of volumes that can be set

RAID level Recommended number of disk drives

RAID1 2

RAID1+0 4, 6, 8, 10

RAID5 3, 4, 5, 6

RAID6 5, 6, 7

Model Per RAID group Per storage system

model 100 Max. 128 Max. 512

model 200 Max. 128 Max. 1,024

RAID Group 1 RAID Group 2

Volume 1

Volume 2

Volume 3

1.2 Configuration

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

• Table 1.5 shows the time for volume formatting.

Table 1.5 Volume formatting time

*1: The value shows the time required for volume formatting when there is no server I/O. The time depends

on the disk drive configuration or the disk type.

*2: 15,000rpm

• No more than 8TB can be used for any one volume. However, the maximum allowed volume capacity is OS dependent.

1.2.3 System Disks

System disks are disk drives which have part of their area (the system area) assigned for use by the firmware.

Figure 1.8 System disk and user disk

Two system disks are installed in Slot0 and Slot1 in the controller enclosure. The location of system disks can be confirmed by the setting/maintenance program.

RAID level No. of disk drives

Time required for volume formatting (*1)

SAS disk drives (*2) Nearline SAS disk drives

RAID1 2 Approx. 30 minutes/100GB Approx. 85 minutes/100GB

RAID1+0 8 Approx. 20 minutes/100GB Approx. 50 minutes/100GB

RAID5 5 Approx. 20 minutes/100GB Approx. 50 minutes/100GB

RAID6 6 Approx. 25 minutes/100GB Approx. 70 minutes/100GB

MPORTAN

System disks cannot be registered as hot spare disks because their user capacity is smaller than other disk drives (user disks).

System

User

System Disk User Disk

Chapter 1 Overview

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

1.2.4 Hot Spare Disks

Hot spare disks are used as the spare disk drives when the disk drives in the RAID group have failed, or are in error status. Make sure to register the hot spare disk. If the hot spare disk has been registered, when one of the disk drives in the RAID group has a problem, data from this drive is automatically repaired into the hot spare disk.

Figure 1.9 Hot Spare Disks

1.2.5 Disk Drives

Two kinds of disk drive can be installed in the device: SAS disk drives and Nearline SAS disk drives. Each disk drive are suitable for the following usages.

• SAS Disk Drive

SAS disk drives are highly-performance/high-reliability disk drives for enterprise use. SAS disk drives support 24/7/365 operations and are used to store frequently accessed data such as high performance databases.

• Nearline SAS Disk Drive

Nearline SAS disk drives are high capacity / cost effective disk drives for data backup and archive use. Nearline SAS disk drives can store information that requires a lower access rate at a still reasonable speed more cost effectively than the SAS disk drives.

CAUTIO

• If a disk drive configured in a RAID1, RAID1+0, RAID5, or RAID6 group fails, contact your maintenance engineer immediately as the failed disk drive should be replaced at once. If another disk drive fails before the first disk drive that failed is replaced, the data of the second disk drive may be lost.

• Disk drives in Slot#0 – Slot#3 of controller enclosure (system disks) cannot be registered as a hot spare disk.

MPORTAN

System disks cannot be registered as hot spare disks.

User Disk User Disk User Disk Hot Spare Disk

Failure

1.2 Configuration

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

1.2.6 Host Interface

ETERNUS2000 is available in three types: a Fibre Channel type with Fibre Channel host interfaces, an iSCSI type with iSCSI host interfaces, and a SAS type with SAS host interfaces.

• Fibre Channel interface

Fibre Channel supports two connection topologies, Arbitrated Loop and Fabric. Maximum transfer speed is 4Gbps. This interface is used for database servers, for the expandability and performance benefits it provides.

• iSCSI interface

iSCSI is the protocol that sends and receives SCSI commands to IP packets on Ethernet. Maximum transfer speed is 1Gbps. This interface is used for a section in large companies, or for small and medium companies, since this interface can be introduced at a lower cost than Fibre Channel interface. To ensure efficient iSCSI performance, we recommend that networks used for general purposes, such as accessing the Internet or transferring files, and networks used for iSCSI be physically separated.

• SAS interface

The SAS (Serial Attached SCSI) interface uses serial rather than parallel data transfers in order to provide improved performance, while still maintaining the high reliability of conventional SCSI. With this interface the server is attached via a DAS (Direct Attached Storage) connection. Because DAS connections are less scalable than SAN connections, it is recommended that use of this interface be restricted to smaller-scale systems. Maximum transfer speed is 3Gbps.

Chapter 1 Overview

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

1.3 Functions

This section describes the main ETERNUS2000 functions.

1.3.1 Rebuild/Copyback

When a disk drive fails and the RAID group redundancy has been broken, Rebuild/Copyback restores the disk drive status back to normal status as a background process.

Figure 1.10 Rebuild/Copyback function

Hot Spare Disk

Creates data from the other disk drive than failed disk drive and writes the data into the hot spare disk.

After replaceing completed, copies the data from the hot spare disk to new disk drive.

Replaces the failed disk drive with the new disk drive.

Failure

Rebuild

Copyback

RAID5 (Redundant)

RAID5 (No Redundancy)

RAID5 (Redundant)

1.3 Functions

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

Table 1.6 shows the times required for the rebuild process to complete for various disk configurations.

Table 1.6 Rebuild process times (for 100GB volumes)

*1: The time required to rebuild a 100GB volume of the indicated RAID level, number and type of disk drives when

there is no concurrent server I/O.

*2: 15,000rpm

Table 1.7 shows the times required for the copyback process to complete for various disk configurations.

Table 1.7 Copyback process times (for 100GB volumes)

*1: The time required to copyback a 100GB volume of the indicated RAID level, number and type of disk drives

when there is no concurrent server I/O.

*2: 15,000rpm

RAID level No. of disk drives

Rebuild process time (*1)

SAS disk drives (*2) Nearline SAS disk drives

RAID1 2 Approx. 20 minutes Approx. 60 minutes

RAID1+0 8 Approx. 5 minutes Approx. 15 minutes

RAID5 5 Approx. 7 minutes Approx. 20 minutes

RAID6 6 Approx. 10 minutes Approx. 30 minutes

RAID level No. of disk drives

Copyback process time (*1)

SAS disk drives (*2) Nearline SAS disk drives

RAID1 2 Approx. 20 minutes Approx. 60 minutes

RAID1+0 8 Approx. 5 minutes Approx. 15 minutes

RAID5 5 Approx. 7 minutes Approx. 20 minutes

RAID6 6 Approx. 10 minutes Approx. 30 minutes

Chapter 1 Overview

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

1.3.2 Redundant Copy

Redundant copy function copies data in the disk drive that found a error by Disk Patrol function requires the preventative maintenance to the hot spare disk. With this function, you can restore the data with keeping the redundancy.

Figure 1.11 Redundant Copy Function

Hot Spare Disk

RAID5 (Redundancy)

Create the data from other disk drive than maintenance target disk drive, and write data into the hot spare disk.

Disconnect the maintenance target disk drive and install the hot spare disk.

Sign of

failure

Disconnected

RAID5 (Redundancy)

1.3 Functions

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

1.3.3 Advanced Copy

The Advanced Copy functions allows the ETERNUS2000 to carry out high-speed data copying operations on its own, with no need to draw on server resources. Advanced Copy is a function that copies the data from one volume (copy source) to another volume in the same device (copy destination), at a specific point in time. This high-speed data copy function makes data backup, data restoration and test data replication quick and easy tasks. To use Advanced Copy functions, "ETERNUS SF AdvancedCopy Manager" is required. By using "ETERNUS SF AdvancedCopy Manager", "High-speed Backup", "High-speed Replication", and "Tape Backup" using Advanced Copy function can be performed without interrupting the operation.

Figure 1.12 Example for use Advanced Copy function

The following methods are available as the Advanced Copy function.

• OPC (One Point Copy)

One Point Copy (OPC) is a function that copies data in the volume (copy source) to another volume in the same device (copy destination) at a specific point in time. OPC is suitable for the following usages.

• Making backup

• Making replicas

• Restoration from the backup data (restoration after replacing a disk drive when the copy source disk drive has failed)

• QuickOPC

QuickOPC copies all data as initial copy as OPC. After the initial copy has completed, only updated data (differential data) need to be copied hereafter. QuickOPC is suitable for the following usages.

• Making backup for less updated data

• Making system test data replication

• Restoration from the backup (restoration after replacing a disk drive when the copy source disk drive has failed)

Volume

Conventional Backup

Reduction of Backup Time Using Advanced Copy

→ Time

OperationOperation

→ Time

OperationOperation

Backup Process (System Down Time)

System Down Time

Reduce the system down time by using the high-speed backup with Advanced Copy function

Backup Software

ETERNUS SF AdvancedCopy Manager

Disk Backup Function Tape Backup Function

Using Advanced Copy

Volume

Backup Volume

Tape Tape

Chapter 1 Overview

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

• SnapOPC

Unlike OPC, the SnapOPC just records changes as the data is updated. SnapOPC is suitable for the following usages.

• Making temporary backup for tape backup

• Backup for less updated data

• SnapOPC+

As updates occur in the source data, SnapOPC+ saves the pre-change for each affected generation level. Registering standby storage areas in the SDP allows SnapOPC+ copy sessions to continue even when the amount of update data exceeds the copy destination capacity. SnapOPC+ is suitable for the following usages.

• Making temporary backup for tape backup

• Backup for less updated data (generation management is available)

• EC (Equivalent Copy)

EC makes a mirror copy of the copy source to the copy destination beforehand, then suspends the copy and treats all data as independent data. When copying is Resumed, only updated data in the copy source is copied to the copy destination. If the copy destination data has been changed, copy the copy source data again. EC is suitable for the following usages.

• Making backup

• Making system test data replication

1.3.4 RAID Migration

RAID migration is a function that transfers a volume to a different RAID group with the data integrity being guaranteed. By using RAID migration, RAID levels and volumes can be hot switched. This allows easy redistribution of volumes among RAID groups in response to customer needs. RAID migration can be carried out while the system is running, and may also be used to switch data to a different RAID level changing from RAID5 to RAID1+0, for example.

The example of RAID migration is as follows:

1.3 Functions

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

• Example when transferring volumes from a RAID5(3+1) 146GB disk configuration to a RAID5(3+1) 300GB disk configuration:

Figure 1.13 Example for use RAID Migration 1

• Example when volumes transferred from a RAID5(3+1) configuration to a different RAID level, RAID1+0(3+3), configuration:

Figure 1.14 Example for use RAID Migration 2

RAID5 (3+1)

Unused 300GB 4 RAID5(3+1)

146GB 146GB 146GB 146GB

300GB 300GB 300GB 300GB 300GB 300GB 300GB 300GB

146GB 146GB 146GB 146GB

Unused 146GB 4

LUN0 438GB

LUN1 300GB

LUN2 162GB

LUN0 438GB

LUN1 146GB

Migrate to another RAID group

Migrate to another RAID group and add the capacity

Define LUN2 additionally in the surplus space

RAID5 (3+1)

Unused 146GB 6 RAID1+0 (3+3)

146GB 146GB 146GB 146GB

146GB 146GB 146GB

146GB 146GB 146GB 146GB

Unused 146GB 4

LUN0 438GB

Migrate to another RAID group

LUN0 438GB

Chapter 1 Overview

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

1.3.5 Logical Device Expansion (LDE)

Logical Device Expansion (LDE) allows the capacity of an existing RAID group to be dynamically extended by the addition of extra disk drives. By using LDE to extend the capacity of existing RAID group in this way, new volume can be added without having to add new RAID groups, as used to be the case.

The following shows the example when RAID5(3+1) 146GB configuration converted to a RAID5(4+1) configuration by the addition of an extra disk.

Figure 1.15 Example for use Logical Device Expansion

146GB 146GB 146GB 146GB

RAID5 (4+1)

RAID5 (3+1)

146GB 146GB 146GB 146GB 146GB

146GB

LUN0 292GB

LUN1 146GB

Unused

LUN0 292GB

LUN1 146GB

LUN2 146GB

1.3 Functions

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

1.3.6 LUN Concatenation

LUN concatenation is a function that is used to add new area to a volume and so expand the volume capacity available to the server. This function enables the reuse of no longer required volumes or leftover free area in a RAID group and can be used to solve capacity shortages.

The following shows the example when concatenating unused areas of different RAID groups to create a new volume.

Figure 1.16 Example for use LUN Concatenation

RAID5 (3+1)

146GB 146GB 146GB 146GB 146GB 146GB 146GB 146GB

RAID5 (3+1)

LUN0 292GB

LUN1 146GB

RAID5 (3+1)

146GB 146GB 146GB 146GB 146GB 146GB 146GB 146GB

RAID5 (3+1)

LUN0 292GB

LUN1 146GB

146GB unused

292GB unused

LUN2 438GB

Chapter 1 Overview

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

1.3.7 Security Functions

ETERNUS2000 possesses functions that allow numbers of volumes, that can be recognized by a server, to be expanded or restricted by adjusting how the logical units (LUN) seen by the host correspond to the volumes within the storage system. "LUN mapping function" and "Host Affinity function" are available as security functions.

• LUN Mapping function

LUN mapping is used to set the relationship between the logical units (LUN) of the host and the volumes of the device, on a per device port basis.

Figure 1.17 LUN Mapping function

By specifying different LUN mapping per port, it is possible to set the volumes that can be accessed for each server.

LUN#00

Volume#00

Volume#7F

Volume#80

Volume#FF

Server A

ETERNUS2000

LUN#7F

LUN#00

Server B

LUN#7F

LUN#00 = Volume#00

LUN#7F = Volume#7F

LUN#00 = Volume#80

LUN#7F = Volume#FF

Port

1.3 Functions

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

• Host Affinity function

The Host Affinity function sets the "Host Affinity Group" to be applied for each server. "Host Affinity Group" defines the relationship between the host logical units (LUN) and the device logical volumes. Multiple settings are available. Host Affinity function uses WorldWideName (WWN) or iSCSI name for the Fibre Channel card in the server to recognize the server.

Figure 1.18 Host Affinity function

When multiple servers access the device using the same port, this allows corresponding different LUNs and volumes per server.

Switch

Apply Host Affinity Group#00 for access from WWN#A (=Server A) or WWN#B (=Server B)

Apply Host Affinity Group #01 for the access from WWN#C (=Server C)

ETERNUS2000

Volume#00

Volume#7F

LUN#00

LUN#7F

Host Affinity Group #00

Host Affinity Group #01

Server A

WWN#A

Server B

WWN#B

Server C

WWN#C

LUN#00 = Volume#00

LUN#7F = Volume#7F

LUN#00 = Volume#80

LUN#7F = Volume#FF

Volume#80

Volume#FF

LUN#00

LUN#7F

Port

Chapter 1 Overview

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

1.3.8 ECO mode

Using ECO mode allows the spindle rotation of the disk drive to be stopped for specified amount of time to reduce power consumption. The schedule for operating the spindle rotation of the disk drive can be set for each RAID group.

Figure 1.19 Setting example for ECO mode schedule

ETERNUS2000

Data Volume Twenty-four 300GB SAS disks RAID1+0

Backup Volume Twenty-four 500GB Nearline SAS disks RAID5

(12:00 to 24:00)

(0:00 to 12:00)

OffOff12On

Activate the whole system between 0:00 to 5:00

Backup

1.3 Functions

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

This page is intentionally left blank.

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

Chapter 2

Hardware

This chapter describes the hardware components of the ETERNUS2000 and standard operations.

2.1 Components

This section describes the components of the various form factors.

2.1.1 Controller Enclosure

The controller enclosure contains disk drives installed in the front, and controller modules, fans, power supplies (with fans), and batteries (with fans) in the rear.

2.1.1.1 Front view (with front cover)

Figure 2.1 Front view of controller enclosure (with front cover)

Lock

This locks the front cover of the device. Keep the front cover key in a safe place.

Power switch

Used to turn the device ON and OFF.

POWER LED

Glows green when the power is turned on.

READY LED

Glows green when device is available for use.

FAULT LED

Glows orange when an internal device part abnormality has been detected.

CACHE LED

Glows green when there is data in the device cache. Blinks when a power failure has occurred and the cache data is being maintained by the battery.

2.1 Components

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

2.1.1.2 Front view (without front cover)

Figure 2.2 Front view of controller enclosure (without front cover)

■ Disk drive slot numbers

Figure 2.3 shows the slot number of each disk drive.

Figure 2.3 Disk drive slot numbers (controller enclosure)

Disk Drive

Up to 12 disk drives can be installed.

DISK STATUS LED

Glows or blinks green when disk drives are operating normally. Glows orange when a disk drive has failed.

AUTO POWER Switch

Enables the AC Auto-Link Mode (This function automatically turns on the linked device once AC power is supplied). This switch is set to "off" as the factory setting.

IP RESET Switch

Click once to switch LAN port communication from the current controller to the other controller. Click twice in succession within a two second interval to revert the IP addresses to their factory settings.

Slot#0

Slot#4

Slot#8

Slot#1

Slot#5

Slot#9

Slot#2

Slot#6

Slot#10

Slot#3

Slot#7

Slot#11

Chapter 2 Hardware

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

2.1.1.3 Rear view

Figure 2.4 Rear view of controller enclosure

■ Controller (CM) Closeups

• Fibre Channel type

Figure 2.5

shows a closeup of the rear panel of a Fibre Channel type controller.

Figure 2.5 Fibre Channel type controller (rear view closeup)

Controller (CM#0) Each controller has one processor and cache memory. This is an example of the Fibre Channel type.

Controller (CM#1) Each controller has one processor and cache memory. This is an example of the Fibre Channel type.

Power Supply Unit

(PSU#0)

Inlet Power cord connects here.

Power Supply Unit (PSU#1)

FAN or Battery Unit Fan or battery unit (optional) is installed here. By default, the battery unit is installed in the top and the fan or the battery unit (optional) is installed in the bottom.

Inlet Power cord connects here.

MASTER LED

Glows green when LAN port is available.

UNIT READY/FAULT LED

Glows green during normal operation. Glows orange during the post power on initialization phase. Also glows orange to indicate a fault has been detected.

FC LINKUP/FAULT LED

Glows green when link has been established. Glows orange when a fault has been detected in the Fibre Channel port.

SAS (DE) LINKUP LED

Glows green when link has been established.

Fibre Channel ports 1 (left), 0 (right)

Dual LC connectors for Fibre Channel cables.

SAS (OUT) port

Connector for a miniSAS cable Used to connect the controller enclosure to a drive enclosure.

LAN port (10BASE-T/100BASE-TX) (RMT port (left), MNT port (right))

RJ45 connectors for Cat-5 twisted pair LAN cables Each controller has two such ports.

LINK LED

Glows green when link has been established.

ACT LED

Glows green when data is being sent and received.

PWC port

Used for power control.

2.1 Components

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

• iSCSI type

Figure 2.6

shows the closeup of the controller of the iSCSI type.

Figure 2.6 iSCSI type controller (rear view closeup)

MASTER LED

Glows green when LAN port is available.

UNIT READY/FAULT LED

Glows green during normal operation. Glows orange during the post power on initialization phase. Also glows orange to indicate a fault has been detected.

SAS (DE) LINKUP LED

Glows green when link has been established.

iSCSI ports 1 (left), 0 (right)

RJ45 connectors for LAN cables (twisted pair cable compatible with Enhanced Category 5).

SAS (OUT) port

Connector for a miniSAS cable Used to connect the controller enclosure to a drive enclosure.

LAN port (10BASE-T/100BASE-TX) (RMT port (left), MNT port (right))

RJ45 connectors for Cat-5 twisted pair LAN cables Each controller has two such ports.

LINK LED

Glows green when link has been established.

ACT LED

Glows green when data is being sent and received.

PWC port

Used for power control.

FAULT LED

Glows orange during the post power on initialization phase. Also glows orange to indicate a fault has been detected in the iSCSI port.

LINK LED

Glows green when link has been established.

Chapter 2 Hardware

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

• SAS type

Figure 2.7

shows the closeup of the controller of the SAS type.

Figure 2.7 SAS type controller (rear view closeup)

MASTER LED

Glows green when LAN port is available.

UNIT READY/FAULT LED

Glows green during normal operation. Glows orange during the post power on initialization phase. Also glows orange to indicate a fault has been detected.

SAS (HOST) LINKUP/FAULT LED

Glows green when link has been established. Glows orange when a fault has been detected in the SAS port.

SAS (DE) LINKUP LED

Glows green when link has been established.

SAS ports 1 (left), 0 (right)

miniSAS (SFF8088) connectors for miniSAS cables

SAS (OUT) port

Connector for a miniSAS cable. Used to connect the controller enclosure to a drive enclosure.

LAN port (10BASE-T/100BASE-TX) (RMT port (left), MNT port (right))

RJ45 connectors for Cat-5 twisted pair LAN cables Each controller has two such ports.

LINK LED

Glows green when link has been established.

ACT LED

Glows green when data is being sent and received.

PWC port

Used for power control.

2.1 Components

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

■ Other LEDs

Figure 2.8 shows the other LEDs.

Figure 2.8 Other controller LEDs (rear view closeup)

■ Battery unit notes

Notes about battery unit is as follows:

POWER STATUS LED

Glows green when AC power is supplied (power cord is connected) and DC power is turned on. Blinks green when AC power is supplied (power cord is connected) but DC power is turned off. Glows orange to indicate a fault has been detected.

BATTERY UNIT STATUS LED or FAN STATUS LED

Glows green when battery or fan status is normal. Glows orange to indicate a fault has been detected. Blinks green when the battery charge is less than 30%.

POWER STATUS LED

CAUTIO

AC power supply recovery after power failure does not automatically start the battery recharge process until the ETERNUS2000 is also turned on. As the contents of the cache memory will clear as soon as the battery is fully drained, the ETERNUS2000 must be turned on immediately following AC power supply recovery, or the AUTO POWER switch may be set to ON instead.

Chapter 2 Hardware

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

MPORTAN

• If a power failure is detected, data in the cache memory is saved for up to 48 hours when the battery is fully charged and for up to 96 hours when additional battery is also fully charged. After AC power supply recovery, the battery recharge process starts as soon as the ETERNUS2000 is turned back on. It takes up to six hours to fully charge the battery.

• If a power failure lasts for more than 20ms, data in the cache memory is saved using the battery. If the power failure ends within 20ms, the operation can be continued.

• When a power failure is detected, a buzzer will sound for 30 seconds. If this occurs, make sure that the power cord has not been accidentally unplugged.

• If the remaining power of the installed battery is less than 30 percent, or a battery unit fails, performance may be degraded temporarily.

• The ETERNUS2000 uses a Nickel-Metal Hydride battery. The cache memory data retention period during power failure shortens depending on the remaining battery power. The battery is charged automatically during ETERNUS2000 operation, but if left unattended without operating for an extended period of time, the battery power remaining will decrease gradually by self-discharge. Make sure to operate the ETERNUS2000 for more than one to two hours every one to two months in order to charge the battery.

• Turn on or off the ETERNUS2000 by power switch or battery control device. If the ETERNUS2000 is turned off in a way other than previously described, the battery is charged and discharged. This shortens the replacement cycle and the battery may need to be replaced earlier than expected.

2.1 Components

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

2.1.2 Drive Enclosure

The drive enclosures contain disk drives installed in the front, and power supplies (with fans), expanders, and fans.

2.1.2.1 Front view (with front cover)

Figure 2.9 Front view of drive enclosure (with front cover)

Lock

This locks the front cover of the device. Keep the front cover key in a safe place.

POWER LED

Glows green when the power is turned on.

READY LED

Glows green when device is available for use.

FAULT LED

Glows orange when a component error has been detected.

Power switch

Used to turn the device ON.

Chapter 2 Hardware

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

2.1.2.2 Front view (without front cover)

Figure 2.10 Front view of drive enclosure (without front cover)

■ Slot number of disk drives

Figure 2.11 shows the slot number of disk drives.

Figure 2.11 Slot number of disk drives (drive enclosure)

Disk Drive

Up to 12 disk drives can be installed.

DISK STATUS LED

Glows or blinks green when disk drives are operating normally. Glows orange when a disk drive has failed.

AUTO POWER Switch

Enables the AC Auto-Link Mode (This function automatically turns on the linked device once AC power is supplied). This switch is off as the factory setting.

Slot#0

Slot#4

Slot#8

Slot#1

Slot#5

Slot#9

Slot#2

Slot#6

Slot#10

Slot#3

Slot#7

Slot#11

2.1 Components

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

2.1.2.3 Rear view

Figure 2.12 Rear view of drive enclosure

■ Closeup of expander

Figure 2.13 shows closeup of the expander.

Figure 2.13 Expander (Closeup)

Expander (EXP#0)

A Unit that controls the interaction between the controller module and disk drives.

Expander (EXP#1)

A Unit that controls the interaction between the controller module and disk drives.

Power Supply Unit

(PSU#0)

Fan

Inlet

Power cord connects here.

Power Supply Unit (PSU#1)

Inlet

Power cord connects here.

SAS LINKUP LED

Glows green when link has been established.

UNIT READY/FAULT LED

Glows green during normal operation. Glows orange during the post power on initialization phase. Also glows orange to indicate a fault has been detected.

SAS (OUT) port

miniSAS cable connects here.

SAS (IN) port

miniSAS cable connects here.

This is not used.

Chapter 2 Hardware

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

■ Other LEDs

Figure 2.14 shows other LEDs.

Figure 2.14 LEDs in the rear side of the controller enclosure

POWER STATUS LED

FAN STATUS LED

Glows green when the fan is in normal status. Glows orange when an abnormality is detected.

POWER STATUS LED

2.1 Components

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

2.1.3 AC outlet box

There are two sizes of AC outlet box: 1U and 4U. 1U AC outlet box has four outlets and two inlets. 4U AC outlet box has twelve outlets and two inlets.

■ 1U

Figure 2.15 AC outlet box (1U)

■ 4U

Figure 2.16 AC outlet box (4U)

Inlet (INPUT)

Power supply code (AC Input cable) connects here.

Outlet (OUTPUT)

Power supply code (AC output cable) connects here.

Main line switch

Inlet

Power supply code (AC Input cable) is attached here.

Outlet (OUTPUT)

Power supply code (AC output cable) is attached here.

Main line switch

Chapter 2 Hardware

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

2.2 Standard Operations

This section explains how to turn the device on and off, and how to attach and remove the front cover.

2.2.1 Power ON Control

This section describes the procedure to turn the power on.

rocedure

1 Press the power switch ( ) of the controller enclosure.

Controller enclosure POWER LED turns on.

Note:

When drive enclosures are installed, the power turns on automatically.

2 After a few minutes, check that controller enclosure’s READY LED is lit up.

MPORTAN

• After turning the power on, it takes about 4 minutes for the device to become READY (i.e. the READY LED turns on). If an error is detected during the initial power-on diagnostic phase, a longer time (up to ten minutes) may be required before the READY LED turns on.

• Before turning the server on, check that the device, Fibre Channel switch, and Fibre Channel hub are all READY. If the server is turned on while any of these devices are not READY, the server will not be able to recognize the device.

Controller enclosure

Drive enclosure 1

Drive enclosure 2

Drive enclosure 3

Drive enclosure 4

Drive enclosure 5

Drive enclosure 6

Drive enclosure 7

Drive enclosure 8

Drive enclosure 9

Power switch

2.2 Standard Operations

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

3 Check that all enclosure’s POWER LED and READY LED are lit up.

Controller enclosure

Drive enclosure 1

Drive enclosure 2

Drive enclosure 3

Drive enclosure 4

Drive enclosure 5

Drive enclosure 6

Drive enclosure 7

Drive enclosure 8

Drive enclosure 9

LED for

controller enclosure

LED for

drive enclosure

Chapter 2 Hardware

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

2.2.2 Power OFF Control

This section describes the procedure to turn the power off.

rocedure

1 Press and hold the console panel's power switch ( ) for 4 seconds or longer.

2 The device power is turned off.

When the power is turned off, the POWER LED will go out.

Note:

When drive enclosures are installed, the power turns off automatically.

MPORTAN

• When turning off the device, the power shuts off only after the data in the cache memory has been written to the hard disk drive. Therefore, it can take five minutes for the power supply to be completely turned off.

• Do not turn off the power of the device or network devices that connect the ETERNUS2000 and server while the server is operating. Turning the power off may result in the loss of data or prevent data from being saved.

Controller enclosure

Drive enclosure 1

Drive enclosure 2

Drive enclosure 3

Drive enclosure 4

Drive enclosure 5

Drive enclosure 6

Drive enclosure 7

Drive enclosure 8

Drive enclosure 9

Power switch

2.2 Standard Operations

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

2.2.3 Attaching and Removing the Front Cover

This section explains how to attach and remove the front cover.

Perform the following procedure to remove the front cover:

Note:

This section explains how to attach and remove the front cover for the controller enclosure. Perform the same procedure to attach and remove the front cover for the drive enclosure.

■ Attaching the front cover

Attach the front cover in the following order.

1 Insert the front cover key and turn it 90° counterclockwise.

2 Fit the front cover on the left end slot of the controller enclosure to attach.

CAUTIO

After completing the operation, be sure to reattach the front cover.

Front cover key

Slot

Chapter 2 Hardware

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

3 Lock the front cover.

Press the front cover lock and turn the key 90° clockwise.

■ Removing the front cover

Remove the front cover in the following order.

1 Unlock the front cover lock.

Press the front cover lock and turn the key 90° counterclockwise.

2 Pull the front cover toward you to remove it.

Front cover key

WARNING

Make sure to hold the cover when unlocking to prevent it from falling.

Front cover key

2.3 Flow from Installation to Operation

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

2.3 Flow from Installation to Operation

This section explains the flow of work from installation to the start of ETERNUS2000 operation. Contact your sales representative or maintenance engineer to perform the device installation and setup, or follow the work flow shown below to perform the device installation and setup by yourself:

(to next page)

Preparation

Prepare and check the following items:

- Acquire IP address (for ETERNUS2000 and PC for maintenance engineer) and check the subnet mask

- Prepare a web browser and install Java Runtime Environment

- Prepare network devices such as a switching hub

The following manuals will be required.

"ETERNUS2000 models 100 and 200 disk storage system Safety Precautions" "ETERNUS2000 models 100 and 200 disk storage system Package Contents" "ETERNUS disk storage systems ETERNUSmgr Install Guide" "ETERNUS disk storage systems ETERNUSmgr User Guide -Introduction-" "ETERNUS2000 ETERNUSmgr User Guide -Settings/Maintenance-" "ETERNUS8000, ETERNUS4000, ETERNUS2000 disk storage system Server Connection Guide"

Refer to "ETERNUS2000 models 100 and 200 disk storage system Package Contents" and check that there are no missing parts.

Installation

"3.2 Rack Installation"

Attach the rack mount kit to the rack and install the ETERNUS2000.

Standard Connection

"4.2 Cable Connection"

Connect the following cables.

- LAN cable (twist pair cable compatible with Category 5) (For operation management)

- Fibre Channel cable (For the Fibre Channel type)

- LAN cable (twist pair cable compatible with enhanced Category 5) (For the iSCSI type)

- miniSAS cable (For the SAS type)

- miniSAS cable (For connecting drive enclosures)

- Power cords

IMPORTANT

"4.1 Prior Preparation"

Preparation

Installation Location Requirements

Check the required space for the ETERNUS2000, conditions and environment for the location, and the number of power cords and the shape of the connector.

"3.1 Preparation"

Package Contents Check

Chapter 2 Hardware

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

(from previous page)

"4.3.1 Basic Setup"

"4.3 ETERNUS2000 Setup"

Perform the device settings. Prepare and check the following items.

- Enter the IP Address and Subnet Mask into the Network Setting Label

- Attach the Network Settings sticker to the Rear Upper Central Label Plate

- Connect the PC and the ETERNUS2000 via LAN Cable (twisted pair cable compatible with Category 5)

- Network Setting for PC

- Web Browser Setting

- Power on the Device

Device Settings (Preparation)

When setting the AC Auto Interlocking mode, turn on the AUTO POWER Switch of the controller enclosure and drive enclosure.

"4.3.3 AC Automatic Linkage Mode Setup"

AC Auto Interlocking Mode

"4.3.2 Advanced Copy Setup"

Advanced Copy Setting

Device Settings (Basic Settings)

Perform the basic settings with Tutorial in setting/maintenance program.

- Network Environment settings

- Device Environment Settings

- Hot Spare Disk Registration

- RAID Group Creation

- Volume Creation

- Host Affinity Group Creation

Perform the following settings (as required).

Other Settings

"4.4 Installing and Setting up ETERNUSmgr"

When monitoring the ETERNUS2000 using the ETERNUSmgr, install ETERNUSmgr on the management server, and perform any required settings.

Installing and Setting ETERNUSmgr

Operation and Troubleshooting

"Chapter 6 Operation and Troubleshooting"

"4.6 Setting up the Server Connection"

Perform the settings required to connect to the server. Install the drivers and perform the Fibre Channel switch setting.

Settings for Connecting Server

"4.5 Maintenance Setup"

Perform the settings to simplify the maintenance (as required). When connecting the device and PRIMERGY to use the server monitoring tool "ServerView", perform the required settings for the SNMP Trap Transfer. When using the Remote Notice function, perform the required settings for connecting to the Fujitsu remote server.

Settings for Maintenance

2.3 Flow from Installation to Operation

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

This page is intentionally left blank.

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

Chapter 3

Installation

This chapter describes the ETERNUS2000 installation procedure. Before installing the device, make sure to check the "ETERNUS2000 disk storage system models 100 and 200 Safety Precautions".

3.1 Preparation

3.1.1 Placement Area

■ Installation area

Refer to the placement area of the rack to install the device.

■ Installation condition

Refer to "Instructions for installation" in "ETERNUS2000 disk storage system models 100 and 200 Safety Precautions" and set the device in a location where all the requirements are satisfied.

MPORTAN

The speed of the ETERNUS2000 fans is stepped up and down in response to the ambient temperature. Up to 25°C the noise level should not exceed about 42dB, but higher temperatures or abnormal fan situations can result in noise levels over 42dB, and seclusion in a dedicated server room is generally recommended.

3.1 Preparation

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

3.1.2 Check the number of wall outlets

Check the required type and number of the wall outlets.

■ Type of wall outlet connectors

All ETERNUS2000 device types include US spec. AC200-240V cables (with plug) as standard. In addition, power cords must comply with the particular safety standards of the country of use. In some cases, a power cord will need to be purchased locally to satisfy the relevant power safety requirements.

Table 3.1 Wall outlets and cable lengths

■ Required Number of Power Outlets

• ETERNUS2000 model 100

Table 3.2 Required number of Power Outlets (ETERNUS2000 model 100)

Point

When determining the rack-mounting layout, consider the interaction between the position of each drive enclosure and AC outlet box in the rack and the length of each cable. For example, for something installed at the top of a 1,800mm rack, about 2m of cable will be required to reach the bottom of the rack.

Cable type ETERNUS2000

connector

Power outlet con-

nector

Cable length

Note

Controller Enclosure Drive Enclosure AC200V outlet box (1U)

IEC320 C13 NEMA L6-15P 4m Max. rating: 250V 15A

(Normal usage <12A)

AC200V outlet box (4U)

Direct connection NEMA L6-20P 4m Max. rating: 250V 20A

(Normal usage <16A)

Component Combination pattern

Controller Enclosure 1 1 1

Drive Enclosure 0 1 0 − 1

AC Outlet Box 0 0 1

No. of power outlets 2 4 2

Chapter 3 Installation

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

• ETERNUS2000 model 200

• AC Outlet Boxes Not Connected

Table 3.3 Required number of power outlets

(ETERNUS2000 model 200 when AC outlet boxes are not connected)

• AC Outlet Boxes Connected

Table 3.4 Required number of power outlets

(ETERNUS2000 model 200 when AC outlet boxes are connected)

Component Combination pattern

Controller Enclosure 1 1 1 1 1 1 1 1 1 1

Drive Enclosure 0 1 2 3 4 5 6 7 8 9

AC Outlet Box 0000000000

No. of power outlets 2 4 6 8 10 12 14 16 18 20

Component Combination pattern

Controller Enclosure1111111

Drive Enclosure 0 − 12 − 34 − 56 − 78 − 90 − 56 − 9

AC Outlet Box (1U) 12345−−

AC Outlet Box (4U) −−−−−12

No. of power outlets24681024

3.2 Rack Installation

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

3.2 Rack Installation

This section describes the procedure for installing the ETERNUS2000 in a rack.

Make sure to check "ETERNUS2000 models 100 and 200 disk storage system Safety Precautions" before installation. Also refer to the manual provided with racks.

■ Rack installation example

Install the controller enclosure, drive enclosures and the AC outlet box in the following layout.

*1: This is an example for installing two 4U size AC outlet boxes. A maximum of five AC outlet boxes can be

installed for a 1U size AC outlet box.

CAUTIO

• Before starting, make sure to attach a wrist strap or touch the metal frame of the device to eliminate static electricity. Failure to discharge static electricity may cause device failure.

• If components are attached or removed in a way other as described herein, damage and/or device failure or electrical shock may occur.

• This device contains delicate components, and should be handled gently. Do not drop or knock the device against the rack when installing it.

• If no other components are installed, attach the blind panels provided with the rack.

Controller enclosure

Drive enclosure 1

Drive enclosure 2

Drive enclosure 3

Drive enclosure 4

Drive enclosure 5

Drive enclosure 6

Drive enclosure 7

Drive enclosure 8

Drive enclosure 9

AC outlet box (4U) (*1)

Chapter 3 Installation

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

3.2.1 Installing Controller Enclosure

This section describes how to mount the controller enclosure in a rack.

1 Refer to "ETERNUS2000 models 100 and 200 disk storage system Package

Contents" to confirm there are no missing parts for the rack mount kit.

2 Adjust the bracket sizes to fit the rack.

Reposition the M4 screws to adjust the length of the brackets to match the distance between the front and rear rack pillars. Leave the M4 screws slightly unscrewed, as the bracket must be attached to the rack before they can be completely tightened.

3 Attach the bracket to the rack.

WARNING

Warnin

For these operations, be sure to turn off the device connected to the ETERNUS2000 (such as servers) when it is turned on, and remove the power cord from the outlet or it may lead to electronic shock.

CAUTIO

o N

Do not move disk drives where RAID group, volume and hot spares are set to another group.

Point

• When the holes in the rack pillars are square, use the screw holders to attach.

• Attach brackets to the outside as far apart as possible.

Distance Between Front and Rear Rack Pillars

M4 screws

Bracket L

3.2 Rack Installation

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

The four M5 screw positions for the brackets and holders are determined relatively to the base line of controller enclosure. The M5 screws should be inserted in the 1st and 3rd holes above the base line.

4 Tighten the screws that were moved in Step 2.

5 Remove the front cover of the controller enclosure.

Refer to "2.2.3 Attaching and Removing the Front Cover" (page 40) for procedure to remove the front cover.

6 Install the controller enclosure in the rack.

CAUTIO

When installing or removing the controller enclosure to or from the rack, contact your sales representatives or maintenance engineer.

(Front rack pillars)

(Rear rack pillars)

Bracket R

Bracket L

Screw holders

M5 screws

Screw holders

M5 screws

(Front rack pillars) (Rear rack pillars)

Brackets

Base line of controller enclosure

1st position

(M5 screws)

3rd position (M5 screws)

Brackets

Base line of controller enclosure

1st position

(M5 screws)

3rd position (M5 screws)

Chapter 3 Installation

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

7 Fix the controller enclosure in the rack.

Fix the controller enclosure in the rack with hand screws in front of the controller enclosure.

8 Replace the front cover.

Refer to "2.2.3 Attaching and Removing the Front Cover" (page 40) for procedure to replace the front cover.

(Rear rack pillars)

Thumb screw

3.2 Rack Installation

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

3.2.2 Installing Drive Enclosure

This section describes how to install the drive enclosure in a rack.

Make sure to check the "ETERNUS2000 disk storage system models 100 and 200 Safety Precautions" before installation. Also notes the following.

WARNING

Electrical Shock

For these operations, be sure to turn off the device connected to the ETERNUS2000 (such as servers) when it is turned on, and remove the power cord from the outlet or it may lead to electronic shock.

CAUTIO

o N

Do not move disk drives where RAID group, volume and hot spares are set to another group.

Make sure to install drive enclosure on the controller enclosure

MPORTAN

When installing multiple drive enclosures, install them on the controller enclosure in order of the "DE_No. label" attached on the drive enclosure. The "DE_No. label" is attached in the following location.

DE_No. label

At the right side of the

front of the drive enclosure

Under the power unit (PSU#0) at

the rear of the drive enclosure

DE_No. label

Chapter 3 Installation

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

1 Refer to "ETERNUS2000 models 100 and 200 disk storage system Package

Contents" to confirm there are no missing parts for the rack mount kit.

2 Adjust the bracket sizes to fit the rack.

3 Attach the bracket to the rack.

The four M5 screw positions for the brackets and holders are determined relative to the AC outlet box base line. The M5 screws should be inserted in the 1st and 3rd holes above the base line.

Point

• When the holes in the rack pillars are square, use the screw holders to attach.

• Attach brackets to the outside as far apart as possible.

Distance Between Front and Rear Rack Pillars

M4 screws

Bracket L

(Front rack pillars)

(Rear rack pillars)

Bracket R

Bracket L

Screw holders

M5 screws

Screw holders

M5 screws

(Front rack pillars) (Rear rack pillars)

Brackets

Base line of controller enclosure

1st position

(M5 screws)

3rd position (M5 screws)

Brackets

Base line of controller enclosure

1st position

(M5 screws)

3rd position (M5 screws)

3.2 Rack Installation

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

4 Tighten the screws that were moved in Step 2.

5 Remove the front cover of the drive enclosure.

Refer to "2.2.3 Attaching and Removing the Front Cover" (page 40) for procedure to remove the front cover.

6 Install the drive enclosure in the rack.

7 Fix the drive enclosure in the rack.

Fix the drive enclosure in the rack with hand screws in front of the controller enclosure.

8 Replace the front cover.

Refer to "2.2.3 Attaching and Removing the Front Cover" (page 40) for procedure to replace the front cover.

CAUTIO

When installing or removing the controller enclosure to or from the rack, contact your sales representatives or maintenance engineer.

(Rear rack pillars)

Thumb screw

Chapter 3 Installation

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

3.2.3 Installing AC Outlet Box

This section describe how to mount the AC outlet box in the rack.

Make sure to check the "ETERNUS2000 models 100 and 200 disk storage system Safety Precautions" before installing the AC outlet box. Also, note the following.

3.2.3.1 For 1U AC outlet box

This section describes how to mount the 1U AC outlet box in a rack.

1 Refer to "ETERNUS2000 models 100 and 200 disk storage system Package

Contents" to confirm there are no missing parts for the rack mount kit.

2 Attach the brackets and holders to the rack.

WARNING

Electrical Shock

For these operations, be sure to turn off the device connected to the ETERNUS2000 (such as servers) when it is turned on, and remove the power cord from the outlet or it may lead to electronic shock.

CAUTIO

AC outlet box cannot be connected to the device other than ETERNUS2000.

Point

When the holes in the rack pillars are square, use the screw holders to attach.

(Rear rack pillars)

Bracket B

Screw holders

M6 screws

Screw holders

Bracket A

Holder

M6 screws

3.2 Rack Installation

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

The four M6 screw positions for the brackets and holders are determined relative to the AC outlet box base line. The M6 screws should be inserted in the 1st and 3rd holes above the base line.

3 Mount the AC outlet box in the rack.

Fasten the AC outlet box to the bracket with two M3 screws.

4 Attach the blind cover plate to the front side of the rack.

The blind cover plate should be attached at the same height as the AC outlet box.

1 Attach nuts to the rack pillars.

The nuts should be inserted in the 2nd holes above the AC outlet boxes base line. The following shows the example when the holes in the rack pillars are square.

Point

When the holes in the rack pillars are circle, use the U-type chimney nuts to attach. When the holes in the rack pillars are square, use the M5 cage nuts to attach.

(Rear rack pillers)

Base line of AC outlet box

3rd position

(M6 screws)

1st position

(M6 screws)

Brackets

(Rear rack pillars)

screws

(Front rack pillars)

Base line of AC outlet boxes

2nd position

(M5 cage nuts)

Chapter 3 Installation

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

2 Attach the blind cover using two black M5 screws to the rack pillars.

3.2.3.2 For 4U AC outlet box

This section describes how to mount the 4U AC outlet box in a rack.

1 Refer to "ETERNUS2000 models 100 and 200 disk storage system Package

Contents" to confirm there are no missing parts for the rack mount kit.

2 Attach the ACS plate to the rack.

Rear rack pillars

Front rack pillars

Blind cover plate

M5 screw

AC outlet box

MPORTAN

When installing an 4U size AC outlet box, 1U size is required for the bottom of the pillar to store cables.

Point

When the holes in the rack pillars are square, use the screw holders to attach.

(Rear rack pillars)

screws

ACS plate

screws

ACS plate

Screw holder

3.2 Rack Installation

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

The four M6 screw positions for the brackets and holders are determined relative to the AC outlet box base line. The M6 screws should be inserted in the 1st and 3rd holes above the base line.

3 Attach the rack nuts to the rack.

The eight rack nut should be inserted in the 2st and 5rd holes above the AC outlet box base line.

4 Mount the AC outlet box and the rack.

Fasten the AC outlet box to the pillars with eight M6 screws.

(Rear rack pillars)

Base line of AC outlet box

3rd position

(M6 screws)

1st position

(M6 screws)

(Rear rack pillars)

Base line of AC outlet box

Rack nut

ACS plate ACS plate

AC outlet box

Rack nut

2nd position

5th position

2nd position

5th position

2nd position

5th position

2nd position

5th position

(Rear rack pillars)

M6 screws

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

Chapter 4

Setup

This chapter explains how to setup the ETERNUS2000. You may contact your sales representative or your maintenance engineer to perform this steps, or alternatively perform them by yourself.

4.1 Prior Preparation

The following preparations are required before starting the ETERNUS2000 setup:

■ Network settings

Determine the following network settings:

❐ IP address and subnet mask for the ETERNUS2000's MNT port (required)

Default IP address: 192.168.1.1 Default subnet mask 255.255.255.0

❐ IP address and subnet mask for the ETERNUS2000's RMT port

No default value is set. This setting is required if the remote support connection is to be independent of the customer network.

❐ Gateway IP address

No default value is set.

❐ IP address for the PC

Prepare an IP address for the PC (FST: Field Support Terminal) used by your maintenance engineer.

CAUTIO

• Before starting, make sure to attach a wrist strap or touch the metal frame of the device to eliminate static electricity. Failure to discharge static electricity may cause device failure.

• When the disk drive is brought from a cold to a warm place, there is a chance that the change in temperature can result in condensation forming on the magnetic platters. Wait for the disk drives to warm up to the local ambient temperature before turning the ETERNUS2000 on.

4.1 Prior Preparation

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

■ Devices

Prepare the following device:

❐ PC

The initial settings are performed by using a Web browser running on a LAN connected PC. Prepare a PC installed with one of following Web browsers:

• Web browser

Microsoft® Internet Explorer 6.0 or later, Mozilla Firefox™ 1.5.0.10 or later, or Netscape 7.1 or later

• Software

Java Runtime Environment 5.0 (Update 11or later) or Java Runtime Environment 6.0 (Update 3 or later)

For details on the installation procedure of Java Runtime Environment, refer to "ETERNUS2000 ETERNUSmgr User Guide -Setting/Maintenance-".

❐ Networking equipment such as a switching hub

■ Related manuals

Prepare the following manuals:

❐ "ETERNUS disk storage systems ETERNUSmgr Install Guide" ❐ "ETERNUS disk storage systems ETERNUSmgr User Guide -Introduction-" ❐ "ETERNUS2000 ETERNUSmgr User Guide -Settings/Maintenance-" ❐ "ETERNUS8000, ETERNUS4000, ETERNUS2000 disk storage system Server Connection

Guide

❐ Other related manuals, for example, for a server or switch to be connected to the device.

■ Power related checks

Refer to "3.1.2 Check the number of wall outlets" (page 46) and check that the available power supply facilities meet the specified requirements.

❐ Number and specifications of the power outlets

Point

The ETERNUS2000 can be reset to the factory default network settings by pressing the Controller Enclosure's IP reset switch twice in succession within a two second interval.

Point

"ETERNUS2000 ETERNUSmgr User Guide -Setting/Maintenance-"

Chapter 4 Setup

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

■ Remote support operation checks

If the remote support connection is to be independent of the customer network, the following components will also be required:

❐ LAN cables x 2 (Cat-5 twisted-pair type) ❐ Routers and other networking equipment

Refer

"ETERNUS2000 ETERNUSmgr User Guide -Settings/Maintenance-"

4.2 Cable Connection

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

4.2 Cable Connection

Various cables now need to be connected.

4.2.1 LAN Cable Connection (Twist Pair Cable Compatible with Category 5) (for Operation Management)

This ETERNUS2000 must be connected to a LAN to perform settings or maintenance operations, for ETERNUSmgr to be used to monitor the device status, or when operating with remote support. Two 5m LAN cables are supplied with the ETERNUS2000.

Point

To help with cable management and prevent incorrect connections, attach labels to the cables and make a note of connection origins and destinations.

MPORTAN

• The ETERNUS2000 has two LAN ports (10BASE-T/100BASE-TX, MNT port and RMT port) for each controller.

- For device management via setting/maintenance program or ETERNUSmgr, use MNT port.

- For remote support operation, use MNT port or RMT port. For remote support on a different network to the customer network, use the RMT port as the remote support port. For remote support over the customer network, only the MNT port need be used.

- Operation using only the RMT port without the MNT port is not allowed.

• The ETERNUS2000 LAN ports operate by default in Auto-Negotiation mode, which recognizes 10BASE-T/100BASE-TX, and Full duplex / Half duplex automatically.

- When connecting networking equipment such as hubs and routers, check the specifications and settings of the equipment to be connected.

- When the LAN ports of the device to be connected operate in Auto-Negotiation mode, the communication mode is set by the specified algorithm.

- When the device cannot be recognized correctly, set both devices to be connected in Fix mode.

• When hub has Spanning Tree Protocol (STP) function and it is enabled, connection to the ETERNUS2000 may fail. If failed, disable the STP function.

- When STP function is not necessary for network configuration, disable the function for hub.

- When STP function is necessary for network configuration, disable the function for the connected port of hub.

Chapter 4 Setup

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

■ LAN cable connection procedure

The following explains how to connect the LAN cable. This example is for the Fibre Channel type. For the iSCSI type port locations, refer to "Figure 2.6 iSCSI

type controller (rear view closeup)" (page 28). For the SAS type port locations, refer to "Figure 2.7 SAS type controller (rear view closeup)" (page 29).

CAUTIO

• Before starting, make sure to attach a wrist strap or touch the metal frame of the device to eliminate static electricity. Failure to discharge static electricity may cause device failure.

• When connecting external (signal, power, etc.) cables, avoid pulling them as it may cause damage.

o N

• Do not bend the cable too much or bind it up. Doing so may cause device damage or failure.

o not bend square Do not bind up

Point

When connecting LAN cables, check the connector orientation and then firmly push it all the way in. When disconnecting LAN cables, depress the tab, then pull out the connector.

4.2 Cable Connection

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

1 Connect the LAN cable to the ETERNUS2000.

Connect the LAN cable connectors to the MNT ports of the controller 0 (CM#0) and controller 1 (CM#1) for the ETERNUS2000.

2 Connect the LAN cables to the networking equipment.

Connect the other end of the LAN cable to the networking equipment, such as hub or router. For more details, refer to the manuals of the network equipment that is to be connected to.

3 If the RMT ports are to be used, connect the LAN cables to RMT ports.

3-1 Connect the connector of the LAN cable to the RMT port of the controller 0 (CM#0)

and controller 1 (CM#1).

3-2 Connect the other end of the LAN cable to the networking equipment, such as hub or

router.

For more details, refer to the manuals of the network equipment that is to be connected to.

CAUTIO

• When connecting the LAN cables, position them so that they will not obstruct replacement of the power supply unit or controllers by the maintenance engineer.

Chapter 4 Setup

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

4.2.2 Fibre Channel Cable Connection (Fibre Channel Type)

Connect the ETERNUS2000 and the server or Fibre Channel switch with Fibre Channel cable. A 5m Fibre Channel cable is supplied for each Fibre Channel port.

CAUTIO

• Before starting, make sure to attach a wrist strap or touch the metal frame of the device to eliminate static electricity. Failure to discharge static electricity may cause device failure.

• When connecting external (signal, power, etc.) cables, avoid pulling them as it may cause damage.

• Before connecting Fibre Channel cables, confirm that the connectors are clean and free of dust, oil, and grease, etc.

CAUTIO

• Fibre Channel cable is thin and breaks easily, so be careful not to pinch the cable between devices or bend it too much. Keep a 30mm or larger radius when bending Fibre Channel cable. Failure to do so may cause device damage or failure.

30mm

or larger

90˚

Do not bend square Do not bind up

4.2 Cable Connection

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

■ Fibre Channel cable connection procedure

The following explains how to connect the Fibre Channel cable.

1 Remove the connector cover of Fibre Channel port.

Remove the connector cover attached to the Fibre Channel port of the controller 0 (CM#0) or controller 1 (CM#1).

2 Connect the Fibre Channel cable to the ETERNUS2000.

Connect the Fibre Channel cable connectors to the Fibre Channel ports of the controller 0 (CM#0) and controller 1 (CM#1) for the ETERNUS2000.

If any one of the Fibre Channel ports is to be used, it should be "0" on each CM.

Point

When connecting the Fibre Channel cable, check the direction of the connector tab and insert it all the way in firmly. When disconnecting the Fibre Channel cable, pull out the connector while holding its tab.

MPORTAN

Keep the removed connector cover in a safe place where they will not be lost.

Connector cover

Chapter 4 Setup

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

3 Connect the Fibre Channel cables to the server or the Fibre Channel switch.

Connect the other end of the Fibre Channel cable to the Fibre Channel adapter of the server or the Fibre Channel switch.

4.2.3 LAN Cable Connection (Twisted Pair Cable Compatible with Enhanced Category 5) (iSCSI Type)

Connect the ETERNUS2000 and the server or Fibre Channel switch with a LAN cable (twisted pair cable compatible with Enhanced Category 5). A 5m LAN cable is supplied for each iSCSI port.

CAUTIO

• When connecting the Fibre Channel cables, position them so that they will not obstruct replacement of the power supply unit or controllers by the maintenance engineer.

MPORTAN

• Separate the LAN used for iSCSI connection from other LAN.

• Operation mode of iSCSI is Full Duplex (FULL).

• When connecting to a server via switching hub, use the switching hub

that supports 1Gbps.

CAUTIO

• Before starting, make sure to attach a wrist strap or touch the metal frame of the device to eliminate static electricity. Failure to discharge static electricity may cause device failure.

• When connecting external (signal, power, etc.) cables, avoid pulling them as it may cause damage.

o N

• Do not bend the cable too much or bind it up. Doing so may cause a device damage or failure.

o not bend square Do not bind up

4.2 Cable Connection

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

■ LAN cable connection procedure

The following explains how to connect the LAN cable.

1 Connect the LAN cable to the ETERNUS2000.

Connect the LAN cable connectors to the iSCSI ports of the controller 0 (CM#0) and controller 1 (CM#1) for the ETERNUS2000.

If any one of the iSCSI ports is to be used, it should be "0" on each CM.

2 Connect the LAN cables to the server or the switching hub.

Connect the other end of the LAN cable to the LAN card / iSCSI HBA of the server or the switching hub. For details about connecting to the switching hub, refer to the user guide for the switching hub to be connected.

Point

When connecting LAN cables, check the connector orientation and then firmly push it all the way in. When disconnecting LAN cables, depress the tab, then pull out the connector.

CAUTIO

• When connecting the LAN cables, position them so that they will not obstruct replacement of the power supply unit or controllers by the maintenance engineer.

Chapter 4 Setup

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

4.2.4 MiniSAS Cable Connection (SAS Type)

Connect the ETERNUS2000 and server with miniSAS cables.

■ MiniSAS cable connection procedure

The following explains how to connect a miniSAS cable.

CAUTIO

• Before starting, make sure to attach a wrist strap or touch the metal frame of the device to eliminate static electricity. Failure to discharge static electricity may cause device failure.

• When connecting external (signal, power, etc.) cables, avoid pulling them as it may cause damage.

o N

• Do not bend the cable too much or bind it up. Doing so may cause a device damage or failure.

o not bend square Do not bind up

Point

When connecting miniSAS cables, check the connector orientation and then firmly push it all the way in. When disconnecting miniSAS cables, use the pull-tab to extract the connector.

miniSAS cable

tab

4.2 Cable Connection

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

1 Attach the miniSAS cables to the ETERNUS2000.

Insert the miniSAS cable connectors in the ETERNUS2000 controller 0 (CM#0) and controller 1 (CM#1) SAS ports.

If only one of a CM's SAS ports is to be used, it should be the "0" port.

2 Attach the miniSAS cables to the server.

Insert the other end of each miniSAS cable in one of the server's SAS adapters.

CAUTIO

• The SAS cables should be positioned so that they will not obstruct replacement of the power supply units or controllers by the maintenance engineer.

Chapter 4 Setup

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

4.2.5 MiniSAS Cable Connection (For Drive Enclosures)

When a Drive Enclosure is installed, connect the Drive Enclosure to the Controller Enclosure with a miniSAS cable. When multiple Drive Enclosures are installed (only for ETERNUS2000 model 200), connect the Drive Enclosures with miniSAS cable. Two miniSAS cables (75cm) are supplied with Drive Enclosure.

CAUTIO

• Before starting, make sure to attach a wrist strap or touch the metal frame of the device to eliminate static electricity. Failure to discharge static electricity may cause device failure.

• When connecting external (signal, power, etc.) cables, avoid pulling them as it may cause device damage.

o N

• Do not bend the cable too much or bind it up. Doing so may cause a device damage or failure.

o not bend square Do not bind up

4.2 Cable Connection

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

■ MiniSAS cable connection procedure

The following explains how to connect the miniSAS cable. This example is for the Fibre Channel type. For the iSCSI type SAS (OUT and IN) port locations, refer to

"Figure 2.6 iSCSI type controller (rear view closeup)" (page 28)

. For the SAS type SAS (OUT and IN)

port locations, refer to "Figure 2.7 SAS type controller (rear view closeup)" (page 29)

Point

• When connecting miniSAS cables, always check the symbols on the connector and port are matching. SAS (OUT): Attach the connector with the symbol to the port with

the symbol.

SAS (IN): Attach the connector with the symbol to the port with

the symbol.

• When connecting miniSAS cables, check the connector orientation and then firmly push it all the way in. When disconnecting miniSAS cables, use the pull-tab to extract the connector.

SAS (OUT)

Plug connecting to SAS (OUT) port

Controller Enclosure

Drive Enclosure

Plug connecting to SAS (IN) port

SAS (IN) port

miniSAS cable

tab

Chapter 4 Setup

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

1 Connect the Controller Enclosure to the Drive Enclosure with miniSAS cable.

1-1 Connect the SAS (OUT) port at controller 0 (CM#0) of Controller Enclosure, to the

SAS (IN) port at expander 0 (EXP#0) of the Drive Enclosure 1.

Connect the plug to be connected to SAS (OUT) port, to the SAS (OUT) port of the controller 0 (CM#0).

Connect the plug to be connected to SAS (IN) port, to the SAS (IN) port of the expander 0 (EXP#0).

1-2 Connect the SAS (OUT) port at controller 1 (CM#1) of Controller Enclosure, to the

SAS (IN) port at expander 1 (EXP#1) of the Drive Enclosure.

Connect the miniSAS cable in the same way as Step 1-1

Controller Enclosure

Drive Enclosure 1

4.2 Cable Connection

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

The following shows the miniSAS connection figure between Controller Enclosure and Drive Enclosure.

Figure 4.1 MiniSAS cable connection

(between the Controller Enclosure and Drive Enclosure)

2 When two or more Drive Enclosures are installed, connect the Drive Enclosures

with miniSAS cable.

2-1 Connect the SAS (OUT) port at expander 0 (EXP#0) of the Drive Enclosure 1, to the

SAS (IN) port at expander 0 (EXP#0) of the Drive Enclosure 2.

Connect the plug to be connected to the SAS (OUT) port, to the SAS (OUT) port of the expander 0 (EXP#0) for the Drive Enclosure 1.

Controller Enclosure

Drive Enclosure 1

CM#1

CM#0

EXP#1

EXP#0

Drive Enclosure 1

Chapter 4 Setup

P3AM-2512-03EN ETERNUS2000 disk storage system User Guide

Connect the connector to be connected to the SAS (IN) port, to the SAS (IN) port of the expander 0 (EXP#0) for the Drive Enclosure 2.

2-2 Connect the SAS (OUT) port at expander 1 (EXP#1) of the Drive Enclosure 1, to the

SAS (IN) port at expander 1 (EXP#1) of the Drive Enclosure 2.

Connect the miniSAS cable in the same way as Step 2-1

The following figure shows the miniSAS connection figure between Drive Enclosures.

Figure 4.2 MiniSAS cable connection

(When two or more Drive Enclosures are added)

Drive Enclosure 2

Controller Enclosure

Drive Enclosure 1

Drive Enclosure 2

CM#1

CM#0

EXP#1

EXP#0

EXP#1

EXP#0

SAS (IN)

port

SAS (OUT)

port

SAS (IN)

port

SAS (OUT)

port

4.2 Cable Connection

ETERNUS2000 disk storage system User Guide P3AM-2512-03EN

4.2.6 Power Cord Connection

Connect the power cords to the ETERNUS2000.

WARNING

o N

• Do not disconnect the power cord plug with wet hands as it may lead to fire or electrical shock.

• Do not attempt to repair a damaged power cord. Do not pull on, excessively bend/twist, apply heat or place heavy objects on the cord. Doing so will damage the cord, which may lead to fire or electrical shock.

• Do not put the stress on the root of the power cord, for example, by twisting it. Doing so may expose or cut the cable core of the power code, causing fire or electric shock

• Do not use the power cord if it is damaged or the plug does not snugly fit into the socket as it may cause fire or electrical shock.

• Do not use a power cord other than one attached, or the one specified. Do not use the attached power cord or specified power cord for other devices. Doing so may cause failure, fire, or electric shock.

• Wipe clean any excess dust from the plug prongs or socket with a dry cloth. Failure to do so, may lead to fire or electrical shock.

CAUTIO

Groun

• Use a power code with ground lead. Using a power code without ground lead may cause fire, electric shock, or malfunction.
