FSR PWB-100 Data Sheet

PWB-100 OVERALL DIMENSIONS

VIEW "A"

3.6310.94

BLOCK-OFF PANEL (3 INCLUDED)
WITH GROMMET (1 INCLUDED)

AC OUTLET BOX

(1 INCLUDED)

LOW-VOLTAGE ENTRY

BOX (1 INCLUDED)

LOW-VOLTAGE ENTRY
BOX AND AC OUTLET
BOX MAY BE MOUNTED
ON TOP OR

BOTTOM

VIEW "A"

WALL MOUNTED

SURFACE

3.55 FROM WALL

MOUNTED SURFACE

C

L

4.40

4.77

1.79

2.16

1.42.58

OPPOSITE SIDE IS MIRROR IMAGE

PWB-100 BOX CAN BE ROTATED 180° TO

POSITION AC OPENING ON LEFT OR

RIGHT

SIDE

7.02

5.23

7.39

C

L

(8) 1/2" KNOCKOUTS

1" & 1-1/4"
KNOCKOUT

1/2" & 3/4"
KNOCKOUT

1/2" & 3/4"
KNOCKOUT

AC OUTLET OPENING

IPS INSERT OPENING

1" x 2" OVAL KNOCKOUT CENTERED ON BLOCK-OFF PANEL

MADE IN
THE USA

PWB-100 OVERALL DIMENSIONS

PWB-100

PWB-100

PWB-100

Plasma/Flat Panel

OTHER FSR PRODUCT OFFERINGS

OTHER FSR PRODUCT OFFERINGS

IPS-WP2Q-WHT (populated)

WB-PR26 (populated)

The Intelligent Plate Solution (IPS) line is a wide variety of inter­connect solutions to satisfy any AV interface application.
Create unlimited combinations of connector inserts with this
diverse assortment of sleek wall plate and under table mount­ing styles. Customize your table, wall or floor box with our IPS
plates.

FSR addresses the rising issue of network security with the new
series of locking wall boxes. With 18 different models, every­thing from recessed to surface mounts are available for new or
existing construction. Store any wall plate or connections safe­ly and securely.

Specifications are subject to
change without notice.

244 Bergen Boulevard, Woodland Park, NJ 07424
Phone: [phone] · Fax: [phone]
Web: www.fsrinc.com · E-mail: [e-mail]

Display Wall Box

With Cover Without Cover

DESCRIPTION

DESCRIPTION

The PWB-100 is the essential installation accessory for any
flat panel display. It installs easily in the wall behind any dis­play allowing your screen to sit flush against the wall. This
unit provides a neat and secure environment for the audio,
video, control and power connections.

The PWB-100 is 11”W x 5.25”H x 3.57”D and installs easi­ly between any two standard studs in the wall. Once pop­ulated the overall height is 7.39” behind the wall.
Connections and cable entry can be on the top or the bot­tom depending on installation preference. Designed to
mount along the bottom edge behind a Plasma or LCD dis­play, the PWB-100 provides a single point for all your con­nections. The unit accommodates up to six single space
Intelligent Plate Solution plates and a UL listed single gang
gem box for AC power.

The PWB is available in white or black and is suitable for
painting or other finishing, matching any décor. It has a
cable exit slot for the display connections and the excess
cable can easily be hidden inside of the box making the
entire installation as clean as possible. The cover screws
onto the front of the box once all connections are in place.

FSR designed this unit for new and existing construction.
Brackets are included for mounting to studs in new con­struction as well as surface mount clips for mounting to
sheet rock or plywood in existing construction.

INCLUDED ACCESSORIES

INCLUDED ACCESSORIES

1 - Low voltage back box 1 - UL listed Gem box
3 - Block off plates 2 - Custom madison clips
2 - Surface mount clips 2 - Stud mount brackets
1- Pass through grommet,

additional grommets available
use part #13342

ORDERING INFORMATION

ORDERING INFORMATION

PWB-100-WHT = White Cover
PWB-100-BLK = Black Cover

Other options are available. Consult sales for details.

Metal Products Group

Now

with three

“block off” plates

and one grommet

included!

Interior shown with IPS

plates and accessories that

are not included.

FEATURES

FEATURES

• Rugged 14 gauge steel back box with

1

⁄16” front cover

• Compatible with FSR’s IPS inserts

• Can be installed in new or old work
(mounting adapters included)

• AC and low voltage back box included

• Connectors are hidden behind an attractive cover

• Multiple knockouts in a variety of sizes

• UL listed AC back box provided

APPLICATIONS

APPLICATIONS

• Anywhere a video display is wall mounted!

• Digital Signage • Electronic Billboards

• Conference Centers • Museums

• Schools • General Meeting Facilities

• Airports • Arenas

CONFORMS TO UL STD 514A

CERTIFIED TO CSA STD C22.2 NO. 18.1-04

FSR Inc.

244 Bergen Boulevard, Woodland Park, NJ 07424
Phone: [phone] · Fax: [phone]
Web: www.fsrinc.com · E-mail: [e-mail]
Order Desk: 1-800-332-FSR1 LIT1163B

PWB-100 ACCESSORIES

P

WB-100

BOX

S

TUD

(2) STUD BRACKET
(2 -

#6-32

x 1/4"

PAN HEAD SCREWS)

COVER (4 PAINTED
#6-32 x 3/4" OVAL
HEAD SCREWS)

1/2" - 5/8" WALL
THICKNESS

NEW WORK INSTALLATION

WALL OPENING: 11" x 5-1/4"

SHOWN WITH ACCESSORY
LOW-VOLTAGE CONDUIT ENTRY
BOX (2 - #6-32 x 1/4" PAN
HEAD SCREWS)

S

TUD MOUNTING

H

ARDWARE BY

CUSTOMER
(#6 SCREW,
1

/2"x1" STAPLE,

OR NAIL)

1

6" STUD CENTERS

MOUNTING HOLES

FOR 1/2" DRYWALL

MOUNTING HOLES
FOR 5/8" DRYWALL

OLD WORK INSTALLATION

WALL OPENING: 11" x 5-1/4"

ROTATE PWB-100
BOX INTO OPENING

(2) MADISON CLIP

(2) SURFACE MOUNTING

IN-STOP BRACKET
(3 - #6-32 x 1/4" UNDERCUT
FLAT HEAD SCREWS)

WALL OPENING

DIRECT-TO-STUD

MOUNTING HOLES

SHOWN WITH ACCESSORY

LOW-VOLTAGE CONDUIT ENTRY

BOX (2 - #6-32 x 1/4" PAN

HEAD SCREWS)

AC OUTLET BOX

(

4 - #6-32 x 1/4"

P

AN HEAD SCREWS)

AC OUTLET BOX
(4 - #6-32 x
1/4" PAN HEAD
SCREWS)

COVER CENTER SECTION
(2 - #6-32 x 1/2"
UNDERCUT FLAT HEAD
SCREWS)

(3) BLOCK-OFF PANEL
(2 - #6-32 x 1/4" PAN
HEAD SCREWS)

COVER (4 PAINTED
#6-32 x 3/4" OVAL
HEAD SCREWS)

(3) BLOCK-OFF PANEL

(2 - #6-32 x 1/4" PAN

HEAD SCREWS)

COVER CENTER
SECTION (2 -

#6-32 x 1/2"
UNDERCUT FLAT
HEAD SCREWS)

IPS Blank Inserts

I

PS-B011Q

Pass Thru .69" x 1.69"

ID Rubber Bushing

IPS-B020D

Pass Thru 2x .312"

ID Bushings

IPS-B000S

Single Space Blank

IPS-B000D

Double Space Blank

IPS-B010D

Pass Thru .812"

ID Bushing

I

PS-B000Q

Four Space Blank

IPS-B030T

Pass Thru 2x .312" ID &

.812" ID Bushings

I

PS Audio / Video Inserts

IPS Video Inserts

IPS Audio Inserts

IPS-AV922S

RCA (YEL) to Solder Cup

w/3.5mm St. to Solder Cup

IPS-AV923D

9-Pin D Female to

Female Bulkhead

w/3.5mm St. to Solder Cup

I

PS-AVC940T

HD-15 to 5 BNC,

3.5mm St.,

2 RJ-45 IDC (Cat 5e)

I

PS-AVC941T

HD-15 to 5 BNC,

3.5mm St., RCA,

RJ-45 IDC (Cat 5e)

I

PS-AVC942T

HD-15 to 5 BNC,

3.5mm St., S-Video,
RJ-45 IDC (Cat 5e)

IPS-AV230S

RCA (RED, WHT, YEL)

to Solder Cup

IPS-AV231S

RCA (RED, WHT, YEL)

to RCA Bulkhead

IPS-AV920D

HD-15 Female to HD-15

Female w/3.5mm St.

to Solder Cup

IPS-AV921D

HD-15 Female to 5-BNC

Tails w/3.5mm St.

to Solder Cup

IPS-V410S

H

D-15 Female to
HD-15 Female

IPS-V110S

BNC (YEL) to

BNC Bulkhead

IPS-V210S

R

CA (YEL) to

Solder Cup

IPS-V120S

BNC (YEL) to

BNC Bulkhead

IPS-V211S

R

CA (YEL) to

RCA Bulkhead

IPS-V310S

S

-Video to 2 BNC Tails

IPS-V311S

S

-Video to S-Video
Bulkhead

IPS-V230S

R

CA (GRN, BLU, RED)

to RCA Bulkhead

IPS-V130D

BNC (GRN, RED, BLU)

to BNC Bulkhead

IPS-V150T

BNC (RED, GRN, BLU,

BLK, YEL) to BNC Bulkhead

IPS-V610S

H

DMI Female to

Female Bulkhead

I

PS-V611T

DVI-I Female to

Female Bulkhead

1

9

17 42

6

8

1

C

1 2

C

C

43

C

C

5

IPS-V922S

B

NC (YEL) to BNC

S-Video (YEL) to S-Video

IPS-V921S

R

CA (YEL) to BNC

S-Video (YEL) to S-Video

IPS-V213S

RCA (YEL) to

BNC Bulkhead

IPS-V231D

RCA (GRN, RED, BLU)

to BNC Bulkhead

IPS-V911S

F-Connector Bulkhead

IPS-A220S

RCA (RED, WHT) to

RCA Bulkhead

IPS-A221S

RCA (RED, WHT) to

Solder Cup

IPS-A222S

RCA (RED, WHT) to

Screw Terminal

IPS-A510S

3.5mm St. to Solder Cup

IPS-A610S

3-Pin Mini XLR (Switchcraft)

IPS-A611D

Female XLR 3-Pin (Neutrik)

IPS-A612D

Male XLR 3-Pin (Neutrik)

IPS-A613D

NEUTRIK SPEAKON

IPS-A512S

1/4" Stereo Jack to

Solder Cup

IPS-A522S

1/4" Stereo Jack to

Solder Cup

I

PS-A620S

3-Pin Mini XLR (Switchcraft)

IPS-A223S

RCA (RED, WHT) to

Balanced Screw Terminal

IPS-A511S

1/8" Stereo Jack to

Balanced Screw Terminal

IPS Voice / Data Inserts

IPS-D715S

USB Type A Bulkhead

IPS-D710S

R

J-45 IDC (Cat 5e)

IPS-D711S

RJ-45 IDC (Cat 6)

IPS-D712S

R

J-45 Bulkhead (Cat 5e)

IPS-D713S

R

J-45 Bulkhead (Cat 6)

IPS-D714S

R

J-11 IDC

I

PS-D720D

RJ-45 IDC (Cat 5e)

IPS-D716S

USB Type A to

Screw Terminal

IPS-D717S

USB Type A Charging

Dock to Screw Terminal

CHARGING

STATION

IPS-D718S

USB Type B

Bulkhead

IPS-D719S

USB Type B to

Screw Terminal

IPS-D801S

Fiber Bulkhead

IPS-D802S

Dual Fiber

Bulkhead

IPS Control Inserts

IPS-C920S

2 Momentary Buttons

IPS-C611S

4-Pin Mini XLR

(Switchcraft)

w/Lamp 5-24V

IPS-C612S

Hole for Crest Net

Cable

IPS-C410S

9-Pin D Male to

Female Bulkhead

IPS-C910S

1 Momentary Button

IPS-C411S

9-Pin D Male
to Solder Cup

w/Lamp 5-24V

IPS-C610D

Female XLR 4-Pin

(Neutrik)

IPS-C710D

Neutrik RJ-45

IPS AC Insert

IPS-AC110D

Enclosed w/8' 14awg Cord

AV Interfaces

Simple Solutions Inserts (Decora)

SS-PBLNK SS-P2DBSS-PORT3 SS-PORT4 SS-PORT6 SS-P1DB SS-PDSXL SS-P2XLR SS-P1XLR SS-DDUP

(Includes Wall Plate)

SS-CBLNK SS-RJ11

SS-SCON

SS-MINI

SS-RJ45

CAT 5

SS-BNC

SS-RCA-R

SS-RCA-B

SS-RCA-YSS-FCON

SS-RJCAT6

Cat 6

SS-USBASS-SWMAINSS-HDMI

HDMI

SS-USBB

SS-USBBHWSS-USBAHWSS-LC SS-SWMOM

CI-5BWPA

Computer

Interface

COMPUTER IN

CI-5BWPA

POWER/
SIGNAL

AUDIO IN

CI-5LB

Computer

Interface

LOCAL MONITOR OUT

CI-5LB

COMPUTER VIDEO IN

POWER/
SIGNAL

AUDIO IN

PCI-5BWA

Passive PC

Interface

PCI-5BWA

AUDIO IN

VIDEO IN

VWP-SVA

Video

Interface

POWER

VWP-SVA

LEFT RIGHT

AUDIO IN

COMP S-VIDEO

OR

VIDEO IN

T2-CATXW

Audio Video

Twister

AUDIO IN

SIGNAL

POWER/

COMPUTER IN

T2-CATXW

T2-DTXW

Data IR
Twister

IR IN POWER

SERIAL IN

T2-DTXW

DV-WPXT-2 TX

HDMI

HD Extender

PWB-100 ACCESSORIES

TYPICAL INSTALLATIONS

TYPICAL INSTALLATIONS

PWB-100

PWB-100

Most items above are available in
white, ivory or black to match the

decor. We are always adding to

our IPS and SS line. Please visit

our website or contact sales

for detailed information.
