FS.COM ELPS Configuration Manual

Page 1

ELPS Configuration Commands

Page 2

Table of Contents

Chapter 1 ELPS Configuration Commands ...................................................................................................................1

1.1 Global Commands........................................................................................................................................1

1.1.1

eellppss

id..............................................................................................................................................1

1.1.2

wwoorrkkiinngg--vvllaannmmaapp

vlanmap

................................................................................................................ 2

1.1.3

pprrootteeccttiioonn--mmooddee {{11pplluuss11--bbiiddiirreeccttiioonnaall | 11pplluuss11--uunniiddiirreeccttiioonnaall | 11ttoo11--bbiiddiirreeccttiioonnaall}}

........................ 2

1.1.4

rreevveerrttiivvee--mmooddee {{rreevveerrttiivvee | nnoonnrreevveerrttiivvee}}

........................................................................................... 4

1.1.5

ddeetteecctt--ffaauulltt {{pphhyyssiiccaall--ppoorrtt--cchheecckk| ccoonnttiinnuuiittyy--cchheecckk | bbootthh--cchheecckk}}

.................................................... 5

1.1.6 WWTTRR--ttiimmee .........................................................................................................................................6

1.1.7 hhoolldd--ooffff--ttiimmee....................................................................................................................................6

1.2 Port Configuration Commands...................................................................................................................... 7

1.2.1 eellppss

{{wwoorrkkiinngg--ttrraannssppoorrtt | prrotteecctiioonn--ttrraannssppoorrtt}}............................................................................. 7

1.2.2 eellppss

mmeepp mmdd

md-string

mmaa

ma-string

lleevveell

level-id

llooccaall

local-id

rreemmoottee

remote-id

....................... 9

1.3 Control Commands ....................................................................................................................................10

1.3.1 eellppss

LLoocckkOOuutt...............................................................................................................................10

1.3.2 eellppss

FFoorrcceeddSSwwiittcchh ...................................................................................................................... 11

1.3.3 eellppss

MMaannuuaallSSwwiittcchh ..................................................................................................................... 11

1.3.4 eellppss

MMaannuuaallSSwwiittcchh--WWoorrkkiinngg........................................................................................................12

1.3.5 eellppss

EExxeerrcciissee .............................................................................................................................. 13

1.3.6 eellppss

CCLLEEAARR................................................................................................................................. 14

1.4 Show .........................................................................................................................................................15

1.4.1 sshhooww eellppss ....................................................................................................................................... 15

- I -

Page 3

ELPS Configuration Commands

Chapter 1 ELPS Configuration Commands

1.1 Global Commands

1.1.1 elps id

To set an instance of ELPS node and enter the node mode, run the following command:

elps

To cancel an instance of ring, run the following command:

no elps

Parameter

Parameter Description

Stands for the node instance ID, which ranges from 0 to 7.

Default value

By default, the ELPS node instance is not configured.

Command mode

Global configuration mode

Explanation

N/A.

Example

S1_config#elps 1

S1_config_elps1#

Related command

N/A.

- 1 -

Page 4

ELPS Configuration Commands

1.1.2 working-vlanmap vlanmap

To set the working vlan map of the ELPS node, run the following command:

working-vlanmap

vlanmap

Parameter

Parameter Description

vlanmap Stands for the VLAN range table (1-4094), which is similar with

(1,3,5,7), (1,3-5,7) or (1-7).

Default value

By default, the working vlan map of a node is not configured.

Command mode

EPLS node configuration mode

Explanation

1. Configuring working VLAN does not mean creating this VLAN, so you have to establish the control VLAN manually.

2. After working-vlanmap, protection-mode, revertive-mode and detect-fault are configured, the ELPS configuration mode exits and the ELPS node is started, the working-vlanmap cannot be modified.

Example

S1_config#elps 1

S1_config_elps1#working-vlanmap 1-10

S1_config_elps1#

Related command

protection-mode {1plus1-bidirectional | 1plus1-unidirectional | 1to1-bidirectional}

revertive-mode {revertive | nonrevertive}

detect-fault {physical-port-check| continuity-check | both-check}

1.1.3 protection-mode {1plus1-bidirectional | 1plus1-unidirectional |

1to1-bidirectional}

To set the protection mode of the ELPS node to be the 1plus1-bidirectional mode, run the following command:

- 2 -

Page 5

ELPS Configuration Commands

protection-mode 1plus1-bidirectional

To set the protection mode of the ELPS node to be the 1plus1-unidirectional mode, run the following command:

protection-mode 1plus1-unidirectional

To set the protection mode of the ELPS node to be the 1to1-bidirectional mode, run the following command:

protection-mode 1to1-bidirectional

Parameter

N/A.

Default value

By default, the ELPS node’s protection mode is not configured.

Command mode

ELPS node configuration mode

Explanation

1. When the ELPS node's protection mode is set to

1plus1-bidirectional

1plus1-unidirectional

, the revertive mode of node is

non-revertive

by default; the

protection mode is

1to1-bidirectional

, it is

revertive

by default.

2. After working-vlanmap, protection-mode, revertive-mode and detect-fault are configured, the ELPS configuration mode exits and the ELPS node is

started, the

working-vlanmap cannot be modified.

Example

S1_config#elps 1

S1_config_elps1#working-vlanmap 1-10

S1_config_elps1#protection-mode 1plus1-bidirectional

S1_config_elps1#

Related command

working-vlanmap vlanmap

revertive-mode {revertive | nonrevertive}

detect-fault {physical-port-check| continuity-check | both-check}

- 3 -

Page 6

ELPS Configuration Commands

1.1.4 revertive-mode {revertive | nonrevertive}

To set the mode of the ELPS to

revertive

, run the following command:

revertive-mode revertive

To set the mode of the ELPS to

non-revertive

, run the following command:

revertive-mode nonrevertive

Parameter

N/A.

Default value

By default, the ELPS node’s mode is not configured.

Command mode

ELPS node configuration mode

Explanation

1. When the ELPS node's protection mode is set to

1plus1-bidirectional

1plus1-unidirectional

, the revertive mode of node is

non-revertive

by default; the

protection mode is

1to1-bidirectional

, it is

revertive

by default. The two cases change

after the configuration of the revertive mode.

2. After working-vlanmap, protection-mode, revertive-mode and detect-fault are configured, the ELPS configuration mode exits and the ELPS node is started, the working-vlanmap

cannot be modified.

Example

S1_config#elps 1

S1_config_elps1#working-vlanmap 1-10

S1_config_elps1#protection-mode 1plus1-bidirectional

S1_config_elps1#revertive-mode revertive

S1_config_elps1#

Related command

working-vlanmap vlanmap

protection-mode {1plus1-bidirectional | 1plus1-unidirectional | 1to1-bidirectional}

detect-fault {physical-port-check| continuity-check | both-check}

- 4 -

Page 7

ELPS Configuration Commands

1.1.5 detect-fault {physical-port-check| continuity-check | both-check}

To set the trouble monitoring mode of the ELPS node to

physical-port-check

, run the

following command:

detect-fault physical-port-check

To set the trouble monitoring mode of the ELPS node to

continuity-check

, run the

following command:

detect-fault continuity-check

To set the trouble monitoring mode of the ELPS node to

both-check

, run the following

command:

detect-fault both-check

Default value

By default, the ELPS node’s trouble monitoring mode is not configured.

Command mode

ELPS node configuration mode

Explanation

1. After working-vlanmap, protection-mode, revertive-mode and detect-fault are configured, the ELPS configuration mode exits and the ELPS node is started, the working-vlanmap cannot be modified.

Example

S1_config#elps 1

S1_config_elps1#workin

g-vlanmap 1-10

S1_config_elps1#protection-mode 1plus1-bidirectional

S1_config_elps1#revertive-mode revertive

S1_config_elps1#detect-fault continuity-check

S1_config_elps1#

Related command

working-vlanmap vlanmap

protection-mode {1plus1-bidirectional | 1plus1-unidirectional | 1to1-bidirectional}

revertive-mode {revertive | nonrevertive}

- 5 -

Page 8

ELPS Configuration Commands

1.1.6 WTR-time

To set the WTR time of the ELPS node, run the following command:

WTR-time

value

To resume the default WTR time of the ELPS node, run the following command:

no WTR-time

Parameter

Parameter Description

value Stands for the WTR time, which ranges from 5 to 12 minutes. Its

step is 1 minute and its default value is 5 minutes.

Default value

By default, the WTR-time is 5 minutes.

Command mode

ELPS node configuration mode

Explanation

N/A.

Example

S1_config#elps 1

S1_config_elps1#working-vlanmap 1-10

S1_config_elps1#protection-mode 1plus1-bidirectional

S1_config_elps1#revertive-mode revertive

S1_config_elps1#detect-fault continuity-check

S1_config_elps1#WTR-time 6

S1_config_elps1#

Related command

N/A

1.1.7 hold-off-time

To set the hold-off time of the ELPS node, run the following command:

- 6 -

Page 9

ELPS Configuration Commands

hold-off-time

value

To resume the default hold-off time of the ELPS node, run the following command:

no hold-off-time

Parameter

Parameter Description

value Stands for the hold-off time, which ranges from 1 to 10 seconds.

Its step is 100ms and its default value is 1 second.

Default value

By default, the hold-off time is one second.

Command mode

ELPS node configuration mode

Explanation

N/A.

Example

S1_config#elps 1

S1_config_elps1#working-vlanmap 1-10

S1_config_elps1#protection-mode 1plus1-bidirectional

S1_config_elps1#revertive-mode revertive

S1_config_elps1#detect-fault continuity-check

S1_config_elps1#hold-off-time 2

S1_config_elps1#

Related command

N/A

1.2 Port Configuration Commands

1.2.1 elps id {working-transport | protection-transport}

To set a port where the ELPS working transport entity is located, run the following command:

- 7 -

Page 10

ELPS Configuration Commands

elps idworking-transport

To delete the ELPS working transport entity configuration on a port, run the following command:

no elps idworking-transport

To set a port where the ELPS protection transport entity is located, run the following command:

elps idprotection-transport

To delete the ELPS protection transport entity configuration on a port, run the following command:

no elps idprotection-transport

Parameter

Parameter Description

id ID of the node

Default value

No ELPS configuration exists on ports by default.

Command mode

The physical port configuration mode and the converged port configuration mode

Explanation

The port cannot be configured until working-vlanmap, protection-mode, revertive-mode and default-fault are all configured.

Example

S1_config#interface GigaEthernet 0/1

S1_config_g0/1# elps 1 working-transport

S1_config_g0/1#exit

Related command

elps id mep md md-string ma ma-string level level-id local local-id remote remote-id

- 8 -

Page 11

ELPS Configuration Commands

1.2.2 elps id mep md md-string ma ma-string level level-id local local-id

remote remote-id

To set the MEP information about the ELPS port, run the following command:

elps id mep md

md-string

ma-string

level

level-id

local

local-id

remote

remote-id

To delete the MEP information about the ELPS port, run the following command:

no elps id mep

Parameter

Parameter Description

id ID of the node

md-string

MEP maintenance domain

ma-string

MEP maintenance link

level-id

MEP level

local-id

Local MEP ID

remote-id

Remote MEP ID

Default value

No MEP information exists on ports by default.

Command mode

The physical port configuration mode and the converged port configuration mode

Explanation

The port cannot be configured until working-vlanmap, protection-mode, revertive-mode and default-fault, transport entity of the ELPS port are all configured.

Example

S1_config#interface GigaEthernet 0/1

S1_config_g0/1#elps 1 working-transport

S1_config_g0/1#elps 1 mep md x ma x level 1 local 1 remote 2

S1_config_g0/1#exit

Related command

elps id {working-transport | protection-transport}

- 9 -

Page 12

ELPS Configuration Commands

1.3 Control Commands

1.3.1 elps id LockOut

To set the protection lockout of ELPS, run the following command:

elps idLockOut

Parameter

Parameter Description

Id ID of the node

Default value

N/A.

Command mode

Monitoring mode

Explanation

N/A.

Example

N/A.

Related command

elps id ForcedSwitch

elps id ManualSwitch

elps id ManualSwitch-Working

elps id Exercise

elps id CLEAR

- 10 -

Page 13

ELPS Configuration Commands

1.3.2 elps id ForcedSwitch

To set the forced switching operation of ELPS, run the following command:

elps idForcedSwitch

Parameter

Parameter Description

Id ID of the node

Default value

N/A.

Command mode

Monitoring mode

Explanation

N/A.

Example

N/A.

Related command

elps id LockOut

elps id ManualSwitch

elps id ManualSwitch-Working

elps id Exercise

elps id CLEAR

1.3.3 elps id ManualSwitch

To set the manual switching operation of ELPS, run the following command:

elps idManualSwitch

- 11 -

Page 14

ELPS Configuration Commands

Parameter

Parameter Description

Id ID of the node

Default value

N/A.

Command mode

Monitoring mode

Explanation

N/A.

Example

N/A.

Related command

elps id LockOut

elps id ForcedSwitch

elps id ManualSwitch-Working

elps id Exercise

elps id CLEAR

1.3.4 elps id ManualSwitch-Working

To switch to the working entity of ELPS manually, run the following command:

elps idManualSwitch-Working

Parameter

Parameter Description

Id ID of the node

- 12 -

Page 15

ELPS Configuration Commands

Default value

N/A.

Command mode

Monitoring mode

Explanation

N/A.

Example

N/A.

Related command

elps id LockOut

elps id ForcedSwitch

elps id ManualSwitch

elps id Exercise

elps id CLEAR

1.3.5 elps id Exercise

To set the exercise operation of ELPS, run the following command:

elps idExercise

Parameter

Parameter Description

Id ID of the node

Default value

N/A.

- 13 -

Page 16

ELPS Configuration Commands

Command mode

Monitoring mode

Explanation

N/A.

Example

N/A.

Related command

elps id LockOut

elps id ForcedSwitch

elps id ManualSwitch

elps id ManualSwitch-Working

elps id CLEAR

1.3.6 elps id CLEAR

To clear the control command of ELPS, run the following command:

elps idCLEAR

Parameter

Parameter Description

Id ID of the node

Default value

N/A.

Command mode

Monitoring mode

- 14 -

Page 17

ELPS Configuration Commands

Explanation

N/A.

Example

N/A.

Related command

elps id LockOut

elps id ForcedSwitch

elps id ManualSwitch

elps id ManualSwitch-Working

elps id Exercise

1.4 Show

1.4.1 show elps

To display the summary information about the ELPS node, run the following command:

show elps

To display the detailed information about the ELPS node, run the following command:

show elps iddetail

To display the information about the ELPS port, run the following command:

show elps id interface

intf-name

To display the summary information about all ELPS nodes, run the following command:

show elps

Parameter

Parameter Description

id ID of the node

intf-name Name of an interface

- 15 -

Page 18

ELPS Configuration Commands

Default value

N/A.

Command mode

Monitoring mode, global configuration mode, node configuration mode or port configuration mode

Explanation

N/A.

Example

N/A.

Related command

N/A.

- 16 -
