Frymaster Single Under Fryer Filter, Under Fryer Filter User Manual

SUFF/UFF Filtration Systems
Installation & Operation Manual
Under Fryer Filter (UFF) and
Single Under Fryer Filter (SUFF)
PARTS LIST
INCLUDED
Frymaster/Dean, a member of the Commercial Food Equipment Service Association, recommends using CFESA Certified Technicians.
PRINTED IN THE USA
24-Hour Service Hotline
OCTOBER 2005
*8195809*
Please read all sections of this manual and retain for future reference.
Installation, maintenance, and repairs should be performed by your Frymaster/Dean
Factory Authorized Service Agency.
WARNING
Safe and satisfactory operation of your equipment depends on its proper installation.
Installation MUST conform to local codes, or in the absence of local codes, with the
latest edition of the National Electric Code, N.F.P.A. 70.
WARNING
ELECTRICAL GROUNDING INSTRUCTIONS
This filter is equipped with a three-prong, grounded plug for your protection against
shock hazard and should be plugged directly into a properly grounded, three-hole
receptacle. Do not cut off, remove or otherwise bypass the grounding prong on this
plug.
If it is necessary to use an extension cord, it MUST be a three-conductor, grounded
cord of 16 gauge or greater.
DANGER
Do not filter more than one fry tank at a time.
Hot fluid – Do not fill above a point 1½ inches below the OIL CONTAINER RIM.
WARNING
This filter unit is not suitable for outdoor use. When operating this unit, it MUST be
placed on a horizontal surface.
WARNING
This filter unit is not suitable for installation in an area where a water jet can be used,
and this appliance MUST NOT be cleaned with a water jet.
NOTICE:
If this filter unit is cleaned with water, disconnect the unit from power source before
cleaning and thoroughly dry the filter unit before reconnecting to electrical power
source.
DANGER
The crumb tray (if equipped) in portable filter systems must be emptied into a fireproof
container at the end of frying operations each day. Some food particles can
spontaneously combust if left soaking in certain shortening material.
NOTICE:
Drawings and photos used in this manual are intended to illustrate operational, cleaning
and technical procedures and may not conform to on-site management operational
procedures.
NOTICE IF, DURING THE WARRANTY PERIOD, THE CUSTOMER USES A PART FOR THIS ENODIS EQUIPMENT OTHER THAN AN UNMODIFIED NEW OR RECYCLED PART
PURCHASED DIRECTLY FROM FRYMASTER/DEAN, OR ANY OF ITS AUTHORIZED
SERVICE CENTERS, AND/OR THE PART BEING USED IS MODIFIED FROM ITS
ORIGINAL CONFIGURATION, THIS WARRANTY WILL BE VOID. FURTHER,
FRYMASTER/DEAN AND ITS AFFILIATES WILL NOT BE LIABLE FOR ANY CLAIMS,
DAMAGES OR EXPENSES INCURRED BY THE CUSTOMER WHICH ARISE DIRECTLY
OR INDIRECTLY, IN WHOLE OR IN PART, DUE TO THE INSTALLATION OF ANY
MODIFIED PART AND/OR PART RECEIVED FROM AN UNAUTHORIZED SERVICE
CENTER.
TABLE OF CONTENTS
SUFF/UFF FILTRATION SYSTEMS INSTALLATION & OPERATION MANUAL
Chapter 1. INTRODUCTION 1-1
1.1 Ordering Parts 1-1
1.2 Service Information 1-1
1.3 After Purchase 1-2
1.4 Safety Information 1-2 Chapter 2 IMPORTANT INFORMATION 2-1
2.1 General 2-1
2.2 Rating Plate 2-1
2.3 Pre-installation 2-2
2.4 Unpacking the Filter System 2-2 Chapter 3 INSTALLATION AND OPERATION INSTRUCTIONS 3-1
3.1 General 3-1
3.2 Filter Prep 3-2
3.2.1 Filter Unit Identification 3-2
3.2.2 Assembling the Filter 3-6
3.2.3 Installing the Filter 3-12
3.3 Daily Filtration Operation 3-13
3.3.1 General Overview 3-13
3.3.2 Filtering Tools 3-13
3.4 Operating the Filter 3-14
3.4.1 Pan Preparation and Operation 3-14
3.4.2 Filter Operation 3-16
3.4.3 Hose and Wand Operation 3-19 Chapter 4 CLEANING AND MAINTENANCE 4-1
4.1 General 4-1
4.2 Each Filter Use 4-1
4.3 Daily (Close of Business) 4-3
4.4 Weekly 4-3 Chapter 5 TROUBLESHOOTING 5-1 Chapter 6 PARTS LIST 6-1
6.1 SUFF 80 BID80 Series 6-1
6.2 SUFF 80 Domestic (Early Style) 6-2
6.3 SUFF 80 Domestic (Current) 6-3
6.4 SUFF 60 (Current Production-Domestic and 18UE/BIH1721) 6-4
6.5 SUUF 50 (Early Style) 6-5
6.6 SUFF 50 (Current Style) 6-6
6.7 Super Cascade 75 (Early Style) 6-7
6.8 UFF Components D50 and D60 Series Fryers (Current Production) 6-9
6.9 UFF Components D50 and D60 Series Fryers (Previous Production) 6-10
6.10 KFC 218G/E UFF (2002) 6-12
6.11 UFF 80 (Current Style) 6-14
6.12 UFF 85 Filter-leaf Equipped Flatbottom (2424) 6-15
6.13 Caster and Accessories 6-17
SUFF/UFF FILTRATION SYSTEMS
CHAPTER 1: INTRODUCTION
1.1 Ordering Parts
Customers may order parts directly from their local Factory Authorized Service Center (FASC). See the numbers listed in section 1.2 to find your nearest FASC.
To speed up your order, the following information is required:
Model Number Type Serial Number Optional Features
Item Part Number Quantity Needed
1.2 Service Information
Call the 1-800-551-8633 or (318) 865-1711 Service Hotline number for the location of your nearest Factory Authorized Service Center. Always give the model and serial numbers of your filter unit.
To assist you more efficiently, the following information will be needed:
Model Number Type Serial Number Optional Features
Nature of Problem:
Additional information (i.e. oil temperature at filter time, time of day and other pertinent information) may be helpful in solving your service problem.
1-1
SUFF/UFF FILTRATION SYSTEMS
CHAPTER 1: INTRODUCTION
1.3 After Purchase
In order to improve service, have the following chart filled in by the Frymaster/Dean Authorized Service Technician who installed this equipment.
Authorized Service Technician/FASC Address
Telephone/Fax Model Number Serial Number
1.4 Safety Information
Before attempting to operate your unit, read the instructions in this manual thoroughly.
Throughout this manual, you will find notations enclosed in double-bordered boxes similar to the ones below.
CAUTION boxes contain information about actions or conditions that may cause or result in a malfunction of your system.
CAUTION
Example of a CAUTION box.
WARNING boxes contain information about actions or conditions that may cause or result in damage to your system, and may cause your system to malfunction.
WARNING
Example of a WARNING box.
DANGER boxes contain information about actions or conditions that may cause or result in injury to personnel, and may cause damage to your system and/or cause your system to malfunction.
DANGER
Example of a DANGER box.
1-2
SUFF/UFF FILTRATION SYSTEMS
CHAPTER 2: IMPORTANT INFORMATION
2.1 General
Multi-batteried frying systems can come equipped with the Under Fryer Filter (UFF) system. Single fryers can come equipped with the Single Under Fryer Filter (SUFF) system. Filter design varies according to the model of the fryer/frying system.
Oil or shortening is drained from the fryer into the filter pan, then pumped back into the frypot by means of oil-return plumbing built into the fryer.
Filtering is accomplished with one sheet of replaceable filter paper and filter powder, or by means of a filter-leaf assembly (see photos below).
Applying filter powder to filter paper.
Optional filter-leaf used in place of filter paper.
CAUTION
The on-site supervisor is responsible for ensuring that operators are made aware of
the inherent dangers of operating a hot oil filter system, particularly the aspects of
oil filtration, and draining/cleaning procedures.
2.2 Rating Plate
Information on the rating plate includes model and serial numbers, as well as electrical requirements. Have the rating plate information handy when communicating with the factory about a unit or requesting special parts or information. Without this information, proper identification of the unit cannot be confirmed.
2-1
SUFF/UFF FILTRATION SYSTEMS
CHAPTER 2: IMPORTANT INFORMATION
2.3 Pre-installation
NOTE: Failure to use qualified service personnel will void the Dean warranty.
A. Standards: Usage of this filter unit must be in accordance with all applicable state and local
codes.
B. Electrical Connections: SUFF/UFF filter systems require connection to a 120V, 60-cycle,
15-amp power supply, or a 220V, 50-cycle, 7-amp power supply. Units are equipped with a grounded male receptacle for use with a 3-wire, 16 AWG power-cord set. If an extension cord is required, it must be a three-conductor, grounded power cord of at least 16 gauge.
C. Safety Features: A 5-amp (230V) or a 7-amp (115V) circuit breaker switches the power OFF
if an overload occurs. In addition, a thermal-overload circuit breaker is built into the filter motor. If an overload occurs, allow the motor to cool for 45 minutes, then press the reset button to reset the thermal-overload circuit.
NOTE: If the circuit breaker is triggered, depress the reset button to activate the circuit after the failure has been detected and repaired.
2.4 Unpacking the Filter System
Ensure the container is upright. Unpack the filter carefully and remove all accessories (if included) from the carton. Do not discard or misplace parts and/or accessories; they will be needed. Any accessories or starter kits included with the unit will be packaged inside the filter tank strapped to the shipping frame.
After unpacking, immediately check the equipment for visible signs of shipping damage. If such damage has occurred, contact the carrier and file the appropriate freight claims. Do not contact the factory, as the responsibility of shipping damage is between the carrier and dealer or end user.
If your equipment arrives damaged: a. File claim for damages immediately – Regardless of extent of damage. b. Visible loss or damage – Be sure this is noted on the freight bill or express receipt and is
signed by the person making the delivery.
c. Concealed loss or damage – If damage is unnoticed until equipment is unpacked, notify
freight company or carrier immediately, and file a concealed damage claim. This should be done within 15 days of date of delivery. Retain the shipping container for inspection.
NOTE: Dean does not assume responsibility for damage or loss incurred in transit.
2-2
SUFF/UFF FILTRATION SYSTEMS
CHAPTER 3: INSTALLATION AND OPERATION
WARNING
Drawings and photos used in this manual are intended to illustrate operational,
cleaning and technical procedures and may not conform to on-site management
operational procedures.
3.1 General
Most SUFF/UFF systems use filter paper as the filter medium. Some filter systems can be special ordered with a filter-leaf assembly, which eliminates the need for filter paper. Both types require the use of filter powder to enhance the filtration process. Photos used in the procedural illustrations may or may not resemble the filter unit that came with the frying system. The following procedures apply to all fryers equipped with SUFF/UFF filter systems. Filter system design depends on the frying system configuration (single or multi-batteried systems- see photos below).
Typical Under Fryer Filter (UFF) installed in a multi-batteried frying system.
Typical Single Under Fryer Filter (SUFF) installed in a single fryer.
3-1
SUFF/UFF FILTRATION SYSTEMS
CHAPTER 3: INSTALLATION AND OPERATION
3.2 Filter Preparation
On initial installation and before each use, clean the filter:
a. remove all loose parts from the filter,
b. wash the filter pan and all accessories in hot, soapy water, c.
and dry thoroughly.
3.2.1 Filter Unit Identification
Current Production
SUFF/UFF filtration systems use filter paper or a filter-leaf to remove impurities. Filter paper is held in place by a hold-down ring.
1. Filter pan.
2. Filter support grid.
3. Filter paper.
4. Hold-down ring.
5. Crumb screen.
6. Filter pan lid.
5
6
4
3
2
1
Latchless or weighted hold-down ring filter assembly (current production ).
3-2
SUFF/UFF FILTRATION SYSTEMS
CHAPTER 3: INSTALLATION AND OPERATION
Previous Production
Previous production filter units differed slightly from current production units. There were two types of hold-down rings: the latchless or weighted hold-down ring (similar to current production) and the latching hold-down ring.
1. Filter pan.
6
2. Filter support grid.
3. Filter paper.
7
4. Hold-down ring.
5. Crumb screen.
6. Front pan cover.
5
7. Rear pan cover.
4
2
3
1
Latchless or weighted hold-down ring filter assembly (previous production).
3-3
SUFF/UFF FILTRATION SYSTEMS
CHAPTER 3: INSTALLATION AND OPERATION
3.2.1 Filter Unit Identification (cont.)
A latching hold-down ring filter assembly is shown below:
1. Filter pan.
2. Filter support grid.
3. Filter paper.
4. Hold-down ring.
5. Crumb screen.
6. Front pan cover.
7. Rear pan cover.
Latching hold-down ring filter assembly (previous production).
7
4
6
5
1
3
2
3-4
SUFF/UFF FILTRATION SYSTEMS
CHAPTER 3: INSTALLATION AND OPERATION
3.2.1 Filter Unit Identification (cont.)
SUFF/UFF systems incorporating a filter-leaf assembly use a fine mesh screen to filter impurities and debris from the oil. The oil is pumped through the screen and then returned to the frypot. The advantages of the filter-leaf include unlimited re-use and the elimination of paper cost.
Filter pans with filter-leaf assemblies are assembled as illustrated below:
5
1. Filter pan with caddy assembly.
2. Compression cap and riser intake
assembly.
3. Filter-leaf assembly.
4. Crumb screen.
4
3
5. Filter pan cover.
Filter-leaf assembly.
2
1
3-5
SUFF/UFF FILTRATION SYSTEMS
CHAPTER 3: INSTALLATION AND OPERATION
3.2.2 Assembling the Filter
Assembling Filter Units with Latchless Hold-down Rings
1. Place the support grid in the bottom of filter
pan.
Support grid properly placed in filter pan.
2. Put one filter paper sheet on top of the
support grid. Be sure the paper covers the filter pan bottom and laps two inches onto the pan wall.
Ensure filter paper overlaps two inches on all sides and is evenly distributed under the hold­down ring.
3. Position the hold-down ring on top of the
filter paper. Ensure the hold-down ring seals around the support grid. This prevents air from getting into the system.
Hold-down ring positioned correctly over filter paper in filter pan.
3-6
SUFF/UFF FILTRATION SYSTEMS
CHAPTER 3: INSTALLATION AND OPERATION
3.2.2 Assembling the Filter (cont.)
4. Sprinkle 8 ounces of filter powder on the
filter sheet. Ensure the powder covers the filter paper evenly.
5. Place the crumb screen in the filter pan.
Allow the crumb screen to rest on the top edges of the hold-down ring.
6. Place filter pan cover onto the filter pan
assembly. Ensure the cover is correctly positioned over the slip fitting.
NOTE: Previous production units had two covers (front and back). If this is the case, place both covers on the filter pan and ensure that the front cover is correctly positioned over the slip fitting.
3-7
Sprinkle the proper amount of filter powder evenly over the paper.
Crumb screen properly placed.
Fully assembled pan with proper placement of lid over slip fitting (slip-fitting orientation may vary according to fryer system).
SUFF/UFF FILTRATION SYSTEMS
CHAPTER 3: INSTALLATION AND OPERATION
3.2.2 Assembling the Filter (cont.) Assembling Filter Units with Latching Hold-down Rings
1. Place the filter screen in the pan. Ensure it is
properly seated in the bottom recess.
Placing filter screen (pan grid) in filter pan.
2. Place one sheet of filter paper over the filter
screen.
3. Install the hold-down ring over the filter
paper. Ensure the hold-down ring is properly seated in the bottom recess.
Note: When placing the hold-down ring over the filter paper, use care not to tear the filter paper when locking the ring down. Sediment can get into the filter system through tears in the filter paper.
Installing hold-down ring over filter paper.
3-8
SUFF/UFF FILTRATION SYSTEMS
CHAPTER 3: INSTALLATION AND OPERATION
3.2.2 Assembling the Filter (cont.)
4. Latch the hold-down ring to lock the filter
paper in place. Simultaneously lock both clamps in place by pressing down and in on each clamp (see photo at right).
5. Sprinkle 1-cup (8 ounces/227 grams) evenly
over the paper.
6. Install crumb screen after applying the proper
amount of filter powder.
Locking hold-down ring in place.
Applying filter powder to filter paper.
Crumb screen properly installed in filter pan.
3-9
Loading...
+ 37 hidden pages
