FRESH COOKING OIL

The Frontline Box System for Standard Packaged Oil is an automated, convenient,
safer and more cost-effective way to re-ll fryers with fresh cooking oil. Simply
place boxes or jugs upside-down in Frontline racks, connect with a Frontline fresh
oil pump station, and ll your fryers using the convenient, no-mess dispensing
wand — or direct plumb to the fryer for a fully automated solution. Upside-down
storage dispenses every drop of oil, increasing yields by up to 10%.

CONSTRUCTION AND FEATURES

• Heavy gauge stainless steel construction

• Free standing

• Standard shortening Capacity: 140 Lb/18.6 Gal (64 kg/70.4 l)

• For multiple fryers or multiple kitchens, standard three jib dispensing
conguaration can be upgraded to link multiple jib racks, increasing
ll capacity

• Control panel with alarm

• UL, UL Sanitation (NSF) Listed (US and Canada)

• Suitable for automatic top off systems

• Easy to access and service components

• One year warranty on all parts and components

• Worldwide delivery and installation available

BOX SYSTEM

MODEL RACK3-NA

BENEFITS

• Minimal handling of fresh cooking oil

• Insurance and Workman’s Comp savings

• Less employee down time

• Labor savings and greater employee safety

• Great option to bulk delivery of cooking oil

• Avoid pollution nes

Installation and Operating Specifications

Model RACK3-NA RACK SYSTEM
Power Requirements 110 V 15 A - 250 V 3.5 A, 50/60 Hz
Installation Space Requirements 24 in. l x 36 in. w x 55 in. h
(609 mm x 914 mm x 1397 mm)
Shortening Capacity 140 Lb/18.6 Gal (64 kg/70.4 l)
Shipping Weight 70 lb (32 kg)
Documentation Installation guide, Operating guide
Warranty 1 year parts and labor

Frontline International, Inc.

187 Ascot Parkway • Cuyahoga Falls, Ohio 44223
330-861-1100 • 877-776-1100 Fax: [phone] • [e-mail]

© Frontline International, 1/12
