WF 25i REEL R /4R
WF 30i REEL R /2R
Operating instructions
EN
Wire-feed unit
42,0426,0154,EN 017-11092020
Contents
Safety rules 5
Explanation of safety notices 5
General 5
Proper use 5
Environmental conditions 6
Obligations of the operator 6
Obligations of personnel 6
Mains connection 6
Protecting yourself and others 7
Danger from toxic gases and vapours 7
Danger from flying sparks 8
Risks from mains current and welding current 8
Meandering welding currents 9
EMC Device Classifications 10
EMC measures 10
EMF measures 11
Specific hazards 11
Requirement for the shielding gas 12
Danger from shielding gas cylinders 12
Danger from escaping shielding gas 13
Safety measures at the installation location and during transport 13
Safety measures in normal operation 13
Commissioning, maintenance and repair 14
Safety inspection 14
Disposal 15
Safety symbols 15
Data protection 15
Copyright 15
General 16
Safety 16
Device concept 16
Application area 16
Proper use 16
Application example 17
Warning notices on the device 17
Description of Warning Notices on the Device 20
Controls, connections and mechanical components 22
Safety 22
Controls, connections and mechanical components 22
Control panel 24
Fitting the wire-feed unit 26
Fitting the unreeling wirefeeder 26
Inserting/replacing feed rollers 27
Safety 27
General 27
4-roller drive: Inserting/replacing feed rollers 27
2-roller drive: Inserting/replacing feed rollers 28
Feeding in the wire electrode 30
Insulated routing of wire electrode to wirefeeder 30
Safety 30
2- and 4-roller drive: feeding in the wire electrode 30
4-roller drive - setting the contact pressure 31
2-roller drive - setting the contact pressure 32
Care, maintenance and disposal 33
General 33
Safety 33
Every start-up 33
Every 6 months 33
Disposal 33
Troubleshooting 34
EN
3
General 34
Safety 34
Fault diagnosis 34
Technical data 36
WF 25i REEL R /4R/G/W 36
WF 30i REEL R /2R/G/W 36
4
Safety rules
EN
Explanation of
safety notices
DANGER!
Indicates immediate danger.
If not avoided, death or serious injury will result.
▶
WARNING!
Indicates a potentially hazardous situation.
If not avoided, death or serious injury may result.
▶
CAUTION!
Indicates a situation where damage or injury could occur.
If not avoided, minor injury and/or damage to property may result.
▶
NOTE!
Indicates a risk of flawed results and possible damage to the equipment.
General The device is manufactured using state-of-the-art technology and according to recog-
nised safety standards. If used incorrectly or misused, however, it can cause:
- injury or death to the operator or a third party,
- damage to the device and other material assets belonging to the operating company,
- inefficient operation of the device.
All persons involved in commissioning, operating, maintaining and servicing the device
must:
- be suitably qualified,
- have sufficient knowledge of welding and
- read and follow these operating instructions carefully.
The operating instructions must always be at hand wherever the device is being used. In
addition to the operating instructions, attention must also be paid to any generally applicable and local regulations regarding accident prevention and environmental protection.
All safety and danger notices on the device
- must be in a legible state,
- must not be damaged,
- must not be removed,
- must not be covered, pasted or painted over.
For the location of the safety and danger notices on the device, refer to the section
headed "General" in the operating instructions for the device.
Before switching on the device, rectify any faults that could compromise safety.
This is for your personal safety!
Proper use The device is to be used exclusively for its intended purpose.
5
The device is intended solely for the welding processes specified on the rating plate.
Any use above and beyond this purpose is deemed improper. The manufacturer shall not
be held liable for any damage arising from such usage.
Proper use includes:
- carefully reading and following all the instructions given in the operating instructions
- studying and obeying all safety and danger notices carefully
- performing all stipulated inspection and maintenance work.
Never use the device for the following purposes:
- Thawing out pipes
- Charging batteries
- Starting engines
The device is designed for use in industry and the workshop. The manufacturer accepts
no responsibility for any damage caused through use in a domestic setting.
The manufacturer likewise accepts no liability for inadequate or incorrect results.
Environmental
conditions
Obligations of the
operator
Operation or storage of the device outside the stipulated area will be deemed as not in
accordance with the intended purpose. The manufacturer shall not be held liable for any
damage arising from such usage.
Ambient temperature range:
- during operation: -10 °C to + 40 °C (14 °F to 104 °F)
- during transport and storage: -20 °C to +55 °C (-4 °F to 131 °F)
Relative humidity:
- up to 50% at 40 °C (104 °F)
- up to 90% at 20 °C (68 °F)
The surrounding air must be free from dust, acids, corrosive gases or substances, etc.
Can be used at altitudes of up to 2000 m (6561 ft. 8.16 in.)
The operator must only allow persons to work with the device who:
- are familiar with the fundamental instructions regarding safety at work and accident
prevention and have been instructed in how to use the device
- have read and understood these operating instructions, especially the section
"safety rules", and have confirmed as much with their signatures
- are trained to produce the required results.
Checks must be carried out at regular intervals to ensure that operators are working in a
safety-conscious manner.
Obligations of
personnel
Mains connection Devices with a higher rating may affect the energy quality of the mains due to their cur-
6
Before using the device, all persons instructed to do so undertake:
- to observe the basic instructions regarding safety at work and accident prevention
- to read these operating instructions, especially the "Safety rules" section and sign to
confirm that they have understood them and will follow them.
Before leaving the workplace, ensure that people or property cannot come to any harm
in your absence.
rent consumption.
This may affect a number device types in terms of:
- Connection restrictions
-
Criteria with regard to the maximum permissible mains impedance
-
Criteria with regard to the minimum short-circuit power requirement
*)
at the interface with the public grid
*)
*)
see "Technical data"
In this case, the plant operator or the person using the device should check whether the
device may be connected, where appropriate by discussing the matter with the power
supply company.
IMPORTANT! Ensure that the mains connection is earthed properly
EN
Protecting yourself and others
Anyone working with the device exposes themselves to numerous risks, e.g.
- flying sparks and hot pieces of metal
- Arc radiation, which can damage eyes and skin
- Hazardous electromagnetic fields, which can endanger the lives of those using cardiac pacemakers
- Risk of electrocution from mains current and welding current
- Greater noise pollution
- Harmful welding fumes and gases
Suitable protective clothing must be worn when working with the device. The protective
clothing must have the following properties:
- Flame-resistant
- Insulating and dry
- Covers the whole body, is undamaged and in good condition
- Safety helmet
- Trousers with no turn-ups
Protective clothing refers to a variety of different items. Operators should:
- Protect eyes and face from UV rays, heat and sparks using a protective visor and
regulation filter
- Wear regulation protective goggles with side protection behind the protective visor
- Wear stout footwear that provides insulation even in wet conditions
- Protect the hands with suitable gloves (electrically insulated and providing protection
against heat)
- Wear ear protection to reduce the harmful effects of noise and to prevent injury
Danger from
toxic gases and
vapours
Keep all persons, especially children, out of the working area while any devices are in
operation or welding is in progress. If, however, there are people in the vicinity:
- Make them aware of all the dangers (risk of dazzling by the arc, injury from flying
sparks, harmful welding fumes, noise, possible risks from mains current and welding
current, etc.)
- Provide suitable protective equipment
- Alternatively, erect suitable safety screens/curtains.
The fumes produced during welding contain harmful gases and vapours.
Welding fumes contain substances that cause cancer, as stated in Monograph 118 of the
International Agency for Research on Cancer.
Use at-source extraction and a room extraction system.
If necessary, use a welding torch with an integrated extraction device.
Keep your face away from welding fumes and gases.
7
Fumes and hazardous gases
- must not be breathed in
- must be extracted from the working area using appropriate methods.
Ensure an adequate supply of fresh air. Ensure that there is a ventilation rate of at least
20 m³ per hour at all times.
Otherwise, a welding helmet with an air supply must be worn.
If there is any doubt about whether the extraction capacity is sufficient, the measured
toxic emission values should be compared with the permissible limit values.
The following components are responsible, amongst other things, for the degree of toxicity of welding fumes:
- Metals used for the workpiece
- Electrodes
- Coatings
- Cleaners, degreasers, etc.
- Welding process used
The relevant material safety data sheets and manufacturer's specifications for the listed
components should therefore be studied carefully.
Recommendations for trade fair scenarios, risk management measures and for identifying working conditions can be found on the European Welding Association website under
Health & Safety (https://european-welding.org).
Danger from flying sparks
Flammable vapours (e.g. solvent fumes) should be kept away from the arc's radiation
area.
Close the shielding gas cylinder valve or main gas supply if no welding is taking place.
Flying sparks may cause fires or explosions.
Never weld close to flammable materials.
Flammable materials must be at least 11 metres (36 ft. 1.07 in.) away from the arc, or
alternatively covered with an approved cover.
A suitable, tested fire extinguisher must be available and ready for use.
Sparks and pieces of hot metal may also get into adjacent areas through small gaps or
openings. Take appropriate precautions to prevent any danger of injury or fire.
Welding must not be performed in areas that are subject to fire or explosion or near
sealed tanks, vessels or pipes unless these have been prepared in accordance with the
relevant national and international standards.
Do not carry out welding on containers that are being or have been used to store gases,
propellants, mineral oils or similar products. Residues pose an explosive hazard.
Risks from mains
current and welding current
8
An electric shock is potentially life threatening and can be fatal.
Do not touch live parts either inside or outside the device.
During MIG/MAG welding and TIG welding, the welding wire, the wirespool, the feed
rollers and all pieces of metal that are in contact with the welding wire are live.
Always set the wirefeeder up on a sufficiently insulated surface or use a suitable, insulated wirefeeder holder.
Make sure that you and others are protected with an adequately insulated, dry base or
cover for the earth or ground potential. This base or cover must extend over the entire
area between the body and the earth or ground potential.
All cables and leads must be secured, undamaged, insulated and adequately dimensioned. Replace loose connections and scorched, damaged, or inadequately dimensioned cables and leads immediately.
Use the handle to ensure the power connections are tight before every use.
In the case of power cables with a bayonet connector, rotate the power cable around the
longitudinal axis by at least 180° and pretension.
Do not wrap cables or leads around the body or parts of the body.
The electrode (rod electrode, tungsten electrode, welding wire, etc.) must
- never be immersed in liquid for cooling
- Never touch the electrode when the power source is switched on.
Double the open circuit voltage of a power source can occur between the welding electrodes of two power sources. Touching the potentials of both electrodes at the same time
may be fatal under certain circumstances.
Arrange for the mains cable to be checked regularly by a qualified electrician to ensure
the ground conductor is functioning properly.
Protection class I devices require a mains supply with ground conductor and a connector
system with ground conductor contact for proper operation.
EN
Operation of the device on a mains supply without ground conductor and on a socket
without ground conductor contact is only permitted if all national regulations for protective
separation are observed.
Otherwise, this is considered gross negligence. The manufacturer shall not be held liable
for any damage arising from such usage.
If necessary, provide adequate earthing for the workpiece.
Switch off unused devices.
Wear a safety harness if working at height.
Before working on the device, switch it off and pull out the mains plug.
Attach a clearly legible and easy-to-understand warning sign to the device to prevent
anyone from plugging the mains plug back in and switching it on again.
After opening the device:
- Discharge all live components
- Ensure that all components in the device are de-energised.
If work on live parts is required, appoint a second person to switch off the main switch at
the right moment.
Meandering welding currents
If the following instructions are ignored, meandering welding currents can develop with
the following consequences:
- Fire hazard
- Overheating of parts connected to the workpiece
- Irreparable damage to ground conductors
- Damage to device and other electrical equipment
Ensure that the workpiece is held securely by the workpiece clamp.
Attach the workpiece clamp as close as possible to the area that is to be welded.
9
Position the device with sufficient insulation against electrically conductive environments,
e.g. Insulation against conductive floor or insulation to conductive racks.
If distribution boards, twin-head mounts, etc., are being used, note the following: The
electrode of the welding torch / electrode holder that is not used is also live. Make sure
that the welding torch / electrode holder that is not used is kept sufficiently insulated.
In the case of automated MIG/MAG applications, ensure that only an insulated wire electrode is routed from the welding wire drum, large wirefeeder spool or wirespool to the
wirefeeder.
EMC Device Classifications
EMC measures In certain cases, even though a device complies with the standard limit values for emis-
Devices in emission class A:
- Are only designed for use in industrial settings
- Can cause line-bound and radiated interference in other areas
Devices in emission class B:
- Satisfy the emissions criteria for residential and industrial areas. This is also true for
residential areas in which the energy is supplied from the public low-voltage mains.
EMC device classification as per the rating plate or technical data.
sions, it may affect the application area for which it was designed (e.g. when there is
sensitive equipment at the same location, or if the site where the device is installed is
close to either radio or television receivers).
If this is the case, then the operator is obliged to take appropriate action to rectify the
situation.
Check and evaluate the immunity to interference of nearby devices according to national
and international regulations. Examples of equipment that may be susceptible to interference from the device include:
- Safety devices
- Power, signal and data transfer lines
- IT and telecommunications devices
- Measuring and calibrating devices
Supporting measures for avoidance of EMC problems:
1. Mains supply
- If electromagnetic interference arises despite correct mains connection, addi-
tional measures are necessary (e.g. use a suitable line filter).
2. Welding power leads
- must be kept as short as possible
- must run close together (to avoid EMF problems)
- must be kept well apart from other leads
3. Equipotential bonding
4. Earthing of the workpiece
- If necessary, establish an earth connection using suitable capacitors.
5. Shielding, if necessary
- Shield off other nearby devices
- Shield off entire welding installation
10
EMF measures Electromagnetic fields may pose as yet unknown risks to health:
- effects on the health of others in the vicinity, e.g. wearers of pacemakers and hearing aids
- wearers of pacemakers must seek advice from their doctor before approaching the
device or any welding that is in progress
- for safety reasons, keep distances between the welding cables and the welder's
head/torso as large as possible
- do not carry welding cables and hosepacks over the shoulders or wind them around
any part of the body
Specific hazards Keep hands, hair, clothing and tools away from moving parts. For example:
- Fans
- Cogs
- Rollers
- Shafts
- Wirespools and welding wires
Do not reach into the rotating cogs of the wire drive or into rotating drive components.
Covers and side panels may only be opened/removed while maintenance or repair work
is being carried out.
During operation
- Ensure that all covers are closed and all side panels are fitted properly.
- Keep all covers and side panels closed.
EN
The welding wire emerging from the welding torch poses a high risk of injury (piercing of
the hand, injuries to the face and eyes, etc.).
Therefore always keep the welding torch away from the body (devices with wire-feed
unit) and wear suitable protective goggles.
Never touch the workpiece during or after welding - risk of burns.
Slag can jump off cooling workpieces. The specified protective equipment must therefore
also be worn when reworking workpieces, and steps must be taken to ensure that other
people are also adequately protected.
Welding torches and other parts with a high operating temperature must be allowed to
cool down before handling.
Special provisions apply in areas at risk of fire or explosion - observe relevant
national and international regulations.
Power sources for work in areas with increased electric risk (e.g. near boilers) must carry
the "Safety" sign. However, the power source must not be located in such areas.
Risk of scalding from escaping coolant. Switch off cooling unit before disconnecting
coolant flow or return lines.
Observe the information on the coolant safety data sheet when handling coolant. The
coolant safety data sheet may be obtained from your service centre or downloaded from
the manufacturer's website.
Use only suitable load-carrying equipment supplied by the manufacturer when transporting devices by crane.
- Hook chains and/or ropes onto all suspension points provided on the load-carrying
equipment.
- Chains and ropes must be at the smallest angle possible to the vertical.
- Remove gas cylinder and wire-feed unit (MIG/MAG and TIG devices).
11
If the wire-feed unit is attached to a crane holder during welding, always use a suitable,
insulated wirefeeder hoisting attachment (MIG/MAG and TIG devices).
If the device has a carrying strap or handle, this is intended solely for carrying by hand.
The carrying strap is not to be used if transporting with a crane, counterbalanced lift truck
or other mechanical hoist.
All lifting accessories (straps, handles, chains, etc.) used in connection with the device or
its components must be tested regularly (e.g. for mechanical damage, corrosion or
changes caused by other environmental factors).
The testing interval and scope of testing must comply with applicable national standards
and directives as a minimum.
Odourless and colourless shielding gas may escape unnoticed if an adapter is used for
the shielding gas connection. Prior to assembly, seal the device-side thread of the
adapter for the shielding gas connection using suitable Teflon tape.
Requirement for
the shielding gas
Danger from
shielding gas cylinders
Especially with ring lines, contaminated shielding gas can cause damage to equipment
and reduce welding quality.
Meet the following requirements regarding shielding gas quality:
- Solid particle size < 40 µm
- Pressure condensation point < -20 °C
- Max. oil content < 25 mg/m³
Use filters if necessary.
Shielding gas cylinders contain gas under pressure and can explode if damaged. As the
shielding gas cylinders are part of the welding equipment, they must be handled with the
greatest of care.
Protect shielding gas cylinders containing compressed gas from excessive heat, mechanical impact, slag, naked flames, sparks and arcs.
Mount the shielding gas cylinders vertically and secure according to instructions to prevent them falling over.
Keep the shielding gas cylinders well away from any welding or other electrical circuits.
Never hang a welding torch on a shielding gas cylinder.
Never touch a shielding gas cylinder with an electrode.
12
Risk of explosion - never attempt to weld a pressurised shielding gas cylinder.
Only use shielding gas cylinders suitable for the application in hand, along with the correct and appropriate accessories (regulator, hoses and fittings). Only use shielding gas
cylinders and accessories that are in good condition.
Turn your face to one side when opening the valve of a shielding gas cylinder.
Close the shielding gas cylinder valve if no welding is taking place.
If the shielding gas cylinder is not connected, leave the valve cap in place on the cylinder.
The manufacturer's instructions must be observed as well as applicable national and
international regulations for shielding gas cylinders and accessories.
Danger from
escaping shielding gas
Risk of suffocation from the uncontrolled escape of shielding gas
Shielding gas is colourless and odourless and, in the event of a leak, can displace the
oxygen in the ambient air.
- Ensure an adequate supply of fresh air with a ventilation rate of at least 20 m³/hour.
- Observe safety and maintenance instructions on the shielding gas cylinder or the
main gas supply.
- Close the shielding gas cylinder valve or main gas supply if no welding is taking
place.
- Check the shielding gas cylinder or main gas supply for uncontrolled gas leakage
before every start-up.
EN
Safety measures
at the installation
location and during transport
A device toppling over could easily kill someone. Place the device on a solid, level surface such that it remains stable
- The maximum permissible tilt angle is 10°.
Special regulations apply in rooms at risk of fire or explosion
- Observe relevant national and international regulations.
Use internal directives and checks to ensure that the workplace environment is always
clean and clearly laid out.
Only set up and operate the device in accordance with the degree of protection shown
on the rating plate.
When setting up the device, ensure there is an all-round clearance of 0.5 m (1 ft. 7.69
in.) to ensure that cooling air can flow in and out freely.
When transporting the device, observe the relevant national and local guidelines and
accident prevention regulations. This applies especially to guidelines regarding the risks
arising during transport.
Do not lift or transport operational devices. Switch off devices before transport or lifting.
Before transporting the device, allow coolant to drain completely and detach the following components:
- Wirefeeder
- Wirespool
- Shielding gas cylinder
Safety measures
in normal operation
After transporting the device, the device must be visually inspected for damage before
commissioning. Any damage must be repaired by trained service technicians before
commissioning the device.
Only operate the device when all safety devices are fully functional. If the safety devices
are not fully functional, there is a risk of
- injury or death to the operator or a third party
- damage to the device and other material assets belonging to the operator
- inefficient operation of the device
Any safety devices that are not functioning properly must be repaired before switching on
the device.
Never bypass or disable safety devices.
Before switching on the device, ensure that no one is likely to be endangered.
Check the device at least once a week for obvious damage and proper functioning of
safety devices.
13
Always fasten the shielding gas cylinder securely and remove it beforehand if the device
is to be transported by crane.
Only the manufacturer's original coolant is suitable for use with our devices due to its
properties (electrical conductibility, anti-freeze agent, material compatibility, flammability,
etc.).
Only use suitable original coolant from the manufacturer.
Do not mix the manufacturer's original coolant with other coolants.
Only connect the manufacturer's system components to the cooling circuit.
The manufacturer accepts no liability for damage resulting from use of other system
components or a different coolant. In addition, all warranty claims will be forfeited.
Cooling Liquid FCL 10/20 does not ignite. The ethanol-based coolant can ignite under
certain conditions. Transport the coolant only in its original, sealed containers and keep
well away from any sources of ignition.
Used coolant must be disposed of properly in accordance with the relevant national and
international regulations. The coolant safety data sheet may be obtained from your service centre or downloaded from the manufacturer's website.
Check the coolant level before starting to weld, while the system is still cool.
Commissioning,
maintenance and
repair
Safety inspection The manufacturer recommends that a safety inspection of the device is performed at
It is impossible to guarantee that bought-in parts are designed and manufactured to meet
the demands made of them, or that they satisfy safety requirements.
- Use only original spare and wearing parts (also applies to standard parts).
- Do not carry out any modifications, alterations, etc. to the device without the manufacturer's consent.
- Components that are not in perfect condition must be replaced immediately.
- When ordering, please give the exact designation and part number as shown in the
spare parts list, as well as the serial number of your device.
The housing screws provide the ground conductor connection for earthing the housing
parts.
Only use original housing screws in the correct number and tightened to the specified
torque.
least once every 12 months.
The manufacturer recommends that the power source be calibrated during the same 12month period.
A safety inspection should be carried out by a qualified electrician
- after any changes are made
- after any additional parts are installed, or after any conversions
- after repair, care and maintenance has been carried out
- at least every twelve months.
14
For safety inspections, follow the appropriate national and international standards and
directives.
Further details on safety inspection and calibration can be obtained from your service
centre. They will provide you on request with any documents you may require.
Disposal Do not dispose of this device with normal domestic waste! To comply with the European
Directive on Waste Electrical and Electronic Equipment and its implementation as
national law, electrical equipment that has reached the end of its life must be collected
separately and returned to an approved recycling facility. Any device that you no longer
require must either be returned to your dealer or given to one of the approved collection
and recycling facilities in your area. Ignoring this European Directive may have potentially adverse affects on the environment and your health!
Safety symbols Devices with the CE mark satisfy the essential requirements of the low-voltage and elec-
tromagnetic compatibility directives (e.g. relevant product standards of the EN 60 974
series).
Fronius International GmbH hereby declares that the device is compliant with Directive
2014/53/EU. The full text on the EU Declaration of Conformity can be found at the following address: http://www.fronius.com
Devices marked with the CSA test mark satisfy the requirements of the relevant standards for Canada and the USA.
Data protection The user is responsible for the safekeeping of any changes made to the factory settings.
The manufacturer accepts no liability for any deleted personal settings.
EN
Copyright Copyright of these operating instructions remains with the manufacturer.
The text and illustrations are all technically correct at the time of printing. We reserve the
right to make changes. The contents of the operating instructions shall not provide the
basis for any claims whatsoever on the part of the purchaser. If you have any suggestions for improvement, or can point out any mistakes that you have found in the instructions, we will be most grateful for your comments.
15
General
Safety
Incorrect operation or shoddy workmanship can cause serious injury and damage.
▶
Risk of injury from rotating drive parts if covers are open.
▶
Device concept The unreeling wirefeeder is an extra drive unit for ensuring constant and precision
wirefeeding over large wirefeeding distances between the welding wire drum and the
robot wirefeeder.
While in operation, the unreeling wirefeeder is synchronised with the power source.
It is supplied with power and controlled by the power source in the welding system.
WARNING!
The following documents must be completely read and understood before commissioning the unreeling wirefeeder:
these Operating Instructions
the Operating Instructions of the power source in use
the Operating Instructions of all other system components
the safety rules and safety instructions in the above-mentioned documents.
CAUTION!
When performing maintenance or set-up work, make sure that the drive components
of the unreeling wirefeeder cannot be started by the power source, by a wirefeeder
or by any other system add-ons.
The unreeling wirefeeder is available in two versions:
- WF 25i REEL R /4R
Integrated version with 4-roller drive
- WF 30i REEL R /2R
Integrated version with 2-roller drive - not permitted in conjunction with a basket-type
spool
Application area All indoor and automated MIG/MAG applications.
Proper use The device is designed exclusively for wirefeeding in automated MIG/MAG welding
applications in conjunction with Fronius system components. Any use above and beyond
this purpose is deemed improper. The manufacturer shall not be held liable for any damage arising from such usage.
Utilisation in accordance with the intended purpose also comprises:
- carefully reading these operating instructions
- following all the instructions and safety rules in these operating instructions
- performing all stipulated inspection and maintenance work
16
Application
(1) (2)
(3)
(6)
(7)
(8)
(9)
(4)
(5)
(10)
(13)
(14)
(12)
(11)
max. 700 mm
max. 27.6 in.
example
EN
(1) Power source (8) Unreeling wire-feed unit control
line *
(2) Robot interface (9) Wirefeeding hose from unreeling
wire-feed unit to robot wire-feed
unit
(3) Cooling unit (10) Interconnecting hosepack
Warning notices
on the device
(4) Robot control (11) Robot wire-feed unit
(5) Welding wire drum (12) Torch hosepack
(6) Wirefeeding hose to the unreeling
(13) CrashBox
wire-feed unit
(7) Unreeling wire-feed unit (14) Robot welding torch
* As an alternative way of connecting the unreeling wire-feed unit control line (8)
to the power source, the options "OPT/i WF R optional PC board" and "OPT/i
TPS SpeedNet Connector" are required on the power source.
The device is fitted with safety symbols and a rating plate. The safety symbols and rating
plate must not be removed or painted over. The safety symbols warn against operating
the equipment incorrectly, as this may result in serious injury and damage.
17
40,0006,3035
Example: WF 30i REEL R /2R/G/W
Do not dispose of used devices with domestic waste. Dispose of them according to the
safety rules.
Welding is dangerous. The following basic requirements must be met to ensure the
equipment is used properly:
- Anyone performing automated welding must be sufficiently qualified
- Suitable protective equipment must be used
- All persons not involved must be kept at a safe distance from the wirefeeder and the
welding process
Do not use the functions described here until you have fully read and understood the following documents:
- These Operating Instructions
- All the Operating Instructions for the system components, especially the safety rules
18
Keep hands, hair, clothing and tools away from moving parts. For example:
- Cogs
- Feed rollers
- Wirespools and welding wires
Do not reach into the rotating cogs of the wire drive or into rotating drive components.
Covers and side panels may only be opened / removed while maintenance or repair
work is being carried out.
Wear eye protection
EN
19
Description of
AB
Warning Notices
on the Device
On certain device versions, warning notices are attached to the device.
The arrangement of the symbols may vary.
. Warning! Watch Out!
There are possible hazards as shown by the symbols.
A Drive rolls can injure fingers.
B Welding wire and drive parts are at welding voltage during operation
Keep hands and metal objects away.
1. Electric shock can kill.
1.1 Wear dry insulating gloves. Do not touch electrode with bare hand. Do not wear
wet or damaged gloves.
1.2 Protect yourself from electric shock by insulating yourself from work and ground.
1.3 Disconnect input plug or power before working on machine
2. Breathing welding fumes can be hazardous to your health.
2.1 Keep your head out of the fumes.
2.2 Use forced ventilation or local exhaust to remove the fumes.
2.3 Use ventilating fan to remove fumes.
20
3 Welding sparks can cause explosion or fire.
xx,xxxx,xxxx *
3.1 Keep flammables away from welding. Don’t weld near flammables.
3.2 Welding sparks can cause fires.Have a fire extinguisher nearby and have a
watchperson ready to use it.
3.3 Do not weld on drums or any closed containers.
EN
4. Arc rays can burn eyes and injure skin.
4.1 Wear hat and safety glasses. Use ear protection and button shirt collar. Use
welding helmet with correct shade of filter. Wear complete body protection.
5. Become trained and read the instructions before working on the machine or
welding.
6. Do not remove or paint over (cover) the label.
* identifying number to order label from manufacturer
21
Controls, connections and mechanical components
(1)(3) (2)
(1)(5) (4)
(6)(7)
(11) (8)
(9)
(10)
Safety
Controls, connections and mechanical components
WARNING!
Danger from incorrect operation.
This can result in severe personal injury and damage to property.
All the functions described may only be used by trained and qualified personnel.
▶
Fully read and understand this document.
▶
Fully read and understand all the Operating Instructions for the system components,
▶
especially the safety rules.
Front of WF 25i REEL R /4R/G/W
Left side
Front of WF 30i REEL R /2R/G/W
Rear
22
(12)(13)
100 mm
50 mm
4 x M5
3.9 in.
2.0 in.
Top/underside
No. Function
(1) Cover
(2) Protective cover for the 4-roller drive
(3) 4-roller drive
(4) Protective cover for the 2-roller drive
EN
(5) 2-roller drive
(6) Opening for optional sash lock
(7) Control panel
(8) SpeedNet connection
(9) Blanking cover for optional component
(10) Blanking cover for optional component
(11) Blanking cover for optional component
(12) M20 thread
for connecting QuickConnect option
(13) Wire infeed/outfeed tube
Wire infeed (underside)
Wire outfeed (top)
23
Control panel
(1) (2) (3) (4)
No. Function
(1) Operating status LED
Shows steady green when the
device is ready for use
(2) Gas-test button
For setting the required gas flow
rate on the pressure regulator
Gas will flow out for 30 seconds
after the gas-test button is
pressed. Press the button again to
stop the gas flow prematurely.
Gas test / wire threading control panel
No. Function
(3) Wire retract button
For retracting the wire electrode with no accompanying flow of gas or current
The wire electrode can be retracted using one of two methods:
Method 1
Retracting the wire electrode using the preset wire retract speed:
Press and hold "Wire retract" button
- The wire electrode will be retracted 1 mm (0.039 in.) after the wire retract
button is pressed
- After a short pause, the wirefeeder continues to retract the wire electrode. If
the wire retract button remains pressed, the speed will increase every
second at a rate of 10 m/min (393.70 ipm) until the preset wire retract speed
is reached
Method 2
Retracting the wire electrode in 1 mm increments (0.039 in. increments) – always
press the wire retract button for less than one second (tap)
NOTE!
Do not allow long lengths of wire electrode to be retracted, as the wire electrode is
not wound onto the wirespool or the welding wire drum when retracted.
24
NOTE!
If there was a ground earth connection with the contact tip before the wire retract
button was pressed, the wire electrode will be retracted when the button is
pressed until it is short-circuit-free - it retracts by no more 10 mm (0.39 in.) with
each press of the button.
If the wire electrode still needs to be retracted, press the wire retract button again.
(4) Wire threading button
For threading the wire electrode into the torch hosepack with no accompanying
flow of gas or current
Wire threading can be performed using one of two methods:
Method 1
Retracting the wire electrode using the preset feeder inching speed:
Press and hold "Wire threading" button
- The wire electrode will be threaded 1 mm (0.039 in.) after the wire threading
button is pressed
- After a short pause, the wirefeeder continues to thread the wire electrode. If
the wire threading button remains pressed, the speed will increase every
second at a rate of 10 m/min (393.70 ipm) until the preset feeder inching
speed is reached
- If the wire electrode comes into contact with a ground earth connection, the
wirefeeding will be stopped and the wire electrode will be retracted again by
1 mm (0.039 in.)
EN
Method 2
Threading the wire electrode in 1 mm increments (0.039 in. increments) – always
press the wire threading button for less than one second (tap)
If the wire electrode comes into contact with a ground earth connection, the
wirefeeding will be stopped and the wire electrode will be retracted again by
1 mm (0.039 in.).
NOTE!
If there was a ground earth connection with the contact tip before the wire threading button was pressed, the wire electrode will be retracted when the button is
pressed until it is short-circuit-free – it retracts by no more than 10 mm (0.39 in.)
with each press of the button.
If there is still a ground earth connection with the contact tip after 10 mm (0.39 in.) of wire
retraction, pressing the wire threading button again will cause the wire electrode to be
retracted again by a maximum of 10 mm (0.39 in.). The process will be repeated until
there is no longer a ground earth connection with the contact tip.
25
Fitting the wire-feed unit
Fitting the unreeling wirefeeder
WARNING!
An electric shock can be fatal.
If the power source is connected to the mains supply while the work described below is
being carried out, there is a risk of serious injury and damage.
Only carry out the work described below when the power source mains switch is in
▶
the "O" position and when the power source is disconnected from the mains.
Ensure that the unreeling wirefeeder is fitted in the correct direction. The threading
direction of the wire electrode is marked
with an arrow.
The unreeling wirefeeder is designed exclusively for vertical installation on the following
mounts:
- WF Mounting WALL 4,100,846
- WF Mounting Drum 4,100,845
Operating a 2-roller WF30i REEL R /2R unreeling wirefeeder with a basket-type spool is
not permitted.
In accordance with the Installation Instructions, mount the unreeling wirefeeder onto
1
the wall bracket or the wire drum mount
Use the QuickConnect option to connect the wirefeeding hose to the unreeling
2
wirefeeder
Use Fronius SpeedNet to connect the unreeling wirefeeder to the power source in
3
the welding system
26
Inserting/replacing feed rollers
2
1
5
6
3
4
4
3
6
7
4
5
1
2
3
EN
Safety
WARNING!
An electric shock can be fatal.
If the power source is connected to the mains supply while the work described below is
being carried out, there is a high risk of very serious injury and damage. Only carry out
the work described below when:
the power source mains switch is in the "O" position
▶
the power source is unplugged from the mains
▶
General The feed rollers are not installed in the device when it is first delivered.
In order to achieve optimum wire electrode feed, the feed rollers must be suitable for the
diameter and alloy of the wire being welded.
NOTE!
Risk from inadequate feed rollers.
This can result in poor weld properties.
Only use feed rollers that match the wire electrode.
▶
An overview of the feed rollers available and their possible areas of use can be found in
the Spare Parts Lists.
4-roller drive:
Inserting/replacing feed rollers
CAUTION!
Risk of injury if the feed roller holders fly upwards.
When unlocking the clamping lever, keep fingers away from the area to the left and
▶
right of the lever.
1
2
27
CAUTION!
8
6
7
9
2
2
5
1
4
4
3
5
5
1
4
2
6
3
Risk of crushing due to exposed feed rollers.
Always fit the protective cover of the 4-roller drive after changing a feed roller.
▶
2-roller drive:
Inserting/replacing feed rollers
3
1 2
4
CAUTION!
Risk of crushing due to exposed feed rollers.
Always fit the protective cover of the 2-roller drive after changing feed rollers.
▶
28
3 4
5
EN
29
Feeding in the wire electrode
Insulated routing
of wire electrode
to wirefeeder
WARNING!
Risk of serious injury and damage or an inferior weld as a result of earth contact
or short-circuit of a non-insulated wire electrode.
In the case of automated applications, ensure that only an insulated wire electrode is
▶
routed from the welding wire drum, large wirefeeder spool or wirespool to the
wirefeeder (e.g. by using a wirefeeding hose).
An earth contact or short-circuit can be caused by:
- a non-insulated, exposed length of wire electrode coming into contact with a conductive object during the welding process
- missing insulation between the wire electrode and the earthed enclosure of a robot
cell
- chafed wirefeeding hoses, exposing the wire electrode
To avoid earth contact or short-circuit:
- Use wirefeeding hoses for insulated routing of wire electrode to wirefeeder
- To prevent chafing, do not route the wirefeeding hoses over sharp edges
- Use hose holders or hose protectors where necessary
- Coupling pieces and hoods for welding wire drums are recommended to ensure safe
transport of the wire electrode
Safety
2- and 4-roller
drive: feeding in
the wire electrode
CAUTION!
Risk of injury by rotating drive components if the cover is opened for maintenance
or set-up work.
Make sure that the drive components of the unreeling wire-feed unit cannot be started at
the power source, the unreeling wire-feed unit itself or other system add-ons.
CAUTION!
Risk of damage to wirefeeding hose and welding torch from sharp end of wire
electrode.
Deburr the end of the wire electrode well before feeding in.
CAUTION!
Risk of injury from springiness of spooled wire electrode.
When inserting the wire electrode into the wirefeeding hose, hold the end of the wire
electrode firmly to avoid injuries caused by the wire springing back.
Slide the wire electrode from the welding wire drum through the wirefeeding hose
1
and up to the feed rollers on the unreeling wire-feed unit
30
CAUTION!
1
2
Risk of injury from wire electrode emerging at speed.
A wire jam may lead to the wire electrode protruding, especially with thin or soft wire
electrodes.
Keep your face and body well away from the 4-roller drive on the robot wire-feed unit.
Use suitable protective goggles.
Press the "Wire threading" button: on the unreeling wire-feed unit, on the robot wire-
2
feed unit or on the power source
- Feed the wire electrode into the wirefeeding hose between the unreeling wirefeed unit and the robot wire-feed unit until the wire electrode arrives at the feed
rollers of the robot wire-feed unit.
Thread the wire electrode into the torch hosepack as described in the operating
3
instructions for the robot wire-feed unit
EN
4-roller drive setting the contact pressure
NOTE!
Set the contact pressure in such a way that the wire electrode is not deformed but
nevertheless ensures proper wirefeeding.
1
Contact pressure stand-
Steel rollers
ard values
Steel 4 - 5
CrNi 4 - 5
Al 0.5 - 1.5
Tubular cored elec-
2 - 3
trodes
Contact pressure stand-
Plastic rollers
ard values
Al 3 - 4
31
2-roller drive setting the contact pressure
NOTE!
Set the contact pressure in such a way that the wire electrode is not deformed but
nevertheless ensures proper wirefeeding.
1 2
Contact pressure standard values
U-groove
rollers
Steel 4 - 6
CrNi 4 - 6
AlMg 3 - 5
Al, AlSi 2 - 4
Tubular cored elec-
3 - 5
trodes
32
Care, maintenance and disposal
General Under normal operating conditions, the welding system requires only a minimum of care
and maintenance. However, it is vital to observe some important points to ensure the
welding system remains in a usable condition for many years.
EN
Safety
An electric shock can be fatal.
Before opening the device
▶
▶
▶
▶
Work that is carried out incorrectly can cause serious injury and damage.
▶
▶
Every start-up - Check torch hosepack, interconnecting hosepack and ground earth connection for
- Check feed rollers and inner liners for signs of damage. Replace any damaged com-
- Check contact pressure of feed rollers and adjust if necessary
- Check that all screw connections between the robot, wire-feed unit mount and wire-
- Check all screw joints on system components and associated mounts for tightness
WARNING!
Turn the mains switch to the "O" position
Unplug the device from the mains
Ensure the device cannot be switched back on
Using a suitable measuring instrument, check to make sure that electrically charged
components (e.g. capacitors) have been discharged
WARNING!
The following activities must only be carried out by trained and qualified personnel.
All instructions in the section headed "Safety rules" must be observed.
signs of damage. Replace any damaged components
ponents
feed unit are secure
Every 6 months
Disposal Dispose of in accordance with the applicable national and local regulations.
NOTE!
Risk of damage to electronic components.
Do not bring the air nozzle too close to electronic components.
- Remove the cover from the device and clean the inside with dry reduced compressed air
33
Troubleshooting
General The devices are equipped with an intelligent safety system. This means that to a large
extent it has been possible to dispense with melting-type fuses. Melting-type fuses therefore no longer need to be replaced. After a possible malfunction has been remedied, the
device is ready for use again.
Safety
Work that is carried out incorrectly can cause serious injury or damage.
The activities described below must only be carried out by trained and qualified personnel. Read the safety rules in the wire-feed unit operating instructions.
An electric shock can be fatal.
Before opening the unit
▶
▶
▶
▶
Fault diagnosis Make a note of the serial number and configuration of the device and contact our After-
Sales Service team with a detailed description of the error, if
- errors occur that are not listed below
- the troubleshooting measures listed are unsuccessful
WARNING!
WARNING!
Turn the mains switch to the "O" position
Unplug the device from the mains
Put up an easy-to-understand warning sign to stop anybody inadvertently switching
it back on again
Using a suitable measuring device, check to make sure that electrically charged
components (e.g. capacitors) have discharged
Irregular wire feed speed
Cause Hole in the contact tip is too narrow
Remedy Use a suitable contact tip
Cause Faulty inner liner in welding torch
Remedy Check the inner liner for kinks, dirt, etc.
Cause The feed rollers are not suitable for the wire electrode being
used
Remedy Use suitable feed rollers
Cause Feed rollers have the wrong contact pressure
Remedy Optimise the contact pressure
Wirefeed problems
when using long hosepacks
34
Cause Incorrect arrangement of hosepack
Remedy Arrange the hosepack in as straight a line as possible, avoid
tight bends
EN
35
Technical data
WF 25i REEL R
/4R/G/W
WF 30i REEL R
/2R/G/W
Supply voltage 24 V DC / 60 V DC
Nominal current 0.5 A / 1.2 A
Wire feed speed 1 - 25 m/min
39.37 - 984.25 ipm.
Wire drive 4-roller drive
Wire diameter 0.8 - 2.4 mm
0.03 - 0.09 in.
Degree of protection IP 21
Marks of conformity CE, CSA
Dimensions l x w x h 250 x 210 x 190 mm
9.8 x 8.3 x 7.5 in.
Weight 4.8 kg
10.58 Ib.
Supply voltage 24 V DC / 60 V DC
Nominal current 0.5 A / 0.9 A
Wire feed speed 1 - 30 m/min
39.37 - 1181.10 ipm.
Wire drive 2-roller drive
Wire diameter 0.8 - 1.6 mm
0.03 - 0.06 in.
Degree of protection IP 21
Marks of conformity CE, CSA
Dimensions l x w x h 250 x 210 x 190 mm
9.8 x 8.3 x 7.5 in.
Weight 4.6 kg
10.14 Ib.
36
EN
37
38
EN
39
FRONIUS INTERNATIONAL GMBH
Froniusstraße 1
A-4643 Pettenbach
AUSTRIA
contact@fronius.com
www.fronius.com
Under www.fronius.com/contact you will find the addresses
of all Fronius Sales & Service Partners and locations.
Loading...
