Fronius TransSteel 2500c, TransSteel 2500c MV, TransSteel 3500c, TransSteel 2700c, TransSteel 2700c MV Operating Instructions Manual
Page 1
/ Perfect Charging / Perfect Welding / Solar Energy
42,0426,0107,EN 034-09012018
TransSteel 2500c
TransSteel 2500c MV
TransSteel 2700c
TransSteel 2700c MV
TransSteel 3500c
Operating Instructions
MIG/MAG Power source
EN
Page 2
2
Page 3
3
EN
Dear reader,
Introduction Thank you for the trust you have placed in our company and congratulations on buying this
high-quality Fronius product. These instructions will help you familiarise yourself with the
product. Reading the instructions carefully will enable you to learn about the many different
features it has to offer. This will allow you to make full use of its advantages.
Please also note the safety rules to ensure greater safety when using the product. Careful
handling of the product will repay you with years of safe and reliable operation. These are
essential prerequisites for excellent results.
Explanation of
safety symbols
If you see any of the symbols depicted in the "Safety rules" chapter, special care is required.
DANGER! Indicates immediate and real danger. If it is not avoided, death or serious injury will result.
WARNING! Indicates a potentially dangerous situation. Death or serious injury
may result if appropriate precautions are not taken.
CAUTION! Indicates a situation where damage or injury could occur. If it is not
avoided, minor injury and/or damage to property may result.
NOTE! Indicates a risk of flawed results and possible damage to the equipment.
IMPORTANT! Indicates tips for correct operation and other particularly useful information.
It does not indicate a potentially damaging or dangerous situation.
Page 4
4
Page 5
5
EN
Contents
Safety rules ................................................................................................................................................ 9
General ................................................................................................................................................. 9
Proper use ............................................................................................................................................ 9
Environmental conditions...................................................................................................................... 10
Obligations of the operator.................................................................................................................... 10
Obligations of personnel ....................................................................................................................... 10
Mains connection .................................................................................................................................. 10
Protecting yourself and others .............................................................................................................. 11
Danger from toxic gases and vapours .................................................................................................. 11
Danger from flying sparks ..................................................................................................................... 12
Risks from mains current and welding current...................................................................................... 12
Meandering welding currents................................................................................................................ 13
EMC Device Classifications .................................................................................................................. 14
EMC measures ..................................................................................................................................... 14
EMF measures...................................................................................................................................... 14
Specific hazards.................................................................................................................................... 15
Factors affecting welding results........................................................................................................... 16
Danger from shielding gas cylinders..................................................................................................... 16
Danger from escaping shielding gas..................................................................................................... 17
Safety measures in normal operation ................................................................................................... 17
Commissioning, maintenance and repair.............................................................................................. 18
Safety inspection................................................................................................................................... 18
Disposal ................................................................................................................................................ 18
Safety symbols...................................................................................................................................... 19
Data protection...................................................................................................................................... 19
Copyright............................................................................................................................................... 19
General information 21
General ...................................................................................................................................................... 23
Device concept ..................................................................................................................................... 23
Functional principle ............................................................................................................................... 23
Application areas .................................................................................................................................. 23
Warning notices on the device.............................................................................................................. 24
System components .................................................................................................................................. 25
General ................................................................................................................................................. 25
Safety.................................................................................................................................................... 25
Overview ............................................................................................................................................... 25
Options....................................................................................................................................................... 27
VRD: safety function ............................................................................................................................. 27
VRD: safety principle ............................................................................................................................ 27
Control elements and connections 29
Synergic Central control panel................................................................................................................... 31
General ................................................................................................................................................. 31
Safety.................................................................................................................................................... 31
Synergic control panel .......................................................................................................................... 31
Service parameters............................................................................................................................... 34
Keylock ................................................................................................................................................. 35
Connections, switches and mechanical components ................................................................................ 36
Front and rear sides, TSt 2500c / TSt 2700c ........................................................................................ 36
Front and rear sides, TSt 3500c ........................................................................................................... 37
Side view............................................................................................................................................... 38
Installation and commissioning 39
Minimum equipment needed for welding task............................................................................................ 41
General ................................................................................................................................................. 41
MIG/MAG welding, gas-cooled ............................................................................................................. 41
Page 6
6
MIG/MAG welding, water-cooled .......................................................................................................... 41
Manual metal arc welding ..................................................................................................................... 41
Before installation and commissioning....................................................................................................... 42
Safety.................................................................................................................................................... 42
Utilisation for intended purpose only..................................................................................................... 42
Setup regulations .................................................................................................................................. 42
Mains connection .................................................................................................................................. 42
Connecting the mains cable....................................................................................................................... 44
General ................................................................................................................................................. 44
Stipulated mains cables and strain-relief devices ................................................................................. 44
Connecting the mains cable.................................................................................................................. 44
Fitting the strain-relief device, TSt 2500c MV / TSt 2700c, single-phase operation ............................. 45
Fitting the strain-relief device, TSt 2500c / TSt 2700c .......................................................................... 46
Fitting the strain-relief device, TSt 2500c MV / TSt 2700c MV ............................................................. 47
Fitting the strain-relief device, TSt 3500c.............................................................................................. 48
Fitting the Canada / U S strain-relief device, TSt 3500c ....................................................................... 48
Generator-powered operation.................................................................................................................... 50
Generator-powered operation............................................................................................................... 50
Single-phase operation .............................................................................................................................. 51
Single-phase operation ......................................................................................................................... 51
Explanation of the term „duty cycle“ in single-phase operation ............................................................ 52
Welding time in single-phase operation ................................................................................................ 52
Fitting/connecting the system components................................................................................................ 54
Information on system components ...................................................................................................... 54
Mounting on the trolley.......................................................................................................................... 54
Connecting the gas cylinder.................................................................................................................. 54
Connecting a MIG/MAG welding torch.................................................................................................. 55
Establishing a ground (earth) connection ............................................................................................ 56
Inserting/replacing feed rollers.............................................................................................................. 56
Inserting the wirespool/basket-type spool............................................................................................. 57
Feeding in the wire electrode................................................................................................................ 58
Setting the contact pressure ................................................................................................................. 60
Adjusting the brake ............................................................................................................................... 60
Design of the brake............................................................................................................................... 61
Start-up ...................................................................................................................................................... 62
General ................................................................................................................................................. 62
Prerequisites ......................................................................................................................................... 62
Commissioning ..................................................................................................................................... 62
Welding 63
Power limitation.......................................................................................................................................... 65
Safety function ...................................................................................................................................... 65
MIG/MAG modes ....................................................................................................................................... 66
General ................................................................................................................................................. 66
Symbols and their explanations ............................................................................................................ 66
2-step mode .......................................................................................................................................... 67
4-step mode .......................................................................................................................................... 67
Special 4-step mode ............................................................................................................................. 67
Spot welding ......................................................................................................................................... 67
2-step stitch welding ............................................................................................................................. 68
4-step stitch welding ............................................................................................................................. 68
MIG/MAG welding...................................................................................................................................... 69
Safety.................................................................................................................................................... 69
Overview ............................................................................................................................................... 69
MIG/MAG standard synergic welding ........................................................................................................ 70
MIG/MAG standard synergic welding ................................................................................................... 70
Corrections during welding ................................................................................................................... 70
MIG/MAG standard manual welding .......................................................................................................... 72
General ................................................................................................................................................. 72
Available parameters ............................................................................................................................ 72
MIG/MAG standard manual welding ..................................................................................................... 72
Corrections during welding ................................................................................................................... 73
MMA welding ............................................................................................................................................. 74
Page 7
7
EN
Safety.................................................................................................................................................... 74
Preparation ........................................................................................................................................... 74
MMA welding ........................................................................................................................................ 74
Corrections during welding ................................................................................................................... 75
HotStart function ................................................................................................................................... 75
Anti-stick function.................................................................................................................................. 75
Saving and retrieving operating points....................................................................................................... 76
General ................................................................................................................................................. 76
Saving operating points ........................................................................................................................ 76
Retrieving operating points ................................................................................................................... 76
Deleting operating points ...................................................................................................................... 76
Retrieving operating points on the Up/Down welding torch .................................................................. 76
Setup settings 79
Setup menu................................................................................................................................................ 81
General remarks ................................................................................................................................... 81
Configuring the setup parameters......................................................................................................... 81
Setup parameters for MIG/MAG standard manual welding .................................................................. 82
Setup parameters for MIG/MAG standard synergic welding................................................................. 84
Setup parameters for MMA welding...................................................................................................... 86
Setup menu - Level 2................................................................................................................................. 87
Restrictions ........................................................................................................................................... 87
Configuring the setup parameters......................................................................................................... 87
Parameters for MIG/MAG welding in the Setup menu level 2 .............................................................. 89
Parameters for manual metal arc (MMA) welding in the Setup menu level 2 ....................................... 90
Measuring welding circuit resistance r ....................................................................................................... 91
General ................................................................................................................................................. 91
Measure the welding circuit resistance r............................................................................................... 91
Displaying welding circuit inductivity L ....................................................................................................... 92
General ................................................................................................................................................. 92
Displaying welding circuit inductivity L .................................................................................................. 92
Laying the hosepacks correctly............................................................................................................. 92
Troubleshooting and maintenance 93
Troubleshooting ......................................................................................................................................... 95
General ................................................................................................................................................. 95
Safety.................................................................................................................................................... 95
Fault diagnosis...................................................................................................................................... 95
Displayed service codes ....................................................................................................................... 98
Care, maintenance and disposal ............................................................................................................... 104
General ................................................................................................................................................. 104
Safety.................................................................................................................................................... 104
At every start-up.................................................................................................................................... 104
If necessary........................................................................................................................................... 104
Every 2 months ..................................................................................................................................... 104
Every 6 months ..................................................................................................................................... 104
Disposal ................................................................................................................................................ 105
Technical data............................................................................................................................................ 106
Special voltages.................................................................................................................................... 106
Explanation of the term "duty cycle" ..................................................................................................... 106
TSt 2500c.............................................................................................................................................. 107
TSt 2500c MV ....................................................................................................................................... 108
TSt 2700c.............................................................................................................................................. 110
TSt 2700c MV ....................................................................................................................................... 111
TSt 3500c.............................................................................................................................................. 113
Appendix .................................................................................................................................................... 114
Quick reference..................................................................................................................................... 114
TSt 2500c / TSt 2700c welding program table ..................................................................................... 116
TSt 2500c USA / TSt 2700c USA welding program table .................................................................... 117
TransSteel 3500 Euro welding program tables .................................................................................... 118
TransSteel 3500 US welding program tables ...................................................................................... 119
Page 8
8
Page 9
9
EN
Safety rules
General
Proper use
The device is manufactured using state-of-the-art technology and according
to recognised safety standards. If used incorrectly or misused, however, it can
cause:
- injury or death to the operator or a third party,
- damage to the device and other material assets belonging to the operating company,
- inefficient operation of the device.
All persons involved in commissioning, operating, maintaining and servicing
the device must:
- be suitably qualified,
- have sufficient knowledge of welding and
- read and follow these operating instructions carefully.
The operating instructions must always be at hand wherever the device is being used. In addition to the operating instructions, attention must also be paid
to any generally applicable and local regulations regarding accident prevention and environmental protection.
All safety and danger notices on the device
- must be in a legible state,
- must not be damaged,
- must not be removed,
- must not be covered, pasted or painted over.
For the location of the safety and danger notices on the device, refer to the
section headed "General" in the operating instructions for the device.
Before switching on the device, rectify any faults that could compromise safety.
This is for your personal safety!
The device is to be used exclusively for its intended purpose.
The device is intended solely for the welding processes specified on the rating
plate.
Any use above and beyond this purpose is deemed improper. The manufacturer shall not be held liable for any damage arising from such usage.
Proper use includes:
- carefully reading and following all the instructions given in the operating
instructions
- studying and obeying all safety and danger notices carefully
- performing all stipulated inspection and maintenance work.
Never use the device for the following purposes:
- Thawing out pipes
- Charging batteries
- Starting engines
The device is designed for use in industry and the workshop. The manufacturer accepts no responsibility for any damage caused through use in a domestic
setting.
The manufacturer likewise accepts no liability for inadequate or incorrect results.
Page 10
10
Environmental
conditions
Obligations of the
operator
Obligations of
personnel
Mains connection
Operation or storage of the device outside the stipulated area will be deemed
as not in accordance with the intended purpose. The manufacturer shall not
be held liable for any damage arising from such usage.
Ambient temperature range:
- during operation: -10 °C to + 40 °C (14 °F to 104 °F)
- during transport and storage: -20 °C to +55 °C (-4 °F to 131 °F)
Relative humidity:
- up to 50% at 40 °C (104 °F)
- up to 90% at 20 °C (68 °F)
The surrounding air must be free from dust, acids, corrosive gases or substances, etc.
Can be used at altitudes of up to 2000 m (6561 ft. 8.16 in.)
The operator must only allow persons to work with the device who:
- are familiar with the fundamental instructions regarding safety at work and
accident prevention and have been instructed in how to use the device
- have read and understood these operating instructions, especially the
section "safety rules", and have confirmed as much with their signatures
- are trained to produce the required results.
Checks must be carried out at regular intervals to ensure that operators are
working in a safety-conscious manner.
Before using the device, all persons instructed to do so undertake:
- to observe the basic instructions regarding safety at work and accident
prevention
- to read these operating instructions, especially the "Safety rules" section
and sign to confirm that they have understood them and will follow them.
Before leaving the workplace, ensure that people or property cannot come to
any harm in your absence.
Devices with a higher rating may affect the energy quality of the mains due to
their current consumption.
This may affect a number of types of device in terms of:
- connection restrictions
- criteria with regard to the maximum permissible mains impedance
*)
- criteria with regard to the minimum short-circuit power requirement
*)
*)
at the interface with the public grid
see Technical Data
In this case, the plant operator or the person using the device should check
whether the device may be connected, where appropriate by discussing the
matter with the power supply company.
NOTE! Ensure that the mains connection is earthed properly
Page 11
11
EN
Protecting yourself and others
Danger from toxic
gases and vapours
Persons involved with welding expose themselves to numerous risks, e.g.:
- flying sparks and hot pieces of metal
- arc radiation, which can damage eyes and skin
- hazardous electromagnetic fields, which can endanger the lives of those
using cardiac pacemakers
- risk of electrocution from mains current and welding current
- greater noise pollution
- harmful welding fumes and gases
Anyone working on the workpiece while welding is in progress must wear suitable protective clothing with the following properties:
- flame-resistant
- insulating and dry
- covers the whole body, is undamaged and in good condition
- safety helmet
- trousers with no turn-ups
Protective clothing refers to a variety of different items. Operators should:
- protect eyes and face from UV rays, heat and sparks using a protective
visor and regulation filter.
- wear regulation protective goggles with side protection behind the protective visor.
- wear stout footwear that provides insulation even in wet conditions.
- protect the hands with suitable gloves (electrically insulated and providing
protection against heat).
- wear ear protection to reduce the harmful effects of noise and to prevent
injury.
Keep all persons, especially children, out of the working area while any devices are in operation or welding is in progress. If, however, there are people in
the vicinity,
- make them aware of all the dangers (risk of dazzling by the arc, injury
from flying sparks, harmful welding fumes, noise, possible risks from
mains current and welding current, etc.),
- provide suitable protective equipment or
- erect suitable safety screens/curtains.
The fumes produced during welding contain harmful gases and vapours.
Welding fumes contain substances that may, under certain circumstances,
cause birth defects or cancer.
Keep your face away from welding fumes and gases.
Fumes and hazardous gases
- must not be breathed in
- must be extracted from the working area using appropriate methods.
Ensure an adequate supply of fresh air with a ventilation rate of at least 20 m³/
hour.
Page 12
12
Danger from flying sparks
Risks from mains
current and welding current
Otherwise, a protective mask with an air supply must be worn.
Close the shielding gas cylinder valve or main gas supply if no welding is taking place.
If there is any doubt about whether the extraction capacity is sufficient, the
measured toxic emission values should be compared with the permissible limit
values.
Amongst others, the following components are responsible for the degree of
toxicity of welding fumes:
- Metals used for the workpiece
- Electrodes
- Coatings
- Cleaners, degreasers, etc.
The relevant material safety data sheets and manufacturer's specifications for
the listed components should therefore be studied carefully.
Flammable vapours (e.g. solvent fumes) should be kept away from the arc's
radiation area.
Flying sparks may cause fires or explosions.
Never weld close to flammable materials.
Flammable materials must be at least 11 metres (36 ft. 1.07 in.) away from the
arc, or alternatively covered with an approved cover.
A suitable, tested fire extinguisher must be available and ready for use.
Sparks and pieces of hot metal may also get into adjacent areas through small
gaps or openings. Take appropriate precautions to prevent any danger of injury or fire.
Welding must not be performed in areas that are subject to fire or explosion or
near sealed tanks, vessels or pipes unless these have been prepared in accordance with the relevant national and international standards.
Do not carry out welding on containers that are being or have been used to
store gases, propellants, mineral oils or similar products. Residues pose an
explosive hazard.
An electric shock is potentially life threatening and can be fatal.
Do not touch live parts either inside or outside the device.
During MIG/MAG welding and TIG welding, the welding wire, the wirespool,
the feed rollers and all pieces of metal that are in contact with the welding wire
are live.
Always set the wirefeeder up on a sufficiently insulated surface or use a suitable, insulated wirefeeder holder.
Make sure that you and others are protected with an adequately insulated, dry
temporary backing or cover for the earth or ground potential. This temporary
backing or cover must extend over the entire area between the body and the
earth or ground potential.
Page 13
13
EN
Meandering welding currents
All cables and leads must be secured, undamaged, insulated and adequately
dimensioned. Replace loose connections and scorched, damaged or inadequately dimensioned cables and leads immediately.
Use the handle to ensure the power connections are tight before every use.
In the case of power cables with a bayonet connector, rotate the power cable
around the longitudinal axis by at least 180° and pre-load.
Do not wrap cables or leads around the body or parts of the body.
The electrode (rod electrode, tungsten electrode, welding wire, etc.) must
- never be immersed in liquid for cooling
- Never touch the electrode when the power source is switched on.
Double the open circuit voltage of a power source can occur between the
welding electrodes of two power sources. Touching the potentials of both electrodes at the same time may be fatal under certain circumstances.
Arrange for the mains cable to be checked regularly by a qualified electrician
to ensure the ground conductor is functioning properly.
The device must only be operated on a mains supply with a ground conductor
and a socket with a ground conductor contact.
Operating the device on a grid without a ground conductor and in a socket
without a ground conductor contact will be deemed gross negligence. The
manufacturer shall not be held liable for any damage arising from such usage.
If necessary, provide an adequate earth connection for the workpiece.
Switch off unused devices.
Wear a safety harness if working at height.
Before working on the device, switch it off and pull out the mains plug.
Attach a clearly legible and easy-to-understand warning sign to the device to
prevent anyone from plugging the mains plug back in and switching it on
again.
After opening the device:
- Discharge all live components
- Ensure that all components in the device are de-energised
If work on live parts is required, appoint a second person to switch off the main
switch at the right moment.
If the following instructions are ignored, meandering welding currents can develop with the following consequences:
- Fire hazard
- Overheating of parts connected to the workpiece
- Irreparable damage to ground conductors
- Damage to device and other electrical equipment
Ensure that the workpiece is held securely by the workpiece clamp.
Attach the workpiece clamp as close as possible to the area that is to be welded.
If the floor is electrically conductive, the device must be set up with sufficient
insulating material to insulate it from the floor.
If distribution boards, twin-head mounts, etc., are being used, note the following: The electrode of the welding torch / electrode holder that is not used is
also live. Make sure that the welding torch / electrode holder that is not used
is kept sufficiently insulated.
In the case of automated MIG/MAG applications, ensure that only an insulated
wire electrode is routed from the welding wire drum, large wirefeeder spool or
wirespool to the wire-feed unit.
Page 14
14
EMC Device Classifications
EMC measures
EMF measures
Devices in emission class A:
- Are only designed for use in industrial settings
- Can cause line-bound and radiated interference in other areas
Devices in emission class B:
- Satisfy the emissions criteria for residential and industrial areas.
This is also true for residential areas in which the energy is supplied from the public low-voltage mains.
EMC device classification as per the rating plate or technical data.
In certain cases, even though a device complies with the standard limit values
for emissions, it may affect the application area for which it was designed (e.g.
when there is sensitive equipment at the same location, or if the site where the
device is installed is close to either radio or television receivers).
If this is the case, then the operator is obliged to take appropriate action to rectify the situation.
Check and evaluate the immunity to interference of nearby devices according
to national and international regulations. Examples of equipment that may be
susceptible to interference from the device include:
- Safety devices
- Power, signal and data transfer lines
- IT and telecommunications devices
- Measuring and calibrating devices
Supporting measures for avoidance of EMC problems:
1. Mains supply
- If electromagnetic interference arises despite correct mains connection, additional measures are necessary (e.g. use a suitable line filter).
2. Welding power leads
- must be kept as short as possible
- must run close together (to avoid EMF problems)
- must be kept well apart from other leads
3. Equipotential bonding
4. Earthing of the workpiece
- If necessary, establish an earth connection using suitable capacitors.
5. Shielding, if necessary
- Shield off other nearby devices
- Shield off entire welding installation
Electromagnetic fields may pose as yet unknown risks to health:
- effects on the health of others in the vicinity, e.g. wearers of pacemakers
and hearing aids
- wearers of pacemakers must seek advice from their doctor before approaching the device or any welding that is in progress
- for safety reasons, keep distances between the welding cables and the
welder's head/torso as large as possible
- do not carry welding cables and hosepacks over the shoulders or wind
them around any part of the body
Page 15
15
EN
Specific hazards
Keep hands, hair, clothing and tools away from moving parts. For example:
- Fans
- Cogs
- Rollers
- Shafts
- Wirespools and welding wires
Do not reach into the rotating cogs of the wire drive or into rotating drive components.
Covers and side panels may only be opened/removed while maintenance or
repair work is being carried out.
During operation
- Ensure that all covers are closed and all side panels are fitted properly.
- Keep all covers and side panels closed.
The welding wire emerging from the welding torch poses a high risk of injury
(piercing of the hand, injuries to the face and eyes, etc.).
Therefore always keep the welding torch away from the body (devices with
wire-feed unit) and wear suitable protective goggles.
Never touch the workpiece during or after welding - risk of burns.
Slag can jump off cooling workpieces. The specified protective equipment
must therefore also be worn when reworking workpieces, and steps must be
taken to ensure that other people are also adequately protected.
Welding torches and other parts with a high operating temperature must be allowed to cool down before handling.
Special provisions apply in areas at risk of fire or explosion - observe relevant
national and international regulations.
Power sources for work in areas with increased electric risk (e.g. near boilers)
must carry the "Safety" sign. However, the power source must not be located
in such areas.
Risk of scalding from escaping coolant. Switch off cooling unit before disconnecting coolant flow or return lines.
Observe the information on the coolant safety data sheet when handling coolant. The coolant safety data sheet may be obtained from your service centre
or downloaded from the manufacturer's website.
Use only suitable load-carrying equipment supplied by the manufacturer when
transporting devices by crane.
- Hook chains and/or ropes onto all suspension points provided on the
load-carrying equipment.
- Chains and ropes must be at the smallest angle possible to the vertical.
- Remove gas cylinder and wire-feed unit (MIG/MAG and TIG devices).
If the wire-feed unit is attached to a crane holder during welding, always use
a suitable, insulated wirefeeder hoisting attachment (MIG/MAG and TIG devices).
Page 16
16
Factors affecting
welding results
Danger from
shielding gas cylinders
If the device has a carrying strap or handle, this is intended solely for carrying
by hand. The carrying strap is not to be used if transporting with a crane, counterbalanced lift truck or other mechanical hoist.
All lifting accessories (straps, handles, chains, etc.) used in connection with
the device or its components must be tested regularly (e.g. for mechanical
damage, corrosion or changes caused by other environmental factors).
The testing interval and scope of testing must comply with applicable national
standards and directives as a minimum.
Odourless and colourless shielding gas may escape unnoticed if an adapter
is used for the shielding gas connection. Prior to assembly, seal the deviceside thread of the adapter for the shielding gas connection using suitable Teflon tape.
The following requirements with regard to shielding gas quality must be met if
the welding system is to operate in a correct and safe manner:
- Size of solid matter particles < 40 μm
- Pressure dew point < -20 °C
- Max. oil content < 25 mg/m³
Filters must be used if necessary.
NOTE! There is an increased risk of soiling if ring mains are being
used
Shielding gas cylinders contain gas under pressure and can explode if damaged. As the shielding gas cylinders are part of the welding equipment, they
must be handled with the greatest of care.
Protect shielding gas cylinders containing compressed gas from excessive
heat, mechanical impact, slag, naked flames, sparks and arcs.
Mount the shielding gas cylinders vertically and secure according to instructions to prevent them falling over.
Keep the shielding gas cylinders well away from any welding or other electrical
circuits.
Never hang a welding torch on a shielding gas cylinder.
Never touch a shielding gas cylinder with an electrode.
Risk of explosion - never attempt to weld a pressurised shielding gas cylinder.
Only use shielding gas cylinders suitable for the application in hand, along with
the correct and appropriate accessories (regulator, hoses and fittings). Only
use shielding gas cylinders and accessories that are in good condition.
Turn your face to one side when opening the valve of a shielding gas cylinder.
Close the shielding gas cylinder valve if no welding is taking place.
If the shielding gas cylinder is not connected, leave the valve cap in place on
the cylinder.
The manufacturer's instructions must be observed as well as applicable national and international regulations for shielding gas cylinders and accessories.
Page 17
17
EN
Danger from escaping shielding
gas
Safety measures
in normal operation
Risk of suffocation from the uncontrolled escape of shielding gas
Shielding gas is colourless and odourless and, in the event of a leak, can displace the oxygen in the ambient air.
- Ensure an adequate supply of fresh air with a ventilation rate of at least
20 m³/hour.
- Observe safety and maintenance instructions on the shielding gas cylinder or the main gas supply.
- Close the shielding gas cylinder valve or main gas supply if no welding is
taking place.
- Check the shielding gas cylinder or main gas supply for uncontrolled gas
leakage before every start-up.
Only operate the device when all safety devices are fully functional. If the safety devices are not fully functional, there is a risk of
- injury or death to the operator or a third party
- damage to the device and other material assets belonging to the operator
- inefficient operation of the device
Any safety devices that are not functioning properly must be repaired before
switching on the device.
Never bypass or disable safety devices.
Before switching on the device, ensure that no one is likely to be endangered.
Check the device at least once a week for obvious damage and proper functioning of safety devices.
Always fasten the shielding gas cylinder securely and remove it beforehand if
the device is to be transported by crane.
Only the manufacturer's original coolant is suitable for use with our devices
due to its properties (electrical conductibility, anti-freeze agent, material compatibility, flammability, etc.).
Only use suitable original coolant from the manufacturer.
Do not mix the manufacturer's original coolant with other coolants.
Only connect the manufacturer's system components to the cooling circuit.
The manufacturer accepts no liability for damage resulting from use of other
system components or a different coolant. In addition, all warranty claims will
be forfeited.
The coolant can ignite under certain conditions. Transport the coolant only in
its original, sealed containers and keep well away from any sources of ignition.
Used coolant must be disposed of properly in accordance with the relevant national and international regulations. The coolant safety data sheet may be obtained from your service centre or downloaded from the manufacturer's
website.
Check the coolant level before starting to weld, while the system is still cool.
Page 18
18
Commissioning,
maintenance and
repair
Safety inspection
Disposal
It is impossible to guarantee that bought-in parts are designed and manufactured to meet the demands made of them, or that they satisfy safety requirements.
- Use only original spare and wearing parts (also applies to standard parts).
- Do not carry out any modifications, alterations, etc. to the device without
the manufacturer's consent.
- Components that are not in perfect condition must be replaced immediately.
- When ordering, please give the exact designation and part number as
shown in the spare parts list, as well as the serial number of your device.
The housing screws provide the ground conductor connection for earthing the
housing parts.
Only use original housing screws in the correct number and tightened to the
specified torque.
The manufacturer recommends that a safety inspection of the device is performed at least once every 12 months.
The manufacturer recommends that the power source be calibrated during the
same 12-month period.
A safety inspection should be carried out by a qualified electrician
- after any changes are made
- after any additional parts are installed, or after any conversions
- after repair, care and maintenance has been carried out
- at least every twelve months.
For safety inspections, follow the appropriate national and international standards and directives.
Further details on safety inspection and calibration can be obtained from your
service centre. They will provide you on request with any documents you may
require.
Do not dispose of this device with normal domestic waste! To comply with the
European Directive on Waste Electrical and Electronic Equipment and its implementation as national law, electrical equipment that has reached the end of
its life must be collected separately and returned to an approved recycling facility. Any device that you no longer require must either be returned to your
dealer or given to one of the approved collection and recycling facilities in your
area. Ignoring this European Directive may have potentially adverse affects on
the environment and your health!
Page 19
19
EN
Safety symbols
Data protection
Copyright
Devices with the CE mark satisfy the essential requirements of the low-voltage
and electromagnetic compatibility directives (e.g. relevant product standards
of the EN 60 974 series).
Fronius International GmbH hereby declares that the device is compliant with
Directive 2014/53/EU. The full text on the EU Declaration of Conformity can
be found at the following address: http://www.fronius.com
Devices marked with the CSA test mark satisfy the requirements of the relevant standards for Canada and the USA.
The user is responsible for the safekeeping of any changes made to the factory settings. The manufacturer accepts no liability for any deleted personal
settings.
Copyright of these operating instructions remains with the manufacturer.
The text and illustrations are all technically correct at the time of printing. We
reserve the right to make changes. The contents of the operating instructions
shall not provide the basis for any claims whatsoever on the part of the purchaser. If you have any suggestions for improvement, or can point out any
mistakes that you have found in the instructions, we will be most grateful for
your comments.
Page 20
20
Page 21
General information
Page 22
Page 23
23
EN
General
Device concept
The TransSteel (TSt) 2500c, 2700c and
3500c power sources are completely digitised, microprocessor-controlled inverter power sources.
The modular design and potential for system add-ons ensure a high degree of flexibility. The devices are designed for the
welding of steel.
All devices are suitable for:
- MIG/MAG welding
- MMA welding
Functional principle
The central control and regulation unit of the power sources is coupled with a digital signal
processor. The central control and regulation unit and signal processor control the entire
welding process.
During the welding process, the actual data is measured continuously and the device responds immediately to any changes. Control algorithms ensure that the desired target
state is maintained.
The device has a "Power limitation" safety feature. This means that the power source can
be operated at the power limit without compromising process safety.
This results in:
- a precise welding process
- a high degree of reproducibility of all results
- excellent weld properties.
Application areas The devices are used in workshops and industry for manual applications with classical
steel and galvanised sheets.
The TSt 2500c and TSt 2700c power sources are primarily used in light-gauge steel sheet
(light steelwork) applications. Repair, maintenance, and assembly work in shipyards, automotive suppliers, workshops or the furniture construction industry are among the typical
application areas. The TSt 2500c et TSt 2700c power sources thus position themselves in
their power category between the trade/workshop sector and the industry sector.
The TSt 3500c power sources are designed for:
- Machine and equipment construction
- Steelwork
- Plant and container construction
- Metal and gantry construction
- Rail vehicle construction
Page 24
24
Warning notices
on the device
Warning notices and safety symbols are affixed to the power sources. These warning notices and safety symbols must not be removed or painted over. They warn against operating the device incorrectly, as this may result in serious injury and damage.
Safety symbols on the rating plate
Welding is dangerous. The following
basic requirements must be met:
- welders must be sufficiently qualified
- suitable protective equipment must
be used
- all persons not involved in the
welding process must be kept at a
safe distance
Do not use the functions described here
until you have thoroughly read and understood the following documents:
- these operating instructions
- all the operating instructions for the
system components, especially
the safety rules
40,0006,3035
inside
Page 25
25
EN
System components
General The power sources can be operated with various system components and options. This
makes it possible to optimise procedures and to simplify machine handling and operation,
as necessitated by the particular field of application in which the power source is to be
used.
Safety
Overview
TSt 2500c / TSt 2700c
No. Function
(1) Welding torch
(2) Gas cylinder holder stabiliser
(3) Power source
(4) Trolley and gas cylinder holder
(5) Grounding (earthing) cable and electrode cable
WARNING! Operating the equipment incorrectly can cause serious injury and
damage. Do not use the functions described until you have thoroughly read and
understood the following documents:
- these operating instructions
- all the operating instructions for the system components, especially the safety rules
(1)
(2)
(3)
(4)
(5)
Page 26
26
TSt 3500c
No. Function
(1) Welding torch
(2) Gas cylinder holder stabiliser
(3) Power source
(4) Cooling unit
TSt 3500c only
(5) Trolley and gas cylinder holder
(6) Grounding (earthing) cable and electrode cable
(1)
(2)
(3)
(4)
(5)
(6)
Page 27
27
EN
Options
VRD: safety function
A Voltage Reduction Device (VRD) is an optional safety device for reducing the voltage. It
is recommended for environments in which the risk of an electric shock or electrical accident is increased considerably during arc welding:
- Due to a low human body resistance of the welder
- If the welder is exposed to a clear risk of touching the workpiece or other parts of the
welding circuit
A low human body resistance is possible when there is:
- water in the area
- humidity
- heat, particularly ambient temperatures in excess of 32°C (89.6°F)
In wet, damp or hot locations, humidity or sweat can significantly reduce the skin resistance
and the insulation resistance of protective equipment and clothing.
Such environments can include:
- Temporary dams for draining certain areas of a site during construction work (cofferdams)
- Trenches
- Mines
- Rain
- Areas partly submerged by water
- Spraywater areas
The VRD option reduces the voltage between the electrode and the workpiece. In safe
conditions, the indicator for the currently selected welding process is permanently lit. A
safe condition is defined as follows:
- The output voltage in an open circuit is limited to 35 V.
For as long as the welding operation is active (welding circuit resistance < 200 Ohm), the
indicator of the currently selected welding process flashes and the output voltage may exceed 35 V.
VRD: safety principle
The welding circuit resistance is greater
than the minimum human body resistance
(greater than or equal to 200 Ohm):
- VRD is active
- Open circuit voltage is limited to 35 V
- Unintentional contact with the output
voltage does not put the welder at risk
The welding circuit resistance is less than
the minimum human body resistance (less
than 200 Ohm):
- VRD is inactive
- Output voltage not restricted in order to
ensure sufficient welding power
- Example: Welding starts
Page 28
28
In MMA welding mode:
Within 0.3 seconds of end of welding:
- VRD is active again
- The output voltage is limited to 35 V once more
Page 29
Control elements and connections
Page 30
Page 31
31
EN
Synergic Central control panel
General The functions on the control panel are all arranged in a logical way. The individual param-
eters required for welding can be
- selected easily using buttons
- altered using buttons or the adjusting dial
- displayed on the digital display during welding
The power source uses the Synergic control panel and certain general items of data such
as sheet thickness, filler metal, wire diameter and shielding gas to calculate the best welding parameters. As a result, stored knowledge is available at all times. All the parameters
can be adjusted manually. The Synergic control panel also allows parameters to be set
manually.
Safety
Synergic control
panel
NOTE! Due to software updates, you may find that your device has certain func-
tions that are not described in these operating instructions or vice versa. Individual illustrations may also differ slightly from the actual controls on your device, but
these controls function in exactly the same way.
WARNING! Operating the equipment incorrectly can cause serious injury and
damage. Do not use the functions described until you have thoroughly read and
understood the following documents:
- these operating instructions
- all the operating instructions for the system components, especially the safety rules
(1)
(2)
(3)
(4)
(5)
(6)(7)
(14)
(15)
(11)
(12)
(10) (8)(9)
(13)
Page 32
32
No. Function
(1) "Parameter selection" button (right)
for selecting the following welding parameters and for changing parameters in the
Setup menu
The relevant symbol lights up when a welding parameter is selected.
Arc length correction
for correcting the arc length
Welding voltage in V *)
Before the start of welding, the system automatically displays a standard value based on the programmed parameters. During welding, the actual value is
displayed.
Dynamic
for influencing the short-circuiting dynamic at the moment of droplet transfer
- ... harder, more stable arc
0 ... neutral arc
+ ... soft, low-spatter arc
Real Energy Input
for displaying the energy applied during the welding operation. **)
(2) "Parameter selection" button (left)
for selecting the following welding parameters and for changing parameters in the
Setup menu
The relevant symbol lights up when a welding parameter is selected.
Sheet thickness in mm or in.
If the welding current to be selected is not known it is sufficient to enter the
sheet thickness. The required welding current and any other parameters
marked with *) will then be adjusted automatically.
Welding current in A *)
Before the start of welding, the device automatically displays a standard value
based on the programmed parameters. During welding, the actual value is
displayed.
Wire feed speed in m/min or ipm
*)
(3) Adjusting dial (right)
for changing the arc length correction, welding voltage and arc-force dynamic parameters as well as changing parameters in the Setup menu
(4) Adjusting dial (left)
for changing the sheet thickness, welding current and wire feed speed parameters
as well as changing parameters in the Setup menu
(5) "Save" buttons (Easy Job)
for saving up to 5 operating points
Page 33
33
EN
(6) "Process" button
***)
for selecting the welding process
MANUAL - MIG/MAG standard manual welding
SYNERGIC - MIG/MAG standard synergic welding
STICK - manual metal arc welding
(7) "Mode" button
for selecting the operating mode
2 T - 2-step mode
4 T - 4-step mode
S 4 T - Special 4-step mode
(8) "Shielding gas" button
for selecting the shielding gas to be used. Parameter SP is reserved for additional
shielding gases.
The LED lights up next to the selected shielding gas.
(9) "Wire diameter" button
for selecting the wire diameter to be used. Parameter SP is reserved for additional
wire diameters.
The LED lights up next to the selected wire diameter.
(10) "Material" button
for selecting the filler metal to be used. Parameter SP is reserved for additional filler
metals.
The LED lights up next to the selected filler metal.
(11) '"Gas-test" button
to set the required gas flow rate at the pressure regulator.
Tap button once: shielding gas flows out
Tap button again: shielding gas flow stops
If the "Gas-test" button is not tapped again, the shielding gas flow will stop after 30
s.
(12) '"Wire threading" button
Press and hold the button:
Thread the wire into the torch hosepack with no accompanying flow of gas
While the button is being held down, the wire drive runs at feeder inching speed.
(13) Intermediate arc indicator
A spatter-prone "intermediate arc" occurs between the dip transfer arc and the
spray arc. To alert you to this critical area - and help you avoid it - the intermediate
arc indicator lights up.
(14) HOLD indicator
At the end of each welding operation, the actual values for welding current and
welding voltage are stored, and the HOLD indicator lights up.
(15) SF - spot / stitch welding indicator
lights up if a value has been entered for the spot / stitch welding time Setup parameter (SPt) (spot or stitch welding operating mode is enabled)
Page 34
34
Service parameters
Various service parameters can be retrieved by pressing the "Parameter selection" buttons
at the same time.
Opening the display
The first parameter ("Firmware version") is displayed, e.g. "1.00 | 4.21"
Selecting parameters
Available parameters
*) If one of these parameters is selected in the MIG/MAG standard synergic welding
process, then the synergic function ensures that all other parameters, including the
welding voltage parameter, are adjusted automatically.
**) The Real Energy Input display must be activated in level 2 of the Setup menu –
EnE parameter. The value continuously rises during welding in line with the permanently increasing energy yield. The final value at the end of welding remains stored
until welding starts again or the power source is switched back on - the HOLD indicator lights up.
***) In conjunction with the VRD option, the currently selected welding process indica-
tor is simultaneously an additional indicator:
- The indicator is permanently lit: The Voltage Reduction Device (VRD) is active
and is limiting the output voltage to less than 35 V.
- The indicator starts to flash as soon as a welding action starts in which the output voltage can exceed 35 V.
Press and hold the "Parameter selection" button (left)
Press the "Parameter selection" button (right)
Release the "Parameter selection" buttons
Select the required setup parameter using the "Mode" and "Process" buttons or the left-hand adjusting dial
1
2
3
1
Example:
1.00 | 4.21
Firmware version
Example:
2 | 491
Welding program configuration
Example:
r 2 | 290
Number of the currently selected welding program
Example:
iFd | 0.0
Motor current for wire drive in A
The value changes as soon as the motor is running.
654 | 32.1
= 65,432.1 hours
= 65,432 hours 6 mins
Indicates the actual arc time since using for the first time
Note: The arc time indicator is not suitable as a basis for calculating hiring fees, for warranty purposes, etc.
2nd 2nd menu level for service engineers
Page 35
35
EN
Keylock A keylock can be selected to prevent the settings from being inadvertently changed on the
control panel. As long as the keylock is active
- no settings can be made on the control panel
- only parameter settings can be retrieved
- any assigned "Save" button can be retrieved provided that an assigned "Save" button
was selected when the keylock was enabled
Activate/deactivate the keylock as follows:
Keylock activated:
The message "CLO | SEd" appears on the displays.
Keylock deactivated:
The message "OP | En" appears on the displays.
Press and hold the "Mode" button
Press the "Parameter selection" button (right)
Release the "Mode" and "Parameter Selection" buttons
1
2
3
Page 36
36
Connections, switches and mechanical components
Front and rear
sides, TSt 2500c /
TSt 2700c
TSt 2500c / TSt 2700c
No. Function
(1) Welding torch connection
for connecting the welding torch
(2) (-) - Current socket with bayonet latch
used for
- connecting the grounding (earthing) cable during MIG/MAG welding
- connecting the electrode cable or grounding (earthing) cable during MMA welding
(depending on the type of electrode used)
(3) LocalNet connection
Standardised connection for remote control
(4) (+) - Current socket with bayonet latch
used for
- connecting the electrode cable or grounding (earthing) cable during MMA welding
(depending on the type of electrode used)
(5) Shielding gas connection
(6) Mains switch
for switching the power source on and off
(7) Mains cable with strain relief device
(8) Air filter
(1) (7)(8)
(2) (3) (4) (5) (6)
Page 37
37
EN
Front and rear
sides, TSt 3500c
TSt 3500c
No. Function
(1) Welding torch connection
for connecting the welding torch
(2) (-) - Current socket with bayonet latch
used for
- connecting the grounding (earthing) cable during MIG/MAG welding
- connecting the electrode cable or grounding (earthing) cable during MMA welding
(depending on the type of electrode used)
(3) (+) - Current socket with bayonet latch
used for
- connecting the electrode cable or grounding (earthing) cable during MMA welding
(depending on the type of electrode used)
(4) LocalNet connection
Standardised connection for remote control
(5) Mains switch
for switching the power source on and off
(6) Mains cable with strain relief device
(7) Air filter
(8) Shielding gas connection
(1) (8) (7)
(2) (3) (4) (5) (6)
Page 38
38
Side view
No. Function
(1) Wirespool holder with brake
for holding standard wirespools
with a max. diameter of 300 mm
(11.81 in.) and a max. weight of up
to 19 kg (41.89 lbs.)
(2) 4-roller drive
(3) LED wirespool interior lighting
(TSt 2500c, TSt 2700c only)
with the setup parameter LED the
turn-off time is adjustable
(1) (2)
(3)
Page 39
Installation and commissioning
Page 40
Page 41
41
EN
Minimum equipment needed for welding task
General Depending on which welding process you intend to use, a certain minimum equipment lev-
el will be needed in order to work with the power source.
The welding processes and the minimum equipment levels required for the welding task
are then described.
MIG/MAG welding, gas-cooled
- Power source
- Grounding (earthing) cable
- MIG/MAG welding torch, gas-cooled
- Gas connection (shielding gas supply)
- Wire electrode
MIG/MAG welding, water-cooled
- Power source
- Cooling unit including coolant
- Grounding (earthing) cable
- MIG/MAG welding torch, water-cooled
- Gas connection (shielding gas supply)
- Wire electrode
Manual metal arc
welding
- Power source
- Grounding (earthing) cable
- Electrode holder
- Rod electrode
Page 42
42
Before installation and commissioning
Safety
Utilisation for intended purpose
only
The power source may only be used for MIG/MAG and MMA welding.
Any other form of usage is deemed "not in accordance with the intended purpose".
The manufacturer shall not be held liable for any damages arising from such usage.
Utilisation in accordance with the "intended purpose" also comprises
- following all the information in the operating instructions
- carrying out all the specified inspection and servicing work
Setup regulations The device is tested to IP 23, meaning:
- protection against penetration by solid foreign bodies with diameters > 12 mm (0.49
in.)
- protection against water sprayed directly at any angle up to 60° from the vertical
The device can be set up and operated outdoors in accordance with degree of protection
IP 23.
Avoid direct wetting (e.g. from rain).
The venting duct is a very important safety feature. When choosing the installation location,
ensure that the cooling air can enter and exit unhindered through the air ducts on the front
and back of the device. Electroconductive metallic dust (e.g. from grinding work) must not
be allowed to get sucked into the device.
Mains connection The devices are designed to run on the mains voltage shown on the respective rating
plates. If your version of the device does not come with mains cables and plugs ready-fitted, these must be fitted in accordance with national regulations and standards. For details
of fuse protection of the mains lead, please see the Technical Data.
WARNING! Operating the equipment incorrectly can cause serious injury and
damage. Do not use the functions described until you have thoroughly read and
understood the following documents:
- these operating instructions
- all the operating instructions for the system components, especially the safety rules
WARNING! An electric shock can be fatal. If the power source is connected to the
mains electricity supply during installation, there is a high risk of very serious injury and damage. Before carrying out any work on the device make sure that:
- the power source mains switch is in the "O" position
- the power source is unplugged from the mains
WARNING! If one of these machines topples over or falls it could cause serious
or even fatal injury. Place device on a solid, level surface in such a way that it remains stable.
CAUTION! Electroconductive metallic dust may damage the device. The air filter
is a very important safety feature for achieving IP 23. Always fit the air filter when
operating the device.
Page 43
43
EN
NOTE! Inadequately dimensioned electrical installations can cause serious dam-
age. The incoming mains lead and its fuse must be dimensioned to suit the local
power supply. The technical data shown on the rating plate applies.
Page 44
44
Connecting the mains cable
General A strain-relief device for the following cable cross-sections is fitted to the power source:
*) Canada / US cable type: Extra-hard usage
Strain-relief devices for other cable cross-sections must be designed accordingly.
Stipulated mains
cables and strainrelief devices
*) Canada / US cable type: Extra-hard usage
The item numbers of the different cables can be found in the spare parts list.
American Wire Gauge
Connecting the
mains cable
If no mains cable is connected, a mains cable that is suitable for the connection voltage
must be fitted before commissioning.
The ground conductor should be approx. 10 - 15 mm (0.4 - 0.6 in.) longer than the phase
conductors.
An illustration of the mains cable connection can be found in the following sections for fitting the strain-relief device. To connect the mains cable, proceed as follows:
Remove the side panel from the device
Push the mains cable in far enough to make it possible to connect the ground conductor and the phase conductors to the block terminal properly.
Fit ferrules to the ground conductor and phase conductors
Power source Cable cross-section
Canada / US Europe
TSt 2500c / TSt 2700c AWG 14 to AWG 6 *) 4G2.5
TSt 3500c AWG 12 *) 4G2.5
Power source Mains voltage Cable cross-sec-
tion
Canada / US
Europe
TSt 2500c / TSt 2700c 1 x 230 / 240 V AWG 14 (15 A) *) 3G2.5 (16 A)
TSt 2500c / TSt 2700c 1 x 240 V AWG 12 (20 A) *) -
TSt 2500c / TSt 2700c 1 x 240 V AWG 12 (30 A) *) -
TSt 2500c / TSt 2700c 3 x 200 V AWG 12 4G2.5
TSt 2500c / TSt 2700c 3 x 230 / 240 V AWG 14 4G2.5
TSt 2500c / TSt 2700c 3 x 380 / 400 V AWG 14 *) 4G2.5
3 x 460 V AWG 14 *) 4G2.5
TSt 3500c 3 x 380 / 400 V AWG 12 *) 4G2.5
3 x 460 V AWG 12 *) 4G2.5
CAUTION! If no ferrules are used, there is a risk of injury and damage from short
circuits between the phase conductors or between the phase conductors and the
PE conductor. Fit ferrules to all phase conductors and the PE conductor of the
stripped mains cable.
1
2
3
Page 45
45
EN
Connect the ground conductor and phase conductors to the block terminal
Use the strain-relief device to secure the mains cable
Fit the side panel of the device
Fitting the strainrelief device, TSt
2500c MV / TSt
2700c, singlephase operation
1 2
3 4
5
4
5
6
1
3,5 Nm
2
3
2
NL2
L1
4
5
IMPORTANT! Tie the phase conductors near the strain-relief device using cable ties.
Page 46
46
Fitting the strainrelief device, TSt
2500c / TSt 2700c
1 2
3 4
5
1
1,2 Nm
2
3 4
5
IMPORTANT! Tie the phase conductors near the strain-relief device using cable ties.
Page 47
47
EN
Fitting the strainrelief device, TSt
2500c MV / TSt
2700c MV
1 2
3 4
5
1
3,5 Nm
2
3 4
5
IMPORTANT! Tie the phase conductors near the strain-relief device using cable ties.
Page 48
48
Fitting the strainrelief device, TSt
3500c
1 2
3 4
Fitting the Canada / U S strain-relief device, TSt
3500c
1 2
1
2
1,2 Nm
3 4
IMPORTANT! Tie the phase conductors near the luster terminal using cable ties.
1
2
Page 49
49
EN
3 4
3 4
IMPORTANT! Tie the phase conductors near the luster terminal using cable ties.
Page 50
50
Generator-powered operation
Generator-powered operation
The power source is generator-compatible.
The maximum apparent power S
1max
of the power source must be known in order to select
the correct generator output.
The maximum apparent power S
1max
of the power source is calculated as follows:
The generator apparent power S
GEN
needed is calculated using the following rule of
thumb:
A smaller generator may be used when not welding at full power.
IMPORTANT! The generator apparent power S
GEN
must always be higher than the maxi-
mum apparent power S
1max
of the power source.
When using single-phase devices with a 3-phase generator, note that the specified generator apparent power is often only available as a whole across all three phases of the generator. If necessary, obtain further information on the single-phase power of the generator
from the generator manufacturer.
3-phase devices:
S
1max
= I
1max
x U1 x √3
Single-phase devices:
S
1max
= I
1max
x U
1
See device rating plate or technical data for I
1max
and U1 values
S
GEN
= S
1max
x 1.35
NOTE! The voltage delivered by the generator must never exceed the upper or
lower limits of the mains voltage tolerance range. Details of the mains voltage tolerance can be found in the "Technical data" section.
Page 51
51
EN
Single-phase operation
Single-phase operation
As an alternative to three-phase operation, the multivoltage variant (MV) of the power
source enables a welding operation with limited power or duration from just a single-phase
supply. The maximum possible welding power is limited due to the dimensioning of the
mains fuse protection, upon which the safety cut-out of the power source is dependant.
If the mains cable has a 20 A or 30 A fuse, the FUS parameter may be changed to 20 A or
30 A. Welding with a higher maximum power or for longer periods is therefore possible.
The FUS parameter is in the level 2 Setup menu and can be set for a single-phase supply
as well as to a US setting (SEt parameter to US).
In order to use the power source in single-phase operation, the following prerequisites
must be fulfilled:
- Correct single-phase power source supply in accordance with the chapter "Installation
and commissioning," section "Connecting the mains cable" - "Fitting the strain-relief
device, single-phase operation."
The following table shows which mains voltages and fuse values limit the welding current
in single-phase operation:
The welding current data applies at an ambient temperature of 40°C (104°F).
At a mains voltage of 240 V and a fuse value of 30 A the maximum value of 220 A for the
MIG/MAG welding for instance is possible at a duty cycle of 40 %.
Mains voltage Fuse value Welding current limitation
230 V 10 A MIG/MAG welding:
max. 170 A; 100 A at 100%*
MMA welding:
max. 140 A; 100 A at 100%*
230 V 13 A MIG/MAG welding:
max. 160 A; 150 A at 100%*
MMA welding:
max. 140 A; 120 A at 100%*
230 V 16 A MIG/MAG welding:
max. 180 A; 145 A at 100%*
MMA welding:
max. 150 A; 130 A at 100%*
240 V 15 A MIG/MAG welding:
max. 180 A; 145 A at 100%*
MMA welding:
max. 150 A; 125 A at 100%*
240 V 20 A MIG/MAG welding:
max. 200 A; 160 A at 100%*
MMA welding:
max. 180 A; 140 A at 100%*
240 V 30 A MIG/MAG welding:
max. 220 A; 175 A at 100%*
MMA welding:
max. 180 A; 140 A at 100%*
* The 100% values relate to welding with no time limits and without cooling breaks
Page 52
52
In single-phase operation a safety cut-out function prevents a triggering of the fuse at higher welding power values. The safety cut-out function is active at fuse values of 15 A, 16 A
and 20 A and determines the possible welding time, without triggering of the fuse. If a cutout of the welding current results due to exceeding the pre-calculated welding time, the service code „toF“ is displayed. In addition to the readout „toF“ from now on a countdown runs
for displaying the remaining waiting time, until the welding readiness is restored. Then the
message disappears an the power source is operational again.
At a fuse value of 30 A the temperature monitoring of the power source ensures the timely
shutdown of the welding current, yet before the fuse triggers. This results in the display of
the service codes „to1“ to „to7“. Detailed information concerning the servicecodes „to1“ to
„to7“ is located in chapter „Troubleshooting and maintenance, section „Displayed service
codes“. If there is no defect or soiling of the cooling components, here the power source is
also ready for welding again after an adequate welding break.
Explanation of
the term „duty cycle“ in singlephase operation
For single-phase operation duty cycle values are given in the chapter „Technical data“, depending on the existing fuse value and the welding current. The percentage rates of this
duty cycle values indeed relate as well to the 10-minute cycle, as explained in chapter
„Technical data“ for the general duty cycle, however the cooling phase of the fuse is rated
at only approximately 60 s. Thereafter, the power source is already operational again.
For reasons of technical standards the duty cycle in single-phase operation is only given
for the time until the cut-out within the first welding cycle takes place. If the reference to the
10 minute cycle would also persist with regard to the cooling phase, which is usually valid
for specifying the duty cycle, in practice longer welding phases than specified would be
possible. You see that the specification relates to cooling phases of only approximately 60
s, after which the power source is already operational again.
The example given in the following shows the standard compliant welding and break cycles, at a welding current of 180 A and a duty cycle of 15 %.
Welding time in
single-phase operation
The following diagram shows the welding time, which is possible according to the technical
standards, depending on the given fuse value and the welding current.
t (min:s)1:30 2:30 6:30 7:30 9 1045
I (A)
180 A
Page 53
53
EN
Legend
Mains fuse protection 10 A
Mains fuse protection 13 A
Mains fuse protection 15 A
Mains fuse protection 16 A
Mains fuse protection 20 A
t (min)
130120 140 150 160 170 180 190 200
I2 (A)
1
2
3
4
5
6
7
8
9
10
11
Page 54
54
Fitting/connecting the system components
Information on
system components
The steps and activities described below include references to various system components, such as
- Trolley
- Cooling units (TSt 3500c only)
- Welding torches, etc.
For more detailed information about installing and connecting the system components,
please refer to the appropriate operating instructions.
Mounting on the
trolley
The following diagram shows an overview of how the individual system components are
put together.
For detailed information about the individual steps, please refer to the corresponding operating instructions for the system components.
TSt 2500c / TSt 2700c TSt 3500c
Connecting the
gas cylinder
WARNING! Work that is carried out incorrectly can cause serious injury and dam-
age. The following activities must only be carried out by trained and qualified personnel. All instructions in the section headed "Safety rules" must be observed.
WARNING! If gas cylinders topple over, there is a risk of very serious injury and
damage. When using gas cylinders
- place them on a solid, level surface in such a way that they remain stable
- secure the gas cylinders to prevent them from falling over
- fit the optional wirefeeder holder
Follow the gas cylinder manufacturer's safety rules.
Page 55
55
EN
TSt 2500c / TSt 2700c TSt 3500c
Secure the gas cylinder with a belt
Briefly open the gas cylinder valve to remove any dust or dirt
Check the seal on the pressure regulator
Connecting a
MIG/MAG welding
torch
1
NOTE! US devices (TSt 3500c only) are supplied with an adapter for the gas
hose:
- Seal male thread spacers on the gas solenoid valve using suitable means before screwing on the adapter.
- Test the adapter to ensure that it is gas-tight.
1
2
3
NOTE! When connecting the welding torch, check that
- all connections are connected properly
- all cables, leads and hosepacks are undamaged and correctly insulated.
1
Page 56
56
Establishing a
ground (earth)
connection
1
Inserting/replacing feed rollers
In order to achieve optimum wire electrode feed, the feed rollers must be suitable for the
diameter and alloy of the wire being welded.
An overview of the available feed rollers can be found in the spare parts lists.
1 2
3 4
1
CAUTION! Risk of injury if the feed roller holders fly upwards. When unlocking
the lever, keep fingers away from the area to the left and right of the lever.
2
1
4
4
5
6
3
1
6
3
31
2
4
5
7
2
3
8
6
7
9
3
1
2
2
5
4
4
3
4
5
5
6
1
2
3
4
Page 57
57
EN
Inserting the wirespool/basket-type
spool
1
CAUTION! Risk of injury from springiness of spooled wire electrode. When inserting the wirespool / basket-type spool, hold the end of the wire electrode firmly to
avoid injuries caused by the wire electrode springing back.
CAUTION! Risk of injury from falling wirespool/basket-type spool. Make sure that
the wirespool or basket-type spool with basket-type spool adapter is fitted securely to the wirespool holder.
CAUTION! Risk of injury and material damage if the wirespool/basket-type spool
topples over because the locking ring has been placed the wrong way round. Always place the locking ring as shown in the diagram on the left.
1
NOTE! When working with basket-type spools, only use the basket-type spool
adapter included in the scope of supply.
Page 58
58
1 2
Feeding in the
wire electrode
1 2
IMPORTANT! To facilitate wire threading, the following sequences are possible when the
"Wire threading" button is pressed and held down.
1
2
CAUTION! Risk of injury from springiness of spooled wire electrode. When inserting the wire electrode into the 4-roller drive, hold the end of the wire electrode
firmly to avoid injuries caused by the wire springing back.
CAUTION! Risk of damage to the welding torch from sharp end of wire electrode.
Deburr the end of the wire electrode well before feeding in.
1
2
CAUTION! Risk of injury from wire electrode emerging at speed. When pressing
the "Wire threading" button or the torch trigger, keep the welding torch away from
your face and body, and wear suitable protective goggles.
Page 59
59
EN
If you release the "Wire threading" button and press it again before one second has
elapsed, the sequence starts again from the beginning. This makes it possible to continuously position the wire at a low wire feed speed of 1 m/min or 39.37 ipm where necessary.
If there is no "Wire threading" / "Gas-test" button, the torch trigger can be used in the usual way. Before using the torch trigger for wire threading, proceed as follows:
Press the "Mode" button to select 2-step mode
Set the "Ito" parameter to "Off" in the Setup menu
IMPORTANT! If the torch trigger is pressed instead of the "Wire threading"/"Gas-test"
button, the welding wire runs at the feeder creep speed (depending on the welding program) for the first 3 seconds. After these 3 seconds, wirefeeding is briefly interrupted.
The welding system detects that the welding process should not start, but that the wire is
to be fed in. At the same time, the gas solenoid valve closes, and the welding voltage on
the wire electrode is switched off.
If the torch trigger is kept pressed, wire feeding restarts immediately without shielding gas
and welding voltage, and the process continues as described above.
- Hold the button for up to one second
... the wire feed speed stays at 1 m/
min or 39.37 ipm for the first second.
- Hold the button for up to 2.5 seconds
... after one second, the wire feed
speed increases over the next 1.5
seconds.
- Hold the button for more than 2.5
seconds ... after 2.5 seconds, the
wire is fed at a constant rate equal to
the wire feed speed set for the Fdi
welding parameter.
CAUTION! Risk of injury and damage from electric shock and from the wire electrode emerging from the torch. When pressing the torch trigger
- keep the welding torch away from your face and body
- wear suitable protective goggles
- do not point the welding torch at people
- make sure that the wire electrode does not touch any conductive or earthed
parts (e.g. Housing etc.)
Fdi
1
23
4
5
2,5
1
t (s)
(m/min, ipm)
1
2
Page 60
60
1 2
Setting the contact pressure
Adjusting the
brake
1 2
2
4
5
3
1
3 4
NOTE! Set the contact pressure in such a way that the wire electrode is not deformed but nevertheless ensures proper wirefeed.
1
Standard values U-grooved rollers
Steel 4 - 5
CrNi 4 - 5
Tubular cored electrodes
2 -3
NOTE! After releasing the torch trigger the wirespool must stop unreeling. If it
continues unreeling, readjust the brake.
4
STOP
6
7
1
2
3
5
3
5
1
2
1
2
Page 61
61
EN
3
Design of the
brake
4
6
OK
STOP
3
5
3
WARNING! Fitting the equipment
incorrectly can cause serious injury and damage.
- Do not dismantle the brake.
- Maintenance and servicing of
brakes is to be carried out by
trained, qualified personnel
only.
The brake is only available as a
complete unit.
This illustration is for information
purposes only.
Page 62
62
Start-up
General
The device is started up by pressing the torch trigger (for manual applications).
Prerequisites The following conditions must be satisfied before the device is started:
- Welding torch connected
- Feed rollers inserted
- Wirespool or basket-type spool with adapter inserted
- Wire electrode fed in
- Brake adjusted
- Feed roller contact pressure set
- All covers closed, all side panels in place, all protection devices intact and in their
proper place
- Where applicable, water connections connected
Commissioning Before proceeding further as described in the "Welding mode" section, the following activ-
ities are required for the "MIG/MAG standard synergic welding" and "MIG/MAG standard
manual welding" processes:
Plug in the mains plug
Turn the mains switch to position "I"
WARNING! Operating the equipment incorrectly can cause serious injury and
damage. Do not use the functions described until you have thoroughly read and
understood the following documents:
- these operating instructions
- all the operating instructions for the system components, especially the safety rules
1
2
Page 63
Welding
Page 64
Page 65
65
EN
Power limitation
Safety function "Power limitation" is a safety function for MIG/MAG welding. This means that the power
source can be operated at the power limit whilst maintaining process safety.
Wire feed speed is a determining parameter for welding power. If it is too high, the arc gets
smaller and smaller and may be extinguished. In order to prevent this, the welding power
is lowered.
For the selected "MIG/MAG standard synergic welding" process, the symbol for the
"Wire feed speed" parameter flashes as soon as the safety function trips. The flashing continues until the next welding start-up, or until the next parameter change.
If the "Wire feed speed" parameter is selected, the reduced value for wire feed
speed is displayed.
Page 66
66
MIG/MAG modes
General
For details of the meaning, settings, setting range and units of the available welding parameters (e.g. gas pre-flow time), please refer to the "Set-up parameters" section.
Symbols and
their explanations
WARNING! Operating the equipment incorrectly can cause serious injury and
damage. Do not use the functions described until you have thoroughly read and
understood the following documents:
- these operating instructions
- all the operating instructions for the system components, especially the safety rules
Press the torch trigger Hold the torch trigger Release the torch trigger
GPr
Gas pre-flow time
I-S
Starting current
can be increased or decreased depending on the application
SL
Slope: the starting current is continuously lowered as far as the welding current and the
welding current as far as the final current
I
Welding-current phase: uniform thermal input into the base material, whose temperature
is raised by the advancing heat
I-E
Final current
for filling the end-crater.
GPo
Gas post-flow time
SPt
Spot welding time / stitch welding time
SPb
Stitch pause time
Page 67
67
EN
2-step mode "2-step mode" is suitable for
- Tacking work
- Short weld seams
4-step mode
"4-step mode" is suitable for longer weld
seams.
Special 4-step
mode
Special 4-step mode allows the starting and
final current to be configured in addition to
the advantages of 4-step mode.
Spot welding
The "Spot welding" mode is suitable for
welded joints on overlapped sheets.
I
GPr
GPo
t
I
+
I
GPr
GPo
t
I
+
+
+ +
I
GPr
I-S I-E
SL SL
GPo
t
I
I
GPr
GPo
SPt
t
I
+
Page 68
68
2-step stitch
welding
The "2-step stitch welding" mode is suitable
for welding short weld seams on thin
sheets, to prevent the weld seams from
dropping through the base material.
4-step stitch
welding
The "4-step stitch welding" mode is suitable
for welding longer weld seams on thin
sheets, to prevent the weld seams from
dropping through the base material.
I
GPr SPt SPtSPb
GPo
t
I
+
+ +
I
GPr SPt SPtSPb
GPo
t
I
Page 69
69
EN
MIG/MAG welding
Safety
Overview MIG/MAG welding is composed of the following sections:
- MIG/MAG standard synergic welding
- MIG/MAG standard manual welding
WARNING! Operating the equipment incorrectly can cause serious injury and
damage. Do not use the functions described until you have thoroughly read and
understood the following documents:
- these operating instructions
- all the operating instructions for the system components, especially the safety rules
WARNING! An electric shock can be fatal. If the power source is connected to the
mains electricity supply during installation, there is a high risk of very serious injury and damage. Before carrying out any work on the device make sure that:
- the power source mains switch is in the "O" position
- the power source is unplugged from the mains
Page 70
70
MIG/MAG standard synergic welding
MIG/MAG standard synergic
welding
Press the "Material" button to select the filler metal to be used.
Press the "Wire diameter" button to select the diameter of the wire electrode used.
Press the "Shielding gas" button to select the shielding gas to be used.
The assignment of the SP position is in the welding program tables in the appendix.
Press the "Process" button to select the desired welding process:
MIG/MAG standard synergic welding
Press the "Mode" button to select the desired MIG/MAG mode:
2-step mode
4-step mode
Special 4-step mode
Use the "Parameter selection" buttons to select the welding parameters to be used to
specify the welding power:
Sheet thickness
Welding current
Wire speed
Welding voltage
Use the appropriate adjusting dial to set the relevant welding parameters.
The welding parameter values are shown in the digital display located above them.
All welding parameter set values remain stored until the next time they are changed. This
applies even if the power source is switched off and on again. To display the actual welding
current during welding, select the welding current parameter.
Open the gas cylinder valve
Setting the shielding gas flow rate:
- Tap the "Gas-test" button
- Turn the adjusting screw on the underside of the pressure regulator until the pres-
sure gauge shows the required gas flow rate
- Tap the "Gas-test" button again
Press the torch trigger and start welding
Corrections during welding
To obtain the best possible welding results, the arc length correction and dynamic welding
parameters will sometimes need to be corrected.
IMPORTANT! Under certain circumstances, it may not be possible to change welding
parameters that have been set on the control panel of a system component (TR 2000
or TR 3000 remote control) on the control panel of the power source.
CAUTION! Risk of injury and damage from electric shock and from the wire electrode emerging from the torch. When pressing the torch trigger
- keep the welding torch away from your face and body
- wear suitable protective goggles
- do not point the welding torch at people
- make sure that the wire electrode does not touch any conductive or earthed
parts (e.g. housing)
1
2
3
4
5
6
7
8
9
10
Page 71
71
EN
Press the "Parameter selection" buttons to select the parameters you wish to correct.
Use the adjusting dials to set the selected welding parameters to the required values.
Welding parameter values are shown in the indicators located above them.
1
2
Page 72
72
MIG/MAG standard manual welding
General The MIG/MAG standard manual welding process is a MIG/MAG welding process with no
synergic function.
Changing one parameter does not result in any automatic adjustments to the other parameters. All of the variable parameters must therefore be adjusted individually, as dictated by
the welding process in question.
Available parameters
The following parameters are available in MIG/MAG manual welding:
Wire feed speed
1 m/min (39.37 ipm.) - maximum wire feed speed, e.g. 25 m/min (984.25 ipm.)
Welding voltage
TSt 2500c: 14.4 - 34.5 V
TSt 2700c: 14.4 - 34.9 V
TSt 3500c: 14.5 - 38.5 V
Dynamic
... for influencing the short-circuiting dynamic at the moment of droplet transfer
Welding current
only for displaying the actual value
MIG/MAG standard manual welding
Press the "Process" button to select the desired welding process:
MIG/MAG standard manual welding
Press the "Mode" button to select the desired MIG/MAG mode:
2-step mode
4-step mode
In MIG/MAG standard manual welding, special 4-step mode corresponds to conventional
4-step mode.
IMPORTANT! Under certain circumstances, it may not be possible to change welding parameters that have been set on the control panel of a system component (TR 2000 or TR
3000 remote control) on the control panel of the wirefeeder.
Press the "Parameter selection" button to select the wire speed parameter
Use the adjusting dial to set the desired value for the wire speed
Press the "Parameter selection" button to select the welding voltage parameter
Use the adjusting dial to set the desired value for the welding voltage
The welding parameter values are shown in the digital display located above them.
All welding parameter set values remain stored until the next time they are changed. This
applies even if the power source is switched off and on again. To display the actual welding
current during welding, select the welding current parameter.
1
2
3
4
5
6
Page 73
73
EN
To display the actual welding current during welding:
- Press the "Parameter selection" button to select the welding current parameter
- The actual welding current is shown on the digital display during welding.
Open the gas cylinder valve
Setting the shielding gas flow rate:
- Tap the "Gas-test" button
- Turn the adjusting screw on the underside of the pressure regulator until the pres-
sure gauge shows the required gas flow rate
- Tap the "Gas-test" button again
Press the torch trigger and start welding
Corrections during welding
To obtain the best possible welding results, the arc-force dynamic parameter will sometimes need to be adjusted.
Press the "Parameter selection" button to select the arc-force dynamic parameter
Use the adjusting dial to set the desired arc-force dynamic value
The welding parameter value is shown in the digital display located above it.
CAUTION! Risk of injury and damage from electric shock and from the wire electrode emerging from the torch. When pressing the torch trigger
- keep the welding torch away from your face and body
- wear suitable protective goggles
- do not point the welding torch at people
- make sure that the wire electrode does not touch any conductive or earthed
parts (e.g. housing)
7
8
9
1
2
Page 74
74
MMA welding
Safety
Preparation Move the mains switch to the "O" position
Disconnect the mains plug
Plug the grounding (earthing) cable into the (-) or (+) current socket (depending upon
which type of electrode is to be used) and latch it by turning it clockwise
Use the other end of the grounding (earthing) cable to establish a connection to the
workpiece
Plug the electrode holder cable bayonet plug into the free current socket with the opposite polarity, according to the type of electrode, and turn it clockwise to latch it in
place
Plug in the mains plug
MMA welding
Move the mains switch to the "I" position: all the indicators on the control panel will
briefly light up
Press the "Process" button to select the MMA welding process:
The welding voltage is connected to the welding socket with a 3-second time lag.
Press the "Parameter selection" button to select the amperage parameter.
Use the adjusting dial to set the desired amperage.
The amperage value is displayed in the left-hand digital display.
All welding parameter set values remain stored until the next time they are changed.
This applies even if the power source is switched off and on again in the meantime.
WARNING! Operating the equipment incorrectly can cause serious injury and
damage. Do not use the functions described until you have thoroughly read and
understood the following documents:
- these operating instructions
- all the operating instructions for the system components, especially the safety rules
WARNING! An electric shock can be fatal. If the machine is plugged into the
mains electricity supply during installation, there is a high risk of very serious injury and damage. Do not carry out any work on the device unless
- the mains switch is in the "O" position,
- the device is unplugged from the mains.
IMPORTANT! Check the rod electrode packaging to determine whether the rod electrodes
are for (+) or (-) welding.
1
2
3
4
5
6
CAUTION! Risk of injury and damage from electric shock. As soon as the mains
switch is in the "I" position, the rod electrode in the electrode holder is live. Make
sure that the rod electrode does not touch any persons or electrically conducting
or earthed parts (e.g. the housing, etc.).
IMPORTANT! Under certain circumstances, welding parameters that have been set
on a system component control panel (TR 2000 and TR 3000) may not be changed
on the control panel of the power source.
1
2
3
4
Page 75
75
EN
Start welding
To display the actual welding current during welding:
- Press the "Parameter selection" button to select the welding current parameter
- The actual welding current is shown on the digital display during welding.
Corrections during welding
To obtain the best possible welding results, the arc-force dynamic parameter will sometimes need to be adjusted.
Press the "Parameter selection" button to select the arc-force dynamic parameter
Use the adjusting dial to set the desired arc-force dynamic value
The welding parameter value is shown in the digital display located above it.
HotStart function To obtain optimum welding results, it will sometimes be necessary to adjust the HotStart
function.
Advantages
- Improved ignition, even when using electrodes with poor ignition properties
- Better fusion of the base material during the start-up phase, meaning fewer cold-shut
defects
- Largely prevents slag inclusions
For details on setting the available welding parameters, please refer to "Setup parameters", "Setup menu - level 2".
Legend
Hti: Hot-current time,
0 - 2 s, factory setting: 0.5 s
HCU: HotStart-current,
100 - 200 %, factory setting 150 %
I
H
: Main current = set welding current
Function
During the specified hot-current time (Hti),
the welding current is increased to a certain
value. This value (HCU) is higher than the
selected welding current (IH).
Anti-stick function
As the arc becomes shorter, the welding voltage may drop so far that the rod electrode will
tend to "stick". This may also cause "burn-out" of the rod electrode.
Electrode burn-out is prevented by activating the anti-stick function. If the rod electrode begins to stick, the power source immediately switches the welding current off. After the rod
electrode has been detached from the workpiece, the welding operation can be continued
without difficulty.
The anti-stick (Ast) function can be activated and deactivated in the Setup parameters in
"Setup menu: level 2".
5
1
2
200
300
I (A)
Hti
HCU > I
H
t (s)
I
H
HCU
0,5 1 1,5
Page 76
76
Saving and retrieving operating points
General The "Save" buttons allow up to 5 operating points to be saved. Every operating point
matches the settings on the control panel.
IMPORTANT! Setup parameters are not saved at this time.
Saving operating
points
Press and hold one of the "Save" buttons to save the current settings on the control
panel, e.g.:
- The left indicator displays "Pro"
- After a short time, the left indicator switches to the original value
Release the "Save" button
Retrieving operating points
To retrieve saved settings, press the corresponding "Save" button briefly, e.g.:
- The control panel will show the saved settings
Deleting operating points
Press and hold the relevant "Save" button to delete the memory content of that "Save"
button, e.g.:
- The left indicator displays "Pro"
- After a short time, the left indicator switches to the original value
Keep the "Save" button held down
- The left display shows "CLr".
- After a while, both displays show "---"
Release the "Save" button
Retrieving operating points on the
Up/Down welding
torch
One of the "Save" buttons on the control panel must be pressed to retrieve the saved settings using the Up/Down welding torch.
Press one of the "Save" buttons on the control panel, e.g.:
- The control panel will show the saved settings
The "Save" buttons can now be selected using the buttons on the Up/Down welding torch.
Vacant "Save" buttons are skipped.
In addition to the "Save" button number lighting up, a number is displayed directly on the
Up/Down welding torch:
1
2
1
1
2
3
Number 1
Number 2
1
Page 77
77
EN
Number 3
Number 4
Number 5
Page 78
78
Page 79
Setup settings
Page 80
Page 81
81
EN
Setup menu
General remarks The Setup menu provides simple access to expert knowledge in the power source and to
additional functions. The Setup menu can be used to make simple adjustments of the parameters to suit the various job settings.
Configuring the
setup parameters
Configuring the setup parameters is described here with reference to the "MIG/MAG standard synergic welding" process. The procedure for changing other setup parameters is identical.
Accessing the Setup menu
The control panel is now in the Setup menu for the "MIG/MAG standard synergic welding"
process - the last setup parameter that was selected is displayed.
Changing welding parameters
Exiting the Setup menu
Use the "Process" button to select the "MIG/MAG standard synergic welding" process
Press and hold the "Mode" button
Press the "Process" button
Release the "Mode" and "Process" buttons
Select the required setup parameter using the "Mode" and "Process" buttons or the left-hand adjusting dial
1
2
3
4
5
Change the value of the setup parameter using the "Parameter
selection" buttons or the right-hand adjusting dial
6
Press and hold the "Mode" button
Press the "Process" button
Release the "Mode" and "Process" buttons
7
8
9
Page 82
82
Setup parameters
for MIG/MAG
standard manual
welding
"Min." and "max." are used for setting ranges that differ according to power source, welding
program, etc.
GPr Gas pre-flow time
Unit: s
Setting range: 0 - 9.9
Factory setting: 0.1
GPo Gas post-flow time
Unit: s
Setting range: 0 - 9.9
Factory setting: 0.5
Fdi Feeder inching speed
Unit: m/min (ipm)
Setting range: 1 - max. (39.37 - max.)
Factory setting: 10 (393.7)
SL Slope (special 4-step mode only)
Unit: s
Setting range: 0 - 9.9
Factory setting: 0.1
I-S I (current) - Starting - Starting current (special 4-step mode only)
Unit: % (of welding current)
Setting range: 0 - 200
Factory setting: 100
I-E I (current) - End: Final current (special 4-step mode only)
Unit: % (of welding current)
Setting range: 0 - 200
Factory setting: 50
t-S t (time) - Starting - Starting current duration (special 4-step mode only)
Unit: s
Setting range: OFF, 0.1 - 9.9
Factory setting: OFF
t-S t (time) - End: Final current duration (special 4-step mode only)
Unit: s
Setting range: OFF, 0.1 - 9.9
Factory setting: OFF
bbc burn-back time correction
Wire burn-back effect due to wire withdrawal at end of welding
Unit: Setting range: 0 - 20
Factory setting: 0
IGC Ignition current
Unit: A
Setting range: 100 - 650
Factory setting: 500
Ito Ignition time-out - length of wire that is fed before the safety cut-out is trig-
gered
Unit: mm (in.)
Page 83
83
EN
Setting range: OFF, 5 - 100 (OFF, 0.2 - 3.94)
Factory setting: OFF
SPt Spot time - spot / stitch welding time
Unit: s
Setting range: OFF, 0.1 - 5
Factory setting: OFF
SPb Spot break - stitch pause time
Unit: s
Setting range: OFF, 0.1 - 10 (in 0.1 s increments)
Factory setting: OFF
FAC Factory - reset power source to factory settings
Press and hold down one of the "Parameter selection" buttons for 2 s to restore the
factory settings
- when "PrG" appears on the digital display, the power source has been reset
IMPORTANT! When the power source is reset, all personal settings in the Setup
menu are lost.
Operating points that were saved using the "Save" buttons are retained when the
power source is reset. The functions in the second level of the Setup menu (2nd)
are also not deleted. Exception: Ignition time-out function parameter (ito).
2nd Second level of the Setup menu (see "Setup menu - level 2")
NOTE! The "Ignition time-out" function (ito) is a safety function. The length of
wire that is fed before the safety cut-out trips may differ from the preset wire
length, particularly when the wire is being fed at high speeds.
Page 84
84
Setup parameters
for MIG/MAG
standard synergic welding
"Min." and "max." are used for setting ranges that differ according to power source, welding
program, etc.
GPr Gas pre-flow time
Unit: s
Setting range: 0 - 9.9
Factory setting: 0.1
GPo Gas post-flow time
Unit: s
Setting range: 0 - 9.9
Factory setting: 0.1
SL Slope
Unit: s
Setting range: 0 - 9.9
Factory setting: 0.1
I-S I (current) - Starting current
Unit: % (of welding current)
Setting range: 0 - 200
Factory setting: 100
I-E I (current) - End: Final current
Unit: % (of welding current)
Setting range: 0 - 200
Factory setting: 50
t-S t (time) - Starting - Starting current duration
Unit: s
Setting range: OFF, 0.1 - 9.9
Factory setting: OFF
t-E t (time) - End: Final current time
Unit: s
Setting range: OFF, 0.1 - 9.9
Factory setting: OFF
Fdi Feeder inching - feeder inching speed
Unit: m/min (ipm.)
Setting range: 1 - max. (39.37 - max.)
Factory setting: 10 (393.7)
bbc burn-back time correction -
Burn back effect due to wire withdrawal at end of welding
Unit: s
Setting range: Aut, 0 - 0.3
Factory setting: Aut
Ito Ignition time-out function - Length of wire that is fed before the safety cut-out
is triggered
Unit: mm (in.)
Setting range: Off, 5 - 100 (Off, 0.2 - 3.94)
Factory setting: OFF
Page 85
85
EN
SPt Spot time - spot / stitch welding time
Unit: s
Setting range: OFF, 0.1 - 5
Factory setting: OFF
SPb Spot break - stitch pause time
Unit: s
Setting range: OFF, 0.1 - 10 (in 0.1 s increments)
Factory setting: OFF
FAC Factory - reset power source to factory settings
Press and hold down one of the "Parameter selection" buttons for 2 s to restore the
factory settings
- when "PrG" appears on the digital display, the power source has been reset.
IMPORTANT! When the power source is reset, all personal settings in the Setup
menu are lost.
When the power source is reset, operating points that were saved using the "Save"
buttons are not deleted, but are retained in the memory. The functions in the second level of the Setup menu (2nd) are also not deleted. Exception: Ignition timeout function parameter (ito).
2nd Second level of the Setup menu (see "Setup menu - level 2")
NOTE! The "Ignition time-out" function (ito) is a safety function. The length of
wire that is fed before the safety cut-out trips may differ from the preset wire
length, particularly when the wire is being fed at fast wire feed speeds.
The "Ignition time-out" function (ito) is explained in the "Special functions and
options" section.
Page 86
86
Setup parameters
for MMA welding
IMPORTANT! If you reset the power source using the FAC factory setup parameter, the
hot-current time (Hti) and HotStart current (HCU) setup parameters are also reset.
HCU HotStart current
Unit: %
Setting range: 100 - 200
Factory setting: 150
Hti Hot-current time
Unit: s
Setting range: 0 - 2.0
Factory setting: 0.5
Ast Anti-Stick
Unit: Setting range: On, OFF
Factory setting: OFF
FAC Factory - Reset power source to factory setting
Press and hold down one of the "Parameter selection" buttons for 2 s to restore the
factory settings
- when "PrG" appears on the digital display, the power source has been reset.
IMPORTANT! When the power source is reset, all personal settings are lost.
When the power source is reset, operating points that were saved using the "Save"
buttons are not deleted, but are retained in the memory. The functions in the second level of the Setup menu (2nd) are also not deleted. Exception: Ignition timeout function parameter (ito).
2nd Second level of the Setup menu (see "Setup menu - level 2")
Page 87
87
EN
Setup menu - Level 2
Restrictions In conjunction with the level 2 of the Setup menu, the following restrictions occur:
Level 2 of the Setup menu cannot be selected:
- during welding
- if the "Gas test" function is active
- if the "Wire threading" function is active
- if the "Wire withdrawal" function is active
- if the "Blow through" function is active
If level 2 of the Setup menu is selected, the following functions are not available, even in
robot mode:
- Welding start-up - the "Power source ready" signal will not be emitted
- Gas testing
- Threading the wire
- Wire withdrawal
- Blow-through
Configuring the
setup parameters
Accessing the Setup menu
The control panel is now in the Setup menu - the last setup parameter that was selected is
displayed.
Selecting the "2nd" parameter
Accessing the Level 2 Setup menu
Press and hold the "Mode" button
Press the "Process" button
Release the "Mode" and "Process" buttons
Use the "Mode" and "Process" buttons or the left-hand adjusting
dial to select the "2nd" setup parameter
1
2
3
4
Press and hold the "Mode" button
Press the "Process" button
Release the "Mode" and "Process" buttons
5
6
7
Page 88
88
Changing welding parameters
Exiting the Level 2 Setup menu
Exiting the Setup menu
Use the "Mode" and "Process" buttons or the left-hand adjusting
dial to select the required setup parameter
8
Change the value of the setup parameter using the "Parameter
selection" buttons or the right-hand adjusting dial
9
Press and hold the "Mode" button
Press the "Process" button
Release the "Mode" and "Process" buttons
Press and hold the "Mode" button
Press the "Process" button
Release the "Mode" and "Process" buttons
10
11
12
13
14
15
Page 89
89
EN
Parameters for
MIG/MAG welding
in the Setup menu
level 2
C-C Cooling unit Control
(only with connected cooling unit)
Unit: Setting range: Aut, On, OFF
Factory setting: Aut
Aut: The cooling unit cuts out after a 2-minute welding off-time.
IMPORTANT! If the coolant temperature and flow monitoring options have been
installed in the cooling unit, the cooling unit cuts out as soon as the return-flow
temperature drops below 50 °C, but at the earliest after a 2-minute welding offtime.
On: The cooling unit is always ON
OFF: The cooling unit is always OFF
IMPORTANT! If the FAC welding parameter is used, the C-C parameter is not
reset to the factory setting. If the MMA welding process is selected, the cooling
unit is always switched off, even if the switch is in the "On" position.
C-t Cooling Time
(only with connected cooling unit)
Time from when flow monitoring is triggered until the "no | H2O" service code is
output. For example, if there are air bubbles in the cooling system, the cooling
unit will not cut out until the end of this preset time.
Unit: s
Setting range: 5 - 25
Factory setting: 10
IMPORTANT! Every time the power source is switched on, the cooling unit carries out a test run for 180 seconds.
SEt Setting - country-specific setting (Standard/USA) ... Std / US
Unit: Setting range: Std, US (Standard / USA)
Factory setting:
Standard version: Std (measurements: cm / mm)
USA version: US (measurements: inches)
r r (resistance) - welding circuit resistance (in mOhm)
see "Measuring welding circuit resistance r"
L L (inductivity) - welding circuit inductivity (in microhenry)
see "Displaying welding circuit inductivity L"
Page 90
90
Parameters for
manual metal arc
(MMA) welding in
the Setup menu
level 2
EnE Real Energy Input – electrical energy of the arc relative to the welding speed
Unit: kJ
Setting range: ON / OFF
Factory setting: OFF
Since the full range of values (1 kJ - 99999 kJ) cannot be displayed on the threedigit display, the following display format has been selected:
Value in kJ / indicator on display:
1 to 999 / 1 to 999
1000 to 9999 / 1.00 to 9.99 (without "ones" digit, e.g. 5270 kJ -> 5.27)
10000 to 99999 / 10.0 to 99.9
(without "ones" and "tens" digits, e.g. 23580 kJ -> 23.6)
ALC Arc Length Correction - correction of the arc length via the welding voltage
Setting range: ON / OFF
Factory setting: OFF
The arc length depends on the welding voltage. The welding voltage can be adjusted to suit individual needs in Synergic operation.
If the ALC parameter is set to "OFF", the welding voltage cannot be adjusted.
The welding voltage is automatically determined by the selected welding current
or wire speed. If the arc length correction is adjusted, the voltage changes, but
the welding current and wire speed remain the same. When setting the arc length
correction using the adjusting dial, the left display is used for the correction value
of the arc length. The welding voltage value on the right display changes simultaneously. Afterwards the left display shows the original value, e.g. welding current.
r r (resistance) - welding circuit resistance (in mOhm)
see "Measuring welding circuit resistance r"
L L (inductivity) - welding circuit inductivity (in microhenry)
see "Displaying welding circuit inductivity L"
Page 91
91
EN
Measuring welding circuit resistance r
General Measuring the welding circuit resistance r makes it possible to have a constant welding re-
sult at all times, even with hosepacks of different lengths. The welding voltage at the arc is
then always precisely regulated, regardless of the length and cross-sectional area of the
hosepack. The use of arc length correction is no longer required.
The calculated welding circuit resistance is shown on the display.
r = welding circuit resistance in milliohm (mOhm)
If the welding circuit resistance r has been measured correctly, the set welding voltage will
correspond exactly to the welding voltage at the arc. If you manually measure the voltage
on the output jacks of the power source, this voltage will be higher than the welding voltage
at the arc - that is, higher by the same amount as the voltage drop of the hosepack.
Measure the
welding circuit resistance r
Establish a grounding (earthing) connection to the workpiece
Accessing the Level 2 (2nd) Setup menu
Select parameter "r"
Remove the gas nozzle from the welding torch
Screw on the contact tip
Place the contact tip flush against the workpiece surface
Press the torch trigger briefly
- The welding circuit resistance is calculated. "run" is shown on the display during
the measurement.
The measurement is finished when the welding circuit resistance is shown on the display
in mOhm (e.g. 11.4).
Fit the gas nozzle back onto the welding torch
NOTE! The welding circuit resistance r depends on the hosepack used:
- If the length or cross-sectional area of the hosepack has changed, measure
the welding circuit resistance r again
- Measure the welding circuit resistance for every welding process separately
with the appropriate welding power-leads
NOTE! In order to obtain good welding results, it is essential to measure the welding circuit resistance correctly. Make sure that the contact between the earthing
clamp and the workpiece is on a cleaned workpiece surface.
NOTE! Make sure that the contact between the contact tip and the workpiece is
on a cleaned workpiece surface.
1
2
3
4
5
6
7
8
Page 92
92
Displaying welding circuit inductivity L
General Laying of the hosepacks has a significant effect on welding circuit inductivity and therefore
affects the welding process. It is important to lay the hosepacks correctly in order to obtain
the best possible welding result.
Displaying welding circuit inductivity L
The setup parameter "L" is used to display the most recently calculated welding circuit inductivity. The welding circuit inductivity is calibrated at the same time as the welding circuit
resistance r is calculated. Detailed information can be found in the "Measuring welding circuit resistance r" section.
Access the setup menu level 2 (2nd)
Select parameter “L”
The most recently calculated welding circuit inductivity L is shown on the right-hand digital
display.
L ... Welding circuit inductivity (in microhenry)
Laying the hosepacks correctly
1
2
Page 93
Troubleshooting and maintenance
Page 94
Page 95
95
EN
Troubleshooting
General The devices are equipped with an intelligent safety system. This means that to a large ex-
tent it has been possible to dispense with melting-type fuses. Melting-type fuses therefore
no longer need to be replaced. After a possible malfunction has been remedied, the device
is ready for use again.
Safety
Fault diagnosis Make a note of the serial number and configuration of the device and contact our After-
Sales Service team with a detailed description of the error, if
- errors occur that are not listed below
- the troubleshooting measures listed are unsuccessful
Power source has no function
Mains switch is on, but indicators are not lit up
Cause: There is a break in the mains lead; the mains plug is not plugged in
Remedy: Check the mains lead, ensure that the mains plug is plugged in
Cause: Mains socket or mains plug faulty
Remedy: Replace faulty parts
Cause: Mains fuse protection
Remedy: Change the mains fuse protection
Nothing happens when the torch trigger is pressed
Power source mains switch is ON and indicators are lit up
Cause: Only for welding torches with an external control plug: The control plug is not
plugged in
Remedy: Plug in the control plug
Cause: Welding torch or welding torch control line is faulty
Remedy: Replace welding torch
WARNING! Work that is carried out incorrectly can cause serious injury or damage. The following activities must only be carried out by trained and qualified personnel. Observe the safety rules in the power source operating instructions.
WARNING! An electric shock can be fatal. Before opening the unit
- Turn the mains switch to the "O" position
- Unplug the device from the mains
- Put up an easy-to-understand warning sign to stop anybody inadvertently
switching it back on again
- Using a suitable measuring device, check to make sure that electrically
charged components (e.g. capacitors) have discharged
CAUTION! Inadequate PE conductor connections can cause serious injury and
damage. The housing screws provide a suitable PE conductor connection for
earthing (grounding) the housing and must NOT be replaced by any other screws
which do not provide a reliable PE conductor connection.
Page 96
96
Nothing happens when the torch trigger is pressed
Power source mains switch is on, power source ON indication is lit up on the power source,
indications on wire-feed unit are not lit up
Cause: The interconnecting hosepack is faulty or not connected properly
Remedy: Check interconnecting hosepack
No welding current
Mains switch is on, one of the overtemperature service codes "to" is displayed. Detailed
information on the service codes "to0" to "to6" can be found in the section "Displayed service codes".
Cause: Overload
Remedy: Take the duty cycle into account
Cause: Thermostatic safety cut-out has tripped
Remedy: Wait until the power source automatically comes back on after the end of the
cooling phase
Cause: Limited supply of cooling air
Remedy: Remove air filter on the rear of the housing from the side and clean. Ensure
that the cooling air ducts are accessible.
Cause: The fan in the power source is faulty
Remedy: Contact After-Sales Service
No welding current
Mains switch is ON and indicators are lit up
Cause: Grounding (earthing) connection is incorrect
Remedy: Check the grounding (earthing) connection for correct polarity
Cause: There is a break in the power cable in the welding torch
Remedy: Replace the welding torch
No protective gas shield
All other functions are OK
Cause: Gas cylinder is empty
Remedy: Change the gas cylinder
Cause: The gas pressure regulator is faulty
Remedy: Replace the gas pressure regulator
Cause: Gas hose is not fitted or is damaged
Remedy: Fit or change the gas hose
Cause: Welding torch is faulty
Remedy: Change the welding torch
Cause: Gas solenoid valve is faulty
Remedy: Contact After-Sales Service
Page 97
97
EN
Irregular wire feed speed
Cause: Braking force has been set too high
Remedy: Loosen the brake
Cause: Hole in the contact tip is too narrow
Remedy: Use a suitable contact tip
Cause: Faulty inner liner in welding torch
Remedy: Check the inner liner for kinks, dirt, etc. and replace if necessary
Cause: The feed rollers are not suitable for the wire electrode being used
Remedy: Use suitable feed rollers
Cause: Feed rollers have the wrong contact pressure
Remedy: Optimise the contact pressure
Wirefeed problems
when using applications with long welding torch hosepacks
Cause: Incorrect arrangement of welding torch hosepack
Remedy: Arrange the welding torch hosepack in as straight a line as possible, avoiding
bends
Welding torch becomes very hot
Cause: The specification of the welding torch is inadequate
Remedy: Observe the duty cycle and loading limits
Cause: Only on water-cooled systems: Inadequate coolant flow
Remedy: Check coolant level, coolant flow, for coolant contamination, etc. For further
information refer to the cooling unit operating instructions.
Page 98
98
Poor weld properties
Cause: Incorrect welding parameters
Remedy: Check the settings
Cause: Poor ground earth connection
Remedy: Ensure good contact to workpiece
Cause: Inadequate or no protective gas shield
Remedy: Check the pressure regulator, gas hose, gas solenoid valve, torch gas con-
nection, etc.
Cause: Welding torch is leaking
Remedy: Change the welding torch
Cause: Wrong contact tip, or contact tip is worn out
Remedy: Replace the contact tip
Cause: Wrong wire alloy or wrong wire diameter
Remedy: Check the wire electrode that has been inserted
Cause: Wrong wire alloy or wrong wire diameter
Remedy: Check weldability of the base material
Cause: The shielding gas is not suitable for this wire alloy
Remedy: Use the correct shielding gas
Displayed service
codes
If an error message that is not described here appears on the displays, proceed as follows
to resolve the problem:
Turn the power source mains switch to the "O" position
Wait 10 seconds
Move the mains switch to the I position
If the error occurs again despite several attempts to eliminate it, or if the troubleshooting
measures listed here are unsuccessful.
Make a note of the error message displayed
Note down the configuration of the power source
Contact our After-Sales Service team with a detailed description of the error
ESr | 20
Cause: The selected cooling unit is not compatible with the power source
Remedy: Connect compatible cooling unit
-----
Cause: An invalid welding process was called up on the robot interface (no. 37) or an
empty flag was selected (no. 32)
Remedy: Call up a valid welding process or select assigned "Save" button
1
2
3
1
2
3
Page 99
99
EN
ELn | 8
Cause: The connected wire-feed unit is not supported
Remedy: Connect supported wire-feed unit
ELn | 12
Cause: Different control panels for selecting materials are in the system
Remedy: Connect similar control panels to select materials
ELn | 13
Cause: Illegal change of welding process during welding
Remedy: During welding do not carry out any illegal change of the welding process, re-
set error message by pressing any button
ELn | 14
Cause: More than only one robot interface is connected
Remedy: Only one robot interface may be connected, check the system configuration
ELn | 15
Cause: More than only one remote control unit is connected
Remedy: Only one remote control unit may be connected, check the system configura-
tion
Err | IP
Cause: The control unit of the power source has detected a primary overvoltage
Remedy: Check mains voltage, if the service code still remains, switch off the power
source, wait for 10 seconds and then switch the power source on again, if the
error keeps recurring, contact After-Sales Service
Err | PE
Cause: The earth current watchdog has triggered the safety cut-out of the power
source.
Remedy: Switch off the power source
Place the power source on an insulating surface
Connect the grounding (earthing) cable to a section of the workpiece that is
closer to the arc
Wait for 10 seconds and then switch the power source on again
If you have tried this several times and the error keeps recurring, contact After-Sales Service
Err | Ur
Cause: If the VRD option is available, the open circuit voltage limit of 35 V has been
exceeded.
Remedy: Switch off power source
Wait for 10 seconds and then switch the power source on again
no | UrL
Cause: The VRD option has tripped too early.
Remedy: Check whether all welding power-leads and control lines are connected.
Switch off the power source
Wait 10 seconds and switch the power source back on again
If the error occurs again - contact After Sales Service.
Page 100
100
E-Stop
Cause: "External stop" has tripped
Remedy: Remedy the event that triggered the external stop
-St | oP-
Cause: At the robot interface the flag was not deleted by the robot
Remedy: Delete the signal robot ready at the robot interface
PHA | SE
Cause: Phase failure
with TSt 2500c / TSt 2700c in particular:
If the failure occurs during welding, the welding operation stops.
with TSt 2500c MV / TSt 2700c MV in particular:
A single-phase operation with limited power is possible:
When switching on the power source, "PHA | SE1" is displayed in order to
show that a power reduction will be in effect.
If a change in supply from three-phase to single-phase occurs during welding
(display: "PHA | SE1") or from single-phase to three-phase (display: "PH |
ASE 3"), the welding operation stops.
Remedy: Check the mains fuse, mains cable and mains plug.
Switch off the power source, wait 10 seconds and switch the power source
back on again.
PHA | SE1
Cause: The power source is operated in single-phase mode.
Remedy: -
PHA | SE3
Cause: The power source is operated in 3-phase mode
Remedy: -
Err | 51
Cause: Mains undervoltage: The mains voltage has fallen below the tolerance range
Remedy: Check the mains voltage, if the error keeps recurring, contact the After-Sales
Service
Err | 52
Cause: Mains overvoltage: The mains voltage has risen above the tolerance range
Remedy: Check the mains voltage, if the error keeps recurring, contact the After-Sales
Service
EFd 5
Cause: Incorrect wire-feed unit connected
Remedy: Connect correct wire-feed unit
EFd 8
Cause: Overtemperature on the wire-feed unit
Remedy: Allow wire-feed unit to cool down
