FRONIUS SYMO ADVANCED UL
Specially developed for the requirements of tomorrow
PC board
replacement
concept
SnapINverter
Technology
Integrated Data
Communication
Smart Grid
Ready
SuperFlex
Design
Dynamic Peak
Manager
Featuring models ranging from 10 kW to 24 kW, the Fronius Symo Advanced is the ideal inverter for commercial applications.
The new Advanced versions combine the benefits of the Fronius Symo with additional features zero tilt mounting, light
weight and field serviceability.
TECHNICAL DATA FRONIUS SYMO ADVANCED (208-240 V VERSIONS)
INPUT DATA SYMO 10.0-3 208-240 SYMO 12.0-3 208-240
Max. PV generator output (P
Max. input current (I
Max. array short circuit current (MPP
Nominal input voltage 350 V 370 V 350 V 370 V
DC input voltage range (U
Feed-in start voltage (U
Usable MPP voltage range (U
Max. input voltage 600 V
Admissable conductor size DC AWG 14-AWG 6 copper direct, AWG 6 aluminum direct, AWG 4-AWG 2 copper or aluminum with input combiner
Number of MPP trackers 2
dc max1
) 15 kW
dc max
/ I
) 25 A / 16.5 A
dc max2
1 / MPP2) 37.5 A / 24.8 A
+ U
dc min
) 200 V
dc start
mpp min
) 200 - 600 V
dc max
+ U
) 300 - 500 V
mpp max
OUTPUT DATA SYMO 10.0-3 208-240 SYMO 12.0-3 208-240
AC nominal output (P ac,r) 9,995 W 11,995 W
Max. output power 9,995 VA 11,995 VA
Output configuration 208 / 240 V
Frequency range (f
Admissable conductor size AC AWG 14 - AWG 6
Total harmonic distortion < 1.5 % < 1.75 %
Power factor (cos φ
Max. continuous output current 27.7 A 24 A 33.3 A 28.9 A
OCPD/AC breaker size 35 A 30 A 45 A 40 A
min - fmax) 45 - 60 Hz
) 0-1 ind. / cap.
ac,r
208 V 240 V 208 V 240 V
peak
18 kW
peak
208 V 240 V 208 V 240 V
EFFICIENCY SYMO 10.0-3 208-240 SYMO 12.0-3 208-240
208 V 240 V 208 V 240 V
Max. Eciency 97.0 %
CEC Eciency 96.5 % 96.5 %
TECHNICAL DATA FRONIUS SYMO (208-240 V VERSIONS)
GENERAL DATA SYMO 10.0-3 208-240 SYMO 12.0-3 208-240
Dimensions (height x width x depth) 510 x 725 x 225 mm (20.1 x 28.5 x 8.9 inches)
Weight 41.7 kg (91.9 lbs)
Protection Class NEMA 4X
Night time consumption < 1 W
Inverter topology Transformerless
Cooling Regulated air cooling
Installation Indoor and outdoor installation, tilt from 0 - 90 degrees
DIN rail (length x width x depth) max. 106 x 90 x 66 mm (max. 4.2 x 3.5 x 2.6 inches)
Ambient operating temperature range -40 - +60 °C (-40 - +140 °F)
Permitted humidity 0 - 100 % (non-condensing)
Elevation max. input voltage of 600 V up to 3,400 m (11.155 ft)
DC connection technology 6x DC+ and 6x DC- screw terminals for copper (solid / stranded / fine stranded) or aluminum (solid / stranded)
AC connection technology Screw terminals 14-6 AWG
1
Fronius Shade Cover required for installation angles less than 15 degree
PROTECTIVE DEVICES SYMO 10.0-3 208-240 SYMO 12.0-3 208-240
DC reverse polarity protection Yes
Anti islanding Yes
Over temperature protection Output power derating /Active cooling
Ground Fault Protection with Isolation Monitor
Interrupter
DC disconnector Yes
Yes
1
INTERFACES SYMO 10.0-3 208-240 SYMO 12.0-3 208-240
USB (A socket) Datalogging and inverter update possible via USB
2x RS422 (RJ45 socket) Fronius Solar Net, interface protocol
Wi-Fi/Ethernet/Serial/ Datalogger and webserver
6 inputs and 4 digital I/Os
2
Available with the Fronius Datamanager 2.0 Card (only one card required for up to 100 inverters)
2
2
Wireless standard 802.11 b/g/n / Fronius Solar.web, SunSpec Modbus TCP, JSON / SunSpec Modbus RTU
Load management; signaling, multipurpose I/O
TECHNICAL DATA FRONIUS SYMO (480 V VERSIONS)
INPUT DATA SYMO 15.0-3 480 SYMO 20.0-3 480 SYMO 22.7-3 480 SYMO 24.0-3 480
Max. PV generator output (P
Max. input current (I
dc max1
Max. array short circuit current (MPP
Nominal input voltage 685 V 710 V 720 V
DC input voltage range (U
DC startup voltage 200 V
Usable MPP voltage range (U
Max. input voltage 1,000 V
Admissable conductor size DC AWG 14 - AWG 6 copper direct, AWG 6 aluminum direct, AWG 4 - AWG 2 copper or aluminum with input combiner
Number of MPP trackers 2
) 22.5 kW
dc max
/ I
) 33 A / 25 A
dc max2
1 / MPP2) 49.5 A / 37.5 A
+ U
dc min
mpp min
) 200 - 1,000 V
dc max
+ U
) 350 - 800 V 450 - 800 V 500 - 800 V
mpp max
peak
30 kW
peak
34 kW
peak
36 kW
peak
