SUGAR cAne MILL cRUSheR RoLLS
Industry: suGAr- / EthAnol sEGMEnt
/ Mechanized hard facing of teeth of sugar cane mill rolls in the sugar & ethanol industry.
stEP 1: l AtErAl
stEP 2: BAsE
stEP 3: hook
Position: Vertical-down
Current: 150 - 170 A
Voltage: 25 - 28 V
Stickout length: 18 mm (0.7 in)
Welding speed: 36 cm/min
(14.17 in/min)
Weaving width: 12 - 20 mm
(0.47 - 0.78 in)
Number of torches: 1 or 2
Position: Vertical down
Current: 150 - 170 A
Voltage: 25 - 28 V
Stickout length: 18 mm (0.7 in)
Welding speed: 36 cm/min
(14.17 in/min)
Weaving width: 12 - 20 mm
(0.47 - 0.78 in)
Number of torches: 1 or 2
Position: Downhand
Current: 150 - 180 A
Voltage: 25 - 28 V
Stickout length: 20 mm (0.78 in)
Number of torches: 1
Base
rEMotE Control
/ FRC-1200 with
magnetic holder
CurrEnt
CouPlInG
/ 1200 A
Hook
Lateral
Arcing
ArCInG
MultIloCk torCh
/ Water-cooled
CArrIAGE
/ ArcingTrack 1200 carriage
/ Arcing torch (multilock)
/ Servo driven torch motion
/ Rail track (2m / 3m)
WIrE fEEdEr
/ WF 15i D400 wire feeder
PoWEr sourCE sEt
/ TPS 600i power source
/ CU 1100i Basic cooling unit
/ Arcing control-box
stEP 4 : ArCInG
Position: Vertical-down
Current: 250 - 350 A
Voltage: 28 - 36 V
Stickout length: 40 - 60 mm
(1.57 - 2.36 in)
Welding speed: 4 - 6 rpm
Number of torches: 1 or 2
/ Watch the video on
our YouTube channel.
