BUILD YOUR ROBOTIC WELDING PACKAGE:

Print or download this page, choose and mark your options
and email to: [e-mail] to request aquote

For additional software and accessories, see page 57 of the
Robotic Packages Catalog.

*Sample robot model image only

CHOOSE ABB ROBOT MODEL

IRB 1520ID - 4/1.50

IRB 1600 - 6/1.45 IRB2600ID - 8/2.00

IRB 2600 - 12/1.85 IRB 4600 - 20/2.50

IRB 2600 - 20/1.65

IRB2600ID - 15/1.85

CHOOSE WELDING SYSTEM

Push

Push/Pull

CMT

TIG

CHOOSE POWER SUPPLY AMPERAGE

CHOOSE WELDING PACKAGE AND SOFTWARE OPTIONS

WP Standard (see page 12)

WP Pulse (see page 13) WP PMC (see page 14)

WP CMT (see page 13) Quality monitoring

WP LSC (see page 12)

CHOOSE COOLING SYSTEM AND HOSEPACK LENGTH

Gas-cooled

Water-cooled 8 m

4 m

10 m

CHOOSE TORCH ANGLE

22 Degree

36 Degree

45 Degree

320A

400A

500A

600A

CHOOSE WIRE DIAMETER AND FILTER METERIAL

0.8

0.9 Steel

1.0 Aluminium

1.2

1.6

Stainless Steel

240A@%100 DC

320A@%100 DC

360A@%100 DC

500A@%100 DC

CHOOSE HARDWARE OPTIONS

Drum components

Spool components

Nozzle touch sense (for water-cooled
systems only)

Gas controller

CHOOSE CLEANING STATION

TC 2000 (magnetic touchless cleaner)

Robacta Reamer V70 (mechanical cleaner)

See page 22-23

See page 22-23
