Features
FTW 10-60
Tube-to-tubesheet
weldhead
Tube-inside diameter range 9,5 - 60,5 mm
(0.374 - 2.381 inch)
- Robust, water-cooled weld head
- Tube-inside diameter range 9,5 - 60,5 mm (0.374-
2.381 inch), optionally up to 120 mm (4.724 inch)
- Pneumatic centering
- Hose pack 8 m (314.96 inch), water-cooled
- Torch with electrode Ø 2,4 mm (0.09 inch)
- Transport case
- Compatible with FPA 4030 System controller
Accessories / Options
- Mandrels and spring sleeves
- Torch for electrode Ø 3.2 mm (0.12 inch)
- Extension-kit for inside Ø >60 mm (>2.36 inch)
- Titanium distribution nozzle-set
- Balancer
3 versions available:
- FTW 10-60 with pneum. centering
- FTW 10-60 with pneum. centering
+ Integrated wire feeder
- FTW 10-60 with pneum. centering
+ Integrated wire feeder
+ AVC
370 mm
550 mm
(21.65 inch)
Technical data FTW 10-60
Tube inside-diameter range
Welding current max. 200 A
Rotation speed max. 5 rpm
Wire spool 1kg (2 .2 lbs), D100
Wire diameter 0,8 - 1,5 mm (0.031 - 0.059 inch)
Weight without wire feeder 8 kg (17.63 lbs)
Weight with wire feeder 10,5 kg (23 .14 lbs)
Weight with wire feeder
& AVC
290 mm
(11.41 inch)
9,5 – 60,5 mm
(0.374-2.381 inch)
11 kg (24. 25 lbs)
(14.56 inch)
www.fronius.com
