1 Introduction

The Fronius Solar API is a means for third parties to obtain data from various Fronius devices (inverters, Sensor
Cards, StringControls) in a defined format through a central facility which acts as a proxy (e.g. Fronius Datalogger
Web or Fronius Solar.web).

Currently, the only way to interact with this API is by making a HTTP request to a specific CGI. The URLs for
the particular requests and the devices supporting them are listed at the beginning of each request description.
The API is versioned, meaning that multiple versions of this API may be available on the same device. The URLs
in this document always point to the version of the API which this document describes. The highest supported
version on the device can be queried. See 2.4.1 for details.
In order to check your product for compatibility with this version of the API specification, please see the separate
document provided for this purpose.

The API divides roughly into realtime and archive requests: Realtime requests will obtain the data directly from the
devices and can therefore only be used when the devices are not in standby or unavailable in any other manner.
Archive requests will use the data stored in a central logging facility to obtain the results and are of course not
subjected to the former limitation.

2 General Considerations

2.1 Output Formats

Currently, the only output format supported is JSON, a lightweight data interchange format. It is easy to read
and write for both humans and machines and it offers some advantages over XML, like basic typing and a leaner
structure.

+ It is strongly recommended to use appropriate frameworks or tools to parse json objects properly

2.2 Fronius GEN24 and Tauro

2.2.1 Client Generation using OAS

We provide an OpenAPI interface specification1file for GEN24/Tauro inverters to support client generation in
multiple languages.

Download the file here: https://www.fronius.com/QR-link/0025.

To display the spec you can use https://editor.swagger.io, for proper client generation please use https:
//openapi-generator.tech.

2.2.2 Inverter to inverter communication

Collecting data from multiple inverters in the same network is not supported by so called system requests on
GEN24/Tauro devices. To gather the information please invoke ident requests on all GEN24/Tauro inverters
interested by you.

2.3 Data Types

2.3.1 Numeric Types

JSON only knows one kind of numeric type, which can represent both floating point and integer values. It is how
ever possible to specify a type in JSON description, but it is always in the hands of the interpreting system into
which datatype a numeric node is converted.
Which range a certain numeric node actually can have is often determined by the device providing the value,
and may also vary depending on the type of device (e.g. ”UAC” can be an integer value on older inverters, but a
floating point value on newer ones).

1

https://swagger.io/specification

6

This means we cannot reliably specify value ranges for all requests. So it is the responsibility of the API user
to determine whether a value fits into a certain datatype in his language of choice.
What we can do is to specify whether a certain value is a floating point value (marked as ”number”) or an integer
value (marked as ”integer”), where ”integer” must not be interpreted as the datatype ”int” like available in C/C++,
it just means it is a value without decimal places.
For these specifications, please refer to the sections discussing the respective request.

Examples

number 1, 2, 0, 4, 4.0, 0.001, 10.002, ....

integer 1, 2, 0, 4, 10

unsigned integer 1, 0, 4, 10

unsigned number 1, 0, 4, 10, 0.001, 14.1234

2.3.2 Date/Time

Information on date/time is always (and can only be) represented by a string. The format for these strings inside
this API has been defined as follows.

• Strings which include information on both date and time are always in RFC3339 format with time zone offset
or Zulu marker.
See Section 5.6 of RFC3339
Example 1: 2011-10-20T10:23:17+02:00 (UTC+2)
Example 2: 2011-10-20T08:23:17Z (UTC)

• Strings which only include information on the date are of the format yyyy-MM-dd.

• Strings which only include information on the time are of the format

hh:mm:ss

.

• If no information on the time zone is given, any date/time specification is considered to be in local time of
the PV system.

2.4 Requests

Currently, the only request protocol supported is HTTP.

+ Use HTTPGET requests to query data from Solar API

2.4.1 Querying of API version

The highest supported version on the device can be queried using the URL
/solar_api/GetAPIVersion.cgi.

Listing 1: Object structure of GetAPIVersion response

ob je ct {

# Numeric ver si on of the API.
# all D at amanager and Hy br id ma na ge r support onl y APIVersion 1

un si gn ed integer APIVer si on ;

# URL under wh ich the CGIs for the re qu ests can be reache d.

st ri ng BaseURL;

# C om pa ti bi li ty v ersion of current im pl em en ta ti on ( ex ce pt Get Po we rF lo wR ealtimeData )
# THIS FIEL D IS AVAILABLE AND MANDATORY SI NC E
# Datamanager 3.9. 1-x
# Hybridmanager 1.7. 1-x
# FORMAT: MAJO R.MINOR -BUI LD
# Major : co mp at ib il it y range (something big c ha ng ed )
# Minor : fe at ure range ( new f ea tu res added )

7

# Build : bu gfix revision (onl y b ug fi xes a pplied )

st ri ng Compati bi li ty Ra ng e;

}

Listing 2: Example: Complete response for GetAPIVersion request

{

"APIVersion " : 1,
"BaseURL" : "/solar_api /v1/",
"Compat ib il it yR an ge " : "1.5 -9 "

}

2.4.2 Addressing of devices

A specific device is identified by the string parameter DeviceId.
For Fronius Solar Net devices this string shall contain the numeric address of the targeted device.
Future generations of Fronius devices may also use non numerical addresses, so this API is designed to allow
for both.

2.5 Responses

The response will always be a valid JSON string ready to be evaluated by standard libraries.
If the response is delivered through HTTP, the Content-Type Header shall be either text/javascript or
application/json.

All JSON structures are described using Orderly JSON, a textual format for describing JSON data. Please refer
to the online documentation on https://github.com/lloyd/orderly/ for details.
Note that the definitions of some response bodies are not totally accurate, because there’s no (known) way to
express nodes named after values/channels (e.g. objects which are named ”PAC” or ”Power”). But each descrip
tion is accompanied by an example which should clear up any uncertainty.

The contents of the response object will vary depending on the preceding request but it always contains a common
response header and a request body.

Listing 3: Object structure of valid response

ob je ct {

ob je ct Head : { }*;

ob je ct Body : { }*;

}

Listing 4: Example: Complete response for GetInverterRealtimeData request on non hybrid system

{

"Body" : {

"Data" : {

"DAY_ENERGY " : {

"Unit" : "Wh",

"Value " : 1639 0

},

"DeviceStatus " : {

"ErrorCode" : 0,

"LEDColor " : 2,

"LEDState " : 0,

"Mgmt Ti me rR em ai ni ngTime" : -1,

"StateToReset " : f alse ,

"StatusCode " : 7

},

"FAC " : {

"Unit" : "Hz",

"Value " : 49.990000000000 00 2

},

8

},

"Head" : {

}

}

"IAC " : {

"Unit" : "A",

"Value " : 17.890000000000 00 1

},

"IDC " : {

"Unit" : "A",

"Value " : 6.7400000000000 00 2

},

"PAC " : {

"Unit" : "W",

"Value " : 40 97

},

"TOTAL_ENERGY " : {

"Unit" : "Wh",

"Value " : 861294 2

},

"UAC " : {

"Unit" : "V",

"Value " : 229.90000000000 00 1

},

"UDC " : {

"Unit" : "V",

"Value " : 67 4

},

"YEAR_ENERGY" : {

"Unit" : "Wh",

"Value " : 7752 71

}

}

"RequestA rg um en ts " : {

"DataCollection " : " CommonInverte rD at a",
"DeviceClass" : " In verter ",
"DeviceId " : "1" ,
"Scope " : "Devic e"

},

"Status" : {

"Code" : 0,
"Reason" : "",
"UserMessage" : ""

},

"Timestamp" : "2018 -03- 01 T12 :4 9: 42 +0 1: 00 "

2.5.1 Availability

A request is listed as ”Available” if the response http code differs to 404 (not found). It does not relay to technical
compatibility nor functionality.

2.5.2 Common Response Header

The common response header (CRH) is present in every response. It indicates, among other things, whether the
request has been successful and the body of the response is valid.

Listing 5: Object Structure of Common Response Header

ob je ct {

# R ep etition of the parameters which pr od uc ed this respon se .

ob je ct {

# Filled with p ro perties named li ke the g iven parameters.

}* RequestArguments;

# I nf or ma ti on about t he response.

9

ob je ct {

# I ndicates if the r eq ue st went OK or give s a hint abou t w hat went wrong .
# 0 m ea ns OK , any ot her value me ans s omething went wrong ( e.g. De vice no t a vailabl e ,
# invalid pa rams , no data in logf la sh for gi ven ti me , ...) .

in te ge r Code;

# Error message , may be empty.

st ri ng Reason ;

# Error me ss ag e to be displayed to th e user , may be empty.

st ri ng UserMessage ;

} Status;

# RFC3339 timestam p i n localtime of the d at al og ge r.
# This is the time the r eq uest was a ns we red - N OT th e time when the d ata
# was qu er ied from th e device.

st ri ng Timestamp ;

};

Value Status Description
0 OKAY Request successfully finished, Data are valid
1 NotImplemented The request or a part of the request is not implemented yet
2 Uninitialized Instance of APIRequest created, but not yet configured
3 Initialized Request is configured and ready to be sent
4 Running Request is currently being processed (waiting for response)
5 Timeout Response was not received within desired time
6 Argument Error Invalid arguments/combination of arguments or missing arguments
7 LNRequestError Something went wrong during sending/receiving of LNmessage
8 LNRequestTimeout LNrequest timed out
9 LNParseError Something went wrong during parsing of successfully received LNmessage
10 ConfigIOError Something went wrong while reading settings from local config
11 NotSupported The operation/feature or whatever is not supported
12 DeviceNotAvailable The device is not available
255 UnknownError undefined runtime error

Table 1: Error Code Table

2.5.3 Request Body

The request body contains the actual data produced by the request and is therefore different for each request.
The object structures of the various response bodies will be detailed later in the description of the respective API
request.

2.6 Timeout

Up to 2 realtime requests are allowed to be performed in parallel with keeping a timeout of 4 seconds between
two consecutive calls.
Archive requests are not allowed to be performed in parallel and need to keep a timeout of 120 seconds between
two consecutive calls.

3 Enable/Disable

The Solar API’s enable/disable feature is available on GEN24 only.

The configuration to enable or disable the Solar API can be found in the WebUI under Communication  So
lar API (1).

If the Solar API is disabled, a Solar API request will return with a 404HTTPerror and the message ”Solar API

10

Figure 1: Solar API activation/deactivation

disabled by customer config” will be displayed.

Default enable/disable behaviour:

• For new devices with a bundle version of 1.14.1 or higher the Solar API is deactivated per default.

• For existing devices which are updated, the Solar API remains enabled.

• If a factory reset is performed with existing devices running a bundle version of 1.14.1 or higher, the Solar
API will be deactivated per default as well.

4 Realtime Requests

These requests will be provided where direct access to the realtime data of the devices is possible. This is cur
rently the case for the Fronius Datalogger Web and the Fronius Datamanager.

In order to eliminate the need to specify each wanted value separately when making a request or querying each
value separately, so called ”Data Collections” were defined.
The values in these collections are gathered from one or more Fronius Solar Net messages and supplied to the
user in a single response to a certain request.
It may be the case that more values are queried from the device than the user is interested in, but the overhead
caused by these superfluous values should be negligible compared to the advantages this strategy provides for
the user.

If a device cannot provide some values of a DataCollection (e.g. because they are not implemented on
the device) then those values are omitted from the response.

4.1 GetInverterRealtimeData request

This request does not care about the configured visibility of single inverters. All inverters are reported.

4.1.1 Availability

Platform Since version
Fronius Hybrid Not all DataCollections supported
Fronius Non Hybrid ALWAYS
Fronius GEN24/Tauro Not all DataCollections supported

4.1.2 Collection availability

DataCollection supported on

Fronius Hybrid Systems Fronius GEN24/Tauro
CumulationInverterData Yes Yes
CommonInverterData Yes Yes
3PInverterData Yes Only on 3 phase inverters
MinMaxInverterData NO NO

11

4.1.3 URL for HTTP requests

/solar_api/v1/GetInverterRealtimeData.cgi

4.1.4 Parameters

Parameter Type Range/Values/Pattern Description
Scope String ”Device”

”System”

Query specific device(s)
or whole system (uses collection ”Cumu
lationInverterData”)

DeviceId String Solar Net: 0 …99 Only needed for Scope ”Device”

Which inverter to query.

DataCollection String ”CumulationInverterData”

”CommonInverterData”
”3PInverterData”
”MinMaxInverterData”

Only needed for Scope ”Device”

Selects the collection of data that should
be queried from the device.
See 4.1.5 for details.

4.1.5 Data Collections

CumulationInverterData Values which are cumulated to generate a system overview.

Value name specific data type Description
PAC integer AC power (negative value for consuming power)
DAY_ENERGY unsigned number AC Energy generated on current day

Non Hybrid: May be imprecise
GEN24/Tauro: will always report null

YEAR_ENERGY unsigned number AC Energy generated in current year

Non Hybrid: May be imprecise
GEN24/Tauro: will always report null

TOTAL_ENERGY unsigned number AC Energy generated overall

Non Hybrid: May be imprecise
GEN24/Tauro: supported since 1.14 (updated every
5min)

DeviceStatus object Status information about inverter

CommonInverterData Values which are provided by all types of Fronius inverters.

12

Value name specific data type Description
PAC integer AC power (negative value for consuming power)
SAC unsigned integer AC power (absolute)

Currently not implemented because not handled correctly
by all inverters.

GEN24/Tauro report this value
IAC unsigned number AC current (absolute, accumulated over all lines)
UAC unsigned number AC voltage
FAC unsigned number AC frequency
IDC unsigned number DC current
IDC_x unsigned number DC current of MPPT tracker x (x = 2..4; available on

GEN24/Tauro only)
UDC unsigned number DC voltage
UDC_x unsigned number DC voltage of MPPT tracker x (x = 2..4; available on

GEN24/Tauro only)
DAY_ENERGY unsigned number AC Energy generated on current day

Non Hybrid: May be imprecise

GEN24/Tauro: will always report null
YEAR_ENERGY unsigned number AC Energy generated in current year

Non Hybrid: May be imprecise

GEN24/Tauro: will always report null
TOTAL_ENERGY unsigned number AC Energy generated overall

Non Hybrid: May be imprecise

GEN24/Tauro: supported since 1.14(updated every

5min)
DeviceStatus object Status information about inverter

3PInverterData Values which are provided by 3phase Fronius inverters.

Value name specific data type Description
IAC_L1 unsigned number AC current Phase 1 (absolute)
IAC_L2 unsigned number AC current Phase 2 (absolute)
IAC_L3 unsigned number AC current Phase 3 (absolute)
UAC_L1 unsigned number AC voltage Phase 1
UAC_L2 unsigned number AC voltage Phase 2
UAC_L3 unsigned number AC voltage Phase 3
T_AMBIENT integer Ambient temperature

Most inverter like GEN24/Tauro do not provide it. Only
provided by CL, XL and IG500/400.

ROTATION_SPEED_FAN_FL unsigned integer Rotation speed of front left fan

not provided on GEN24/Tauro

ROTATION_SPEED_FAN_FR unsigned integer Rotation speed of front right fan

not provided on GEN24/Tauro

ROTATION_SPEED_FAN_BL unsigned integer Rotation speed of back left fan

not provided on GEN24/Tauro

ROTATION_SPEED_FAN_BR unsigned integer Rotation speed of back right fan

not provided on GEN24/Tauro

MinMaxInverterData Minimum and Maximumvalues of various inverter values.

13

Value name specific data type Description
DAY_PMAX unsigned integer Maximum AC power of current day
DAY_UACMAX number Maximum AC voltage of current day
DAY_UACMIN number Minimum AC voltage of current day
DAY_UDCMAX number Maximum DC voltage of current day
YEAR_PMAX unsigned integer Maximum AC power of current year
YEAR_UACMAX number Maximum AC voltage of current year
YEAR_UACMIN number Minimum AC voltage of current year
YEAR_UDCMAX number Maximum DC voltage of current year
TOTAL_PMAX unsigned integer Maximum AC power of current year
TOTAL_UACMAX number Maximum AC voltage overall
TOTAL_UACMIN number Minimum AC voltage overall
TOTAL_UDCMAX number Maximum DC voltage overall

4.1.6 Object structure of response body (Scope ”Device”)

Listing 6: Object structure of response body for GetInverterRealtimeData request (Scope ”Device”)

ob je ct {

# C ol lection of na me d valu e -uni t p airs accordin g to selected DataCollection.
# Members of Data object ar e n amed accordin g to the v al ue they r epresent (e .g. " PAC").

ob je ct {

# Value -Uni t pair.

ob je ct {

# U nscaled value.
# value na me base d s pe ci fi c data type

<specifi c data type > V alue ;

# Base un it of the v alue , n ever contai ns any pr ef ix es .

st ri ng Unit ;

} _ _V AL UE _N AM E_ _;

}* Data ;

};

4.1.7 Example of response body (Scope ”Device”)

Listing 7: Response body for GetInverterRealtimeData scope=”Device” and collection=”CommonInverterData”

{

"Body" : {

"Data" : {

"DAY_ENERGY " : {

"Unit" : "Wh",

"Value " : 1393 .2

},

"DeviceStatus " : {

"ErrorCode" : 0,

"LEDColor " : 2,

"LEDState " : 0,

"Mgmt Ti me rR em ai ni ngTime" : -1,

"StateToReset " : f alse ,

"StatusCode " : 7

},

"FAC " : {

"Unit" : "Hz",

"Value " : 49.969999999999 99 9

},

"IAC " : {

"Unit" : "A",

14

},

"Head" : {

}

}

"Value " : 0.35999999999 99 99 99

},

"IDC " : {

"Unit" : "A",

"Value " : 0.32000000000 00 00 01

},

"PAC " : {

"Unit" : "W",

"Value " : 84

},

"TOTAL_ENERGY " : {

"Unit" : "Wh",

"Value " : 1734796.1200000 00 1

},

"UAC " : {

"Unit" : "V",

"Value " : 232.40000000000 00 1

},

"UDC " : {

"Unit" : "V",

"Value " : 399.89999999999 99 8

},

"YEAR_ENERGY" : {

"Unit" : "Wh",

"Value " : 322593 .5

}

}

"RequestA rg um en ts " : {

"DataCollection " : " CommonInverte rD at a",
"DeviceClass" : " In verter ",
"DeviceId " : "1" ,
"Scope " : "Devic e"

},

"Status" : {

"Code" : 0,
"Reason" : "",
"UserMessage" : ""

},

"Timestamp" : "2019 -06- 12 T15 :3 1: 03 +0 2: 00 "

Listing 8: Response body for GetInverterRealtimeData scope=”Device” and collection=”3PInverterData” on Symo
Hybrid

{

"Body" : {

"Data" : {

"IAC_L1" : {

"Unit" : "A",

"Value " : 0.08000000000 00 00 00 2

},

"IAC_L2" : {

"Unit" : "A",

"Value " : 0.04000000000 00 00 00 1

},

"IAC_L3" : {

"Unit" : "A",

"Value " : 0.08000000000 00 00 00 2

},

"UAC_L1" : {

"Unit" : "V",

"Value " : 233.90000000000 00 1

},

"UAC_L2" : {

15

"Unit" : "V",

"Value " : 23 3

},

"UAC_L3" : {

"Unit" : "V",

"Value " : 230.69999999999 99 9

}

}
},

"Head" : {

"RequestA rg um en ts " : {

"DataCollection " : " 3PInverterData" ,
"DeviceClass" : " In verter ",
"DeviceId " : "1" ,

"Scope " : "Devic e"

},

"Status" : {

"Code" : 0,

"Reason" : "",

"UserMessage" : ""

},

"Timestamp" : "2021 -05- 19 T09 :4 9: 39 +0 2: 00 "

}

}

Listing 9: Response body for GetInverterRealtimeData scope=”Device” and collection=”3PInverterData” on
GEN24 Symo

{

"Body" : {

"Data" : {

"IAC_L1" : {

"Unit" : "A",

"Value " : 0.39000001549 72 07 64

},

"IAC_L2" : {

"Unit" : "A",

"Value " : 0.38900002837 18 10 91

},

"IAC_L3" : {

"Unit" : "A",

"Value " : 0.3970000147819 51 9

},

"UAC_L1" : {

"Unit" : "V",

"Value " : 233.10000610351 56 2

},

"UAC_L2" : {

"Unit" : "V",

"Value " : 234. 5

},

"UAC_L3": {

"Unit" : "V",

"Value " : 230.71844482421 87 5

}

}
},

"Head" : {

"RequestA rg um en ts " : {

"DataCollection " : " 3PInverterData" ,
"DeviceClass" : " In verter ",
"DeviceId " : "1" ,

"Scope " : "Devic e"

},

"Status" : {

"Code" : 0,

"Reason" : "",

16

"UserMessage" : ""

},

"Timestamp" : "2021 -01- 19 T11 :0 4: 36 +0 0: 00 "

}

}

Listing 10: Response body for GetInverterRealtimeData scope=”Device” and collection=”CommonInverterData”
on GEN24 Symo

{

"Body" : {

"Data" : {

"DAY_ENERGY " : {

"Unit" : "Wh",

"Value " : nu ll

},

"DeviceStatus " : {

"ErrorCode" : 0,

"InverterState" : "Running " ,

"StatusCode " : 7

},

"FAC " : {

"Unit" : "Hz",

"Value " : 50.012432098388 67 2

},

"IAC " : {

"Unit" : "A",

"Value " : 1.5640000402927 39 9

},

"IDC " : {

"Unit" : "A",

"Value " : 0.66413545608 52 05 08

},

"IDC_2 " : {

"Unit" : "A",

"Value " : 0.65616516515 61 65 18

},

"IDC_3 " : {

"Unit" : "A",

"Value " : 0.68945421323 03 22 08

},

"IDC_4 " : {

"Unit" : "A",

"Value " : 0.63216161556 16 51 68

},

"PAC " : {

"Unit" : "W",

"Value " : 1965.2919921875

},

"SAC " : {

"Unit" : "VA",

"Value " : 1965.4365234375

},

"TOTAL_ENERGY " : {

"Unit" : "Wh",

"Value " : 3120.0222222222 22 4

},

"UAC " : {

"Unit" : "V",

"Value " : 234.19126892089 84 4

},

"UDC " : {

"Unit" : "V",

"Value " : 1.9832431077957 15 3

},

"UDC_2 " : {

"Unit" : "V",

17

},

"Head" : {

}

}

"Value " : 72.425910949707 03 1

},

"UDC_3 " : {

"Unit" : "V",

"Value " : 416.4656516515115

},

"UDC_4 " : {

"Unit" : "V",

"Value " : 409.69140625

},

"YEAR_ENERGY" : {

"Unit" : "Wh",

"Value " : nu ll

}

}

"RequestA rg um en ts " : {

"DataCollection " : " CommonInverte rD at a",
"DeviceId " : "1" ,
"Scope " : "Devic e"

},

"Status" : {

"Code" : 0,
"Reason" : "",
"UserMessage" : ""

},

"Timestamp" : "2022 -02- 14 T12 :3 3: 54 +0 0: 00 "

Listing 11: Response body for GetInverterRealtimeData scope=”Device” and collection=”CumulationInverterData”
on GEN24 Primo

{

"Body" : {

"Data" : {

"DeviceStatus :" : {

"InverterState" : "Running "

},

"PAC " : {

"Unit" : "W",

"Value " : 8.4296154682294 41 7e+252

}

}
},

"Head" : {

"RequestA rg um en ts " : {

"DataCollection " : " Cumulatio nI nv er te rD at a ",
"DeviceClass" : " In verter ",
"DeviceId " : "1" ,

"Scope " : "Devic e"

},

"Status" : {

"Code" : 0,

"Reason" : "",

"UserMessage" : ""

},

"Timestamp" : "2019 -08- 28 T05 :5 9: 13 +0 0: 00 "

}

}

Listing 12: Response body for GetInverterRealtimeData scope=”Device” and collection=”CumulationInverterData”
on Tauro

{

"Body" : {

18

"Data" : {

"DAY_ENERGY " : {

"Unit" : "Wh",

"Value " : nu ll

},

"DeviceStatus " : {

"ErrorCode" : 0,

"InverterState" : "Running " ,

"StatusCode " : 7

},

"FAC " : {

"Unit" : "Hz",

"Value " : 50.025005340576 17 2

},

"IAC " : {

"Unit" : "A",

"Value " : 426.41439819335 93 8

},

"IDC " : {

"Unit" : "A",

"Value " : 8.0665655136108 39 8

},

"IDC_2 " : {

"Unit" : "A",

"Value " : nu ll

},

"IDC_3 " : {

"Unit" : "A",

"Value " : nu ll

},

"IDC_4 " : {

"Unit" : "A",

"Value " : 0.63216161556 16 51 68

},

"PAC " : {

"Unit" : "W",

"Value " : 2941.389892578125

},

"SAC " : {

"Unit" : "VA",

"Value " : 100970.953125

},

"TOTAL_ENERGY " : {

"Unit" : "Wh",

"Value " : 36742265.892499 99 8

},

"UAC " : {

"Unit" : "V",

"Value " : 236.7030029296875

},

"UDC " : {

"Unit" : "V",

"Value " : 636.800048828125

},

"UDC_2 " : {

"Unit" : "V",

"Value " : nu ll

},

"UDC_3 " : {

"Unit" : "V",

"Value " : nu ll

},

"UDC_4 " : {

"Unit" : "V",

"Value " : 409.69140625

},

"YEAR_ENERGY" : {

19

"Unit" : "Wh",

"Value " : nu ll

}

}
},

"Head" : {

"RequestA rg um en ts " : {

"DataCollection " : " CommonInverte rD at a",
"DeviceId " : "1" ,

"Scope " : "Devic e"

},

"Status" : {

"Code" : 0,

"Reason" : "",

"UserMessage" : ""

},

"Timestamp" : "2021 -10- 14 T13 :0 5: 55 +0 0: 00 "

}

}

4.1.8 Object structure of response body (Scope ”System”)

Listing 13: Object structure of response body for GetInverterRealtimeData request (Scope ”System”)

ob je ct {

# C ol lection of na me d o bject( s) containing values pe r device and m et ad ata.
# Members of Data object ar e n amed accordin g to the v al ue they r epresent (e .g. " PAC").

ob je ct {

# Value -Uni t pair.

ob je ct {

# Base un it of the v alue , n ever contai ns any pr ef ix es .

st ri ng Unit ;

# U nscaled values pe r d evice.
# P roperty name is th e D eviceId to wh ich the value belongs.

ob je ct {

<specific data type > 1; # va lue from d evice with i ndex 1.
<specific data type > 2; # va lue from d evice with i ndex 2.

# .. and so on .

}* Values ;

} _ _V AL UE _N AM E_ _;

}* Data ;

};

4.1.9 Example of response body (Scope ”System”)

Listing 14: Example of response body for GetInverterRealtimeData request (Scope ”System”)

{

"Body" : {

"Data" : {

"DAY_ENERGY " : {

"Unit" : "Wh",
"Values" : {

"1" : 1 393,
"2" : 1 618,
"3" : 1 695,

20

},

"Head" : {

}

}

"55" : 1698

}
},

"PAC " : {

"Unit" : "W",

"Values" : {

"1" : 84,
"2" : 1 09 ,
"3" : 1 09 ,
"55" : 108

}
},

"TOTAL_ENERGY " : {

"Unit" : "Wh",

"Values" : {

"1" : 1734796 ,
"2" : 3026782 ,
"3" : 3160499 ,
"55" : 3275219

}
},

"YEAR_ENERGY" : {

"Unit" : "Wh",

"Values" : {

"1" : 322593 ,
"2" : 385172 ,
"3" : 399904 ,
"55" : 403993

}
}

}

"RequestA rg um en ts " : {

"DeviceClass" : " In verter ",
"Scope " : "Syste m"

},

"Status" : {

"Code" : 0,
"Reason" : "",
"UserMessage" : ""

},

"Timestamp" : "2019 -06- 12 T15 :3 1: 04 +0 2: 00 "

Listing 15: Example of response body for GetInverterRealtimeData request (Scope ”System”) on GEN24/Tauro

{

"Body" : {

"Data" : {

"PAC " : {

"Unit" : "W",

"Value " : {

"1" : 27 1.0

}
}

}
},

"Head" : {

"RequestA rg um en ts " : {

"DeviceClass" : " In verter ",

"Scope " : "Syste m"

},

"Status" : {

"Code" : 0,

"Reason" : "",

21

"UserMessage" : ""

},

"Timestamp" : "2019 -08- 28 T05 :2 8: 12 +0 0: 00 "

}

}

4.2 GetSensorRealtimeData request

This request provides data for all channels of a single Fronius Sensor Card.
Inactive channels and channels with damaged sensors are not included in the response.

4.2.1 Availability

Platform Since version
Fronius Hybrid ALWAYS
Fronius Non Hybrid ALWAYS
Fronius GEN24/Tauro ALWAYS

+ This API is useless on Fronius Hybrid systems which are unable to get connected to sensor cards

anyway.

+ API is available but returns an error on GEN24/Tauro.

4.2.2 URL for HTTP requests

/solar_api/v1/GetSensorRealtimeData.cgi

4.2.3 Parameters

Parameter Type Range/Values/Pattern Description
Scope String ”Device”

”System”

Query specific device(s)

or whole system
DeviceId String Solar Net: 0 …9 Which card to query.
DataCollection String ”NowSensorData”

”MinMaxSensorData”

Selects the collection of data that should

be queried from the device.

See 4.2.4 for details.

4.2.4 Data Collections

NowSensorData The presently measured values of every active channel.

MinMaxSensorData The minimum and maximum values for every time period (day, month, year, total) of every

channel.
Some channels do not have a minimum value because it would always be zero. For these channels, the minimum
value is not included.

4.2.5 Object structure of response body (DataCollection ”NowSensorData”)

Listing 16: Object structure of response body for GetSensorRealtimeData request (DataCollection ”NowSensor
Data”)

ob je ct {

# C ol lection of na me d o bject( s) containing values pe r channel an d m etadata.
# Members of Data object ar e n amed accordin g to the c ha nn el index they represen t ( e. g.

"0 ") .

ob je ct {

# Value -Uni t pair.

ob je ct {

22

# Value for the c ha nn el .

nu mb er Value;

# Base un it of the v alue , n ever contai ns any pr ef ix es .

st ri ng Unit ;

} _ _C HA NN EL _I ND EX __;

}* Data ;

};

4.2.6 Example of response body (DataCollection ”NowSensorData”)

Listing 17: Example of response body for GetSensorRealtimeData request (DataCollection ”NowSensorData”)

{

"Body" : {

"Data" : {

"0" : {

"Unit" : "°C",

"Value " : -9

},

"1" : {

"Unit" : "°C",

"Value " : 24

},

"2" : {

"Unit" : "W/m2 ",

"Value " : 58 9

},

"4" : {

"Unit" : "KWh /m2 ",

"Value " : 0

}

}
},

"Head" : {

"RequestA rg um en ts " : {

"DataCollection " : " NowSensorData ",
"DeviceClass" : " Se ns or Ca rd ",
"DeviceId " : "1" ,

"Scope " : "Devic e"

},

"Status" : {

"Code" : 0,

"Reason" : "",

"UserMessage" : ""

},

"Timestamp" : "2018 -03- 01 T13 :2 5: 34 +0 1: 00 "

}

}

4.2.7 Object structure of response body (DataCollection ”MinMaxSensorData”)

Listing 18: Object structure of response body for GetSensorRealtimeData request (DataCollection ”MinMaxSen
sorData”)

ob je ct {

# C ol lection of na me d o bject( s) containing min/max va lu es per c ha nn el and m et ad at a.
# Members of Data object ar e n amed accordin g to the c ha nn el index they represen t ( e. g.

"0 ") .

23

ob je ct {

# Object representing one ch annel.

ob je ct {

# Whether th is channel is curren tl y ac tive .

bo ol ea n S en so rA ct iv e;

# Object representing min/max va lu es of cu rr ent day.

ob je ct {

# Maximum valu e with unit .

ob je ct {

nu mb er Value;
st ri ng Unit ;

} Max;

# Minimum valu e with unit .
# This obje ct is on ly present i n temperature channels (channel # 0 an d 1)
# as ot her c hannels do not have m inimum valu es .

ob je ct {

nu mb er Value;
st ri ng Unit ;

} Min;

} Day;

# Object representing min/max va lu es of cu rr ent month .

ob je ct {

ob je ct {

nu mb er Value;
st ri ng Unit ;

} Max;

ob je ct {

nu mb er Value;
st ri ng Unit ;

} Min;

} Month ;

# Object representing min/max va lu es of cu rr ent year.

ob je ct {

ob je ct {

} Max;

ob je ct {

} Min;

} Year;

# Object representing total min/ ma x v alues.

ob je ct {

ob je ct {

} Max;

ob je ct {

} Min;

} Total ;

} _ _C HA NN EL _I ND EX __;

}* Data ;

nu mb er Value;
st ri ng Unit ;

nu mb er Value;
st ri ng Unit ;

nu mb er Value;
st ri ng Unit ;

nu mb er Value;
st ri ng Unit ;

};

24

4.2.8 Example of response body (DataCollection ”MinMaxSensorData”)

Listing 19: Example of response body for GetSensorRealtimeData request (DataCollection ”MinMaxSensorData”)

{

"Body" : {

"Data" : {

"0" : {

"Day " : {

"Max " : {

"Unit" : "°C",

"Value " : 66

},

"Min " : {

"Unit" : "°C",

"Value " : 46

}

},

"Month " : {

"Max " : {

"Unit" : "°C",

"Value " : 85

},

"Min " : {

"Unit" : "°C",

"Value " : 0

}

},

"SensorActive " : true ,
"Total " : {

"Max " : {

"Unit" : "°C",

"Value " : 85

},

"Min " : {

"Unit" : "°C",

"Value " : -35

}

},

"Year" : {

"Max " : {

"Unit" : "°C",

"Value " : 85

},

"Min " : {

"Unit" : "°C",

"Value " : 0

}

}
},

"1" : {

"Day " : {

"Max " : {

"Unit" : "°C",

"Value " : 27

},

"Min " : {

"Unit" : "°C",

"Value " : 27

}

},

"Month " : {

"Max " : {

"Unit" : "°C",

"Value " : 77

},

"Min " : {

25

"Unit" : "°C",

"Value " : 27

}

},

"SensorActive " : true ,
"Total " : {

"Max " : {

"Unit" : "°C",

"Value " : 18 7

},

"Min " : {

"Unit" : "°C",

"Value " : -35

}

},

"Year" : {

"Max " : {

"Unit" : "°C",

"Value " : 77

},

"Min " : {

"Unit" : "°C",

"Value " : 27

}

}
},

"2" : {

"Day " : {

"Max " : {

"Unit" : "W/m2 ",
"Value " : 0

}
},

"Month " : {

"Max " : {

"Unit" : "W/m2 ",
"Value " : 15 9

}
},

"SensorActive " : true ,
"Total " : {

"Max " : {

"Unit" : "W/m2 ",
"Value " : 1003 6

}
},

"Year" : {

"Max " : {

"Unit" : "W/m2 ",
"Value " : 15 9

}
}

},

"3" : {

"Day " : {

"Max " : {

"Unit" : "Hz",
"Value " : 0

}
},

"Month " : {

"Max " : {

"Unit" : "Hz",
"Value " : 0

}
},

"SensorActive " : f alse ,

26

"Total " : {

"Max " : {

"Unit" : "Hz",
"Value " : 29 75

}
},

"Year" : {

"Max " : {

"Unit" : "Hz",
"Value " : 0

}
}

},

"4" : {

"Day " : {

"Max " : {

"Unit" : "Hz",
"Value " : 0

}
},

"Month " : {

"Max " : {

"Unit" : "Hz",
"Value " : 0

}
},

"SensorActive " : f alse ,
"Total " : {

"Max " : {

"Unit" : "Hz",
"Value " : 29 82

}
},

"Year" : {

"Max " : {

"Unit" : "Hz",
"Value " : 0

}
}

},

"5" : {

"Day " : {

"Max " : {

"Unit" : "A",
"Value " : 0

}
},

"Month " : {

"Max " : {

"Unit" : "A",
"Value " : 0

}
},

"SensorActive " : true ,
"Total " : {

"Max " : {

"Unit" : "A",
"Value " : 3693 4

}
},

"Year" : {

"Max " : {

"Unit" : "A",
"Value " : 0

}
}

}

27

}

},

"Head": {

"RequestA rg um en ts ": {

"DataCollection ": " MinMaxS en so rD at a",
"DeviceClass" : " Se ns or Ca rd ",
"DeviceId " : "1"

"Scope ": "Devic e"

},

"Status": {

"Code": 0 ,

"Reason": " ",

"UserMessage" : ""

},

"Timestamp" : "2018 -03- 01 T13 :2 5: 34 +0 1: 00 "

}

}

4.3 GetStringRealtimeData request

4.3.1 Availability

Platform Since version
Fronius Hybrid ALWAYS
Fronius Non Hybrid ALWAYS
Fronius GEN24/Tauro ALWAYS

+ This API is useless on Fronius Hybrid systems which are unable to get connected to string controls

anyway.

+ String Control does not exist for GEN24/Tauro

4.3.2 URL for HTTP requests

/solar_api/v1/GetStringRealtimeData.cgi

4.3.3 Parameters

Parameter Type Range/Values/Pattern Description
Scope String ”Device”

”System”
DeviceId String Solar Net: 0 …199 Which device to query.
DataCollection String ”NowStringControlData”

”LastErrorStringControlData”

”CurrentSumStringControlData”
TimePeriod String ”Day”

”Year”

”Total”

Query specific device
or whole system

Selects the collection of data that
should be queried from the device.
See 4.3.5 for details.

Only needed for Collection ”Cur
rentSumStringControlData”

For which time period the current
sums should be requested.

4.3.4 Collection availability

DataCollection supported on

Non Hybrid Hybrid GEN24/Tauro
NowStringControlData YES useless YES
LastErrorStringControlData YES useless NO
CurrentSumStringControlData YES useless NO

4.3.5 Data Collections

NowStringControlData The presently measured currents of every channels.

28

LastErrorStringControlData Information about the last error which triggered a service message.

CurrentSumStringControlData

Current sums of all channels for a selected time period (day, year or total).

4.3.6 Object structure of response body (DataCollection ”NowStringControlData” and ”CurrentSum
StringControlData”)

Listing 20: Object structure of response body for GetStringRealtimeData request (DataCollection ”NowStringCon
trolData” and ”CurrentSumStringControlData”)

ob je ct {

# C ol lection of na me d o bject( s) containing values pe r channel an d m etadata.
# Members of Data object ar e n amed accordin g to the c ha nn el index they represen t ( e. g.

"0 ") .

ob je ct {

# Value -Uni t pair.

ob je ct {

# Value for the c ha nn el .

nu mb er Value;

# Base un it of the v alue , n ever contai ns any pr ef ix es .

st ri ng Unit ;

} _ _C HA NN EL _I ND EX __;

}* Data ;

};

4.3.7 Example of response body (DataCollection ”CurrentSumStringControlData”)

Listing 21: Example of response body for GetStringRealtimeData request (DataCollection ”CurrentSumString
ControlData”)

{

"Body" : {

"Data" : {

"1" : {

"Unit" : "Ah",

"Value " : 0

},

"2" : {

"Unit" : "Ah",

"Value " : 0

},

"3" : {

"Unit" : "Ah",

"Value " : 0

},

"4" : {

"Unit" : "Ah",

"Value " : 0

},

"5" : {

"Unit" : "Ah",

"Value " : 0

}

}
},

"Head" : {

"RequestA rg um en ts " : {

29

"DataCollection " : " Current Su mS tr in gControlData",
"DeviceClass" : " St ri ng Co nt ro l",
"DeviceId " : "8" ,
"Scope " : "Devic e",

"TimePeriod " : " Day"

},

"Status" : {

"Code" : 0,

"Reason" : "",

"UserMessage" : ""

},

"Timestamp" : "2019 -06- 13 T15 :0 6: 54 +0 2: 00 "

}

}

Listing 22: Reply body for GetStringRealtimeData DataCollection=”NowStringControlData” on GEN24/Tauro

{

"Body" : {

"Data" : {}

},

"Head" : {

"RequestA rg um en ts " : {

"DataCollection " : " NowStringCo nt ro lD at a",

"DeviceClass" : " St ri ng Co nt ro l",

"Scope " : "Syste m"

},

"Status" : {

"Code" : 0,

"Reason" : "",

"UserMessage" : ""

},

"Timestamp" : "2019 -08- 28 T07 :2 0: 58 +0 0: 00 "

}

}

4.3.8 Object structure of response body (DataCollection ”LastErrorStringControlData”)

Listing 23: Object structure of response body for GetStringRealtimeData request (DataCollection ”LastErrorString
ControlData”)

ob je ct {

ob je ct {

# T imestamp when the error was d et ec te d.

st ri ng TimeOfError ;

# Average valu e of al l c hannels
# at the time the error was detected.

ob je ct {

nu mb er Value;

# Base un it of the v alue , n ever contai ns any pr ef ix es .

st ri ng Unit ;

} S tr in gA ve ra ge ;

# C ontains information about e ve ry channel
# at the time the error was detected.

ob je ct {

# Object representing one ch annel.

ob je ct {

30

}

# D eviation from string average.

ob je ct {

nu mb er Value;

# Base un it of the v alue , n ever contai ns any pr ef ix es .

st ri ng Unit ;

} D eviation ;

# Current su m

ob je ct {

nu mb er Value;

# Base un it of the v alue , n ever contai ns any pr ef ix es .

st ri ng Unit ;

} Sum;

} _ _C HA NN EL _I ND EX __;

}* Channels;

} Data;

4.3.9 Example of response body (DataCollection ”LastErrorStringControlData”)

Listing 24: Example of response body for GetStringRealtimeData request (DataCollection ”LastErrorStringCon
trolData”)

{

"Body" : {

"Data" : {

"Channels " : {

"1" : {

"Deviation" : {

"Unit" : "%",

"Value " : 5.7000000000000 00 2

},

"Sum " : {

"Unit" : "Ah",

"Value " : 0.84999999999 99 99 98

}

},

"2" : {

"Deviation" : {

"Unit" : "%",

"Value " : -12.6

},

"Sum " : {

"Unit" : "Ah",

"Value " : 0.69999999999 99 99 96

}

},

"3" : {

"Deviation" : {

"Unit" : "%",

"Value " : 7.0999999999999 99 6

},

"Sum " : {

"Unit" : "Ah",

"Value " : 0.85999999999 99 99 99

}

},

31

},

"Head" : {

}

}

"4" : {

"Deviation" : {

"Unit" : "%",

"Value " : 0

},

"Sum " : {

"Unit" : "Ah",

"Value " : 0

}

},

"5" : {

"Deviation" : {

"Unit" : "%",

"Value " : 0

},

"Sum " : {

"Unit" : "Ah",

"Value " : 0

}

}
},

"StringAverage" : {

"Unit" : "Ah",

"Value " : 0.81000000000 00 00 05

},

"TimeOfError" : " 2010 -10-23 T09 :3 2: 00 +0 2: 00 "

}

"RequestA rg um en ts " : {

"DataCollection " : " LastErr or St ri ng Co ntrolData ",
"DeviceClass" : " St ri ng Co nt ro l",
"DeviceId " : "8" ,
"Scope " : "Devic e"

},

"Status" : {

"Code" : 0,
"Reason" : "",
"UserMessage" : ""

},

"Timestamp" : "2019 -06- 13 T15 :0 6: 56 +0 2: 00 "

4.3.10 Object structure of response body (DataCollection ”NowStringControlData”)

Listing 25: Object structure of response body for GetStringRealtimeData request (DataCollection ”NowStringCon
trolData”)

ob je ct {

ob je ct {

# Object representing one ch annel.

ob je ct {

nu mb er Value;

# Base un it of the v alue , n ever contai ns any pr ef ix es .

st ri ng Unit ;

} _ _C HA NN EL _I ND EX __;

} Data;

}

4.3.11 Example of response body (DataCollection ”NowStringControlData”)

32

Listing 26: Example of response body for GetStringRealtimeData request (DataCollection ”NowStringControl
Data”)

{

"Body" : {

"Data" : {

"1" : {

"Unit" : "A",

"Value " : 0

},

"2" : {

"Unit" : "A",

"Value " : 0

},

"3" : {

"Unit" : "A",

"Value " : 0

},

"4" : {

"Unit" : "A",

"Value " : 0

},

"5" : {

"Unit" : "A",

"Value " : 0

}

}
},

"Head" : {

"RequestA rg um en ts " : {

"DataCollection " : " NowStringCo nt ro lD at a",
"DeviceClass" : " St ri ng Co nt ro l",
"DeviceId " : "8" ,

"Scope " : "Devic e"

},

"Status" : {

"Code" : 0,

"Reason" : "",

"UserMessage" : ""

},

"Timestamp" : "2019 -06- 13 T15 :0 6: 57 +0 2: 00 "

}

}

4.4 GetLoggerInfo request

This request provides information about the logging device which provides this API.

4.4.1 Availability

Platform Since version
Fronius Hybrid ALWAYS
Fronius Non Hybrid ALWAYS
Fronius GEN24/Tauro ALWAYS

+ API is available but returns an error on GEN24/Tauro.

4.4.2 URL for HTTP requests

/solar_api/v1/GetLoggerInfo.cgi

4.4.3 Object structure of response body

33

Listing 27: Object structure of response body for GetLoggerInfo request

ob je ct {

ob je ct {

# Unique ID of the lo gging device.

st ri ng UniqueID;

# String identifying th e exact pr od uc t t ype.
# e xamples: "fro nius - hy br id " or "fro nius - da tamanager-c ard"

st ri ng ProductID ;

# String identifying th e exact hard wa re p latform.

st ri ng PlatformID;

# H ardware version of th e logging devi ce .

st ri ng HWVersion ;

# S oftware version of th e logging devi ce . ( Ma jo r.Minor.R evision -Build )

st ri ng SWVersion ;

# Name of city / co untry which the user
# s elected as time zo ne .

st ri ng TimezoneL oc at io n/[a-zA -Z ]+|/ ;

# Name of the s el ec ted time zone .
# May b e empty i f information not a va il ab le .

st ri ng TimezoneName/[a -zA-Z ]+ |/;

# UTC of fset in seconds east of UTC,
# i ncluding adjustments fo r d aylight saving.

in te ge r U TC Of fset ;

# Default langua ge set on the logging devi ce
# as a two l etter a bb re viation (e. g. " en ").
# NOTE: Th is attribute wi ll be REMOVED soon

st ri ng DefaultLang ua ge ;

# Grid supp ly tariff
# This fiel d is mandatory only fo r all Fr on ius Hybrid inverter
# and Fr on ius Non Hy brid sinc e 3 .3.3 -1

nu mb er DeliveryFactor;

# The cash fact or set on the l og gi ng device ,
# NOT t he factor set on the inverters .

nu mb er CashFactor;

# C urrency of cash fact or set o n the l og gi ng devi ce ,
# NOT t he currency se t on the inverters .

st ri ng CashCurrency;

# The C O2 factor set on the logging device ,
# NOT t he factor set on the inverters .

nu mb er CO2Factor ;

# Unit of CO2 f actor set on the l og gi ng device ,
# NOT t he unit set on the i nv er te rs .

st ri ng CO2Unit;

} L og gerInfo;

};

+ Item ”DefaultLanguage” will be removed soon

34

4.4.4 Example of response body

Listing 28: Example of response body for GetLoggerInfo request

{

"Body" : {

"LoggerInfo " : {

"CO2Factor" : 0.52999997138977051 ,

"CO2Unit" : "kg",

"CashCurrency " : " EUR" ,

"CashFactor " : 0 .1 19 99 99 97 31 77 9099 ,

"DefaultLan gu ag e" : "en",

"DeliveryFactor " : 0 .25,

"HWVersion" : "2.4D",

"PlatformID " : " wi lma" ,

"ProductID" : "froni us - data ma nager -car d",

"SWVersion" : "3.14. 1-2 ",

"Timezone Lo ca ti on " : " Paris",

"TimezoneName " : " CE ST ",

"UTCOffset" : 7200 ,

"UniqueID " : " 24 0. 10 76 20 "

}

},

"Head" : {

"RequestA rg um en ts " : {} ,
"Status" : {

"Code" : 0,

"Reason" : "",

"UserMessage" : ""

},

"Timestamp" : "2019 -06- 12 T15 :3 1: 06 +0 2: 00 "

}

}

4.5 GetLoggerLEDInfo request

This request provides information about the LED states and colors on the device which provides this API.

4.5.1 Availability

Platform Since version
Fronius Hybrid ALWAYS
Fronius Non Hybrid

ALWAYS

Fronius GEN24/Tauro ALWAYS

+ API is available but returns an error on GEN24/Tauro.

4.5.2 URL for HTTP requests

/solar_api/v1/GetLoggerLEDInfo.cgi

4.5.3 Object structure of response body

Listing 29: Object structure of response body for GetLoggerLEDInfo request

ob je ct {

ob je ct {

# State of on e LED.

ob je ct {

# Color (" re d", " gr een" or "none ") .

st ri ng Color;

35

# State (" on ", "off", "blinking" or "alternating").

st ri ng State;

} _ _L ED _N AM E_ _ ;

}* Data ;

};

4.5.4 Example of response body

Listing 30: Example of response body for GetLoggerLEDInfo request

{

"Body" : {

"Data" : {

"PowerLED " : {

"Color " : "green ",

"State " : "on"

},

"SolarNetLED" : {

"Color " : "green ",

"State " : "on"

},

"SolarWebLED" : {

"Color " : "green ",

"State " : "on"

},

"WLANLED" : {

"Color " : "red ",

"State " : "on"

}

}
},

"Head" : {

"RequestA rg um en ts " : {} ,

"Status" : {

"Code" : 0,
"Reason" : "",

"UserMessage" : ""

},

"Timestamp" : "2019 -06- 12 T15 :3 1: 07 +0 2: 00 "

}

}

4.6 GetInverterInfo request

This request provides information about all inverters that are currently being monitored by the logging device. So
this means that inverters which are currently not online are also reported by this request, provided these inverters
have been seen by the logging device within the last 24 hours.

If information about devices currently online is needed, the GetActiveDeviceInfo request should be used. This
request also provides information about device classes other than inverters.

4.6.1 Availability

Platform Since version
Fronius Hybrid ALWAYS
Fronius Non Hybrid ALWAYS
Fronius GEN24/Tauro ALWAYS

36

4.6.2 URL for HTTP requests

/solar_api/v1/GetInverterInfo.cgi

4.6.3 Object structure of response body

Listing 31: Object structure of response body for GetInverterInfo request

ob je ct {

# C ol lection of obje ct s w ith infos about one i nverter ,
# mapped by inverter index.

ob je ct {

# Info abou t a si ngle inverter.
# Name of object is th e i nverter index.

ob je ct {

# Device type of the inverter.
# GEN24 /Tau ro inverter will always report d evice type 1.

in te ge r DT;

# PV po wer c on nected to this inve rt er (in wa tts) .
# If no ne defined, defaul t p ow er for t his DT is used .
# Will provid e dc power values sinc e G EN24 /Tauro v ersion 1.13.5 .

in te ge r P VPower ;

# Custom name of the invert er , assigned by th e c ustomer.
# P rovided since 1.18.1 -0 on Symo Hybr id
# Will contai n h tml encoded stri ng s on Datamanager an d Symo Hybr id
# Will contai n p la in utf-8 t ext on GE N24/ Tauro

st ri ng CustomName;

# Whether th e device shall be displayed in visualizations according
# to cust om er s ettings. (0 do not s how; 1 show)
# v is ua li za ti on s ettings.

un si gn ed integer Sh ow ;

# Unique ID of the in ve rt er (e.g. se rial numb er ).

st ri ng UniqueID;

# Error co de that is cu rr en tl y p re se nt on inverter.
# A v al ue of -1 me ans that t here is no valid e rr or code .

in te ge r E rr or Code ;

# Status code r ef lecting the op er at io na l s ta te of the i nv er te r.
# S upported sinc e 1 .1 3.5 on GE N2 4/Tauro, olde r v er si on s r eport a n um eric string here.

in te ge r S ta tu sC od e;

# Status string r ef le ct in g the operationa l st ate of the inverter.
# Only provided for GE N24/Tauro si nce version 1. 13 .5

st ri ng InverterState ;

} _ _I NV ER TE R_ IN DEX__ ;

}* Data ;

};

4.6.4 Example of response body

Listing 32: Example of response body for GetInverterInfo request

{

"Body" : {

"Data" : {

37

},

"Head" : {

}

}

"1" : {

"CustomName " : "

&# 80;r &# 10 5; m 11 ;& #3 2;8. ;& #5 0;-1 ;& #3 2;( ",
"DT" : 102,
"ErrorCode" : 0,
"PVPower" : 500,
"Show" : 1,
"StatusCode " : 7,
"UniqueID " : " 38183"

},

"2" : {

"CustomName " : "

&# 80;r &# 10 5; m 11 ;& #3 2;5&# 46 ;& #4 8;-&# 49 ;& #3 2;20 ;"

,

"DT" : 86 ,
"ErrorCode" : 0,
"PVPower" : 500,
"Show" : 1,
"StatusCode " : 7,
"UniqueID " : " 16 77 7215 "

},

"3" : {

"CustomName " : "

&# 71;a& #1 08 ;& #118; 1; &# 32 ;3 6; &# 49 ;-1 &# 32 ;20 ",
"DT" : 106,
"ErrorCode" : 0,
"PVPower" : 500,
"Show" : 1,
"StatusCode " : 7,
"UniqueID " : " 7262 "

},

"55" : {

"CustomName " : "

&# 71;a& #1 08 ;& #118; 1; &# 32 ;3 6; &# 48 ;-1 &# 32 ;(5 ",
"DT" : 224,
"ErrorCode" : 0,
"PVPower" : 500,
"Show" : 1,
"StatusCode " : 7,
"UniqueID " : " 10 0372 "

}

}

"RequestA rg um en ts " : {} ,
"Status" : {

"Code" : 0,
"Reason" : "",

"UserMessage" : ""

},

"Timestamp" : "2019 -06- 12 T15 :3 1: 02 +0 2: 00 "

{

"Body" : {

Listing 33: Example of response body for GetInverterInfo on GEN24/Tauro

"Data" : {

"1" : {

"CustomName " : "tr -3 pn -01",
"DT" : 1,
"PVPower" : 0,
"Show" : 1,
"StatusCode " : " Ru nn ing",
"UniqueID " : " 29 30 10 00 987160033 "

}

38

}

},

"Head" : {

"RequestA rg um en ts " : {} ,
"Status" : {

"Code" : 0,

"Reason" : "",

"UserMessage" : ""

},

"Timestamp" : "2019 -08- 28 T07 :4 7: 43 +0 0: 00 "

}

}

4.6.5 Meaning of numerical status codes

The StatusCode Field is only reported as numerical value. The meaning of the numbers is shown in the table
below.

Value Description provided by

Datamanager and Hybridmanager GEN24/Tauro
0  6 Startup YES Yes
7 Running YES Yes
8 Standby YES Yes
9 Bootloading YES No
10 Error YES Yes
11 Idle No Yes
12 Ready No Yes
13 Sleeping No Yes
255 Unknown No Yes

INVALID No Yes

4.7 GetActiveDeviceInfo request

This request provides information about which devices are currently online.

4.7.1 Availability

Platform Since version
Fronius Hybrid ALWAYS
Fronius Non Hybrid ALWAYS
Fronius GEN24/Tauro ALWAYS

4.7.2 URL for HTTP requests

/solar_api/v1/GetActiveDeviceInfo.cgi

4.7.3 Parameters

Parameter Type Range/Values/Pattern Description
DeviceClass String ”Inverter”

”Storage”
”Ohmpilot”
”SensorCard”
”StringControl”
”Meter”

2

3

4

4

Which kind of device class to search for
active devices.

2 3 4

”System”

2

Supported since version 3.3.45

3

Supported since version 3.6.13

4

Not listed and provided on GEN24/Tauro

2

Uses different response format

39

4.7.4 DeviceClass is not System

Listing 34: Object structure of response body for GetActiveDeviceInfo request

ob je ct {

# C ol lection of obje ct s w ith infos about one i nverter ,
# mapped by inverter index.

ob je ct {

# Info abou t a si ngle device .
# Name of object is th e device index.

ob je ct {

# M andatory Device type of the d ev ice.
# (onl y for Inverte r , S en so rC ar d or StringControl ; others have - 1)

in te ge r DT;

# O ptional attribute : s er ia lnumber
# usually supporte d b y new I nv erters , O hm Pilots , Ba tt er ie s and Sm art Meters

st ri ng Se ri al ;

# Channel list in g f or Sens or Cards

ar ray {

st ri ng ;

} C ha nn el Na me s;

} _ _D EV IC E_ IN DE X_ _;

}* Data ;

};

{

"Body" : {

"Data" : {

"1" : {

"DT" : 102,

},

"2" : {

"DT" : 86

},

"3" : {

"DT" : 106

},

"55" : {

"DT" : 224

}

}
},

"Head" : {

"RequestA rg um en ts " : {

"DeviceClass" : " In verter "

},

"Status" : {

"Code" : 0,

"Reason" : "",

"UserMessage" : ""

},

"Timestamp" : "2019 -06- 12 T15 :3 0: 57 +0 2: 00 "

}

}

Listing 35: Example of response body for GetActiveDeviceInfo Inverter request

"Serial": " 27135399"

40

Listing 36: Example of response body for GetActiveDeviceInfo SensorCard request

{

"Body" : {

"Data" : {

"1" : {

"ChannelNames " : [

"Temperature 1",
"Temperature 2",
"Irradiation" ,
"Digital 1" ,
"Digital 2" ,
"Current"

],

"DT" : 254

},

"2" : {

"ChannelNames " : [

"Temperature 1",
"Temperature 2",
"Irradiation" ,
"Digital 1" ,
"Digital 2" ,
"Current"

],

"DT" : 254

}

}

},

"Head" : {

"RequestA rg um en ts " : {

"DeviceClass" : " Se ns or Ca rd "

},

"Status" : {

"Code" : 0,

"Reason" : "",

"UserMessage" : ""

},

"Timestamp" : "2018 -03- 01 T14 :4 1: 12 +0 1: 00 "

}

}

Listing 37: Example of response body for GetActiveDeviceInfo deviceclass=Inverter on GEN24/Tauro

{

"Body" : {

"Data" : {

"1" : {

"DT" : 1,
"Serial" : " 29 09 10 00 97 50 90 00 7"

}

}

},

"Head" : {

"RequestA rg um en ts " : {

"DeviceClass" : " In verter "

},

"Status" : {

"Code" : 0,

"Reason" : "",

"UserMessage" : ""

},

"Timestamp" : "2019 -08- 28 T09 :0 2: 48 +0 0: 00 "

}

}

41

+ The item ’DT’ is not valid for Inverters on GEN24/Tauro

4.7.5 DeviceClass is System

Listing 38: Object structure of response body for GetActiveDeviceInfo request

ob je ct {

# C ol lection of obje ct s w ith infos about one i nverter ,
# mapped by inverter index.

ob je ct {

#name of DeviceClass

ob je ct {

# Info abou t a si ngle device .
# Name of object is th e device index.

ob je ct {

# Device type only fo r Invert er , SensorCard or Strin gC on tr ol . o th ers have -1

in te ge r DT;

# O ptional attribute : s er ia lnumber

st ri ng Se ri al ;

# This obje ct only exis ts for Se ns or Ca rd device clas s

ar ray { s tr in g } Ch an ne lN am es ;

} _ _D EV IC E_ IN DE X_ _;

} _ _D EV IC E_ CL AS S_ _;

}* Data ;

};

Listing 39: Example of response body for GetActiveDeviceInfo request on non hybrid inverter systems

{

"Body" : {

"Data" : {

"Inverter " : {

"1" : {

"DT" : 102,

"Serial" : " 27135399 "

},

"2" : {

"DT" : 86

},

"3" : {

"DT" : 10 6

},

"55" : {

"DT" : 22 4

}

},

"Meter " : {

"0" : {

"DT" : -1 ,

"Serial" : " 16420055 "

},

"2" : {

"DT" : -1 ,

"Serial" : "475619 "

},

"3" : {

42

},

"Head" : {

}

}

"DT" : -1 ,

"Serial" : " 17362721 "

}

},

"Ohmpilot " : {

"0" : {

"DT" : -1 ,

"Serial" : " 12345678 "

}

},

"SensorCard " : {

"1" : {

"ChannelNames " : [

"Temperature 1",
"Temperature 2",
"Irradiation" ,
"Digital 1" ,
"Digital 2" ,

"Current"

],

"DT" : 25 4

}
},

"Storage" : {} ,
"StringControl" : {

"3" : {

"DT" : 25 3

}

}

}

"RequestA rg um en ts " : {

"DeviceClass" : " System "

},

"Status" : {

"Code" : 0,

"Reason" : "",

"UserMessage" : ""

},

"Timestamp" : "2019 -06- 12 T15 :3 0: 59 +0 2: 00 "

{

"Body" : {

Listing 40: Example of response body for GetActiveDeviceInfo request on hybrid inverter systems

"Data" : {

"Inverter " : {

"1" : {

"DT" : 99

}
},

"Meter " : {

"0" : {

"DT" : -1,
"Serial" : " 16250161 "

}
},

"Ohmpilot " : {},
"SensorCard " : {},
"Storage" : {

"0" : {

"DT" : -1,
"Serial" : " 26175063 "

}

43

},

"StringControl" : {}

}
},

"Head" : {

"RequestA rg um en ts " : {

"DeviceClass" : " System "

},

"Status" : {

"Code" : 0,

"Reason" : "",

"UserMessage" : ""

},

"Timestamp" : "2019 -06- 12 T15 :3 0: 59 +0 2: 00 "

}

}

Listing 41: Example of response body for GetActiveDeviceInfo deviceclass=Inverter on GEN24/Tauro

{

"Body" : {

"Data" : {

"1" : {

"DT" : 1,

"Serial" : " 29 09 10 00 97 50 90 00 7"

},

"Meter " : {

"0" : {

"DT" : -1,
"Serial" : " 18142251 "

}
},

"Ohmpilot " : {

"0" : {

"DT" : -1,
"Serial" : " 28136344 "

}
},

"Storage" : {}

}
},

"Head" : {

"RequestA rg um en ts " : {

"DeviceClass" : " System "

},

"Status" : {

"Code" : 0,

"Reason" : "",

"UserMessage" : ""

},

"Timestamp" : "2019 -08- 28 T08 :5 9: 41 +0 0: 00 "

}

}

+ The item ’DT’ is not valid for Inverters on GEN24/Tauro

4.8 GetMeterRealtimeData request

This request provides detailed information about Meter devices. Inactive channels are not included in the re
sponse and may vary depending on used metering device and software version. Take care about permanently or
temporary missing channels when processing this response.

44

4.8.1 Availability

Platform Since version
Fronius Hybrid ALWAYS
Fronius Non Hybrid 3.3.48
Fronius GEN24/Tauro planned in 1.13

4.8.2 URL for HTTP requests

/solar_api/v1/GetMeterRealtimeData.cgi

4.8.3 Parameters

Parameter Type Range/Values/Pattern Description
Scope String ”System”

Mandatory

”Device”

DeviceId String 0..65535 Mandatory on non system scope

4.8.4 Devicetypes and provided channels

45

Group Fronius Smart Meter Fronius Smart Meter UL Generic

Model

63A3

63A1

50kA3

TS 100A1

TS 65A3

TS 5kA3

WNC3D240MB

WNC3D480MB

WND3D240MB

WND3Y600MB

WND3D480MB

Compatibility

sw=1

sw=1

sw=1

sw=26

sw=26

hw=0 and sw=2.7

hw=0 and sw=1.9

hw=16 and sw is 21 or 22

hw=17 and sw is 29 or 30

hw=1 and (sw=2.9 or sw=3.0)

hw=1 and sw is 3.00, 3.01, 3.03 or 3.04)

Channel provided (m…mandatory, …never, o…optional)
Details / Manufacturer m m m m m m m m m m m o
Details / Model m m m m m m m m m m m o
Details / Serial m m m m m m m m m m m o

Current_AC_Phase_1 m m m m m m m m m m m o
Current_AC_Phase_2 m  m  m m o o o o o o
Current_AC_Phase_3 m  m  m m o o o o o o
Current_AC_Sum  m  m m m m m m m m o
Enable m m m m m m m m m m m m
EnergyReactive_VArAC_Phase_1_Consumed  m          
EnergyReactive_VArAC_Phase_1_Produced  m          
EnergyReactive_VArAC_Sum_Consumed m m m m m m      
EnergyReactive_VArAC_Sum_Produced m m m m m m      
EnergyReal_WAC_Minus_Absolute m m m m m m m m m m m m
EnergyReal_WAC_Phase_1_Consumed  m     m m m m m o
EnergyReal_WAC_Phase_1_Produced  m     m m m m m o
EnergyReal_WAC_Phase_2_Consumed       o o o o o o
EnergyReal_WAC_Phase_2_Produced       o o o o o o
EnergyReal_WAC_Phase_3_Consumed       o o o o o o
EnergyReal_WAC_Phase_3_Produced       o o o o o o
EnergyReal_WAC_Plus_Absolute m m m m m m m m m m m m
EnergyReal_WAC_Sum_Consumed m m m m m m m m m m m m
EnergyReal_WAC_Sum_Produced m m m m m m m m m m m m
Frequency_Phase_Average m m m m m m m m m m m m
Meter_Location_Current m m m m m m m m m m m m
PowerApparent_S_Phase_1 m m m m m m m m m m m o
PowerApparent_S_Phase_2 m  m  m m o o o o o o
PowerApparent_S_Phase_3 m  m  m m o o o o o o
PowerApparent_S_Sum m m m m m m m m m m m m
PowerFactor_Phase_1 m m m m m m m m m m m o
PowerFactor_Phase_2 m  m  m m o o o o o o
PowerFactor_Phase_3 m  m  m m o o o o o o
PowerFactor_Sum m m m m m m m m m m m m
PowerReactive_Q_Phase_1 m m m m m m m m m m m o
PowerReactive_Q_Phase_2 m  m  m m o o o o o o
PowerReactive_Q_Phase_3 m  m  m m o o o o o o
PowerReactive_Q_Sum m m m m m m m m m m m m

SunsSpec Meter

model=307 or model=70307

46

Group Fronius Smart Meter Fronius Smart Meter UL Generic

Model

63A3

63A1

50kA3

TS 100A1

TS 65A3

TS 5kA3

WNC3D240MB

WNC3D480MB

WND3D240MB

WND3Y600MB

WND3D480MB

Article Number

43,0001,1473

43,0001,1477

43,0001,1478

43,0001,0045

43,0001,0044

43,0001,0046

43,0001,3529

43,0001,3530

43,0001,3552

PowerReal_P_Phase_1 m m m m m m m m m m m o
PowerReal_P_Phase_2 m  m  m m o o o o o o
PowerReal_P_Phase_3 m  m  m m o o o o o o
PowerReal_P_Sum m m m m m m m m m m m m
TimeStamp m m m m m m m m m m m m
Visible m m m m m m m m m m m m
Voltage_AC_PhaseToPhase_12 m  m  m m o o o o o o
Voltage_AC_PhaseToPhase_23 m  m  m m o o o o o o
Voltage_AC_PhaseToPhase_31 m  m  m m o o o o o o
Voltage_AC_Phase_1 m m m m m m m m m m m o
Voltage_AC_Phase_2 m  m  m m o o o o o o
Voltage_AC_Phase_3 m  m  m m o o o o o o
Voltage_AC_Phase_Average       m m m m m o

Some values are optional since meter is able to operate on one or three phases.

SunsSpec Meter

device dependend

4.8.5 Channel Descriptions

Name Description
Enable 1...enabled, 0...disabled
Visible 1...use values, 0...incomplete or outdated values
Current_AC_Phase_* absolute values for 63A3,63A1 and 50KA3

only UL and TS meter provide directions
feedin negative(); consumption positive(+)

Meter_Location_Current 0...grid interconnection point (primary meter)

1...load (primary meter)

3...external generator (secondary meters)(multiple)
256511 subloads (secondary meters)(unique)

EnergyReactive_VArAC_Phase_*_Consumed/Produced

meter specific view
EnergyReactive_VArAC_Sum_Consumed/Produced
EnergyReal_WAC_Plus/Minus_Absolute system specific view
EnergyReal_WAC_Phase_*_Consumed/Produced

meter specific view
EnergyReal_WAC_Sum_Consumed/Produced

The values EnergyReal_WAC_Sum_Produced and EnergyReal_WAC_Sum_Consumed represent the values
for the Smart Meter itself. The values EnergyReal_WAC_Minus_Absolute and EnergyReal_WAC_Plus_Absolute
represent the values for Solar.web. Now it depends where the Smart Meter is installed (FeedInPoint or Consumption
Path), so that either EnergyReal_WAC_Minus_Absolute is the same as EnergyReal_WAC_Sum_Produced or
EnergyReal_WAC_Sum_Consumed.

47

4.8.6 Meter Location Dependend Directions (primary meter)

Meter_Location_Current 0

feed in

1

consumption path
PowerReal_P_Sum (+ positive) consuming from grid producing power
PowerReal_P_Sum ( negative) feeding in to grid normal consumption
EnergyReal_WAC_Plus_Absolute
(absolute counter)
EnergyReal_WAC_Minus_Absolute
(absolute counter)

import from grid
EnergyReal_WAC_Phase_*_Consumed
export to grid
EnergyReal_WAC_Phase_*_Produced

producing power *

EnergyReal_WAC_Phase_*_Produced

consumption

EnergyReal_WAC_Phase_*_Consumed

* May occur when other power generation is located in load path and producing more power than load can con
sume.

4.8.7 Meter Location Dependend Directions (secondary meter)

Meter_Location_Current 3

ext. generator

256511

subloads
PowerReal_P_Sum (+ positive) generation load is producing power
PowerReal_P_Sum ( negative) consumption normal consumption
EnergyReal_WAC_Plus_Absolute
(absolute counter)
EnergyReal_WAC_Minus_Absolute
(absolute counter)

generation
EnergyReal_WAC_Phase_*_Produced
consumption
EnergyReal_WAC_Phase_*_Consumed

producing power *

EnergyReal_WAC_Phase_*_Produced

consumption

EnergyReal_WAC_Phase_*_Consumed

* May occur when other power generation is located in load path and producing more power than load can con
sume.

4.8.8 SystemRequest

Listing 42: Object structure of response body for GetMeterRealtimeData request

# C ol lection of obje ct s w ith infos about multiple Me ters ,
# mapped by serial numb er .

ob je ct {

#list of single d evice objects

ob je ct {

#optional de ta il ed i nf or ma tion about de vice
#supported since:
# Fro ni us Symo H ybrid : w ith version grea te r t han or equal t o 1.1.2 -14
# Non Fronius Sy mo Hybrid : with vers io n g re at er than or eq ua l to 3. 3.6-14

ob je ct {

st ri ng Serial ;

st ri ng Model;

st ri ng Manufacturer;

} Details ;

#channels of devi ce ( textual name and va lue)

nu mb er * _ _C HA NN EL _N AM E__;

} * D ev ic eI d;

} Data ;

{

"Body" : {

"Data" : {

"0" : {

Listing 43: Example of response body for GetMeterRealtimeData System request

"Curren t_ AC _P ha se _1 " : 0.74199999999999 99 9 ,
"Curren t_ AC _P ha se _2 " : 0.63200000000000 00 1 ,

48

"Curren t_ AC _P ha se _3 " : 0.65400000000000 00 3 ,
"Details" : {

"Manufacturer " : " Fron iu s",
"Model " : "Smart Meter 63 A",

"Serial" : " 15160189 "

},

"Enable" : 1,
"En er gy Re ac tive_VArAC_Su m_ Co ns um ed" : 9156 420,
"En er gy Re ac tive_VArAC_Su m_ Pr od uc ed" : 878944 50 ,
"En er gy Re al _W AC_Minus_Abso lu te " : 16 42802,
"Ener gy Re al _W AC_Plus_Absolut e" : 1983 86 97 ,
"Ener gy Re al _W AC_Sum_Consumed " : 19 838697 ,
"Ener gy Re al _W AC_Sum_Produced " : 1642802,
"Freq ue nc y_ Ph as e_Average " : 50,
"Mete r_ Lo ca ti on _C urrent" : 0,
"Powe rA pp ar en t_ S_Phase_1 " : 1 72 .3 66 60 00 00 00001,
"Powe rA pp ar en t_ S_Phase_2 " : 1 47 .0 03 19 99 99 99999,
"Powe rA pp ar en t_ S_Phase_3 " : 1 52 .5 78 20 00 00 00001,
"Powe rA pp ar en t_ S_ Su m" : 31 ,
"Powe rF ac to r_ Ph as e_ 1" : 0,
"Powe rF ac to r_ Ph as e_ 2" : 0.97999999999999998 ,
"Powe rF ac to r_ Ph as e_ 3" : 1,
"PowerFacto r_ Su m" : 0.81999999999999995 ,
"Powe rR ea ct iv e_ Q_Phase_1 " : 1 2. 55 00 00 00 00 00001,
"Powe rR ea ct iv e_ Q_Phase_2 " : 5 .8 09 99 99 99 99 99996,
"Powe rR ea ct iv e_ Q_Phase_3 " : 0,
"Powe rR ea ct iv e_ Q_ Su m" : 18.359999999999999,
"Powe rR ea l_ P_ Ph as e_ 1" : 0,
"Powe rR ea l_ P_ Ph as e_ 2" : -40.56 00 00 000000002,
"Powe rR ea l_ P_ Ph as e_ 3" : 15.029999999999999,
"PowerReal_ P_ Su m" : -25.53000 00 00 000001 ,
"TimeStamp" : 15613649 09 ,
"Visible" : 1,
"Volt ag e_ AC _P haseToPhase_12" : 402.6000000000 00 02 ,
"Volt ag e_ AC _P haseToPhase_23" : 40 3.5,
"Volt ag e_ AC _P haseToPhase_31" : 403.1999999999 99 99 ,
"Voltag e_ AC _P ha se _1 " : 232.30000000 00 00 01 ,
"Voltag e_ AC _P ha se _2 " : 232.59999999 99 99 99 ,
"Voltag e_ AC _P ha se _3 " : 233.300000000 00 00 1

},

"1" : {

"Curren t_ AC _P ha se _1 " : -0.5831 04 49 12 3382568,
"Curren t_ AC _P ha se _2 " : -0.6785 48 27 64 2440796,
"Curren t_ AC _P ha se _3 " : -0.7008 51 67 88482666 ,
"Current_AC_Sum " : - 1. 9625044465065 00 2 ,
"Details" : {

"Manufacturer " : " Fron iu s",

"Model " : "CCS WattNode W NC -3D -480-M B" ,

"Serial" : "186477 "

},

"Enable" : 1,
"En er gy Re al _W AC_Minus_Abso lu te " : 73 36854,
"En er gy Re al _WAC_Phase_1_Co ns um ed " : 1320 806,
"En er gy Re al _WAC_Phase_1_Pr od uc ed " : 1933 071,
"En er gy Re al _WAC_Phase_2_Co ns um ed " : 15 8238 ,
"En er gy Re al _WAC_Phase_2_Pr od uc ed " : 3043 466,
"En er gy Re al _WAC_Phase_3_Co ns um ed " : 17 9872 ,
"En er gy Re al _WAC_Phase_3_Pr od uc ed " : 2912 264,
"Ener gy Re al _W AC_Plus_Absolut e" : 1106 969,
"Ener gy Re al _W AC_Sum_Consumed " : 1106969,
"Ener gy Re al _W AC_Sum_Produced " : 7336854,
"Freq ue nc y_ Ph as e_Average " : 5 0. 11 68 44 17 72 46094,
"Mete r_ Lo ca ti on _C urrent" : 256,
"Powe rA pp ar en t_ S_Phase_1 " : 1 35 .0 41 27 50 24 41406,
"Powe rA pp ar en t_ S_Phase_2 " : 1 60 .4 32 67 82 22 65625,
"Powe rA pp ar en t_ S_Phase_3 " : 1 63 .0 42 28 21 04 49219,
"Powe rA pp ar en t_ S_ Su m" : 458.5162353515625 ,

49

"Powe rF ac to r_ Ph as e_ 1" : 1,
"Powe rF ac to r_ Ph as e_ 2" : 1,
"Powe rF ac to r_ Ph as e_ 3" : 1,
"PowerFacto r_ Su m" : 1,
"Powe rR ea ct iv e_ Q_Phase_1 " : 0,
"Powe rR ea ct iv e_ Q_Phase_2 " : 0,
"Powe rR ea ct iv e_ Q_Phase_3 " : 0,
"Powe rR ea ct iv e_ Q_ Su m" : 0,
"Powe rR ea l_ P_ Ph as e_ 1" : -135.0 41 27 502441406,
"Powe rR ea l_ P_ Ph as e_ 2" : -160.4 32 67 822265625,
"Powe rR ea l_ P_ Ph as e_ 3" : -163.0 42 28 210449219,
"PowerReal_ P_ Su m" : -458.5162 35 35 15625,
"TimeStamp" : 15613649 87 ,
"Visible" : 1,
"Volt ag e_ AC _P haseToPhase_12" : 405.3290710449 21 88 ,
"Volt ag e_ AC _P haseToPhase_23" : 406.2306823730 46 88 ,
"Volt ag e_ AC _P haseToPhase_31" : 402.0307006835 93 75 ,
"Voltag e_ AC _P ha se _1 " : 231.59017944 33 59 38 ,
"Voltag e_ AC _P ha se _2 " : 236.43516540 52 73 44 ,
"Voltag e_ AC _P ha se _3 " : 232.63450622 55 85 94 ,
"Volt ag e_ AC _P ha se_Average" : 2 33 .5 53 28 369140625

},

"2" : {

"Curren t_ AC _P ha se _1 " : 0.57899999999999 99 6 ,
"Current_AC_Sum " : 0. 57 89 99 99 99 99 99 99 6,
"Details" : {

"Manufacturer " : " Fron iu s",

"Model " : "Smart Meter 63 A-1",

"Serial" : " 15160009 "

},

"Enable" : 1,
"En er gy Re ac tive_VArAC_ Ph as e_ 1_ Consumed" : 260,
"En er gy Re ac tive_VArAC_ Ph as e_ 1_ Produced" : 826179 0,
"En er gy Re ac tive_VArAC_Su m_ Co ns um ed" : 26 0,
"En er gy Re ac tive_VArAC_Su m_ Pr od uc ed" : 8261 790,
"En er gy Re al _W AC_Minus_Abso lu te " : 0 ,
"En er gy Re al _WAC_Phase_1_Co ns um ed " : 5670 793,
"En er gy Re al _WAC_Phase_1_Pr od uc ed " : 0,
"Ener gy Re al _W AC_Plus_Absolut e" : 5670 793,
"Ener gy Re al _W AC_Sum_Consumed " : 5670793,
"Ener gy Re al _W AC_Sum_Produced " : 0 ,
"Freq ue nc y_ Ph as e_Average " : 50,
"Mete r_ Lo ca ti on _C urrent" : 257,
"Powe rA pp ar en t_ S_Phase_1 " : 1 35.19 ,
"Powe rA pp ar en t_ S_ Su m" : 135. 19 ,
"Powe rF ac to r_ Ph as e_ 1" : 0.96999999999999997 ,
"PowerFacto r_ Su m" : 0.96999999999999997 ,
"Powe rR ea ct iv e_ Q_Phase_1 " : -22.62999999 99 99999,
"Powe rR ea ct iv e_ Q_ Su m" : -22.62 99 99 999999999,
"Powe rR ea l_ P_ Ph as e_ 1" : 132.09999999999999,
"PowerReal_ P_ Su m" : 132.09999999999999,
"TimeStamp" : 15613650 38 ,
"Visible" : 1,
"Voltag e_ AC _P ha se _1 " : 233. 5

},

"3" : {

"Details" : {

"Manufacturer " : " Fron iu s",

"Model " : "S0 Meter at inverter 40 ",

"Serial" : "n.a."

},

"Enable" : 1,
"Mete r_ Lo ca ti on _C urrent" : 258,
"TimeStamp" : 15609428 97 ,
"En er gy Re al _W AC_Minus_Rela ti ve ": 0,
"Ener gy Re al _W AC_Plus_Relativ e": 0 ,
"PowerReal_ P_ Su m": 0 ,

50

"Visible" : 1

},

"4": {

"Curren t_ AC _P ha se _1 ": 0,
"Curren t_ AC _P ha se _2 ": 0,
"Curren t_ AC _P ha se _3 ": 0,
"Current_AC_Sum ": 0 ,
"Details" : {

"Manufacturer ": " Froniu s",
"Model ": "CCS WattNode WND -3Y -600-M B" ,
"Serial": " 475619 "

},

"Enable": 1 ,
"En er gy Re al _W AC_Minus_Abso lu te ": 3321 ,
"En er gy Re al _WAC_Phase_1_Co ns um ed ": 33 21 ,
"En er gy Re al _WAC_Phase_1_Pr od uc ed ": 10 996,
"En er gy Re al _WAC_Phase_2_Co ns um ed ": 0,
"En er gy Re al _WAC_Phase_2_Pr od uc ed ": 0,
"En er gy Re al _WAC_Phase_3_Co ns um ed ": 0,
"En er gy Re al _WAC_Phase_3_Pr od uc ed ": 14 ,
"Ener gy Re al _W AC_Plus_Absolut e": 1 1010 ,
"Ener gy Re al _W AC_Sum_Consumed ": 3321 ,
"Ener gy Re al _W AC_Sum_Produced ": 11010,
"Freq ue nc y_ Ph as e_Average ": 49.98338699340 82 ,
"Mete r_ Lo ca ti on _C urrent" : 259,
"Powe rA pp ar en t_ S_Phase_1 ": 0,
"Powe rA pp ar en t_ S_Phase_2 ": 0,
"Powe rA pp ar en t_ S_Phase_3 ": 0,
"Powe rA pp ar en t_ S_ Su m": 0 ,
"Powe rF ac to r_ Ph as e_ 1": 1 ,
"Powe rF ac to r_ Ph as e_ 2": 1 ,
"Powe rF ac to r_ Ph as e_ 3": 1 ,
"PowerFacto r_ Su m": 1 ,
"Powe rR ea ct iv e_ Q_Phase_1 ": 0,
"Powe rR ea ct iv e_ Q_Phase_2 ": 0,
"Powe rR ea ct iv e_ Q_Phase_3 ": 0,
"Powe rR ea ct iv e_ Q_ Su m": 0 ,
"Powe rR ea l_ P_ Ph as e_ 1": 0 ,
"Powe rR ea l_ P_ Ph as e_ 2": 0 ,
"Powe rR ea l_ P_ Ph as e_ 3": 0 ,
"PowerReal_ P_ Su m": 0 ,
"TimeStamp" : 15199119 21 ,
"Visible" : 1,
"Volt ag e_ AC _P haseToPhase_12": 2 38 .1 53 83 91 11 32812,
"Volt ag e_ AC _P haseToPhase_23": 0,
"Volt ag e_ AC _P haseToPhase_31": 2 32 .9 16 76 33 05 66406,
"Voltag e_ AC _P ha se _1 ": 404.5267944335 93 75 ,
"Voltag e_ AC _P ha se _2 ": 231.7088470458 98 44 ,
"Voltag e_ AC _P ha se _3 ": 232.7247924804 68 75 ,

"Volt ag e_ AC _P ha se_Average" : 2 89 .6 53 47 29 003906

},

"5": {

"Curren t_ AC _P ha se _1 ": 0,

"Curren t_ AC _P ha se _2 ": 0,

"Curren t_ AC _P ha se _3 ": 0,

"Details" : {

"Manufacturer ": " Froniu s",
"Model ": "Smart Meter 50 kA -3",

"Serial": " 17362721"

},

"Enable": 1 ,
"En er gy Re ac tive_VArAC_Su m_ Co ns um ed" : 34 ,
"En er gy Re ac tive_VArAC_Su m_ Pr od uc ed" : 17 4,
"En er gy Re al _W AC_Minus_Abso lu te ": 3940 ,
"Ener gy Re al _W AC_Plus_Absolut e": 434 ,
"Ener gy Re al _W AC_Sum_Consumed ": 3940 ,
"Ener gy Re al _W AC_Sum_Produced ": 434,

51

}

},

"Head" : {

}

}

"Freq ue nc y_ Ph as e_Average ": 49.900000743567944,
"Mete r_ Lo ca ti on _C urrent" : 3,
"Powe rA pp ar en t_ S_Phase_1 ": 0,
"Powe rA pp ar en t_ S_Phase_2 ": 0,
"Powe rA pp ar en t_ S_Phase_3 ": 0,
"Powe rA pp ar en t_ S_ Su m": 0 ,
"Powe rF ac to r_ Ph as e_ 1": 0.9999 99 97 76 48 25 82 ,
"Powe rF ac to r_ Ph as e_ 2": 0.9999 99 97 76 48 25 82 ,
"Powe rF ac to r_ Ph as e_ 3": 0.9999 99 97 76 48 25 82 ,
"PowerFacto r_ Su m": 0. 99 99 999776482582 ,
"Powe rR ea ct iv e_ Q_Phase_1 ": 0,
"Powe rR ea ct iv e_ Q_Phase_2 ": 0,
"Powe rR ea ct iv e_ Q_Phase_3 ": 0,
"Powe rR ea ct iv e_ Q_ Su m": 0 ,
"Powe rR ea l_ P_ Ph as e_ 1": 0 ,
"Powe rR ea l_ P_ Ph as e_ 2": 0 ,
"Powe rR ea l_ P_ Ph as e_ 3": 0 ,
"PowerReal_ P_ Su m": 0 ,
"TimeStamp" : 15199119 21 ,
"Visible" : 1,
"Volt ag e_ AC _P haseToPhase_12": 4 04 .9 00 01 92 31 71803,
"Volt ag e_ AC _P haseToPhase_23": 4 04 .5 00 01 92 12 71905,
"Volt ag e_ AC _P haseToPhase_31": 4 04 .4 00 01 92 079693 ,
"Voltag e_ AC _P ha se _1 ": 233.7000111001 54 37 ,
"Voltag e_ AC _P ha se _2 ": 233.8000111049 04 12 ,
"Voltag e_ AC _P ha se _3 ": 233.30001108115 54

}

"RequestA rg um en ts " : {

"DeviceClass" : " Meter" ,

"Scope " : "Syste m"

},

"Status" : {

"Code" : 0,

"Reason" : "",

"UserMessage" : ""

},

"Timestamp" : "2019 -06- 24 T10 :3 1: 54 +0 2: 00 "

Examples for GEN24/Tauro are identical.

4.8.9 DeviceRequest

Listing 44: Object structure of response body for GetMeterRealtimeData request

# object with d etailed informations about one Meter,

ob je ct {

ob je ct {

st ri ng Serial ;

st ri ng Model;

st ri ng Manufacturer;

} Details ;

#channels of devi ce ( textual name and va lue)

nu mb er * _ _C HA NN EL _N AM E__;

} Data ;

Listing 45: Example of response body for GetMeterRealtimeData Device request

52

{

"Body" : {

},

"Head" : {

}

}

"Data" : {

"Curren t_ AC _P ha se _1 " : 0.61899999999999 99 9 ,

"Curren t_ AC _P ha se _2 " : 0.68799999999999 99 4 ,

"Curren t_ AC _P ha se _3 " : 0.55100000000000 00 5 ,

"Details" : {

"Manufacturer " : " Fron iu s",
"Model " : "Smart Meter 63 A",

"Serial" : " 15480258 "

},

"Enable" : 1,
"En er gy Re ac tive_VArAC_Su m_ Co ns um ed" : 2183 700,
"En er gy Re ac tive_VArAC_Su m_ Pr od uc ed" : 47100,
"Ener gy Re al _W AC_Minus_Abso lu te " : 40 75753,
"Ener gy Re al _W AC_Plus_Absolut e" : 9418 40 ,
"Ener gy Re al _W AC_Sum_Consumed " : 941840 ,
"Ener gy Re al _W AC_Sum_Produced " : 4075753,
"Freq ue nc y_ Ph as e_Average " : 50,
"Mete r_ Lo ca ti on _C urrent" : 0,
"Powe rA pp ar en t_ S_Phase_1 " : 1 43.9794,
"Powe rA pp ar en t_ S_Phase_2 " : 1 59.5472,
"Powe rA pp ar en t_ S_Phase_3 " : 1 27 .4 46 30 00 00 00002,
"Powe rA pp ar en t_ S_ Su m" : 211.36000000000001,
"Powe rF ac to r_ Ph as e_ 1" : 0.97999999999999998 ,
"Powe rF ac to r_ Ph as e_ 2" : 1,
"Powe rF ac to r_ Ph as e_ 3" : 1,
"PowerFacto r_ Su m" : 1,
"Powe rR ea ct iv e_ Q_Phase_1 " : 9 .9 00 00 00 00 00 00004,
"Powe rR ea ct iv e_ Q_Phase_2 " : 0,
"Powe rR ea ct iv e_ Q_Phase_3 " : 4 .7 99 99 99 99 99 99998,
"Powe rR ea ct iv e_ Q_ Su m" : 14.699999999999999,
"Powe rR ea l_ P_ Ph as e_ 1" : -75,
"Powe rR ea l_ P_ Ph as e_ 2" : -74.28 00 00 000000001,
"Powe rR ea l_ P_ Ph as e_ 3" : -62.07 99 99 999999998,
"PowerReal_ P_ Su m" : -211.3600 00 00 000001 ,
"TimeStamp" : 15604303 30 ,
"Visible" : 1,
"Volt ag e_ AC _P haseToPhase_12" : 402.3000000000 00 01 ,
"Volt ag e_ AC _P haseToPhase_23" : 401.1000000000 00 02 ,
"Volt ag e_ AC _P haseToPhase_31" : 401.6999999999 99 99 ,
"Voltag e_ AC _P ha se _1 " : 232.59999999 99 99 99 ,
"Voltag e_ AC _P ha se _2 " : 231.90000000 00 00 01 ,
"Voltag e_ AC _P ha se _3 " : 231.300000000 00 00 1

}

"RequestA rg um en ts " : {

"DeviceClass" : " Meter" ,
"DeviceId " : "0" ,
"Scope " : "Devic e"

},

"Status" : {

"Code" : 0,
"Reason" : "",
"UserMessage" : ""

},

"Timestamp" : "2019 -06- 13 T14 :5 2: 10 +0 2: 00 "

Examples for GEN24/Tauro are identical.

4.9 GetStorageRealtimeData request

This request provides detailed information about batteries. Inactive channels are not included in the response and
may vary depended on battery used and software version. Take care about permanently or temporary missing

53

channels when processing this response.

4.9.1 Availability

Platform Since version
Fronius Hybrid 1.1.213
Fronius Non Hybrid NOT AVAILABLE
Fronius GEN24/Tauro 1.13

4.9.2 3rd Party Batteries

will be displayed since HybridManager version 1.13.1x and Solar API Version 1.517. Older versions reported
an error:

Listing 46: Former response body for GetStorageRealtimeData request using BYD Box

{

"Body" : {

"Data" : {}

},

"Head" : {

"RequestA rg um en ts " : {

"DeviceClass" : " St orage" ,
"DeviceId " : "0" ,

"Scope " : "Devic e"

},

"Status" : {

"Code" : 255,

"Reason" : " battery type 'BYD ' is not su pp orted",

"UserMessage" : ""

},

"Timestamp" : "2019 -06- 03 T17 :0 1: 01 +0 2: 00 "

}

}

4.9.3 Supported

manufacturer model versions
Fronius Fronius Solar Battery bms sw 0x18XX
BYD BYD BatteryBox HV protocol 0x0  0x1ffff
LGChem Resu H dcdc sw 0x5046  0x50ff

dcdc sw 0x7046  0x70ff

+ If storage version is incompatible, it will be operative and an inconsistency warning will be shown to

update the storage if possible.

4.9.4 URL for HTTP requests

/solar_api/v1/GetStorageRealtimeData.cgi

4.9.5 Parameters

Parameter Type Range/Values/Pattern Description
Scope String ”System”

”Device”

DeviceId String 0..65535 Mandatory on non system scope

4.9.6 Reference to manual

Mandatory

Reference to Fronius Energy Package and 3rd Party support can be found here:

https://www.fronius.com/~/downloads/Solar%20Energy/Operating%20Instructions/42%2C0426%2C0222%

2CEN.pdf

54

4.9.7 Channel Descriptions

Table 3: Channel and description for control section

Name of channel Description Available

Fronius LG BYD

Solar Chem Box

Battery Resu H
Details / Manufacturer name of manufacturer always always always
Details / Model model of battery always always always
Details / Serial unique identification serial always always always

TimeStamp last timestamp data has been refrehsed always always always
Enable device is managed (1.0) or disconnected (0.0) always always always
StateOfCharge_Relative relative charged capacity in % always always always
Capacity_Maximum current max capacity always always always
DesignedCapacity max designed capacity always always always
Current_DC battery output current (+ charging) always always always
Voltage_DC battery output voltage always always always
Temperature_Cell temperature in degree celsius always always always

Table 4: Channel and description for module section (only Solar Battery provides module informations)

Name of channel Description Available

Fronius LG BYD

Solar Chem Box

Battery Resu H
Details / Manufacturer manufacturer always  
Details / Model model identifier always  
Details / Serial unique identifier always  

Capacity_Maximum always  
Current_DC always  
CycleCount_BatteryCell always  
DesignedCapacity always  
Enable always  
StateOfCharge_Relative always  
Status_BatteryCell always  
Temperature_Cell always  
Temperature_Cell_Maximum always  
Temperature_Cell_Minimum always  
TimeStamp always  
Voltage_DC always  
Voltage_DC_Maximum_Cell always  
Voltage_DC_Minimum_Cell always  

4.9.8 SystemRequest

Listing 47: Object structure of response body for GetStorageRealtimeData request

# object with d etailed informations about one Battery

ob je ct {

ob je ct {

ob je ct {

ob je ct {

# serial number of batter y

st ri ng Serial ;

55

Table 2: Channel and value description

Name of channel Description
Status_BatteryCell Fronius Solar Battery at section Modules

Previuos and current state of a battery cell. One Byte printed
in hexadecimal. 0xYX (Y: Current status, X: Previous status)
Meaning of numerical status codes:

Status value Description
0

16

1

16

2

16

3

16

4

16

5

16

6

16

7

16

8

16

9

16

A

16

B

16

C

16

D

16

E

16

F

16

RESERVED
Pre Charge
Initial
Normal Charge
Charge Terminate
Normal Discharge
Over Voltage
Over Discharge
RESERVED
Over Temp Charge
Over Current Charge
Over Temp Discharge
Over Current Discharge
Cell Unbalance
Charge Suspend
RESERVED

Status_BatteryCell for LGChem Resu H at section Controller

Status value Description
1 STANDBY
3 ENABLED
5 FAULTED
10 SLEEP

Status_BatteryCell for BYD Box at section Controller

Status value Description
0 STANDBY
1 INACTIVE
2 DARKSTART
3 ACTIVE
4 FAULT
5 UPDATING

56

# device type i de ntifier

st ri ng Model;

# Solar ba tt er y m an uf ac tu re r ch anged from "Froni us I nt er na ti on al " to "Fronius"
# So la r API Ve rs ion : 1.5 -16
# Fr on iu s S ymo Hybrid : 1.12.1 -3

st ri ng Manufacturer;

} Details ;

#channels of devi ce ( textual name and va lue)

nu mb er * _ _C HA NN EL _N AM E__;

} C on troller;

ar ray {

ob je ct {

st ri ng Serial ;

st ri ng Model;

st ri ng Manufacturer;

} Details ;

#channels of devi ce ( textual name and va lue)

nu mb er * _ _C HA NN EL _N AM E__;

} * M od ul es ;

} * D ev ic eI d; / / 0...65535

} Data ;

Manufacturer has been updated at version HM1.12.1X from ”Fronius International” to ”Fronius”

Listing 48: Reply body for GetStorageRealtimeData System request (Solar Battery)

{

"Body" : {

"Data" : {

"0" : {

"Controller " : {

"Capacity _M ax im um " : 7200 ,
"Current_DC " : 1 .1 20 00 00 00 0000001,
"Designed Ca pa ci ty " : 7200 ,
"Details" : {

"Manufacturer " : " Fron iu s",
"Model " : "Fronius So lar Battery",

"Serial" : " 26175063 "

},

"Enable" : 1,
"Stat eO fC ha rg e_ Re lative" : 55 ,
"Temperat ur e_ Ce ll " : 26.150 00 00 00 00 00 34 ,
"TimeStamp" : 15603462 72 ,
"Voltage_DC " : 3 18 .8 00 00 00 0000001,
"Volt ag e_ DC _M ax imum_Cell " : 3 .3 29 00 00 00 00 00002,
"Volt ag e_ DC _M in imum_Cell " : 3 .3159999999999998

},

"Modules" : [

{

"Capacity _M ax im um " : 1200 ,

"Current_DC " : 1 .1 10 00 00 00 0000001,

"Cycl eC ou nt _B at te ryCell" : 255,

"Designed Ca pa ci ty " : 1200 ,

"Details" : {

"Manufacturer " : " So ny ",
"Model " : "unknown " ,

57

"Serial" : " S0 12002885 "

},

"Enable" : 1,
"Stat eO fC ha rg e_ Re lative" : 55 ,
"Status _B at te ry Ce ll " : 53 ,
"Temperat ur e_ Ce ll " : 27.25,
"Temp er at ur e_ Ce ll_Maximum" : 27.7 5,
"Temp er at ur e_ Ce ll_Minimum" : 2 6. 95 0000000000045,
"TimeStamp" : 15603462 63 ,
"Voltage_DC " : 5 3. 14 20 00 00 0000003,
"Volt ag e_ DC _M ax imum_Cell " : 3 .3 23 99 99 99 99 99998,
"Volt ag e_ DC _M in imum_Cell " : 3 .3140000000000001

},
{

"Capacity _M ax im um " : 1200 ,
"Current_DC " : 1 .1 20 00 00 00 0000001,
"Cycl eC ou nt _B at te ryCell" : 257,
"Designed Ca pa ci ty " : 1200 ,
"Details" : {

"Manufacturer " : " So ny ",

"Model " : "unknown " ,

"Serial" : " S0 12002843 "

},

"Enable" : 1,
"Stat eO fC ha rg e_ Re lative" : 55 ,
"Status _B at te ry Ce ll " : 53 ,
"Temperat ur e_ Ce ll " : 26.650 00 00 00 00 00 34 ,
"Temp er at ur e_ Ce ll_Maximum" : 2 7. 15 0000000000034,
"Temp er at ur e_ Ce ll_Minimum" : 2 6. 35 0000000000023,
"TimeStamp" : 15603462 63 ,
"Voltage_DC " : 53.137 ,
"Volt ag e_ DC _M ax imum_Cell " : 3 .3 27 99 99 99 99 99998,
"Volt ag e_ DC _M in imum_Cell " : 3 .3159999999999998

},
{

"Capacity _M ax im um " : 1200 ,
"Current_DC " : 1 .1 29 99 99 99 9999999,
"Cycl eC ou nt _B at te ryCell" : 257,
"Designed Ca pa ci ty " : 1200 ,
"Details" : {

"Manufacturer " : " So ny ",

"Model " : "unknown " ,

"Serial" : " S0 12002844 "

},

"Enable" : 1,
"Stat eO fC ha rg e_ Re lative" : 55 ,
"Status _B at te ry Ce ll " : 53 ,
"Temperat ur e_ Ce ll " : 26.450 00 00 00 00 00 45 ,
"Temp er at ur e_ Ce ll_Maximum" : 2 7. 05 0000000000011,
"Temp er at ur e_ Ce ll_Minimum" : 26.2 5,
"TimeStamp" : 15603462 63 ,
"Voltage_DC " : 5 3. 16 40 00 00 0000001,
"Volt ag e_ DC _M ax imum_Cell " : 3 .3 29 00 00 00 00 00002,
"Volt ag e_ DC _M in imum_Cell " : 3 .319

},
{

"Capacity _M ax im um " : 1200 ,
"Current_DC " : 1 .1 29 99 99 99 9999999,
"Cycl eC ou nt _B at te ryCell" : 254,
"Designed Ca pa ci ty " : 1200 ,
"Details" : {

"Manufacturer " : " So ny ",

"Model " : "unknown " ,

"Serial" : " S0 12002838 "

},

"Enable" : 1,
"Stat eO fC ha rg e_ Re lative" : 55 ,

58

"Status _B at te ry Ce ll " : 53 ,
"Temperat ur e_ Ce ll " : 26.150 00 00 00 00 00 34 ,
"Temp er at ur e_ Ce ll_Maximum" : 26.7 5,
"Temp er at ur e_ Ce ll_Minimum" : 25.7 5,
"TimeStamp" : 15603462 63 ,
"Voltage_DC " : 5 3. 15 89 99 99 9999999,
"Volt ag e_ DC _M ax imum_Cell " : 3 .3 29 00 00 00 00 00002,
"Volt ag e_ DC _M in imum_Cell " : 3 .3180000000000001

},
{

"Capacity _M ax im um " : 1200 ,
"Current_DC " : 1 .1 20 00 00 00 0000001,
"Cycl eC ou nt _B at te ryCell" : 256,
"Designed Ca pa ci ty " : 1200 ,
"Details" : {

"Manufacturer " : " So ny ",

"Model " : "unknown " ,

"Serial" : " S0 12002884 "

},

"Enable" : 1,
"Stat eO fC ha rg e_ Re lative" : 55 ,
"Status _B at te ry Ce ll " : 53 ,
"Temperat ur e_ Ce ll " : 25.550 00 00 00 00 00 11 ,
"Temp er at ur e_ Ce ll_Maximum" : 2 6. 15 0000000000034,
"Temp er at ur e_ Ce ll_Minimum" : 2 5. 35 0000000000023,
"TimeStamp" : 15603462 63 ,
"Voltage_DC " : 5 3. 14 60 00 00 0000001,
"Volt ag e_ DC _M ax imum_Cell " : 3 .3 26 00 00 00 00 00001,
"Volt ag e_ DC _M in imum_Cell " : 3 .3170000000000002

},
{

"Capacity _M ax im um " : 1200 ,
"Current_DC " : 1 .1 20 00 00 00 0000001,
"Cycl eC ou nt _B at te ryCell" : 255,
"Designed Ca pa ci ty " : 1200 ,
"Details" : {

"Manufacturer " : " So ny ",

"Model " : "unknown " ,

"Serial" : " S0 12002857 "

},

"Enable" : 1,
"Stat eO fC ha rg e_ Re lative" : 55 ,
"Status _B at te ry Ce ll " : 53 ,
"Temperat ur e_ Ce ll " : 25.25,
"Temp er at ur e_ Ce ll_Maximum" : 25.7 5,
"Temp er at ur e_ Ce ll_Minimum" : 2 4. 95 0000000000045,
"TimeStamp" : 15603462 63 ,
"Voltage_DC " : 5 3. 15 69 99 99 9999996,
"Volt ag e_ DC _M ax imum_Cell " : 3 .3 26 00 00 00 00 00001,
"Volt ag e_ DC _M in imum_Cell " : 3 .3199999999999998

}

]

}

}
},

"Head" : {

"RequestA rg um en ts " : {

"DeviceClass" : " St orage" ,

"Scope " : "Syste m"

},

"Status" : {

"Code" : 0,

"Reason" : "",

"UserMessage" : ""

},

"Timestamp" : "2019 -06- 12 T15 :3 1: 12 +0 2: 00 "

}

59

}

{

"Body" : {

},

"Head" : {

}

}

Listing 49: Reply body for GetStorageRealtimeData System request (BYD BBox)

"Data" : {

"0" : {

"Controller " : {

"Capacity _M ax im um " : 11520,
"Current_DC " : 0,
"Designed Ca pa ci ty " : 11520,
"Details" : {

"Manufacturer " : " BYD" ,
"Model " : "BYD Batte ry - Bo x HV",

"Serial" : " 400481708-0005 9"

},

"Enable" : 1,
"Stat eO fC ha rg e_ Re lative" : 4.7000000000000002,
"Status _B at te ry Ce ll " : 3,
"Temperat ur e_ Ce ll " : 23.949 99 99 99 99 99 99 ,
"TimeStamp" : 15604305 43 ,
"Voltage_DC " : 4 62 .60000000000002

},

"Modules" : []

}

}

"RequestA rg um en ts " : {

"DeviceClass" : " St orage" ,

"Scope " : "Syste m"

},

"Status" : {

"Code" : 0,

"Reason" : "",

"UserMessage" : ""

},

"Timestamp" : "2019 -06- 13 T14 :5 5: 44 +0 2: 00 "

4.9.9 DeviceRequest

Listing 50: Object structure of response body for GetStorageRealtimeData request

# object with d etailed informations about one Battery

ob je ct {

ob je ct {

ob je ct {

#serial nu mber of Fronius So lar Battery

st ri ng Serial ;

st ri ng Model;

st ri ng Manufacturer;

} Details ;

#channels of devi ce ( textual name and va lue)

nu mb er * _ _C HA NN EL _N AM E__;

} C on troller;

ar ray {

60

ob je ct {

} Details ;

#channels of devi ce ( textual name and va lue)

nu mb er * _ _C HA NN EL _N AM E__;

} * M od ul es ;

} Data ;

{

"Body" : {

"Data" : {

}

},

"Head" : {

"RequestA rg um en ts " : {

},

"Status" : {

},

"Timestamp" : "2019 -06- 12 T15 :3 1: 08 +0 2: 00 "

}

}

st ri ng Serial ;

st ri ng Model;

st ri ng Manufacturer;

Listing 51: Reply body for GetStorageRealtimeData Device request (LG Chem Resu H)

"Controller " : {

"Capacity _M ax im um " : 9800 ,
"Current_DC " : 0 .9 00 00 00 00 00 00 0002 ,
"Designed Ca pa ci ty " : 9800 ,
"Details" : {

"Manufacturer " : " LG -Che m",
"Model " : "Res u H",

"Serial" : " 17 06179036 "

},

"Enable" : 1,
"Stat eO fC ha rg e_ Re lative" : 56 ,
"Status _B at te ry Ce ll " : 3,
"Temperat ur e_ Ce ll " : 27.550 00 00 00 00 00 01 ,
"TimeStamp" : 15603462 67 ,
"Voltage_DC " : 4 07.5

},

"Modules" : []

"DeviceClass" : " St orage" ,
"DeviceId " : "0" ,
"Scope " : "Devic e"

"Code" : 0,
"Reason" : "",
"UserMessage" : ""

4.10 GetOhmPilotRealtimeData request

This request provides detailed information about Ohmpilot. Inactive channels are not included in the response
and may vary depending on hardware and software version used. Take care about permanently or temporary
missing channels when processing this response.

4.10.1 Availability

Platform Since version
Fronius Hybrid 1.6.14
Fronius Non Hybrid 3.8.14
Fronius GEN24/Tauro 1.13

61

4.10.2 URL for HTTP requests

/solar_api/v1/GetOhmPilotRealtimeData.cgi

4.10.3 Parameters

Parameter Type Range/Values/Pattern Description
Scope String ”System”

Mandatory

”Device”

DeviceId String 0..65535 Mandatory on non system scope

4.10.4 Reference to manual

https://www.fronius.com/~/downloads/Solar%20Energy/Operating%20Instructions/42%2C0410%2C2141.pdf

4.10.5 SystemRequest

Listing 52: Object structure of response body for GetOhmPilotRealtimeData System request

# object with d etailed informations about all Ohmpil ots ,

ob je ct {

ob je ct {

ob je ct {

# serial number of devi ce

st ri ng Serial ;

# e.g. "Ohmpilot"

st ri ng Model;

# e.g. "Fronius "

st ri ng Manufacturer;

# s oftware version

st ri ng Software;

# h ardware version

st ri ng Hardware;

} Details ;

# total co ns um ed energy [Wh]

nu mb er Ene rg yR ea l_ WA C_Sum_Consumed;

# C od eO fS ta te Values:
# 0 . .. up an d r un ning
# 1 . .. ke ep minimum temp er at ur e
# 2 . .. legionella protection
# 3 . .. critic al f ault
# 4 . .. faul t
# 5 . .. boos t m ode

nu mb er CodeOfState ;

# refer to Ohmpil ot m anual
# o ptional field

nu mb er CodeOfError ;

# actual power co ns um pt io n [W]

nu mb er PowerRe al _P AC _S um ;

# t em pe ra tu re from se ns or [°C]

nu mb er Tempe ra tu re _C ha nn el_1;

} * O hm pi lo t;

} Data ;

62

{

"Body" : {

},

"Head" : {

}

}

Listing 53: Reply body for GetOhmPilotRealtimeData System request

"Data" : {

"0" : {

"CodeOfError" : 926,
"CodeOfState" : 0,
"Details" : {

"Hardware " : "3" ,

"Manufacturer " : " Fron iu s",

"Model " : "Ohmpilot",

"Serial" : " 28136344 ",

"Software " : " 1.0.19 -1 "

},

"Ener gy Re al _W AC_Sum_Consumed " : 2964307,
"PowerR ea l_ PA C_ Su m" : 0,
"Temp er at ur e_ Ch an nel_1 " : 2 3. 89 99 99 999999999

}

}

"RequestA rg um en ts " : {

"DeviceClass" : " Oh mPilot ",

"Scope " : "Syste m"

},

"Status" : {

"Code" : 0,

"Reason" : "",

"UserMessage" : ""

},

"Timestamp" : "2019 -06- 24 T10 :1 0: 44 +0 2: 00 "

4.10.6 DeviceRequest

Listing 54: Object structure of response body for GetOhmPilotRealtimeData Device request

# object with d etailed informations about one Ohmpil ot ,

ob je ct {

ob je ct {

# serial number of devi ce

st ri ng Serial ;

# e.g. "Ohmpilot"

st ri ng Model;

# e.g. "Fronius "

st ri ng Manufacturer;

# s oftware version

st ri ng Software;

# h ardware version

st ri ng Hardware;

} Details ;

# total co ns um ed energy [Wh]

nu mb er Ene rg yR ea l_ WA C_Sum_Consumed;

# C od eO fS ta te Values:
# 0 . .. up an d r un ning
# 1 . .. ke ep minimum te mp er at ur e
# 2 . .. legionella protection
# 3 . .. critic al f ault

63

# 4 . .. faul t
# 5 . .. boos t mode

nu mb er CodeOfState ;

# refer to Ohmpil ot m anual
# o ptional field

nu mb er CodeOfError ;

# actual power co ns um pt io n [W]

nu mb er PowerRe al _P AC _S um ;

# t em pe ra tu re from s ensor [°C]

nu mb er Tempe ra tu re _C ha nn el_1;

} Data ;

Listing 55: Reply body for GetOhmPilotRealtimeData Device request

{

"Body" : {

"Data" : {

"CodeOfError" : 926,

"CodeOfState" : 0,

"Details" : {

"Hardware " : "3" ,
"Manufacturer " : " Fron iu s",
"Model " : "Ohmpilot",
"Serial" : " 28136344 ",

"Software " : " 1.0.19 -1 "

},

"Ener gy Re al _W AC_Sum_Consumed " : 2964307,
"PowerR ea l_ PA C_ Su m" : 0,
"Temp er at ur e_ Ch an nel_1 " : 2 3. 89 99 99 999999999

}
},

"Head" : {

"RequestA rg um en ts " : {

"DeviceClass" : " Oh mPilot ",
"DeviceId " : "0" ,

"Scope " : "Devic e"

},

"Status" : {

"Code" : 0,

"Reason" : "",

"UserMessage" : ""

},

"Timestamp" : "2019 -06- 24 T10 :1 0: 41 +0 2: 00 "

}

}

4.11 GetPowerFlowRealtimeData request

This request provides detailed information about the local energy grid. The values replied represent the current
state. Because data has multiple asynchronous origins it is a matter of fact that the sum of all powers (grid, load
and generate) will differ from zero.
This request does not care about the configured visibility of single inverters. All inverters are reported. Same for
batteries.

4.11.1 Availability

Platform Since version
Fronius Hybrid 1.2.1X
Fronius Non Hybrid 3.3.9X
Fronius GEN24/Tauro ALWAYS

64

4.11.2 Version

This request is only a gateway to internal generated data containers. Please take care about the ”Version” field
in the response. Newer versions usually contain all previous items.

Version Changes 10 added smartloads/ohmpilot

added Version field
11 added secondary meters for subloads or extra production (Datamanager and HybridManager)
12 inverter nodes now provide component id
13 added secondary meters for subloads or extra production (GEN24/Tauro)

added active power and apparent current per phase for primary meter

4.11.3 URL for HTTP requests

/solar_api/v1/GetPowerFlowRealtimeData.fcgi

Please note, for performance reasons the URL extension is different to other Solar API requests.

4.11.4 Parameters

There are no parameters. Only one type of query exists.

4.11.5 Request

Listing 56: Object structure of response body for GetPowerFlowRealtimeData request

ob je ct {

# m andatory fiel d
# i mp le me nt ed since Fr on ius Non Hy brid version 3 .8.1 -1
# Fronius Hy br id version 1.6.1- 1
# d escribes the a va il ab le fields fo r this reques t ( PowerFlowVersion)
# Vers io n s tr ing contains a p os itive integer

st ri ng Version;

ob je ct {

# m andatory fiel d
# Mode: Co nt ai ns :
# " produce - only ", in ve rt er only
# " meter" , "vague - mete r", i nv er ter and me ter
# " bi di re ct io na l" or "ac-coupled " invert er , mete r and batt er y

st ri ng Mode ;

# o ptional field, supported si nce Fronius Hy br id version 1. 4.1- 6
# su pp or te d on Gen2 4 d ev ic es having batt er y
# not available on Froniu s N on Hybr id
# true wh en battery is in standb y

bo ol ea n B at te ry St an db y;

# o ptional field, supported si nce Fronius Hy br id version 1. 3.1- 0
# not available on Froniu s N on Hybr id
# su pp or te d on Gen2 4/Tauro devi ce s
# field is availabl e if configured (false) or acti ve ( true )
# if not availa ble , mandatory conf ig is not set.
# On Ge n24 this flag is al wa ys available

bo ol ea n B ac ku pM od e;

# m andatory fiel d
#this v al ue is null if no mete r is enabled ( + from grid , - to grid )

nu mb er P_Grid ;

# m andatory fiel d
#this v al ue is null if no mete r is enabled ( + genera tor , - c on su mer )

nu mb er P_Load ;

65

# m andatory fiel d
#this v al ue is null if no batter y is active ( - charge , + d ischarge )

nu mb er P_Akku ;

# m andatory fiel d
#this v al ue is null if invert er is no t running ( + production ( default ) )
# On GE N24 and Sy mo Hy br id : re ports production on DC si de (PV g en er at or ).
# On SnapInverter: is iden t to powe r g en er at ed on AC si de (ac p ower outp ut ).

nu mb er P_PV ;

# m andatory fiel d
# a vailable sinc e F ro ni us Hybrid versio n 1 .3.1 -1
# a vailable sinc e F ro ni us Non H yb rid v ersion 3. 7.1-2
# current relati ve self consumption in %, null if no smar t m eter is connected

nu mb er rel_S el fC on su mp ti on ;

# m andatory fiel d
# a vailable sinc e F ro ni us Hybrid versio n 1 .3.1 -1
# a vailable sinc e F ro ni us Non H yb rid v ersion 3. 7.1-2
# current relati ve a ut onomy in %, nu ll if no sm art meter is connec te d

nu mb er rel_Autonomy;

# o ptional field
# " load ", "gri d" or " unknown" (during ba ckup powe r)

st ri ng Meter_Location;

# o ptional field
# i mp le me nt ed since Fr on ius Non Hy brid version 3 .4.1 -7
# this valu e is alwa ys null on GEN24/T auro
# AC En er gy [Wh] th is day, null if no inverter is connected

nu mb er E_Day;

# o ptional field
# i mp le me nt ed since Fr on ius Non Hy brid version 3 .4.1 -7
# this valu e is alwa ys null on GEN24/T auro
# AC En er gy [Wh] th is year , n ull if no inve rt er is conn ec te d

nu mb er E_Year ;

# o ptional field
# i mp le me nt ed since Fr on ius Non Hy brid version 3 .4.1 -7
# i mp le me nt ed since Fr on ius GEN24 /Tau ro version 1. 14 an d null before
# updated on ly every 5 minu te s on GEN2 4/T auro .
# AC En er gy [Wh] ev er si nce, nu ll if no inverter is connected

nu mb er E_Total;

} Site;

ob je ct {

ob je ct {

# m andatory fiel d
# device type of inve rt er
# GEN24 /Tau ro do report 1

in te ge r DT;

# m andatory fiel d
# current powe r in Watt , n ull if not r un ni ng (+ pr od uce/expo rt , - consume/

im po rt )

# This is powe r g en er at ed on AC si de (ac p ower output ).

in te ge r P;

# o ptional field
# current stat e of char ge in % as decimal ( 5.3% ) or integer ( 0 - 1 00%)

un si gn ed number SO C;

66

# m andatory fiel d
# i mp le me nt ed since Fr on ius Non Hy brid version 3.13.1 -1
# Fronius Hy br id version 1.11.1 -1
# PowerFl ow Ve rs io n 12
# c omponent identification (8bit group , 16 bit e num)

un si gn ed integer CID;

# o ptional field
# "disab le d", " norm al ", "servi ce ", "charg e b oost ",
# "nea rl y d ep le ted", " su sp en de d", " calibrat e",
# "gri d s upport ", "deplete recovery ", "non operable (voltage) ",
# "n on operable (temperature) ", "preheating ", "startup" ,
# "sto pp ed ( te mp er at ur e)", "batte ry full"

st ri ng Battery_Mode;

# o ptional field
# i mp le me nt ed since Fr on ius Non Hy brid version 3 .7.1 -1
# Fronius Hy br id version 1.3.1- 1
# Fronius GE N24/ Tauro always null
# AC En er gy [Wh] th is day, null if no inverter is connected

nu mb er E_Day;

# o ptional field
# i mp le me nt ed since Fr on ius Non Hy brid version 3 .7.1 -1
# Fronius Hy br id version 1.3.1- 1
# Fronius GE N24/ Tauro always null
# AC En er gy [Wh] th is year , n ull if no inve rt er is conn ec te d

nu mb er E_Year ;

# o ptional field
# i mp le me nt ed since Fr on ius Non Hy brid version 3 .7.1 -1
# Fronius Hy br id version 1.3.1- 1
# Fronius GE N24/ Tauro ve rsion 1.14 an d null befo re
# updated only ever y 5 mi nu tes on GE N2 4/Tauro.
# AC En er gy [Wh] ev er si nce, nu ll if no inverter is connected

nu mb er E_Total;

} * D ev ic eI d; # SolarNet ring address (" 1" on hybrid system s)

#GEN24 / Ta uro devices al wa ys will use De vi ce Id 1

} I nverters ;

# o ptional field
# i mp le me nt ed since Fr on ius Non Hy brid version 3 .8.1 -1
# Fronius Hy br id version 1.6.1- 1
# PowerFl ow Ve rs io n 10

ob je ct {

# o ptional field
# i mp le me nt ed since Po we rFlowVersion 10
# always available on GEN2 4/Tauro
# on DM /HM only available when Ohmpilot is existing

ob je ct {

# o ptional field
# i mp le me nt ed since Po we rF lowVersion 10

ob je ct {

# m andatory fiel d
# i mp le me nt ed since Po we rF lowVersion 10
# current powe r c on su mp ti on in Wa tt

nu mb er P_AC_Total;

# m andatory fiel d
# i mp le me nt ed since Po we rF lowVersion 10
# o perating stat e " no rm al ", " min-t em pe ra tu re ", "leg ionella-pro te ct io n",

67

# "fau lt ", " warning" or "boost"

st ri ng State;

# m andatory fiel d
# i mp le me nt ed since Po we rF lowVersion 10
# t em pe ra tu re of storage / tank in degr ee Celsius

nu mb er Temperature ;

} C om po ne nt Id ;

} O hmpilots ;

} S ma rtloads;

# o ptional field
# i mp le me nt ed since Fr on ius Non Hy brid version 3.12.1 -1
# Fronius Hy br id version 1.10.1 -1
# PowerFl ow Ve rs io n 11
#
# Fronius GE N24/ Tauro 1.22.1 -1
# PowerFl ow Ve rs io n 13

ob je ct {

# i mp le me nt ed since Po we rFlowVersion 11

ob je ct {

# m andatory fiel d
# i mp le me nt ed since Po we rFlowVersion 11
# current powe r c on su mp ti on / pr od uc ti on in Watt (direction is based on meter

lo ca ti on )
# c on su mp ti on is ne ga ti ve for m et er location >= 256
# p ro du ct io n is positi ve for me ter location 3

nu mb er P;

# m andatory fiel d
# i mp le me nt ed since Po we rFlowVersion 11
# meter lo ca ti on of the device (see end of listing for more details )

nu mb er MLoc ;

# m andatory fiel d
# i mp le me nt ed since Po we rFlowVersion 11
# user define d n ame of se co nd ar y m eter or
# "<primar y >" for p ri ma ry meters

st ri ng Label;

# m andatory fiel d
# i mp le me nt ed since Po we rFlowVersion 11
# c ategory token
# "METER_CAT_WR " ... Photovoltaic i nv erter
# "METER_CAT_BAT" ... AC storag e u nit
# "METER_CAT_PV_BAT " .. . P ho to vo lt ai c i nv er te r + st or age unit
# "METER_CAT_WINDMILL " ... Wind turbin e
# "METER_CAT_BHKW " ... Co mb in ed heat and po wer station ( CHP)
# "METER_CAT_ECAR " ... El ec tr ic vehicle
# "METER_CAT_HEATPUMP " ... H eatpump
# "METER_CAT_OT HE RH EA TI NG " ... O th er heating sy st em
# "METER_CAT_PUMP " ... Pump
# "METER_CAT_WHIT EG OO DS " ... W hite good s
# "METER_CAT_CLIMATE" ... C li ma te control / cooling sy st ems
# "METER_CAT_BUILDING " ... B uilding services
# "METER_CAT_OTHER" ... Ot he r

st ri ng Category;

} C om po ne nt Id ;

} S ec on da ry Me te rs ;

68

} Data ;

Reference to device type table in section 6.2.
Reference to meter location table in section 6.5.

+ On GEN24/Tauro devices having no battery the fields ”SOC”=0.0 and ”Battery_Mode”=”disabled” are

falsely reported until 1.17.x.

Listing 57: Reply body for GetPowerFlowRealtimeData on Fronius Hybrid System

{

"Body" : {

"Data" : {

"Inverters" : {

"1" : {

"Battery_Mode " : " no rm al ",
"DT" : 99 ,
"E_Day " : 6758 ,
"E_Total" : 7604 38 5.5,
"E_Year" : 1342638. 25 ,
"P" : 5 06 ,
"SOC " : 55

}
},

"Site" : {

"BatteryStandby " : f alse ,

"E_Day " : 6758 ,

"E_Total" : 7604 38 5.5,

"E_Year" : 1342638.2000000002,

"Meter_Location " : " grid ",

"Mode" : "bidirectional",

"P_Akku" : -384 .7 00 00000000005,

"P_Grid" : -511 .9 90 00000000001,

"P_Load" : 5.9900000000000091,

"P_PV" : 941.60000000000002,

"rel_Autonomy " : 100 ,

"rel_ Se lf Co ns um pt io n" : 0

},

"Smartloads " : {

"Ohmpilots" : {

"720897" : {

"P_AC_Total " : 2635 ,
"State " : "norma l",
"Temperature" : 30.7

}

}
},

"Version" : "12"

}
},

"Head" : {

"RequestA rg um en ts " : {} ,

"Status" : {

"Code" : 0,
"Reason" : "",

"UserMessage" : ""

},

"Timestamp" : "2019 -06- 12 T15 :3 1: 07 +0 2: 00 "

}

}

{

"Body" : {

Listing 58: Reply body for GetPowerFlowRealtimeData on Fronius Non Hybrid System

"Data" : {

69

},

"Head" : {

}

}

"Inverters" : {

"1" : {

"DT" : 102,
"E_Day " : 1393.20007 32 42 18 75 ,
"E_Total" : 173479 6. 125,
"E_Year" : 322593 .5 ,

"P" : 8 8

},

"2" : {

"DT" : 86 ,

"E_Day " : 16 18.5 ,

"E_Total" : 3026 782,

"E_Year" : 385172.093 75 ,

"P" : 1 04

},

"3" : {

"DT" : 106,

"E_Day " : 1695.800 04 88 28 12 5 ,

"E_Total" : 316049 9. 75 ,

"E_Year" : 399904.093 75 ,

"P" : 1 09

},

"55" : {

"DT" : 224,

"E_Day " : 1699 ,

"E_Total" : 327521 9. 75 ,

"E_Year" : 403993.218 75 ,

"P" : 1 09

}

},

"Site" : {

"E_Day " : 6406.50012 20 70 31 25 ,
"E_Total" : 111972 97 .6 25 ,
"E_Year" : 1511662.9062 5 ,
"Meter_Location " : " unknow n",
"Mode" : "produce - on ly ",
"P_Akku" : null ,
"P_Grid" : null ,
"P_Load" : null ,
"P_PV" : 410,
"rel_Autonomy " : null ,
"rel_ Se lf Co ns um pt io n" : null

},

"Version" : "12"

}

"RequestA rg um en ts " : {} ,
"Status" : {

"Code" : 0,
"Reason" : "",

"UserMessage" : ""

},

"Timestamp" : "2019 -06- 12 T15 :3 1: 08 +0 2: 00 "

{

"Body" : {

Listing 59: Reply body for GetPowerFlowRealtimeData on GEN24 Primo

"Data" : {

"Inverters" : {

"1" : {

"Battery_Mode " : " no rm al ",
"DT" : 1,
"P" : 5 01 ,

70

},

"Head" : {

}

}

"SOC " : 30.600000381469727

}
},

"Site" : {

"BatteryStandby " : f alse ,

"E_Day " : null ,

"E_Total" : nu ll ,

"E_Year" : null ,

"Meter_Location " : " grid ",

"Mode" : "bidirectional",

"P_Akku" : -100 6. 18 68286132812,

"P_Grid" : -497.62 ,

"P_Load" : -3.3 79 99 99999999955,

"P_PV" : 1547.73999023437 5 ,

"rel_Autonomy " : 1 00.0 ,

"rel_ Se lf Co ns um pt io n" : 0 .6 74 65 06 98 60 279347

},

"Version" : "12"

}

"RequestA rg um en ts " : {} ,
"Status" : {

"Code" : 0,
"Reason" : "",
"UserMessage" : ""

},

"Timestamp" : "2019 -08- 28 T09 :4 3: 29 +0 0: 00 "

{

"Body" : {

Listing 60: Reply body for GetPowerFlowRealtimeData on Tauro

"Data" : {

"Inverters" : {

"1" : {

"Battery_Mode " : " disa bl ed ",
"DT" : 1,
"E_Day " : null ,
"E_Total" : 36741974.335000001 ,
"E_Year" : null ,
"P" : 34 60 .2 57 32421875 ,
"SOC " : 0.0

}
},

"Site" : {

"BackupMode " : fals e ,

"BatteryStandby " : f alse ,

"E_Day " : null ,

"E_Total" : 36741974.335000001 ,

"E_Year" : null ,

"Meter_Location " : " unknow n",

"Mode" : "produce - on ly ",

"P_Akku" : null ,

"P_Grid" : null ,

"P_Load" : null ,

"P_PV" : 5671.977050781 25 ,

"rel_Autonomy " : null ,

"rel_ Se lf Co ns um pt io n" : null

},

"Smartloads " : {

"Ohmpilots" : {}

},

"Version" : "12"

}

71

},

"Head" : {

"RequestA rg um en ts " : {} ,
"Status" : {

"Code" : 0,
"Reason" : "",
"UserMessage" : ""

},

"Timestamp" : "2021 -10- 14 T13 :0 4: 00 +0 0: 00 "

}

}

+ Energies are not provided and device types DT are invalid on GEN24/Tauro

5 Archive Requests

5.1 Common

Archive requests shall be provided whenever access to historic devicedata is possible and it makes sense to
provide such a request.
Of course, the Datalogger Web can only provide what is stored in its internal memory and has not been overwritten
by newer data yet. It can loose data, due to capacity reason. The number of days stored is dependent on the
number of connected units to log. This limitation is not present for Solar.web, provided that the Datalogger has
reliably uploaded the data.

Different from what is specified within the previously released drafts, there is only one CGI to access all historic

data. This CGI contains detailed, summed, error and events queries.

Call is http://<insert hostname or IP here>/solar_api/v1/GetArchiveData.cgi?<your query parameters>

The number of parallel queries is system wide restricted to 4 clients.

5.1.1 Availability

Platform Since version
Fronius Hybrid 1.1.216
Fronius Non Hybrid 3.3.45
Fronius GEN24/Tauro NEVER

+ GEN24/Tauro does not provide access to history data

+ On days where daylight saving time is changing (begin or end of summertime) a few problems are

known regarding time calculation.

5.1.2 ChannelId

Each channel is handled and requested by name. Most of the channels are recorded in constant cyclic intervals
which can be set between 5 and 30 minutes. Only Digital_PowerM anagementRelay_Out_∗, I nverterErrors,
InverterEvents and Hybrid_Operating_State are event triggered and may occure every time.

5

5

introduced in Solar API CompatibilityRange Version 1.510 (Datamanager 3.11.1 or Hybridmanager 1.9.1)

72

Table 5: Available channels

Name Unit
TimeSpanInSec sec

EnergyReal_WAC_Sum_Produced Wh
EnergyReal_WAC_Sum_Consumed

5

Wh
InverterEvents struct
InverterErrors struct
Current_DC_String_1 1A
Current_DC_String_2 1A
Voltage_DC_String_1 1V
Voltage_DC_String_2 1V
Temperature_Powerstage deg C
Voltage_AC_Phase_1 1V
Voltage_AC_Phase_2 1V
Voltage_AC_Phase_3 1V
Current_AC_Phase_1 1A
Current_AC_Phase_2 1A
Current_AC_Phase_3 1A
PowerReal_PAC_Sum 1W

EnergyReal_WAC_Minus_Absolute 1Wh
EnergyReal_WAC_Plus_Absolute 1Wh
Meter_Location_Current 1

Temperature_Channel_1 1
Temperature_Channel_2 1
Digital_Channel_1 1
Digital_Channel_2 1
Radiation 1

Digital_PowerManagementRelay_Out_1 1
Digital_PowerManagementRelay_Out_2 1
Digital_PowerManagementRelay_Out_3 1
Digital_PowerManagementRelay_Out_4 1
Hybrid_Operating_State 1

73

5.1.3 Parameters

Scope String ”Device”

”System”

SeriesType String ”DailySum”

Query specific device(s) or whole system.

Mandatory

Resolution of the dataseries. Optional

”Detail” (default)

HumanReadable BoolString ”True” (default)

Unset/Set readable output. Optional

”False”

StartDate DateString ”21.5.[20]14”

”5/21/[20]14”
”[20]14521”

Mandatory

supplying only the date will be interpreted as

local time
”201110
20T10:09:14+02:00”

EndDate DateString ”21.5.[20]14”

Mandatory

”5/21/[20]14”
”[20]14521”
”201110
20T10:09:14Z”

Channel String available channels from table 5. Mandatory, multiple times
DeviceClass String ”Inverter”

”SensorCard”
”StringControl”

DeviceClass ”Meter”

”Storage”
”OhmPilot”

Which kind of device will be queried. Manda

tory and accepted only if Scope is not ”Sys

tem”

since DM 3.7.46 HM 1.3.11

since DM 3.7.46 HM 1.3.11

since DM 3.8.14 HM 1.6.14

DeviceId String Solar Net: 0 …199 Only needed for Scope ”Device”

Which device to query.

This parameter can be given more than once,

thus specifying a list of devices to query.

5.1.4 Object Structure of response body

Listing 61: Object structure of request body

ob je ct {

# Object with d at aseries for each requeste d de vice .
# P roperty names co rr es po nd to the DeviceId the s er ies belongs to .

ob je ct {

# Object representing data - se ri es of one d ev ic e ( may contain m or e than on e c hannel ).

ob je ct {

# O ptional Nodetype if localnet node

in te ge r N od eType;

# O ptional Devicetype if lo ca ln et node

in te ge r D ev ic eT yp e;

# S tarting date of th e series (i.e. d ate of the first value in Values)
# yyyy - MM -ddThh -mm-ss% z "2017 -05-20 T00 :0 0: 00 +0 2: 00 "

st ri ng Start;

# S tarting date of th e series (i.e. d ate of the first value in Values)
# yyyy - MM -ddThh -mm-ss% z "2017 -05-20 T23 :5 9: 59 +0 2: 00 "

st ri ng End;

# C ol lection of obje ct s r ep re se nt in g o ne channel, ea ch object containing valu es and

me ta da ta .

# Objects ar e named af ter the Ch an nel they represent ( e. g. " Powe r").

ob je ct {

# Object representing one ch annel.

74

ob je ct {

# B aseunit of the chan nel, neve r c on ta in s any pr ef ix es

st ri ng Unit ;

# U nscaled valu es , of fs et between data po in ts can be dedu ce d t hr ou gh "SeriesType "
# A TTENTION : U na va il ab le datapoints are in cl uded but h ave value n ull
# NOTE: the data re co rd s are li st ed in a lp ha be ti ca l o rder

# example : "3600" : 10.11 .... offs et is 36 00 se c and va lue is 10 .1 1

nu mb er * _ _O FF SE T_IN_SECONDS__;

# r eference to internal used unique channel id en ti fi er

st ri ng _comment;

} _ _C HA NN EL _N AM E_ _;

}* Data ;

}* __DEVICE_ID__ ;

} Data;

};

5.2 Example of response body

5.2.1 Meter data

Listing 62: detailed response body for meter data

// /solar_api/ v1 /GetArchiveData .cgi? Sc ope= System& St ar tD at e =1 .3 .2 018& EndDate =1.3.2 01 8&

Ch an nel=T im eS pa nI nS ec & Channel= Energ yR ea l_ WA C_Plus_Absolute & Channel=
En ergyReal_WAC_Mi nu s_ Ab so lute& Channe l=M eter_Location_Curre nt

{

"Body" :

{

"Data" :

{

"inverter /1 " :

{

"Data" :

{

"TimeSpanInSec" :

{

"Unit" : "sec ",
"Values" :

{

"0" : 2 98 , /* 0 s ec on ds after " Star t" the value w as 29 8 */
"10200 " : 299,

/* shorten l ist for re ad ab il it y */

"1200" : 300,

/* shorten l ist for re ad ab il it y */

"12000 " : 300,

/* shorten l ist for re ad ab il it y */

"2100" : 300,

/* shorten l ist for re ad ab il it y */

"900 " : 299,
"9000" : 300,
"9300" : 299,
"9600" : 299,

"9900" : 300

},

"_comment " : " ch an ne lId=65549"

}
},

"DeviceType " : 99,
"End " : " 2018 -03 -01T23 :59:59+01:00" ,

75

"NodeType " : 97,
"Start " : "201 8-03 -01 T00:00:00+01:00 "

},

"meter : 15 48 02 58 " :

{

"Data" :

{

"En er gy Re al _W AC_Minus_Abso lu te " :

{

"Unit" : "Wh",
"Values" :

{

"0" : 744657 ,
"10200 " : 74 4657 ,
"10500 " : 74 4657 ,

/* shorten l ist for re ad ab il it y */

"9300" : 7446 57 ,
"9600" : 7446 57 ,

"9900" : 744657

},

"_comment " : " ch an ne lId=167837960 "

},

"Ener gy Re al _W AC_Plus_Absolut e" :

{

"Unit" : "Wh",
"Values" :

{

"0" : 605047 ,

"10200 " : 60 5194 ,

"10500 " : 60 5198 ,

"10800 " : 60 5202 ,

/* shorten l ist for re ad ab il it y */

"9000" : 6051 77 ,

"9300" : 6051 81 ,

"9600" : 6051 85 ,

"9900" : 605190

},

"_comment " : " ch an ne lId=167772424 "

},

"Mete r_ Lo ca ti on _C urrent" :

{

"Unit" : "1",
"Values" :

{

"0" : 0 ,

"10200 " : 0,

"10500 " : 0,

"10800 " : 0,

/* shorten l ist for re ad ab il it y */

"9600" : 0,

"9900" : 0

},

"_comment " : " ch an ne lId=117050390 "

}
},

"End " : " 2018 -03 -01T23 :59:59+01:00" ,
"Start " : "201 8-03 -01 T00:00:00+01:00 "

}

}
},

"Head" :

{

"RequestA rg um en ts " :

{

"Channel" :

[

"TimeSpanInSec",

76

"Ener gy Re al _W AC_Plus_Absolut e",
"Ener gy Re al _W AC_Minus_Abso lu te " ,

"Mete r_ Lo ca ti on _C urrent"

],

"EndDate" : "201 8-03- 01 T2 3:59:59+01:00 ",
"HumanReadable" : "Tru e",
"Scope " : "Syste m",
"SeriesType " : " De ta il ",
"StartDate" : "2018 -03- 01 T00 :0 0: 00 +0 1: 00 "

},

"Status" :

{

"Code" : 0,
"ErrorDetail" :

{

"Nodes " : []

},

"Reason" : "",
"UserMessage" : ""

},

"Timestamp" : "2018 -03- 02 T07 :5 7: 54 +0 1: 00 "

}

}

5.2.2 Inverter data

Listing 63: detailed response body with multiple inverters

// /solar_api/ v1 /GetArchiveData .cgi? Sc ope= System& St ar tD at e =1 .3 .2 018& EndDate =1.3.2 01 8&

Ch an nel=E ne rg yR ea l_WAC_Sum_Produ ce d&C ha nnel =En er gy Re al _W AC_Sum_Consumed

{

"Body" :

{

"Data" :

{

"inverter /24" :

{

"Data" :

{

"Ener gy Re al _W AC_Sum_Produced " :

{

"Unit" : "Wh",
"Values" :

{

"39900 " : 457831.954 72 22 22 23 ,
"40200 " : 316.860277 77 77 77 75 ,
"40500 " : 350.181666 66 66 66 67 ,
"40800 " : 357.113055 55 55 55 55 ,
"41100 " : 330.606111 11 11 11 09 ,

/* shorten l ist for re ad ab il it y */

"85800 " : 0,

"86100 " : 0

},

"_comment " : " ch an ne lId=67830024"

}
},

"DeviceType " : 192,
"End " : " 2018 -03 -01T23 :59:59+01:00" ,
"NodeType " : 120,
"Start " : "201 8-03 -01 T00:00:00+01:00 "

},

"inverter /25" :

{

"Data" :

77

{

"Ener gy Re al _W AC_Sum_Produced " :

{

"Unit" : "Wh",
"Values" :

{

"39900 " : 319.235555 55 55 55 55 ,

/* shorten l ist for re ad ab il it y */

"85200 " : 0,
"85500 " : 0,
"85800 " : 0,

"86100 " : 0

},

"_comment " : " ch an ne lId=67830024"

}
},

"DeviceType " : 192,
"End " : " 2018 -03 -01T23 :59:59+01:00" ,
"NodeType " : 121,
"Start " : "201 8-03 -01 T00:00:00+01:00 "

}

}
},

"Head" :

{

"RequestA rg um en ts " :

{

"Channel" :

[

"Ener gy Re al _W AC_Sum_Produced ",

"Ener gy Re al _W AC_Sum_Consumed "

],

"EndDate" : "201 8-03- 01 T2 3:59:59+01:00 ",
"HumanReadable" : "Tru e",
"Scope " : "Syste m",
"SeriesType " : " De ta il ",
"StartDate" : "2018 -03- 01 T00 :0 0: 00 +0 1: 00 "

},

"Status" :

{

"Code" : 0,
"ErrorDetail" :

{

"Nodes " : []

},

"Reason" : "",
"UserMessage" : ""

},

"Timestamp" : "2018 -03- 02 T09 :4 9: 51 +0 1: 00 "

}

}

5.2.3 Errors  Structure

Listing 64: Example of response body for inverter errors

// /solar_api/ v1 /GetArchiveData .cgi? Sc ope= System& St ar tD at e =1 .3 .2 018& EndDate =2.3.2 01 8&

Ch an nel=I nv er te rE rr or s

{

"Body": {

"Data": {

"inverter /1 ": {

"Data": {

"InverterErrors ": {

"Unit": " Obje ct ",

78

"Values": { /* alphabetic sorted list of time o ffsets */

"123180" : { /* 123180 s econds afte r " St art" */

"flags " : [ "fatal" ," official " ] ,

"#" : 7 31 /* Erro r C ode 731 */

},

"123240" : {

"flags " : [ "fatal" , "official "] ,

"#" : 7 66

},

"23240 " : {

"flags " : [ "fatal" , "official "] ,

"#" : 4 82

}

},

"_comment ": "channelId=16 64 61 44 "

}
},

"DeviceType ": 99 ,
"End ": "2018-03 -02 T23:59:59+01:00 ",
"NodeType ": 97 ,
"Start ": "201 8-03 -01 T00:00:00+01:00 "

}

}
},

"Head": {

"RequestA rg um en ts ": {

"Channel" : [

"InverterErrors "

],

"EndDate" : "201 8-03- 02 T2 3:59:59+01:00 ",
"HumanReadable": " True ",
"Scope ": "Syste m",
"SeriesType ": "Detail",
"StartDate" : "2018 -03- 01 T00 :0 0: 00 +0 1: 00 "

},

"Status": {

"Code": 0 ,
"ErrorDetail" : {

"Nodes ": []

},

"Reason": " ",
"UserMessage" : ""

},

"Timestamp" : "2018 -03- 02 T11 :3 2: 22 +0 1: 00 "

}

}

5.2.4 Events  Structure

Listing 65: Example of response body for inverter events

// /solar_api/ v1 /GetArchiveData .cgi? Sc ope= System& St ar tD at e =2 .3 .2 018& EndDate =2.3.2 01 8&

Ch an nel=I nv er te rE ve nt s

{

"Body" :

{

"Data" :

{

"broadcast/ " :

{

"Data" :

{

"InverterEvents " :

{

"Unit" : "Object",

79

"Values" :

{

"42060 " : /* seco nd s a fter "Start " */

{

"#" : 3 , /* Ev ent Code 3 */
"attr" : /* Event Specific Data */

{

"Power " : "20 [%]",
"Radient" : "255 [1]" ,

"affect" : "P"

},

"desc" : "Power li mi ta ti on 20%" , /* Even t De sc ri pt io n */
"flags " :

[

"send"

]

}
},

"_comment " : " ch an ne lId=16711680"

}
},

"End " : " 2018 -03 -02T23 :59:59+01:00" ,
"Start " : "201 8-03 -02 T00:00:00+01:00 "

}

}
},

"Head" :

{

"RequestA rg um en ts " :

{

"Channel" :

[

"InverterEvents "

],

"EndDate" : "201 8-03- 02 T2 3:59:59+01:00 ",
"HumanReadable" : "Tru e",
"Scope " : "Syste m",
"SeriesType " : " De ta il ",
"StartDate" : "2018 -03- 02 T00 :0 0: 00 +0 1: 00 "

},

"Status" :

{

"Code" : 0,
"ErrorDetail" :

{

"Nodes " : []

},

"Reason" : "",
"UserMessage" : ""

},

"Timestamp" : "2018 -03- 02 T11 :4 2: 50 +0 1: 00 "

}

}

5.2.5 OhmPilot Energy

OhmPilot uses total energy counter!

Listing 66: detailed response body for one OhmPilot

// /solar_api/ v1 /GetArchiveData .cgi? Sc ope= Device& De vi ce Cl as s=O hm Pi lo t&D eviceId=0& StartDate

=6 .3 .2 01 8& E ndDate =6.3.2018&Cha nn el = En er gy Real_WAC_Sum_Co ns um ed

{

"Body" :

{

80

"Data" :

{

"ohmpilot :281 36 34 4" :

{

"Data" :

{

"Ener gy Re al _W AC_Sum_Consumed " :

{

"Unit" : "Wh",
"Values" :

{

"0" : 858547 ,
"10200 " : 85 8547 ,
"10500 " : 85 8547 ,
"10800 " : 85 8547 ,
"11100 " : 85 8547 ,
"11400 " : 85 8547 ,
"11700 " : 85 8547 ,
"1200" : 8585 47 ,
"12000 " : 85 8547 ,

/* shorten l ist for re ad ab il it y */

"84000 " : 86 7084 ,
"84300 " : 86 7085 ,
"84600 " : 86 7087 ,
"84900 " : 86 7089 ,
"85200 " : 86 7091 ,
"85500 " : 86 7093 ,
"85800 " : 86 7095 ,
"86100 " : 86 7097 ,
"8700" : 8585 47 ,
"900 " : 858547 ,
"9000" : 8585 47 ,
"9300" : 8585 47 ,
"9600" : 8585 47 ,

"9900" : 858547

},

"_comment " : " ch an ne lId=67895560"

}
},

"End " : " 2018 -03 -06T23 :59:59+01:00" ,
"Start " : "201 8-03 -06 T00:00:00+01:00 "

}

}
},

"Head" :

{

"RequestA rg um en ts " :

{

"Channel" :

[

"Ener gy Re al _W AC_Sum_Consumed "

],

"DeviceClass" : " Oh mPilot ",
"DeviceId " : "0" ,
"EndDate" : "201 8-03- 06 T2 3:59:59+01:00 ",
"HumanReadable" : "Tru e",
"Scope " : "Devic e",
"SeriesType " : " De ta il ",
"StartDate" : "2018 -03- 06 T00 :0 0: 00 +0 1: 00 "

},

"Status" :

{

"Code" : 0,
"ErrorDetail" :

{

"Nodes " : []

},

81

"Reason" : "",
"UserMessage" : ""

},

"Timestamp" : "2018 -03- 07 T10 :2 8: 39 +0 1: 00 "

}

}

6 Definitions and Mappings

6.1 Sunspec State Mapping

Table 6: Shows mapping between Fronius device status and SunSpec InverterModel states

Fronius device state SunSpec device state
not used I_STATUS_OFF

not used I_STATUS_SLEEPING
not used I_STATUS_THROTTLED
not used I_STATUS_SHUTTING_DOWN
10 I_STATUS_FAULT
8 I_STATUS_STANDBY
7 I_STATUS_MPPT
others I_STATUS_STARTING

6.2 Inverter Device Type List

DeviceType Model Name
1 any Fronius GEN24/Tauro
67 Fronius Primo 15.01 208240
68 Fronius Primo 12.51 208240
69 Fronius Primo 11.41 208240
70 Fronius Primo 10.01 208240
71 Fronius Symo 15.03 208
72 Fronius Eco 27.03S
73 Fronius Eco 25.03S
75 Fronius Primo 6.01
76 Fronius Primo 5.01
77 Fronius Primo 4.61
78 Fronius Primo 4.01
79 Fronius Primo 3.61
80 Fronius Primo 3.51
81 Fronius Primo 3.01
82 Fronius Symo Hybrid 4.03S
83 Fronius Symo Hybrid 3.03S
84 Fronius IG Plus 120 V1
85 Fronius Primo 3.81 208240
86 Fronius Primo 5.01 208240
87 Fronius Primo 6.01 208240
88 Fronius Primo 7.61 208240
89 Fronius Symo 24.03 USA Dummy
90 Fronius Symo 24.03 480
91 Fronius Symo 22.73 480
92 Fronius Symo 20.03 480
93 Fronius Symo 17.53 480
94 Fronius Symo 15.03 480
95 Fronius Symo 12.53 480

82

96 Fronius Symo 10.03 480
97 Fronius Symo 12.03 208240
98 Fronius Symo 10.03 208240
99 Fronius Symo Hybrid 5.03S
100 Fronius Primo 8.21 Dummy
101 Fronius Primo 8.21 208240
102 Fronius Primo 8.21
103 Fronius Agilo TL 360.03
104 Fronius Agilo TL 460.03
105 Fronius Symo 7.03M
106 Fronius Galvo 3.11 208240
107 Fronius Galvo 2.51 208240
108 Fronius Galvo 2.01 208240
109 Fronius Galvo 1.51 208240
110 Fronius Symo 6.03M
111 Fronius Symo 4.53M
112 Fronius Symo 3.73M
113 Fronius Symo 3.03M
114 Fronius Symo 17.53M
115 Fronius Symo 15.03M
116 Fronius Agilo 75.03 Outdoor
117 Fronius Agilo 100.03 Outdoor
118 Fronius IG Plus 55 V1
119 Fronius IG Plus 55 V2
120 Fronius Symo 20.03 Dummy
121 Fronius Symo 20.03M
122 Fronius Symo 5.03M
123 Fronius Symo 8.23M
124 Fronius Symo 6.73M
125 Fronius Symo 5.53M
126 Fronius Symo 4.53S
127 Fronius Symo 3.73S
128 Fronius IG Plus 60 V2
129 Fronius IG Plus 60 V1
130 SPR 8001F3 EU
131 Fronius IG Plus 25 V1
132 Fronius IG Plus 100 V3
133 Fronius Agilo 100.03
134 SPR 3001F1 EU
135 Fronius IG Plus V/A 10.03 Delta
136 Fronius IG 50
137 Fronius IG Plus 30 V1
138 SPR11401f1 UNI
139 SPR12001f3 WYE277
140 SPR11401f3 Delta
141 SPR10001f1 UNI
142 SPR7501f1 UNI
143 SPR6501f1 UNI
144 SPR3801f1 UNI
145 SPR3301f1 UNI
146 SPR 12001F3 EU
147 SPR 10001F3 EU
148 SPR 8001F2 EU
149 SPR 6501F2 EU
150 SPR 4001F1 EU
151 SPR 3501F1 EU
152 Fronius CL 60.0 WYE277 Dummy
153 Fronius CL 55.5 Delta Dummy
154 Fronius CL 60.0 Dummy

83

155 Fronius IG Plus V 12.03 Dummy
156 Fronius IG Plus V 7.51 Dummy
157 Fronius IG Plus V 3.81 Dummy
158 Fronius IG Plus 150 V3 Dummy
159 Fronius IG Plus 100 V2 Dummy
160 Fronius IG Plus 50 V1 Dummy
161 Fronius IG Plus V/A 12.03 WYE
162 Fronius IG Plus V/A 11.43 Delta
163 Fronius IG Plus V/A 11.41 UNI
164 Fronius IG Plus V/A 10.01 UNI
165 Fronius IG Plus V/A 7.51 UNI
166 Fronius IG Plus V/A 6.01 UNI
167 Fronius IG Plus V/A 5.01 UNI
168 Fronius IG Plus V/A 3.81 UNI
169 Fronius IG Plus V/A 3.01 UNI
170 Fronius IG Plus 150 V3
171 Fronius IG Plus 120 V3
172 Fronius IG Plus 100 V2
173 Fronius IG Plus 100 V1
174 Fronius IG Plus 70 V2
175 Fronius IG Plus 70 V1
176 Fronius IG Plus 50 V1
177 Fronius IG Plus 35 V1
178 SPR 11400f3 208/240
179 SPR 12000f277
180 SPR 10000f
181 SPR 10000F EU
182 Fronius CL 33.3 Delta
183 Fronius CL 44.4 Delta
184 Fronius CL 55.5 Delta
185 Fronius CL 36.0 WYE277
186 Fronius CL 48.0 WYE277
187 Fronius CL 60.0 WYE277
188 Fronius CL 36.0
189 Fronius CL 48.0
190 Fronius IG TL 3.0
191 Fronius IG TL 4.0
192 Fronius IG TL 5.0
193 Fronius IG TL 3.6
194 Fronius IG TL Dummy
195 Fronius IG TL 4.6
196 SPR 12000F EU
197 SPR 8000F EU
198 SPR 6500F EU
199 SPR 4000F EU
200 SPR 3300F EU
201 Fronius CL 60.0
202 SPR 12000f
203 SPR 8000f
204 SPR 6500f
205 SPR 4000f
206 SPR 3300f
207 Fronius IG Plus 12.03 WYE277
208 Fronius IG Plus 50
209 Fronius IG Plus 100
210 Fronius IG Plus 100
211 Fronius IG Plus 150
212 Fronius IG Plus 35
213 Fronius IG Plus 70

84

214 Fronius IG Plus 70
215 Fronius IG Plus 120
216 Fronius IG Plus 3.01 UNI
217 Fronius IG Plus 3.81 UNI
218 Fronius IG Plus 5.01 UNI
219 Fronius IG Plus 6.01 UNI
220 Fronius IG Plus 7.51 UNI
221 Fronius IG Plus 10.01 UNI
222 Fronius IG Plus 11.41 UNI
223 Fronius IG Plus 11.43 Delta
224 Fronius Galvo 3.01
225 Fronius Galvo 2.51
226 Fronius Galvo 2.01
227 Fronius IG 4500LV
228 Fronius Galvo 1.51
229 Fronius IG 2500LV
230 Fronius Agilo 75.03
231 Fronius Agilo 100.03 Dummy
232 Fronius Symo 10.03M
233 Fronius Symo 12.53M
234 Fronius IG 5100
235 Fronius IG 4000
236 Fronius Symo 8.23M Dummy
237 Fronius IG 3000
238 Fronius IG 2000
239 Fronius Galvo 3.11 Dummy
240 Fronius IG Plus 80 V3
241 Fronius IG Plus 60 V3
242 Fronius IG Plus 55 V3
243 Fronius IG 60 ADV
244 Fronius IG 500
245 Fronius IG 400
246 Fronius IG 300
247 Fronius Symo 3.03S
248 Fronius Galvo 3.11
249 Fronius IG 60 HV
250 Fronius IG 40
251 Fronius IG 30 Dummy
252 Fronius IG 30
253 Fronius IG 20
254 Fronius IG 15

6.3 Event Table for Fronius Devices

Event Code Description
1 System offset
2 Calibrate factor
3 Power control commands
4 Gradual Voltage dependend Power Reduction
5 Frequency Limit Change
6 Enter Backup Power Mode
7 Leave Backup Power Mode
8 Critical SOC reached within backmode
9 Component Specific StateCode
10 Calibration Suspension enabled
11 Datamanager reboot due to malfunction

85

6.4 Hybrid_Operating_State

Hybrid_Operating_State Description
0 disabled
1 normal
2 service
3 charge boost
4 nearly depleted
5 suspended
6 calibrate
7 grid support
8 deplete recovery
9 non operable ( temperature )
10 non operable ( voltage )
11 preheating
12 startup
13 until Hybrid 1.13.1: awake but non operable ( temperature )

since Hybrid 1.13.1: stopped ( temperature )

14 battery full

6.5 Meter Locations

Meter Location Description
0 Load
1 Grid
2 RESERVED
3 additional A.C. generator (generation only)
4 additional A.C. generator providing a battery (consumption and generation)
5255 RESERVED
256511 Sub Load

7 Changelog

Document Version 18

• fixed dead reference to online manual under section 4.10.4

• Tauro behaves ident to GEN24. Added Tauro examples.

• Added GEN24/Tauro devicetype 1 to table.

• Adding four MPPT tracker IDC/UDC entries to GEN24 Symo GetInverterRealtimeData CommonInver
terData example.

Document Version 17

• Fixed description about PowerFlow version attribute which is infact a number within a string.

• Updated details about GetInverterRealtime DataCollections at Gen24 and Symo Hybrid.

• Adding chapter explaining enabling/disabling of Solar API (3).

• Reediting meter model descriptions at GetMeterRealtimeData. TS and UL Meter have signed current.

Document Version 16

• Timing constraints for archive requests updated (2.6).

• Update json example of request GetInverterRealtimeData and collection 3PInverterData for GEN24.

• Value T_Ambient in GetInverterRealtimeData is only supported by few devices (added listing).

• Added meter location dependend direction table for energies and powers (4.8.6)

• GEN24 Inverter will only provide total energy counters in 1.14 or later (no year and day values anymore)

• GEN24 provide swagger open api interface specification file (2.2.1)

Document Version 15

86

• Timing constraints for Realtime Requests added (2.6).

• Carlo Gavazzi meter devices added (4.8).

Document Version 14

• PowerFlowRealtimeData battery state 14 ”battery full” added

• Flag inverter energies within realtime requests as imprecise

Document Version 13

• description for Fronius GEN24 added.

• updated and added missing json examples

• added inverter device type list in section 6.2

• PowerFlowRealtimeData provides data of secondary meters

• added GetStorageRealtime example for LGChem and BYD BBox

• NOTE: manufacturer changed for Solar Battery at GetStorageRealtimeData.cgi

• PowerFlowRealtimeData battery state 13 ”stopped (temperature)” added

• Inverter energy is AC related

• PowerFlowRealtimeData battery soc changed from nondecimal to decimal on demand (support both)

• PowerFlowRealtimeData introduced component identifier field CID

• added meter location table in section 6.5

Document Version 12

• never been published. Changes listed at version 13

Document Version 11

• NOTE: DefaultLanguage at GetLoggerInfo will be removed soon

Document Version 10

• note that all inverters (even invisible configured) are reportet at PowerFlow and Inverter request

• fixed description about availability of rel_Autonomy and rel_SelfConsumption at PowerFlow request

• fixed missing description of BatteryStandby at PowerFlow request

• improved and fixed GetArchiveData descriptions and examples

Document Version 9

• Battery_Mode at PowerFlowRealtimeData got more states

• fixed GetLoggerLEDInfo.cgi example

• added meter location state ”unknown” while backup power is active

• placed notification to use httpget request (refer to section 2.4)

• added Smartloads/OhmPilot node at PowerFlowRealtimeData.fcgi

• added description about PowerFlowRealtimeData versioning

• described Status_BatteryC ell for Controller of Tesla at GetStorageRealtimeData.cgi

• added Status_Battery description for Tesla at GetStorageRealtimeData.cgi

• GetInverterRealtimeData PAC type changed from unsigned to signed integer

• added channel names for Sensor Card (refer to table 5)

• added description of field DeliveryFactor at GetLoggerInfo and updated example

• fixed description of GetInverterInfo: properties ’Show’ and ’CustomName’ have been mandatory since
Version 3.0.3

• added GetOhmPilotRealtimeData.cgi

• added description of all possible Error Codes

• intodruced Solar API ”Compatibility Range” at GetAPIVersion.cgi

87

• fixed description of datatypes

cgi Field old description fixed description
GetAPIVersion.cgi APIVersion number unsigned integer

GetInverterInfo.cgi Body.Data.<>...

GetInverterRealtimeData.cgi Body.Data...

15th Septemper 2016

• fixed availability notes of GetInverterRealtimeData

• OhmPilot is listed too

• added battery status description

• added description for energies at GetPowerFlowRealtimeData

11th February 2016

• fixed availability of request GetPowerFlowRealtimeData

number integer
...ErrorCode
...StatusCode
Body.Data.<>.Show number unsigned integer

unsigned int unsigned number
...DAY_ENERGY
...YEAR_ENERGY
...TOTAL_ENERGY

13th August 2015

• Added realtime request GetPowerFlowRealtimeData to api

10th July 2015

• Added realtime request GetStorageRealtimeData to api

1st June 2015

• Minor documentation update.

GetLoggerLedInfo.cgi added ”alternating” led state (timeout of access point)
GetArchiveData.cgi revised data queries and responses

8 Frequently asked questions

1. The application I wrote for the Fronius Datalogger Web does not work with the Fronius Datamanager.

Why is that?

This is because we had to make some changes in the API to ensure compatibility with future devices.
Specifically the DeviceIndex parameter is now named DeviceId and the request URLs have been changed
to include an API version. For further details please refer to the latest version of the API specs.

2. Which data can I get?
Currently only realtime data from inverters, Fronius Sensor Cards and Fronius String Controls. Also some
information about the logging device itself is available.
Please refer to the API specs for further details.

3. Can multiple clients send requests to the API at the same time?
Yes, but the requests may take longer to complete.

4. Can I use this API at the same time as other services of the Datalogger Web / DataManager?
Yes. The datalogging, Solar.access/Solar.web connection, Webinterface, this API or any other service can
be used independently from the others.

5. Can the API calls be password protected?
No. The API is always accessible without authentication, regardless of the user or admin password set on
the Webinterface.

88

6. The API reports more inverters than I have, why is that?
This may be the case when the inverter number of an inverter is changed while the Fronius Datalogger Web
/ Fronius Datamanager is running. The logger then detects a new device but keeps the same device with
the previous inverter number in the system for 24 hours. This is due to the fact that the datalogger is caching
the devices for a certain time even if they are not present on the bus (e.g. to be able to display energy values
during the night when the inverters are offline).
Those ghost devices will disappear 24 hours after the have been last seen by the datalogger. Alternatively,
a reboot of the datalogger also clears the device cache and repopulates it with the currently present devices.

89

Fronius Worldwide  www.fronius.com/addresses

Fronius International GmbH

4600 Wels, Froniusplatz 1, Austria
EMail: pv[e-mail]

http://www.fronius.com

Under http://www.fronius.com/addresses you will find all addresses of our sales branches and partner firms!

Fronius USA LLC Solar Electronics Division

6797 Fronius Drive, Portage, IN 46368
EMail: pv[e-mail]

http://www.froniususa.com

90
