Operating
Instructions
Fronius Smart Meter TS 65A-3
Operating Instructions
EN
42,0426,0349,EN 013-25052022
Contents
Safety rules 5
Safety rules 7
Explanation of safety notices 7
General 7
Environmental conditions 8
Qualified personnel 8
Copyright 8
Data protection 8
General information 9
Fronius Smart Meter TS 65A-3 11
Device description 11
Information on the device 12
Intended use 12
Scope of supply 13
Positioning 13
Installation 15
Installation 17
Checklist for installation 17
Installation 17
Protective circuit 17
Cabling 18
Fitting the protective cover for the terminals 19
Connecting the data communication cable to the inverter 19
Terminating resistors - Explanation of symbols 20
Connecting the terminating resistor 21
Terminating resistors 21
Mounting the connection cover 22
Multi-meter system - Explanation of symbols 23
Modbus participants - Fronius SnapInverter 24
Multi-meter system - Fronius SnapINverter 24
Modbus participants - Fronius GEN24 25
Multi-meter system - Fronius GEN24 inverter 26
Menu - Measured variables 27
Configuration menu - structure and parameters 30
Setting the address on the Fronius Smart Meter TS 31
EN
Start-up 33
Fronius SnapINverter 35
General 35
Connecting to the Fronius Datamanager 35
Configuring the Fronius Smart Meter TS as the primary meter 35
Configuring the Fronius Smart Meter TS as a secondary meter 36
Fronius GEN24 inverter 37
General 37
Installation using the web browser 37
Configuring the Fronius Smart Meter TS as the primary meter 38
Configuring the Fronius Smart Meter TS as a secondary meter 38
Technical data 40
Technical data 40
Fronius manufacturer's warranty 41
3
4
Safety rules
5
6
Safety rules
EN
Explanation of
safety notices
DANGER!
Indicates immediate danger.
If not avoided, death or serious injury will result.
▶
WARNING!
Indicates a potentially hazardous situation.
If not avoided, death or serious injury may result.
▶
CAUTION!
Indicates a situation where damage or injury could occur.
If not avoided, minor injury and/or damage to property may result.
▶
NOTE!
Indicates a risk of flawed results and possible damage to the equipment.
General The device has been manufactured in line with the state of the art and according
to recognized safety standards. If used incorrectly or misused, however, it can
cause:
Injury or death to the operator or a third party
-
Damage to the device and other material assets belonging to the operating
-
company.
All personnel involved in commissioning, maintenance, and servicing of the
device must:
Be suitably qualified
-
Have knowledge of and experience in dealing with electrical installations and
-
Have fully read and precisely followed these Operating Instructions
-
The Operating Instructions must always be at hand wherever the device is being
used. In addition to the Operating Instructions, attention must also be paid to
any generally applicable and local regulations regarding accident prevention and
environmental protection.
All safety and danger notices on the device:
Must be kept in a legible state
-
Must not be damaged
-
Must not be removed
-
Must not be covered, pasted or painted over
-
The terminals can reach high temperatures.
Only operate the device when all protection devices are fully functional. If the
protection devices are not fully functional, there is a danger of:
Injury or death to the operator or a third party
-
Damage to the device and other material assets belonging to the operating
-
company
7
Any safety devices that are not fully functional must be repaired by an authorised specialist before the device is switched on.
Never bypass or disable protection devices.
For the location of the safety and danger notices on the device, refer to the section headed "General remarks" in the Operating Instructions for the device.
Any equipment malfunctions which might impair safety must be remedied before
the device is turned on.
This is for your personal safety!
Environmental
conditions
Qualified personnel
Operation or storage of the device outside the stipulated area will be deemed as
not in accordance with the intended purpose. The manufacturer accepts no liability for any damage resulting from improper use.
The servicing information contained in these operating instructions is intended
only for the use of qualified service engineers. An electric shock can be fatal. Do
not carry out any actions other than those described in the documentation. This
also applies to qualified personnel.
All cables and leads must be secured, undamaged, insulated and adequately dimensioned. Loose connections, scorched, damaged or inadequately dimensioned
cables and leads must be immediately repaired by authorised personnel.
Maintenance and repair work must only be carried out by an authorised specialist.
It is impossible to guarantee that bought-in parts are designed and manufactured to meet the demands made on them, or that they satisfy safety requirements. Use only original spare parts (also applies to standard parts).
Do not carry out any alterations, installations, or modifications to the device
without first obtaining the manufacturer's permission.
Components that are not in perfect condition must be changed immediately.
Copyright Copyright of these operating instructions remains with the manufacturer.
The text and illustrations are all technically correct at the time of printing. We
reserve the right to make changes. The contents of the operating instructions
shall not provide the basis for any claims whatsoever on the part of the purchaser. If you have any suggestions for improvement, or can point out any mistakes that you have found in the instructions, we will be most grateful for your
comments.
Data protection The user is responsible for the safekeeping of any changes made to the factory
settings. The manufacturer accepts no liability for any deleted personal settings.
8
General information
9
10
Fronius Smart Meter TS 65A-3
EN
Device description
The Fronius Smart Meter TS is a bidirectional electricity meter which optimises
self-consumption and records the household's load curve. In conjunction with
the Fronius inverter, Fronius Datamanager and Fronius data interface, the Fronius Smart Meter TS provides a clear overview of a user's own power consumption.
The meter measures the power flow to the loads or to the grid and forwards the
information via the Modbus RTU/RS485 communication to the Fronius inverter
and the Fronius Datamanager.
CAUTION!
Observe and follow safety instructions!
Failure to observe the safety instructions will result in damage to personnel and
equipment.
Switch off the power supply before establishing a mains connection.
▶
Observe the safety instructions.
▶
11
Information on
the device
Technical data, markings and safety symbols are located on the Fronius Smart
Meter TS. These must NOT be removed or painted over. They warn against incorrect operation which can lead to serious injury and damage.
Markings:
The devices comply with all the requisite and relevant standards and
guidelines that form part of the relevant EU Directive, and are therefore
permitted to display the CE mark.
Insulated (protection class II)
Regulatory Compliance Mark (RCM)
Complies with all applicable regulatory requirements in Australia and
New Zealand regarding safety and electromagnetic compatibility, as
well as specific requirements for radio equipment.
To comply with European Directive 2012/19/EU on Waste Electrical and
Electronic Equipment and its implementation as national law, electrical
equipment that has reached the end of its life must be collected separately and returned to an approved recycling facility. Any device that you
no longer require must be returned to your distributor or disposed of at
an approved collection and recycling facility in your area. Ignoring this
European Directive may have potentially adverse effects on the environment and your health!
RoHS (Restriction of Hazardous Substances)
The limited use of certain hazardous substances in electrical and electronic equipment has been complied with in accordance with EU Directive 2011/65/EU.
Safety symbols:
Danger of serious injury and property damage due to incorrect operation.
Dangerous electrical voltage.
Intended use The Fronius Smart Meter TS is a fixed piece of equipment for public grids of
TN/TT systems and records self-consumption and/or individual loads in the system. The Fronius Smart Meter TS is required for systems with a battery storage
12
system and/or a Fronius Ohmpilot installed for communication between the individual components. The installation is carried out on an indoor DIN rail with corresponding back-up fuses, which are adapted to the cable cross-sections of the
copper conductors and to the maximum current of the meter. The Fronius Smart
Meter TS must only be operated in accordance with the specifications in the enclosed documentation and in accordance with local laws, regulations, provisions,
standards and within the limits of technical possibilities. Any use of the product
other than as described in the intended use shall be deemed to be not in accordance with the intended purpose. The available documentation forms part of the
product and must be read, observed and kept in good condition. It must also be
accessible at all times at the place of installation. The available documents do
not replace regional, state, provincial or national laws, or regulations or standards that apply to the installation, electrical safety and use of the product. Fronius International GmbH assumes no responsibility for compliance with or noncompliance with these laws or regulations in connection with the installation of
the product.
Interventions on the Fronius Smart Meter TS, e.g. modifications and alterations,
are not permitted. Unauthorised interventions will void the warranty and warranty claims and, as a rule, void the user's authority to operate the equipment.
The manufacturer shall not be liable for any damage resulting from such use.
Reasonably foreseeable misuse:
The Fronius Smart Meter TS is not suitable for the supply of life-sustaining medical devices or for the billing of subtenants.
EN
Scope of supply
Positioning The Fronius Smart Meter TS can be installed in the following positions in the sys-
tem:
Positioning at the feed-in point:
(1) 2x protective cover
(2) Fronius Smart Meter TS 65A-3
(3) 2x seal wire
(4) 2x connection cover
(5) Quick Start guide
13
Positioning at consumption point:
For use as a secondary meter to measure individual loads and producers, see
chapter Multi-meter system - Fronius SnapINverter on page 24.
14
