VR 1500
VR 1500-11
VR 1500-12
VR 1500-30
Installation instructions
EN
42,0426,0029,EN 003-15102021
Optional “VR 1500 Wirefeeder hose”
(a)
1.
2. / 5.
3.
4.
(b)
(c)
(d)
(e)
EN
Safety
WARNING!
Danger due to work that has been carried out incorrectly.
This can result in severe personal injury and damage to property.
All the work described below must only be carried out by trained and qualified per-
▶
sonnel.
Fully read and understand this document.
▶
Fully read and understand all the Operating Instructions for the system components,
▶
especially the safety rules.
WARNING!
Danger from electric current.
An electric shock can be fatal.
Before opening the device:
▶
Turn the power source mains switch to the "O" position
▶
Unplug the power source from the mains
▶
Put up an easy-to-understand warning sign to stop anybody inadvertently switching
▶
it back on again
Mounting optional “VR 1500
Wirefeeder hose”
(1) Tilt up the optional “VR 1500 cover” (a), if available
(2) Remove the knurled thumb-screw (b)
(3) Remove the wire infeed (c)
(4) Insert the wirefeeder hose (d) into the wire infeed opening (e)
(5) Fix the wirefeeder hose (d) with the knurled thumb-screw (b); the knurled thumb-
screw must slot into the groove of the wirefeeder hose
