Page 1
42,0410,2670 004-10112022
(PzS, GiS, ..):
WARNING! Incorrect operation can cause serious injury and damage. Observe battery manufacturer’s instructions. When parameters are being set, make sure that battery is disconnected from charger.
Overheated battery and high charging voltage can cause serious injury and damage. When using the „formatting“ or „deep discharge“ characteristics, disconnect battery from the vehicle, always supervi-
se the battery and disconnect it from the charger, if a battery temperature of 60 °C (140 °F) is exceeded.
1 IUI - WET IUIoTC X 12-25 [20] 5 X 2.35-2.50 [2.40] X dU/dt X I-Puls, IU-Puls, Uconst, OFF [IU-Puls]
3 IU - WET IUoTC X 12-25 [20] X X 2.35-2.45 [2.40] X dI/dt X I-Puls, IU-Puls, Uconst, OFF [IU-Puls]
Number Name Type Charging Time I1 (A/100Ah) I2 (A/100Ah) I3 (A/100Ah) U1 (V/Cell) Charging Factor Cut-Off Criterion Ch.Fac.Calib. (%) Trickle Charge
Characteristics | Settings
Battery Pb - WET
10 Deep discharge - WET¹ IUIoTC 120 2 X X 2.6 X fi xed time X I-Puls, IU-Puls, Uconst, OFF [IU-Puls]
Battery Pb - CSM - WET (Copper Strained Metal):
31 IUI - CSM - WET IUIoTC X 12-25 [25] 5 X 2.35-2.45 [2.40] X dU/dt X I-Puls, IU-Puls, Uconst, OFF [IU-Puls]
32 Deep discharge - CSM - WET¹ IUIoTC 120 2 X X 2.6 X fi xed time X I-Puls, IU-Puls, Uconst, OFF [IU-Puls]
35 IUI - PzQ - WET IUIoTC X 12-25 [25] 5 X 2.35-2.45 [2.40] X dU/dt X I-Puls, IU-Puls, Uconst, OFF [IU-Puls]
37 Deep discharge - PzQ - WET¹ IUIoTC 120 2 X X 2.6 X fi xed time X I-Puls, IU-Puls, Uconst, OFF [IU-Puls]
Battery Pb - PzQ - WET:
42 TagID guided charging X 5-12 X X X X X intelligent X IU-Puls
Battery Pb - WET (PzS,GiS, ..) | Pb - GEL (PzV, GiV, ..):
Deep discharge .......................................... Use only for deep discharged batteries (Battery voltage below the normal operating range) or reactivation charge
Values in brackets are preset standard values | Valid from CHARGE CONFIG V 1.8.1
1)
Page 2
Serial Number Additional Information:
Item Number:
Main Software Version:
RCS remote indication
Electrolyte circulation Aquamatic
External start/stop Charge fi nish
Charging lights Common error message
Temperature controlled charging Immobiliser
Relay board Main charge fi nished
Option box Battery cooled down
LED strip External air pump
Floor bracket Charge 80 %
Wall bracket Charge in progress
Airfi lter On
Battery
Factory setting for this device:
Name Type Charging Time I1 (A/100Ah) I2 (A/100Ah) I3 (A/100Ah) U1 (V/Cell) Charging Factor Cut-Off Criterion Ch.Fac.Calib. (%) Trickle Charge
Equalisation Charge ON OFF
Options: Confi guration Relay Board or Option Box: Relais 1 Relais 2 Relais 3 Relais 4
„Mobile“ kit Refi ll indicator
InterLock
