SOLAR CELL-STRING OPTIMIZATION
/ Cutting costs while driving performance with Fronius inverters
/ PV system designers often are confronted with a difficult environment. Rooftops with different orientations or partial
shading have to be handled with critical examination. We are convinced that modules will be smart in the future.
Traditional module electronics (e.g. added panel optimizers) are in our opinion, due to their complexity and additional
costs, not future proof. When it comes to real optimization, Maxim Integrated presents a new generation of Optimization
with easy installation, high cost-effectiveness and greatest design flexibility. This perfectly complements and enhances
Fronius’ Design Flexibility.
/ Maxim Integrated offers a solar cell-string optimization technology, which replaces the traditional bypass diode in a
solar module. This means that each module has 3 optimizers, and therefore 3 independent MPPTs – the best-in-class
solution for shade mitigation, string mismatch and soiling. Furthermore reliability is increased by eliminating a potential
source of failure.
Conventional panel
250W
panel optiMiZeR MoDUle
Optimizer
125W
250W
solaR Cell-stRinG optiMiZeR
125W
250W
165W
215W
YoUR BeneFtis
DesiGn FleXiBilitY
/ Fronius offers greatest design flexibility, accommodates multiple orientations, different modules, shading or unsymmetrical
designs. With Maxim Integrated the flexibility is further increased and allows for up to 20% difference in string length on
one input.
/ The tolerance for shading allows for the tightest row spacing in commercial rooftop systems without any limitations.
easY installation
/ A system with Maxim optimization is easy to install – just like any standard system. There are no additional hardware
components to install, no extra settings to make and no communication hassles on the roof.
/ The optimizer replaces bypass diodes and is embedded in the module junction box eliminating the need for any extra
installation steps.
Best peRFoRManCe - HiGHest RetURns
/ Systems show up to 5% more energy harvest compared to traditional optimizers, due to DC optimization on each cell-string
(each module has 3 MPP trackers) and highest optimization efficiency.
/ The Maxim solution is highly cost-effective and offers the most affordable optimization technology on the market - giving
you the highest return on any system.
MaXiM inteGRateD anD FRoniUs
/ Fronius has committed significant engineering resources to work with Maxim
to provide the market with the best-in-class optimization technology.
Go WitH a testeD anD FielD-pRoven inveRteR
/ Fronius SnapINverters (Fronius Eco, Fronius Primo, Fronius Symo) in conjunc-
tion with Fronius Solar.web
/ At Fronius we have always been committed to flexible system design, ease of
installation, and field-servicability. Learn more about our Fronius SnapINverter
family at www.fronius.com
/ To learn more about Maxim Integrated, visit www.maximintegrated.com
