AccuPocket 150/400
Quick reference
Safety
Before carrying out any work with the device, ensure that you have read and understood all the documents provided as well as those
available online! This document does not describe all the functions of the device. For a complete description of the device, refer to
the Operating Instructions!
Welding Settings
Setting values:
Available welding processes:
Arc-force dynamic: 0 - 100 | factory setting = 20
Welding current: 10 - 140 A (STICK), 3 - 150 A (TIG)
SoftStart / HotStart function: 0 - 200% | factory setting = 130%
TIG pulsing (only available with TIG version)
Operating Instructions
MMA welding
i
42,0426,0246,EN
002-21092022
MMA welding with Cel electrode
TIG welding
Reserved for special programs
https://manuals.fronius.com/
html/4204260176
Accessing the setup menu
Setup menu - MMA welding Setup menu - Cel electrodes Setup menu - TIG
Changing welding parameters
Turn and press the adjusting dial to select and change parameters.
Parameters for MMA Welding Parameters for TIG welding
Starting current duration: 0.1 - 1.5 seconds | 0.5 seconds*
Anti-stick: On*/OFF
Break voltage: 25 - 80 V | 45 V*
Software version
Automatic switch-off: 300 - 900* seconds / OFF
Factory setting
Comfort Stop sensitivity: 0.3 - 2.0 V / OFF | 0.5 V*
Break voltage: 12 - 35 V | 15 V*
Software version
Automatic switch-off: 300 - 900* seconds / OFF
Factory setting
*factory setting
