Operating Instructions

Boiler controller Lambdatronic H 3200 T4 - Touch

Version 50.04 - Build 05.09 | Version 60.01 - Build 01.23

Translation of the original German operating instructions for technicians and operators

Read and follow the instructions and safety information!

Technical changes, typographical errors and omissions reserved!

B0820314_en | Edition 24/07/2014

Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

Table of Contents

1 General 6

1.1 About these instructions 6

1.2 Safety information 6

2 Electrical connection and wiring 7

2.1 Core module and connection options 7

2.1.1 Board view 7

Connection instructions

2.1.2 Mains connection 9

2.1.3 Connecting the flue gas sensor 9

2.1.4 Combination with oil burner 10

2.1.5 Connecting the remote control 10

2.1.6 Boiler enable input 11

2.1.7 Connecting a high efficiency pump to the core module 12

2.2 Expansion modules 13

2.2.1 Heating circuit module 13

2.2.2 Hydraulic module 14

Connecting an isolating valve

Connecting a high efficiency pump to the hydraulic module

2.2.3 Wood chip module 17

2.2.4 Digital module 18

2.2.5 Power supply 19

2.2.6 Connecting the bus cable 19

2.2.7 Connect the patch cable to the bus plug 20

2.2.8 Setting end jumpers 20

2.2.9 Setting the module address 21

2.3 Connection diagrams according to pump types 21

3 Overview of the basic functions 23

3.1 Visual display 23

3.1.1 Status LED 23

3.1.2 Control icons 24

3.1.3 Display icons 25

3.2 Operating statuses 26

3.3 Updating the software of the touch control 27

3.4 Calibrating the touchscreen 29

4 Operation 31

4.1 Switching the boiler on/off 31

4.2 Navigation within the info menu 31

4.3 Navigation within the system menu 32

4.3.1 Navigating the menus 32

4.4 Adjusting parameters 34

4.5 Setting times 35

4.6 Setting the date/time 37

4.7 Quick menu 38

Table of Contents

2 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

4.7.1 "Operating level” function 38

4.7.2 "Choose language” function 38

4.7.3 "Chimney sweep” function 38

4.7.4 "Service mode” function 38

4.7.5 "Extra heating” function 38

4.7.6 "Summer op.” function 38

4.7.7 “Mode in automatic mode” function 38

4.7.8 "Extra loading” function 38

4.7.9 "Touch cleaning” function 39

4.8 Boiler modes 39

4.8.1 Explanation of terms 39

4.8.2 Transition op. without storage tank 40

4.8.3 Transition op. with storage tank 41

4.8.4 Winter op. without storage tank 42

4.8.5 Winter op. with storage tank 42

4.8.6 Summer op. without storage tank 43

4.8.7 Summer op. with storage tank 44

4.9 Initial startup 45

4.9.1 Switching user level 45

4.9.2 Setting the system selection 46

Open the system selection menu

Selecting the boiler type

Selecting the feed system

System selection

DHW tank system

Heating system

Solar system

Boiler remote control

4.9.3 Before heating up for the first time 52

Drives

4.9.4 Starting the system on initial startup 53

Feeding fuel into the combustion chamber

Setting parameters

Adjusting the feed output of the feed screw

5 Menu overview and parameters 55

5.1 Menu - Heating 55

5.1.1 Status displays for the heating circuits 56

5.1.2 Temperature settings for the heating circuits 57

5.1.3 Heating times of the heating circuits 58

5.1.4 Service parameters of the heating circuits 58

5.1.5 Service parameters for heating up program 59

Heating up programs

5.1.6 General Settings 62

5.2 Menu - Water 62

5.2.1 Status displays for the DHW tank 63

5.2.2 Temperature settings of the DHW tank 63

5.2.3 Heating times of the DHW tank 64

5.2.4 Service parameters of the DHW tank 64

5.3 Menu - Solar 65

5.3.1 Status displays for the solar system 66

5.3.2 Temperature settings for the solar system 67

5.3.3 Service parameters of the solar system 68

5.3.4 Solar heat meter 70

5.4 Menu - Storage tank 71

Table of Contents

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 3

5.4.1 Status displays of the storage tank 72

5.4.2 Temperature settings for the storage tank 72

5.4.3 Heating times of the storage tank 73

5.4.4 Service parameters of the storage tank 74

5.5 Menu - Boiler 75

5.5.1 Status displays for the boiler 76

5.5.2 Temperature settings for the boiler 77

5.5.3 Heating times of the boiler 78

5.5.4 Service parameters of the boiler 78

5.5.5 General Settings 79

Operator data

5.6 Menu - Boiler 2 80

5.6.1 Status displays for the backup boiler 81

5.6.2 Temperature settings for the backup boiler 81

5.6.3 Service parameters of the backup boiler 82

5.7 Menu - Fuel 83

5.7.1 Service parameters for fuel 84

5.8 Menu - Feed system 84

5.8.1 Stoker screw 85

5.8.2 Feed screw 85

5.8.3 Screw 1 86

5.8.4 Screw 2 86

5.9 Menu - Network pump 87

5.9.1 Network pump status displays 88

5.9.2 Network pump temperature settings 88

5.9.3 Service parameters for the network pump 89

5.10 Menu - Cascade 90

5.10.1 Status displays for the cascade 91

5.10.2 Status display of the cascade backup boiler 91

5.10.3 Temperature settings for the cascade 92

5.10.4 Service parameters of the cascade 92

5.11 Menu - Difference regulator 93

5.11.1 Status displays for the difference regulator 94

5.11.2 Temperature settings for the difference regulator 94

5.11.3 Service parameters for the difference regulator 95

5.12 Menu - Circulation pump 95

5.12.1 Status displays for the circulation pump 96

5.12.2 Temperature settings for the circulation pump 96

5.12.3 Time settings for the circulation pump 97

5.12.4 Service parameters of the circulation pump 97

5.13 Menu - Manual 98

5.13.1 Manual operation 99

5.13.2 Digital outputs 99

5.13.3 Analogue outputs 100

5.13.4 Digital inputs 101

5.14 Menu - System 102

5.14.1 Setting 103

Adjustable parameters: Boiler temperature

103

Adjustable Parameters: Flue Gas

104

Adjustable parameters - Ignition

106

Adjustable Parameters: Air settings

107

Adjustable parameters: Fuel feed

108

Adjustable parameters: WOS / Cleaning

109

Adjustable parameters: Combustion chamber

109

Table of Contents

4 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

Adjustable parameters: Lambda values

110

Adjustable parameters: Lambda values - LSM11 Lambda probe

111

Adjustable parameters: Lambda values – Broadband probe

111

Adjustable parameters: General settings

113

5.14.2 Current values 113

Service hours

115

5.14.3 Sensors and pumps 116

5.14.4 Display operating rights 117

Froeling Connect

118

5.14.5 Display allocation 118

5.14.6 System selection 119

5.15 Menu - Diagnostics 119

5.15.1 Error display 120

5.15.2 Error history 120

5.15.3 Clear error history 121

5.16 Menu - Display settings 121

5.16.1 General 122

Network settings

123

5.16.2 Date / Time 123

5.16.3 Software update / Service 124

5.17 PWM / 0 - 10V settings 124

6 Troubleshooting 126

6.1 Procedure for fault messages 126

7 Setting protocol 128

Table of Contents

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 5

1 General

1.1 About these instructions

Please read and follow the operating instructions, in particular the safety information contained therein. Keep them available next to the boiler.

These operating instructions contain important information about operation, electrical connection and troubleshooting for the

Lambdatronic H 3200 T4 control.

NOTICE

The values given in the parameter lists are examples, and should not be used as standard values!

The constant further development of our products means that there may be minor dif‐ ferences from the pictures and content. If you discover any errors, please let us know.

1.2 Safety information

DANGER

When working on electrical components:

Risk of electrocution!

When work is carried out on electrical components:

❒ Only have work carried out by a qualified electrician ❒ Observe the applicable standards and regulations

➥ Work must not be carried out on electrical components by unauthorised

people

WARNING

When touching hot surfaces:

Severe burns are possible on hot surfaces and the flue gas pipe!

When work is carried out on the boiler:

❒ Shut down the boiler in a controlled way (operating status "Boiler off") and al‐

low it to cool down

❒ Protective gloves must generally be worn for work on the boiler, and it should

only be operated using the handles provided

❒ Insulate the flue pipes or simply avoid touching them during operation.

The information on safety, standards and guidelines in assembly and operating in‐ structions for the boiler should also be observed.

General

About these instructions

6 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

2 Electrical connection and wiring

2.1 Core module and connection options

2.1.1 Board view

Electrical connection and wiring

Core module and connection options

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 7

Connection instructions

Port Cable dimensions / Specifications / Information

Bus (1) Port with cable – LIYCY paired 2x2x0.5;

⇨ See "Connecting the bus cable" [page

19]

❒ Warning! CAN L and CAN H must not be connected to +U

BUS

Bus (2) Patch cable CAT 5 RJ45 SFTP 1:1 configuration; wood chip module connection

Bus (3) Patch cable CAT 5 RJ45 SFTP 1:1 configuration, boiler display port

COM 2 (4) Null modem cable 9-pin SUB-D;

❒

Port can be used as a MODBUS interface

⇨ See "General Settings" [page 79]

COM 1 (5) Null modem cable 9-pin SUB-D;

❒

Service interface for installing new boiler software or port for the visualisation software

Broadband probe (6)

Connection cable1) 5 x 0.75 mm

❒

Connection of a BOSCH or NTK broadband Lambda probe

Primary air (7)

Connection cable1) 5 x 0.75 mm

❒

Primary air flap for T4 90-150

Air flap (8)

Connection cable1) 5 x 0.75 mm

Latch (9)

Connection cable1) 2 x 0.75 mm

High-limit thermostat - STL (10)

EMERGENCY STOP (11)

Connection cable1) 2 x 0.75 mm

❒

Warning! Do not connect the emergency off/emergency stop switch to the power supply cable of the boiler. The switch must be a N/C switch and it must be linked to the 24V safety chain of the STL at this terminal.

Flowmeter FLM (12)

Connection cable1) 2 x 0.75 mm

Lambda probe (13) LSM11 Lambda probe connection

Boiler release (14)

Connection cable1) 2 x 0.75 mm

❒

Warning! The connection must be a floating connection.

Flue gas temperature sensor (15)

Connection cable1) 3 x 0.75 mm

Ash box contact switch (16)

Connection cable1) 2 x 0.75 mm

Sensor 2/1 (17/18)

Connection cable1) 2 x 0.75 mm

Outside temperature sensor (19)

Connection cable1) 2 x 0.75 mm2,shielded from 25m cable length

Room temperature sensor 2/1 (20/21)

Flow temperature sensor 2/1 (22/23)

Return sensor RTS (24)

Connection cable1) 2 x 0.75 mm

Boiler sensor BS (25)

PDM / 0-10V Pump 1 (26)

Induced draught (27)

Connection cable1) 3 x 1.5 mm2, power supply Connection cable1) 3 x 0.75 mm2, analysis of current speed

Pump 1 on core module (28)

Connection cable1) 3 x 1.5 mm2, max. 1.5A / 280W / 230V

Mains (29)

Connection cable 1) 3 x 1.5 mm2; fused with C16A (provided by the customer)

Electrical connection and wiring

Core module and connection options

8 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

Port Cable dimensions / Specifications / Information

Mixing valve 2/1 (30/31)

Connection cable

4 x 0.75 mm2, max. 0.15A / 230V

Heating circuit pump 2/1 (32/33)

Connection cable1) 3 x 1.5 mm2, max. 2.5A / 500W

Heating circuit pump HCP 0 / burn‐ er relay (34)

Connection cable1) 3 x 1.5 mm2, max. 3A / 600VA

(35)

Connection cable1) 2 x 0.75 mm2,

1.YMM as per ÖVE-K41-5 or H05VV-F as per DIN VDE 0881-5

2.1.2 Mains connection

Connect the power supply at the "Mains connection" plug

❒

Flexible sheathed cable must be used for the wiring; this must be of the correct size to comply with applicable regional standards and regulations.

❒ The power supply line (mains connection) must be fitted with a C16A fuse by the

customer. If a safety overload switch is used it should be a type with C16A.

2.1.3 Connecting the flue gas sensor

green-yellow red+ blue-

Coremodule

Electrical connection and wiring

Core module and connection options

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 9

2.1.4 Combination with oil burner

The connection "Heating circuit pump 0" can be used for heating circuit pump 0 or as burner relays depending on the system setting.

Connecting a HCP 0 up to max. 2 Ampere:

Coremodule

HCP

Connecting a HCP 0 up to max. 5 Ampere:

Connection as burner relays:

Coremodule

Tooilboilercontrol: floatingcontactforburner release

2.1.5 Connecting the remote control

A room temperature sensor is included in the remote control, which sends the current room temperature to the control.

affecting room:

AUS

UHR

NACHT

TAG

RFFV

COM

Raumfühler FRA

RF 1/2

Kernmodul S/P/H 3200

not affecting room:

AUS

UHR

NACHT

TAG

RFFV

COM

Raumfühler FRA

RF 1/2

Kernmodul S/P/H 3200

Switch settings:

Switched-off Heating circuit deactivated, only frost protec‐

tion!

Automatic mode Heating phases according to setback program

Setback mode Ignores the heating phases

Override circuit Ignores the setback

Handwheel… Allows you to adjust the temperature by +/- 3°C

IMPORTANT! See assembly instructions/functional description for room temperature sensor FRA

Electrical connection and wiring

Core module and connection options

10 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

2.1.6 Boiler enable input

When setting the system type, the parameter "Boiler enable input available" is preset to enable potential analysis of an external floating release or start contact.

Boiler enable input available YES

This is set if the boiler enable input is available. As long as the contact is closed, the controls operate according to the speci‐

fied operating mode. If the external contact is opened, the boiler loses the enable and follows the shutdown procedure. As soon as the handle is opened, the controls cease to accept any heat re‐ quirement (e.g. flue gas thermostat of a supply boiler).

Boiler enable input available NO

This is set if there is a boiler start input or no allocation. As long as the contact is open, the controls operate according to the speci‐

fied parameters. If the external contact is closed, the boiler starts and works in continuous operation. (e.g. heat requirements of a heating fan)

Note: No handle required for operation.

❒

If the boiler is enabled or started by the parameter, it goes at least to "Heating"

status, even if the signal has stopped in the meantime. Only then does the boiler follow the shutdown procedure.

Electrical connection and wiring

Core module and connection options

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 11

2.1.7 Connecting a high efficiency pump to the core module

Wire the high efficiency pump as shown in the connection diagram below:

KERNMODUL

FRKEM25

PDM / 0-10V (+)

PDM / 0-10V ( )

Pump 1 (L)

Pump 1 ( )

Pump 1 (N)

❒ Connect the power supply for the high efficiency pump to output "Pump 1" of the

core module

❒

Connect the PWM cable of the high efficiency pump to the corresponding port “PWM / 0-10V"

➥ Make sure that the cables are configured correctly (polarity) in accordance with

the connection diagram of the pump!

Important! When using a Froling pump assembly:

⇨ See "Connection diagrams according to pump types" [page 21]

Electrical connection and wiring

Core module and connection options

12 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

2.2 Expansion modules

2.2.1 Heating circuit module

Two heating circuits can be controlled as standard with the core module. The heating circuit module boards must be used to expand the heating circuit control. Eight heating circuit modules (addresses 0 to 7) can be added, and the module ad‐ dress must be set correctly.

⇨ See "Setting the module address" [page

21]

Connection instructions

Port Cable dimensions / Specifications / Information

Bus (1) Port with cable – LIYCY paired 2x2x0.5;

⇨ See "Connecting the bus cable" [page

19]

❒ Warning! CAN L and CAN H must not be connected to +U

BUS

Flow temperature sensor 1/2 (2)

Connection cable1) 2 x 0.75mm

Room temperature sensor 1/2 (3)

Connection cable1) 2 x 0.75mm2, shielded from 25m cable length

Mains (4)

Connection cable1) 3 x 1.5mm2, fuse 10A

Heating circuit pump 1/2 (5)

Connection cable1) 3 x 1.5mm2, max. 2.5A / 230V / 500W

Mixing valve 1/2 (6)

Connection cable

4 x 0.75mm2, max. 0.15A / 230V

1.YMM as per ÖVE-K41-5 or H05VV-F as per DIN VDE 0881-5

Electrical connection and wiring

Expansion modules

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 13

2.2.2 Hydraulic module

The hydraulic module makes the connections of sensors and pumps available for the hydraulic components of the system (storage tank, DHW tank etc.).

A hydraulic module is included in the delivery as standard (address 0). A further seven modules (addresses 1 to 7) can be retrofitted.

You must ensure that the module address is given correctly.

⇨ See "Setting the module address" [page

21]

AO-

6,3AT

Hydraulikmodul

(FRHYU 21)

Bus (2)

Fühler 1 (3)

Fühler 5 (7)

Netz (9)

Pumpe 2 (11)

Fühler 2 (4)

Fühler 4 (6)

Fühler 3 (5)

Pumpe 1 (10)

Fühler 6 (8)

Bus

(2)

2x Bus

(1)

Modul-Adresse

End-Jumper

Netzsicherung

CAN L

CAN H

Bus

Connection instructions

Port Cable dimensions / Specifications / Information

2 x Bus (1) Patch cable CAT 5 RJ45 SFTP 1:1 configuration

Bus (2) Connection with cable - LIYCY paired 2x2x0.5;

⇨ See "Connecting the bus cable" [page

19]

❒ Important! CAN L and CAN H must not be connected to +U

BUS

Sensors 1 – 6 (3-8)

Connection cable1) 2 x 0.75mm2, shielded from 25m cable length

Mains (9)

Connection cable1) 3 x 1.5mm2, fuse 10A

Pump 1/2 (10/11)

Connection cable1) 3 x 1.5mm2, max. 1.5A / 230V / 280W

1.YMM as per ÖVE-K41-5 or H05VV-F as per DIN VDE 0881-5

Electrical connection and wiring

Expansion modules

14 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

Connecting an isolating valve

If an isolating valve is connected to a speed-controlled pump outlet, an RC element must be used.

Furthermore, the minimum speed for the pump outlet in use must be set to 100% in the boiler control system.

Connection example:

The outer cable L(bn) should be connected to the outer cable of the respective mains supply of the module or to the core module, HCP0/burner relay output at pin “LV”.

Electrical connection and wiring

Expansion modules

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 15

Connecting a high efficiency pump to the hydraulic module

Wire the high efficiency pump as shown in the connection diagram below:

❒ Connect the power supply for the high efficiency pump to output "Pump 1" or

"Pump 2" of the hydraulic module

❒

Connect the PWM cables of the high efficiency pump to the corresponding port "AO-P1" or "AO-P2"

➥ Make sure that the cables are configured correctly (polarity) in accordance with

the connection diagram of the pump!

IMPORTANT! When using a Froling pump assembly:

⇨ See "Connection diagrams according to pump types" [page 21]

Electrical connection and wiring

Expansion modules

16 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

2.2.3 Wood chip module

The wood chip module is included in standard delivery and has the connections of the hardware components for the wood chip boiler:

Connection instructions

Port Cable dimensions / Specifications / Information

Bus (1) CAT 5 patch cable grey RJ45 SFTP 1:1 configuration

Return sensor (2) 2 x 0.75 mm², shielded

Combustion chamber sensor (3)

Connection cable of the respective unit

Underpressure sensor car‐ tridge (4)

24V power supply (5/6)

Connection cable 1) 2 x 0.75 mm²

Fault message (7)

Connection cable 1) 3 x 1.5 mm² Floating changeover contact, max. 2A / 24V, 1A / 230V

CAF n.a. (8) Not in use!

Return mixer (9)

Connection cable 1) 4 x 1.5 mm², max. 0.15A / 230V

Ash screw (10)

Connection cable 1) 3 x 1.5 mm²

Ash screw (11)

Connection cable 1) 3 x 1.5 mm²

❒

Connection of the drive unit of the ash discharge into a standard dustbin

Vibration motor n.a. (12) Not in use!

WOS drive (13) Connection cable of the respective unit

Electric ignition (14)

Mains connection (15)

Connection cable 1) 5 x 2.5 mm², 400VAC

Feed screw (16)

Connection cable 1) 4 x 1.5 mm², max. 0.75kW / 400V

Stoker screw (17)

Connection cable 1) 4 x 1.5 mm², max. 0.55kW / 400V

Gravity shaft level sensor (18)

Connection cable 1) 3 x 0.75 mm², N/O switch contact 24V

Ash screw monitoring (19)

Connection cable 1) 3 x 0.75 mm², inductive sensor 24V

Lock (20)

Connection cable 1) 2 x 0.75 mm², 24V looping through

Electrical connection and wiring

Expansion modules

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 17

Port Cable dimensions / Specifications / Information

Combustion chamber over‐ pressure sensor n.a. (21)

Not in use!

Free input (22)

Connection cable 1) 2 x 0.75 mm²

❒

Connection of the contact switch to the monitoring system of the heat exchanger system (T4 130/150)

Gravity shaft cover (23)

Connection cable 1) 2 x 0.75 mm², N/O switch contact

Grate tip drive (24) Not in use!

Tipper drive (25)

Connection cable 1) 6 x 0.75 mm²

1.YMM as per ÖVE-K41-5 or H05VV-F as per DIN VDE 0881-5

Fuses:

F1, F3, F6 2.5 AT Stoker screw

F4, F5, F7 2.5 AT Feed screw

F2 6.3 AT 230V drives

2.2.4 Digital module

The digital module has additional digital inputs and outputs:

Connection instructions

Port Cable dimensions / Specifications / Information

2 x Bus (1) CAT 5 patch cable grey RJ45 SFTP 1:1 allocation

Output 1 … 8 (2)

Connection cable 1) 1 x 0.75 mm²

24V (3)

Connection cable 1) 1 x 1.0 mm²

Input 1 … 8 (4)

Connection cable 1) 1 x 0.75 mm²

1) YMM as per ÖVE-K41-5 or H05VV-F as per DIN VDE 0881-5

Electrical connection and wiring

Expansion modules

18 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

2.2.5 Power supply

The power supply is used to supply all parts of the system that consume energy with 24 VDC:

Connection instructions

Connection Cable dimensions / Specifications / Notice

Mains

Connection cable 1) 3 x 1.5 mm²

24V power supply

Connection cable 1) 2 x 1.0 mm², max. 2A

1) YMM as per ÖVE-K41-5 or H05VV-F as per DIN VDE 0881-5

Fuses

F1 2 AT 24 VDC

2.2.6 Connecting the bus cable

For the bus connections between the individual modules, cable type LIYCY paired 2x2x0.5 should be used. The connection to the 5-pin plugs should be carried out according to the following diagram:

CANH

CANL

CANH

CANL

Braidedshield

White

Green

ellow

Brown

Braidedshield White Green Yellow Brown

Electrical connection and wiring

Expansion modules

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 19

2.2.7 Connect the patch cable to the bus plug

To connect a patch cable to a RJ45 bushing and a 5-pin plug, follow the connection diagram below:

2.2.8 Setting end jumpers

To ensure smooth running of the bus system, the jumper must be placed on the last module.

End jumper not set End jumper set

If the contacts at the base of the end jumper are not bridged (image left), it is referred to as “not set". In this case there is no bus termination. If the contacts are closed (im‐ age right), the end jumper is set and the bus connection is terminated.

Electrical connection and wiring

Expansion modules

20 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

2.2.9 Setting the module address

For hydraulic modules or heating circuit modules it is necessary to set the required or‐ der with the module addresses. The first board of a module type should always have the address 0, so that the standard hydraulic systems set do not have to be subse‐ quently configured. For further module types ascending module addresses (address 1

- 7) are set. A hydraulic module with address 0 is included in standard delivery. If a second hy‐

draulic module is also installed, address 1 is set.

Module

address set

Heating circuit mod‐

ule

Hydraulic module

Heating circuit Sensor Pump

0 03 – 04 0.1 – 0.6 0.1 – 0.2

1 05 – 06 1.1 – 1.6 1.1 – 1.2

2 07 – 08 2.1 – 2.6 2.1 – 2.2

3 09 – 10 3.1 – 3.6 3.1 – 3.2

4 11 – 12 4.1 – 4.6 4.1 – 4.2

5 13 – 14 5.1 – 5.6 5.1 – 5.2

6 15 – 16 6.1 – 6.6 6.1 – 6.2

7 17 - 18 7.1 – 7.7 7.1 – 7.2

Electrical connection and wiring

Expansion modules

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 21

2.3 Connection diagrams according to pump types

Three different pump types are used in all depending on the pump assembly used:

WILO Stratos Para WILO Stratos TEC WILO Yonos Para

Either a 2-pin control cable (WILO Stratos TEC, WILO Yonos Para) or a 4-pin control cable (WILO Stratos Para) is used for the connection depending on the pump type. Please follow the connection instructions below for the wiring depending on the pump type used:

Pump type with 2-pin control cable

Power supply 2-pin control cable

(brown) L

(blue) N

(yellow-green) PE

Wire the power supply to the pump outlet on the board

Connect the control cable to the board’s PWM output, making sure that the polarity is correct:

- blue wire to earth

- brown wire to plus

Pump type with 4-pin control cable

Power supply 4-pin control cable

(brown) L

(blue) N

(yellow-green) PE

Wire the power supply to the pump outlet on the board

Connect the control cable to the board’s PWM output, making sure that the polarity is correct:

- brown wire to earth

- white wire to plus Do not use the other two wires (blue, black) and insu‐

late if necessary

Electrical connection and wiring

Connection diagrams according to pump types

22 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

3 Overview of the basic functions

3.1 Visual display

A Date and time display

B Image of set boiler type

C Info menu icon for viewing all system information

D System menu icon for opening the system settings. All parameters can be displayed/

edited depending on the user level

E Quick menu icon for viewing the available quick functions

F Mode icon for switching the boiler on/off

⇨ See "Switching the boiler on/off" [page

31]

G Status LED for displaying the current operating status

H Brightness sensor for automatically adjusting the display brightness

I USB port for connecting a USB stick for software updates

3.1.1 Status LED

The status LED shows the operating status of the system:

▪

GREEN flashing (interval: 5 sec OFF, 1 sec ON): Boiler off ▪ GREEN constant: BOILER SWITCHED ON ▪ ORANGE flashing: WARNING ▪ RED flashing: FAULT

Overview of the basic functions

Visual display

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 23

3.1.2 Control icons

Cancel icon

Discards any values entered without saving and closes messages.

Confirm icon

Confirms any values entered and activates parameters.

Home icon

Tapping the Home icon takes you back to the basic display from any menu.

Info menu icon

To access all system information. The information is ordered in a circular buffer. The right and left arrows are used to switch between the individual pages.

Quick menu icon

Opens the quick menu. Various functions are available depending on the user level, system configuration and current status.

Pen icon

If a parameter has the pen symbol beside it, it means that the parameter can be adjus‐ ted. If you open the parameter, either the numeric keypad or a list box for changing the value of the parameter will appear.

System menu icon

Opens the system settings. Depending on the operating level and system configura‐ tion, the various menu items available are organised in a circular buffer which can be navigated using the right and left arrow.

Back icon

Takes you back up one menu level of the system menu. Can be used to return to the basic display.

Overview of the basic functions

Visual display

24 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

3.1.3 Display icons

Depending on the selected settings and current status, additional icons may be shown in the upper left section of the display. Tapping the upper left display section takes the user to the “Connection Center”. Here the online portal “froeling-connect.com” can be activated or deactivated.

froeling-connect.com is not in use or was deactivated by the user.

Command server error; a connection with the froeling-connect.com server was not able to be established.

Connection with the froeling-connect.com server is being established.

froeling-connect.com is available.

Remote control of the boiler can also be activated or deactivated in the “Connection Center”. The prerequisite is that the parameter “Remote control of the boiler can be activated” is set to “YES” in the menu “System selection” under “Boiler remote control”.

⇨ See "Boiler remote control" [page 52

]

Remote control (switching the boiler on and off) by external operators via froeling-con‐ nect.com is permitted.

Remote control (switching the boiler on and off) by external operators via froeling-con‐ nect.com is not permitted.

Overview of the basic functions

Visual display

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 25

3.2 Operating statuses

Preparation The boiler is ventilated, the Lambda probe heated and the ash screws

are switched on; underpressure test.

Heating up The stoker is filled with fuel and a quantity of fuel that can be ignited is

pushed onto the grate.

Pre-heating The fan-assisted ignition switches on and the fuel is pre-warmed until a

flame forms. For this period, infeed is deactivated.

Ignition The fan-assisted ignition ignites the fuel. The flame is distributed

throughout the entire combustion chamber. Control of the induced draught fan and infeed for this operating status are defined in the "Igni‐ tion" parameter menu.

Heating The Lambdatronic H 3200 T4 controls combustion according to the boil‐

er setpoints.

Empty stoker The stoker is emptied according to procedure.

Shutdown wait Safety time during which the residual material on the grate is burnt.

Stopped The combustion process has ended.

Tip grate The grate opens / closes a specified number of times

Cleaning The grate is tipped and the boiler is ventilated for 1 minute. The stoker

switches on and the ignition opening is cleared by blowing. The ash screw runs and the grate opens / closes twice the specified number of times during the entire procedure. This operating status can only be opened in "Boiler off" status. The status that follows is "Boiler off" and the boiler must be activated by pressing the start key.

Standby The boiler is ready to start and is waiting for a heat requirement (a start

command).

Boiler off The Lambdatronic H 3200 T4 now only controls the connected heating

components. All parts of the boiler are deactivated. Lambda probe heat‐ ing remains active for 1 hour after the operating status has been reached.

Fault WARNING - There is a fault!

⇨ See "Troubleshooting" [page

126]

TS (Troubleshoot‐ ing)

If a fault occurs during heating (up), the boiler will switch to “Trouble- shooting” status. In this status the stoker is emptied at minimum fuel feed-in (“The time until the stoker is empty is” parameter) whilst the ignition fan is active. The boiler then switches to “Shutdown wait” status and “Tip grate”. It will remain in this status for at least 30 mins depending on the boiler output, the fuel used and the parame‐ ters set.

Overview of the basic functions

Operating statuses

26 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

3.3 Updating the software of the touch control

❒ Insert the USB stick with the necessary data (linux.bin; rootfs.img; update) into the

USB port

❒

“Display settings” menu → “Software update / Service”

❒ Set “Restart control / Update” parameter to “Yes”

➥ Update will begin

Display during the update:

Overview of the basic functions

Updating the software of the touch control

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 27

Once the update is complete, a message will appear that you can remove the stick

❒

Remove the USB stick

❒ Close the USB cover cap on the barrel

➥ The cap must click into place

❒ Tap the touch screen

After restarting the display will start calibrating.

Once the calibration is complete, it will restart again to finish. The touch control soft‐ ware is now up to date.

NOTICE

Inaccurate calibration

If you do not tap the indicated points accurately, the control may stop working properly and a software update may be required.

Overview of the basic functions

Updating the software of the touch control

28 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

3.4 Calibrating the touchscreen

If the touchscreen stops working properly, it will need to be calibrated.

❒

Go to the “Display settings” menu

❒ Scroll down with the down arrow until the “Software update / Service" submenu

appears and open the submenu

❒

In the “Software update / Service" menu open the “Recalibrate touch con-

trol” parameter

Overview of the basic functions

Calibrating the touchscreen

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 29

❒ Set the parameter to “YES” and confirm at the bottom right

➥ The touchscreen will restart and begin calibrating

To calibrate the touchscreen, you much press five points indicated by a crosshair in the order shown. The control will restart after calibration.

NOTICE

Inaccurate calibration

If you do not tap the indicated points accurately, the control may stop working properly and a software update may be required.

Overview of the basic functions

Calibrating the touchscreen

30 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

4 Operation

4.1 Switching the boiler on/off

Boiler is switched on. Heating circuits and domestic hot water are controlled according to the programs and times set.

The control follows the boiler shutdown procedure and starts the cleaning cycle. After the cleaning cycle the boiler switches to "Boiler off" status. The

Lambdatronic H 3200 T4 controls the connected heating components. All parts of the boiler are deactivated. Chamber discharge system active!

4.2 Navigation within the info menu

The info menu displays all the information about the system. Use the right and left ar‐ rows to go to the individual menu items for the relevant information. The next time you open the info menu, the last page viewed will be displayed.

Boiler ON

Boiler OFF

Operation

Switching the boiler on/off

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 31

4.3 Navigation within the system menu

The system menu shows the menu items available depending on the user level and the system configuration. Tap the icon to open the corresponding menu item. The sys‐ tem menu is structured in a circular buffer, which can be navigated using the right and left arrows. The next time you open the system menu, the last page viewed will be dis‐ played.

4.3.1 Navigating the menus

After you open a menu item, the corresponding status display with current values will appear. If, for example, several heating circuits are installed, you can use the right and left arrows to navigate to the desired heating circuit. You can open any other menu items available in the same way.

The individual menus are divided into tabs for quicker navigation.

❒

Tap on the desired tab

➥ The list of parameters for the selected area will appear

Operation

Navigation within the system menu

32 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

The parameter list shows three parameters. The up and down arrows can be used to scroll through longer lists of parameters. If you have reached the start or end of the parameter list, the relevant arrow symbol will become inactive.

Operation

Navigation within the system menu

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 33

4.4 Adjusting parameters

A parameter can only be adjusted if there is a pen icon beside it. Depending on the type of parameter, either the numeric keypad...

... or a list box will appear.

In both cases you need to tap the confirm icon to save the entry.

Operation

Adjusting parameters

34 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

4.5 Setting times

The desired time window for the component can be set in the "Times" tab in the indi‐ vidual menus of the heating components (heating circuits, DHW tanks etc.). The struc‐ ture of the time menu and the procedure for changing the times are always the same.

❒

Use the left or right arrow to navigate to the desired day of the week

❒ Tap the symbol under the day of the week

➥ The edit window will appear

You can specify up to four time windows per component and day.

❒

Tap the desired time window

❒

The time window will open for editing

❒ Set the start and end time for the time window using the up and down arrows ❒ Save the time window setting by tapping on the confirm icon

Operation

Setting times

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 35

To delete a time window, set the times so that the hour and minute displays are re‐ placed by two dashes.

If you want to apply the time window setting to another day in addition, you can do this by activating the relevant day.

Operation

Setting times

36 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

4.6 Setting the date/time

❒ To set / adjust the date and time displayed, tap on the date/time at the top right of

the basic display.

❒

A menu will then appear allowing you to adjust the date and time. To apply the

new values you need to confirm the date and time by tapping the “confirm” icon.

Operation

Setting the date/time

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 37

4.7 Quick menu

4.7.1 "Operating level” function

To change the operating level you need to enter the relevant code.

⇨ See "Switching user level" [page

45]

4.7.2 "Choose language” function

The control starts in German by default. If you change the language of the control, it will restart, uploading all text in the selected language from the core module.

4.7.3 "Chimney sweep” function

The chimney sweep function is used for measuring boiler emissions using the chim‐ ney sweeper. For further information and the procedure for measuring emissions, see the operating instructions of the boiler.

❒

The boiler runs for 45 minutes at nominal load

➥ The boiler temperature setpoint is set to 85 °C ➥ The heating pumps switch on and the mixer valves regulate to the maximum

flow temperature setpoint

➥ DHW tank and storage tank loading pump are controlled as normal

4.7.4 "Service mode” function

Only possible in "Boiler off" operating status. The boiler switches to "Cleaning" status and starts the cleaning cycle. When this is fin‐

ished the boiler switches to "Boiler off" status.

4.7.5 "Extra heating” function

During extra heating, heating and domestic hot water are heated for 6 hours. The mode setting is ignored.

Caution: The external temperature heating limit set in the "Heating" menu is active and can prevent release of the heating circuits.

4.7.6 "Summer op.” function

To change to summer mode. Domestic hot water loading is controlled according to the program that is set, the heating circuit controller is deactivated.

4.7.7 “Mode in automatic mode” function

⇨ See "Boiler modes" [page 39]

4.7.8 "Extra loading” function

One-off manual loading of domestic hot water. After loading, the mode that was previ‐ ously set becomes active again.

Operation

Quick menu

38 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

4.7.9 "Touch cleaning” function

For cleaning the touchscreen surface. The screen is disabled for 10 seconds to allow you to clean it without opening a menu or inadvertently adjusting a parameter.

4.8 Boiler modes

4.8.1 Explanation of terms

Boiler time The time in which the boiler is producing heat, i.e. during this time the boiler is adjus‐

ted to its boiler temperature setpoint. Outside this time there is no heat available for the heating system.

❒

If there is a storage tank, the boiler time is replaced by the storage time

⇨ See "Heating times of the boiler" [page 78]

Storage tank loading time The time in which the storage tank can be loaded by the boiler, provided that the crite‐

rion for starting the boiler is met ("Boiler start if difference between boiler setpoint and top store is larger“ parameter).

❒ Storage tank loading only takes place within the defined time window.

⇨ See "Heating times of the storage tank" [page 73]

Heating time The time in which the heating circuit is supplied at the desired temperature. Outside

this time (setback mode) the heating circuit is supplied at reduced temperature.

❒ Requirement: a sufficiently high temperature in the boiler or top storage tank.

⇨ See "Heating times of the heating circuits" [page 58]

DHW tank loading time The time in which DHW tank loading is released.

❒ Requirement: The DHW tank temperature is below the minimum value and the

boiler or storage tank temperature is sufficiently high.

⇨ See "Heating times of the DHW tank" [page 64]

Operation

Quick menu

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 39

4.8.2 Transition op. without storage tank

In transition operation without a storage tank the boiler only produces heat during the specified boiler times. Outside these times the boiler follows the shutdown procedure and switches to "Standby" status. It is, therefore, important to note that in this mode the heating circuits and DHW tank are only supplied with heat during the boiler times.

In example 1 the boiler times have been set to cover the necessary heat requirement. The heating times and DHW tank loading times have been set within the boiler time range, with the heating time being extended approximately one hour beyond the boiler time. This allows the residual energy in the boiler to be used by the heating circuits after the end of the boiler time.

Note that outside the boiler times for setback mode, heat is only available until the boiler temperature falls below the setting value (parameter "Pumps start at").

Example 1:

Boiler heating time 1

Heating time 1 Heating time 2

DHW tank loading time 1 DHW tank loading time 2

Setback mode

Boiler heating time 2

Transition operation without storage tank

Time

Tip: In systems with solar panels, choose the DHW tank loading time so that solar en‐ ergy can be used.

Example 2:

Boiler heating time 1

Heating time 1 Heating time 2

DHW tank loading time 1

Setback mode

Boiler heating time 2

Transition operation without storage tank with solar panel system

Time

Operation

Boiler modes

40 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

4.8.3 Transition op. with storage tank

In transition operation with storage tank the boiler only produces heat if the storage tank actually requests heat within the specified storage tank loading time. Outside these times the boiler is in “Standby" status.

The heating times should be set within the storage tank loading times so that the pro‐ vision of heat is guaranteed over the entire heating time.

Note that the heating circuit and DHW tank are only supplied with heat if the storage tank temperature is sufficient for the requirement.

Example 1:

Heating time 1 Heating time 2

DHW tank loading time 1

Setback mode

Storage tank loading time 1

DHW tank loading time 2

Transition operation with storage tank

Time

Tip. In systems with a storage tank and solar panels, choose the storage tank loading time so that solar energy can be used.

In order to ensure that there is sufficient heat at the start of the DHW tank loading time and heating time, we recommend setting the storage tank charging time to begin be‐ fore the start of the DHW tank time or heating time.

Example 2:

Heating time 1 Heating time 2

DHW tank loading time 1

Setback mode

Storage tank loading time 1

DHW tank loading time 2

Transition operation with storage tank and solar panel system

Time

Operation

Boiler modes

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 41

4.8.4 Winter op. without storage tank

In winter operation the boiler produces heat around the clock, in other words it tries to maintain its boiler temperature setpoint 24 hours a day. The boiler time settings are ignored in this mode.

The heating times and DHW tank loading times can be distributed throughout the day as required.

Example 1:

Heating time 1 Heating time 2

DHW tank loading time 1

Setback mode

DHW tank loading time 2

Winter operation

Time

Tip: In systems with solar panels, choose the DHW tank loading time so that solar en‐ ergy can be used.

Example 2:

Heating time 1 Heating time 2

Setback mode

DHW tank loading time 1

Winter operation with solar panel system

Time

4.8.5 Winter op. with storage tank

To ensure efficient operation, set systems with a storage tank to transition op. rather than winter op.

Set systems with a storage tank to transition op.

⇨ See "Transition op. with storage tank" [page 41

]

Operation

Boiler modes

42 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

4.8.6 Summer op. without storage tank

In summer operation the boiler only produces heat if the DHW tank actually requests heat within the specified DHW tank loading time.

Example 1:

DHW tank loading time 1 DHW tank loading time 2

Summer operation without storage tank

Time

Tip: In systems with solar panels, choose the DHW tank loading time so that solar en‐ ergy can be used.

Example 2:

DHW tank heating time 1

Summer operation with solar panel system

Time

Operation

Boiler modes

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 43

4.8.7 Summer op. with storage tank

In systems with a storage tank, note that in summer operation the storage tank loading times remain active as the DHW tank is supplied with heat from the storage tank.

Within the storage tank loading time the boiler only produces heat if the storage tank temperature is below the minimum value and the DHW tank is requesting heat.

Example 1:

Storage tank loading time 1

DHW tank laoding time 1 DHW tank loading time 2

Summer operation with storage tank

Time

Tip: In systems with a storage tank and solar panels, choose the storage tank loading time so that solar energy can be used.

Example 2:

Storage tank loading time 1

DHW tank loading time 1 DHW tank loading time 2

Summer operation with storage tank and solar panel system

Time

Operation

Boiler modes

44 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

4.9 Initial startup

4.9.1 Switching user level

The range of functions of the touch display depends on the current user level setting. To switch to another user level, open the “Operating level” function in the quick menu.

⇨ See "Quick menu" [page 38]

Once you have entered and confirmed the relevant user code, the number of functions available will vary. The “installer" and “service" user levels are also shown on the ba‐ sic display above the quick menu icon.

Operating level Description

Child lock (Code 0)

At “Child lock” level, only the “Status” menu appears. It is not possible to change parameters at this level.

Customer (Code 1)

Standard level for normal operation of the touch display. All cus‐ tomer-specific parameters are displayed and can be changed.

Installer / Service Releases parameters to adjust the controller to the system com‐

ponents (if configured).

Operation

Initial startup

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 45

4.9.2 Setting the system selection

Open the system selection menu

❒ In the system menu open “System”

❒

Then navigate to “System selection” in the menu and open the menu

Operation

Initial startup

46 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

Selecting the boiler type

The boiler type selection of the T4 wood chip boiler is divided into two output bands:

- T4 24 – 75

- T4 90 – 150 In its delivery configuration, the relevant output band is already preconfigured; howev‐

er, the actual nominal output of the boiler and the discharge and hydraulic heating sys‐ tem still need to be set!

NOTICE! Only for trained personnel!

❒ In the boiler type menu navigate to the preconfigured menu and open.

❒

In the submenu, set the actual output of the boiler and the fuel used, and activate

the relevant parameters.

➥ Active parameters are identifiable by the confirm icon

NOTICE! The boiler and specified material values must be applied before you exit this menu!

Operation

Initial startup

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 47

Fuel selection - Dry chip

- Wet chip

- Pellets

Adopt specified boiler values NO

Adopt specified material values NO

Boiler enable input available NO

Boiler stops automatically when no heat required NO

Bypass pump installed NO

Return feed mixer installed YES

Maintaining outfeed through return feed mixer NO

Troubleshooting active YES

E-filter present? NO

AGR installed NO

WOS monitoring active YES

Rotary valve types:

Rotary valve type I Rotary valve type II

T207075

T209715

Selecting the feed system

Operation

Initial startup

48 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

Feed system

Screw delivery system ➔ Delivery screw availa‐

ble

YES/NO

Intermediate screw in‐ stalled

YES/NO

Relative delay time for level control of deliv‐ ery

YES/NO

Control stoker and feed screw with digital module 4

YES/NO

Sliding floor available YES/NO

Sliding floor always active

YES/NO

Feed system module present

YES/NO

System selection

Hydraulic system 0 Hydraulic system 1 Hydraulic system 2 Hydraulic system 3 Hydraulic system 4

SELECT For description see “ Lambdatronic H 3200 T4

Energy Systems” brochure

Hydraulic system for S3 boiler DO NOT SELECT

Hydraulic system 12 Hydraulic system 13

SELECT For description see “ Lambdatronic H 3200 T4

Energy Systems” brochure

Variant 1 Variants 2 and 5 Variant 3 Variant 4

Multiple house diagrams

Slave boiler for boiler sequence control Only for systems in the cascade!

Operation

Initial startup

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 49

If the system has a Non-binding Planning Suggestion, the hydraulic system setting can be found at the top right-hand corner of the planning suggestion.

Otherwise, the selection table below shows the hydraulic system to be set for the spe‐ cific system:

DHW tank system

DHW tank 01 installed ❒

DHW tank 02 installed ❒

Operation

Initial startup

50 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

: :

DHW tank 08 installed ❒

Heating system

Heating circuit 01 installed ❒

Remote control 01 installed ❒

Heating circuit 02 installed ❒

Remote control 02 installed ❒

: :

Heating circuit 18 installed ❒

Remote control 18 installed ❒

❒ The “remote control XX installed” parameter should be checked if any of the the

three remote controls shown is used for the respective heating circuit.

Solar system

Solar collector 01 installed ❒

A second pump is used instead of the isolating valve ❒

Operation

Initial startup

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 51

Boiler remote control

Remote control of the boiler can be activated ❒

4.9.3 Before heating up for the first time

❒ Check the system pressure of the heating system ❒

Check that the heating system is fully ventilated ❒ Check that the safety devices are present and working correctly ❒ Check that there is sufficient ventilation in the boiler room ❒ Check the seal of the boiler

➥ All doors and inspection openings must be tightly sealed!

❒ Calibrate the broadband probe

⇨ See "Starting calibration" [page 112]

❒ Check that the Ash box contact switch is working correctly

⇨ See "Digital inputs" [page 101]

Drives

❒ Check that drives and actuators are working and turning in the right direction

⇨ See "Analogue outputs" [page 100] and

⇨ See "Digital outputs" [page 99]

Operation

Initial startup

52 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

4.9.4 Starting the system on initial startup

Feeding fuel into the combustion chamber

For initial startup there is no fuel in the stoker and in the feed screw.

❒ Set the "Delivery system from bunker" parameter in the Manual operation

menu to ON.

Open the gravity shaft cover briefly at regular intervals and check for fuel:

❒ As soon as the first pieces of fuel fall onto the rotary valve, leave the gravity shaft

cover open and set the "Delivery system from bunker" parameter back to

OFF. ❒ Close the gravity shaft cover and start the system in automatic mode. ❒ After the boiler has reached the operating status, "Heating", switch off the boiler

again.

Setting parameters

❒ Start the boiler for a second heating up process in automatic mode

➥ The grate is opened and it remains open until the specified time has elapsed

(parameter "Stoker full").

➥ The grate is closed again and a suitable quantity of fuel for ignition is fed in.

❒ While the boiler is heating up, open the "Current values" menu and scroll to

the parameter, "Current status runtime"

❒ Observe the following times (current and maximum) during the second heating up

process and compare with the preset standard values:

▪ Time until fuel falls onto the lifting grate: …….. seconds

(no fuel should fall into the ash chamber)

▪ Time until a sufficient quantity for ignition is present: …….. seconds

(approx. a quarter of the grate is covered with fuel, at least up to the igniter tube)

☞ For this procedure it is necessary to open the boiler door, which is screwed shut,

after preparation.

☞ The combustion chamber must only be opened in the course of initial start-up or

by qualified technicians during operation.

❒ After a suitable quantity of fuel for ignition has been fed in, quickly close the com‐

bustion chamber door and screw it shut.

❒ If you notice any deviations in the status runtimes in the menus, "Ignition" and

"Fuel feed", adjust them.

As well as the status runtimes, you should also check the parameter, "Slide-in during ignition", and adjust it if necessary.

☞ In reality this parameter depends on the fuel used and therefore should be set by

the customer service technician during initial startup.

☞ When you change the fuel (supplier, type of wood etc.) you must have the param‐

eters changed by a customer service technician. Flash fire hazard!

❒ The following parameters (depending on the configuration) can/should be set ac‐

cording to the customer's wishes:

▪ Desired boiler setpoint

Operation

Initial startup

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 53

▪ DHW tank loading times ▪

Storage tank loading times ▪ Solar controller ▪ Heating and setback times of the heating circuits ▪ Heating curve (radiator or underfloor heating)

Adjusting the feed output of the feed screw

NOTICE! This adjustment must ONLY be carried out by a qualified technician.

If an original Froling discharge system is installed, no adjustments are necessary, as it has already been adapted to the boiler.

If a discharge system from a third-party manufacturer or an older discharge system with a higher feed output is used, the parameter, "Time feed screw is on un-

til stoker screw

, must be adjusted, as the stoker could be overfilled otherwise. For discharge systems with higher feed outputs, the feed screw to stoker screw ratio must be reduced.

Procedure:

Open the gravity shaft cover briefly at regular intervals during operation and check the area above the rotary valve to see if fuel is jammed. If this is the case, the parameter "Time feed screw is on until stoker screw", must be reduced.

Please note that when this parameter is changed, the values of the parameters "The

time until the stoker is full is", "The time until the stoker is empty is" and "Feed time until there is a fuel quantity suitable for ignition" must be reset.

❒ Shorter time feed screw is on until stoker screw

➥ The times are reduced!

As the infeed of the T4 relates to the feed screw, the parameter, "Minimum loading rate", must also be adjusted. If the time feed screw is on until stoker screw is re‐ duced considerably (= high feed output of the feed screw), this means a low feed rate during heating. For this reason the minimum feed rate should be set very low for the first heating process (~1%). Calculate the average feed rate at full load at "Heating" status and set the parameter, "Minimum loading rate" to about a quarter of this value. If the feed screw has a higher feed output, the parameter, "Slide-in during ignition" must also be reduced. Set this value to around half the average feed rate at full load.

Operation

Initial startup

54 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

5 Menu overview and parameters

Menu overview and parameters

Menu - Heating

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 55

5.1 Menu - Heating

⇨ See "Navigation within the system menu" [page 32]

5.1.1 Status displays for the heating circuits

Parameter Description

Control heating circuit according to program (NO -> heating circuit is switched off)

YES NO -> Heating circuit is completely switched off. No frost protection!

Actual flow temperature 46°C Shows the current flow temperature

Flow temperature setpoint 52°C The calculated flow temperature setpoint

Room temperature 21°C Temperature on remote control of the current heating circuit (optional)

Override switch Auto Shows the current switch setting on the remote control (optional)

(Party) = party mode; the setback program is ignored

(Setback) = setback mode; the heating phases are ignored

(Auto) = automatic mode; heating phases according to setback

program

(Off) = switched off; heating circuit deactivated, only frost protection!

External temperature 2°C Shows the current external temperature

Menu overview and parameters

Menu - Heating

56 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

5.1.2 Temperature settings for the heating circuits

Parameter Description

Desired room temperature during heating mode

20°C Room temperature during heating mode (only with remote control)

Desired room temperature during setback mode

16°C Room temperature during setback mode (only with remote control)

Flow temperature SP at external temperature of +10°C

40°C The heating curve can be adjusted to the relevant system with these two

work points.

Flowtemperature

-10

External temperature

-15 -5 0 5 10 15

Exampleof floorheating

Exampleof radiators

Flow temperature SP at external temperature of -10°C

60°C

Controller gain room temperature Kp-Rm

6.0 Influencing factor of room temperature on the flow temperature of the heating circuit. If there is a deviation in the room temperature of +/- 1°C the set value of the flow temperature is corrected by this value.

(Parameter only with optional remote control!) Recommended values for:

- Floor heating 2 - 3

- Radiators (new build): 4 – 5

- Radiators (old build): 6 – 7 Note:Observe external influences on the room sensors!

Reduction of flow temperature in setback mode

15°C The flow temperature is reduced by this value during setback mode.

External temperature below which the heating circuit pump switches on in heating mode

18°C If the external temperature exceeds this value during heating, the heating

circuit pumps and mixing valve are deactivated.

External temperature below which the heating circuit pump switches on in setback mode

7°C If the external temperature falls below this value in setback mode, the

heating circuit pumps and mixing valve are activated.

Menu overview and parameters

Menu - Heating

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 57

Maximum heating circuit flow temp. 75°C Maximum temperature for limiting outfeed temperature at which the heat‐

ing circuit is supplied.

Maximum DHW tank flow temp. 75°C If DHW tank 1 is supplied directly from heating circuit 1, you can set anoth‐

er maximum flow temperature for the time of DHW tank loading.

Frost protection temperature 10°C If the room temperature or the flow temperature is lower than the set val‐

ue, the heating circuit pump will be switched on.

5.1.3 Heating times of the heating circuits

⇨ See "Setting times" [page 35]

5.1.4 Service parameters of the heating circuits

Parameter Description

Heating circuit pump A 0 Used for testing the individual outputs.

Heating circuit mixing valve OPEN A 0

Heating circuit mixing valve CLOSED

A 0

Mixer runtime 240s Set mixer runtime of heating circuit mixer in use.

Recommendation to reduce mixer vibration: do not set to < 150 s

Switch off heating circuit pump when flow setpoint is lower than

20°C If a flow temperature setpoint is calculated below the value set here, the

heating circuit pump switches off and the mixing valve closes (just without remote control).

Menu overview and parameters

Menu - Heating

58 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

Parameter Description

Should this heating circuit heat when there is DHW tank priority?

NO Generally the heating circuits are released with active DHW tank priority

only when the DHW tank is fully charged. If this parameter is set to "YES", the DHW tank priority for this heating circuit is deactivated.

From which storage tank or distribu‐ tor is the heating circuit supplied (0 = boiler)

1 NOTE: Only valid for multiple house systems (variants).

Allocation of the heating source for this heating circuit: 0 = Boiler, 1 = Storage tank 01, ...

High temperature requirement be‐ cause of DHW tank 1 loading

NO If DHW tank 1 is supplied directly from the heating circuit as well as the

isolating valve, this parameter must be set to “YES”. If there is a require‐ ment from the DHW tank and the criteria for DHW tank loading have been met, the isolating valve immediately clears the way for boiler loading. The heating circuit pump starts running as soon as the “Load if tempera- ture difference between boiler and DHW tank is” criterion is reached. Once DHW tank loading is complete, the heating circuit pump will stop, the isolating valve will remain active for a specified period of time and the heating circuit mixer will close. If time has run out, the heating cir‐ cuit will go back to being supplied on a weather-compensated basis.

NOTE: Parameter only available with heating circuit 1 and generally only used in conjunction with the unit model of the P1 Pellet pellet boiler!

High temperature requirement be‐ cause of DHW tank loading

NO If this parameter is set to YES, the remote line is operated according to

the set heating curve + overcharge. Whilst the DHW tank is loading, the remote line is supplied for a short time at a higher temperature, but once the DHW tank is loaded, it is supplied again according to the heating curve.

NOTE: Parameters for heating circuit 2 only!

For high temperature requirement don't look at DHW tank 01

NO If DHW tank 1 is positioned in front of the network mixer, it should not af‐

fect the temperature control of the remote line, therefore this parameter should be set to YES.

NOTE: Parameters for heating circuit 2 only!

⇨ See "Digital outputs" [page 99]

5.1.5 Service parameters for heating up program

Menu overview and parameters

Menu - Heating

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 59

Parameter Description

Heating up program active NO If this parameter is activated, the 30-day program that has been set starts.

After the 30 days, the heating circuit that has been set operates based on the set heating times again.

❒

The heating times of the selected heating circuit are automatically set to 0:00-24:00 and the external temperature heating limit is ignored.

❒ In order that enough heat is always available to the heating circuit, the

boiler and/or storage tank loading times must be set to 0:00-24:00. When using a firewood boiler, a corresponding heat supply must be ensured.

Current day of the heating up pro‐ gram

1 Shows the current day of the heating program that is running

For which heating circuit should the program apply

1 This parameter determines which heating circuit is supplied by the heating

up program. Heating circuit 1 ... 18

❒

Only one heating circuit can be selected.

Which heating up program is used 1 There are set options for the progression of the flow temperature in heat‐

ing up programs 1 – 6. With heating up program 7 the flow temperature can be selected freely.

Outfeed setpoint for all days in pro‐ gram 7

35°C If heating up program 7 is active, the selected heating circuit is adjusted to

the specified flow temperature.

⇨ See "Heating up programs" [page 61]

Menu overview and parameters

Menu - Heating

60 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

Heating up programs

Heating up program 1:

1 6 11 16 21 26

Day

Flow temp. setpoint [°C]

Heating up program 2:

1 6 11 16 21 26

Day

Flow temp. setpoint [°C]

Heating up program 3:

1 6 11 16 21 26

Day

Flow temp. setpoint [°C]

Heating up program 4:

1 6 11 16 21 26

Day

Flow temp. setpoint [°C]

Heating up program 5:

1 6 11 16 21 26

Day

Flow temp. setpoint [°C]

Heating up program 6:

1 6 11 16 21 26

Day

Flow temp. setpoint [°C]

Heating up program 7:

1 6 11 16 21 26

Day

Flow temp. setpoint [°C]

The heating up programs listed are non-binding rec‐ ommendations. If the heating up program is to be used for floor screed drying, you must consult the manufacturer of the floor finish and/or the installer

Menu overview and parameters

Menu - Heating

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 61

5.1.6 General Settings

Parameter Description

Correction value for external sensor

0°C If the outside temperature sensor shows an incorrect value, the value can

be adjusted using this parameter.

Heating circuit module to which the external sensor is con‐ nected (0 = core module)

0 If the outside temperature sensor is not connected to the core module, the

address of the relevant heating circuit module +1 must be set here. (Sen‐ sor 1 on relevant module)

Use room temperature sensor input for room thermostat

NO If room thermostats are used instead of room temperature sensors, this

parameter must be set to YES.

Menu overview and parameters

Menu - Heating

62 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

5.2 Menu - Water

⇨ See "Navigation within the system menu" [page 32]

5.2.1 Status displays for the DHW tank

Parameter Description

DHW tank top temperature 60°C Current temperature in the top part of the DHW tank. The DHW tank is

heated during the loading times until the specified parameter, "Set DHW temperature", is reached.

DHW tank bottom temperature 55°C Current temperature in the lower part of the DHW tank.

(Parameter only available with solar element)

DHW tank pump control 0% Specifies the speed of the DHW tank pump as a percentage of the maxi‐

mum speed

5.2.2 Temperature settings of the DHW tank

Parameter Description

DHW setpoint 55°C When this DHW tank temperature is reached the DHW tank loading pump

switches off.

Reload if DHW tank temperature is below

45°C Reloading of the DHW tank is authorised when the DHW tank temperature

is below this level.

Menu overview and parameters

Menu - Water

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 63

Load if temperature difference be‐ tween storage tank and DHW tank is

6°C When the storage tank top temperature is above the DHW tank tempera‐

ture by this value, the DHW tank loading pump is released. (Only for systems with storage tanks)

Load if temperature difference be‐ tween boiler and DHW tank is

6°C Initial value of DHW tank loading. The boiler temperature must be higher

than the DHW tank temperature by this value so that the DHW tank load‐ ing process begins.

(Only for systems without storage tanks)

5.2.3 Heating times of the DHW tank

⇨ See "Setting times" [page 35]

5.2.4 Service parameters of the DHW tank

Parameter Description

Residual heat use NO Function can only be used with systems with return mixer and no storage

tank. This diverts the residual energy to the DHW tank, the "Above Boiler temp pumps start” parameter is ignored. The pump is acti‐ vated at minimum speed until the boiler temperature is lower than the DHW tank temperature + 3°C.

Only load DHW tank once a day NO If this parameter is set to "YES", repeated heating on one day is preven‐

ted.

Legionella heating activated YES The DHW tank is heated to at least 65°C once a week.

Which day for legionella heating MO Day of the week on which the Legionella heating is carried out.

Menu overview and parameters

Menu - Water

64 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

Parameter Description

Which storage tank or heat distribu‐ tor supplies the heat to this DHW tank (0 = boiler)

1 When using several storage tanks or heat distributors, the source of heat

for DHW tank loading is selected here. If only one storage tank or heat distributor is used, leave the parameter at

the default setting of 1. NOTE: Only valid for multiple house systems.

DHW tanks run-on (this parameter applies for all DHW tanks)

0m Run-on time for all DHW tanks

Which sensor is used for top DHW tank 1

0.3 Bus address of the sensors and pumps used.

⇨ See "Setting the module address" [page

21]

Which sensor is used for solar refer‐ ence DHW tank 1

0.4

Which pump is used for DHW tank 1 0.2

PWM setting for DHW tank pump Normal

pump

▪ Normal pump ▪

PWM / field pump ▪ PWM / solar pump ▪ PWM field pump + valve ▪ 0 – 10V / field pump ▪ 0 – 10V / solar pump ▪ 0 – 10V field pump + valve

Properties of the respective setting:

⇨ See "PWM / 0 - 10V settings" [page 124]

Minimum DHW tank pump speed 45% Adjustment of the minimum speed to the pump type. (Set the pump mode

according to pump manufacturer’s instructions)

Maximum DHW tank pump speed 100% If you need to limit the maximum speed of the DHW tank pump for system‐

ic reasons, you can do so by adjusting this parameter.

Menu overview and parameters

Menu - Solar

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 65

5.3 Menu - Solar

⇨ See "Navigation within the system menu" [page 32]

5.3.1 Status displays for the solar system

Parameter Description

Collector Temperature 80°C Current temperature at collector.

Solar temperature bottom storage tank

43°C Current temperature at solar sensor at bottom of storage tank.

Collector return feed temperature 50°C Current temperature at collector return.

(Only for systems 12, 13)

Current output of Solar WMZ [kW] 0.00 Displays current output of solar collector.

DFL Sensor [l/h] 0 Display of the water quantity currently being pumped through the solar col‐

lector. NOTE: Display is active only if an external volume flow sensor is used and it has been activated in the controller.

Todays yield [kWh]] 0 Heat quantity that has been supplied by the solar panel system today

Total yield [kWh] 0 Heat quantity that has been supplied since activation of the solar panel

system

DHW tank bottom temperature 39°C Current temperature at the solar reference sensor in the DHW tank.

Heat exchanger sec. return feed temperature (line to storage tank)

78°C Current temperature at heat exchanger flow on the secondary side. (only

for systems 12, 13)

Collector pump runtime 1 h Specifies the runtime of the collector pump.

Collector pump control 52% Specifies the speed of the collector pump as a percentage of maximum

speed.

Pump between heat exchanger and storage tank

100% Current speed of the pump between heat exchanger and storage tank (on‐

ly for systems 12, 13)

Menu overview and parameters

Menu - Solar

66 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

Parameter Description

Pump between heat exchanger and DHW tank

0% Current speed of the pump between heat exchanger and DHW tank (only

for system 12)

Diverter valve for top/bottom coils 0% Current control of the isolating valve on the solar side. If the valve is cor‐

rectly fitted: 0% ... storage tank below 100% .. storage tank above If the valve is incorrectly fitted, the output of the isolating valve can be in‐ verted in the Service menu. Service parameters of the solar system (only with system 12, 13)

5.3.2 Temperature settings for the solar system

Parameter Description

Boiler target temperature during so‐ lar charging

75°C Up to this temperature the DHW tank is heated by the solar system.

Temp differential to start collector pump

10°C The collector loading pump activates when the collector temperature ex‐

ceeds the storage or DHW tank temperature by this value.

Temp difference to stop collector pump

5°C The collector loading pump switches off when the collector temperature

exceeds the storage or DHW tank temperature by this value.

Maximum storage tank bottom tem‐ perature during solar charging

85°C Maximum bottom storage tank temperature at which the collector pump is

switched off (only with storage tank).

Minimum collector temperature 20°C Below this collector temperature the collector pump is switched off.

Heat exchanger - storage tank pump startup delay

120s Delay for switching on the pump between heat exchanger and storage

tank (only for systems 12, 13).

Heat exchanger - storage tank pump stop delay

240 s Delay for switching off the pump between heat exchanger and storage

tank (only for system 12, 13).

Storage tank top solar setpoint (fast loading until this temperature)

60°C Once the top storage tank sensor reaches the set value during solar

charging, the isolating valve switches to bottom storage tank (Only with systems 12, 13).

Collector - storage tank top differen‐ tial

20°C This is the overcharge for the collector pump controller for the top or bot‐

tom storage tank temperature.

Collector - heat exchanger sec., out‐ feed difference

10°C This parameter specifies how much the heat exchanger secondary out‐

feed should be below the collector temperature. If the temperature is too low, the speed of the storage tank or DHW tank pump will be reduced.

Collector return - storage tank bot‐ tom differential

20°C Storage tank bottom plus the set value produces the desired temperature

of the collector return. If the collector return is too high, the storage tank pump speed is reduced.

Menu overview and parameters

Menu - Solar

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 67

5.3.3 Service parameters of the solar system

Parameter Description

Solar system 1 Specifies the type of solar system. The parameter should be set according

to the solar diagram. 1: Solar panel system only on domestic hot water tank 2: Solar panel system only on storage tank 3: Solar panel system with switch valve (switch from domestic hot water

tank to storage tank, or between top and bottom solar elements with the H3 hygienic solar layered tank)

Observe the information on the solar panel system in the "

Lambdatronic H

3200 T4 energy systems" documents.

Which pump is used for the solar collector

1.1 Bus address of the pump that is used.

⇨ See "Setting the module address" [page

21]

Observe the information on the solar panel system in the "Lambdatronic H 3200 T4 energy systems" documents.

PDM setting for solar collector pump Normal

pump

▪ Normal pump ▪

PDM / field pump ▪ PDM / solar pump ▪ PDM field pump + valve ▪ 0 – 10V / field pump ▪ 0 – 10V / solar pump ▪ 0 – 10V field pump + valve

Properties of the respective setting:

⇨ See "PWM / 0 - 10V settings" [page 124]

Minimum collector pump speed 45% Adjustment of the minimum speed to the pump type. (Set the pump mode

according to pump manufacturer’s instructions)

Maximum collector pump speed 100% If you need to limit the maximum speed of the collector pump for systemic

reasons, you can do so by adjusting this parameter.

Collector monitoring → Collector pump is switched on every 30 min. for 10 sec

NO If this parameter is active the collector pump is switched on every 30 mi‐

nutes for 10 seconds. If the collector sensor detects an increase in tem‐ perature, the pump is kept on.

This function is active from 10:00am - 7:00pm and the threshold value of the collector temperature, from which this function is active, is dynamically adjusted.

Menu overview and parameters

Menu - Solar

68 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

Parameter Description

For solar to store and DHW tank, the DHW tank has priority

YES YES: The DHW tank is charged until the temperature setpoint is reached,

and only then is the storage tank supplied. NO: The DHW tank is charged until the temperature difference between

the collector and the DHW tank is no longer sufficient. When the tempera‐ ture difference has fallen too low, the storage tank is supplied with heat for 20 minutes. Then the collector pump is stopped for 20 minutes and a check is carried out to see if the temperature difference is now sufficient for DHW tank charging.

Solar charging to which store 1 Defines the storage tank to which the solar charging takes place.

Solar charging to which DHW tank 1 Defines the DHW tank to which the solar charging takes place.

Which sensor is used for the solar collector

1.1 Bus addresses of the sensors used, depending on the system

⇨ See "Setting the module address" [page

21]

Observe the information on the solar panel system in the "Lambdatronic H 3200 T4 energy systems" documents.

Which sensor is used for the stor‐ age tank reference

0.2

Which sensor is used for the heat exchanger sec. flow?

1.4

Which sensor is used for the collec‐ tor return

1.5

Which pump is used for the solar isolating valve

1.2

Which pump is used for storage tanks - heat exchanger

2.1

PDM setting for the storage tank heat exchanger pump

Normal

pump

▪ Normal pump ▪

PDM / field pump ▪ PDM / solar pump ▪ PDM field pump + valve ▪ 0 – 10V / field pump ▪ 0 – 10V / solar pump ▪ 0 – 10V field pump + valve

Properties of the respective setting:

⇨ See "PWM / 0 - 10V settings" [page 124]

Which pump is used for DHW tanks

- heat exchanger

2.2 Bus addresses of the sensors used, depending on the system

⇨ See "Setting the module address" [page

21]

Observe the information on the solar panel system in the "Lambdatronic H 3200 T4 energy systems" documents.

PDM setting for the DHW tank heat exchanger pump

Normal

pump

▪ Normal pump ▪

PDM / field pump ▪ PDM / solar pump ▪ PDM field pump + valve ▪ 0 – 10V / field pump ▪ 0 – 10V / solar pump ▪ 0 – 10V field pump + valve

Properties of the respective setting:

⇨ See "PWM / 0 - 10V settings" [page 124]

Invert isolating valve NO For DHW tank loading through the collector, the isolating valve is activated

with 230V. If the valve switches incorrectly, the way it is controlled can be adjusted using this parameter.

Menu overview and parameters

Menu - Solar

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 69

Parameter Description

Is a PT1000 sensor used as a solar sensor?

NO Basic setting for the sensor type used:

NO: Solar sensor - Froling YES: Sensor PT1000

Collector pump control Kp value 1.00 Control parameter for collector pump

Collector pumps control Tn value 300s

5.3.4 Solar heat meter

Parameter Description

Outfeed: 0 °C / Return: NA P: 0.0kW / DFL: 0 Today: 0 kWh Total: 0 kWh

Solar heat meter:

Outfeed: Flow temperature of the solar panel system Return: Return of the solar panel system P: Current output of the solar panel system DFL: Flow-through of the solar panel system Today: Heat quantity that has been supplied by the solar panel system to‐ day Total: heat quantity that has been supplied since activation of the solar panel system

Collector Temperature 80°C Current temperature at collector.

Collector return feed temperature 50°C Current temperature at collector return.

Current output of Solar WMZ [kW] 0.00 Displays current output of solar collector.

DFL Sensor [l/h] 0 Display of the water quantity currently being pumped through the solar

collector. NOTE: Display is active only if an external volume flow sensor is used and it has been activated in the controller.

Todays yield [kWh]] 0 Heat quantity that has been supplied by the solar panel system today

Total yield [kWh] 0 Heat quantity that has been supplied since activation of the solar panel

system

Nominal flow of collector pump for heat meter [L/h]

0 Sets the nominal flow of the collector pump used.

This setting can be ignored if using an external flow meter.

Pulses per litre from the flow sensor 2.0 If an external flow meter is used, adjust this value according to the device

used. [0.5 – 5 pulses/L]

Which sensor is used for the collec‐ tor return

1.5 Bus addresses of the sensors used, depending on the system

⇨ See "Setting the module address" [page

21]

Menu overview and parameters

Menu - Solar

70 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

Which sensor is used for heat meter flow temperature

1.3 If a flow temperature sensor is used for the heat meter in addition to the collector sensor, set the sensor address accordingly. Bus addresses of the sensors used, depending on the system

⇨ See "Setting the module address" [page 21]

Is an external flow through counter used

NO If an external volume flow sensor is used in the collector return, set this

parameter to “YES”.

Menu overview and parameters

Menu - Storage tank

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 71

5.4 Menu - Storage tank

⇨ See "Navigation within the system menu" [page 32]

5.4.1 Status displays of the storage tank

Parameter Description

Storage tank top temperature 58°C Current temperature at top storage tank sensor.

Storage tank temperature, sensor 2 55°C Only for the master boiler in the cascade.

Storage tank temperature, sensor 3 54°C Only for the master boiler in the cascade.

Storage tank middle temperature 53°C Current temperature at middle storage tank sensor (depending on configu‐

ration).

Storage tank bottom temperature 50°C Current temperature at bottom storage tank sensor.

Store pump control 50% Specifies the current speed of the storage tank pump as a percentage of

the maximum speed.

Store charge 25% Shows the current storage tank charge.

5.4.2 Temperature settings for the storage tank

Menu overview and parameters

Menu - Storage tank

72 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

Parameter Description

Heating circuit release from follow‐ ing storage tank temperature

30°C Minimum value of storage tank top temperature for heating circuit release

in combinations with a storage tank

Boiler start if difference between boiler setpoint and top store is larg‐ er

15°C If the difference between the top store and the boiler setpoint is greater

than the specified value, the boiler starts

Start of store charging from charge

75% If the storage tank charge is below the specified value, the boiler system

starts.

100% boiler control variable when store charge is lower than

40% If the storage tank charge is below the specified value, the boiler system

runs at nominal load.

0% boiler output if store charge is over

100% If the storage tank charge is greater than the specified value, the boiler

system follows the shutdown procedure.

Store charge is 100% at boiler setpoint parameter

4°C 100% storage tank charge is calculated from the specified boiler tempera‐

ture setpoint minus the specified value.

Store charge is 0% at the following temperature

30°C If the average temperature in the storage tank is less than the specified

value, the storage tank has a charge of 0%.

Storage tank fully loaded if tempera‐ ture difference between boiler and bottom storage tank

10°C From this temperature difference between the boiler target temperature

and the bottom storage tank temperature, storage tank loading is stopped.

5.4.3 Heating times of the storage tank

⇨ See "Setting times" [page 35]

Menu overview and parameters

Menu - Storage tank

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 73

5.4.4 Service parameters of the storage tank

Parameter Description

Enable heating circuit pump 0 ac‐ cording to top store

NO NO: Release of heating circuit pump 0 from boiler temperature

Temperature settings for the boiler Parameter "Minimum boiler temperature to release all

pumps". YES: Release of heating circuit pump 0 from top storage tank temp. Temperature settings for storage tanks Parameter "Heating circuit release from following storage

tank temperature"

Control store requests according to system environment

NO All heating circuits and DHW tanks that are connected to the boiler system

and activated report requirements back to the controller on the basis of temperature specifications or according to the outside temperature. These requirements are compared with the current temperature in the top stor‐ age tank and if this temperature is too low the boiler is started. If there is no requirement from the system or if the loading criterion is fulfilled, the boiler system is stopped.

According to system environment, store request shutdown delay of

10m Parameter only if "Control store requests according to sys-

tem environment" parameter is active. If there is no requirement from the system, the boiler system stops at the end of the specified time.

Which sensor is used for storage tank top

0.1 Parameter display depends on the system. Observe the information on the hydraulic system in the "

Lambdatronic H

3200 T4 energy systems" documents.

Which sensor is used for storage tank sensor 2

0.4

Which sensor is used for storage tank sensor 3

0.6

Which sensor is used for bottom storage tank

0.2

Menu overview and parameters

Menu - Storage tank

74 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

Which pump is used for the storage tank

0.1

PWM setting for storage tank pump Normal

pump

▪ Normal pump ▪

PWM / field pump ▪ PWM / solar pump ▪ PWM field pump + valve ▪ 0 – 10V / field pump ▪ 0 – 10V / solar pump ▪ 0 – 10V field pump + valve

Properties of the respective setting:

⇨ See "PWM / 0 - 10V settings" [page 124]

Minimum storage tank pump speed 45% Adjustment of the minimum speed to the pump type. (Set the pump mode

according to pump manufacturer’s instructions)

Maximum storage tank pump speed 100% If you need to limit the maximum speed of the storage tank pump for sys‐

temic reasons, you can do so by adjusting this parameter.

Menu overview and parameters

Menu - Boiler

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 75

5.5 Menu - Boiler

⇨ See "Navigation within the system menu" [page 32]

5.5.1 Status displays for the boiler

Parameter Description

Boiler temperature 77°C Display of the current values for the relevant parameter.

Flue gas temperature 190°C

Flue gas setpoint 193°C

Boiler control variable 58%

ID fan control 88%

ID fan speed 2460

rpm

Air flap control 50%

Position of the air flap 49%

Residual oxygen content 8.5%

Calculated boiler setpoint 77°C

Return setpoint calculated 62°C

Return feed sensor 63°C

Return pump controller 60%

Menu overview and parameters

Menu - Boiler

76 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

5.5.2 Temperature settings for the boiler

Parameter Description

Boiler temperature setpoint 80°C The boiler temperature is regulated to this temperature.

Shutdown if current boiler tempera‐ ture is higher than boiler setpoint +

7°C If the current boiler temperature exceeds the boiler temperature setpoint

by this value, the boiler switches off.

Always shutdown when boiler maxi‐ mum setpoint is exceeded by

3°C The boiler switches off if the current boiler temperature exceeds the maxi‐

mum adjustable boiler temperature by this value. The heating circuit and storage tank loading pump are also switched on to cool the boiler.

Above Boilertemp pumps start 65°C The pumps are released at this boiler temperature.

(Hysteresis 2°C)

Minimum return temperature 60°C The minimum temperature required of the return to the boiler.

Return setpoint delay 200 s Waiting time between the calculations for the return temperature setpoint

adjustment. Once the specified time has passed, the heating system tem‐ peratures are evaluated.

Return setpoint boost (power influ‐ ence)

50% This setting determines how heavily the deviation of the actual boiler tem‐

perature from the boiler temperature setpoint is weighted.

Return feed lift min. dif. at min. out‐ put

10°C Minimum difference between boiler setpoint and return setpoint. The boil‐

er temperature difference should not fall below this value. (Setting applies to partial load)

Return feed lift min. dif. at 100% output

10°C Minimum difference between boiler setpoint and return setpoint. The boil‐

er temperature difference should not fall below this value. (Setting applies to partial load)

An interpolation is made between the two settings between partial and nominal load.

Heating circuit overheat in variable mode

1°C If variable mode is activated, the boiler setpoint temperature in heating

mode is increased by this value compared to the required flow tempera‐ ture.

Menu overview and parameters

Menu - Boiler

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 77

5.5.3 Heating times of the boiler

⇨ See "Setting times" [page 35]

5.5.4 Service parameters of the boiler

Parameter Description

Variable mode activated NO The boiler temperature is controlled according to the calculated flow value

for the heating circuit/DHW tank.

Mixer runtime 240 s Sets mixer runtime of the mixer in use.

Recommendation to reduce mixer vibration: Do not set to < 150 s

Menu overview and parameters

Menu - Boiler

78 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

5.5.5 General Settings

Parameter Description

Modem installed NO If the boiler has a modem for data transfer, this value must be set to

"YES".

Memory cycle of data logger 5 s Do not change this value!

This is the memory cycle used for saving data on the data logger.

Output warnings through fault mes‐ sage relays

NO If this parameter is set to "YES", warnings from the boiler system are also

displayed on the fault message relay.

COM 2 is used as a MODBUS inter‐ face

NO YES:

The COM 2 interface can be used for connection with a MODBUS (RTU/ ASCII)

NO: The COM 2 interface sends the most important boiler values every sec‐ ond

MODBUS address 2 Adjustable parameters for MODBUS

MODBUS protocol (1 – RTU / 2 – ASCII)

Set hours since last maintenance to0NO To reset the counter “Hours since last maintenance”, this parameter must

be set to "YES”. After the has been reset, the parameter jumps to "NO”.

Menu overview and parameters

Menu - Boiler

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 79

Operator data

Parameter Description

Facility name 199999999 For unique identification of the boiler on the froeling-connect.com server,

the facility number listed on the identification plate must be set here.

Customer no. 263586 If both the customer and the boiler number are set, they are automatically

transferred into the commissioning report when it is saved.

Boiler number 560

Menu overview and parameters

Menu - Boiler

80 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

5.6 Menu - Boiler 2

⇨ See "Navigation within the system menu" [page 32]

5.6.1 Status displays for the backup boiler

Parameter Description

Temperature of standby boiler

23°C Display of the current temperature of the standby boiler

Burner relay status 0 Shows the current status of the burner relay

Manual start of standby boiler (only when ID fan is switched off)

OFF When the parameter is activated the standby boiler starts.

Warning! Burner blockage noted.

5.6.2 Temperature settings for the backup boiler

Parameter Description

Standby boiler start delay 10 m Start delay of the burner relay if the boiler fails (the boiler status is off, fault

or shut down and the boiler temperature is 5°C below the setpoint). In storage mode the burner relay, however, only comes on when the storage tank has cooled down. (Top storage tank temperature is lower than the highest required tempera‐ ture)

Standby boiler start, if storage tank top temperature is below

20°C Temperature at the top of the storage tank, which the temperature must

fall below for the standby boiler to be activated

Menu overview and parameters

Menu - Boiler 2

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 81

Standby boiler minimum runtime 5 m Standby boiler minimum runtime

Minimum temperature of standby boiler

55°C Minimum temperature of the standby boiler for release of standby boiler

unloading output.

Temperature difference between standby boiler and storage tank

10°C Minimum temperature difference between standby boiler and storage tank,

which releases secondary boiler unloading output.

Oil valve shut delay 30s The switching back of the isolating valve is delayed by the specified time.

Standby boiler delivery temperature 95°C If the standby boiler exceeds the specified temperature, the isolating valve

switches and skims the boiler (only with hydraulic system 3)

5.6.3 Service parameters of the backup boiler

Parameter Description

Control backup boiler variably to the target value

YES If the backup boiler has no independent control, the main control takes

over control of the boiler setpoints of the backup boiler.

Which sensor is used for standby boilerWhich sensor is used for back‐ up boiler

0.5 Bus address of the sensor used.

⇨ See "Setting the module address" [page

21]

Observe the information on hydraulic systems in the "Lambdatronic H 3200 T4 energy systems" documents.

Which output is used for unloading backup boiler

Pump 1

PWM setting for solar collector pump

Normal

pump

▪ Normal pump ▪

PWM / field pump ▪ PWM / solar pump ▪ PWM field pump + valve ▪ 0 – 10V / field pump ▪ 0 – 10V / solar pump ▪ 0 – 10V field pump + valve

Properties of the respective setting:

⇨ See "PWM / 0 - 10V settings" [page 124]

Minimum speed of boiler 2 pump 45% Adjustment of the minimum speed to the pump type. (Set the pump mode

according to pump manufacturer’s instructions)

Maximum speed of boiler 2 pump 100% If you need to limit the maximum speed of the boiler 2 pump for systemic

reasons, you can do so by adjusting this parameter.

Invert backup boiler isolating valve NO For DHW tank loading through the backup boiler, the isolating valve is ac‐

tivated with 230V. If the valve switches incorrectly, this parameter can be adjusted.

Menu overview and parameters

Menu - Boiler 2

82 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

Parameter Description

Which second boiler is installed? Oil boil‐erStandby boiler type:

- - OIL BOILER

- MANUALLY FED

- AUT. FED

- GAS BOILER

Burner relays A 0

Menu overview and parameters

Menu - Fuel

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 83

5.7 Menu - Fuel

⇨ See "Navigation within the system menu" [page 32]

5.7.1 Service parameters for fuel

Parameter Description

Fuel selection Dry chip Selection of the fuel used:

(depending on the boiler and discharge)

Dry chip

Moist chip

Pellets

Adopt specified material values NO Parameter for adopting the preset boiler parameters for the previously set

fuel. Adopt specified values:

Set parameter to "YES" and wait until the value returns to "NO". Only then have the values been adopted.

❒

Only adopt specified values in "Boiler off" status.

➥ Warning! Startup values are reset.

Menu overview and parameters

Menu - Fuel

84 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

5.8 Menu - Feed system

⇨ See "Navigation within the system menu" [page 32]

5.8.1 Stoker screw

Parameter Description

Nominal current for stoker screw (MSS*2)

1.00 A Nominal current for the stoker screw motor according to the identification plate on the motor.

5.8.2 Feed screw

Parameter Description

Nominal current for feed screw 0.80 A Nominal current for the discharge screw motor according to the identifica‐

tion plate on the motor.

When troubleshooting the feed screw, it turns backwards for

1.0 s How long should the screw turn backwards during troubleshooting

When troubleshooting the feed screw, it turns forwards for

1.5 s How long should the feed screw turn forwards during troubleshooting

Menu overview and parameters

Menu - Feed system

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 85

5.8.3 Screw 1

Parameter Description

Screw active NO If “Screw 1” is used at the feed system module, set this parameter to

“YES”. The relevant connection components are:

❒

“Screw 1” output ❒ “Drop box cover 1” input ❒ “Light barrier 1” connection

Nominal current for feed screw 0.8 A Nominal current for the motor of “screw 1” motor according to the identifi‐

cation plate on the motor.

During troubleshooting of feed screw, it turns backwards for

1.0 s How long should the screw turn backwards during troubleshooting.

During troubleshooting of feed screw, it turns forwards for

1.5 s How long should the feed screw turn forwards during troubleshooting.

Switch-on delay feed screw light barrier

3.0 s The time for which the light barrier must consistently recognise material to activate material recognition in the drop box.

Switch-off delay feed screw light barrier

2.0 s The time for which the light barrier must consistently recognise no material to deactivate material recognition in the drop box.

Maximum idle time of screw 60 m Time delay until an error in the material recognition is tripped.

5.8.4 Screw 2

Menu overview and parameters

Menu - Feed system

86 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

Parameter Description

Screw active NO If “Screw 2” is used at the feed system module, set this parameter to

“YES”. The relevant connection components are:

❒

“Screw 2” output ❒ “Gravity shaft cover 2” input ❒ “Light barrier 2” connection

Nominal current for feed screw 0.8 A Nominal current for the motor of “screw 2” motor according to the identifi‐

cation plate on the motor.

When troubleshooting the feed screw, it turns backwards for

1.0 s How long should the screw turn backwards during troubleshooting

When troubleshooting the feed screw, it turns forwards for

1.5 s How long should the feed screw turn forwards during troubleshooting

Switch-on delay feed screw light barrier

3.0 s The time for which the light barrier must consistently recognise material to activate material recognition in the drop box.

Switch-off delay feed screw light barrier

2.0 s The time for which the light barrier must consistently recognise no material to deactivate material recognition in the drop box.

Maximum idle time of screw 60 m Time delay until an error in the material recognition is tripped.

Menu overview and parameters

Menu - Network pump

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 87

5.9 Menu - Network pump

⇨ See "Navigation within the system menu" [page 32]

5.9.1 Network pump status displays

Parameter Description

Network return temperature 40°C Display of the current values for the relevant parameter. Position of the

sensors and pumps depending on the system used: Note the information on multiple house diagrams in the “

Lambdatronic H

3200 T4 energy systems" documents.

Network pump speed 60%

Return temperature feeder 1 0°C

Speed, feeder 1 0%

Return temperature feeder 2 0°C

Speed, feeder pump 2 0%

5.9.2 Network pump temperature settings

Parameter Description

Network return temperature setpoint 50°C Settings for the desired network temperature setpoints. Position of the

sensors depending on the system used: Note the information on multiple house diagrams in the “

Lambdatronic H

3200 T4 energy systems" documents.

Return temperature setpoint at feeder 1

50°C

Return temperature setpoint at feeder 2

50°C

Menu overview and parameters

Menu - Network pump

88 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

5.9.3 Service parameters for the network pump

Parameter Description

Only switch on the network pump when required by the store (variant 3 / 4 only)

NO YES:

The network pump switches on, if there is a requirement from a storage tank.

NO: The network pump switches on, if there is a requirement from a storage tank, a DHW tank or a heating circuit.

With variant 3 only storage tanks 2, 3 and 4 are considered.

Which sensor is used for the network return temperature

0.6 Bus addresses of the sensors used, depending on the system

⇨ See "Setting the module address" [page

21]

Observe the information on hydraulic systems in the "Lambdatronic H 3200 T4 energy systems" documents.

Which pump is used for the network pump

0.2

PWM setting for network pump Normal

pump

▪ Normal pump ▪

PWM / field pump ▪ PWM / solar pump ▪ PWM field pump + valve ▪ 0 – 10V / field pump ▪ 0 – 10V / solar pump ▪ 0 – 10V field pump + valve

Properties of the respective setting:

⇨ See "PWM / 0 - 10V settings" [page 124]

Minimum speed of network pump 45% Adjustment of the minimum speed to the pump type. (Set the pump mode

according to pump manufacturer’s instructions)

Maximum speed for network pump 100% If you need to limit the maximum speed of the storage tank pump for sys‐

temic reasons, you can do so by adjusting this parameter.

Which sensor is used for feeder 1

1.6 Bus addresses of the sensors used, depending on the system

⇨ See "Setting the module address" [page

21]

Observe the information on hydraulic systems in the "Lambdatronic H 3200 T4 energy systems" documents.

Which pump is used for feeder 1

1.1

Menu overview and parameters

Menu - Network pump

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 89

Parameter Description

PWM setting for feeder pump 1 Normal

pump

▪ Normal pump ▪

PWM / field pump ▪ PWM / solar pump ▪ PWM field pump + valve ▪ 0 – 10V / field pump ▪ 0 – 10V / solar pump ▪ 0 – 10V field pump + valve

Properties of the respective setting:

⇨ See "PWM / 0 - 10V settings" [page 124]

Minimum speed for feeder pump 1 45% Adjustment of the minimum speed to the pump type. (Set the pump mode

according to pump manufacturer’s instructions)

Maximum speed for feeder pump 1 100% If you need to limit the maximum speed of the storage tank pump for sys‐

temic reasons, you can do so by adjusting this parameter.

Menu overview and parameters

Menu - Cascade

90 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

5.10 Menu - Cascade

⇨ See "Navigation within the system menu" [page 32]

5.10.1 Status displays for the cascade

Parameter Description

Store charge 0% Displays the current values for the relevant parameter.

Backup boiler 1

Backup boiler 2

Backup boiler 3

5.10.2 Status display of the cascade backup boiler

Parameter Description

Backup boiler boiler temperature 40°C Displays the current values for the relevant parameter.

Backup boiler OK 1

Backup boiler is heating 1

Backup boiler control variable 96%

Boiler charging pump speed 45%

Menu overview and parameters

Menu - Cascade

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 91

5.10.3 Temperature settings for the cascade

Parameter Description

Storage tank charge is 100% at boil‐ er setpoint parameter

4°C The store charge is 100% if the average temperature of the storage tank is

below the specified boiler setpoint temperature by the specified value.

Store charge is 0% at the following temperature

30°C The average temperature the storage tank must reach in order to show a

store charge of 0%.

Start point 1 at store charge 75% If the store charge falls below the specified value, the first boiler in the

cascade starts up.

Start point 2 at store charge 60% If the store charge falls below the specified value, the second boiler in the

cascade starts up.

Start point 3 at store charge 40% If the store charge falls below the specified value, all boilers in the cas‐

cade start up.

Quick start if store discharge is greater than (%/10 min)

15 If the storage tank is discharged by the specified value within 10 min, the

largest boiler in the cascade starts up.

Reduce the overall output of the cascade before the storage tank is fully loaded

60% The parameter defines the maximum power reduction of the cascade be‐

fore the storage tank is fully loaded (modulation of the boiler system)

5.10.4 Service parameters of the cascade

Menu overview and parameters

Menu - Cascade

92 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

Parameter Description

Start priority of the master boiler

1 Defines the start priorities of the individual boiler systems in the cascade.

If the same priority is set for two or more boiler systems, the boiler start order is determined by the service hours of the boiler systems

Start priority of slave boiler 1

Start priority of slave boiler 2

Start priority of slave boiler 3

Menu overview and parameters

Menu - Difference regulator

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 93

5.11 Menu - Difference regulator

⇨ See "Navigation within the system menu" [page 32]

5.11.1 Status displays for the difference regulator

Parameter Description

Heat source sensor 70°C Current temperature of the heat source (heat distributor, e.g. storage tank)

Heat sink sensor 60°C Current temperature of the heat sink (user, e.g. DHW tank)

Pump speed 45% Current pump speed

5.11.2 Temperature settings for the difference regulator

Parameter Description

Startup difference 10°C If the temperature difference between the heat source and the heat sink

exceeds this value, the pump activates

Shutdown difference 5°C If the temperature difference between the heat source and the heat sink

falls below this value, the pump is deactivated.

Minimum temperature for heat source

10°C Temperature settings for regulating range of the differential temperature

regulating output.

Maximum temperature for heat sink

100°C The standard settings of 10°C or 100°C are selected so that the values in

normal operation stay outside a limit.

Menu overview and parameters

Menu - Difference regulator

94 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

5.11.3 Service parameters for the difference regulator

Parameter Description

Which pump is used

7.2 Bus addresses of the sensors used, depending on the system

⇨ See "Setting the module address" [page

21]

Observe the information on hydraulic systems in the "Lambdatronic H 3200 T4 energy systems" documents.

PDM setting for diff. controller pump Normal

pump

▪ Normal pump ▪

PDM / field pump ▪ PDM / solar pump ▪ PDM field pump + valve ▪ 0 – 10V / field pump ▪ 0 – 10V / solar pump ▪ 0 – 10V field pump + valve

Properties of the respective setting:

⇨ See "PWM / 0 - 10V settings" [page 124]

Minimum pump speed

45% Adjustment of the minimum speed to the pump type. (Set the pump mode

according to pump manufacturer’s instructions)

Maximum pump speed 100% If you need to limit the maximum speed of the diff. controller pump for sys‐

temic reasons, you can do so by adjusting this parameter.

Which sensor is used for the heat source

7.5 Bus addresses of the sensors used, depending on the system

⇨ See "Setting the module address" [page

21]

Observe the information on hydraulic systems in the "Lambdatronic H 3200 T4 energy systems" documents.

Which sensor is used for the heat sink

7.6

Sensor monitoring YES If relatively low temperatures (< 5°C) occur when using the diff. controller,

setting the parameter to “NO” suppresses the error message

Menu overview and parameters

Menu - Difference regulator

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 95

5.12 Menu - Circulation pump

⇨ See "Navigation within the system menu" [page 32]

5.12.1 Status displays for the circulation pump

Parameter Description

Return temperature in circulation line

45°C Shows the current temperature at the return sensor of the circulation line.

If the parameter "Return sensor present" is set to "NO", 0°C is permanent‐ ly displayed.

Flow switch on the domestic hot water line

1 Shows the current status of the flow sensor.

0 ... No flow at the valve 1 ... Valve registers flow

Speed of the circulation pump

100% Current circulation pump speed

5.12.2 Temperature settings for the circulation pump

Menu overview and parameters

Menu - Circulation pump

96 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

Parameter Description

Is a return sensor present? YES YES:

The circulation pump is controlled according to time program and temper‐ ature at the sensor. In conjunction with the use of a flow valve, the circula‐ tion pump is also activated at a signal from the flow valve.

NO: The circulation pump is controlled according to time program. In conjunc‐ tion with the use of a flow valve, the circulation pump is also activated at a signal from the flow valve.

Connect the flow sensor as the return sensor!

Switch off the pump at what return temperature in the circulation line

50°C Parameter only relevant when a return sensor is used!

If the set temperature is reached, the circulation pump shuts down.

Circulation pump run-on 300s Parameter only when a flow valve is used!

If the flow valve does not register any more flow, the circulation pump car‐ ries on running for the time set.

5.12.3 Time settings for the circulation pump

⇨ See "Setting times" [page 35]

5.12.4 Service parameters of the circulation pump

Menu overview and parameters

Menu - Circulation pump

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 97

Parameter Description

Which sensor is used for the circulation return

0.6 Bus addresses of the sensors and pumps used, depending on the system

⇨ See "Setting the module address" [page

21]

Observe the information on hydraulic systems in the "Lambdatronic H 3200 T4 energy systems" documents.

Which sensor input is used for the flow switch

1.5

Which pump is used for the circula‐ tion

3.1

PWM settings for the circulation pump

Normal

pump

▪ Normal pump ▪

PWM / field pump ▪ PWM / solar pump ▪ PWM field pump + valve ▪ 0 – 10V / field pump ▪ 0 – 10V / solar pump ▪ 0 – 10V field pump + valve

Properties of the respective setting:

⇨ See "PWM / 0 - 10V settings" [page 124]

Minimum speed of the circulation pump

45% Adjustment of the minimum speed to the pump type. (Set the pump mode

according to pump manufacturer’s instructions)

Maximum speed of the circulation pump

100% If you need to limit the maximum speed of the circulation pump for system‐

ic reasons, you can do so by adjusting this parameter.

Menu overview and parameters

Menu - Manual

98 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

5.13 Menu - Manual

⇨ See "Navigation within the system menu" [page 32]

5.13.1 Manual operation

Parameter Description

Stoker ON OFF Used to switch on individual boiler components. The parameters displayed

depend on the boiler configuration.

❒

Manual operation is only possible in "Boiler off" operating status.

Feed screw ON OFF

Screw 1 OFF

Screw 2 OFF

Oufeeder - manual OFF

Ignition OFF

Discharge screw OFF

Ash screw OFF

WOS motor OFF

Grate tip drive OFF

Rinse the condenser manually (only when boiler is off / on standby)

OFF

5.13.2 Digital outputs

Menu overview and parameters

Menu - Manual

Operating Instructions Lambdatronic H 3200 T4 - Touch | B0820314_en 99

Parameter Description

Lambda probe heating A 0 Used to test the digital outputs and is intended only for service techni‐

cians. The parameters displayed vary depending on the configuration A … Automatic

-A 0 ... Automatic, OFF

-A 1 … automatic, ON

0 … MANUAL, OFF 1 … MANUAL, ON

Heating circuit pump 0 A 0

Standby relay A 0

Ignition A 0

Common fault relay A 0

WOS motor A 0

Ash screw A 1

Return feed mixing valve open A 0

Return feed mixing valve closed A 0

Grate tip drive A 0

Stoker forwards A 0

Stoker backwards A 0

Feed screw forwards A 0

Feed screw backwards A 0

Delivery screw forwards A 0

Delivery screw backwards A 0

Screw 1 Forward A 0

Screw 1 Back A 0

Screw 2 Forward A 0

Screw 2 Back A 0

5.13.3 Analogue outputs

Parameter Description

Air flap Actual

value:

18%

A 0%

Used to test the analogue outputs and is intended only for service techni‐ cians. The parameters displayed vary depending on the configuration

A … automatic

-A 0% … automatic, OFF

-A 1% - 100% … automatic, with % value ON

0% … manual, OFF

ID Fan Actual

value: 0

rpm

A 0%

Menu overview and parameters

Menu - Manual

100 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

Froling Lambdatronic H 3200 T4 Operating Instructions Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
