Fri-Jado Bake Basic 3 User Manual
Top features
• Table-top economic choice
• Consistent, even baking result
• Simple manual controls
Standard characteristics
• Capacity: 60 bread rolls per batch
• Auto-reverse fan system
• 3 baking layers, with a height of 75 mm
• Optimum airfl ow
• 25 programs with three baking steps
• Set time, temperature and steam mode
• Steam injection
• Single phase connection
• Rounded corners for easy cleaning
• Perfect product illumination
• Side hinged door
• Stainless steel interior and exterior
Accessories
• Extraction hood
• Stand
• Water fi ltration system
• Baking trays, grids 400x600 mm
Optional
• Stacked as 3+3, 5+3
Bakery Ovens
Bake Basic 3
Programmable
The features of the Fri-Jado Bake
Basic are as simple as they are
effective. They include three
baking positions with a height of
75mm, brilliant halogen lighting,
automatic cool-down, clear
display and rounded corners in
the baking chamber for easy
cleaning.
The Bake Basic is fi tted with a
large fan that rotates alternately
in opposite directions, achieving
optimum airfl ow in the baking
room. This ensures that all your
bread products are evenly baked
with consistently perfect results.
Rounded corners
The Bake Basic Programmable can
memorize 25 baking programs
with up to three baking steps per
program. You can set the time,
temperature and steam mode.
Large fan
Halogen lightingBake Basic stacked
Practical and compact
100
410
205
1415
Bake Basic 3
Programmable
3
205
Item Description
5
340
4
47
5
1060
840
340
3
4
946
2
1
6
7
3
205
5
340
4
47
5
5
460
6
7
946
2
1
6
7
1 Power cable 2 m
2 Water supply inlet
3 Fume outlet
4 Fume outlet
5 Space to wall
6 Location for wall socket
7 Location for tap
Dimensions
Width 840 mm
Depth 732 mm
Height 460 mm
Height on stand 1470 mm
Technical data
Net weight 63 kg
Gross weight 77 kg
Voltage 230 V
1~
Frequency 50...60 Hz
Power 2.8 kW
Temperature range 50-250°C
Halogen lights 4
Water connection G ¾ inch
Water pressure min 1.5
bar
787
732
These are basic drawings. For more detailed technical information,
please refer to the installation manual at www.frijado.com.
540
15
5
1
2
Phone +31 76 50 85 400
50
Fax +31 76 50 85 444
e-mail info@frijado.com
Fri-Jado B.V.
P.O. Box 560
4870 AN Etten-Leur
The Netherlands
www.frijado.com
BB3-EN-09062011
