Frigor FHC 85 User Manual

REFRIGERATORREFRIGERATOR

FHC 85

Fridge

REFRIGERATORREFRIGERATOR

USER'S MANUALUSER'S MANUAL

1.Name of parts1.Name of parts

PARTS AND FEATURESPARTS AND FEATURES

11

44

55

22

33

88

99

Top Cover Top Cover

Freezer Compartment DoorFreezer Compartment Door

Freezer CompartmentFreezer Compartment

Shelves of refrigerator chamber Shelves of refrigerator chamber

Leveling LegsLeveling Legs

Bottle RacksBottle Racks

Door Storage CompartmentDoor Storage Compartment

Temperature Control Knob Temperature Control Knob

Recessed HandleRecessed Handle

1

66

77

1010

Crisper boxCrisper box

1111

1010

1111

1212

Glass coverGlass cover

Door switchDoor switch

2.Correctly positioning 2.Correctly positioning

¡À¡À

¡À¡À

10%10%

10%10%

++

__
50Hz50Hz

60Hz60Hz

NN

(+220-240)V~(+220-240)V~

230V~ 230V~

Well Ventilating

Power Supply

Power Line Cord

Protection from Moisture

There is need of good ventilation around the refrigerator for easy
dissipation of heat, high efficiency of refrigeration and low power
consumption. For this purpose, sufficient clear space should be
need around the refrigerator. Its back is at least 100mm away from
the wall, its sides at least have a space of 100mm separately and
the height from over its top is not less than 200mm. A clear space
should be left to open its doors to 160

The refrigerator is only applied with power supply of single phase
alternating current of (220-240)V~/50Hz;230V~/60Hz.If fluctuation
of voltage in the district user is of so large that the voltage
exceeds the above scope, for safety sake, be sure to apply a.c.
automatic voltage regulator to the refrigerator. The refrigerator
must employ a special power socket instead of common one with
other electric appliances. Its plug must match the socket with
ground wire.

The cord should be neither lengthened nor folded into
coil during operation. Moreover, it is forbidden that cord
is kept close onto the compressor at the back of the
refrigerator, the surface temperature of which is quite
high when operating. Touching with it would deactivate
the insulation or cause leakage for electricity.

Avoiding placing the refrigerator in a place where heavy
moisture is present so as to minimize possibility of rusty
for its metal parts. Still more, the refrigerator is forbidden to
be directly sprayed by water, otherwise, poor insulation and
current leakage would occur.
