Frigidaire TRMKTEZ2FL75, TRMKTEZ1FL79 Installation guide

INSTRUCTION SHEET

Single-Door All Refrigerator and All Freezer Trim Kit Installation

Product Line: All Refrigerator and All Freezer Models Serial Number Range: All Serial Number Ranges

Single Trim Kit Components (79˝ & 84˝ Tall Cabinet Cutouts)

Brand Kit # Single Trim Kit #

Frigidaire Professional TRMKTEZ1FL79 A16405201

Item # Part Number Description Qty

1A

2A

3A

4A

5

6

7

8

A18684901

A18684902

A16766503

A16766505

A18684505

A18684507

A17111301

A20841303

Side Trim, RH

Side Trim, LH

Top Trim, Flat RH

Top Trim, Flat LH

Toe Kick, RH

Toe Kick, LH

Leveler Assembly

Hardware Pack U19, Single

1

2

1

Item # Part Number Description Qty

Brand Kit # Single Trim Kit #

Electrolux TRMKTSS1LV84 A19895901

Side Trim, RH

Side Trim, LH

Top Trim, Louver RH

Top Trim, Louver LH

Toe Kick, RH

Toe Kick, LH

Leveler Assembly

Hardware Pack U19, Single

Side Trim Attachment

2B

3B

4B

1B

5

6

7

8

9

A19036503

A19036504

A19036402

A19036403

A18684506

A18684508

A17111301

A20841304

A19036701

1

2

1

2

Hardware Pack A20841303

ITEM PART NUMBER DESCRIPTION QTY

1H

2H

3H

A18695801 Tie-Bar, Top 1

297142600 Screw, Flathead, #8-32 2

050149 Screw, Round, #8-18 4

7

1A

2A

3B

4B

3A

4A

5

6

1B

2B

9

Hardware Pack A20841304

ITEM PART NUMBER DESCRIPTION QTY

1H

2H

3H

A18695801 Tie-Bar, Top 1

297142600 Screw, Flathead, #8-32 2

050149 Screw, Round, #8-18 12

4H

5H

6H, 7H

A16955502 Bolt, M5 x 16 6

A21188301 Bolt, ¼-20 2

A20706101 Trim Base Screw 1

NOTE: All Hardware Pack components mentioned throughout this instruction sheet will have an “H” after the item number.

4H

5H

A16955502 Bolt, M5 x 16 6

A21188301 Bolt, ¼-20 2

6H 7H

2.12" Ref

1H

2H

3H

4H

5H

5" Ref

Dual Trim Kit Components (75˝ & 79˝ Tall Cabinet Cutouts)

Brand Kit # Dual Trim Kit #

Frigidaire TRMKTEZ2FL75 A18643301

Item # Part Number Description Qty

Side Trim, RH

Side Trim, LH

Top Trim, Collar

Center Trim

Toe Kick

Leveler Assembly

Hardware Pack U19, Single

4

2B

3A

1B

A18685001

A18685002

A18694901

4

5

6

7

A18685101

A18684501

A17111301

A20841301

INSTRUCTION SHEET

Brand Kit # Dual Trim Kit #

Frigidaire TRMKTEZ2LV79 A16405401

Item # Part Number Description Qty

Side Trim, RH

Side Trim, LH

Top Trim, Louver

Center Trim

Toe Kick

Leveler Assembly

Hardware Pack U19, Single

2A

3B

1A

4

5

6

7

A18684901

A18684902

A18804301

A18685101

A18684501

A17111301

A20841301

1

4

1

Brand Kit # Dual Trim Kit #

Frigidaire TRMKTEZ2FL79 A16404901

Item # Part Number Description Qty

Side Trim, RH

Side Trim, LH

Top Trim, Flat

Center Trim

Toe Kick

Leveler Assembly

Hardware Pack U19, Single

1

4

1

2A

3C

1A

A18684901

A18684902

A16766501

4

5

6

7

A18685101

A18684501

A17111301

A20841301

Brand Kit # Dual Trim Kit #

Electrolux TRMKTSS2FL79 A16404902

Item # Part Number Description Qty

Side Trim, RH

Side Trim, LH

Top Trim, Flat

Center Trim

Toe Kick

Leveler Assembly

Hardware Pack U19, Single

1

4

1

6

1A

2A

1B

2B

2A

3C

1A

4

5

6

7

A18684903

A18684904

A16766502

A18685102

A18684502

A17111301

A20841301

3A

3B

3C

4

5

Hardware Pack A20841301

ITEM PART NUMBER DESCRIPTION QTY

1H

2H

A18695801 Tie-Bar, Top 1

297142600 Screw, Flathead, #8-32 2

INSTRUCTION SHEET

3H

4H

5H

6H, 7H

8H

9H

10H

050149 Screw, Round, #8-18 4

A16955502 Bolt, M5 x 16 6

A21188301 Bolt, ¼-20 2

A20706101 Trim Base Screw 1

A20632701 Screw, 10-24 x  8

A16770801 Tie Bar, Bottom 2

A18685301 Center Trim Support 1

0.87" Ref

10H

Dual Trim Kit Components (84˝ Tall Cabinet Cutouts)

Brand Kit # Dual Trim Kit #

Electrolux TRMKTSS2LV84 A16405301

Item # Part Number Description Qty

Side Trim, RH

Side Trim, LH

Top Trim, Louver

Center Trim

Toe Kick

Leveler Assembly

Hardware Pack U19, Double

Side Trim Attachment

2A

3A

1A

A19036501

A19036502

A19036401

4

A18685102

5

A18684502

6

7

8

A17111301

A20841302

A19036701

2.12" Ref

9H

6H

1H

5" Ref

7H

2H

3H

4H

5H

8H

12.21" Ref

6

1A

2A

1

3A

4

5

8

1

4

1

2

Hardware Pack A20841301

ITEM PART NUMBER DESCRIPTION QTY

1H

2H

A18695801 Tie-Bar, Top 1

297142600 Screw, Flathead, #8-32 2

INSTRUCTION SHEET

3H

4H

5H

8H

9H

10H

050149 Screw, Round, #8-18 12

A16955502 Bolt, M5 x 16 14

A21188301 Bolt, ¼-20 4

A20632701 Screw, 10-24 x  8

A16770801 Tie Bar, Bottom 2

A18685301 Center Trim Support 1

0.87" Ref

10H

2.12" Ref

9H

12.21" Ref

1H

5" Ref

2H

3H

4H

5H

8H

INSTRUCTION SHEET

Single Trim Kits (79" & 84" Tall Cabinet Cutouts)

TRMKTEZ1FL79 (Frigidaire) TRMKTSS1LV84 (Electrolux)

IMPORTANT

Make sure there are two separate dedicated grounding-type duplex wall outlets for the freezer and the refrigerator as speciﬁed in the Use & Care Manual.

25.25" minimum

1.021"

minimum

(25.9 mm)

Min. 35.01" Max. 35.57"

79" +/- 0.06"

33" +/- 0.032"

Min. 79.22" Max. 80.18"

83.75" +/- 0.06"

24"

minimum

35.5" +/- 0.032"

0.706"

minimum

(17.9 mm)

Min. 36.88" Max. 37.67"

Min. 83.88" Max. 84.85"

Dual Trim Kits (75" & 79" Tall Cabinet Cutouts)

NOTE



To install a dual trim kit or a pairing kit, a partition cannot exist between the Freezer and the Refrigerator.

INSTRUCTION SHEET

TRMKTEZ2FL75 (Frigidaire)

25.25"

minimum

75" +/- 0.06"

66.25" +/- 0.032"

TRMKTEZ2FL79 (Frigidaire) TRMKTSS2FL79 (Electrolux) TRMKTEZ2LV79 (Frigidaire)

79" +/- 0.06"

25.25"

minimum

66.25" +/- 0.032"

Min. 75.21" Max. 76.17"

0.896"

minimum

(22.8 mm)

Min. 68.01" Max. 68.57"

0.896"

minimum

(22.8 mm)

Min. 68.01" Max. 68.57"

Min. 79.22" Max. 80.18"

24"

minimum

INSTRUCTION SHEET

Dual Trim Kits (84" Tall Cabinet Cutouts)

TRMKTSS2LV84 (Electrolux)

Min. 72.88" Max. 73.67"

83.75" +/- 0.06"

Min. 83.88" Max. 84.85"

71.5" +/- 0.032"

0.706"

minimum

(17.9 mm)



NOTE

Use two recessed duplex electrical outlets and a recessed water shutoﬀ valve for a 24” minimum opening. For new construction, use a

25.25” cabinet depth dimension.

Safety: Always wear safety glasses when using power tools.

Tools Needed:

• PhillipsTM Screwdriver • 3/8” & 5/16” Socket Wrench • Step Ladder

• Flathead Screwdriver • Power Drill and 5/16” Nut Driver Bit • Tape Measure

• Safety Glasses • 3/8” Nut Driver • Gloves

• Level

Before You Begin

• Be careful when unpacking components. Do not use sharp objects when removing packaging material. This may scratch the surface of trim components.

• Use extreme care when handling the metal trim pieces. Corners are very sharp and easily damaged if dropped.

INSTRUCTION SHEET

Instructions for Dual Installation Trim Kits:

TRMKTEZ2FL75 (Frigidaire) TRMKTEZ2LV79 (Frigidaire) TRMKTEZ2FL79 (Frigidaire) TRMKTSS2FL79 (Electrolux) TRMKTSS2LV84 (Electrolux)

Leveling System Installation

1. a. Lay refrigerator and freezer on their backs on packing material or a drop cloth to prevent damage.

b. Remove all 4 rear leg

levelers from the 2 units by unscrewing counterclockwise (Fig. 1A), and store them with your Product Literature.

A

3. a. Fit the first Leveler Assembly onto a refrigerator/freezer (Fig. 3).

b. Using a 5H bolt and

a power drill, fasten the bottom of the Leveler Assembly with a

3

/8”

hex drill bit in whichever

hole overlaps the screw hole (Fig. 4). Note: The rear of the bracket is contoured to slip over the metal compressor base. Driving the rear bolt first will ensure proper alignment of the lever assembly.

c. Using the 4H bolts from step 1, fasten the front of the Leveler Assembly to the refrigerator/freezer using a (Fig. 5).

5

/16” nut driver

Fig. 3

Fig. 4

c. Remove all 4 front leg

levelers from the 2 units by unscrewing the outer peg and 2 bolts on each front leveler with a

5

/16” nut driver and

store them with your Product Literature. Remove the hinge cover if it is installed (Fig 1B).

2. Lay the parts out on a cleared area face down. Be sure to place a drop cloth over the floor to prevent scratching the trim kit and/or floor (Fig. 2).

B

Fig. 1

Fig. 2

If more fastening space

is required, rotate the bolt labeled F clockwise (Fig. 6) using a flathead screwdriver or a

3

/8”

socket wrench.

d. Attach remaining 3

Leveler Assemblies as described in the previous 3 steps using the remaining six 4H bolts and the remaining three 5H bolts. With the unit(s) still on their backs, adjust all leveling wheels to approximately the orientation in Fig. 7.

Fig. 5

Fig. 6

Fig. 7

INSTRUCTION SHEET

Trim Kit Center Trim Support

4. With the refrigerator still on its back, use a remove two 4H bolts and fasten the 10H L-Bar (Fig. 8). Note: The short flange on L-Bar should be facing upward toward the top of the refrigerator.

5. Stand both units upright.

5

/16” nut driver to

Fig. 8

CAUTION

The cabinet is heavy. Two people are recommended to lift or move the cabinet..

Pairing Kit Installation

Before cleaning your appliance, turn oﬀ power to your appliance by unplugging the power cord from the electrical outlet. Wipe down both sides of the refrigerator and the freezer.



NOTE

Never use CHLORIDE to clean stainless steel. Clean stainless-steel front and handles with non-abrasive soapy water and a dishcloth. Rinse with clean water and a soft cloth. Wipe stubborn spots with an ammoniasoaked paper towel, and rinse. Use a non-abrasive stainless-steel cleaner, such as Frigidaire ReadyClean™ Stainless Steel Cleaner found on Frigidaire.com. Always follow the manufacturer’s instruction.

NOTE

Always, clean, wipe and dry with the grain to prevent scratching. Wash the rest of the cabinet with warm water and mild liquid detergent. Rinse well and wipe dry with a clean soft cloth.

NOTE For the best results, please use the conﬁgurations of the heaters mentioned (Freezer- top right side and Refrigerator bottom left side).

Avoid:

Both heaters on the Freezer Both heaters on the Refrigerator Both heaters on the top Both heaters on the bottom Both heaters in the center

10. Plug in the connector of the two Heaters A into the Power

Supply C (Fig. 10).

NOTE: Conﬁrm the power supply

ﬁts into the cutout when placed on top of the unit. Also conﬁrm the power supply reaches the power outlet when placed on top of the unit (Fig. 11A). The extra wire length is provided to accommodate receptacle location.

11. Apply the 2 strips of doublesided tape to the power supply and adhere the power supply on top of the unit (Fig. 11B).

C

B

A

Fig. 10

Fig. 11

IMPORTANT

Make sure there are two separate outlets for the freezer and the refrigerator.

B

A

Note: Use gloves for the next step.

. Peel oﬀ the paper backing from the ﬁrst heater.

7. Adhere the ﬁrst heater to the lower right side of the left-side unit (0.5" from the bottom and 0.5" from the back wall) so the harnesses come out at the top.

NOTE Make sure you adhere the heater completely with no air pockets (Fig. 9A).

8. Peel oﬀ the paper backing

from the second heater.

9. Adhere the second heater to

the upper left side of the rightside unit (0.5” from the top and 0.5” from the back wall) so the harnesses come out at the bottom.

NOTE Make sure you adhere the heater completely with no air pockets (Fig. 9B). For better adhesion remove the yellow label on the side of the cabinet.

NOTE: Before removing the paper backing, align the heaters to ensure the wires exit toward the center and rear of refrigerator/ freezer (as shown in Fig 9).

A

0.5"

Fig. 9

12. If the power supply cannot be placed on top of the unit, adhere it vertically on the back wall of the unit and make sure the connection of the 3-prong connector to the power supply is facing down (Fig. 12).

NOTE: You cannot feel the heater temperature.

B

Fig. 12

INSTRUCTION SHEET

13. Use the clips provided to hold the excess power cords to the back of the units such that all wires are away from the ﬂoor (Fig. 13).

NOTE: Make sure the harnesses and cables are cleared oﬀ the ﬂoor before the units are pushed back in place. This will prevent any damage to the wires. NOTE: The location of clips shown is an example.

14. Plug the power supply into the main outlet before pushing the units into the ﬁnal position.

Fig. 13

Trim Kit Tie Bar Installation

NOTE



Before proceeding with trim installation, make sure both refrigerator and freezer are leveled front to back and side to side. Make sure all 8 wheels are touching the ﬂoor.

15. Having the refrigerator/ freezer standing side by side ½” apart, fasten a 9H bracket to the front of the Levelers (Fig. 14), keeping the left-side 8H screws loose.

NOTE: One side of the brackets is slotted for ﬁne adjustments in step 18c.

16. Attach the other 9H bracket to the rear levelers (Fig. 15), keeping the right screws loose.

17. Attach the 1H top tie bar (Fig. 16), keeping the 2 left 4H bolts loose.

Fig. 14

Fig. 15

NOTE Before continuing, ensure doors close without interference and remain parallel. Adjusting the height of the wheels can help remedy door alignment issues. Refer to INSTALLATION in the Use & Care Manual to adjust the door height.

Fig. 18

NOTE



Before proceeding plug in units and verify they are functioning properly.

NOTE



Some cabinet substrates may require pre-drilling holes using a mm) diameter drill bit.

1

/8” (3

Electrolux TRMKTSS2LV84 Side Trim Attachment Setup (some models)

19. Using eight 3H screws and a power drill, attach the two Side Trim Attachment brackets to the front left and right cabinet cut-out edges with the brackets touching the floor (Fig. 19). Ensure the rectangular slots extend over the cabinet edge.

Fig. 16

18. a. Open the doors and place the middle trim in between the 2 units.

b. Adjust the proximity

of the units as needed to centralize the middle trim. Start by fastening the screws on top 1H bracket in order to evenly space the Center Trim (Fig. 17).

Fig. 17

c. Fasten the four 8H screws (Fig. 14 and 15) through 2 front and

back 9H brackets. You may need several adjustments for the center trim to be consistently flush and centered to the units.

Side Trim Attachment Setup For:

Fig. 19

TRMKTEZ2FL75 (Frigidaire) TRMKTEZ2LV79 (Frigidaire) TRMKTEZ2FL79 (Frigidaire) TRMKTSS2FL79 (Electrolux)

20. Depending on which long screw you received (6H or 7H), screw a long screw into the lower left (Fig. 20A) of the front wall cabinet, close to the location shown in Fig. 20B.

21. Repeat step 20 for the right side of the wall cabinet using the other 6H/7H screw.

B

Fig. 20

A

INSTRUCTION SHEET

Power and Water Line Connection

Note: Refer to the Use & Care Manual for power requirements and water

supply hookup before proceeding. Find Service Kit TTFLTRICEKIT at ElectroluxAppliances.com for connecting the water line and ﬁltering ice.

Top Trim Attachment

NOTE



You will need a step ladder to install top trim components.

Note: If freezer unit is compatible with water filter kit, please see filtered water kit instructions.

22. a. Remove the front outer hinge screws, common on both sides of the dual installation, as well as the front two 4H screws that fasten the 1H Tie Bar (Fig. 21).

b. Roll the dual installation

into the cabinet, roughly  of the way in, ensuring the product is centered in the cabinet cutout.

c. Install the top trim by

fastening four 4H screws along the base of the trim with a wrench (Fig. 21).

23. a. Slide the dual installation into place, and make sure it is center inside the cabinets.

b. Drill

fasten two 3H screws on the right side of the Top Trim (one screw per side for Collared top trim) with a Phillips screwdriver to the cabinets (Fig. 22).

c. Repeat for the left side.

5

/16” socket

1

/

” pilot holes and

8

Fig. 21

Fig. 22

Side Trim Installation For:

TRMKTEZ2FL75 (Frigidaire) TRMKTEZ2LV79 (Frigidaire) TRMKTEZ2FL79 (Frigidaire) TRMKTSS2FL79 (Electrolux)

24. a. Place side trims in position by dropping them over the placement screw as seen in Fig. 21 and fitting over the top trim (Fig. 23).

b. Fasten 2H screws to

the top trim (Fig. 25) and repeat for the right hand side.

26. a. Carefully place the Toe Kick over the 4 Leveler Assembly Slots. The first Leveler Assembly slot is circled in Fig. 26, and the fourth Leveler Assembly slot is circled in Fig. 27.

b. Adjust the Toe kick until

the magnets are engaged to the Leveler Assembly bolts and the Toe Kick is resting vertically in place.

Fig. 25

Fig. 26

Fig. 27

Electrolux TRMKTSS2LV84 Side Trim Installation

25. a. Slide the left Side Trim into place by carefully guiding the Side Trim Attachment slots. Fig. 24 shows an inside view.

Fig. 23

Fig. 24

Instructions for Single Installation Trim Kits:

TRMKTEZ1FL79 (Frigidaire) TRMKTSS1LV84 (Electrolux)

Leveling System Installation

1. a. Lay the unit on its back on packing material or a drop cloth to prevent damage.

b. Remove both rear leg

levelers by unscrewing counterclockwise (Fig. 1A), and store them with your Product Literature.

c. Remove both front leg

levelers by unscrewing the outer peg and 2 bolts on each front leveler with a driver. Remove the hinge cover if it is installed (Fig 1B), and store them with your Product Literature.

2. Lay the parts out on a cleared area face down. Be sure to place a drop cloth over the floor to prevent scratching the trim kit and/or floor (Fig. 2).

3. a. Fit the first Leveler Assembly onto a refrigerator/freezer (Fig. 3).

b. Using a 5H bolt and

a power drill, fasten the bottom of the Leveler Assembly with a

5

/16” nut

3

/8”

hex drill bit in whichever

hole overlaps the screw hole (Fig. 4).

c Using the 4H bolts from

step 1, fasten the front of the Leveler Assembly to the refrigerator/freezer using a (Fig. 5). If more fastening space is required, rotate the bolt labeled F clockwise (Fig. 6) using a flathead screwdriver or a

5

/16” nut driver

3

/8” socket wrench.

A B

Fig. 1

Fig. 2

Fig. 3

Fig. 4

INSTRUCTION SHEET

Fig. 6

d. Attach the remaining Leveler Assembly as described in the previous 3 steps. With the unit still on its back, adjust all leveling wheels to approximately the orientation in Fig. 7.

Leveling the Unit

4. a. Tilt the unit upright. b. Place the unit into the

cabinet space, or as close to the final position as possible (do not hook up power or water yet). This step is important to accurately level the unit prior to further installs.

c. Use a flat head screw

driver or a the Leveler Assemblies (Fig. 8). Raise or lower the front and back wheels as needed until the unit rests properly in the cabinet space.

d. Once the Leveler Assemblies have been checked, roll out

the unit in front of the cabinetry for accessibility.

NOTE



Some cabinet substrates may require pre-drilling holes using a (3 mm) diameter drill bit.

3

/8” socket wrench to adjust the front bolts of

Electrolux TRMKTSS1LV84 Side Trim Attachment Setup

5. Using eight 3H screws and a power drill, attach the 2 Side Trim Attachment brackets to the front left and right cabinet cutout edges with the brackets touching the floor (Fig. 9). Ensure the rectangular slots extend over the cabinet edge.

Fig. 7

Fig. 8

1

/8”

Fig. 5

INSTRUCTION SHEET

Frigidaire TRMKTEZ1FL79 Side Trim Attachment Setup

6. Depending on which long screw you received (6H or 7H) screw a long screw in the lower left area (Fig. 9A) of the front cabinet space, approximately in the location described in Fig. 9B.

7. Repeat step 6 for the right side of the cabinet using the other 6H/7H screw.

B

A

Fig. 9

Power and Water Line Connection

Note: Refer to the Use & Care Manual for power requirements and water

supply hookup before proceeding. Find Service Kit TTFLTRICEKIT at ElectroluxAppliances.com for connecting the water line and ﬁltering ice.

Top Trim Attachment

NOTE



You will need a step ladder to install top trim components.

8. a. Remove the front outer screw from the top hinge (Fig. 10) using a

5

/16”

socket driver or wrench

and save for later. Locate bracket 1H and place it on the top of the unit to be used on Step 14.

b. Roll the unit into the

cabinet roughly  of the way in, ensuring the product is centered in the cabinet cutout.

c. Choose the top trim

according to which side the door hinge is on (Fig. 11). You do not need the other Top Trim for the installation.

d. Install the Top Trim by

fastening two 4H screws along the base of the trim with a wrench (Fig. 12). Screw through the 1H bracket in step 8a to properly level the Top Trim.

5

/16” socket

Fig. 10

Fig. 11

9. a. Slide the unit into place, and ensure the dual installation is centered.

b. Drill

fasten two 3H screws on the right side of the Top Trim with a Phillips screwdriver to cabinets (Fig. 13).

c. Repeat for the left side.

1

/8” pilot holes and

Frigidaire TRMKTEZ1FL79 Side Trim Installation

10. a. Place the Side Trims in position by dropping them over the placement screw as seen in Fig. 9 and fitting them over the Top Trim (Fig. 14).

b. Fasten a 2H screw to

each side of the Top Trim (Fig. 14).

Electrolux TRMKTSS1LV84 Side Trim Installation

11. a. Slide the left Side Trim into place by carefully guiding the Side Trim hooks through the Side Trim Attachment slots. Fig. 15 shows an inside view.

b. Fasten 2H screws to

the Top Trim (Fig. 16) and repeat for the right hand side.

Fig. 13

Fig. 14

Fig. 15

Fig. 12

Fig. 16

INSTRUCTION SHEET

12. a. Choose which Toe Kick to place below the unit based on which side the door hinge is on (Fig. 17). You do not need the other Toe Kick.

b. Carefully place the Tow

Kick over the 2 Leveler Assembly Slots. The first Leveler Assembly slot is circled in Fig. 18, and the second Leveler Assembly slot is circled in Fig. 19.

c. Adjust the Toe Kick

until the magnets are engaged to the Leveler Assembly bolts and the Toe Kick is resting vertically in place.

Note: Refer to the Use & Care Manual to adjust the door height if needed.

Fig. 17

Fig. 18

Fig. 19

Frigidaire TRMKTEZ2FL75, TRMKTEZ1FL79 Installation guide

Specifications and Main Features

Frequently Asked Questions

User Manual
