Built-In Downdraft Cooktop
RC30DE60PB
Signature Features
30" Electric
Product Dimensions
Width 30-3/4"
Depth 22-1/16"
Height (Min.)/(Max.) 18-19/32"/ 23-3/8"
More Easy-To-Use Features
SpaceWise® Expandable
Elements
Flexible elements expand to
your cooking needs.
Hot Surface Indicators
Smoothtop Ceramic Glass
Cooking Surface
3 Ducting Options
Dishwasher-Safe Filter
Available in:
Black
(B)
Elements
Right Front
Right Rear
Left Front
Left Rear
Left Bridge
Size
9"
5" / 7"
7"
7"
SpaceWise®
Bridge
Watts
3,200
750 / 1,800
1,800 / 2,600
1,800
800
Downdraft System
Whisks away odors and smoke without
the need for overhead ventilation.
Pro-Select® Controls
Precise control at your fingertips.
PowerPlus® Boil
Boil water faster.
SpaceWise® Bridge Element
A flexible element lets you combine
two elements into one to fit larger
cookware.
frigidaire.com
Features
A
B
C
Rear
Right Side View
Down
Controls
Surface Type
Right Front Element (Watts)
Right Rear Element (Watts)
Left Front Element (Watts)
Left Rear Element (Watts)
Left Bridge Element (Watts)
Center Element (Watts)
Hot Surface Indicators
Control Location
Knob Color
Knob Type
Nominal Width
Installation Type
Style
Air Discharge
Air Delivery (CFM)
Intake Area
Blower Type
Sound Level (dBA)
Fan Speeds
Dishwasher-Safe Stainless Steel Filters
Exhaust Duct
Duct Required
Pro-Select®
Black Ceramic Glass
9" - 3,200
5" / 7" - 750 / 1,800
7" - 1,800
7" - 1,800
SpaceWise® Bridge - 800
Yes
Right Side
Black
Plastic
30"
Built-In Downdraft
In-Cabinet
Rear, Down
1
500
39 Sq. In.
Centrifugal
71
3-Speed
1
External
3-1/4" x 10" or 6" Round
Optional Accessories
Alternate Duct Transition Kit
PN #5304488297
Specifications
Power Supply Connection Location
Voltage Rating
Connected Load
(kW Rating) @ 240 / 208 Volts
Amps @ 240 / 208 Volts
Minimum Circuit Required (Amps)
Approved for Electric Single
Wall Oven Combination Installation
Shipping Weight (Approx.)
1
Down discharge can also be adapted for alternate ductwork installation
providing left or right exhaust, by ordering Alternate Duct Transition Kit
(PN # 5304488297).
2
Single phase 3- or 4-wire cable, 120 / 240 or 120 / 208 Volt, 60 Hertz AC
only electrical supply with ground required on separate circuit fused on
both sides of line.
2
Right Front
240V /208V / 60Hz
41.7/36.4
50
50
78 Lbs.
Built-In Downdraft Cooktop
RC30DE60PB 30" Electric
NOTE: For planning purposes only. Always consult local and national electric codes.
Refer to Product Installation Guide for detailed installation instructions on the web
at frigidaire.com.
Product Dimensions
A - Width
B - Depth
C - Height (Min.)/(Max.)
3
Overall height determined by discharge direction.
30-3/4"
22-1/16"
3
18-19/32"/23-3/8"
Cutout Dimensions
Width (Min.)/(Max.)
Depth (Min.)/(Max.)
Height (Min.)/(Max.)
28-7/8"/29"
21-1/8"/21-1/4"
18-19/32"/23-3/8"
Granite Countertop
Installation Kit available.
•
USA
10200 David Taylor Drive
•
CANADA
RC30DE60P 07/13 © 2013 Electrolux Home Products, Inc.
5855 Terry Fox Way
•
Charlotte, NC 28262
•
Mississauga, ON L5V 3E4
•
1-800-FRIGIDAIRE
•
1-800-265-8352
•
frigidaire.com
•
frigidaire.ca
Accessories information available
on the web at frigidaire.com
Specifications
subject to change.
