1 Year Limited Warranty
WARRANTY
ELECTRIC FIREPLACE
LIMITED WARRANTY: This manufacturer’s product warranty extends to the original con-
sumer purchaser of the product. Neither the retailer nor any other company involved in the
sale or promotion of this product is a co-warrantor of this manufacturer warranty.
WARRANTY DURATION: All materials and workmanship are warranted to the original
consumer purchaser for a period of one (1) year from the original purchase date.
WARRANTY COVERAGE: This product is warranted against defective materials or workmanship when used under normal conditions. This warranty is void if the product has been
damaged by accident, in shipment, unreasonable use, misuse, neglect, improper service,
commercial use, repairs by unauthorized personnel or other causes not arising out of defects in materials or workmanship. There is no warranty with respect to the following, which
may be supplied with this product, including without limitation: glass parts, brackets, bulbs,
grommet etc. This warranty extends only to the original consumer purchase. This warranty
is effective only if the product is purchased and operated in the USA or Canada, and does
not extend to any units which have been used in violation of written instructions furnished
by manufacturer or to units which have been altered or modied or to damage to products
or parts thereof which have had the serial number removed, altered, defaced or rendered
illegible.
WARRANTY DISCLAIMERS: This warranty is in lieu of all warranties expressed or implied
and no representative or person is authorized to assume for manufacturer any other liability
in connection with the sale of our products. There shall be no claims for defects or failure
under any theory of tort, contractor commercial law including, but not limited to, negligence,
gross negligence, strict liability, breach of warranty and breach of contract.
WARRANTY PERFORMANCE: During the above one (1) year warranty period, a product
with a defect will be either repaired or replaced with a reconditioned comparable model (at
manufacturer’s option). The repaired or replacement product will be in warranty for the balance of the one (1) year warranty period and an additional six (6) month period. No charge
will be made for such repair or replacement.
SERVICE AND REPAIR: If service is required for an appliance, you should rst contact
Nuvatek Distribution customer service at info@nuvatek.com or by calling 1-855-286-
8688.
NOTE: Manufacturer cannot assume responsibility for loss or damage during incoming
shipment. For your protection, carefully package the product for shipment, and insure it
with the carrier. Be sure to enclose the following items with your appliance: your full name,
return address and daytime phone number; a note describing the problem you experienced;
a copy of your sales receipt or other proof of purchase to determine warranty status. C.O.D. shipments
cannot be accepted.
1
Oslo
Wall Mount Color Changing LED Fireplace
Item No: OWF-1/0303
Read these instructions carefully before attempting to assemble, install, operate
or maintain the product. Protect yourself and others by observing all safety
information. Failure to comply with instructions could result in personal injury
and / or property damage. Retain instructions for future reference.
IMPORTANT INSTRUCTIONS & OPERATING
2
GENERAL SAFETY INFORMATION
When using this fireplace, basic precautions should always be taken to reduce the risk
of fire, electric shock and injury to persons, including the following:
CAUTION – Due to the high temperature, keep electrical cords, drapery and other furnishings at
least 3 feet from the front, side and rear of the fireplace.
1. Carefully read all instructions before using the fireplace and retain for future reference.
2. Remove the unit from its packaging and check to make sure it is in good condition before
use.
3. Do not let children play with any parts of the packing (such as plastic bags, etc.).
4. Check the household voltage to ensure that it matches the fireplace’s rated specification.
5. Before using the fireplace, carefully check the power cord and plug for any damage.
6. Be sure that the room is equipped with a working smoke detector.
7. Before unplugging the power cord, turn off the power. When touching the unit, keep your
hands dry to prevent electric shock.
8. Do not place the fireplace near curtains or other inflammable objects. Keep combustible
materials, such as pillows, bedding, papers, clothes, and curtains at least 3 feet away from
the front, side and rear of the fireplace.
9. Do not block air intakes or exhaust in any manner to prevent fire.
10. Do not use on soft or uneven surfaces, like a bed, where openings may become blocked.
11. Exhibit extreme caution when any fireplace is in the vicinity of children and infants.
12. Never leave children or infants unattended while the fireplace is on or plugged in.
13. When not in use, always unplug the fireplace.
14. Prevent water from entering the housing of the fireplace during operation or while in storage.
15. Always store the fireplace in a dry area free from any moisture. This fireplace is not intended
for use in bathrooms, laundry areas, or similar indoor locations. Never place the fireplace
where it may fall into a bath tub or get exposed to water in any way.
16. Do not use in places where gasoline, paint, or other inflammable liquids are used or stored.
17. Do not run the cord under carpets. Do not cover the cord with throw rugs, runners, or similar
products. Arrange the cord away from traffic areas such that it will not be tripped over by
anyone.
18. Do not operate any fireplace with a damaged cord, a damaged plug, after the fireplace
malfunctions, or if it has been dropped or damaged in any manner. Return the fireplace to
an authorized service facility for examination, electrical or mechanical adjustment, or repair.
19. Do not insert fingers or allow foreign objects to enter any ventilation or exhaust opening as
this may lead to an electric shock or fire, or may even damage the fireplace.
20. This fireplace becomes hot during use. To avoid burns, do not let bare skin touch hot
surfaces. If necessary, use the handles when moving this fireplace.
21. Use this fireplace only as described in this manual. Any other uses not recommended by the
manufacturer may cause fire, electric shock, or personal injury and may void warranty
privileges.
22. Always plug fireplaces directly into a wall outlet. Never use an extension cord, power strip,
surge protector, multiple outlet adapter, cord reel or outlet-type air freshener. The use of
such devices creates a fire hazard.
23. Faulty wall outlet connections may cause the wall outlet to overheat. Be sure that the
fireplace plug properly fits into the outlet before each use. During use, make sure the
fireplace plug does not overheat. If necessary, have a qualified electrician check and / or
replace the wall outlet.
24. Do not place the fireplace near a bed for objects such as pillows or blankets can fall off the
bed
and be ignited by the fireplace.
25. Never clean this fireplace while it is plugged in. To disconnect, turn control to OFF, then
remove the plug from the outlet. Never pull the cord. Always hold the plug firmly and then
3
remove from the outlet.
26. This fireplace is intended for supplemental heat and / or decorative purposes. Continuous
use for several hours can impact the performance and life of the fireplace.
27. It is not intended to be used in commercial, industrial or agricultural settings.
28. Do not use outdoors.
29. Do not shorten or change the shape of the bracket.
Getting Started
• Remove the fireplace from the box.
• Remove the packaging. Place it inside the box or safely dispose elsewhere.
Package Contents
• Electric Fireplace
• Wall Mount Bracket
• Screws and Screw Anchors
• Pebble Pack
• Remote Control (Requires 2 x AAA Batteries – Not Included)
• Instruction Manual
Features
• Dual heat settings (750Watts / 1500Watts)
• Realistic color changing LED flames with 10 different colors to choose from
• Auto color changing mode built-in
• Flames operate with & without heat with adjustable flame brightness
• Black, heat resistant, tempered flat glass panel
• Built-in overheating protection, auto safety shut-off
Quick Reference Guide
• Prior to installation, please ensure that the voltage and capacity of your power outlet is
compatible with your fireplace.
• Your fireplace may emit a slight, harmless odor during its first use. This odor is a normal
reaction caused by the initial heating of internal fireplace parts and it will not occur again.
• It is normal for fireplace to make a rattling sound for a short duration of time during its
first use.
• If your fireplace does not emit heat, please ensure the fireplace switch is on. For further
information, please refer to the Troubleshooting section of this manual.
4
Sr. No
Item Description
Quantity
006
012
007
008
009
011
003
001
A
013
002
004
005
010
001
Carton 1
002
Screws (4 x 8 mm)
2
003
Screws (4 x 35mm)
2
004
Fixed Angle
1
005
Plastic Plug ( 8 mm)
2
006
Foam Protection (Left)
1
007
Electric Fireplace
1
008
Bracket 1
009
Plastic Plug (8 mm)
5
010
Screws (4x35 mm)
5
011
Remote Control
1
012
Foam Protection (Right)
1
013
Power Cord
1
Helpful Advice Before Installation
• Please retain all packaging until you have checked and counted all the parts and other
package contents.
• The package contains small apparatus which should be kept away from young children
and infants.
• We suggest that you move all the smaller parts into a container to reduce the risk of
losing them.
• At least 2 people are required to install this fireplace.
• It is recommended to place your fireplace near an existing outlet, for ease of electric
connection.
• Store your fireplace in a dry, safe and dust-free place while drilling, for fireplace
installation.
• Do not attempt to wire new outlets or circuits. To reduce the risk of fire, electric shock or
injury to persons, always have a licensed electrician perform maintenance and other
repairs.
Tools Needed
• Power drill
• Screwdriver
5
Installation
• Do not connect the fireplace to the power supply until properly fixed to the wall and the
instructions are carefully read.
• Make sure the area to be drilled does not have any hidden electrical wires or water and
gas pipes.
• The minimum distances must be observed as shown in the diagrams below.
• During installation of the fireplace, avoid any possible damage to concealed cables.
• Please be careful when drilling holes.
• This fireplace is designed to be permanently fixed to a wall. Choose a wall that is sturdy
enough to hold the weight of the fireplace such as a brick or cinder block wall. If
positioning on drywall, it must be fixed to studs. If you are not sure if the wall is stable
enough,
then consult a hardware expert. The wall bracket must be fixed horizontally
with the cable routed to the bottom right of the fireplace.
• For optimum viewing of the fuel bed, it is recommended that there be a distance of 2 feet
from the bottom of the fireplace relative to the floor (see figure for recommended fixed
dimensions).
35.4 inch
22 inch
2 feet
5.9 inch
Step One
• Keep the top of the fireplace at least 3 feet away from the ceiling or other objects for
optimum heat ventilation.
• Remove the front frame from the fireplace and place it away safely so that it does not
become damaged.
• For optimum viewing, place four marks on the wall with respect to the recommended
fixed dimensions for the top screws (see figure below).
• Note: use a level when marking the positions of the holes to ensure that the bracket is
mounted horizontally.
22 inch
11 inch
41 inch
Step Two
• Make sure the area to be drilled does not have any hidden electrical wires or water and
gas pipes.
• The screws provided is for concrete walls only; please use suitable fixings for your wall
type. If in doubt, contact a qualified hardware expert.
• Drill holes into the wall with respect to the four markings and then insert the screw
anchors. Next, place the bracket onto the wall such that the holes are aligned. Insert the
appropriate screws into the wall and then tighten them with a screwdriver.
Step Three
• Using the two supplied (small) black screws, attach the lower fixing bracket to the base
of the fireplace such that the bracket is fitted to be level with the back.
• Carefully lift up the fireplace onto the top rear ledge of the fireplace. Once the ledge
latches onto the wall bracket and is evenly balanced, gently bring the fireplace down
against the wall.
• Mark two positions on the wall for two holes to match the lower fixing bracket holes.
Once the positions are properly marked, remove the fireplace.
• Drill holes into the marked position on the wall and then insert the screw anchors.
• Put the fireplace on the wall and fasten the bottom fixing bracket to the wall using the
provided screws to permanently fix the fireplace in place
.
6
Step Four
!
• Unpack the pebbles from the bag and place them along the light unit in the desired
position. Please note the pebbles are located in the side of the polystyrene packaging.
Step Five
• Place the front frame over the front of the fireplace aligning the slots in the bracket at
each side of the glass panel with the knobs on the sides of the fire (see figure below).
Two people will be required for this operation.
Instructions for Use
This fireplace can be operated either by the switches located on the top right hand side
of the fireplace or the supplied remote control.
Manual Operation
• The switches are located on the top right hand side of the fireplace. The standby switch
must first be turned on.
• Press the button once to turn on the fireplace and flame effect. A red indicator light will
appear to indicate that the function is ON.
• Press the button for 3 seconds to operate the automatic color change function. The
flame colors will change every 10 seconds.
• Press the 750W button once for low heat setting; press twice to turn off the heat.
• Press the 1500W button once for high heat setting; press twice to turn off the heat.
Remote Control Operation
• The power switch located at the right hand side of the fireplace must first be switched
on; the fireplace will beep to indicate that it is powered up.
• Insert 2 x 1.5V AAA batteries (not included) into the battery compartment of the remote
control. Make sure they are inserted with the correct polarity. (The -/+ signs placed in the
proper position.) Securely close the battery compartment cover.
• It takes some time for the receiver to respond to the transmitter. Do not press any
7
buttons on the remote control more than once within two seconds in order for the
Problem
Possible Solution
Check if the unit is plugged in the power
Check if the unit is plugged in the power
Check if the unit is in Standby mode. Turn
fireplace to operate properly.
• Press the standby button
on the remote control once to turn on the fireplace with
flame effect.
• Press the “750W” button once for low heat setting. Press the button again to switch off
the heat.
• Press the “1500W” button once for high heat setting. Press the button again to switch off
the heat.
• Press the “DIMMER” button to change the flame color. Every time you push the button,
the colors will change in the following order:
o Amber
o Red
o Green
o Blue
o Red and Green
o Red and Blue
o Green and Blue
o Red and Amber
o Green and Amber
o Blue and Amber
Auto Safety Shut-Off Mechanism
• This fireplace is equipped with a safety shut-off feature which initiates if the fireplace
overheats (e.g. Due to blocked air vents). For safety reasons, the fireplace will NOT
automatically reset, and will need to be manually turned ON.
• To restart the fireplace, unplug the fireplace from the power outlet for at least 15 minutes.
Next, reconnect to the power outlet and turn on the fireplace.
Troubleshooting
Unit does not work / does not heat
No flame effect
!
outlet.
! Check if the unit is in Standby mode. If so,
turn the unit ON.
! Check if the heat is turned OFF.
! Check for safety cut-off operation.
!
outlet.
!
the unit ON.
8
9
Cleaning & Maintenance
• Disconnect from the power supply before attempting any maintenance or cleaning in
order to reduce the risk of fire, electric shock to persons or damage to property.
• Warning - Always disconnect from the power supply before cleaning fireplace.
• For general cleaning, use a soft, clean duster. Never use abrasive cleaners. The glass
viewing screen should be cleaned thoroughly with a soft cloth. Do NOT use proprietary
glass cleaners.
• Periodically check all fixings and tighten if necessary.
• The LED bulbs inside can NOT be replaced.
Technical Specification
• Supply: 120V, 60Hz
• Rated Power: 1500W
• Bulb: LED (cannot be replaced)
Loading...
