FACTORY
PARTS CATALO
G
PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
GLHS269ZCB0 GLHS269ZC R134a black 115
GLHS269ZCQ0 GLHS269ZC R134a bisque 115
GLHS269ZCW0 GLHS269ZC R134a white 115
MARKET
North America
ENERGY GUIDE - 240592223
OWNER’S GUIDE - # 240389311
SERVICE DATA SHEET - #240389610
SIDE BY SIDE
REFRIGERATOR
ELECTROLUX HOME PRODUCTS, INC.
P.O. BOX 212378, Augusta, GA 30917
Publication No.
5995390118
030506
-EN/SERVICE/KHB
357
©2003 Electrolux Home Products, Inc.
All rights reserved
Model No.
GLHS269ZC
Publication No. GLHS269ZC
5995390118
FREEZER DOOR
05/03 2
A = GLHS269ZC (GLHS269ZCB0)
B = GLHS269ZC (GLHS269ZCQ0)
C = GLHS269ZC (GLHS269ZCW0)
POS. NO PART NO DESCRIPTION
1 # 240390606 A - - Gasket-frzr door,black ,magnetic
1 # 240390602 - B C Gasket-frzr door,white ,magnetic
4A 240334202 A B C Bin-door,frzr-upper
4B 240351602 A B C Bin-door
4C 240351702 A B C Bin-door,frzr-dispenser
11 240451813 A - - Door-frzr,black ,complete assy
11 240451806 - B - Door-frzr,bisque ,complete assy
11 240451800 - - C Door-frzr,white ,complete assy
13A 240537106 A - - Door Stop,black ,frzr
13A 240537104 - B - Door Stop,bisque ,frzr
13A 240537102 - - C Door Stop,white ,frzr
18 240359108 A - - Handle-door,black ,LH
18 240359109 - B - Handle-door,bisque
18 240359106 - - C Handle-door,white
21 218781100 A B C Screw, pan head ,8-18 x 0.625
21A 5308016566 A B C Screw, hex washer head, 8-15A x 0.625, low profile
21C 240521302 A B C Screw,#8-18 x 3/4
22A 240561602 A B C Bearing-hinge,closer
22C 240328404 A - - Bearing-hinge,black ,upper
22C 240328402 - B C Bearing-hinge,upper
37 240359203 A - - Trim-handle,30.13" ,black ,lower
37 240359204 - B - Trim-handle,30.13" ,bisque ,lower
37 240359201 - - C Trim-handle,30.13" ,white ,lower
68 240467701 A B C Chute-ice
72 240421701 A B C Button-handle mtg,dovetail
73 218396700 A B C Block-handle mtg,dovetail
74 215503200 A B C Screw,cr pan hd ,10-16 x 0.500
GLHS269ZC Publication No.
5995390118
FREEZER DOOR
* 240470401 A B C Connector-amp
* 240545101 A B C Connector-water,straight
* 240552102 A B C Harness-wiring,door
* 5303918256 A B C Dispenser heater kit
# = Fast-moving Parts 3 05/03
* = Non-Illustrated Parts
Publication No. GLHS269ZC
5995390118
REFRIGERATOR DOOR
05/03 4
A = GLHS269ZC (GLHS269ZCB0)
B = GLHS269ZC (GLHS269ZCQ0)
C = GLHS269ZC (GLHS269ZCW0)
POS. NO PART NO DESCRIPTION
2 240390605 A - - Gasket-refr door,black ,magnetic
2 # 240390601 - B C Gasket-refr door,white ,magnetic
4 240323002 A B C Bin-door,pseudo ,bottom
7 240326203 A B C Door-dairy
12 240449707 A - - Nameplate,black
12 240449706 - B - Nameplate,bisque
12 240449705 - - C Nameplate,white
13 240537105 A - - Door Stop,black ,ref
13 240537103 - B - Door Stop,bisque ,ref
13 240537101 - - C Door Stop,white ,ref
15 240451908 A - - Door-refr,black ,complete assy
15 240451904 - B - Door-refr,bisque ,complete assy
15 240451900 - - C Door-refr,white ,complete assy
18 240359103 A - - Handle-door,black ,RH
18 240359104 - B - Handle-door,bisque
18 240359101 - - C Handle-door,white
21 218781100 A B C Screw, pan head, 8-18 x 0.625
21A 5308016566 A B C Screw, hex washer head, 8-15A x 0.625, low profile
21C 240521302 A B C Screw,#8-18 x 3/4
22 240561601 A B C Bearing-hinge,closer
22B 240328403 A - - Bearing-hinge,upper
22B 240328401 - B C Bearing-hinge,upper
27A 240396102 A B C Retainer,tall bottle
37 240359203 A - - Trim-handle,30.13" ,black ,lower
37 240359204 - B - Trim-handle,30.13" ,bisque ,lower
37 240359201 - - C Trim-handle,30.13" ,white ,lower
49 240430311 A B C Bin-door,gallon
72 240421701 A B C Button-handle mtg,dovetail
73 218396700 A B C Block-handle mtg,dovetail
74 215503200 A B C Screw,cr pan hd ,10-16 x 0.500
GLHS269ZC Publication No.
5995390118
REFRIGERATOR DOOR
# = Fast-moving Parts 5 05/03
* = Non-Illustrated Parts
Publication No. GLHS269ZC
5995390118
CABINET
05/03 6
A = GLHS269ZC (GLHS269ZCB0)
B = GLHS269ZC (GLHS269ZCQ0)
C = GLHS269ZC (GLHS269ZCW0)
POS. NO PART NO DESCRIPTION
10 240435902 A B C Cover-air duct
10A 240475902 A B C Cover-evap coil,lower
11 5303208309 A B C Plug-hole,factory test
14 # 240505801 A B C Switch,light/lamp
14A# 215486600 A B C Switch-light/lamp
21C 218252200 A B C Screw,#8 truss hd ,10-32CA x 0.500
22 240457701 A B C Plate-door closer
23 240402701 A B C Screw-#10-32 x 1/4 flat hd
28 240335501 A B C Bolt-roller adj,hex wshr hd,1/4-20 x 4.020, (2), special
30 240419103 A B C Bracket-lower hinge, ref
30A 240419104 A B C Bracket-lower hinge
37 240337603 A - - Trim-cabinet corner,black ,(2)
37 240337604 - B - Trim-cabinet corner,bisque ,(2)
37 240337601 - - C Trim-cabinet corner,white ,(2)
38 240327202 A B C Bracket-upper hinge
40 240327007 A - - Cover-upper hinge,black
40 240327006 - B - Cover-upper hinge,bisque
40 240327005 - - C Cover-upper hinge,white
41 240358701 A B C Grommet-shelf mtg,1.40" long
41* 240358801 A B C Grommet-shelf mtg,.875" long
42 240578901 A B C Screw-hinge mtg,hex head ,1/4-20 x 5/8
43 240335003 A B C Roller Assy,front ,(2)
45 241500301 A B C Screw,hex washer head ,8-18AB x 0.500
47 240349402 A B C Channel-shelf mtg,side ,(2)
58 218749600 A B C Screw,#10 pan hd ,8-18 x .5
66 240504901 A B C Cover-damper
66A 240505001 A B C Damper-meat keeper
66B 240355901 A B C Insulation-damper
66B* 240518802 A B C Pin-push,push-in ,plastic
72 240324406 A - - Grille/Kickplate,black
72 240324404 - B - Grille/Kickplate,bisque
72 240324402 - - C Grille/Kickplate,white
81 5308016566 A B C Screw,hex washer head, 8-15A x 0.625, low profile
82 5304418225 A B C Roller,compressor base ,rear ,(2)
83 5303316859 A B C Rivet,flat head ,1/4 OD x 1-3/4, roller pin
89 240326104 A B C Cover,access ,system compt ,with label
90 218249808 A B C Seal-coil cover
91 240380101 A B C Duct-ice maker
92 216850900 A B C Screw, hex washer hd, 1/4 x 7/8, hinge mtg
100 240423701 A B C Support,crisper cover ,front ,(4)
100* 240350802 A B C Support,crisper cover ,rear ,(4)
150 240368701 A B C Guide-control bulb
GLHS269ZC Publication No.
5995390118
CABINET
* 218515401 A B C Clip
* 240396801 A B C Clamp, tube/wiring, nylon, black/natural
* 240479601 A B C Plug, button, cab liner holes
* 240481601 A B C Shim-lower hinge
* 5303305345 A - - Paint,touch-up ,black
* 5304414035 - B - Paint,touch-up ,bisque
* 5303305324 - - C Paint,touch-up ,white
# = Fast-moving Parts 7 05/03
* = Non-Illustrated Parts
Publication No. GLHS269ZC
5995390118
SHELVES
05/03 8
A = GLHS269ZC (GLHS269ZCB0)
B = GLHS269ZC (GLHS269ZCQ0)
C = GLHS269ZC (GLHS269ZCW0)
POS. NO PART NO DESCRIPTION
2 240434604 A B C Trim-basket
11 240350668 A B C Shelf-freezer,glass ,lower
11A 240350667 A B C Shelf-freezer,glass ,upper
11C 240324101 A B C Shelf-pizza
15 240588001 A B C Light Bulb
15A 240436702 A B C Light Bulb/Lamp,A-15 ,clear ,40 W, 120 V, miniature
16 240590401 A B C Socket-light
16* 240587702 A B C Harness-wiring
16A 218906801 A B C Socket-light/lamp
24 240355203 A B C Shelf-"Spill-Safe",fixed
24A 240350106 A B C Shelf-"Spill-Safe",cantilever ,sliding
24B 240424602 A B C Shelf-"Spill-Safe",sliding ,"Aspect", complete
25 240350702 A B C Cover-crisper pan,upper
25* 240362101 A B C Clip-slide,cover-crisper
25A 240350902 A B C Cover-crisper pan,lower
26 240351021 A B C Pan-crisper,upper
26* 240349801 A B C Clip-slide,pan-crisper
26* 240423101 A B C Channel-divider
26* 240423201 A B C Retainer
26* 240423301 A B C Divider-crisper pan
26A 240422901 A B C Control-humidity
26A* 240423001 A B C Frame-humidity control,upper
27 240351218 A B C Pan-crisper,lower
27A 240362201 A B C Control-humidity
39 240367602 A B C Trim-shelf,front
42 240356501 A B C Track,meat pan hanger ,RH
42A 240349701 A B C Hanger-meat pan,LH
42A* 240349901 A B C Block-meat pan rail,LH
42A* 240350001 A B C Spring-meat pan rail
47 240350602 A B C Insert-pan cover,glass
47A 240350603 A B C Insert-pan cover,glass
49 240564401 A B C Basket-sliding
49A 240530502 A B C Basket-sliding,upper ,half
49B 240530504 A B C Basket-sliding,upper ,full
51 240343002 A B C Hanger-basket,RH
51A 240395502 A B C Hanger-basket,RH
51B 240579801 A B C Hanger-basket,RH
52 240343102 A B C Hanger-basket,LH
52A 240395602 A B C Hanger-basket,LH
52B 240579802 A B C Hanger-basket,LH
62 240342817 A B C Pan-meat
81 5308016566 A B C Screw,hex washer head ,8-15A x 0.625, low profile
97 240545303 A B C Water Tank Assy,coiled tubing, front filter
100 240326302 A B C Cover-water tank
101 218493100 A B C Screw,hex washer head ,8-18AB x 1-3/4
109 240351301 A B C Base-crisper light socket
120 240342902 A B C Shelf-ice cream
123 215005100 A B C Screw,hanger/rlr mtg ,8-10 x 0.438
126 218867405 A B C Channel,auger mtg ,LH
126 218867406 A B C Channel,auger mtg ,RH
136 240424501 A B C Dispenser-can,white
140 240430501 A B C Channel,wtr tube cover
140A 240430503 A B C Channel,wtr tube cover
141 240585404 A B C Bracket-light socket
142 240582701 A B C Shield-light,deli pan
GLHS269ZC Publication No.
5995390118
SHELVES
# = Fast-moving Parts 9 05/03
* = Non-Illustrated Parts
Publication No. GLHS269ZC
5995390118
CONTROLS
05/03 10
A = GLHS269ZC (GLHS269ZCB0)
B = GLHS269ZC (GLHS269ZCQ0)
C = GLHS269ZC (GLHS269ZCW0)
POS. NO PART NO DESCRIPTION
5 # 5308000010 A B C Fan Blade,red ,evaporator fan
8 5300157666 A B C Bushing-motor mtg,(2)
9 5303292396 A B C Bracket-motor mtg,front
13 # 240315802 A B C Motor-evap fan
13* 215474201 A B C Washer,"slinger" ,nylon ,evap fan shaft
14 5303292397 A B C Bracket-motor mtg,rear
15 240436702 A B C Light Bulb/Lamp, A-15, clear, 40 W, 120 V,miniature
16 218906801 A B C Socket-light/lamp
17 240317701 A B C Box-control,front
17* 240439901 A B C Wiring Harness,controls
18 240360801 A B C Knob,temp control
21 # 240383703 A B C Control-temperature
21A 5304421768 A B C Control-temperature
22 218660702 A B C Tube-insulator
23 240554501 A B C Control-defrost, adaptive timer, PC board
23* 5303001259 A B C Screw-timer mtg, pan hd, 6-20 x 0.438, (2)
45 5303001343 A B C Screw, hex washer head, 8-15A x 0.500
53 240369501 A B C Box-control
81 5308016566 A B C Screw, hex washer head, 8-15A x 0.625, low profile
101 218493100 A B C Screw, hex washer head ,8-18AB x 1-3/4
115 240521103 A B C Damper Assy,w/seal
137 240396401 A B C Filter,water ,front ,cassette
137* 240396701 A B C Bypass,water filter ,Optional Part
138 240397301 A B C Button-filter release
139 240396001 A B C Base-water filter
139* 240526901 A B C O-ring,wtr filter base
149 240331602 A B C Shroud-fan orfice
150 240394204 A B C Insulation-water tube cover
151 240373806 A B C Cover-water tube
198 240397401 A B C Retainer
199 240397501 A B C Rod
199* 240398401 A B C Spring-filter release rod
200 240397601 A B C Light Pipe
201 240398509 A B C Label-control box
GLHS269ZC Publication No.
5995390118
CONTROLS
* 3205266 A B C Edge Protector,wiring harness
* 240427201 A B C Heater-freezer control
* 240470401 A B C Connector-amp
# = Fast-moving Parts 11 05/03
* = Non-Illustrated Parts
Publication No. GLHS269ZC
5995390118
SYSTEM
05/03 12
A = GLHS269ZC (GLHS269ZCB0)
B = GLHS269ZC (GLHS269ZCQ0)
C = GLHS269ZC (GLHS269ZCW0)
POS. NO PART NO DESCRIPTION
1 240333603 A B C Condenser
3 218679607 A B C Block-evap coil,styrofoam ,(2)
4 # 218944001 A B C Drier-filter,R134a System
6 240346402 A B C Harness-wiring,machine compt
6* 240439901 A B C Wiring Harness,controls
6* 240449601 A B C Harness-wiring
14 # 5303918253 A B C Defrost Heater Kit
15 # 5303918284 A B C Evaporator Kit
16 5308000110 A B C Strap-evap/heater,aluminum ,(2)
21 5303918214 A B C Thermostat-defrost,kit
22 240330003 A B C Base-compressor
22* 218252200 A B C Screw,#8 truss hd ,10-32CA x 0.500
23 218513300 A B C Grommet-compr mtg,(4)
25 240491501 A B C Screw-compr mtg,1/4-28 x 1.16,shoulder, typ CF
26 240332602 A B C Pan-defrost drain
29 # 5303918292 A B C Compressor,w/electricals
30 # 218721119 A B C Starter,PTC
32 218973501 A B C Clamp,elec cont mtg ,compressor
34 240405201 A B C Grommet,rubber ,black ,cond tube/wire
41 240555001 A B C Screw-#8-32 X 3/8
44 215174700 A B C Clamp-service cord, strain relief, galv steel
45 5308016566 A B C Screw, hex washer head, 8-15A x 0.625, low profile
55 # 218909901 A B C Capacitor,run ,50/60 Hz ,220 VAC, 15 microfarad
57 240542601 A B C Clip-wiring harness
58 215004600 A B C Screw,hx wshr hd ,8-36 x 7/16, cond fan motor, (2)
59 240315501 A B C Shroud-cond fan
59* 240346701 A B C Tape-foam seal,shroud
59* 240359401 A B C Screw-fan shroud,(2)
59A 240346501 A B C Bracket-support,cond mtr ,(3)
59B 240346601 A B C Grommet-bracket,(3)
60 # 240334002 A B C Motor-condenser fan
61 # 240315401 A B C Fan Blade,galv steel ,condenser fan
61A 215004700 A B C Nut,speed
61B 215004800 A B C Grommet-silencer
62 240429402 A B C Trough-drain
70 218990801 A B C Bracket-evap/cvr mtg
72 218397000 A B C Button-handle mtg,dovetail
82 5304418225 A B C Roller, compressor base ,rear ,(2)
83 5303316859 A B C Rivet, flat head, 1/4 OD x 1-3/4, roller pin
84 5304421068 A B C Tube-drain,lower
85 240346201 A B C Tube-connector,suction
86 240409302 A B C Spacer-cond tube,black
GLHS269ZC Publication No.
5995390118
SYSTEM
* # 5303918213 A B C Heat Exchanger Kit,suction line
* # 5303918222 A B C Hot Tube Repair Kit,Service
# = Fast-moving Parts 13 05/03
* = Non-Illustrated Parts
Publication No. GLHS269ZC
5995390118
DISPENSER
05/03 14
A = GLHS269ZC (GLHS269ZCB0)
B = GLHS269ZC (GLHS269ZCQ0)
C = GLHS269ZC (GLHS269ZCW0)
POS. NO PART NO DESCRIPTION
1 218976409 A B C Tube-water
1* 218976901 A B C Tube-water inlet, inlet valve to ice maker
1* 218976903 A B C Tube-water inlet, inlet valve to filter
1* 218976907 A B C Tube-water inlet, valve to door
4 5304422012 A - - Cover-module, black
4 5304421848 - B - Cover-module, bisque
4 5304421822 - - C Cover-module, white
8 5304433616 A - - Module-dispenser, black
8 5304433617 - B - Module-dispenser,bisque
8 5304433618 - - C Module-dispenser, white
10 5304426649 A B C Spring-torsion
14 240323969 A - - Label-module cover, black
14 240323968 - B - Label-module cover, bisque
14 240323967 - - C Label-module cover, white
17 5304421619 A B C Screw
23 240323603 A - - Drip Tray,black
23 240323602 - B - Drip Tray,bisque
23 240323601 - - C Drip Tray,white
24 5304433613 A - - Actuator-water,black
24 5304433614 - B - Actuator-water,bisque
24 5304433615 - - C Actuator-water,white
24A 5304433610 A - - Actuator-ice,black
24A 5304433611 - B - Actuator-ice,bisque
24A 5304433612 - - C Actuator-ice,white
30 5304421628 A B C Door Assy-ice chute
30A 5304421624 A B C Door center
30B 5304421625 A B C Insulation-door
30C 5304421629 A B C Door seal
35 5304421620 A B C Damper-rotary
36 5304421824 A B C Carrier
38 5304433619 A B C Board-power
38A# 5304421617 A B C Switch-micro,single pole ,double throw
38C 5304433609 A B C Board-control
38C* 5304430811 A B C Harness-ribbon cable
39 5304421627 A B C Pin-hinge
41 5304421829 A B C Spring-actuator
43 215296300 A B C Screw,plask h/l ,#6 x 3/8
56 5304421830 A B C Screw-micro switch,pan head
87 5304421622 A B C Bearing Plate
87A 5304421621 A B C Bearing Plate
90 5304421831 A B C Light Pipe,reflector
91 5304421850 A B C Light Pipe,reflector ,short
GLHS269ZC Publication No.
5995390118
DISPENSER
* 5303918256 A B C Dispenser heater kit
* 5304426535 A B C Insulator-electrical
# = Fast-moving Parts 15 05/03
* = Non-Illustrated Parts
Publication No. GLHS269ZC
5995390118
ICE CONTAINER
05/03 16
A = GLHS269ZC (GLHS269ZCB0)
B = GLHS269ZC (GLHS269ZCQ0)
C = GLHS269ZC (GLHS269ZCW0)
POS. NO PART NO DESCRIPTION
2 5304428402 A B C Auger-ice
3 5304404343 A B C Cam-drive
4 218815300 A B C Container-ice,bucket only
6 5304404346 A B C Drum-ice disp
7 5304422805 A B C Front-ice container
10 5304404337 A B C Bar-drive
13 5304404359 A B C Gate
15 5303001179 A B C Light Bulb/Lamp,40 W
16 5303289050 A B C Socket-light/lamp
17 5304404345 A B C Drive Blade
18 # 240326903 A B C Motor-auger
18* 5304404335 A B C Wiring Harness,auger motor
20 5304404332 A B C Cover-motor
21 215285100 A B C Nut-drive
23 5304404347 A B C Plate-front
25 5304404362 A B C Screw,hex washer head ,8-32T x 0.375
26 215503200 A B C Screw,cr pan hd ,10-16 x 0.500
33 5304404351 A B C Spacer
34 5304404349 A B C Spacer
35A 5304404353 A B C Fixed Blade,round
35B 5304404352 A B C Fixed Blade,square
37A 5304404348 A B C Blade,crusher #1
37B 5304404350 A B C Blade,crusher #2
37C 5304404356 A B C Blade,crusher #3
39 5304404365 A B C Screw
41 5304404358 A B C Housing-crusher
44 218359200 A B C Screw,pan head ,8-32 x 0.250
45 # 5304404333 A B C Solenoid Assy
45A 5304406816 A B C Spring-solenoid
45B 5304406817 A B C E-Ring-solenoid
45C 5304406818 A B C Actuator-solenoid
45D 5304406819 A B C Solenoid
46 5304404341 A B C Control Rod
47 5304404342 A B C Spring-control rod
48 5304404340 A B C Bracket-control rod
48* 5304404364 A B C Screw-bracket
49 5304404329 A B C Rail Assy
50 5304404334 A B C Guide-solenoid
51 5304404336 A B C Rotation Stop
52 5304404354 A B C Spacer-fixed blades
53 5304404355 A B C Pin-spiral,fixed blades
54 5304404357 A B C Nut-auger
55 5304404360 A B C Washer
56 5304404361 A B C E-ring
58 5304404331 A B C Screw-solenoid
GLHS269ZC Publication No.
5995390118
ICE CONTAINER
* 240323806 A B C Ice Container Assy,w/moving parts
# = Fast-moving Parts 17 05/03
* = Non-Illustrated Parts
Publication No. GLHS269ZC
5995390118
ICE MAKER
05/03 18
A = GLHS269ZC (GLHS269ZCB0)
B = GLHS269ZC (GLHS269ZCQ0)
C = GLHS269ZC (GLHS269ZCW0)
POS. NO PART NO DESCRIPTION
1 218976409 A B C Tube-water
1* 218976901 A B C Tube-water inlet, inlet valve to ice maker
1* 218976903 A B C Tube-water inlet, inlet valve to filter
1* 218976907 A B C Tube-water inlet, valve to door
1* 240561701 A B C Seal-water inlet, inlet valve to ice maker
2 5304420650 A B C Spring,shut-off arm
3 3206299 A B C Label,ID plate
4 3206301 A B C Gear
5 3206303 A B C Plate-mounting
6 3206305 A B C Screw-ground wire,8-32 x 0.250
7 # 3206306 A B C Motor-ice maker
8 3206312 A B C Spacer-hold switch
9 3206313 A B C Cam
10 3206315 A B C Clamp
11 # 3206319 A B C Thermal Cutoff, ice maker, complete assy
12 # 240352601 A B C Wiring Harness, ice maker, internal, with plug
13 # 3206322 A B C Thermostat Assy,ice maker
14 5304420652 A B C Screw,4 x 0.750 ,switch mtg.
15 # 3206324 A B C Switch,(3)
16 5304420653 A B C Support,phenolic
17 # 5303320545 A B C Mold-ice maker, Radius Cube, with heater
18 3206328 A B C Ejector-ice
19 3206330 A B C Bearing & Inlet
20 5304408581 A B C Screw, 8-32 x 0.375
21 3206332 A B C Ice Stripper
22 3206333 A B C Shut-off Arm
23 5304408582 A B C Screw, 8-32 x 0.875, mold-to-support, (3)
24 3206335 A B C Lever Arm
25 3206336 A B C Screw, 8-18 x 0.562, lever arm/sprt
26 5304420654 A B C Screw-thermo/sprt,4-24 x 0.375 ,(4)
27 3206338 A B C Screw, 4-40 x 1.000 ,hold switch mtg, (2)
28 3206339 A B C Screw-timing stop,4-40 x 0.375
29 3206323 A B C Screw, 4-24 x 0.750, (6)
30 3206341 A B C Screw-timing adj,8-32 x 1.000
31 3206342 A B C Insulator
32 3206343 A B C Plate-valve switch
33 5304408583 A B C Spring-timing adj
34 5304420655 A B C Screw,plazscrew ,8-10 ,(3)
35 5304408585 A B C Screw
36 3206347 A B C Cover-ice maker
42 5303001199 A B C Clamp-wiring harness,strain relief, galv steel
42* 218515402 A B C Clip,(2) ,tube mtg.
45 5308016566 A B C Screw, hex washer head, 8-15A x 0.625, low profile
45* 5303001343 A B C Screw,hex washer head ,8-15A x 0.500
46 5303001193 A B C Clamp,.50 ID ,steel ,water tube
46* 5308000133 A B C Clamp,nylon ,.625 ID
51 240387101 A B C Tube-water,ice mold fill ,extension
55 # 240531101 A B C Valve-water,triple solenoid
55* 218709100 A B C Screw,hex head ,10-32 x 0.500
55* 240363601 A B C Screw-shoulder
55* 240542901 A B C Cap-water valve
60 5303207328 A B C Screw, hex washer head, 8-15A x 1.000, (2)
61 218721500 A B C Bracket-leveling,ice maker
62 218737900 A B C Screw-IM brkt mtg,hex washer head, 8-32D x 0.375
64 5303001549 A B C Clamp,0.31 ID ,steel ,copper wtr line
GLHS269ZC Publication No.
5995390118
ICE MAKER
* 218888001 A B C Adapter-water supply,nut & sleeve, compression ftg
* 240352411 A B C Ice Maker,Radius Cube ,115 V, no instl parts
# = Fast-moving Parts 19 05/03
* = Non-Illustrated Parts
Publication No. GLHS269ZC
5995390118
WIRING SCHEMATIC
05/03 20
GLHS269ZC Publication No.
5995390118
WIRING DIAGRAM
# = Fast-moving Parts 21 05/03
* = Non-Illustrated Parts
Loading...
