WASHER
Owner's Guide
LAVEUSE
Guide de L’utilisateur
www.frigidaire.com P/N 1371235000 (0809)
1
Table of Contents
Important Safety Instructions...........................................................................................................................3-4
Washing Procedures.........................................................................................................................................5-6
Stain Removal.......................................................................................................................................................7
Common Washing Problems...............................................................................................................................8
Care and Cleaning...............................................................................................................................................9
Avoid Service Checklist................................................................................................................................10-11
Warranty and Service.........................................................................................................................................12
Français..........................................................................................................................................................13-23
Assistance or Service
The symbol on the product or on its packaging indicates that this product may not be treated as household waste.
Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By
ensuring this product is disposed of correctly, you will help
prevent potential negative consequences for the environment and human health, which could otherwise be caused by
inappropriate waste handling of this product. For more detailed information about recycling of this product, please contact your
local city office, your household waste disposal service or the shop where you purchased the product.
This Use and Care Guide provides general operating
instructions for your washer. It also contains information about
features for several other models. Your washer may not have
every feature included here.
Use the washer only as instructed in this Use and Care Guide
and the Operating Instructions included with your washer.
Read all instructions before using this appliance. This book
contains valuable information about
• Operation
• Care
• Service
Keep it in a safe place.
If you need assistance or service, first see the "Avoid Service
Checklist" section. Additional help is available by calling
1-800-944-9044 from anywhere in the U.S.A.
Read and Save These Instructions
Record Your Model and Serial Numbers
The model and serial numbers of your washer are found on
the washer serial plate located at the top, inside of the door
opening. Record and retain these numbers.
Model Number____________________________________
Serial Number_____________________________________
Purchase Date_____________________________________
WASHER SAFETY
Your safety and the safety of others is very important.
We have provided many important safety messages in the Use and Care Guide, Operating Instructions, Installation Instructions
and on your appliance. Always read and obey all safety messages.
This is the safety alert symbol. This symbol alerts you to hazards that can kill or hurt you or others. All safety messages
will be preceded by the safety alert symbol and the word "DANGER" or "WARNING". These words mean:
DANGER
All safety messages will identify the hazard, tell you how to reduce the chance of injury, and tell you what can happen if
the instructions are not followed.
You can be killed or seriously injured if you don't immediately follow instructions.
You can be killed or seriously injured if you don't follow instructions.
2
G
rounding type
g
g
wall receptacle
Avoid
fire hazard or electrical
shock. Do not use an
adaptor plug or
extension cord or
remove grounding
prong from electrical
power cord. Failure to
follow this warning can
cause serious injury, fire
or death.
Grounding
type wall
receptacle
Do not under
Do not under
any circumstances
any circumstances
cut, remove,
cut, remove,
or bypass the
or bypass
grounding prong
the grounding prong
from this plug
from this plug.
Power supply
Power supply
cord with 3-prong
cord with 3-prong
grounding plug
rounding plu
CORRECTCORRECT
CORRECT
CORRECTCORRECT
Use this way ONLYUse this way ONLY
Use this way ONLY
Use this way ONLYUse this way ONLY
use or mix liquid chlorine
bleach with other
household chemicals
such as toilet cleaners,
rust removers, acid or
products containing
ammonia. These
mixtures can produce
dangerous fumes which
can cause serious injury
or death.
Do not
Important Safety Instructions
Read all instructions before using this washer.
You can be killed or seriously injured if you don't follow these Important Safety Instructions:
• To reduce the risk of fire, electrical shock, or injury to persons when using this washer, comply with the basic warnings listed
below.
• Failure to comply with these warnings could result in serious personal injuries.
Prevent Fire
• Do not wash items that have been previously cleaned in, soaked in, or spotted with gasoline, cleaning solvents, kerosene,
cooking oils, waxes, etc. Do not store these items on or near the washer. These substances give off vapors or chemical
reactions that could ignite or explode.
• Do not put oily or greasy rags or clothing on top of the washer. These substances give off vapors that could ignite the
materials.
• Do not add gasoline, cleaning solvents, or other flammable or explosive substances to the wash water. These substances
give off vapors that could ignite or explode.
• Under certain conditions, hydrogen gas may be produced in a hot water system that has not been used for 2 weeks or more.
HYDROGEN GAS IS EXPLOSIVE. If the hot water system has not been used for such a period, before using the washer,
turn on all hot water faucets and let the water flow from each for several minutes. This will release any accumulated hydrogen
gas. Hydrogen gas is flammable; do not smoke or use an open flame during this time.
• Failure to comply with these warnings could result in fire, explosion, serious bodily injury and/or damage to the rubber or
plastic parts of the washer.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapors or liquids in the vicinity of this or any other appliance.
Protect Children
• Do not allow children to play on or in the washer. Close supervision of children is necessary when the washer is used near
children. As children grow, teach them the proper, safe use of all appliances.
• Destroy the carton, plastic bag and other packing materials after the washer is unpacked. Children might use them for play
Cartons covered with rugs, bedspreads or plastic sheets can become airtight chambers.
• Keep laundry products out of children's reach. To prevent personal injury, observe all warnings on product labels.
• Before the washer is removed from service or discarded, remove the washer lid to prevent accidental entrapment.
• Failure to comply with these warnings could result in serious personal injuries.
3
Printed in U.S.A.
Important Safety Instructions (con't)
Prevent Injury
• To prevent shock hazard and assure stability during operation, the washer must be installed and electrically grounded by
a qualified service person in accordance with local codes. Installation instructions are packed in the washer for installer's
reference. Refer to INSTALLATION INSTRUCTIONS for detailed grounding procedures. If the washer is moved to a new
location, have it checked and reinstalled by a qualified service person.
• To prevent personal injury or damage to the washer, the electrical power cord of the washer must be plugged into a properly
grounded and polarized 3-prong outlet. The third grounding prong must never be removed. Never ground the washer
to a gas pipe. Do not use an extension cord or an adaptor plug.
• Follow package directions when using laundry products. Incorrect usage can produce poisonous gas--resulting in serious
injury or death.
-Do not combine laundry products for use in 1 load unless specified on the label.
-Do not mix chlorine bleach with ammonia or acids such as vinegar.
• To prevent serious personal injury and damage to the washer:
-All repairs and servicing must be performed by an authorized servicer unless specifically recommended in this
Owner's Guide. Use only authorized factory parts.
-Do not tamper with controls.
-Do not install or store the washer where it will be exposed to the weather.
• ALWAYS disconnect the washer from the electrical supply before attempting any service or cleaning. Failure to do so can
result in electrical shock or injury.
• To prevent injury, do not reach into the washer while parts are moving. Before loading, unloading or adding items, push in
the cycle selector knob and allow the tub to coast to a complete stop before reaching inside.
• Failure to comply with these warnings could result in serious personal injuries.
• This washer is equipped with an electrical overload protector. The motor will stop if it becomes overheated. The washer will
automatically restart after a cool down period of up to 30 minutes, if the washer has not been manually turned off during this
time.
This Owner's Guide provides general
operating instructions for your
washer. It also contains information
about features for several other
models. Your washer may not have
every feature included here. Use
the washer only as instructed in this
Owner's Guide and the Operating
Instructions card included with
your washer.
SAVE THESE INSTRUCTIONS
Note: The instructions appearing in
this Owner's Guide are not meant to
cover every possible condition and
situation that may occur. Common
sense and caution must be practiced
when installing, operating and
maintaining any appliance.
4
Washing Procedures
Sort laundry into loads that can be
washed together.
• Follow the guidelines below for preparing the wash load.
• Read the Operating Instructions for operating your specific model.
• Always read and follow fabric care and laundry product labels.
To reduce the risk of fire, electrical shock, or injury to persons, read
Important Safety Instructions before operating this washer.
1. Sort laundry into loads that can be washed together.
Sort items by recommended water temperatures, wash time, and agitate/spin
speeds.
• Separate white, light, and colorfast items from dark and noncolorfast items.
• Separate items which shed lint from items which attract lint. Permanent
press, synthetic, knit and corduroy items will pick up lint from towels, rugs
and chenille bedspreads.
• Separate heavily soiled items from lightly soiled items.
• Separate lacy, sheer and loosely knit items from sturdy items.
2. Prepare items for washing.
• Empty pockets.
• Brush off lint and dirt. Shake out rugs and beach towels.
• Close zippers, fasten hooks, tie strings and sashes, and remove
nonwashable trims and ornaments.
• Remove pins, decorative buttons, belt buckles, and other objects which
could be damaged. This also helps protect other items in the wash load.
• Mend rips and tears to prevent further damage during washing.
• Place delicate items such as bras, shoulder pads, hosiery, and belts in a
mesh bag to prevent tangling during the wash cycle.
• Turn knit items inside out to prevent pilling.
Empty pockets.
Place delicate items in a mesh bag.
Bleach Dispenser (some models)
3. Pretreat stains and heavy soil.
See Stain Removal for details.
4. Add a measured amount of detergent to the wash tub before adding the
laundry load.
Follow detergent manufacturer's directions. The amount required depends on
type of detergent, load size and soil level, and water hardness.
5. If desired, add liquid bleach to bleach dispenser (available on some
models).
• Before adding the wash load, add liquid bleach to bleach dispenser located
in left front corner under the lid:
• 3/4 cup (180 ml) for small loads
• 1 cup (240 ml) for large loads
• 1-1/4 cups (300 ml) for extra-large loads.
• Then add 1 cup (240 ml) water to flush the dispenser.
• Do not use powdered bleach in the bleach dispenser. Add powdered
bleach to the empty tub.
For models without a bleach dispenser, dilute the recommended amount
of liquid chlorine bleach in 1 quart (.95 L) of water. Add it to the wash water after
a few minutes of agitation. DO NOT pour bleach directly onto wash load.
5
Washing Procedures
(continued)
Do not load higher than top of agitator
vanes.
Built-In Fabric Softener Dispenser
(some models)
6. Add laundry load to washer.
• Dry load level should not be higher than the top of the agitator vanes.
Do not overload the washer.
• Do not put items on top of agitator or wrap them around it. Load items
evenly.
• Combine large and small items in a load. Load large items first. Large
items should not be more than half the total wash load.
• When washing a single heavy item, add 1 or 2 towels to balance the load.
7. If desired, add liquid fabric softener to fabric softener dispenser (available
on some models).
For models with a built-in dispenser (see picture to the left):
1. Add liquid softener to the dispenser, following fabric softener label directions.
2. Add water to bring liquid level to fill line on dispenser cap.
3. Remove the dispenser from the agitator after each use. Rinse both cap and
cup with warm water. Replace dispenser in the agitator.
NOTE: To separate cap from cup, put thumb into dispenser and push against side
of cup (see picture to the left). After cleaning, push cap and cup firmly together.
Replace dispenser by lining up the ribs and grooves and snapping it into position.
Built-In Fabric Softener Dispenser
(some models)
If a build-up of fabric softener occurs, clean with hot water. DO NOT REMOVE
SERVICE CAP FOUND INSIDE THE AGITATOR POST.
For models without a fabric softener dispenser, follow fabric softener label
directions. Add diluted fabric softener to the final rinse. Do not pour fabric
softener directly on the wash load.
8. Select cycle and settings according to type, size and soil level of each
load.
See Operating Instructions for your specific model controls.
9. Start the washer.
Close the washer lid and pull out the cycle selector knob. The washer will not
fill with water, agitate or spin when the lid is open, and will only start to do so
if the lid is closed.
• To stop the washer, push in the cycle selector knob.
• Do not stop and restart washer during a spin when using the fabric softener
dispenser.
• To change a cycle, push in the cycle selector knob. Turn it clockwise to
the desired setting. Pull out the knob to restart the washer.
10. Remove items when the cycle is completed.
For your safety, the lid locks when the tub is spinning. It will remain locked for
about 2-3 minutes after the tub stops spinning.
• To open the lid during a spin, push in the cycle selector knob and wait about
2-3 minutes for the lid lock to release. Do not force open the locked lid.
Place washed items in automatic dryer, line dry, or dry flat as directed by fabric
care label. Excess wrinkling, color transfer or odors may develop in items left in
the washer after the cycle has ended.
To avoid serious personal injury, do not operate washer if safety lid
lock is missing or damaged.
6
Stain Removal
Do not combine stain removal products.
Follow fabric care label instructions.
STAIN
Adhesive tape, chewing gum,
rubber cement
Baby formula, dairy products,
egg
Beverages (coffee, tea, soda,
juice, alcoholic beverages)
Blood
Candle wax, crayon
Chocolate
Collar or cuff soil, cosmetics
Dye transfer on white fabric
Grass
Grease, oil, tar (butter, fats,
salad dressing, cooking oils,
car grease, motor oils)
Ink
Mildew, scorch
Mud
Mustard, tomato
Nail polish
Paint, varnish
Perspiration
Rust, brown or yellow
discoloration
Shoe polish
TREATMENT
Apply ice. Scrape off excess. Place stain face down on paper towels. Saturate with prewash stain remover or nonflammable dry
cleaning fluid.
Use product containing enzymes to pretreat or soak stains. Soak for 30 minutes or more. Wash.
Pretreat stain. Wash using cold water and bleach safe for fabric.
Rinse with cold water. Rub with bar soap. Or, pretreat or soak with product containing enzymes. Wash using bleach safe for
fabric.
Scrape off surface wax. Place stain face down between paper towels. Press with warm iron until wax is absorbed. Replace
paper towels frequently. Treat remaining stain with prewash stain remover or nonflammable dry cleaning fluid. Hand wash to
remove solvent. Wash using bleach safe for fabric.
Pretreat or soak in warm water using product containing enzymes. Wash using bleach safe for fabric.
Pretreat with prewash stain remover or rub with bar soap.
Use packaged color remover. Wash using bleach safe for fabric.
Pretreat or soak in warm water using product containing enzymes. Wash using bleach safe for fabric.
Scrape residue from fabric. Pretreat. Wash using hottest water safe for fabric. For heavy stains and tar, apply nonflammable dry
cleaning fluid to back of stain. Replace towels under stain frequently. Rinse thoroughly. Wash using hottest water safe for
fabric.
Some inks may be impossible to remove. Washing may set some inks. Use prewash stain remover, denatured alcohol or
nonflammable dry cleaning fluid.
Wash with chlorine bleach if safe for fabric. Or, soak in oxygen bleach and hot water before washing. Badly mildewed fabrics
may be permanently damaged.
Brush off dry mud. Pretreat or soak with product containing enzymes.
Pretreat with prewash stain remover. Wash using bleach safe for fabric.
May be impossible to remove. Place stain face down on paper towels. Apply nail polish remover to back of stain. Repeat,
replacing paper towels frequently. Do not use on acetate fabrics.
WATER BASED: Rinse fabric in cool water while stain is wet. Wash. Once paint is dry, it cannot be removed. OIL BASED AND
VARNISH: Use solvent recommended on can label. Rinse thoroughly before washing.
Use prewash stain remover or rub with bar soap. Rinse. Wash using nonchlorine bleach in hottest water safe for fabric.
For spots, use rust remover safe for fabric. For discoloration of an entire load, use detergent and nonchlorine bleach. Do not
use chlorine bleach because it may intensify discoloration.
LIQUID: Pretreat with a paste of granular detergent and water. PASTE: Scrape residue from fabric. Pretreat with prewash stain
remover or nonflammable dry cleaning fluid. Rinse. Rub detergent into dampened area. Wash using bleach safe for fabric.
Safe Stain Removal Procedures
To reduce the risk of fire or serious injury to persons or property,
comply with the basic warnings listed in Important Safety Instructions and those
listed below
• Read and comply with all instructions on stain removal products.
• Keep products in their original labeled containers and out of children's reach.
• Thoroughly wash any utensils used.
• Do not combine stain removal products, especially ammonia and chlorine
bleach. Dangerous fumes may result.
• Never wash items which have been previously cleaned in, washed in, soaked
in or spotted with gasoline, dry cleaning solvents or other flammable or
explosive substances because they give off vapors that could ignite or explode.
• Never use highly flammable solvents, such as gasoline, inside the home.
Vapors can explode on contact with flames or sparks.
For successful stain removal:
• Remove stains promptly.
• Determine the kind of stain, then follow recommended treatment in the stain
removal chart on the next page.
• To pretreat stains, use a prewash product, liquid detergent, or a paste made
from granular detergent and water.
• Use cold water on unknown stains because hot water can set some stains.
• Check label instructions for treatments to avoid on specific fabrics.
• Check for colorfastness by testing stain remover on an inside seam.
• Rinse and wash items after stain removal.
Stain Removal
Urine, vomit, mucus, feces
Pretreat or soak in product containing enzymes. Wash using bleach safe for fabric.
7
Common Washing Problems
Many washing problems involve poor soil and stain removal, residues of lint and scum, and fabric damage. For satisfactory washing
results, follow these suggestions provided by The Soap and Detergent Association.
PROBLEM
Blue stains
Discoloration,
graying
Greasy, oily stains
Holes, tears, or
snags
Lint
POSSIBLE CAUSES
•Detergent or liquid fabric softener
did not dissolve or disperse.
•Not enough detergent.
•Wash water temperature too low.
•Incorrect sorting.
•Not enough detergent.
•Undiluted liquid fabric softener
poured directly on fabric.
•Incorrect use of chlorine bleach.
•Unfastened zippers, hooks,
buckles.
•Rips, tears and broken threads.
•Overloading the washer.
•Degradation of fabric.
•Incorrect sorting.
•Tissues left in pocket.
•Overloading the washer.
•Not enough detergent.
•Undissolved detergent has left
residue.
•Static cling is attracting lint.
•Load washed too long.
SOLUTIONS
•If caused by detergent, mix 1 cup (240
ml) white vinegar with 1 quart (.95 L)
water in a plastic container. Soak item 1
hour. Rinse.
•If caused by fabric softener, rub stains
with bar soap. Wash.
•Rewash with correct amount of
detergent and hottest water safe for
fabric. Add bleach safe for fabric.
•Treat with prewash stain remover or
liquid detergent.
•Increase detergent and water
temperature. Rewash.
•Rub fabric softener stains with bar soap.
•May be irreversible if rips, tears and
seams cannot be mended.
•Reduce load size. Rewash using correct
water temperature, water level, and
amount of detergent.
•Add nonprecipitating water conditioner
to wash water.
•Add liquid fabric softener to final rinse.
•Dry load in dryer.
•Remove lint with lint brush or roller.
PREVENTIVE MEASURES
•Add detergent before wash load. Then
start washer.
•Add fabric softener to dispenser
(available on some models).
•Dilute fabric softener with water.
•Sort items by soil level and color.
•Use correct amount of detergent, hottest
water and bleach safe for fabric.
•Use correct cycle, amount of detergent
and hottest water safe for fabric.
•Do not pour liquid fabric softener
directly on fabric. See package
directions or Washing Procedures for
proper diluting.
•Never pour chlorine bleach directly on
fabric.
•Check condition of items before washing.
See Washing Procedures for preparing
and loading the wash load.
•See Washing Procedures for sorting
and preparing the wash load.
•Do not overload washer.
•Use correct amount of detergent, water
temperature and water level.
Pilling
(Fibers break off,
ball up and cling to
fabric)
Residue or powder
on dark items;
Stiff, harsh fabrics.
Wrinkling
Yellow buildup of
body soil on
synthetic fabrics
Yellow or brown
rust stains
•Pilling is normal with synthetic and
permanent press fabrics. This is
due to abrasion from normal
wear.
•Undissolved detergent.
•Some granular detergents can
combine with hard water minerals
to form a residue.
•Overloading the washer.
•Agitation time too short.
•Wash water temperature too low.
•Not enough detergent.
•Iron or manganese in water
supply, water pipes, or water
heater.
•Use a lint brush or shaver to remove pills.
•Reduce load size.
•Add dissolved detergent to tub . Rewash
load.
•Mix 1 cup (240 ml) white vinegar to 1
gallon (3.8 L) warm water in plastic
container. Soak item. Rinse and rewash.
•Reduce load size.
•Rinse in cold water with liquid fabric
softener.
•Soak in detergent booster or product
containing enzymes.
•Wash in hot water using permanent
press cycle. Increase detergent.
•Add bleach safe for fabric or, treat with
color remover.
•To restore discolored load of whites, use
rust remover safe for fabric.
DO NOT use chlorine bleach to
remove rust stains. It may intensify
discoloration.
•Use fabric softener in the washer to
lubricate fibers.
•When ironing, use spray starch or fabric
finish on collars and cuffs.
•Turn items inside out to reduce abrasion.
•Increase water temperature using hottest
water safe for fabric.
•Do not overload washer.
•Use liquid detergent or use nonprecipitating
water conditioner with granular detergent.
•Do not overload washer.
•Remove items from washer as soon as
cycle is completed.
•Use liquid fabric softener.
•Wash synthetics frequently using water at
least 100°F (37°C ) and correct water
level.
•Use nonprecipitating water softener.
•Before washing, run hot water for a few
minutes to clear lines.
•Drain water heater occasionally.
•For an ongoing problem, install an iron filter
in your water supply system.
8
Care and Cleaning
Use care with laundry
products. They can damage finish on
the washer.
To reduce the risk of fire or serious injury to persons or property,
comply with the basic warnings listed below in Important Safety Instructions and
those listed below.
Inside
• Remove items from the washer as soon as the cycle ends. Excess wrinkling, color
transfer, and odors may develop in items left in the washer.
• Dry the washer top, the area around the lid opening, and the underside of the
lid. These areas should always be dry before the lid is closed.
• Before cleaning the washer interior, unplug the electrical power cord to avoid
electrical shock hazards.
• When extremely soiled items have been washed, a dirty residue may remain on
the tub. Remove this by wiping the tub with a nonabrasive household cleanser.
Rinse thoroughly with water.
• The agitator or tub may become stained from fabric dye. Clean these parts with
a nonabrasive household cleanser. This prevents dye transfer to future loads.
Outside
• When washing is completed, wipe top and sides of washer with a damp cloth.
Turn water faucets off to prevent pressure build-up in the hoses.
Follow Winterizing
Instructions for cold
weather care.
• As needed, clean the cabinet with mild soap and water. Never use harsh,
gritty or abrasive cleansers. If top or lid becomes stained, clean with diluted
chlorine bleach [1/2 cup (120 ml) in 1 quart (.95 L) water]. Rinse several times
with clear water.
• Remove glue residue from tape or labels with a mixture of warm water and mild
detergent. Or, touch residue with the sticky side of the tape or label.
• Before moving the washer, place a strip of cardboard or thin fiberboard under
the front leveling legs to prevent floor damage.
Winterizing Instructions
If the washer is stored in an area where freezing can occur or moved in freezing
temperatures, follow these winterizing instructions to prevent damage to the washer:
1. Turn off water supply faucets.
2. Disconnect hoses from water supply and drain water from hoses.
3. Plug electrical cord into a properly grounded electrical outlet.
4. Add 1 gallon nontoxic recreational vehicle (RV) antifreeze to empty wash tub.
Close lid.
5. Set cycle selector knob at a spin setting. Pull out knob and let washer spin for
1 minute to drain out all water. Not all of the RV antifreeze will be expelled.
6. Push in knob, unplug electrical power cord, dry tub interior, and close lid.
7. Store washer in an upright position.
8. To remove antifreeze from washer after storage, run empty washer through a
complete cycle using detergent. Do not add wash load.
9
Avoid Service
Checklist
Before calling for service, review this list. It may save both time and expense. The list includes
common concerns that are not the result of defective workmanship or materials in this washer.
OCCURRENCE
NOISE
"Clunking" or gear
sounds.
Rattling and clanking
noise.
Squealing sound or hot
rubber odor.
Thumping sound.
Vibrating noise.
POSSIBLE CAUSE
A certain amount of "clunking" or gear
sounds are normal in a heavy-duty
washer.
Foreign objects such as coins or safety
pins may be in tub or pump.
Belt buckles and metal fasteners are
hitting wash tub.
Washer is overloaded.
Heavy wash loads may produce a
thumping sound.
Washer is not resting firmly on floor.
Shipping bolt and block have not been
removed during installation.
SOLUTION
This is normal.
Stop washer and check tub. If noise continues after
washer is restarted, objects may be in pump. Call your
authorized servicer.
To prevent unnecessary noise and damage to tub,
fasten fasteners and turn items inside out.
Do not overload washer. Stop washer and reduce
load.
This is usually normal. If sound continues, washer is
probably out of balance. Stop washer and redistribute
wash load.
Move washer so it rests firmly on floor. Adjust leveling
legs. See INSTALLATION INSTRUCTIONS for details.
See INSTALLATION INSTRUCTIONS for removing
shipping bolt and block.
OPERATING
Washer does not start.
Washer won't spin.
Wash load unevenly distributed in tub.
Washer lid is open.
Electrical power cord may not be plugged
in or connection may be loose.
House fuse blown, circuit breaker tripped,
or a power outage has occurred.
Water supply faucets are not turned on.
Cycle selector is not in correct position.
Motor is overheated.
Lid is not completely closed.
Stop washer and rearrange wash load.
Close washer lid.
The washer will not fill with water,
agitate or spin when the lid is open, and will only start
to do so if the lid is closed.
Make sure plug fits tightly in wall outlet.
Reset circuit breaker or replace fuse. Do not increase
fuse capacity. If problem is a circuit overload, have it
corrected by a qualified electrician. If problem is a
power outage, call local electric company.
Turn on water supply faucets.
Move indicator clockwise slightly. Pull out knob.
Washer motor will stop if it becomes overheated. It
will automatically restart after a cool down period of
up to 30 minutes (if washer has not been manually
turned off).
Close lid completely.
The washer will not fill with
water, agitate or spin when the lid is open, and will
only start to do so if the lid is closed.
Residue left in tub.
Heavily soiled items.
Wipe tub with a nonabrasive household cleanser, then
rinse. Shake or brush excess dirt and sand from items
before washing.
10
OCCURRENCE
WATER
Wash load too wet after
spin.
POSSIBLE CAUSE
Washer is overloaded.
SOLUTION
Do not overload washer. See Washing
Procedures.
Water does not enter
washer or it enters
slowly.
Water level does not
cover load.
Warm or hot water is not
hot enough.
Load is out of balance.
Drain hose is kinked.
Washer lid is open.
Water supply is not adequate in area.
Water supply faucets are not completely
open.
Water is being used elsewhere in the house.
Water inlet hoses are kinked.
Washer is overloaded.
Hot water heater is set too low or is a distance
from washer.
Rearrange load to allow proper spinning.
Straighten drain hose.
Close washer lid.
The washer will not fill with
water, agitate or spin when the lid is open, and
will only start to do so if the lid is closed.
Check another faucet in the house. Wait until
water supply and pressure increase.
Fully open hot and cold faucets.
Water pressure must be at least 30 psi (260 kPa).
Avoid running water elsewhere while washer is
filling.
Straighten hoses.
Do not overload washer. Dry load level should not
be higher than top of agitator vanes.
Measure hot water temperature at nearby faucet
with candy or meat thermometer. Water
temperature should be at least 120°F (50°C).
Adjust water heater as necessary.
Water in washer does
not drain or drains slowly.
Water leaks.
Incorrect wash and rinse
temperatures.
Water is entering washer
but tub does not fill.
Water is present in tub
after wash cycle is
complete.
The drain and spin cycles
did not occur.
Hot water is being used elsewhere in the
house.
To conserve energy, the temperature of the
hot wash is regulated.
Drain hose is kinked or clogged.
Loose fill hose connection at faucet or washer.
House drain pipes are clogged.
Oversudsing.
Hot and cold water hoses are connected to
wrong supply faucets.
Drain hose standpipe is incorrect height.
Lid lock malfunction.
Lid lock malfunction.
11
Avoid using hot water elsewhere before or during
washer use. There may not be enough hot water
available for proper cleaning. If problem persists,
your hot water system may be unable to support
more than 1 use at a time.
See Operating Instructions for your washer.
Clean and straighten the drain hose.
Check and tighten hose connections. Install rubber
sealing washers provided.
Unclog drain pipes. Contact plumber if necessary.
Use less detergent.
Connect hot water hose to hot water faucet and
cold water hose to cold water faucet.
Standpipe must be a minimum of 33" (83.82 cm)
high to prevent siphoning. See INSTALLATION
INSTRUCTIONS.
Do not bypass lid lock. Call your authorized
servicer.
Do not bypass lid lock. Call your authorized
servicer.
Major Appliance Warranty Information
Your appliance is covered by a one year limited warranty. For one year from your original date of
purchase, Electrolux will pay all costs for repairing or replacing any parts of this appliance that prove to
be defective in materials or workmanship when such appliance is installed, used and maintained in
accordance with the provided instructions.
Exclusions
This warranty does not cover the following:
1. Products with original serial numbers that have been removed, altered or cannot be readily determined.
2. Product that has been transferred from its original owner to another party or removed outside the USA or
Canada.
3. Rust on the interior or exterior of the unit.
4. Products purchased "as-is" are not covered by this warranty.
5. Food loss due to any refrigerator or freezer failures.
6. Products used in a commercial setting.
7. Service calls which do not involve malfunction or defects in materials or workmanship, or for appliances
not in ordinary household use or used other than in accordance with the provided instructions.
8. Service calls to correct the installation of your appliance or to instruct you how to use your appliance.
9. Expenses for making the appliance accessible for servicing, such as removal of trim, cupboards, shelves,
etc.,which are not a part of the appliance when it is shipped from the factory.
10. Service calls to repair or replace appliance light bulbs, air filters, water filters, other consumables, or
knobs, handles, or other cosmetic parts.
11. Surcharges including, but not limited to, any after hour, weekend, or holiday service calls, tolls, ferry trip
charges, or mileage expense for service calls to remote areas, including the state of Alaska.
12. Damages to the finish of appliance or home incurred during installation, including but not limited to floors,
cabinets, walls, etc.
13. Damages caused by: services performed by unauthorized service companies; use of parts other than
genuine Electrolux parts or parts obtained from persons other than authorized service companies; or
external causes such as abuse, misuse, inadequate power supply, accidents, fires, or acts of God.
DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES
CUSTOMER’S SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE PRODUCT
REPAIR OR REPLACEMENT AS PROVIDED HEREIN. CLAIMS BASED ON IMPLIED WARRANTIES,
INCLUDING WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE
LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW, BUT NOT LESS THAN ONE YEAR.
ELECTROLUX SHALL NOT BE LIABLE FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH AS
PROPERTY DAMAGE AND INCIDENTAL EXPENSES RESULTING FROM ANY BREACH OF THIS WRITTEN
LIMITED WARRANTY OR ANY IMPLIED WARRANTY. SOME STATES AND PROVINCES DO NOT ALLOW THE
EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, OR LIMITATIONS ON THE
DURATION OF IMPLIED WARRANTIES, SO THESE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO
YOU. THIS WRITTEN WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER
RIGHTS THAT VARY FROM STATE TO STATE.
If Y
ou Need
Service
This warranty only applies in the USA and Canada. In the USA, your appliance is warranted by Electrolux Major Appliances
North
America, a division of Electrolux Home Products, Inc. In Canada, your appliance is warranted by Electrolux Canada
Corp. Electrolux authorizes no person to change or add to any obligations under this warranty. Obligations for service and
parts under this warranty must be performed by Electrolux or an authorized service company. Product features or
specifications as described or illustrated are subject to change without notice.
USA
1.800.944.9044
Electrolux Major Appliances
North America
P.O. Box 212378
Augusta, GA 30907
Keep your receipt, delivery slip, or some other appropriate payment record to establish the warranty period
should service be required. If service is performed, it is in your best interest to obtain and keep all receipts.
Service under this warranty must be obtained by contacting Electrolux at the addresses or phone
numbers below.
Canada
1.800.668.4606
Electrolux Canada Corp.
5855 Terry Fox Way
Mississauga, Ontario, Canada
L5V 3E4
Loading...
