Page 1

All about the

Use & Care

of your

www.frigidaire.com USA 1-800-944-9044 www.frigidaire.ca Canada 1-800-265-8352

Wall Oven

Product Record and Registration . . . . . . . . . . . . . . 2

Important Safety Instructions . . . . . . . . . . . . . . . . . 3

Before Setting Oven Controls . . . . . . . . . . . . . . . . . 8

Setting Oven Controls . . . . . . . . . . . . . . . . . . . . . . 10

TABLE OF CONTENTS

Care and Cleaning . . . . . . . . . . . . . . . . . . . . . . . . 26

Before You Call . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

A00538201 Rev C (April 2018)

Page 2

PRODUCT RECORD AND REGISTRATION

Need Help? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Product Registration . . . . . . . . . . . . . . . . . . . . . . . . . .2

Product Record and Registration . . . . . . . . . . . . . . . . . 2

Important Safety Instructions . . . . . . . . . . . . . . . . . . . . 3

Before Setting Oven Controls . . . . . . . . . . . . . . . . . . . . 8

Setting Oven Controls . . . . . . . . . . . . . . . . . . . . . . . . . 10

Care and Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Before You Call. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Need Help?

Visit the Frigidaire web site at www.frigidaire.com

Before you call for service, there are a few things you can do to help us serve you better.

Read this Use & Care Manual

This manual contains instructions to help you use and maintain your oven properly.

If You Received a Damaged Oven...

Immediately contact the dealer (or builder) that sold you the oven.

Save Time and Money

Check “Solutions to Common Problems” on page 32. This section helps step you through some common problems that might occur.

If you do need service, help is only a phone call away. Call Frigidaire customer services at 1-800-944-9044.

Questions?

For toll-free telephone support in the U.S. and Canada call

1-800-944-9044 For online support and product information visit http://

www.frigidaire.com. Thank you for choosing Frigidaire.

This Use & Care manual is part of our commitment to customer satisfaction and product quality throughout the service life of your new appliance. We view your purchase as the beginning of a relationship. To ensure our ability to continue serving you, please use this page to record important product information.

Product Registration

Registering your product with Frigidaire enhances our ability to serve you. You can register online at http:// www.frigidaire.com or by dropping your product registra tion card in the mail.

Record model and serial numbers here

Purchase Date: _______________________________ Frigidaire model number: _______________________ Frigidaire serial number: ________________________

Serial Plate Location

Page 3

WARNING

CAUTION

IMPORTANT

NOTE

IMPORTANT SAFETY INSTRUCTIONS

Read all instructions before using this appliance. This manual contains important safety symbols

and instructions. Please pay attention to these symbols and follow all instructions given.

Do not attempt to install or operate your appliance until you have read the safety precautions in this manual. Safety items throughout this manual are labeled with a WARNING or CAUTION statement based on the risk type.

Warnings and important instructions appearing in this guide are not meant to cover all possible conditions and situations that may occur. Common sense, caution, and care must be exercised with installing, maintaining, or operating your appliance.

DEFINITIONS

This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.

Indicates a potentially hazardous situation which, if not avoided, may result in death or serious injury.

WARNING

Tip Over Hazard

• A child or adult can tip the oven and be killed.

• Install the anti-tip device to oven and/or structure per

• Ensure the anti-tip device is re-engaged when the oven is moved.

• Do not operate the oven without the anti-tip device in place and engaged.

• Failure to follow these instructions can result in death or serious burns to children and adults.

Anti-tip mounting holes

installation instructions.

Refer to the installation instructions supplied with your appliance for proper installation.

Check for proper installation with a visual check that the anti-tip screws are present. Test the installation with light downward pressure on the open oven door. The oven should not tip forward.

Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.

Indicates installation, operation, maintenance,

or valuable information that is not hazard related.

Indicates a short, informal reference – something written down to assist the memory or for future reference.

Page 4

IMPORTANT SAFETY INSTRUCTIONS

WARNING

IMPORTANT INSTRUCTIONS FOR UNPACKING AND INSTALLATION

IMPORTANT - Read and follow the below instructions and precautions for unpacking, installing, and servicing your appliance:

Remove all tape and packaging before using the appliance. Destroy the carton and plastic bags after unpacking the appliance. Never allow children to play with packaging material. Do not remove the wiring label and other literature attached to the appliance. Do not remove model/ serial number plate.

Cold temperatures can damage the electronic control. When using this appliance for the first time, or when the appliance has not been used for an extended period of time, be sure the appliance has been in temperatures above 32ºF (0ºC) for at least 3 hours before turning on the power to the appliance.

Never modify or alter the construction of the appliance by removing the leveling legs, panels, wire covers, anti-tip brackets/screws, or any other part of the appliance.

Be sure to have an appropriate foam-type fire extinguisher available, visible, and easily accessible located near the appliance.

GROUNDING INSTRUCTIONS

Proper Installation—Be sure your appliance is properly installed and grounded by a qualified technician. In the United States, install in accordance with the National Fuel Gas Code ANSI Z223.1/NPFA No. 54, latest edition and National Electrical Code NFPA No. 70 latest edition, and local electrical code requirements. In Canada, install in accordance with CAN/CGA B149.1 and CAN/CGA B149.2 and CSA Standard C22.1, Canadian Electrical code, Part 1-latest editions and local electrical code requirements. Install only per installation instructions provided in the literature package for this appliance.

For personal safety, this appliance must be properly grounded. For maximum safety, the power cord must be securely connected to an electrical outlet or junction box that is the correct voltage, is correctly polarized and properly grounded, and protected by a circuit breaker in accordance with local codes.

It is the personal responsibility of the consumer to have the appropriate outlet or junction box with the correct, properly grounded wall receptacle installed by a qualified electrician. It is the responsibility and obligation of the consumer to contact a qualified installer to assure that the electrical installation is adequate and is in conformance with all local codes and ordinances.

See the installation instructions packaged with this appliance for complete installation and grounding instructions.

Avoid fire hazard or electrical shock. Failure to follow this warning may cause serious injury, fire, or death.

Avoid fire hazard or electrical shock. Do not use an adapter plug, use an extension cord, or remove grounding prong from the power cord. Failure to follow this warning may cause serious injury, fire, or death.

Page 5

IMPORTANT SAFETY INSTRUCTIONS

WARNING

CAUTION

IMPORTANT INSTRUCTIONS FOR USING THE APPLIANCE

Storage In or On Appliance—Flammable

materials should not be stored in an oven or microwave, near surface burners or elements, or in the storage or warmer drawer (if equipped). This includes paper, plastic, and cloth items, such as cookbooks, plastic ware, and towels, as well as flammable liquids. Do not store explosives, such as aerosol cans, on or near the appliance.

Do not leave children alone - Children should not be left alone or unattended in the area where appliance is in use. They should never be allowed to sit or stand on any part of the appliance, including the storage drawer, lower broiler drawer , warmer drawer, or lower double oven.

Do not store items of interest to children in the cabinets above the appliance or on the backguards of ranges. Children climbing on or near the appliance to reach items could be seriously injured.

Do not allow children to climb or play around the appliance. The weight of a child on an open over door may cause the appliance to tip, resulting in serious burns or other injury. An open drawer when hot may cause burns.

Stepping, leaning, or sitting on the door or drawers of this appliance can result in serious injuries and also cause damage to the appliance.

Never cover any slots, holes, or passages in the oven bottom or cover an entire oven rack with any materials, such as aluminum foil or aftermarket oven liners. Doing so blocks air flow through the oven and may couase carbon monoxide poisoning. Aluminum foil and other liners may trap heat, causing a fire hazard.

Do not use oven or warmer drawer (if equipped) for storage.

Never use your appliance as a space heater to heat or warm the room. Doing so may result in carbon monoxide poisoning and overheating of the appliance.

When heating fat or grease, watch it closely. Grease may catch fire if it becomes too hot.

Do not use water or flour on grease fires. Smother fire or flame or use dry chemical or foam-type extinguisher. Cover the fire with a pan lid or use baking soda.

Use dry potholders. Moist or damp potholders on hot surfaces may result in burns from steam. Do not let potholders touch hot cooking areas. Do not use towels or other bulky cloths.

Do not heat unopened food containers - Buildup of pressure may cause container to burst and result in injury.

Wear proper apparel - Loose-fitting or hanging garments should never be worn while using the appliance. Do not let clothing or other flammable materials contact hot surfaces.

Do not touch surface burners or elements, areas near these burners or elements, interior surfaces of the oven, or the warmer drawer (if equipped). Surface burners and elements may be hot even though they appear cool. Areas near surface burners and elements may become hot enough to cause burns. During and after use, do not touch, or let clothing or other flammable materials touch these areas until they are cool. These areas may include the cooktop, surfaces facing the cooktop, oven vent areas, oven door, and oven window.

Page 6

IMPORTANT SAFETY INSTRUCTIONS

CAUTION

Do not use a broiler pan without its insert. Broiler pans and inserts allow dripping fat to drain away from the high heat of the broiler. Do not cover the

Do not attempt to operate the appliance during a power failure. If the power fails, always turn off the appliance. If the appliance is not turned off and the power resumes, electric surface elements may resume operation when power is restored. Once the power resumes, reset the clock and the oven function.

IIMPORTANT INSTRUCTIONS FOR USING YOUR OVEN

Protective liners—Do not use aluminum foil, aftermarket oven liners, or any other materials or devices to line oven bottom, oven racks, or any other part of the appliance. Only use aluminum as recommended for baking, such as lining cookware or as a cover placed on food. Any other use of protective liners or aluminum foil may result in a risk of electric shock or fire or a short circuit.

Use care when opening oven door, lower oven door, or warmer drawer (some models). Stand to the side of the appliance when opening the door of a hot oven. Let hot air or steam escape before you remove or replace food in the oven.

Keep oven vent ducts unobstructed. Touching surfaces in this area when the oven is on may cause severe burns. Do not place plastic or heatsensitive items on or near the oven vent. These items can melt or ignite.

broiler insert with aluminum foil; exposed fat and grease could ignite.

Do not cook food on the oven bottom. Always cook in proper cookware and always use the oven racks.

IMPORTANT INSTRUCTIONS FOR CLEANING YOUR APPLIANCE

Clean the appliance regularly to keep all parts free of grease that could catch fire. Do not allow grease to accumulate. Greasy deposits in the fan could catch fire.

Always follow the manufacturer’s recommended directions for use of kitchen cleaners and aerosols. Be aware that excess residue from cleaners and aerosols may ignite causing damage and injury.

Clean ventilating hoods frequently - Grease should not be allowed to accumulate on hood or filter. Follow the manufacturer’s instructions for cleaning vent hoods.

Before manually cleaning any part of the appliance, be sure all controls are turned off and the appliance is cool. Cleaning a hot appliance can cause burns.

Placement of oven racks - Always place oven racks in desired location while oven is cool. If rack must be moved while oven is hot, do not let potholder contact hot burner or element in oven. Use potholders and grasp the rack with both hands to reposition. Remove all cookware and utensils before moving the rack.

Page 7

IMPORTANT SAFETY INSTRUCTIONS

IMPORTANT INSTRUCTIONS FOR SELF CLEANING OVENS

Do not clean the oven door gasket. The door gasket is essential for a good seal. Care should be taken not to rub, damage, or move the gasket.

Do not use oven cleaners. No commercial oven cleaner or oven liner protective coating of any kind should be used in or around any part of the appliance.

Use the self clean cycle to clean only the parts listed in this manual.

Before using self clean, remove the broiler pan, any food, utensils, and cookware from the oven, storage drawer or warming drawer (if equipped). Remove oven racks unless otherwise instructed.

Some birds are extremely sensitive to the fumes given off during the self clean cycle of any oven. Move birds to another well-ventilated room.

Do not touch a hot oven light bulb with a damp cloth. Doing so could cause the bulb to break. Handle halogen lights (if equipped) with paper towels or soft gloves. Disconnect the appliance or shut off the power to the appliance before removing and replacing the bulb.

Important Safety Notice - The California Safe Drinking Water and Toxic Enforcement Act requires the governor of California to publish a list of substances known to cause cancer, birth defects, or other reproductive harms, and requires businesses to warn customers of potential exposures to such substances.

IMPORTANT INSTRUCTIONS FOR SERVICE AND MAINTENANCE

Do not repair or replace any part of the appliance unless specifically recommended in the manuals. All other servicing should be done only by a qualified technician. This reduces the risk of personal injury and damage to the appliance.

Always contact your dealer, distributor, service agent, or manufacturer about problems or conditions you do not understand.

Ask your dealer to recommend a qualified technician and an authorized repair service. Know how to disconnect the power to the appliance at the circuit breaker or fuse box in case of an emergency.

Remove the oven door from any unused oven if it is to be stored or discarded.

Page 8

oven vent location

OVEN DISPLAY

CAUTION

WARNING

IMPORTANT

Glide Rack

BEFORE SETTING OVEN CONTROLS

Oven Vent Location

The oven is vented as shown below. When the oven is on, warm air is released through the vent. This venting is necessary for proper air circulation in the oven and good baking results. Do not block oven vent. Never close off the openings with aluminium foil or any other material. S team or moisture may appear near the oven vent. This is normal.

Figure 1: Do not block oven vent

Always use pot holders or oven mitts when using the oven. When cooking, the oven interior and exterior, oven racks, and cooktop will become very hot which can cause burns.

Protective Liners — Do not use aluminum foil or any oth er material to line the oven bottom. Only use aluminum foil as recommended in this manual. Improper installation of these liners may result in risk of electric shock or fire.

Types of oven racks

at handle oven rack

oset oven rack

Oven Rack Descriptions

• Flat oven racks (or the flat handle oven rack) may be

used for most cooking needs and may be placed in most oven rack positions.

• The offset oven rack (some models) provides additional step down positions from the standard flat rack design. The offset design positions the base of the rack about ½ of a rack position lower than the flat rack and may be used in most oven rack positions.

• The fully extendable oven glide rack allows you to effortlessly extend your food away from the oven.

Removing, replacing, and arranging flat or offset oven racks

All oven racks should be removed before a clean operation. Racks left in the oven during the high heat of the clean function can easily discolor. The ability of the racks to easily slide in and out along the rack positions may also be affected. Remove all oven racks and clean according to instructions provided in the Care & Cleaning section of this manual. Never pick up hot oven rack s or parts.

T o arrange - Always arrange the oven racks when the oven

is cool (prior to operating the oven). To remove - Pull the oven rack straight forward until it

reaches the stop position. Lift up front of oven rack slightly and slide out.

To replace - Place the oven rack on the rack guides on both sides of oven walls. Tilt the front of oven rack upward slightly and slide the oven rack back into place. Be sure oven racks are level before using.

Page 9

Removing and Replacing the Glide Racks

IMPORTANT

The fully extendable Glide rack makes food preparation easier. This oven rack has glide tracks that allow the rack to be pulled away from the oven without rubbing the sides of the oven wall.

To remove - Using one hand, reach through handle opening and lift up on the release lever located across the lower front of the rack as shown in

Figure 2: Grasp handle and lift up on bar

While holding up the release lever, pull the glide rack out of the oven until the stop position is reached (

Figure 2.

Figure 3)

BEFORE SETTING OVEN CONTROLS

Figure 4: Remove and replace using both hands

The rack portions move independently an d are difficult to handle unless held together.

To replace - Grasp both upper and lower portions of glide rack, lift and hold the rack level between the oven cavity walls. Tilt the front of the rack upward slightly and slide the rack completely into position.

Important: To prevent possible damage to the oven, do not attempt to close the oven door until all the oven racks are fully positioned back inside the oven cavity.

Figure 3: Pull rack to stop position

Using both hands, grasp the upper and lower por tions of the glide rack. Lift up the front of the rack slightly and continue to pull the rack away from the oven ( grasp both upper and lower rack portions together when removing or handling the glide rack.

Figure 4). Be sure to

Do not line the oven walls, racks, bottom or any other parts of the oven with aluminum foil or with any other materials or oven liners. Doing so will alter heat distribu tion and may cause permanent damage to the oven interior. During clean the oven temperatures will be hot enough to melt foil.

Page 10

OVEN DISPLAY

PREHEAT

SETTING OVEN CONTROLS

OVEN MODE SETTINGS

NO PREHEAT - Use no preheat for single rack items only

and place food in center of oven before setting temper ature. BAKE - Use to select bake function before setting tempera-

ture. CLEAN - Use to select clean feature cycle before setting

clean with oven temperature selector. CONV BAKE - Use to select convection baking before

setting oven temperature. CONV ROAST - Use to select convection roast for beef,

lamb, pork, and poultry before setting oven temperature. BROIL - Use to set broil feature before setting broil with

oven temperature selector. KEEP WARM - Set BAKE, CONV BAKE, or CONV ROAST

mode, then set keep warm with oven temperature selector. Keep warm provides a low heat for keeping cooked foods at serving temperature.

OVEN DISPLAY FEATURES

1. Oven light - Use to turn on the internal oven light.

2. Clock - Use to set the time of day.

3. TIMER - Use to set or cancel the minute timer. The

minute timer does not start or stop any cooking function.

OVEN TEMP SETTINGS

Before setting the oven, both the mode and temp knobs should be set to OFF. Set both mode and temp knobs to OFF when finished cooking.

Use to set oven temperatures between 170°F (KEEP WARM) and 550°F. The CLEAN setting should only be used after reading all cautions and warnings in the

“Self

Cleaning” sections of this manual starting on page 23.

Oven Minimum and Maximum Control Settings

Feature Min. Temp/Time Max. Temp/Time BAKE 170°F (77°C)

(KEEP WARM) NO PREHEAT 200°F (93°C) 550°F (288°C) CONV BAKE 170°F (77°C)

(KEEP WARM) CONV ROAST 170°F (77°C)

(KEEP WARM) MEAT PROBE 140°F (60°C) 210°F (99°C) BROIL 550°F (288°C) TIMER 0:01 Hr 11:59 CLOCK (12hr) 1:00 Hr 12:59 Hr

550°F (288°C)

User Preference Settings

The default (factory) settings for sounds, energy saving, temperature offset, and convection convert are pre-set in the oven control. These may be changed by accessing the user preference display while the oven is in the idle mode and no timers are active. Once the user preference menu is activated, the user can make changes and scroll through a menu of options, choosing from AUd (audible control setting), ES (energy saving), UPO (User Programmable Offset for changing the oven temperature), Aut (automatic convection convert), and dEF (default) setting with rSt reset choice (which will allow all preferences to reset to default settings).

Page 11

SETTING OVEN CONTROLS

NOTE

Setting the Clock

The clock icon is used to access the time of day setting. When the oven is first plugged in or if there has been an interruption in power to the oven, 12:00 will flash in the display.

To set the correct time of day:

1. Press the clock icon.

2. The display will show a time along with a – and a + key

in the display below.

3. Press either – or + key to scroll to the correct time of

day and release the key.

4. The control will accept the new set time with a chime, and the control will show the time of day along with the two timers that are available.

The clock cannot be changed when the oven is set for cooking or self clean is active. Only a 12 hour clock is available on the Frigidaire Professional model.

Oven Light

The oven light will turn on automatically when the oven door is opened. The oven light may be turned on when the door is closed by using the oven light key located on the control panel.

Note: Keep oven light off while baking. The oven light will turn off during a clean cycle and not operate.

To toggle the oven lights on and off:

1. Press oven light symbol .

The interior oven light is covered with a glass shield. The glass shield must be in place whenever the oven is in use.

T o change the interior oven lights, see ““Replacing the Oven

Light” in the Care & Cleaning section.

Setting the Timer

The minute timers in the oven display serve as extra timers to help keep track of cooking functions. The timer cannot be used during a self clean cycle or if the meat probe function associated with the timer display is in use. The minimum timer setting is 1 minute and the maximum setting is 11:59 (HR:MIN).

To set the timer:

1. Press either TIMER key.

2. The timer display will show 0:00 and the – and + keys

on either side of the time display. NOTE: If the pressed at this time an invalid key chime will sound.

3. Press the + key to begin to scroll to the desired setting.

If the

+ key is held, the timer value will increase rapidly.

Once the desired setting is reached, release the key and the timer will start counting down automatically after a short time-out.

4. The timer display will show the H:M icon if the timer is set for more than 1 minute. If the value is under 1 minute, the timer will display the time in seconds and the H:M icon will not appear.

5. When the timer ends, a reminder chime will sound and repeat once every 60 seconds for a period of five minutes. Before the user can program an expired timer again, the timer key must be pressed.

6. To cancel the timer before the set time expires, press the TIMER key.

The minute timers will not start or stop the cooking process. The minute timers can be used alone or while using most of the other oven features.

– key is

Page 12

SETTING OVEN CONTROLS

Setting Continuous Bake or 6 Hour Energy Saving

The oven is preset to cook up to 6 hours and to shut off automatically. For longer periods of cooking, this feature can be changed to continuous cooking by setting the user preference and turning the energy saving feature off.

To set the oven for continuous cooking:

1. Press and hold both the light icon and th e clock icon at

the same time for a few seconds until the display sounds an acceptance chime and the display will show one of the user preferences.

2. Press the + key in the upper part of the display until ES

appears and ON is showing.

Setting Control for Silent Operation

The oven is set to operate with certain chimes and tones (default settings) that alert the user to certain oven functions. The silent operation feature allows the oven control to be operated without sounds when necessary. By accessing user preferences, this option can be later returned to operate with normal programming sounds.

To set the oven control for silent operation:

1. Press and hold both the light icon and the clock icon at

the same time for a few seconds until the display sounds an acceptance chime. AUd should appear in the display.

2. If Aud is not showing, press the + key in the upper part of the display until AUd appears and HI is showing in the lower part of the display. This is the normal (default) setting.

Figure 1: Energy saving with ON and OFF options

3. To turn the energy saving feature off, press the + or –

key in the lower part of the display and OFF will appear in the display.

4. The control will accept the change in a few seconds and sound the acceptance chime. The oven is now set for continuous cooking.

5. To return to the time of day display, press and hold the light and clock icons at the same time for a few

seconds until the display chimes and fades back to showing the time of day in the display.

Figure 2: Default setting for oven control sounds

3. To turn the audible feature to a lower sound or

completely OFF, press the of the display until LO or OFF appears in the display.

Figure 3:

4. When the desired setting appears in the display , release

the key and wait for an acceptance chime.

5. To return to the time of day display, press and hold both the light and clock icons at the same time for a few seconds until the display chimes and fades back to showing the time of day.

+ or – key in the lower part

Page 13

Setting No Preheat

CAUTION

3 2

Use the No Preheat feature when you want to start baking immediately, without the need for preheating. No Preheat provides good results when preparing convenience foods such as cinnamon rolls, frozen pizza, bacon, french fries, and tater tots. Food will finish cooking in the time stated in the package directions without the extra time required for preheating.

During No Preheat the convection fan will pulse on and off, and the bake element will cycle on and off to maintain the set temperature for precise baking.

Important: For batter and dough-based baked goods such as cakes, pastries, and breads, use the convection function for best results.

No Preheat is designed for baking on a single rack placed in the center of the oven and may be set for any tempera ture from 200°F to 550°F.

No Preheat tips for best results:

SETTING OVEN CONTROLS

Always use potholders or oven mitts when using the oven. When cooking, the oven interior will become hot and could cause burns.

To set No Preheat:

1. Remove food from packaging and arrange on baking

pan.

2. Place pan in oven on rack position 3 and close oven door.

3. Turn the oven mode selector to No Preheat.

4. Turn the oven temperature selector to the desired

temperature. Baking will begin immediately.

5. To stop baking turn the oven mode selector and oven temperature selector to the OFF positions.

• Always place the food in the center of the oven on rack position 3 ( on a single oven rack.

• When using No Preheat, use bakeware with low or no sides. This allows the air to circulate around the food evenly.

• Food that comes in strips, such as fish sticks and chicken tenders, should be placed on the pan with the ends pointing to the sides of the oven.

• Follow the package directions for food preparation time and temperature. No Preheat works best when cooking foods longer than 10 minutes. If directions call for a shorter cooking time, a few extra minutes may be required for optimal cooking results.

• Do not open the oven door often. Opening the door will reduce the temperature in the oven and may increase bake time.

Figure 4). No Preheat is designed for baking

Figure 4: Use rack position 3 for No Preheat baking

Page 14

SETTING OVEN CONTROLS

Setting Bake

Use the Bake function whenever a recipe calls for baking using normal temperatures. When the set bake temperature is reached the control will sound a chime to alert that the oven is fully preheated. During Bake, the convection fan may pulse on and off to help maintain optimum bakin g temperatures.

Important: For batter and dough-based baked goods such as cakes, pastries, and breads, use the convection function for best results.

Baking tips For best bake results:

• Leave the oven light off while baking.

• Fully preheat the oven before baking items like cookies,

cakes, biscuits, and breads.

• When using any single rack, position the rack so that the food is in the center of the oven.

• When using two oven racks, position cookware as shown in of space between cookware for proper air circula tio n.

Figure 5. Allow at least 2-4 inches (5-10 cm)

To set a bake for 350°F:

1. Be sure to arrange racks to the desired positions.

2. Turn the oven mode selector to the Bake position.

3. Turn the oven temperature selector to 350°F.

4. The PREHEAT and the oven temperature light will turn

on and sound an acceptance tone. The oven will begin heating.

5. When the set temperature is reached the PREHEAT light will turn off and a reminder chime will sound alerting you to place food in oven.

6. Set either timer to keep track of actual cooking time if necessary.

7. When finished baking, be sure to return both the temperature selector knob an d th e ove n mod e kno b to the OFF positions.

• For best results when baking cakes using two oven racks, place Glide rack in position 4 with the flat rack in position 1. (See

• For cookies on multiple racks place sheets on rack position 3 using the flat rack, and 5 with the glide rack.

• Dark or dull bakeware absorbs more heat than shiny bakeware. It may be necessary to reduce oven temper ature and cook time to prevent overbrowning of some foods. Dark bakeware is recommended for pies. Shiny bakeware is recommended for cakes, cookies, and muffins.

• Do not open the oven door often. Doing may increase the cooking time necessary for best results.

• Many factors can affect baking results. See “Solutions

to Common Problems” on page 32 of this owner’s

manual.

Figure 6).

Figure 5: Pan spacing on multiple racks

Figure 6: Use rack positions 1 and 5 for multiple rack baking

Page 15

SETTING OVEN CONTROLS

3 2

Convection Baking

Convection baking enables you to obtain the best results when baking with multiple pans and racks. The oven ca n be programmed for convection baking at any temperature between 170°F to 550°F. The convection function uses a fan to circulate the oven heat uniformly an d co ntinuously around the oven ( allows for fast, even cooking and browning results.

Benefits of convection cooking:

• Multiple rack baking.

• Some foods may cook faster, saving time and energy. Convection baking tips:

• Because most food items will cook faster and more

evenly with the convection feature, it is advisable to reduce recipe’s recommended temperature by 25° for best results. Follow the recipe’s instructions using the minimum recommended cook time.

• Fully preheat the oven before baking items like cookies, cakes, biscuits, and breads. For single rack baking, position the rack so that food is in the center of the oven.

• If your recipe cooking temperature has already been converted for convection baking, there is no need to reduce your oven temperature. If not, see “Setting

Convection Convert” on page 15 for further instructions

on temperature conversion.

• When baking cakes using two oven racks, place Glide rack in position 4 with the flat rack in position 1. (See

Figure 7).

Figure 7). This improved heat distribution

Setting Convection Bake

To set the oven for convection bake and temperature to 375°F:

1. Arrange interior oven racks.

2. Turn the oven mode selector to CONV BAKE.

3. Turn the oven temperature selector to 375°F.

4. The oven temperature light will blink for a few seconds

before sounding a chime confirming the setting. The convection fan will turn on and the oven will begin heating. Once the oven reaches the set temperatur e the oven will sound a chime indicating the food items can be placed in the oven. At times, the convection fan may pulse on and off in order to maintain optimum baking temperature.

5. When finished baking, be sure to return both the temperature selector knob and the oven mode knob to the OFF positions.

Figure 7: Convection air flow

• For cookies on multiple racks place sheets on rack

positions 3 with flat rack, and 5 with glide rack.

• When baking using two oven racks, position cookware as shown in

Figure 8. Allow at least 2 inches (5 cm) of

space between cookware for proper air circulation.

• Dark or dull bakeware absorbs more heat than shiny bakeware. It may be necessary to reduce oven temper ature and cook time to prevent overbrowning of some foods. Dark bakeware is recommended for pies. Shin y bakeware is recommended for cakes, cookies, and muffins.

• Do not open oven door too often. Doing so reduces oven temperature and may extend cooking time.

• Most baked goods (except cakes) should be baked on pans with no sides or low sides to allow air to circulate.

Figure 8: Pan spacing suggestion

Page 16

SETTING OVEN CONTROLS

Setting Convection Convert

Convection convert automatically converts a standard baking recipe for convection baking. Convection convert may only be used with convection bake.This feature must be set before selecting the oven mode and oven tempera ture by using the user preference setting in the oven display.

Because convection baking generally cooks food faster than normal baking, food items should be checked for doneness before the suggested normal recipe cook times.

To set convection convert:

1. The oven temperature selector must be in the OFF

position.

2. Turn the oven mode selector to CONV BAKE.

3. Press and hold both the oven light key and the clock

key for about 3 seconds until Aut° (automatic convec tion convert) appears in the display.

Setting Convection Roast

Convection roast is best for cooking tender cuts of beef, lamb, pork, and poultry. Use this mode when cooking speed is desired. Convection roasting gently browns the exterior

and seals in the juices. Convection roasting uses the bake element, convection element, broil element, and fan to circulate the heat evenly and continuously within the oven.

Convection roasting tips:

• Use a broiler pan and grid, as well as a roasting rack

(available by mail order). The broiler pan will catch grease drippings, and the grid will help prevent spatters. The roasting rack will hold the meat. Make sure the roasting rack is securely seated on the grid in the broiler pan. Do not use the broiler p an without the grid or cover the grid with aluminum foil.

• Pull the rack out to the stop position before removing

food. Position food (fat side up) on the roasting rack.

• Do not open the oven door often. Doing so will reduce the temperature in the oven and may increase the cooking time necessary for best results.

• It is not recommended to roast chicken on a roasting rack. Use a deep pan and place on rack position 1 (offset rack).

Figure 9: Convection convert off (L) and on (R)

4. Press either the – or + key until On appears.

5. Turn the oven mode selector to the OFF position. The

oven will accept the convection convert setting with an acceptance chime and the control will return to display the time of day . The convection bake function will now automatically convert normal baking temperatures for convection baking.

To change back to regular convection baking, repeat the same steps in this process and press the + or - key until OFF appears. Once the control accepts the change with a chime, turn the oven mode selector to OFF.

To set oven for convection roasting:

1. Place meat on roasting rack and place in oven.

2. Turn oven mode selector to CONV ROAST.

3. Turn oven temperature selector to desired roasting

temperature.

4. Once the control accepts the setting, the convection fan turns on and the oven will heat to the set temperature.

5. To cancel convection roast at any time, turn both the temperature control and the oven mode control to the OFF position.

Note: Preheating the oven for convection roasting is not necessary. At this time you may want to set TIMER as a reminder for checking food.

Page 17

SETTING OVEN CONTROLS

Roasting rack

Insert

Broil pan

CAUTION

WARNING

Table 1: Convection roasting temperature and time rec ommendations

Meat Weight Oven Temp Internal Temp Minutes per lb.

Beef Standing rib roast* 4 to 6 lb. 350°F (177ºC) *160ºF (71ºC) 25-30

Rib eye roast* 4 to 6 lb. 350°F (177ºC) *160ºF (71ºC) 25-30 Tenderloin roast 2 to 3 lb. 400°F (204ºC) *160ºF (71ºC) 15-25

Poultry Turkey whole** 12 to 16 lb. 325°F (163ºC) 180°F (82ºC) 8-10

Turkey whole** 16 to 20 lb 325°F (163ºC) 180°F (82ºC) 10-15 Turkey whole** 20 to 24 lb. 325°F (163ºC) 180°F (82ºC) 12-16 Chicken 3 to 4 lb. 350°F-375°F (177ºC-191ºC) 180°F (82ºC) 12-16

Pork Ham roast, fresh 4 to 6 lb. 325°F (163ºC) 160°F (71ºC) 30-40

Shoulder blade roast 4 to 6 lb. 325°F (163ºC) 160°F (71ºC) 20-30 Loin 3 to 4 lb. 325°F (163ºC) 160°F (71ºC) 20-25 Pre-cooked ham 5 to 7 lb. 325°F (163ºC) 160°F (71ºC) 30-40

* The U.S. Department of Agriculture states, “Rare fresh beef is popular, but you should know that cooking it to only 140°F (60°C) means some

food poisoning organisms may survive.” (Source: Safe Food Book, Your Kitchen Guide, USDA Rev. June 1985.) The lowest temperature recommended by the USDA is 145°F (63°C) for medium rare fresh beef. For well done 170°F (77ºC)

** Stuffed turkey requires additional roasting time. Shield legs and breast with foil to prevent over browning and drying of the skin.

Figure 10: Roast with broil pan and insert and roasting rack

Do not use the broiler pan without the insert. A roasting rack (some models) can be used when convection roasting. Do not cover the broil pan or insert with aluminum foil; the exposed grease could ignite.

Figure 11: Convection air flow and rack positions

To prevent food from contacting the broil element and to prevent grease splattering, do not use the roasting rack when broiling.

Important: When roasting chicken use the offset rack in th e lowest position for best results.

Page 18

SETTING OVEN CONTROLS

CAUTION

WARNING

Using the Broil Feature

Use the broil feature to cook meats requiring direct exposure to radiant heat for optimum browning results. Broiling will produce some smoke. If smoke is excessive, place the food further away from the broil element. Always watch food carefully to prevent burning. Always arrange oven racks when the oven is cool. The door must be closed for broil to operate. If the door is left open the display will show "d-O". Close the door for the function to resume. When broiling, always pull the oven rack out to the stop position before turning or removing food.

Always use pot holders or oven mitts when working with a hot oven. When broiling, the oven interior, oven racks and cooktop will become hot enough to cause burns. Do not use the broiler pan without the insert. The insert is slotted and allows the grease to drain away from the meat and the high heat of the broiler into the broiler pan. Do not cover the broil pan or insert with aluminum foil; the exposed grease could ignite.

To set broil:

1. Arrange oven racks while oven is cool. Turn the mode selector knob to BROIL. The indicator light will flash.

2. Turn the temperature selector knob to BROIL. The

indicator light will turn on and remain lit. For optimum browning results, preheat oven for 2 minutes before adding food.

3. Place the broiler pan on the rack. Be sure to center the broiler pan directly under the broiler element.

4. Broil with the oven door closed. Always pull the oven rack out to the stop position before turning or removing food.

5. Turn the temperature and the selector knobs to OFF

when broiling is complete or to cancel broil

Note: If a broiler pan and insert are not supplied with this

appliance, they may be purchased from frigidaire.com.

If an oven fire occurs, close the oven door. If the fire continues, throw baking soda on the fire or use a fire extinguisher. Do not put water or flour on the fire. Flour can be explosive; water can cause a grease fire to sp read possibly causing personal injury.To prevent grease splat tering, use the broil pan and insert when broiling

Table 2: Recommended Broiling Times

Food Rack Position Temperature Cook time (minutes)

Steak 1” thick 5th or 6th* 550F (288ºC) 5 4 145ºF (63ºC) Medium* Steak 1” thick 5th or 6th* 550F (288ºC) 8 7 160°F (71ºC) Medium-Well Steak 1” thick 5th or 6th* 550F (288ºC) 8 7 170°F (77ºC) Well Pork Chops 3/4” thick 5th 550F (288ºC) 8 6 170°F (77ºC) Well Chicken bone-in 4th 550F (288ºC) 20 10 170°F (77ºC) Well Chicken boneless 4th 550F (288ºC) 8 6 170°F (77ºC) Well Fish 4th 550F (288ºC) 13 n/a 170°F (77ºC) Well Shrimp 4th 550F (288ºC) 5 n/a 170°F (77ºC) Well Hamburger 1” thick 6th* 550F (288ºC) 5 4 135°F (57°C) Rare** Hamburger 1” thick 6th* 550F (288ºC) 9 7 145ºF (63ºC) Medium Hamburger 1” thick 6th* 550F (288ºC) 10 8 170°F (77ºC) Well

Depending on the type, the thickness, and the desired doneness of meat, it might be necessary to increase or decrease suggested broiling times or adjust the broiling pan to different rack positions.

*Use offset rack in top position. The U.S. Department of Agriculture states, **Rare fresh beef is popular, but you should know that cooking it to only 140°F (60°C)

means some food poisoning organisms may survive.” (Source : S afe Food Book, Yo ur K itche n Gui de, USDA Rev. June 1985.) The lowest temperature recommended by the USDA is 145°F (63°C) for medium rare fresh beef. For well done 170°F (77ºC). All cook times shown are after 2 minutes of preheating.

Figure 12: Rack positions (L) Broil pan and insert (R)

1st side 2nd side

Internal

T emperature

Doneness

Page 19

SETTING OVEN CONTROLS

IMPORTANT

handle

probe cable

probe sensor

handle

receptacle

probe

connector

Meat Probe

Use the probe feature for best results when cooking foods such as roasts, hams or poultry, using a probe to check internal temperature is the safest method to ensure properly cooked food. Before using the meat probe read the important information listed here:

• The probe feature must be set before setting the cooking mode and oven temperature.

• If no cooking mode is selected within 30 seconds of setting the target temperature, the oven mode indicator light will stop blinking. The display will continue to show the meat probe settings until an allowable cooking mode is selected.

• If a timer is running it must be canceled before the probe temperature can be set.

• If the meat probe is unplugged during a cooking function (or plugged in during BROIL) the oven will turn off.

• When the meat probe is set correctly, the control will signal an alert when the internal food temperature reaches the set temperature.

• When active, the internal food temperature is visible in the display during the cooking process. This eliminates any guesswork or the need to open the oven door to check the thermometer.

Important: If the meat probe is plugged in while the oven is in a function that allows for the meat probe, the control will sound an alert (triple beep) indicating that the meat probe cannot be set until the user does the following:

Proper placement of probe in food.

• Insert the probe so that the probe tip rests inside the

center of the thickest part of meat or food (

Figure 13).

For best results, do not allow the probe to cont act bone, fat, gristle, or the cookware.

• For bone-in ham or lamb, insert the probe into the center of lowest large muscle or joint.

• For meatloaf or casseroles, insert the probe into center of food.

• When cooking fish, insert meat probe just above the gill.

• For whole poultry or turkey , fully insert the pr obe into the

thickest part of the breast.

Figure 13: Placing probe in poultry To set probe:

1. Insert the probe into the food. Place prepared food on

the desired oven rack position and slide into the oven.

2. Plug the connector end of the probe into the probe receptacle while the oven is still cool. The receptacle is located on the upper left front oven cavity wall.

1. Cancel the active oven mode.

2. The display will show the meat probe icon and temperature 000°.

3. Set the desired meat probe temperature.

4. Set the desired oven mode.

Page 20

SETTING OVEN CONTROLS

WARNING

Meat Probe (cont’d)

3. When the probe is inserted, an acceptance tone will

sound,

the probe icon appears in the display (See

Figure 14). Close the oven door.

Figure 14: Probe inserted and ready to set temperature

4. Press the + key to set the desired probe temperature

between 140°F and 210°F. If no selection is made within 10 seconds, the control will automatically set the default temperature of 170°F and the display will sound an acceptance chime.

Note: The probe must be fully set before setting the oven mode and temperature mode.

5. Set the oven mode to NO PREHEAT, BAKE, CONV BAKE, or CONV ROAST.

6. Set the oven temp control to the desired cooking

temperature.The oven will begin heating.

7. During the cooking process, an up arrow and the current meat probe temperature will appear in the display until the meat probe target temperature is reached.

8. When 75% of the target temperature is reached, the control will chime and a CHECK FOOD reminder will appear in the display. CHECK FOOD will remain in the display and continue to chime every 60 seconds for five minutes or until the oven door is open.

9. Once the target temperature of the food is reached, the control will chime to signal the end of cooking. At this time the FOOD READY and OVEN WARM messages.

will turn off and the display will show the

Trailing Keep Warm with Meat Probe

When the meat probe reaches the target temperature, the oven will automatically switch to keep warm (170°F) and remain on for up to 3 hours before turning off automatically. The display will continue to show the meat probe tempera ture until either keep warm is canceled or by disconnecting the meat probe from the receptacle. Once turned off, the probe icon and temperature will fade from the display.

Important: If the meat probe temperature should exceed the maximum allowable temperature, the oven control will beep and HOT will appear in the display for 40 seconds to notify that the probe temperature is too high.

Setting Keep Warm

Keep Warm maintains a temperature of 170°F (77°C) for

keeping oven baked foods at serving temperature until canceled. The feature may be used with BAKE, CONV

BAKE, and CONV ROAST. Keep warm tips:

• Always start with hot food. Do not use the keep warm

feature to heat cold food.

• Food in heat-safe glass and glass ceramic containers may need higher temperature settings compared to food in regular containers. Avoid repeated openings of the oven, it will allow hot air to escape and the food to cool.

• Aluminum foil may be used to cover food to increase moisture content.

To set keep warm:

1. Arrange interior oven racks and place food in oven.

2. Turn the oven mode selector to BAKE, CONV BAKE, or CONV ROAST.

3. Set the oven temperature selector to KEEP WARM.

4. The indicator light will blink and then an acceptance

chime will sound.

Food Poisoning Hazard. Do not let food sit for more than one hour before or after cooking. Doing so can result in food poisoning or sickness.

5. The preheat indicator light will turn on and stay on until

the oven reaches the keep warm temperature of 170°

6. When finished with keep warm, be sure to turn both the oven mode selector and the oven temperature selector to OFF.

Page 21

Setting the Sabbath Feature

WARNING

This appliance provides special settings for use when observing the Jewish Sabbath/ Holidays. For further assistance, guidelines for proper usage, and a complete list of models with the Sabbath feature, please

visit the web at www.star-k.org. Sabbath mode disables all audible tones or visual display changes on the oven control. The Sabbath feature may only be used with the bake function. Once the oven is properly set using bake with the Sabbath feature active, the oven will remain on until cancelled. The Sabbath feature overrides the factory preset 6 hour energy saving feature.

Important: The oven light will turn off during the Sabbath mode and remain off until the Sabbath mode is canceled. before activating the Sabbath feature.

The meat probe feature is not available in Sabbath mode.

Food Poisoning Hazard. Do not let food sit for more than one hour before or after cooking. Doing so can result in food poisoning or sickness. Foods that can easily spoil such as milk, eggs, fish, meat, or poultry should be chilled in the refrigerator first. Even when chilled, they should not stand in the oven for more than 1 hour before cooking begins and should be removed promptly when finished cooking.

To set the oven for baking and activate the Sabbath feature:

1. Be sure the clock is set to the correct time of day. Place

food in the oven.

2. Turn the oven mode selector to BAKE.

3. Turn the oven temperature selector to the desired bake

temperature.

4. An acceptance chime will sound, the oven will start

heating and the LED lights will stop blinking and remain on.

5. To enter Sabbath mode press and hold the oven light

key and the clock key at the same time for about 3 seconds. The control will sound an acceptance chime and SAB will appear in the display below the time of day.

SETTING OVEN CONTROLS

Figure 15: Oven display showing Sabbath mode Note: During the Sabbath mode all normal sounds of the

oven control will be turned off. However the control will allow any sounds associated with alarms.

During Sabbath operation the oven temperature may be changed by adjusting the oven temperatu r e sele ct or . Th e oven will remain in Sabbath until canceled by the user.

To turn off the Sabbath feature:

1. Turn both the oven m ode selector a nd th e oven te mpe r-

ature selector to the OFF position. This cancels BAKE only .

2. Press and hold both the oven light key and the clock key for about 3 seconds.

3. The acceptance chime will sound and SAB will

disappear from the display.

4. The oven is now ready for normal use.

Power failure while using Sabbath feature:

Should you experience a power failure or interruption, the oven will shut off. When power is returned, SF (Sabbath Failure) will be displayed, and the oven will not turn back on automatically. If your food was nearly fully cooked, you may allow the trapped heat in the oven to finish the cooking process. Otherwise, you should remove the food when the power failure occurs because you may only start the oven once during the Sabbath/Jewish holidays.

To turn off the Sabbath Failure (SF) message:

1. Turn the oven mode selector and the oven temperature selector to the OFF position.

2. Press and hold both the oven light and clock key for at

least 3 seconds.

3. SF will disappear from the display, and the oven may be used with all normal functions.

Page 22

SETTING OVEN CONTROLS

NOTE

Adjusting the Oven Temperature

The temperature in the oven is pre-set at the factory. When first using the oven, be sure to follow recipe times and

temperatures.

Do not use oven thermometers such as those found in grocery stores to check the temperature settings inside your oven. These oven thermometers may vary as much as 20 to 40 degrees from actual temperatures.

If you think the oven is cooking too hot or too cool for the temperature you select, you can adjust the actual oven temperature to be more or less than what is displayed by accessing the UPO (User Programmable Offset).

Before adjusting, test a recipe by using a temperature setting higher or lower than the recommended temperatur e. The baking results should help you to decide how mu ch of an adjustment is needed.

Important: Befo re making a temperatur e adjustment, make sure both the oven mode and oven temperature control knobs are in the OFF position.

To adjust the oven temperature:

1. When the oven is idle, press and hold both the light icon

and the clock icon at the same time for a few seconds until the display sounds an acceptance chime. AUd should appear in the display.

2. Press the + key in the upper part of the display until

UPO appears and the default setting of

offset temperature) is showing.

0° (or the last

If a lower temperature offset is desired, press the – key in the bottom of the display until the desired lower tempera ture appears.

Figure 18: UPO shown 10° lower than default

4. Release the key and the control will accept the change.

5. To return the display to normal, press and hold both the

oven light icon and the clock icon at the same time until an acceptance chime sounds. The display will return to show the time of day.

Changing the UPO will not affect the broil or self clean temperatures.

Restoring Factory Control Settings

Your appliance was set with standard oven control settings. Over time these may have been changed. Restoring the control to factory (default) settings will affect the following:

• Continuous bake or 6 hour energy saving

• Silent or audible control

• Oven temperature adjustments

To restore oven control to default settings:

1. When the oven is idle, press and hold both the light icon

and the clock icon at the same time for a few seconds until the display sounds an acceptance chime. AUd should appear in the display.

2. Press the + key in the upper part of the disp lay until rS t appears and yes or no appears in the lower part of the display.

Figure 16: UPO shown at default setting

3. Using the + or - key in the bottom of the display, press

until the desired temperature change (offset) is reached. The display will change press to a maximum of

Figure 17: UPO shown 10° higher than default

+ 35° or a minimum of – 35°F.

± 5° with each key

3. Press the + or - key to toggle between yes (to reset to

default) or no (to leave current settings as they are).

4. When the desired setting appears, the control will

accept the change after a few seconds with a beep a nd return to the clock mode.

Page 23

SETTING OVEN CONTROLS

IMPORTANT

CAUTION

Self Cleaning

A self cleaning oven cleans itself with temperatures well above normal cooking temperatures which eliminate soils completely or reduces them to a fine powdered ash you can wipe away with a damp cloth.

While the oven is in operation, the oven heats to temperature much higher than those used in normal cooking. Sounds of metal expansion and contraction are normal. Odor is also normal because the food soil is being removed. Smoke may appear through the oven vent.

Adhere to the following self clean precautions:

• Do not use oven cleaners or oven protective coatings

in or around any part of the oven interior.

• Do not clean the oven door gasket (Figure 19). The woven material of the oven door gasket is essential for a good seal. Care should be taken not to rub, damage, or remove the gasket. Do not use any cleaning materials on the oven door gasket. Doing so could cause damage.

• Remove the broiler pan and insert, all utensils, and any aluminum foil. These items cannot withstand high cleaning temperatures and will melt.

During the self cleaning cycle, the outside o f the oven can become very hot to the touch. Do not leave small children unattended near the appliance.

The health of some birds is extremely sensitive to the fumes given off during the self cleaning cycle of any oven. Move birds to another well ventilated room.

Do not force the oven door open. This can damage the automatic door locking system. Use caution when opening the door after the self cleaning cycle is complete. The oven may still be very hot.

• Completely remove all oven racks and any accessories. If the oven racks are not removed, they will lose their special coating properties and no longer slide in and out of the oven cavity easily.

• Remove any excessive spills. Any spills on the oven bottom should be wiped up and removed before starting the self cleaning cycle. To clean, use hot, soapy water and a cloth. Large spills can cause heavy smoke or fire when subjected to high tempera tures.

• Do not allow food spills with a high sugar or acid content (such as milk, tomatoes, sauerkraut, fruit juices, or pie filling) to remain on the surface as they may leave a dull spot even after cleaning.

• Clean any soil from the oven frame, the door liner outside the oven door gasket, and the small area at the front center of the oven bottom. These areas heat sufficiently to burn soil on. Clean with soap and water. These areas are shown in white (

Figure 19).

Figure 19: Clean around the oven door gasket

To avoid possible burns, use care when ope ning the oven door after the self-cleaning cycle. Stand to the side of the

oven when opening the door to allow hot air or steam to

escape. Do not line the oven walls, racks, bottom, or any other

part of the oven with aluminum foil. Doing so will destroy heat distribution, produce poor baking results, and cause permanent damage to the oven interior (aluminum foil will melt to the interior surface of the oven).

Page 24

SETTING OVEN CONTROLS

Setting Self Clean

If you are planning to use the oven directly after a self clean cycle, remember to allow time for the oven to cool down and the oven door to unlock. This normally takes about one hour. A 3 hour self clean cycle will actually take about 4 hours to complete.

It is recommended to use a 2 hour self clean cycle for light soils, a 3 hour cycle for average soils, and a 4 hour cycle for heavy soils.

To set the controls for a 3 hour self clean cycle and shut off automatically:

1. Turn both the oven mode and oven temperature

selectors to CLEAN. The display will show a 3 hour time (normal clean) and the

Figure 20: Oven set for 3 hour clean

2. If a 3 hour clean is desired, the control will accept the

time within 3 seconds. However, the user may select a 2 or 4 hour clean by using the – or + keys to change to the desired clean time and then allow the control to accept the change.

– and + keys.

Figure 22: Setting 4 hour clean

Once the control accepts the clean time the display will flash a reminder for the user to REMOVE RACKS.

Figure 23: Display prompting user to remove racks REMOVE RACKS notification will flash for a few seconds

prompting the user to remove all oven racks. If the oven door is opened as this time the display will show CLO to indicate that the door must be closed before the clean cycle can begin. If the door remains open for more than 3 minutes, the clean function will be canceled.

The

Figure 21: Setting 2 hour clean

Figure 24: Message of open door that must be closed before oven can begin the clean cycle

When the oven is set to run the clean cycle, the motor door lock will begin locking the oven door. Do not open the oven door while the lock motor is running or when any locking indicators or displays are showing. The oven door is completely locked in about 15 seconds.

Page 25

SETTING OVEN CONTROLS

3. Once the door is closed the time of day will be visible

along with the selected clean time and the door lock icon will be blinking in the display. Do not force the oven door open when the self clean is active. This can damage the automatic door locking system .

Figure 25: Clean cycle in progress

4. During the clean cycle the time of day remains in the

display and the time remaining in the clean cycle will also be active.(

Figure 25)

Figure 26: Hot oven after clean with door still locked

5. When the clean cycle ends the oven will be too hot for

the door to unlock until the oven cools to a safe temper ature. This may take up to an hour. During this time the display will show Hot along with the door lock icon.

6. Once the oven temperature reaches a saf e level, CLn will appear in the display and the lock icon will blink to signal the end of the clean cycle with a chime. Do not force the oven door open when the lock icon is showing in the display; this can damage the automatic door locking system.

7. Move both the oven mode and temperature mode knob to the OFF position to clear the display.

Caution: To avoid possible burns, use care when opening the oven door after a self clean cycle. Stand to the side to allow any steam and heat to escape. The internal oven temperature will still be hot enough to cause burns even though the bake and broil elements appear to have cooled.

Figure 27: Clean lock icon blinks as door unlocks

Note: Once the clean cycle ends the oven will not be

available for another clean for 4 hours.

To cancel a self clean before it end s:

Turn both the oven selector knob and th e oven tempe rature knob to the OFF position.

Page 26

CARE AND CLEANING

Cleaning Various Parts of Your Oven

Before cleaning any part of the oven, be sure all controls are turned off and the oven is cool. Remove spills and any heavy soiling as soon as possible. Regular cleaning will reduce the number of major cleaning later.

Surface Type Recommendation

Aluminum and Vinyl trim Painted body parts Painted decorative trims Plastic

Control Pad Decorative trim (some models)

Stainless steel (some models) Only use cleaners and polishes specifically manufactured for cleaning stainless steel.

Smudge-Proof™ Stainless Steel (some models)

Porcelain enamel broiler pan and insert (available by mail order)

Door liner and body parts

Oven interior Remove oven racks from the oven cavity before cleaning the oven interior. Use a mild,

Oven racks

Use hot, soapy water and dry with a clean cloth. Use a soft cloth and clean with mild dish detergent and water or a 50/50 solution of vinegar and water. Follow by rinsing the area with clean water; dry and polish with a soft cloth. Glass cleaners may be used if sprayed on a soft cloth first. Do not spray liquids directly on the oven control and display area. Do not use large amounts of water on the control panel. Excess water on the control area may cause damage to the appliance. Do not use other liquid cleaners, abrasive cleaners, scouring pads, or paper towels. They will damage the finish.

Use a soft cloth and clean with mild dish detergent and water or a 50/50 solution of vinegar and water. Follow by rinsing the area with clean water; dry and polish with a soft cloth. Glass cleaners may be used if sprayed on a soft cloth first. Do not spray liquids directly on the oven control and display area. Do not use large amounts of water on the control panel. Excess water on the control area may cause damage to the appliance. Do not use other liquid cleaners, abrasive cleaners, scouring pads, or paper towels. They will damage the finish.

Always rub in direction of metal grain to avoid damaging. Do not use cleaners with high concentrations of chlorides or chlorine. Do not use harsh scrubbing cleaners. Polish with a lint-free cloth. Be sure to wipe excess cleaner/polish off from the metal surface as bluish stains may occur during future oven heating that cannot be removed. Clean heavier soils with hot, soapy water and a cloth or sponge. Use clean water to rinse; use a cloth to dry

Clean the stainless with warm soapy water using a clean sponge or cloth. Rinse with clean water and dry with a soft clean cloth. Do not use store bought cleaners like stainless steel cleaners or any other types of cleaners containing any abrasive, chlorides, chlorine, or ammonia. Use mild dish soap and water or a 50/50 solution of water and vinegar.

Gentle scouring with a soapy scouring pad will remove most spots. Rinse with a 1:1 solution of clear water and ammonia. If necessary, cover difficult spots with an ammonia soaked paper towel for 30 to 40 minutes. Rinse with clean water and a damp cloth, then scrub with a soap-filled scouring pad. Rinse and wipe dry with a clean cloth. Remove all cleaners or the porcelain may become damaged during future heating.

abrasive cleaner following manufacturer’s instructions. Rinse with clean water and dry. Oven racks must be removed before a self clean. Clean by using a mild, abrasive cleaner

following manufacturer’s instructions. Rinse with clean water and dry.

Glide Rack Oven door Use soap and water to thoroughly clean the top, sides, and front of the oven door. Rinse

To maintain the glide rack see Caring for your glide rack on page 28.

well. Only use a glass cleaner on the outside glass of the door. Do not immerse the door in water. Do not spray or allow water or the glass cleaner to enter the door vents. Do not use oven cleaners, powders, or any harsh abrasive cleaning materials on the outside of the oven door. Do not clean the oven door gasket which is essential for a good seal. Do not rub, damage, or remove this gasket.

Page 27

CARE AND CLEANING

CAUTION

General Cleaning

Refer to the table at the beginning of this chapter for more information about cleaning specific parts of the oven.

Before manually cleaning any part of the oven , be sure all controls are turned off and the oven is cool. The oven may be hot and can cause burns.

Remove all racks and accessories from the oven before cleaning.

Ammonia must be rinsed before operating the oven. Provide adequate ventilation.

Follow these cleaning precautions:

• Allow the oven to cool before cleaning.

• Wear rubber gloves when cleaning the app liance

manually.

Remove soils using hot, soapy water. Do not allow food spills with a high sugar or acid content (such as milk, tomatoes, sauerkraut, fruit juices or pie filling) to remain on the surface as they may cause a dull spot even after cleaning. Remove spillovers and heavy soiling as soon as possible. Regular cleaning will reduce the effort required for major cleaning later.

Cleaning Porcelain Enamel Oven

The oven interior is porcelain on steel, it is safe to clean using oven cleaners.

To remove heavy soil:

1. Allow a dish of ammonia to sit in the oven overnight or

for several hours with the oven door closed. Clean softened dirt spots using hot, soapy water. Rinse well with water and a clean cloth.

2. If soil remains, use a nonabrasive scouring pad or a nonabrasive cleaner. If necessary, use an oven cleaner following manufacturer's instructions. Do not mix ammonia with other cleaners.

3. Clean any soil from the oven frame, the door liner outside the oven door gasket and the small area at the front center of the oven bottom. Clean with hot, soapy water. Rinse well using clean water and a cloth.

Boiler Pan Cleaning Tips

To prevent grease from baking on, remove the broiler pan from the oven as soon as cooking is completed. Use oven mitts because the broiler pan is extremely hot. Pour off grease. Soak the pan in hot, soapy water.

Clean the broiler pan as soon as possible after each use. If necessary , use soap-filled stee l wool pads. Heavy scouring may scratch the grid.

Figure 1: Broiler pan with insert

Page 28

CARE AND CLEANING

WARNING

CAUTION

NOTE

Aluminum Foil, Aluminum Utensils, and Oven Liners

Never cover any slots, holes, or passages in the oven bottom or cover an entire oven rack with materials such as aluminum foil. Doing so blocks air flow through the oven and may cause carbon monoxide poisoning. Aluminum foil linings may trap heat, causing a fire hazard.

• Protective liners—Do not use aluminum foil to line the oven bottom. The high heat of the oven can melt these materials to the oven cavity and ruin the oven. These types of materials can also reduce the effectiveness of the air circulation in the oven and produce poor baking results. Only use aluminum foil as recommended in this manual. Improper installation of these liners may result in risk of electric shock or fire.

• Aluminum utensils - The melting point of aluminum is much lower than that of other metals. Care must be taken when aluminum pots or pans are used.

• Oven racks - Do not use aluminum foil to cover the oven racks. Using a liner in the oven restricts the heat a nd air flow needed to obtain the best possible cooking result s for any oven.

Replacing the Oven Light

Be sure the oven is unplugged and all parts are cool before replacing the oven light.

The interior oven lights are located at the rear of the oven cavity and is covered by a glass shield. The glass shield must be in place whenever the oven is in use (

To replace the oven interior light bulb:

1. Turn electrical power off at the main source or unplug

the appliance.

2. Remove interior oven light shield by turning a quarter turn counter-clockwise.

3. Replace bulb with a new T-4 type Halogen 25 watt appliance bulb.

Wear a cotton glove or use a paper towel when installing a new bulb. Do not touch the new bulb with your fingers when replacing. This will shorten the life of the bulb.

Figure 2).

Adhere to the following precautions when using spray oven cleaners:

• Do not spray cleaner on the electrical controls or

switches because it could cause a short circuit and result in sparking or fire.

• Do not spray any cleaner on the oven door trim or gasket, broiler drawer glides, handles or any exterior surfaces of the oven, plastic or painted surfaces. The cleaner can damage these surfaces.

• Do not allow a film from the cleaner to build up on the temperature sensing bulb; it could cause the oven to heat improperly. The bulb is located in the rear of the oven. Carefully wipe the bulb clean after each oven cleaning, being careful not to move the bulb. A change in its position could affect how the oven bakes. Avoid bending the bulb and capillary tube.

4. Replace glass oven light shield by rotating clockwise.

5. Turn power back on again at the main source (or plug

the appliance back in).

6. Be sure to reset the time of day on the clock

Figure 2: Wall oven Halogen light

Page 29

Removing and Replacing the Oven Door

IMPORTANT

Oven door hinge locations

Door frame ﬂush with hinge lock

Hinge notch

Special door care instructions - The door is heavy. For safe, temporary storage, lay the door flat with the inside of the door facing down.

Most oven doors contain glass that can break. Do not close the oven door until all the oven racks are positione d correctly in the cavity. Do not hit the glass with bakeware or any other objects. Scratching, hitting, jarring, or stressing the glass may weaken its structure, causing an increased risk of breakage at a later time.

To remove the oven door:

1. Open oven door completely, horizontal with floor.

2. Pull up the lock located on each hinge support toward

front of the oven until the lock stops. You may have to apply a little upward pressure on the lock to pull it up (

Figure 4 and Figure 5).

3. Grasp the door by the sides, and close the door until the door frame makes contact with the unlocked hinges.

4. Pull the bottom of the door toward you while rotating the top of the door toward the appliance to completely disengage the hinge levers (

Figure 6).

CARE AND CLEANING

Figure 3: Door hinge location

Figure 4: Door hinge locked

To Replace Oven Door:

1. Firmly grasp both sides of oven door along the door

sides. Do not use the oven door handle (

2. Hold the oven door at the same angle as the removal position. Carefully insert the hinge levers into the oven frame until you feel the hinge levers are seated into the hinge notches. The hinge arms must be fully seated in to the hinge notches before the oven door can be fully opened. (

3. Fully open the oven door, horizontal with floor (

Figure 3).

4. Push the door hinge locks up toward and into the oven frame on both left and right oven door hinges to the locked position (

5. Close the oven door.

Figure 6).

Figure 4).

Figure 6).

Figure 5: Unlocking door hinge

Figure 6: Remove door position

Page 30

CARE AND CLEANING

CAUTION

Caring for your glide racks

Handle oven racks only when they are cool. After cooking racks will be very hot and can cause burns.

Important: Remove all oven racks before starting a self

clean cycle. If oven racks are left inside the oven during a cleaning cycle, the slide ability of the glide rack may be damaged and the racks will lose their finish.

• Anytime the gliding is rough, the glide rack tracks should be treated with graphite lubrication .

• Do not use cooking oil, cooking spray , or other oil-based

lubrication products on the glide rack extension tracks. Use only the graphite lubrication in this area. To order graphite lubrication, contact your installer, servicer or dealer.

To lubricate the glide rack:

1. Remove the rack from the oven and place the rack on a large flat surface covered with newspaper or scrap cloth. Fully extend the rack.

2. Wipe away debris and crumbs from the glide tr ack using a cloth or sponge.

4. Extend and return the glide rack several times along the

tracks to distribute the lubrication

5. Turn glide rack over. Shake graphite lubrication very well before applying. Place four drops of graphite lubri cation along the tracks. Repeat on both sides of the glide rack.

6. Extend and return the glide rack several times along the tracks to distribute the lubrication.

3. Shake graphite lubrication very well before applying. Place four drops of graphite lubrication along the tracks (see area circled on figure below). Repe at on both sides of the glide rack.

7. Apply a thin layer of cooking oil to the outer frame of the

glide rack as shown below. Keeping the frame sides lightly lubricated allows the entire rack to slide easily when changing rack positions.

8. Replace rack in oven right side up.

Page 31

BEFORE YOU CALL

Solutions to Common Baking Problems

For best cooking results, fully preheat the oven before baking cookies, breads, cakes, pies or pastries, etc. There is no need to preheat the oven for roasting meat or baking casseroles. The cooking times and temperatures needed to bake a product may vary slightly from your previously owned appliance.

Baking Problems and Solutions Chart Baking Problems Causes Corrections Cookies and biscuits

burn on the bottom.

Cakes too dark on top or bottom.

Cakes not done in center.

Cakes not level. • Oven not level.

• Cookies and biscuits put into

oven before the preheating time is completed.

• Oven rack is overcrowded.

• Dark pans absorb heat too fast.

• Cakes put in oven before

preheating time is completed.

• Rack position too high or too low.

• Oven too hot.

• Incorrect pan size.

• Pan not centered in oven.

• Pan too close to oven wall or

rack overcrowded.

• Pan warped.

• Allow oven to preheat to desired temperature before

placing food in oven,

• Choose pan sizes that will permit 2 to 4 inches (5.1 to 10.2 cm) space on all sides when placed in the oven.

• Use a medium weight baking sheet.

• Allow oven to preheat to the selected temperature

before placing food in the oven.

• Use proper rack position for baking needs.

• Set oven temperature 25°F (13°C) lower than

recommended.

• Set oven temperature 25°F (13°C) lower than recommended.

• Use pan size suggested in recipe.

• Use proper rack position and place pan to allow for

2 to 4 inches (5.1 cm to 10.2 cm) space on all sides of pan.

• Place a marked glass measuring cup filled with water on the center of the oven rack. If the water level is uneven, refer to the installation instructions for leveling the oven.

• Be sure to allow 2” to 4” (5.1 cm to 10.2 cm) of clearance on all sides of each pan in the oven.

• Do not use pans that are dented or warped.

Foods not done when cooking time is over.

• Oven light left on while baking.

• Oven too cool.

• Oven overcrowded.

• Oven door opened too

frequently.

• Leave oven light off while baking.

• Set oven temperature 25°F (13°C) higher than

suggested and bake for the recommended time.

• Be sure to remove all pans from the oven except the ones to be used for baking.

• Open oven door only after shortest recommended baking time.

Page 32

BEFORE YOU CALL

Solutions to Common Problems

Before you call for service, review the following list. It may sa ve yo u tim e and ex pe n se. Possible solutions are provided with the problem listed:

Problem Solution

Oven control panel beeps and displays error codes

Poor baking results • Many factors effect baking results.

No Preheat performs poorly • No Preheat not used corre c tly. This cooking function is intended for convenience,

Appliance is not level • Poor installation. Place oven rack in center of oven. Place a level on the oven rack

Cannot move appliance easily Appliance must be accessible for

service Appliance does not operate • Electrical power outage. Check house lights to be sure.

• Oven control has detected a fault or er ror condition. Whe n this occurs an E or F will show in the display.

• Turn both oven selectors to the OFF position; Activate a Bake or Broil using both the oven mode and temperature selectors.

• If the F or E code error repeats, turn off power to appliance, wait 5 minutes and then repower appliance. Set clock with correct time of day.

• Try Bake or Broil function again. If a fault code appear again, turn both oven selectors to the OFF position to clear the error code and contact your servicer.

• Use proper oven rack position.

• Center food in the oven and space pans to allow air to circulate.

• Preheat oven to the set temperature before placing food in the oven.

• Try adjusting the recipe's recommended temperature or baking time. See

“Adjusting the Oven Temperature”on page 22 if you feel the oven is too hot or cold.

precooked, and other specific foods. See follow tips for best using this feature.

to check if oven has been properly installed.

• Kitchen cabinet alignment may make oven appear not level. Be sure cabinets are square and have sufficient room for appliance clearance.

• If cabinets are not square or are built in too tightly, contact builder or installer to make appliance accessible.

• Cabinets not square or are built in too tightly.

• Contact builder or installer to make appliance accessible.

“Setting No Preheat” on page 13 and

Flames inside oven or smoking from oven vent

• Call your local electric company for service outage information.

• Service wiring is incomplete. Call 1-800-944-9044 for assistance.

• Excessive spills in oven. Grease or food spilled onto oven bottom or oven cavity.

Wipe up excessive spills before starting oven.

• If flames or excessive smoke are present when broiling, see “Using the Broil

Feature” on page 18.

Page 33

BEFORE YOU CALL

Oven does not operate. • The time of day is not set. The oven clock must first be set in order to operate the

oven.

See “Setting the Clock”on page 11.

• Be sure oven controls are set properly. See “OVEN DISPLAY FEATURES” beginning on page 10 and review instructions for the desired cooking function in this manual.

• Before setting the oven, both mode and temperature knobs should be set to OFF.

• If the indicator lights above oven mode or oven temp selection knobs remain

flashing, the oven will not heat. Turn both knobs to OFF, wait 5-10 seconds, then set the oven mode and oven temp again.

• If the oven mode and oven temp combination is mismatched, the oven will not heat. For example: bake mode with broil temperature, or clean mode with a cooking temperature. These combinations will cause an error. T urn both knobs to OFF, wait 5-10 seconds, then set the oven mode and oven temp again, with a correct mode and temperature. For example: broil mode should have broil temperature selected; clean mode should have clean temperature selected. Review the section of this manual for the cooking mode you wish to use.

• Set both mode and temperature selection knobs to OFF when finished cooking.

Oven smokes excessively when broiling.

Oven racks discolored or do not slide easily.

Glide racks Oven light does not work. • Be sure the oven light is secure in the socket. “See “Replacing the Oven Light”on

Fan noise occurring after the oven is turned off

• Incorrect setting. See “Using the Broil Feature” on page 18.

• Meat too close to the broil element. Reposition rack to provide proper clearance

between the meat and broil element. Remove excess fat from meat. Cut remaining fatty edges to prevent curling, but do not cut into lean.

• Grease build up on oven surfaces. Regular cleaning is necessary when broiling frequently. Grease or food splatters will cause excessive smoking.

• Clean by using a mild abrasive cleaner following manufacturer's instructions. Rinse with clean water, dry, and replace in oven.

• To maintain glide rack see “Caring for your glide racks” on page 30.

page 28.

• Some models are equipped with a cooling fa n that r uns during the cooking process to cool internal electronic components. It is normal for this fan to continue to run for an extended period of time, even when the oven has been turned off.

Page 34

Your appliance is covered by a one year limited warranty. For one year from your original date of purchase, Electrolux will pay all costs for repairing or replacing any parts of this appliance that prove to be defective in materials or workmanship when such appliance is installed, used and maintained in accordance with the provided instructions.

Exclusions

This warranty does not cover the following:

1. Products with original serial numbers that have been removed, altered or cannot be readily determined.

2. Product that has been transferred from its original owner to another party or removed outside the USA or Canada.

3. Rust on the interior or exterior of the unit.

4. Products purchased “as-is” are not covered by this warranty.

5. Food loss due to any refrigerator or freezer failures.

6. Products used in a commercial setting.

7. Service calls which do not involve malfunction or defects in materials or workmanship, or for appliances not in ordinary household use or used other than in accordance with the provided instructions.

8. Service calls to correct the installation of your appliance or to instruct you how to use your appliance.

9. Expenses for making the appliance accessible for servicing, such as removal of trim, cupboards, shelves, etc., which are not a part of the appliance when it is shipped from the factory.

10. Service calls to repair or replace appliance light bulbs, air filters, water filters, other consumables, or knobs, handles, or other cosmetic parts.

11. Surcharges including, but not limited to, any after hour, weekend, or holiday service calls, tolls, ferry trip charges, or mileage expense for service calls to remote areas, including the state of Alaska.

12. Damages to the finish of appliance or home incurred during installation, including but not limited to floors, cabinets, walls, etc.

13. Damages caused by: services performed by unauthorized service companies; use of parts other than genuine Electrolux parts or parts obtained from persons other than authorized service companies; or external causes such as abuse, misuse, inadequate power supply, accidents, fires, or acts of God.

CUSTOMER’S SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE PRODUCT REPAIR OR REPLACEMENT AS PROVIDED HEREIN. CLAIMS BASED ON IMPLIED WARRANTIES, INCLUDING WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW, BUT NOT LESS THAN ONE YEAR. ELECTROLUX SHALL NOT BE LIABLE FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH AS PROPERTY DAMAGE AND INCIDENTAL EXPENSES RESULTING FROM ANY BREACH OF THIS WRITTEN LIMITED WARRANTY OR ANY IMPLIED WARRANTY. SOME STATES AND PROVINCES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, OR LIMITATIONS ON THE DURATION OF IMPLIED WARRANTIES, SO THESE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU. THIS WRITTEN WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE.

Keep your receipt, delivery slip, or some other appropriate payment record to establish the warranty period should service be required. If service is performed, it is in your best interest to obtain and keep all receipts. Service under this warranty must be obtained by contacting Electrolux at the addresses or phone numbers below.

DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES

This warranty only applies in the USA and Canada. In the USA, your appliance is warranted by Electrolux Major Appliances North America, a division of Electrolux Home Products, Inc. In Canada, your appliance is warranted by Electrolux Canada Corp. Electrolux authorizes no person to change or add to any obligations under this warranty. Obligations for service and parts under this warranty must be performed by Electrolux or an authorized service company. Product features or specifications as described or illustrated are subject to change without notice.

If You Need Service

Canada

1.800.265.8352

Electrolux Canada Corp.

5855 Terry Fox Way

USA

1.800.944.9044 Electrolux Home Products, Inc. 10200 David Taylor Drive Charlotte, NC 28262

Frigidaire FPEW3077RFD, FPEW3077RFC, FPEW3077RFB, FPEW3077RFA Owner’s Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

PRODUCT RECORD AND REGISTRATION

IMPORTANT SAFETY INSTRUCTIONS

BEFORE SETTING OVEN CONTROLS

SETTING OVEN CONTROLS

CARE AND CLEANING

BEFORE YOU CALL

WARRANTY
