Frigidaire FGGF3032K B User Manual
Freestanding Ranges
FGGF3032K W/ B
Signature Features
30" Gas
Product Dimensions
Height (Max.) 47-1/2"
Width 29-7/8"
Depth (Including Handle) 28-1/2"
More Easy-To-Use Features
Quick Bake Convection
Bake faster and more evenly with Quick
Bake Convection.
Low Simmer Burner
Perfect for delicate foods and sauces.
Continuous Grates
Continuous Grates make it easy to
move heavy pots and pans between
burners without lifting.
Even Baking Technology
Our latest technology ensures even
baking every time.
Auto Shut-O
As an extra safety measure, the oven
will automatically shut off after 6 hours.
One-Touch Self Clean
Start the self-cleaning cycle with
just the touch of a button.
Quick Boil
Boils water faster.
Fits-More™ Cooktop
The Fits-More™ cooktop features five
burners so you can cook more at once.
Express-Select® Controls
Easily go from warm to boil.
Eortless™ Oven Rack
Bottom rack extends when you
open the door for easy access.
Quick Clean
For a quick, light oven cleaning.
Delay Start
Set your oven to begin cooking on
your schedule. It can be programmed
from 1 to 24 hours.
Available in:
White
(W)
Burners
Right Front
Right Rear
Left Front
Left Rear
Center Extra Zone
Black
(B)
BTU
17,000
5,000
9,500
14,000
9,500
frigidaire.com
C
A
36"
(Adjustable)
B
Features
Oven Control / Timing System
Surface Type
Sealed Gas Burners
Grates
Window
Exterior Door Finish
Handle Design
Exterior Finish (Side Panels)
Convection System
Oven Cleaning System
Drawer Functionality
Express-Select® Controls
Black Porcelain
Yes
Continuous Cast Iron
w/ Black Matte Finish
Extra-Large
Color-Coordinated
Color-Coordinated
Color-Coordinated
Quick Bake Convection
Self Clean
Storage
Oven Controls
Bake / Broil
Eortless™ Convection Conversion
Convection Bake / Broil / Roast
Quick Bake Convection
Quick Preheat
My Favorite
Chicken Nugget Button
Pizza Button
Keep Warm
Add-a-Minute
Delay Bake
Self Clean
Quick Clean Option
Delay Clean
Kitchen Timer / Timed Cook Option
Auto Oven Shuto
Lower Drawe r Control
Yes / Low and High
Yes
2, 3 Hours
Yes
Yes
Yes / Yes
12 Hours
Cooktop Features
Right Front Burner (BTU)
Right Rear Burner (BTU)
Left Front Burner (BTU)
Left Rear Burner (BTU)
Center Extra Zone Burner (BTU)
17,000
5,000
9,500
14,000
9,500
Oven Features
Capacity (Cu. Ft.)
Oven Light
Rack Configuration
Baking System
Broiling System
Bake Burner / Broil Burner (BTU)
Drawer Racks
5.0
1
1 Standard, 1 Oset,
1 Eortless™
Even Baking Technology
Vari-Broil™ Hi/Lo
18,000 / 13,500
Optional Accessories
LP Gas Conversion Kit
PN # GRLP3
Specifications
Oven Interior ( H x W x D )
Power Supply Connection Location
Gas Supply Connection Location
Voltage Rating
Conn. Load (kW Rating) @ 120 Volts
Amps @ 120 Volts
Shipping Weight (Approx.)
1
For use on adequately wired 120V, dedicated circuit having 2-wire service
with a separate ground wire. Appliance must be grounded for safe operation.
17-5/8" x 24-3/8" x 19-3/4"
Left Bottom Rear
Right Bottom Rear
120V / 60Hz / 15A
1
1.8
15
215 Lbs.
Freestanding Ranges
FGGF3032K W/ B 30" Gas
NOTE: For planning purposes only. Always consult local and national electric and gas codes.
Refer to Product Installation Guide for detailed installation instructions on the web at frigidaire.com.
Product Dimensions
A - Height (Max.)
B - Width
C - Depth (Including Handle)
Depth with Door Open 90˚
47-1/2"
29-7/8"
28-1/2"
46-5/8"
Cutout Dimensions
Height (Standard)
Width (Min.)
Depth (Min.)
36"
30"
24"
Accessories information available
on the web at frigidaire.com
•
USA
10200 David Taylor Drive
•
CANADA
FGGF3032K 01/11 © 2011 Electrolux Home Products, Inc. Printed in the U.S.A.
5855 Terry Fox Way
•
Charlotte, NC 28262
•
Mississauga, ON L5V 3E4
•
1-800-FRIGIDAIRE
•
1-800-265-8352
•
frigidaire.com
•
frigidaire.ca
Specifications
subject to change.
