Frigidaire FGGF301DNB User Manual
Freestanding Ranges
FGGF301DN F/ W/ B
30" Gas
Product Dimensions
Height (Max.) 49"
Width 30"
Depth (Including Handle) 28-7/8"
More Easy-To-Use Features
Even Baking Technology
Our Even Baking Technology ensures
even baking every time.
Add-a-Minute
Easily add a minute to the oven timer in
the middle of a cycle without resetting.
Sabbath Mode (Star-K® Certified)
Available in:
Stainless
(F)
White
(W)
Black
(B)
Signature Features
Quick Clean
Quickly clean your oven in 2 hours
with our quick self-clean cycle.
One-Touch Keep Warm Setting
Just one touch of a button keeps food
warm until everything — and everyone —
is ready.
Double Oven Range
A second oven provides the
ultimate flexibility — you can cook
two different dishes at different
temperatures, and all at the same
time.
Continuous Grates
Continuous Grates make it easy to
move heavy pots and pans between
burners without lifting.
Burners
Right Front
Right Rear
Left Front
Left Rear
1
Select model only.
BTU
17,000
5,000
9,500
9,500
frigidaire.com
Features
Oven Control / Timing System
Surface Type
Sealed Gas Burners
Grates
Window
Exterior Door Finish
Handle Design
Exterior Finish (Side Panels)
Convection System
Oven Cleaning System
Upper Oven
Express-Select® Controls
Black Porcelain
Yes
Continuous Cast Iron
w/ Black Matte Finish
Large
Smudge-Proof Stainless
Steel (F), Color-Coord. (W/B)
Stainless Steel (F),
Color-Coordinated (W/B)
Black (F), Color-Coord. (W/B)
Self Clean
Fits-More™ Upper Oven
Oven Controls
Bake / Broil
Eortless™ Convection Conversion
Convection Bake / Broil / Roast
Quick Bake Convection
Quick Preheat
Eortless™ Temperature Probe
My Favorite
Chicken Nugget Button
Pizza Button
Keep Warm
Add-a-Minute
Delay Start
Self Clean
Quick Clean Option
Delay Clean
Kitchen Timer / Timed Cook Option
Auto Oven Shuto
Oven Lock-Out
Yes / Variable (400-550°F)
Yes
Yes
Yes
Yes
Yes
2, 3, 4 Hours
Yes / Yes
12 Hours
Yes
Cooktop Features
Right Front Burner (BTU)
Right Rear Burner (BTU)
Left Front Burner (BTU)
Left Rear Burner (BTU)
Center Extra Zone Burner (BTU)
17,000
5,000
9,500
9,500
Oven Features
Upper/Lower Capacity (Cu. Ft.)
Upper/Lower Oven Light
Upper/Lower Rack Configuration
Baking System
Broiling System
Upper Bake / Broil Burners (BTU)
Lower Bake / Broil Burners (BTU)
2.3/3.5
1/1
1/2 Standard
Even Baking Technology
Vari-Broil™
11,500/10,000
12,500 / No
Optional Accessories
LP Gas Conversion Kit
PN# 318565419
Certifications
Sabbath Mode (Star-K® Cert.)
Yes
Specifications
Upper Oven Interior ( H x W x D )
Lower Oven Interior ( H x W x D )
Power / Gas Supply Conn. Location
Voltage Rating
Conn. Load (kW Rating) @ 120 Volts
Amps @ 120 Volts
Shipping Weight (Approx.)
1
For use on adequately wired 120V, dedicated circuit having 2-wire service
with a separate ground wire. Appliance must be grounded for safe operation.
8-3/8" x 24-3/8" x 19-3/8"
12-3/4" x 24-1/8" x 19-1/2"
Left Bottom/
Right Bottom Rear
120V / 60Hz / 15A
1
1.8
15
260 Lbs.
Freestanding Ranges
FGGF301DN F/ W/ B 30" Gas
36"
(Adjustable)
C
B
NOTE: For planning purposes only. Always consult local and national electric and gas codes.
Refer to Product Installation Guide for detailed installation instructions on the web at frigidaire.com.
Product Dimensions
A - Height (Max.)
B - Width
C - Depth (Including Handle)
Depth with Door Open 90˚
49"
30"
28-7/8"
46"
Cutout Dimensions
Height (Stand.)
Width (Min.)
Depth (Min.)
Accessories information available
on the web at frigidaire.com
A
36"
30-1/8"
24"
•
USA
10200 David Taylor Drive
•
CANADA
FGGF301DN 12/13 © 2013 Electrolux Home Products, Inc.
5855 Terry Fox Way
•
Charlotte, NC 28262
•
Mississauga, ON L5V 3E4
•
1-800-FRIGIDAIRE
•
1-800-265-8352
•
frigidaire.com
•
frigidaire.ca
Specifications
subject to change.
Freestanding Ranges
FGGF301DN F/ W/ B 30" Gas
Freestanding Range Specifications
•
Product Shipping Weight (approx.) – 260 Lbs.
•
Voltage Rating – 120V / 60 Hz / 15 Amp
•
Connected Load (kW Rating) @ 120 Volts = 1.8 kW
(For use on adequately wired 120V, dedicated circuit having 2-wire
service with a separate ground wire. Appliance must be grounded
for safe operation.)
•
Amps @ 120 Volts = 15 Amps
•
Always consult local and national electric and gas codes.
•
Make sure wall coverings around range can withstand heat generated
by range.
•
Linoleum or any other synthetic floor covering located beneath range,
must be capable of withstanding minimum heat of 90° F above room
temperature without shrinking, warping or discoloring. Insulating pad
or 1/4"-thick plywood required between range and a carpeted floor.
•
Do not obstruct flow of combustion air at oven vent nor around base
or beneath lower front panel of range. Range requires fresh air for
proper burner combustion.
•
Do not install range beneath any downward-blowing, overhead vent
hood or air curtain.
•
Range ships with 1/2" NPT factory regulator.
•
Range is LP Gas convertible. (Optional LP Gas Conversion
Kit available.)
•
Overhead cabinetry should not exceed a 13" maximum depth.
•
USA
10200 David Taylor Drive
•
CANADA
FGGF301DN 12/13 © 2013 Electrolux Home Products, Inc.
5855 Terry Fox Way
•
Charlotte, NC 28262
•
Mississauga, ON L5V 3E4
•
1-800-FRIGIDAIRE
•
1-800-265-8352
•
frigidaire.com
•
frigidaire.ca
•
Allow 30" minimum clearance between top of cooking surface and
bottom of unprotected wood or metal overhead cabinet; or 24"
minimum clearance when bottom of wood or metal overhead cabinet
is protected by not less than 1/4" flame-retardant millboard covered
with not less than No. 28 MSG sheet steel, 0.015" stainless steel,
0.024" aluminum or 0.020" copper.
•
Absolute minimum horizontal distance between overhead cabinets
installed to either side of appliance must be no less than maximum
width of appliance.
•
Range can be installed flush to wall with 0" minimum rear clearance.
•
Minimum 7" clearance required from edge of rangetop to nearest
combustible wall on either side of range above 36" height.
•
To reduce risk of fire when using overhead cabinetry, install vent hood
that projects horizontally a recommended minimum of 5" beyond
bottom of cabinets.
•
Follow all dimension requirements provided to prevent property
damage, potential fire hazard, and incorrect countertop and
cabinet cuts.
Optional Accessories
•
LP Gas Conversion Kit – (PN # 318565419)
Note: For planning purposes only. Refer to Product Installation Guide
on the web at frigidaire.com for detailed instructions.
Specifications
subject to change.
