Frigidaire FGEW3065K DATASHEET
Single Wall Ovens
FGEW3065K F/ W/ B
30" Electric
Product Dimensions
Height 29"
Width 30"
Depth 24-1/2"
More Easy-To-Use Features
SpaceWise® Half Rack
Flexible rack system that adjusts to cook
multiple dishes at once. Remove the half
rack and you’ll have extra height for tall
dishes.
One-Touch Keep Warm Setting
Just one touch of a button keeps food
warm until everything — and everyone —
is ready.
Real Stainless Steel
Real stainless steel with a protective
coating that reduces fingerprints and
smudges so it’s easy to clean.
Eortless™ Convection
Takes the guesswork out of convection
cooking — our oven does the converting
for you.
Signature Features
Quick Preheat
Preheat in less than 6 minutes.
Express-Select™ Controls
Easily set cooking temperature or
choose one-touch cooking options.
Even Baking Technology
Our latest technology ensures even baking
every time.
Auto Shut-O
As an extra safety measure, the oven will
automatically shut off after 6 hours.
Quick Clean
For a quick, light oven cleaning.
A.D.A. Compliant
1
True Convection
Multi-rack baking is faster and more
even with True Convection.
Available in:
Stainless
(F)
1
Based on single rack cooking performance, not set
temperature, using Quick Preheat.
2
When properly installed, meets the appliance
standards in the Americans with Disabilities Act and
the Architectural Barriers Act Accessibility Guidelines
as published by the United States Access Board on
June 23, 2004, as amended August 5, 2005.
2
White
(W)
Black
(B)
One-Touch Options
Our ovens feature easy-to-use
one-touch buttons so you can cook
pizza or chicken nuggets — or even
add a minute to the timer — with the
touch of a button.
frigidaire.com
Features
E
D
B
C
A
Spacer
Oven Control / Timing System
Window
Exterior Door Finish
Handle Design
Oven Cleaning System
Express-Select™
Extra-Large
Real Stainless Steel (F),
Color-Coordinated (W/B)
Stainless Steel (F),
Color-Coordinated (W/B)
Self Clean
Oven Controls
Bake / Broil
Convection Conversion
Convection Bake / Broil / Roast
Quick Bake Convection
Oven Preheat
My Favorite
Chicken Nugget Button
Pizza Button
Keep Warm
Add-a-Minute
Delay Bake
Self-Clean
Clean Option
Delay Clean
Kitchen Timer
Timed Cook Option
Control Lock
Auto Oven Shuto
Oven Lock-Out
Yes / Variable (400 - 500 °F)
Eortless™
Yes / Yes / Yes
Yes
Quick
Yes
Yes
Yes
Yes
Yes
Quick
2, 3, 4 Hours
Yes
Yes
Yes
Yes
Oven Features
Capacity (Cu. Ft.)
Convection System
Oven Light
Hidden Bake Element
Rack Configuration
Baking System
Broiling System
Bake / Broil Element (Watts)
4.2
True Convection
2
Yes
1 Heavy Duty, 1 SpaceWise®
1/2 Rack, 1 Oset Rack
Even Baking Technology
Power Broil
2,200 / 4,000
Optional Accessories
3"-High Bottom Trim – Stainless
Steel (F) / White (W) /Black (B)
(F) PN # 318258707
(W) PN # 318258703
(B) PN # 318258704
Certifications
A.D.A. Compliant
Sabbath Mode (Star-K® Certified)
1
Yes
Yes
Specifications
Oven Interior ( H x W x D )
Power Supply Connection Location
Voltage Rating
Connected Load (kW Rating)
@ 240 / 208 Volts
Amps @ 240 / 208 Volts
Minimum Circuit Required (Amps)
Approved for
Under-Counter Installation
Shipping Weight (Approx.)
1
When properly installed, meets the appliance standards in the Americans
with Disabilities Act and the Architectural Barriers Act Accessibility
Guidelines as published by the United States Access Board on June 23,
2004, as amended August 5, 2005.
16-1/2" x 24-1/8" x 18-1/32"
Left Bottom Rear
240V / 208V / 60Hz
4.7 /3.6
20.0 / 17.0
20
Yes
175 Lbs.
Single Wall Ovens
FGEW3065K F / W / B 30" Electric
NOTE: For planning purposes only. Always consult local and national electric codes.
Refer to Product Installation Guide for detailed installation instructions on the web at frigidaire.com.
Product Dimensions
A - Height
B - Width
C - Depth
D - Height (Wrapper)
E - Width (Wrapper)
Depth with Door Open 90˚
29"
30"
24-1/2"
27-3/16"
28-1/4"
44-1/2"
Cutout Dimensions –
Height (min.) / (max.)
Width (min.) / (max.)
Depth (min.)
27-1/4" / 28-5/8"
28-1/2" / 29"
23-1/2"
•
USA
10200 David Taylor Drive
•
CANADA
FGEW3065K 10/10 © 2010 Electrolux Home Products, Inc. Printed in the U.S.A.
5855 Terry Fox Way
•
Charlotte, NC 28262
•
Mississauga, ON L5V 3E4
•
1-800-FRIGIDAIRE
•
1-800-265-8352
•
frigidaire.com
•
frigidaire.ca
Accessories information available
on the web at frigidaire.com
Specifications
subject to change.
