Frigidaire FGEF3058RB User Manual

Freestanding Ranges

FGEF3058R F/ W/ B

Signature Features

30" Electric

Product Dimensions

Height (Max.) 47-3/4"

Width 29-7/8"

Depth (Including Handle) 28-13/32"

More Easy-To-Use Features

Eortless™ Convection

Takes the guesswork out of
convection cooking — our oven
automatically adjust standard
baking temperatures to convection
temperatures for consistent results.

Fits-More™ Cooktop with
SpaceWise® Expandable
Elements

The cooktop features five burners
including two SpaceWise® Expandable
elements and a Warming Zone so you
can cook more at once.

Eortless™ Temperature Probe
with Auto Keep Warm

The Effortless™ Temperature Probe
allows you to set the desired finished
temperature and alerts you when
that temperature has been reached.
The oven then holds the desired
temperature of the meat by switching
to a Keep Warm function for better
cooking results.

Quick Preheat

Preheat in just a few minutes.

1

One-Touch Quick Self Clean

Your oven cleans itself — so you don’t
have to. Self clean options available in
2-, 3- and 4-hour cycles.

True Convection

Single convection fan circulates hot
air throughout the oven for faster and
more even multi-rack baking.

Smudge-Proof™ Stainless Steel

Resists fingerprints and cleans easily.

One-Touch Keep Warm Setting

Just one touch of a button keeps food
warm until everything — and everyone —
is ready.

Built with American Pride

Designed, enginereed and assembled
in the U.S.A. Appliances that are high­performing, more accessible, and more
innovative than ever.

Sabbath Mode (Star-K® Certified)

Available in:

Stainless

(F)

Elements

Right Front

Right Rear

Left Front

Left Rear

Center

1

Based on single rack cooking performance, not set
temperature, using Quick Preheat.

White

(W)

Size

9" / 12"
Expandable

6"

6" / 9"
Expandable

6"

Keep Warm
Zone

Black

(B)

Watts

1,800 /3,200

1,200

1,200 /3,000

1,200

100

frigidaire.com

Features

Oven Control / Timing System

Surface Type

Window

Exterior Door Finish

Handle Design

Exterior Finish (Side Panels)

Convection System

Oven Cleaning System

Drawer Functionality

Oven Controls

Bake / Broil

Eortless™ Convection Conversion

Convection Bake / Broil / Roast

Quick Bake Convection

Quick Preheat

My Favorite

Eortless™ Temperature Probe

Pizza Button

Keep Warm

Add-a-Minute

Delay Start

Self Clean

Quick Clean Option

Delay Clean

Kitchen Timer / Timed Cook Option

Auto Oven Shut-O

Oven Lock-Out

Lower Drawer Control

Cooktop Features

Right Front Element (Watts)

Right Rear Element (Watts)

Left Front Element (Watts)

Left Rear Element (Watts)

Bridge Element (Watts)

Center Element (Watts)

Hot Surface Indicator Light

Oven Features

Capacity (Cu. Ft.)

Oven Light

Hidden Bake Element

Rack Configuration

Baking System

Broiling System

Bake Element / Broil Element (Watts)

Drawer Racks

Certifications

Sabbath Mode (Star-K® Cert.)

Specifications

Oven Interior ( H x W x D )

Power Supply Connection Location

Voltage Rating

Connected Load (kW Rating)
@ 240 / 208 Volts

Minimum Circuit Required (Amps)

Shipping Weight (Approx.)

Express-Select® Controls

Black Ceramic Glass


Smudge-Proof™ Stainless
Steel (F), Color-Coord. (W/B)

Stainless Steel (F),
Color-Coordinated (W/B)

Black (F), Color-C. (W/B)

True Convection

Self Clean

Storage

Yes /Variable (400-550°F)

Yes

Yes / No / Yes

Yes

Yes

Yes

Yes

Yes

Yes

2, 3, 4 Hours

Yes

2, 3, 4 Hours

Yes / Yes

Yes

Yes

SpaceWise® Expandable
9" / 12" – 1,800 / 3,200

6" – 1,200

SpaceWise® Expandable
6" / 9" – 1,200 / 3,000

6" – 1,200

Keep Warm Zone  – 100

Yes

5.8

1

Yes

3 Standard

Even Baking Technology

Vari-Broil™ Hi / Lo

3,500 / 3,900

Yes

21" x 24-3/8" x 19-1/2"

Middle Bottom Rear

240V / 208V / 60 Hz

12.5 / 9.5

40

195

Freestanding Ranges

FGEF3058R F/ W/ B 30" Electric

36"

(Adjustable)

C

B

NOTE: For planning purposes only. Always consult local and national electric codes.
Refer to Product Installation Guide for detailed installation instructions on the web at frigidaire.com.

Product Dimensions

A - Height (Max.)

B - Width

C - Depth (Including Handle)

Depth with Door Open 90˚

47-3/4"

29-7/8"

28-13/32"

48-1/4"

Cabinet Cutout Dimensions

Height (Standard)

Width (Min.)

Depth (Min.)

A

36"

30"

24"

•

USA

10200 David Taylor Drive

•

CANADA

FGEF3058R 04/15 © 2015 Electrolux Home Products, Inc.

5855 Terry Fox Way

•

Charlotte, NC 28262

•

Mississauga, ON L5V 3E4

•

1-800-FRIGIDAIRE

•

1-800-265-8352

•

frigidaire.com

•

frigidaire.ca

Accessories information available

on the web at frigidaire.com

Specifications

subject to change.
