Frigidaire FFHP124CS1 Installation Manual

All about the

Installation

of your

Split Type Room Air Conditioner

Refer to Page 2 for table of contents.

www.frigidaire.com USA 1-866-942-1567

2020323B2335 (June 2009)

www.frigidaire.ca Canada 1-866-942-1567

Welcome to the world of simple handling and no worries

Thank you for choosing Frigidaire. This manual contains all of the information required to guarantee your safety and the appropriate use of your air conditioner. Please read all of the instructions before using the air conditioner and keep this manual for future reference. We know you will enjoy your new air conditioner and thank you for choosing our product. We hope you will consider us for future purchases.

Environmental advices

The packaging material used is recyclable. We recommend that you separate plastic, paper and cardboard and give them to recycling companies. If you need to dispose of this appliance in the future, do not throw it away with the rest of your domestic garbage.

Attention!!

The air conditioner that you have bought may be slightly different from the one illustrated in this manual. Please refer to the information related to the model you have. This air conditioner is for domestic use only. It is not recommended for heavy commercial or industrial use.

Welcome

Contents

01. Welcome..........................................................................................01

02. Environmental advices........................................................................01

03. Contents...........................................................................................02

04. Safety precautions............................................................................. 03

05. Installation:

5.1 Choosing the installation site.................................................04

5.2 Parts list..............................................................................06

5.3 Indoor unit installation.......................................................... 08

5.4 Outdoor unit installation....................................................... 12

5.5 Refrigerant piping connection................................................14

5.6 Electrical work.....................................................................16

5.7 Purging the system............................................................... 20

5.8 Electrical safety....................................................................23

5.9 Gas leak check....................................................................23

5.10 Initial operation test..............................................................24

Contents

Safety precautions

This appliance must be installed by a qualified licensed HVAC technician in accordance with all applicable codes. All electrical connections should be performed by a licensed electrician. Manufacturer's warranty will be voided with failure to comply.

Incorrect Handling could result in Serious Injury or Death!

1. Do not attempt to install the split air conditioner by yourself.

2. This air conditioner contains no user-serviceable parts. Always call an authorized Electrolux servicer for repairs.

3. When moving the air conditioner, always call an authorized Frigidaire servicer for disconnection and reinstallation.

4. Do not insert fingers or place objects into the discharge area in the front of the indoor unit.

5. Do not insert fingers or place objects into the discharge area in the front of the outdoor unit.

6. Do not start or stop the air conditioner by turning off the power at the electrical box.

7. In the event of a malfunction (sparks, burning smell, etc.) immediately power off unit and call an authorized Frigidaire servicer.

8. Do not operate the air conditioner with wet hands.

9. Do not drink any water or condensation that is drained from the air conditioner.

.Provide occasional ventilation

during use. Do not direct airflow at fire places or other heat related sources as this could cause flare ups or make units run excessively.

11. Do not climb on or place objects on the outdoor unit.

12. Do not hang objects off the indoor unit.

13. Do not place objects containing water on the indoor and/or outdoor units.

14. Turn off the air conditioner at the power source when it will not be used for an extended period of time.

15. Periodically check the condition of the outdoor unit’s installation base for any damage.

16. Do not apply heavy pressure to the coil fins of the indoor and/or outdoor units.

17. Operate the indoor unit with air filters in place.

18. Do not block or cover the intake grille, discharge area and outlet ports.

19. Ensure that any electrical/ electronic equipment is 36” away from the indoor unit and outdoor unit.

20. Do not use or store flammable gases near the indoor and/or outdoor units.

Satety precautions

Choosing the installation site

Installation Warnings

1. Carefully read the installation manual before beginning.

2. Follow each step as shown.

3. Observe all local, state and national electric codes. This appliance must be installed by a qualified licensed HVAC technician in accordance with all applicable codes. All electrical connections should be performed by a licensed electrician. Failure to comply will result in a void of the manufacturer's warranty.

4. Pay attention to all safety notices.

Precautions for Installation

Installation at the following sites may cause problems. If you must inevitably install the unit at one of these sites, please consult your local distributor beforehand:

1. Sites with machine oil.

2. Sites with a high concentration of salinity, such as coastal areas.

3. Sites with sulfuric gas, such as hot water springs.

4. Sites with high frequency equipment, such as wireless equipment, welding machines and medical installations.

5. Sites with flammable gases or volatile material.

6. Sites with special environmental conditions.

7. Laundry rooms.

Choosing the installation site

Indoor Unit

than 2"

1. Install unit where air flow will not be obstructed.

2. The installation location must support the weight of the indoor unit.

3. The site must be easily accessible for maintenance and replacement of the air filter.

4. The installation location must allow for the necessary space around the indoor unit, as shown in the figure

1.1.

5. There should be at least 3 feet (1 meter) between the unit and radio or television devices. It is ideal that the unit be installed at the center of the wall.

6. The indoor unit must be kept away from fire, smoke and flammable gases.

Outdoor Unit

1. The outdoor unit must be installed at a convenient site that is not exposed to strong winds. The site should be dry and well ventilated.

2. The site must support the weight of the outdoor unit and allow for vertical installation.

3. The site must be kept away from flammable gases.

4. The site must provide enough space around the unit, as shown in figure

1.2.

5. Children must not be able to access the installation site.

7. We recommend the indoor unit to be installed as high up as possible on the inside wall (minimum of 7 feet high), always leaving a space of at least 6" between the top of the indoor unit and the ceiling.

8. The installation location must allow for the easy removal of the connector pipe and drain hose.

9. The unit must be installed at a location protected from direct sunlight.

More than 6"

More than 12"

Figure 1.1

More than 8.5"

More than 6"

More than 12"

More than 78"

Figure 1.2

More than 18.5"

Choosing the installation site

Part Lists

Tools needs for installation

1. Level gauge

2. Screw driver

3. Electric drill

4. Hole core drill (ø55mm / ø70mm)

5. Flaring tool set

6. Specied torque wrenches

7. Spanner (half union)

8. A glass of water

9. Hexagonal wrench (4mm)

10. Gas-leak detector

11. Vacuum pump

12. Gauge manifold

13. Users manual

14. Thermometer

15. Multimeter

16. Pipe cutter

17. Measuring tape

Accessories

Number Name of Accessories Quantity

Note: Other necessary parts for the installation, besides the above mentioned, must be provided by the customer/installer.

Indoor unit mounting plate 1

Clip anchor Not supplied

Self-tapping screw A ST3.9X25 5-8

Remote control 1

Remote control holder (Optional) 1

Screw for remote holder ST2.9X10 (Optional) 2

Battery (AAA 1.5V) 2

Insulation material Not supplied

Connection piping assembly(Optional) 1

Insulation hose for refrigerant piping Not supplied

Drain hose Not supplied

Wall clamp Not supplied

Connection power cable Not supplied

Drain connector (Heat Pump model only) 1

Drain plug (Heat Pump model only) (Optional) 2-3

Thermal insulating pipe for extending drain hose 1

Flare nut (for suction pipe) (Optional) 1

Flare nut (for liquid pipe) (Optional) 1

Part list

Product Description

Indoor

1 23

Unit

Space to the wall

Space to the ceiling

15cm above

3m above

Air outlet side

Space to the wall

30cm above

Space to obstruction

2m above

Air outlet side

50cm above

Space to the wall

15cm above

Air inlet side

30cm above

50cm above

Space to the wall

NOTE All the pictures in this manual are for explanation purposes only. The actual shape of the indoor unit you purchased may be slight different on front panel and display window.The actual shape shall prevail.

Part list
