Frigidaire FFEF3012TB Specsheet
Drop-In Cooktop
Freestanding Ranges
FPEC3085K S
FFEF3012T W/ B
30" Electric30" Electric
Product Dimensions
Height (Max.) 46-5/8"
Width 29-7/8"
Depth (Including Handle) 28-1/2"
More Easy-To-Use Features
Electronic Kitchen Timer
Times up to 12 hours.
Manual Clean Oven
Available in:
White
(W)
Elements
Right Front
Right Rear
Left Front
Left Rear
Black
(B)
Size
6"
8"
8"
6"
Watts
1,250
2,100
2,100
1,250
Signature Features
Store-More™
Storage Drawer
With the Store-More™ Storage Drawer,
you will have extra space to store your
cookware.
Color-Coordinated Oven
Door with Large Window
Our large oven window makes it easier to
check on the status of your dish without
having to open the oven door.
Built with American Pride
Designed, engineered and assembled in
the U.S.A.
Hi/Lo Broil Options
Offers two-position broiling and variable
temperature control for more control.
frigidaire.com
Features
C
A
36"
(Adjustable)
B
Oven Control / Timing System
Surface Type
Window
Exterior Door Finish
Handle Design
Exterior Finish (Side Panels)
Convection System
Oven Cleaning System
Drawer Functionality
Oven Controls
Bake
Broil
Add-a-Minute
Delay Start
Self-Clean
Quick Clean Option
Delay Clean
Kitchen Timer
Timed Cook Option
Auto Oven Shut-O
Cooktop Features
Right Front Element (Watts)
Right Rear Element (Watts)
Left Front Element (Watts)
Left Rear Element (Watts)
Center Element (Watts)
Hot Surface Indicator Light
Coil Cooktop / Drip Bowls
Oven Features
Capacity (Cu. Ft.)
Oven Light
Hidden Bake Element
Rack Configuration
Baking System
Broiling System
Bake Element / Broil Element (Watts)
Specifications
Oven Interior ( H x W x D )
Power Supply Connection Location
Voltage Rating
Connected Load
(kW Rating) @ 240 / 208 Volts
Minimum Circuit Required (Amps)
Shipping Weight (Approx.)
Ready-Select® Controls
Color-Coordinated Porcelain
Large
Color-Coordinated
Color-Coordinated
Color-Coordinated
Manual Clean
Storage
Yes
Variable (High/Low)
Yes
6" – 1,250
8" – 2,100
8" – 2,100
6" – 1,250
Yes
Yes / Chrome
4.8
1
2 Standard
Even Baking Technology
Vari-Broil™ Hi / Lo
2,600 / 3,000
19-3/4" x 23" x 18-3/4"
Right Bottom Rear
240V / 208V / 60Hz
10.0 / 7.5
40
145 Lbs.
Freestanding Ranges
FFEF3012T W/ B 30" Electric
NOTE: For planning purposes only. Always consult local and national electric codes.
Refer to Product Installation Guide for detailed installation instructions on the web at frigidaire.com.
Product Dimensions
A - Height (Max.)
B - Width
C - Depth (Including Handle)
Depth with Door Open 90˚
46-5/8"
29-7/8"
28-1/2"
45"
Cabinet Cutout Dimensions
Height (Standard)
Width (Min.)
Depth (Min.)
36"
30"
24"
•
USA
10200 David Taylor Drive
•
CANADA
FFEF3012T 05/17 © 2017 Electrolux Home Products, Inc.
5855 Terry Fox Way
•
Charlotte, NC 28262
•
Mississauga, ON L5V 3E4
•
1-800-FRIGIDAIRE
•
1-800-265-8352
•
frigidaire.com
•
frigidaire.ca
Accessories information available
on the web at frigidaire.com
Specifications
subject to change.
