Page 1
Drop-In Cooktop
Built-In Cooktop
FPEC3085K S
FFEC2111QB
30" Electric
22" Electric
Product Dimensions
Width 21-1/8"
Depth 17-1/8"
Height 2-1/2"
More Easy-To-Use Features
Built with American Pride
Appliances that are high-performing,
more accessible, and more innovative
than ever — designed, built, and
engineered in the U.S.A.
Available in:
Black
(B)
Elements
Right Front
Left Rear
Size
6"
6 / 9"
Watts
1,200
1,000 / 2500
Signature Features
SpillSafe® Cooktop
Cooktop contains your spillovers for easier
clean up.
Ready-Select® Controls
Select options or control cooking temperature
with our easy-to-use controls.
Hot Surface Indicator
Alerts you when your cooktop may be too
warm to touch.
Ceramic Glass Cooktop
For a more beautiful cooktop that’s easy
to clean.
frigidaire.com
Page 2
A
B
C
Features
Controls
Surface Type
Right Front Element (Watts)
Left Rear Element (Watts)
Hot Surface Indicator
Control Location
Knob Color
Knob Type
Ready-Select®
Black Ceramic Glass
6" - 1,200
6 / 9" - 1,000 / 2500
Yes
Front Left
Black
Plastic
Specifications
Power Supply Connection Location
Voltage Rating
Connected Load
(kW Rating) @ 240 / 208 Volts
Amps @ 240 / 208 Volts
Minimum Circuit Required (Amps)
Approved for Electric Single Wall Oven
Combination Installation
Shipping Weight (Approx.)
1
Single phase 3- or 4-wire cable, 120 / 240 or 120 / 208 Volt, 60 Hertz AC
only electrical supply with ground required on separate circuit fused on
both sides of line.
1
Center Bottom Rear
240V /208V / 60Hz
3.7 / 2.7
15.4 / 15.4
20
22 Lbs.
Built-In Cooktop
NOTE: Always consult local and national electric codes. Refer to Product Installation
Guide for detailed installation instructions on the web at frigidaire.com.
FFEC2111QB 22" Electric
Product Dimensions
A - Width
B - Depth
C - Height
21-1/2"
17-1/8"
2-1/2"
Cutout Dimensions – Horizontal
Width (Min.)
Width (Max.)
Depth (Min.)
Depth (Max.)
Height
Cutout Dimensions – Vertical
Width (Min.)
Width (Max.)
Depth (Min.)
Depth (Max.)
Height
Installation Kit available.
20-1/8"
20-1/2"
16-1/8"
16-1/2"
4"
16-1/8"
16-1/2"
20-1/8"
20-1/2"
4"
Granite Countertop
•
USA
10200 David Taylor Drive • Charlotte, NC 28262 • 1-800-FRIGIDAIRE • frigidaire.com
•
CANADA
FFEC2111Q 10/14 © 2014 Electrolux Home Products, Inc.
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
Accessories information available
on the web at frigidaire.com
Specifications
subject to change.
Page 3
Drop-In Induction / Electric Cooktops
(Callouts MUST be charted per individual model).
Professional / Gallery / Baseline
Horizontal or Vertical
Installation
Built-In Cooktop
FFEC2111QB 22" Electric
A - Width B - Depth C - Height
Horizontal
Vertical
Horizontal
Vertical
Built-In Cooktop Specifications
•
Product Shipping Weight (approx.) – 22 Lbs.
•
Single phase 3- or 4-wire cable, 120 / 240 or 120 / 208 Volt, 60 Hertz
AC only electrical supply with ground required on separate circuit
fused on both sides of line.
•
Connected Load (kW Rating) @ 240 / 208 Volts = 3.7 / 2.7 kW
•
Amps @ 240 / 208 Volts = 15.4 / 15.4 Amps
•
Recommended Circuit Breaker – 20 Amps
•
Always consult local and national electric codes.
•
Cooktop cutout height includes clearance needed beneath cooktop
to allow for armored cable and installation of junction box on back
wall. Position center of junction box 10" inward from right side of
cooktop cutout, and 12" down from underside of countertop.
•
Overhead cabinetry should not exceed a 13" maximum depth.
•
Absolute minimum horizontal distance between overhead cabinets
installed to either side of appliance must be no less than 21" for
horizontal installation or 17" for vertical installation.
•
Allow 30" minimum clearance between top of cooktop platform
and bottom of unprotected wood or metal overhead cabinet; or 24"
minimum clearance when bottom of wood or metal overhead cabinet
is protected by not less than 1/8" flame-retardant millboard covered
with not less than No. 28 MGS sheet steel, 0.015" stainless steel,
0.024" aluminum or 0.020" copper.
USA • 10200 David Taylor Drive • Charlotte, NC 28262 • 1-800-FRIGIDAIRE • frigidaire.com
•
CANADA
FFEC2111Q 10/14 © 2014 Electrolux Home Products, Inc.
5855 Terry Fox Way • Mississauga, ON L5V 3E4 • 1-800-265-8352 • frigidaire.ca
21-1/2" 17-1/8" 2-1/2"
17-1/8" 21-1/2" 2-1/2"
D - Width (min. - max.) E - Depth (min. - max.) F - Height (min.)*
20-1/8" - 20-1/2" 16-1/8" - 16-1/2"
16-1/8" - 16-1/2" 20-1/8" - 20-1/2"
Product Dimensions
Product Cutout Dimensions
4"
4"
•
Allow 2" minimum clearance between rear edge of cutout and nearest
combustible surface (or backsplash) above countertop.
•
Allow 7-1/2" minimum required clearance from left edge of cooktop
to nearest combustible wall and 7-1/2" minimum from right edge of
cooktop to nearest combustible wall.
•
Installation of drawer beneath cooktop is not recommended. Empty
space is needed for installation use.
•
To reduce risk of fire when using overhead cabinetry, install
range hood that projects horizontally a recommended minimum
of 5" beyond bottom of cabinets.
Note: For planning purposes only. Refer to Product Installation Guide
Optional Accessories
•
Granite Countertop Installation Kit – (PN # 903061-9010).
Required Clearances
G (min.) H (min.) I (min.) J (min.)
2" 7-1/2" 7-1/2" 2-1/2"
K - Cabinet Opening Width
on the web at frigidaire.com for detailed instructions.
(min.)
Horizontal – 21"
Vertical – 17"
Accessories information available
on the web at frigidaire.com
Utility Connection Locations
Power Supply
Center Bottom Rear
Specifications
subject to change.
