Frigidaire FC525C User Manual

OPERATING AND INSTALLATION MANUAL

FC 525 C

CHEST FREEZER

Technical Data

Contents

Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Product Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

First use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Switch on-off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Daily use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Care and Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Helpful hints and tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

What to do if... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Service or repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Guarantee Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Model BNI 525

FC 525 C

Volume (gross) Litre 500 Volume (net) Litre 495 Height without/with roller Cm 87,6 Width Cm 160 Depth Cm 66,5 Weight Kg 66 Energy consumption/24h kWh/24h 1,608 Freezing capacity kg/24h 20 Hold-over time Hours 32 Rated power Watt 140 Voltage Volts 230 Climatic class SN

Safety Information

Before installing and using the appliance read this user's instruction book carefully. It contains safety precautions, hints, information and ideas. If the freezer is used in compliance with the instructions written, it will operate properly and provide you with greatest satisfaction. These warnings are provided in the interest of safety. You must read them carefully before installing or using the appliance.

Use the freezer only for storing frozen food, freezing fresh food and making ice cubes.

Do not eat ice cubes or ice lollies immediately after taking them out of the freezer, since they may cause frost burns.

Do not allow children to play or hide inside the freezer, since they may become trapped inside and suffocate.

Do not store glass containers with liguids in the freezer, since they may burst.

Ensure that the freezer is not resting on the power supply cable.

Before servicing or cleaning, always unplug the appliance or disconnect the power supply.

Do not use other electrical appliances (such as ice cream makers) inside the appliance.

Your appliance contains an environmentally friendly natural gas, isobuthane (R600a). Caution is required however, since isobuthane is flammable. Therefore it is essential to ensure that the refrigerant pipelines are not damaged.

It is most important that this instruction book should be retained with the appliance for future reference.

Product Description

1. Lid handle

2. Seal

3. Defrost water drain

4. Control panel

5. Thermostat knob: temperature adjustment

6. Upper edge

Control panel

A. Red light: Illuminates when the freezer temperature is

not sufficiently low. B. Green light: Illuminates when the appliance is on. C. Yellow light: Illuminates when the Super Freeze

function is activated. D. Super Freeze button: Activates/de-activates the Super

Freeze function for large quantities for fresh food and

switches off the beeping alarm.

Installation

Wait at least 2 hours before connecting the freezer to the power supply to ensure the refrigerant circuit is fully efficient.

Install the freezer in a dry, well ventilated room. Avoid locations near a source of heat or in direct sunlight.

The room temperature should correspond to the climatic classification for which the freezer was designed, see chapter "Technical data".

Place the freezer horizontally on a firm surface, resting on all four feet.

For optimum operation and in order to avoid damage when the lid is opened, leave a space of at least 5 cm from the rear wall and 5 cm at the sides.

Before connecting the freezer to the power supply, ensure that the voltage corresponds to that indicated in chapter "Technical data" under "Voltage".

Danger!

Ensure that the freezer is not resting on the power supply cable.

Do not remove the power supply cable by pulling on its lead, particularly when the freezer is being pulled out of its niche.

If the supply cord is damaged it must be replaced by the manufacturer, its service agent, or similarly qualified persons in order to avoid a hazard.

Ensure that the power plug is not squashed or damaged by the back of the freezer.

There must be adequate ventilation around the appliance.

Any electrical work required to install this appliance should be carried out by an authorised engineer.

Electrical connection

The appliance is supplied with a 13amp plug fitted. In the event of having to change the fuse in the plug supplied, a 13amp ASTA approved (BS1362) fuse must be used. Should the plug need to be replaced for any reason. The wires in the power supply cable are coloured in accordance with the following code:
