OPERATING AND INSTALLATION MANUAL
820 41 77 43
4-11GB
FC 7509 R
FC 1039 R
FC 1459 R
FC 1822 R
CHEST FREEZER
2
5.
7.
6.
8.
FREEZING
CAPACITY
1.
2.
3.
4.
1
2
34
5
3
10.
11.
9.
4
CONTENTS
TECHNICAL SPECIFICATIONS
Model
Volume (gross) litres
Volume (net) litres
Height without/with roller cm
Width cm
Depth cm
Weight kg
Energy consumpt./24h kWh
Freezing capacity kg/24h
Hold-over time hours
Rated power W
BBeeffoorree iinnssttaalllliinngg aanndd uussiinngg tthhee aapppplliiaannccee rreeaadd tthhiiss uusseerr''ss iinnssttrruuccttiioonn bbooookk ccaarreeffuullllyy.. IItt ccoonnttaaiinnss ssaaffeettyy pprreeccaauuttiioonnss,,
hhiinnttss,, iinnffoorrmmaattiioonn aanndd iiddeeaass.. IIff tthhee rreeffrriiggeerraattoorr iiss uusseedd iinn ccoommpplliiaannccee wwiitthh tthhee
iinnssttrruuccttiioonnss wwrriitttteenn,, iitt wwiillll ooppeerraattee pprrooppeerrllyy
aanndd pprroovviiddee yyoouu wwiitthh ggrreeaatteesstt ssaattiissffaaccttiioonn..
The symbols below help you to find things more easily:
SSaaffeettyy p
prreeccaauuttiioonnss
Warnings and information at this symbol serve safety for you and your appliance.
HHiinnttss,, uusseeffuull iinnffoorrmmaattiioonn
EEnnvviirroonnmmeennttaall iinnffoorrmmaattiioonn
TECHNICAL SPECIFICATIONS............................................................................................................................4
SAFETY INSTRUCTIONS ....................................................................................................................................5
Warnings and Guidelines.................................................................................................................................5
INSTALLATION ..................................................................................................................................................5
Position ........................................................................................................................................................5
Electrical connections.....................................................................................................................................6
Switching On.................................................................................................................................................6
HOW TO USE.....................................................................................................................................................6
Temperature Control.......................................................................................................................................6
Opening/Closing the Lid.................................................................................................................................6
Control Panel ................................................................................................................................................6
Freezing .......................................................................................................................................................6
Packaging and Positioning...............................................................................................................................6
Capacity .......................................................................................................................................................6
Lock ............................................................................................................................................................7
Baskets ........................................................................................................................................................7
HELPFUL HINTS ................................................................................................................................................7
Storage ........................................................................................................................................................7
Freezing .......................................................................................................................................................7
Defrosting .....................................................................................................................................................7
Accessories ..................................................................................................................................................7
MAINTENANCE..................................................................................................................................................7
Defrosting .....................................................................................................................................................7
How to Clean Your Freezer .............................................................................................................................7
When Not in Use............................................................................................................................................8
IF SOMETHING DOES NOT WORK......................................................................................................................8
How to Change the Bulb .................................................................................................................................8
SSeerrvviiccee aanndd SSppaarree PPaarrttss
......................................................................................................................................9
EElleeccttrriiccaall CCoon
nnneeccttiioonn
.........................................................................................................................................11
FC 7509 R
220
215
87,6/88,3
79,5
66,5
39
0,948
14
26
80
FC 1459 R
414
404
87,6/88,3
132,5
66,5
56
1,395
19
32
105
FC 1039 R
271
265
87,6/88,3
93,5
66,5
44
1,066
16
27
80
GB
FC 1822 R
514
502
87,6/88,3
160
66,5
66
1,8 14
24
32
130
5
GB
SAFETY INSTRUCTIONS
WARNINGS AND GUIDELINES
These warnings are provided to improve safety, and
should be read carefully before installing or using your
freezer.
IMPORTANT
It is vital that these instructions are kept with the
freezer for future use. If the freezer is sold or given to
another user, or if you move and leave the freezer
behind, you must ensure that the instructions
accompany the freezer to enable the next user to use
the freezer correctly and read the relevant warnings.
This freezer is only intended for the freezing and
storage of food.
This freezer should only be operated by adults.
Children must not be allowed to tamper with the
control buttons or play with the freezer.
Changes in the electrical mains system in connection
with the installation of this freezer should always be
carried out by an authorised electrician or competent
person.
Do not under any circumstances attempt to repair the
freezer yourself. Repairs carried out by untrained
people may result in personal injury or serious
malfunction of the freezer.
Service of the freezer should be carried out by an
authorised service company, and only original spare
parts should be used. See under “Guarantee
Conditions and Service”.
It is dangerous to alter the freezer specifications, or to
change the freezer in any other way.
Make sure that the freezer is not placed on top of the
mains cable.
Do not re-freeze food once it has been defrosted.
Observe the recommendations for storage carefully.
See under “Helpful Hints”.
This freezer includes components that are heated
during operation. Consequently, adequate ventilation
must always be provided. If ventilation is insufficient
defects may occur, resulting in the loss of food. See
under “Installation”.
The inside of the freezer contains pipes through which
coolant flows. If these pipes are punctured the freezer
may be damaged beyond repair, and food may be
lost. Do not use sharp implements to remove frost or
ice. Frost can be removed using the enclosed
scraper. Do not knock ice off the sides of the freezer,
but remove it by defrosting the freezer. See under
“Maintenance”.
Do not place drinks in the freezer. Bottles and cans
containing carbonic acid or sparkling drinks are
particularly prone to explosion, which may damage
the freezer.
This freezer is heavy. Take care when moving it.
If the freezer is fitted with a lock to prevent tampering
by children, the key must always be kept safely out of
the reach of children, and far away from the freezer.
Before disposing of an old freezer, make sure that the
lock (if present) no longer works. This is to prevent
accidents and avoid the danger of children getting
locked inside.
Ice lollies can cause frostbite if eaten direct from the
freezer.
Make sure that the power plug is not squashed
or damaged by the back of the fridge/freezer.
- A damaged power plug may overheat and cause a
fire.
Do not place heavy articles or the fridge/freezer
itself on the power cord.
- There is a risk of a short circuit and fire.
Do not remove the power cord by pulling on its
lead, particularly when the fridge/freezer is
being pulled out of its niche.
- Damage to the cord may cause a short-circuit, fire
and/or electric shock.
- If the power cord is damaged, it must be replaced
by a certified service agent or qualified ser vice
personnel.
If the power plug socket is loose, do not insert
the power plug.
- There is a risk of electric shock or fire.
REFRIGERANT
Your appliance contains an environmental friendly
natural gas, isobutane (R600a) as refrigerant,
which is nevertheless flammable.
During transportation and installation of the
appliance, be sure that none of the components of
the cooling circuit become damaged.
If any part of the cooling circuit damaged:
- avoid naked flames and sources of ignition;
- thoroughly ventilate the room in which the
appliance is installed.
The symbol on the product or on its packaging
indicates that this product may not be treated as
household waste. Instead it shall be handed over to the
applicable collection point for the recycling of electrical
and electronic equipment. By ensuring this product is
disposed of correctly, you will help prevent potential
negative consequences for the environment and human
health, which could otherwise be caused by
inappropriate waste handling of this product. For more
detailed information about recycling of this product,
please contact your local city office, your household
waste disposal service or the shop where you purchased
the product.
INSTALLATION
POSITION (1)
Place the freezer horizontally on a firm surface,
resting on all four plastic feet. Use a wooden block or
similar object to compensate for any bumps/holes in
the surface.
The room should be dry and adequately ventilated.
6
GB
Temperatures of the external environment have an
impact on the energy consumption of the device.
Therefore:
-do not put the device to a place exposed to
sunshine ore besides a radiator or oven,
-put it to a place where the temperature of the
environment corresponds to the climatic
classification for which the device was designed.
Climatic classification Ambient temperature limits
SN from +10°C to +32°C
N from +16°C to +32°C
ST from +18°C to +38°C
T from +18°C to +43°C
If the freezer has been handled standing on end it
should be allowed to stand in normal position for
about 12 hours before switching it on.
Please ensure that when the appliance is installed it
is easily accessible for the engineer in the event of a
breakdown.
SWITCHING ON (2)
Before switching on, the freezer should be cleaned
inside. See under “Maintenance”.
Set the thermostat button in middle position. Allow the
freezer to run for several hours before placing food inside.
ELECTRICAL REQUIREMENTS
Before switching on, make sure that the voltage of your
electricity supply is the same as that indicated on the
rating plate, located inside the lid.
this appliance complies with the following EC
Directives:
- 73/23/EEC of 19. 02. 1973 - Low-Voltage Directive
- 89/336/EEC of 03. 05. 1989 (including Amendment
Directive 92/31/EEC - EMC Directive.
Some of the models are not available in all countries.
Testing has been carried out in accordance with ISO
5155 regarding the determination of freezer capacity,
energy consumption and hold-overtime.
Information for test institute: A plan of the positioning of
test packages may be obtained directly from the
manufacturer.
HOW TO USE
TEMPERATURE CONTROL (3)
The thermostat ensures that the required
temperature is maintained in the freezer. Adjust the
temperature by turning the button with a coin that fits the
groove. Turning the thermostat button towards „MAX”
makes the temperature in the freezer colder, and turning the
button towards „min” makes the temperature warmer. The
correct setting can be found by measuring the temperature
of the top package in the middle of the freezer. This should
not have a temperature higher than -18°C.
OPENING/CLOSING THE LID
The lid is fitted with a tightly closing sealing strip to
prevent moisture getting inside the freezer and
increasing the amount of frost formed.
When the lid is opened the air inside the freezer
becomes slightly warmer and expands.
As soon as the lid is closed again the air is cooled
immediately.
This may lead to the creation of a vacuum which makes it
hard to open the lid immediately after it has been closed.
This is quite normal.
Wait a few minutes until the vacuum has disappeared,
then open the lid by pulling gently. Never pull the handle
violently.
CONTROL PANEL (4)
The green light is illuminated as long as the freezer
is connected.
The yellow light is illuminated when the “Super” button is
depressed. See under “Freezing”.
The red light is illuminated when the temperature in the
freezer is higher than the thermostat setting (alarm).
1. Thermostat button
2. Green light
3. Red light
4. Yellow light
5. “SUPER”
The red alarm light can be due to:
Insertion of a large amount of fresh food. The red
alarm light will go out after a while.
Opening the lid too long. The red alarm light will go
out after a while.
A defect in the system. See under “If something does
not work”.
FREEZING
It is important that fresh food placed in the freezer
is frozen quickly, and that the food already in the
freezer is heated as little as possible in this connection.
If more than 3-4 kg of food is to be frozen:
Press the square “Super” button (yellow light comes
on). The freezer will now run continuously, creating a
sufficient reserve of the temperature required.
Press the “Super” button 6-24 hours before placing
fresh food in the freezer, depending on how much
food is to be frozen.
Place the food in the freezer and leave the “Super”
button on for about 24 hours more.
Then press the “Super” button again (yellow light
goes off). The freezer will return to normal storage
temperature. If you forget to press the “Super” button
again, the freezer will not be damaged by running at
the “Super” setting for some time - but energy will be
wasted.
HOW TO USE
PACKAGING AND POSITIONING
Food must be cold before freezing (no more than
room temperature).
Food must be packed in airtight and moisture-proof
packaging to prevent it from drying out.
7
GB
Place fresh food for freezing close to the cold sides
of the freezer, making sure that it is not in contact with
the frozen food already in the freezer.
Never fill the freezer to more than 5 mm below the top
edge.
See under “Helpful hints”.
CAPACITY (5)
The freezing capacity of the freezer is stated in the data
plate (kg/24 hours). Do not exceed the amount stated - if
you do, the freezing time will be extended. The data plate
is located inside the lid.
IMPORTANT
The freezing capacity stated can be utilised to the
full occasionally to freeze large amounts of fresh
food. However, if the freezer is filled with large
amounts of food for freezing every day, the capacity
stated is reduced by about one-third.
LOCK (6)
(Not a standard accessory for all models.) The lock works
as shown in the drawings. Remember to keep the key out
of the reach of children.
BASKETS (7)
The baskets are designed for the storage of food which
has already been frozen. The handles can be placed in
two positions, as shown in the drawings.
The baskets can either be placed inside the freezer or
hung on the edge of the casing.
HELPFUL HINTS (9)
STORAGE
Frozen food can be stored anywhere inside the
freezer, but should be kept at least 5 mm below the
top edge. Never exceed the maximum storage time for
purchased frozen food. When you buy frozen food, make
sure that it has been stored at the correct temperature. Do
not buy products which have wet or damaged packaging.
Place purchased products in your freezer as quickly as
possible. We recommend using an insulated bag to bring
such products home with you. Never place bottles, warm
objects, or fizzy drinks in the freezer.
FREEZING
Only use fresh food of the best quality. Cool hot
dishes to room temperature as quickly as possible
before placing them in the freezer. Wrap food carefully in
freezer foil, or use the special freezer boxes or bags which
are on the market. Divide food into small portions before
freezing - this ensures that freezing is more rapid, and
means that you only need to defrost the amount needed
for immediate consumption. Remember that defrosted
food must not be re-frozen. However, dishes which have
been made using defrosted food may be frozen. Mark the
freezer packaging with the date of freezing. We
recommend keeping a record of the contents of your
freezer. If freezing is too slow, the quality of the food being
frozen deteriorates. Consequently, do not freeze larger
amounts than stated in the freezer’s data plate. If you wish
to freeze food several days in a row, the maximum freezing
capacity stated per day is reduced by about one-third. As
far as possible, keep the lid closed during freezing. If you
know nothing about home freezing, we recommend that
you purchase a book containing advice and guidelines.
DEFROSTING
In general food should not be defrosted at room
temperature, since this increases the risk of
bacteria growth. It is best to defrost large portions of
meat or poultry in the refrigerator, and this also applies to
food which is to be consumed as it is (e.g. fruit, butter
and sliced meat). Small portions of food can be cooked
straight from the freezer. A good number of ready-to-cook
dishes can also be cooked without defrosting. Always
observe the instructions on product packaging. Bread
tastes good when defrosted in a moderate oven.
Microwave ovens can be used for the rapid defrosting of
most frozen foods. Observe the instructions for use of
the microwave oven concerned.
ACCESSORIES
Spare baskets can be obtained from your local
Service Centre.
MAINTENANCE
DEFROSTING (8)
The formation of frost on the inside of freezers cannot be
avoided. Frost is formed when moisture contained in the
air comes into contact with the cold surfaces of the
freezer.
Consequently, the lid should only be opened when
necessary, and it should never be left open.
A thin layer of ice or frost does not affect the function of
the freezer adversely, and can be removed carefully
using the scraper provided.
IMPORTANT
Never use a knife or any other sharp implement to
remove frost.
When the frost or ice layer is 10-15 mm thick, the freezer
should be defrosted. We suggest that you defrost your
freezer when there is little or no food inside.
Switch off the current. Remove the contents of the
freezer, wrap them in newspapers, and leave them in a
cold place.
The speed of defrosting can be increased by placing one
or more bowls of hot (not boiling) water inside the freezer
and closing the lid. Open the lid after a while, and remove
the layer of ice carefully.
The defrost water can be collected in a bowl as shown in
the drawing.
Do not try to speed up defrosting by using anything other
than hot water, since this may damage the freezer. After
defrosting, clean the inside of the freezer.
IMPORTANT
Remember to replace the plug in the drip water drain.
8
GB
HOW TO CLEAN YOUR FREEZER INSIDE
Remove the plug from the mains socket, and remove all
loose accessories before cleaning the freezer.
The best time to clean your freezer is after defrosting and
before the electricity supply is connected again.
Use a damp cloth to clean your freezer. Use hot water,
and a mild, non-aromatic cleaning agent.
After cleaning the freezer, clean the basket/baskets
before replacing them.
IMPORTANT
Never use strong cleaning agents, scouring powder
or strongly aromatic cleaning agents to clean your
freezer inside, since this will damage the inside and
leave a strong smell.
If you are still unable to solve the problem, summon the
assistance of authorised service staff.
Do not take any other steps. Incorrect procedure may
cause personal injury or lead to additional defects.
It is quite normal for the freezer to seem warm on the
outside occasionally, owing to the heat generated by the
freezing process. This heat also helps to prevent the
formation of moisture on the outside of the appliance
which could cause rust.
If the freezer has been switched off briefly, the
compressor may not start immediately when the current
is re-connected. This is quite normal.
IN THE CASE OF A POWER FAILURE OR
BREAKDOWN
The hold-over period mentioned in the "Technical
Specification" section of this book refers to an estimated
time the freezer temperature will take to rise to an
unacceptable level for keeping frozen foods.
Providing the period of power failure or breakdown does
not exceed the hold-over period there will be no risk of
damage to the frozen food, providing you do not open the
lid during this period.
If the freezer is only half full or the lid is opened this will
reduce the hold-over time.
After the breakdown period you are recommended to
check the condition of food to ensure it has not started to
thaw. Frozen food must NOT be re-frozen once it has
thawed out. The following guidelines should assist you.
Ice cream: Once thawed should be
discarded.
Fruits & Vegetables: If soft should be cooked and used
up.
Breads & Cakes: Can be re-frozen without danger.
Shellfish: Should be refrigerated and used
up quickly.
Cooked Dishes: ie. casseroles should be
refrigerated and used up.
Small Joints: Should be cooked and can then
be re-frozen as cooked dishes.
Chicken: Should also be cooked and re-
frozen as a cooked dish.
HOW TO CHANGE THE BULB (10)
Before changing the bulb, isolate the appliance from the
electricity supply.
Unscrew the bulb, and replace it with a new bulb (max.
15W). Then reconnect the electricity supply.
Defect:
Freezer not
cold enough
Freezer too
cold
Too much frost
formed
Check if:
Green light not on
Green and red light on
Green light on, red light
not on
Yellow light on
Yellow light not on
Lid does not close
completely
Lot of moisture in the
room
Goods packed poorly
Possible cause:
Plug not connected correctly
Defect in switch or fuse
Power failure
Fresh food recently placed in freezer
Lid open too long
Thermostat set too warm
Lot of frost and ice formed
“Super” function active
Thermostat set too cold
Lid in contact with goods in freezer
Moisture from washing machine,
tumble-dryer, etc.
Lot of moisture from goods
Action:
Check plug and socket
Check fuse, call electrician
Wait until current returns
Wait a couple of hours
Wait a couple of hours
Set thermostat colder
Defrost freezer
Press “Super” button out
Set thermostat warmer
Re-arrange goods, check that lid closes
correctly
Move freezer to a room with less
moisture, or air regularly
Re-pack goods, see under “How to
use”
EXTERNAL CLEANING
Wash the outer cabinet with warm soapy water. Do NOT
use abrasive products.
WHEN NOT IN USE
Disconnect the appliance from the electricity supply.
Remove all goods from the freezer.
Clean the freezer as described above.
Leave the lid slightly open.
IF SOMETHING DOES NOT
WORK
IF YOUR FREEZER DOES NOT
FUNCTION SATISFACTORILY
Check the following before calling for service staff:
9
GB
SSEERRVVIICCEE AANNDD SSPPAARREE PPAARRTTSS
In the event of your appliance requiring service, or if you wish to purchase spare parts, please contact you local
Electrolux Service Force Centre by telephoning:
00887700 55 992299992299
Your telephone call will be automatically routed to the Service Force Centre covering your post code area. For the
address of your local Service Force Centre and further information about Service Force please visit the website at
www.serviceforce.co.uk.
CCUUSSTTOOMMEERR CCAARREE DDEEPPAARRTTMMEENNTT
For general enquiries concerning your Electrolux appliance or for further information on Electrolux products, you are
invited to contact our Customer Care Department by letter or telephone at the address below or visit the website at
www.electrolux.co.uk:
Customer Care Department
Electrolux
55-77 High Street
Slough
Berkshire
SL1 1DZ
Tel: 08705 950 950*
* calls to this number may be recorded for training purposes
10
GGUUAARRAANNTTEEEE CCOONNDDIITTIIOONNSS
We, Electrolux undertake that if within 12 months of the date of the purchase this Electrolux appliance or any part
thereof is proved to be defective by reason only of faulty workmanship or materials, the company will, at our option
repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that:
The appliance has been correctly installed and used only on the electrical supply stated on the rating plate.
The appliance has been used for normal domestic purposes only, and in accordance with the manufacturer's
instructions.
The appliance has not been serviced, maintained, repaired, taken apart or tampered with by any person not
authorised by us.
All service work under this guarantee must be undertaken by a Electrolux Service Force Centre.
Any appliance or defective part replaced shall become the Company's property.
Home visits are made between
88..3300aamm
and
55..3300ppmm MMoonnddaayy ttoo FFrriiddaayy..
Visits may be available outside these hours in
which case a premium will be charged.
EEXXCCLLUUSSIIOONNSS
TThhiiss GGuuaarraanntteeee ddooeess nnoott ccoovveerr::
Damage or calls resulting from transportation, improper use or neglect, the replacement of any light bulbs or removable
parts of glass or plastic.
Costs incurred for calls to put right an appliance improperly installed or calls to appliances outside the United
Kingdom.
Appliances found to be in use within a commercial environment, plus those which are the subject of rental
agreements.
Products of Electrolux manufacture which are not marked by Electrolux.
This guarantee is in addition to your statutory and legal rights.
EELLEECCTTRROOLLUUXX EEUURROOPPEEAANN GGUUAARRAANNTTEEEE
If you should move to another country within Europe then your guarantee moves with you to your new home subject to
the following qualifications:
The guarantee starts from the date you first purchased your product.
The guarantee is for the same period and to the same extent for labour and parts as exists in the new country of
use for this brand or range of products.
This guarantee relates to you and cannot be transferred to another user.
Your new home is within the European Community (EC) or European Free Trade Area
The product is installed and used in accordance with our instructions and is only used domestically, i.e. a normal
household.
The product is installed taking into account regulations in your new country.
Before you move please contact your nearest Customer Care Centre, list below, to give them details of your new home.
They will then ensure that the local Service Organisation is aware of your move and able to look after you and your
appliances.
France Senlis +33 (0)3 44 62 22 22
Germany Nurenberg +49 (0)911 323 2600
Italy Pordenone +39 (0)1678 47053
Sweden Stockholm +46 (0)20 78 77 55
UK Slough +44 (0)1753 219 898
GB
11
Any electrical work required to install this
appliance should be carried out by a qualified
electrician or competent person.
This appliance must be earthed.
The manufacturer declines any liability should these
safety measures not be observed.
Electrical Requirements
Before switching on, make sure the electricity supply
voltage is the same as that indicated on the appliance
rating plate.
The appliance is supplied with a 13amp plug fitted. In
the event of having to change the fuse in the plug
supplied, a 13amp ASTA approved (BS1362) fuse must
be used.Should the plug need to be replaced for any
reason. The wires in the mains lead are coloured in
accordance with the following code:
Green and Yellow: Earth
Blue: Neutral
Brown: Live
The wire coloured green and yellow must be connected
to the terminal marked with the letter "E" or by the earth
symbol or coloured green and yellow.
The wire coloured blue must be connected to the
terminal "N" or coloured black.
The wire coloured brown must be connected to the
terminal marked "L" or coloured red.
Upon completion there must be no cut, or stray strands
of wire present and the cord clamp must be secure
over the outer sheath.
EELLEECCTTRRIICCAALL CCOONNNNEECCTTIIOONN
GB
GREEN & YELLOW
BLUE
P1041
E
N
13 A
L
BROWN
CORD CLAMP
2006. 01. 03.
Printed by Océ-Hungária Kft.
Loading...
