OPERATING AND INSTALLATION MANUAL

820 41 70 601293305

FC 100

CHEST FREEZER

TECHNICAL SPECIFICATIONS ........................ ............................................................................................................2 page

SAFETY INSTRUCTIONS .......................................... ....................................................................................................3 page

Warnings and Guidelines Refrigerant Disposal

INSTALLATION ................................................................................................................................................................4 page

Position Electrical connections Switching On

HOW TO USE ....................................... ...........................................................................................................................5 page

Temperature Control Opening/Closing the Lid Control Panel Freezing Packaging and Positioning Capacity Baskets

HELPFUL HINTS ................................................................................................................. ............................................6 page

Storage Freezing Defrosting

MAINTENANCE ................................................................................................................... ............................................6 page

Defrosting How to Clean Your Freezer When Not in Use

IF SOMETHING DOES NOT WORK .............................. ...............................................................................................7 page

GUARANTEE CONDITIONS & SERVICE ............................. ........................................................................................8 page

CONTENTS

TECHNICAL SPECIFICATIONS

Model FC 100

Volume (gross) litres 105 Volume (net) litres 102 Height with roller cm 86,1 Width cm 55 Depth cm 55 Weight kg 33 Energy consumpt./24h kWh 0,76 Freezing capacity kg/24h 10 Hold-over time hours 18 Rated power W 60

this appliance complies with the following EC Directives:

- 73/23/EEC of 19. 02. 1973 - Low-Voltage Directive

- 89/336/EEC of 03. 05. 1989 (including Amendment Directive 92/31/EEC - EMC Directive. Some of the models are not available in all countries. Testing has been carried out in accordance with ISO 5155 regarding the determination of freezer capacity, energy consumption and hold-overtime. Information for test institute: A plan of the positioning of test packages may be obtained directly from the manufacturer.

WWAARRNNIINNGGSS AANNDD GGUUIIDDEELLIINNEESS

These warnings are provided to improve safety, and should be read carefully before installing or using your freezer.

This freezer is only intended for the freezing and storage of food.

This freezer should only be operated by adults. Children must not be allowed to tamper with the control knobs or play with the freezer.

Changes in the electrical mains system in connection with the installation of this freezer should always be carried out by an authorised electrician or competent person.

Do not under any circumstances attempt to repair the freezer yourself. Repairs carried out by untrained people may result in personal injury or serious malfunction of the freezer.

Service of the freezer should be carried out by an authorised service company, and only original spare parts should be used. See under Guarantee Conditions and Service.

It is dangerous to alter the freezer specifications, or to change the freezer in any other way.

Make sure that the freezer is not placed on top of the mains cable.

Do not re-freeze food once it has been defrosted. Observe the recommendations for storage carefully. See

under Helpful Hints. This freezer includes components that are heated during

operation. Consequently, adequate ventilation must always be provided. If ventilation is insufficient defects may occur, resulting in the loss of food. See under Installation.

The inside of the freezer contains pipes through which coolant flows. If these pipes are punctured the freezer may be damaged beyond repair, and food may be lost. Do not use sharp implements to remove frost or ice. Frost can be removed using the enclosed scraper. Do not knock ice off the sides of the freezer, but remove it by defrosting the freezer. See under Maintenance.

Do not place drinks in the freezer. Bottles and cans containing carbonic acid or sparkling drinks are particularly prone to explosion, which may damage the freezer.

This freezer is heavy. Take care when moving it. If the freezer is fitted with a lock to prevent tampering by

children, the key must always be kept safely out of the reach of children, and far away from the freezer.

Before disposing of an old freezer, make sure that the lock (if present) no longer works. This is to prevent accidents and avoid the danger of children getting locked inside.

Ice lollies can cause frostbite if eaten direct from the freezer.

RREEFFRRIIGGEERRAANNTT

Your appliance contains an environmental friendly natural gas, isobutane (R600a) as refrigerant, which is nevertheless flammable.

During transportation and installation of the appliance, be sure that none of the components of the cooling circuit become damaged.

If any part of the cooling circuit damaged:

 avoid naked flames and sources of ignition;  thoroughly ventilate the room in which the

appliance is installed.

DDIISSPPOOSSAALL

Appliance Packaging Information

All materials are environmentally sound! They can be dumped or burned at an incinerating plant without danger!

About the materials: The plastics can be recycled and are identified as follows:

>PE< for polyethylene, e.g. the outer covering and the bags in the interior.

>PS< for polystyrene foam, e.g. the pads, which are all free of chlorofluorocarbon.

The carton parts are made from recycled paper and should be disposed of at a waste-paper recycling collection location.

Disposal of old Appliances

For environmental reasons, refrigaration appliances must be disposed of properly. This applies to your old appliance, and -at the end of its service life- for your new appliance as well.

Warning!

Before disposing of old appliances make them inoperable. Remove plug from mains, sever the power cable, remove or destroy any snap or latch closures. This eliminates the danger that playing children lock themselves into the appliance (danger of suffocation!) or place themselves into other life-endangering situations.

Disposal

The appliance may not be disposed of with domestic waste or bulky refuse.

The refrigerating circuit may not be damaged. Information concerning collection schedules or

locations can be obtained from the disposal authorities or town hall.

SAFETY INSTRUCTIONS

IMPORTANT It is vital that these instructions are kept with the freezer for future use. If the freezer is sold or given to another user, or if you move and leave the freezer behind, you must ensure that the instructions accompany the freezer to enable the next user to use the freezer correctly and read the relevant warnings.
