DESCRIPTION OF COMPONENTS
Figure 1
AIR FILTER
MOIST AIR
INTAKE
CONTROL PANEL
920-198-10
DEHUMIDIFIED
DRY AIR VENT
HANDLE
DRAIN BUCKET
FUNCTION EXPLANATION
Figure 2
BUCKET FULL LAMP
LAMP LIGHTS WHEN
DRAIN BUCKET IS
FULL AND NEEDS TO
BE EMPTIED.
FAN SPEED
HIGH/LOW
POWER
ON/OFF
DEFROST LAMP
LAMP LIGHTS WHEN UNIT IS
DEFROSTING (SEE PAGE 5).
TIMERS
WHEN THE UNIT IS ON PRESS THE
TIMER BUTTON TO DISPLAY THE
POWER OFF TIMER.
SELECT FROM 1-24 HOURS OF
RUNNING TIME UNTIL THE UNIT
SHUTS OFF AUTOMATICALLY.
WHEN THE UNIT IS OFF PRESS THE
TIMER BUTTON TO DISPLAY THE
POWER ON TIMER. SELECT FROM
1-24 HOURS UNTIL THE UNIT WILL
TURN ON AUTOMATICALLY.
ROLL CASTERS
DRAIN PUMP OUTLET
(ONLY ON 50 AND 70 PINT MODELS)
CURRENT TEMP / TIMER SET DISPLAY
WHEN THE UNIT IS RUNNING THE CURRENT TEMP IS DISPLAYED.
WHEN THE TIMER BUTTON IS PRESSED THIS WINDOW DISPLAYS
THE TIMER SETTING THEN REVERTS BACK TO THE TEMPERATURE
AFTER 10 SECONDS.
CURRENT HUMIDITY DISPLAY
DISPLAYS THE CURRENT
RELATIVE HUMIDITY (RH) IN
THE ROOM. WHEN THE OR
IS PRESSED THE HUMIDITY
SETTING IS DISPLAYED.
SET HUMIDITY
ADJUST THE HUMIDITY % FROM
30% TO 90% RH BY PRESSING THE
OR BUTTONS. HUMIDITY IS
ADJUSTED IN 5% INCREMENTS.
CONTINUOUS
DRAINAGE OUTLET
°C/°F SELECTOR
PRESS THE °C/°F
SWITCH BUTTONS
IT WILL SWITCH
BETWEEN °C AND °F.
FRD001
FRD002
3
www.sylvane.com 1-800-934-9194
920-198-10
INSTALLATION INSTRUCTIONS
Follow the steps below for unpacking and set up your unit.
STEP 1. Remove unit from carton and inspect.
STEP 2. Remove accessories from drain bucket.
STEP 3. Install Roll Casters (D25D models only) per installation
instructions below.
STEP 4. Set up unit in position with adequate clearance. Installation
of unit is complete.
Roll Caster Installation (D25D Models only)
STEP 1. Locate Roll Casters removed during STEP 2 above.
STEP 2. Lay unit on its side for ease of installation.
STEP 3. Insert Roll Casters in slots as shown (See Figure 3) until they
click into place.
Figure 3
ROLL CASTER
OPERATION INSTRUCTIONS
WARNING
Electrical Hazards
Do not fold power cord as shown at left.
Make sure the plug is placed fully and
firmly into the receptacle.
Do not use multiple sockets as shown at
left.
FRD031
STEP 4. Set the unit upright. Roll Caster installation is complete.
STEP 5. Allow unit to sit upright 1 hour before operating.
Allow 8 inches of space on all sides of the unit.
Figure 4
8’’
8’’
8’’
4
8’’
FRD032
Make sure the plug is clean.
After turning the unit off please take plug
out of the receptacle.
Do not have wet hands when connecting
the power plug.
Do not pull the power cord to avoid a
broken cord, which can lead to danger.
www.sylvane.com 1-800-934-9194
920-198-10
Start Operation
STEP 1. Place the unit in an upright position on a at, steady, stable and
heat resistant surface. Make sure there is nothing ammable
or heat sensitive within 39 inches. Operating the product in
any other position could cause a hazard.
WARNING
Electrical Shock Hazard
Make sure your electrical receptacle has the
same configuration as your dehumidifier’s
plug. If different, consult a Licensed Electrician.
Do not use plug adapters.
Do not use an extension cord.
Do not remove ground prong.
Always plug into a grounded 3 prong oulet.
Failure to follow these instructions can result in
death, fire, or electrical shock.
STEP 2. Insert the plug into a suitable wall
socket. The dehumidier is suitable
for operation on an electricity supply
having the same voltage as that
shown on its rating label.
STEP 3. Make sure the Drain Bucket is correctly placed in the proper
position (See Figure 5). (After switching the unit 'ON" for the
rst time, if the Bucket Full lamp illuminates, just pull out
the drain bucket; check to ensure that the oat lever is able
to move freely, then return the drain bucket to the correct
position).
When Bucket Full Lamp Is On
When the drain bucket is full, the Bucket Full lamp will illuminate and the
unit will stop operating. The drain bucket should be carefully removed from
the unit by sliding it outwards (See Figure 6) and should be emptied. Then
place the empty drain bucket back to its proper position, (See Figure 7)
the unit will start operating and run normally.
Figure 6
PLEASE USE BOTH HANDS
TO CAREFULLY EMPTY THE
DRAIN BUCKET.
FRD005
Defrost
When the unit is operated in low temperatures (les s than 54 °F
the surface of the evaporator will accumulate a layer of frost which will
reduce the efciency of the dehumidier. When this happens the unit will go
into periodic defrost mode automatically. The Defrost Lamp will illuminate
on control panel, this is quite normal (See Figure 7).
The dehumidier will operate in temperatures down to 41 °F. The time it
takes to defrost may vary. If the unit freezes up it should be turned off at the
power supply for a few hours and then re-started. If the room temperature
remains below 41 °F the unit should be switched off. It is not recommended
to use the dehumidier in temperatures below 41 °F.
Figure 5
BUCKET FULL LAMP
DRAIN BUCKET
FRD004
Figure 7
DEFROST LAMP
DRAIN BUCKET
FRD006
5
www.sylvane.com 1-800-934-9194
920-198-10
OPERATING DO'S AND DON'TS
Do not place anything on top of the unit or control panel (See Figure 8).
Figure 8
FRD007
Do not place anything over the inlet or outlet points (See Figure 9).
Figure 9
Do not use insect, oil or paint spray around the unit (See Figure 11), it might
cause damage to the plastic parts or start a re.
Figure 11
FRD014
Do not place the unit on an uneven surface (See Figure 12), to avoid
shaking, noise and leakage of water.
Figure 12
Do not wet the unit or the control panel (See Figure 10).
Figure 10
FRD008
FRD010
FRD015
Do always keep the unit 8 in. away from the wall (See Figure 13) to dissipate
the heat properly.
Figure 13
8.00 IN.
FRD016
6
www.sylvane.com 1-800-934-9194
920-198-10
Do not put any foreign objects into the unit, it is dangerous and will result
in damage to the unit (See Figure 14).
Figure 14
FRD017
Do close all open windows to reach the maximum possible efciency of
dehumidier removing moisture (See Figure 15).
When moving or putting unit in storage, do not place the unit on its side or
upside down and avoid violent shaking (See Figure 16).
Figure 16
FRD020
Do ask professional service technicians to service the unit as required
(See Figure 17).
Figure 17
Figure 15
FRD012
FRD018
7
www.sylvane.com 1-800-934-9194
920-198-10
CONTINUOUS DRAINAGE
To save having to periodically empty the drain bucket, this unit can be
congured for continuous drainage. You can use the supplied drain hose
to connect to the continuous drainage connector (See Figure 18).
Figure 18
BACK OF UNIT
DRAIN HOSE
DRAIN COVER
FRD021
Unscrew and remove the drain cover at the rear of the unit (See Figure 19).
Remove the soft rubber stopper. Put it into the drain bucket for safe keeping
(See Figure 19).
Figure 19
Insert the drain hose through the hole of the drain cover. Then connect the
drain hose to the drain port (See Figure 20).
Figure 20
BACK OF UNIT
DRAIN HOSE
DRAIN COVER
FRD023
Tighten the drain cover in clockwise direction onto the rear of the unit
(See Figure 21).
Figure 21
BACK OF UNIT
BACK OF UNIT
SOFT RUBBER STOPPER
DRAIN COVER
FRD022
DRAIN COVER
DRAIN HOSE
FRD024
Place the bucket in its original location (See Figure 22).
Figure 22
PUSH THE DRAIN BUCKET
BACK INTO THE UNIT IN THE
DIRECTION THE ARROW IS
POINTING.
DRAIN
BUCKET
DRAIN HOSE
8
FRD025
www.sylvane.com 1-800-934-9194
920-198-10
Drain Hose Routings
When using the function of continuous drainage, the drain hose must be
placed horizontally below the drainage hole (See Figure 23).
You must avoid uneven ground and folding the hose (See Figure 23).
Figure 23
Continuous Draining using the Pump
(D50D/D70D models only)
Installation:
STEP 1. Connect the attached continuous drainage adaptor (1) to the
drain hole on the rear panel (2).
STEP 2. Connect the supplied water hose to the plug that ts into the
drain hole.
STEP 3. Lead the other end to a suitable location for drainage, like a
drain or sink and insert the plug into the water drain.
The maximum distance and the rise may be 15 ft from the unit. Exceeding
this distance may damage the unit or cause leaks. When the unit’s drain
bucket capacity reaches a certain water level, it will drain automatically
(See Figure 24).
Dismantle:
Press the drain hole (3) on the unit rear panel. The automatic drainage
adaptor will pull out (See Figure 24).
Figure 24
3
FRD026
1
2
SUPPLIED
WATER
HOSE
PLUG
FRD027
NOTICE
In the automatic mode, the condensed moisture
is always removed through the air exhaust hose.
Removing the rubber plug from the water drain
will allow the water to drain out at this point. The
water drain can not be used.
9
www.sylvane.com 1-800-934-9194
920-198-10
MAINTENANCE
WARNING
Electrical Shock Hazard
Make sure your electrical receptacle has the
same configuration as your dehumidifier’s
plug. If different, consult a Licensed Electrician.
Do not use plug adapters.
Do not use an extension cord.
Do not remove ground prong.
Always plug into a grounded 3 prong oulet.
Failure to follow these instructions can result in
death, fire, or electrical shock.
For safety reasons, make sure the unit is
unplugged before servicing or cleaning.
Cleaning the shell
Cleaning Steps
STEP 1. Pull the air lter out gently (See Figure 25).
Figure 25
AIR FILTER
FRD029
STEP 2. Clean the air lter with a vacuum cleaner or wash it with clean
water and dry with a dry cloth (See Figure 26).
STEP 1. Wipe the shell with a clean, soft cloth.
STEP 2. If the unit is very dirty, use mild detergent then wipe off the
detergent with half dried cloth.
WARNING
Water Hazard
Do not wash the unit with a hose
or immerse it in water. This may
cause leakage of electricity or a
shock hazard.
Cleaning the air lter
The purpose of the air lter is to lter dust and other materials from the
air. If the lter is blocked by dust the electricity usage will be greater than
normal. For optimal moisture removal and efciency, clean the lter every
two weeks.
Figure 26
FRD030
STEP 3. Put the clean air lter back in place and continue to operate
the dehumidier.
10
www.sylvane.com 1-800-934-9194
IN CASE OF EMERGENCY
If a problem occurs, unplug the unit and contact a qualied servicing center
immediately. Do not disassemble the unit yourself.
NOTICE
If the power cord on this unit is damaged it must
be replaced by the manufacturer, its service agent
or qualified service technician in order to avoid a
hazard.
NOTICE
This appliance is not intended for use by childern
or other persons without assistance or supervision
if their physical, sensory or mental capabilities
prevent them from using it safely. Children should
be supervised to ensure that they do not play with
the appliance.
920-198-10
11
www.sylvane.com 1-800-934-9194
920-198-10
Friedrich Air Conditioning Company
P.O. Box 1540
San Antonio, TX 78295
210.357.4400
www.friedrich.com
DEHUMIDIFIERS
LIMITED WARRANTY
FIRST YEAR
ANY PART: If any part supplied by FRIEDRICH fails because of a defect in workmanship or material within twelve months from
date of original purchase, FRIEDRICH will repair the product at no charge, provided the product is transported to a Friedrich
Authorized Service Center for repair. ALL transportation charges are the sole responsibility of the owner. This remedy is expressly
agreed to be the exclusive remedy within twelve months from the date of the original purchase.
SECOND THROUGH FIFTH YEAR
SEALED REFRIGERANT SYSTEM: If the Sealed Refrigeration System (dened for this purpose as the compressor, condenser
coil, dehumidifying coil, capillary, lter drier, and all interconnecting tubing) supplied by FRIEDRICH in your dehumidier fails
because of a defect in workmanship or material within sixty months from date of purchase, FRIEDRICH will pay a labor allowance
and parts necessary to repair the Sealed Refrigeration System; PROVIDED FRIEDRICH will not pay the cost of diagnosis of the
problem, removal, freight charges, and transportation of the dehumidier to and from the Service Agency, and the reinstallation
charges associated with repair of the Sealed Refrigeration System. All such cost will be the sole responsibility of the owner. This
remedy is expressly agreed to be the exclusive remedy within sixty months from the date of the original purchase.
APPLICABILITY AND LIMITATIONS: This warranty is applicable only to units retained within the Fifty States of the U.S.A.,
District of Columbia, and Canada. This warranty is not applicable to:
1. Air lters or fuses.
2. Products on which the model and serial numbers have been removed.
3. Products which have defects or damage which results from improper installation, wiring, electrical current
characteristics, or maintenance; or caused by accident, misuse or abuse, re, ood, alterations and/or misapplication
of the product and/or units installed in a corrosive atmosphere, default or delay in performance caused by war,
government restrictions or restraints, strikes, material shortages beyond the control of FRIEDRICH, or acts of God.
OBTAINING WARRANTY PERFORMANCE: Service will be provided by the FRIEDRICH Authorized Dealer or Service
Organization in your area. They are listed in the Yellow Pages. If assistance is required in obtaining warranty performance, write
to: Room Air Conditioner Service Manager, Friedrich Air Conditioning Co., P.O. Box 1540, San Antonio, TX 78295-1540.
LIMITATIONS: THIS WARRANT Y IS GIVEN IN LIEU OF ALL OTHER WARRANTIES. Anything in the warranty
notwithstanding, ANY IMPLIED WARRANTIES OF FITNESS FOR PARTICULAR PURPOSE AND/OR MERCHANTABILITY
SHALL BE LIMITED TO THE DURATION OF THIS EXPRESS WARRANTY. MANUFACTURER EXPRESSLY DISCLAIMS AND
EXCLUDES ANY LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL DAMAGE FOR BREACH OF ANY EXPRESSED OR
IMPLIED WARRANTY.
NOTE: Some states do not allow limitations on how long an implied warranty lasts, or do not allow the
limitation or exclusion of consequential or incidental damages, so the foregoing exclusions and limitations
may not apply to you.
OTHER: This warranty gives you specic legal rights, and you may also have other rights which vary from
state to state.
PROOF OF PURCHASE: Owner must provide proof of purchase in order to receive any warranty related services.
All service calls for explaining the operation of this product will be the sole responsibility of the consumer.
All warranty service must be provided by an Authorized FRIEDRICH Service Agency, unless authorized
by FRIEDRICH prior to repairs being made.
12
(2-10)
www.sylvane.com 1-800-934-9194
920-198-10
Friedrich Air Conditioning Co.
Post Ofce Box 1540 • San Antonio, Texas 78295-1540
4200 N. Pan Am Expressway • San Antonio, Texas 78218-5212
(210) 357-4400 • FAX (210) 357-4480
www.friedrich.com
Printed in the U.S.A.
13
Loading...
+ hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
