Before Setting
Setting Surface Controls
Oven Control Func
www fdg[daire.com USA 1-800-944-9044
www.frigidaire.ca Canada 1-800-_
Contents
Thank youfor choosing Frigidare.
Product Registration ...................................................... 2
Important Safety Instructions ............................ 3-5
Before Setting Oven Controls .................................. 6
Removing, replacing & arranging the oven racks ........... 6
Before Setting Surface Controls ........................... 1-8
About the ceramic cooktop & radiant elements ............. 7
Cookware material types ............................................ 8
Setting Surface Controls .................................... 9-11
Setting single radiant surface elements ........................ 9
Setting dual radiant surface elements ........................ 10
Home canning ......................................................... 11
Oven Control Functions ......................................... 12
Setting Oven Controls ...................................... 12=15
Setting the clock ...................................................... 12
Changing oven temperature display (F° or C°) ............ 12
Setting minute timer ................................................ 13
Setting bake ........................................................... 13
Setting broil ............................................................ 14
Adjusting oven temperature ..................................... 15
Operating oven light ................................................. 15
Care & Cleaning ............................................... 16-19
Cleaning recommendation table ................................ 16
Cooktop maintenance & cleaning ........................... 17-18
Cautions for aluminum use ....................................... 18
Replacing the oven light ........................................... 18
Removing & replacing oven door ............................... 19
Before You Call
Solutions to common problems ............................. 20-21
Appliance Warranty .............................................. 22
This Use & Care Guide is part of our commitment to customer
satisfaction and product quality throughout the service life of
your new appliance.We view your purchase asthe beginning
of a relationship. To ensure our ability to continue serving you,
please use this page to record important product information.
Need help??
Visit the Frigidaire web site at www,frigidaire.com
Before you call for service, there are a few things you can
do to help us serve your better.
Read this Use & Care manual,
It contains instructions to help you use and maintain your
range properly.
If you received a damaged range ,,,
immediately contact the dealer (or builder) that sold you the
range.
Save time and money.
Check the section titled "Before you call". This section helps
step you through some common problems that might occur.
If you do need service, help is only a phone call away. Call
Frigidaire Customer Services at 1=800=944=9044.
Product Registration
Registering your product with Frigidaire enhances our ability
to serve you. You can register online at
www,frigidaire,com or by dropping your Product
Registration Card in the mail.
2
Serial plate location
i _ i
Serial plate location:
open storage drawer (some models) or
remove lower front panel(some models).
Record model & serial numbers here
Purchase date
Model number
Serial number
@2009 Electrolux Home Products, Inc. All ri0hts reserved. Printed in the USA
Read all instructions before using this appliance,
Do not attempt to install or operate your appliance until you
have read the safety precautions in this manual. Safety
items throughout this manual are labeled with a WARNING
or CAUTION statement based on the risk type.
Definitions
_:_ This isthe safety alert symbol. It is used to alert you to
potential personal injury hazards. Obey all safety messages
that follow this symbol to avoid possible injury or death.
CAUTION indicates a potentially hazardous
situation which, if not avoided, may result in minor
or moderate injury,
IMPORTANT indicates installation, operation,
maintenance or valuable information that is not hazard
related.
Important Safety Instructions
= Remove all tape and packaging before using the
range, Destroy the carton and plastic bags after
unpacking the range. Never allow children to play with
packaging material.
Ask your dealer to recommend a qualified technician and
an authorized repair service. Know how to disconnect the
power to the range at the circuit breaker or fuse box in
case of an emergency.
= All ranges can tip.
= Injuryto persons could result.
= Install anti=tipdevice packed
with range.
= See Installation Instructions.
To reduce the risk of tipping, the
range must be secured by properly
installed anti-tip bracket provided
with the range. To check if the
bracket is installed properly, visually
check that rear leveling leg is
inserted into and fully secured by the
anti-tip bracket by removing lower
front panel or storage drawer from
the range.
For models equipped with a warmer drawer or lower
oven, grasp the top rear edge of the range and carefully
attempt to tilt it forward. Refer to the installation
instructions for proper anti- tip bracket installation.
=Never modify or alter the construction of a range
by removing the leveling legs, panels, wire covers,
anti=tip brackets/screws, or any other part of the
range.
= Remove the oven door from any unused range if it
is to be stored or discarded.
= Proper installation--Be sure your appliance is
properly installed and grounded bya qualified
technician in accordance with the National Electrical
Code ANSI/N FPA No. 70 latest edition and local
electrical code requirements, Install only per
installation instructions provided in the literature package
for this range.
= User servicing=Do not repair or replace any part
of the appliance unless specifically recommended in
the manuals. All other servicing should be done only by a
qualified technician. This may reduce the risk of personal
injury and damage to the range.
Save these instructions for future reference,
Stepping, leaning or sitting on the door or
drawers of a range can result in serious injuries
and also cause damage to the appliance. DO NOT
allow children to climb or play around the range. The
weight of a child on an open oven door may causethe
range to tip, resulting in serious burns or other injury.
Never use your appliance for warming or heating
the room.
Do not use the oven, warmer drawer or lower
oven (if equipped) for storage.
3
= Storage in or on appliance--flammable materials
should not be stored in an oven, warmer
drawer, near surface units or in the storage
drawer, This includes paper, plastic and cloth items,
such as cookbooks, plasticware and towels, as well as
flammable liquids. Do not store explosives, such as
aerosol cans, on or near the range.
• DO NOT LEAVE CHILDREN ALONE--children
should not be left alone or unattended in the
area where appliance is in use. They should never
be allowed to sit or stand on any part of the appliance,
including the storage drawer, lower broiler drawer,
warmer drawer or lower double oven.
= Do not store items of interest to children in the
cabinets above a range or on the backguard of
the range. Children climbing on the range to reach
items could be seriously injured.
= Do not use water or flour on grease fires=
smother the fire with a pan lid, or use baking soda,
a dry chemical or foam=type extinguisher.
= When heating fat or grease, watch it closely. Fat
or grease may catch fire if allowed to become too hot.
Use dry potholders = moist or damp potholders on
hot surfaces may result in burns from steam. Do
not let potholders touch hot heating elements. Do not use
a towel or other bulky cloth instead of a potholder.
= Do not heat unopened food containers =buildup of
pressure may cause container to burst and result
in injury.
IMPORTANT INSTRUCTIONS FOR USING
YOUR OVEN
• Use care when opening oven door, lower oven
door or warmer drawer (if equipped)--Sta nd to the
side of the range when opening the door of a hot oven.
Let hot air or steam escape before you remove or replace
food in the oven.
= Do not touch surface heating units or surface
ii
cooking elements, areas near these units or
elements, or interior surface of the oven. Both
surface heating and oven heating elements may behot
even though they are dark in color. Areas near surface
cooking units may become hot enough to cause burns.
ii
During and after use, do not touch, or let clothing or
ii
other flammable materials touch these areas until they
have had sufficient time to cool. Among these areas
are the cook top, surfaces facing the cook top, the
oven vent openings and surfaces near these openings,
oven door and oven door window.
ii
ii
• Wear proper apparel=loose=fitting or hanging
garments should never be worn while using the
appliance. Do not let clothing or other flammable
materials contact hot surfaces.
Do not attempt to operate the range during a
power failure. If the power fails, always turn offthe
range. If the range is not turned off and the power
resumes, the range will begin to operate again. Once the
power resumes, reset the clock and oven function.
Keep oven vent ducts unobstructed. The oven vent
is located under the left rear surface element if your
model isequipped with coil elements. The oven vent is
located below the backguard for models equipped with
ceramic-glass cook tops. Touching the surfaces in this
area when the oven is operating may cause severe
burns. Also, do not place plastic or heat-sensitive items
on or near the oven vent. These items could melt or
ignite.
Placement of interior oven racks. Always place oven
racks in desired location while oven is cool. If rack must
be moved while oven is hot use extreme caution. Use
potholders and grasp the rack with both hands to
reposition. Do not let potholders contact the hot heating
elements in the oven. Remove all utensils from the rack
before moving.
Do not use the broiler pan without its insert. The
broiler pan and its insert allow dripping fat to drain and
be kept away from the high heat of the broiler. Do not
cover the broiler insert with aluminum foil. Exposed
fat and grease could ignite.
Protective liners--Do not use aluminum foil to line the
oven bottom. Only use aluminum foil as recommended in
this manual. Improper installation of these liners may
result in risk of electric shock, or fire.
IMPORTANT INSTRUCTIONS FOR USING
YOUR COOKTOP
• Know which knobcontrols each surface heating
unit.Placea pan of food on the unit beforeturning it on,
and turn the unit off beforeremovingthe pan.
FOR CERAMIC=GLASS COOK TOP MODELS
• Do not cook on broken cook top--lfcooktopshould
break, cleaning solutions and spillovers may penetrate
the broken cook top and create a risk of electric shock.
Contact aqualified technician immediately.
• Use proper pan size--This appliance isequipped with
one or more surface units of different sizes. Select
utensils having flat bottoms large enough to cover the
surface unit heating element. The use of undersized
utensils will expose a portion of the heating element to
direct contact and may result in ignition of clothing.
Proper relationship of utensil to element will also improve
efficiency.
= Utensil handles should be turned inward and not
extend over adjacent surfaceelements--To reduce
the risk of burns, ignition of flammable materials, and
spillage due to unintentional contact with the utensil, the
handle of the utensil should be positioned so that it is
turned inward, and does not extend over adjacent
surface units.
• Never leave surface elements unattended at high
heat settings--Boilovers causesmoking and greasy
spillovers that may ignite, or a pan that has boiled dry
may melt.
• Do not immerse or soak removable heating
elementsmHeating elements should never be immersed
in water. Heating elements clean themselves during
normal operation.
• Glazed cooking utensils--Only certain types of glass,
glass/ceramic, ceramic, earthenware, or other glazed
utensils are suitable for cook top service without breaking
due to the sudden change in temperature. Check the
manufacturer's recommendations for cook top use.
Clean cook top with caution--lfa wet sponge orcloth
isusedtowipe spillson a hotcookingarea,be carefulto
avoida steam burn.Some cleanerscan producenoxious
fumes ifappliedtoa hotsurface.
IivIPORTANTINSTRUCTIONS FOR CLEANING
YOUR RANGE
• Clean the range regularly to keep all parts free of
grease that could catch fire. Pay particular attention
to the area around each surface element. Do not allow
grease to accumulate.
Kitchen cleaners and aerosolsmAIways follow the
manufacturer's recommended directions for use.
Be aware that excess residue from cleaners and aerosols
may ignite causing damage and injury.
= Clean ventilating hoods frequently=Grease should
not be allowed to accumulate on the hood or filter.
Follow the manufacturer's instructions for cleaning hoods.
IHPORTANT SAFETY NOTICE
The California Safe Drinking Water and Toxic Enforcement
Act requires the Governor of California to publish a list of
substances known to the state to cause cancer, birth
defects or other reproductive harm, and requires
businesses to warn customers of potential exposure to such
substances.
= When flaming foods under a ventilating hood, turn
the fan on.
Oven vent location
The oven vent is located under the left side of the
control panel (See Fig. 1). When the oven is on, warm
air passes through this vent. This venting is necessary for
proper air circulation in the oven and good baking results.
Do not block the oven vent.
oven vent location
_ Fig. 1
Types of oven racks
Your range may be equipped with one or more of the oven
rack styles shown.
___ flat handle
Removing, replacing & arranging racks
To remove - pull the rack forward until it stops. Lift up
front of rack and slide out.
To replace - fit the rack onto the guides on the oven walls.
Tilt the front of the rack upward and slide the rack back into
place.
Arranging - always arrange the oven racks when the oven
is cool (prior to operating the oven).
Always use oven mitts when using the oven. When
using the appliance, oven racks and cooktop will become
very hot which can cause burns.
rack
l_n rack "___
_va_nrack
oven rack
The flat oven rack or flat handle oven rack (some
models) may be used for most cooking needs.
The offset oven rack (some models) is designed to place
the base of the rack about 1/2 of a rack position lower than
normal. This rack design provides several additional
possible locations between the standard positions.
Fig. 2
Recommended rack positions by food type
Food type Position
Broiling meats See broil
Cookies, cakes, pies, biscuits & muffins 2 or 3
Frozen pies, angel food cake, yeast, bread
and casseroles 1 or 2
Small cuts of meat or poultry 1 or 2
Turkey, roast or ham 1
Air circulation in the oven
For best baking results allow 2-4" (5-10 cm) around the
cookware for proper air circulation and be sure pans and
cookware do not touch each other, the oven door, sides or
back of the oven cavity. Hot air must beable to circulate
around the pans and cookware inthe oven for even heat to
reach around the food.
About the ceramic glass cooktop
The ceramic cooktop has radiant surface elements located
below the surface of the glass. The design of the ceramic
cooktop outlines the area of the surface element
underneath. Be sure to match the pan size with the
diameter of the element outline on the cooktop and only
flat-bottomed cookware should be used.
The type and size of cookware, the number of surface
elements in use and their settings are all factors that will
affect the amount of heat that will spread to areas beyond
the surface elements. The areas surrounding the elements
may become hot enough to cause burns,
element ON indicator light
OFF
LO
4
reed
Fig. 1
6
o
4
e
2
About the radiant surface elements
The element temperature rises gradually and evenly. As the
temperature rises, the element will glow red. To maintain
the selected setting the element will cycle ON and OFF. The
heating element retains enough heat to provide a uniform
and consistent heat during the off cycle.
Forefficient cooking, turn OFFthe element several minutes
before cooking is complete. This will allow residual heat to
complete the cooking process.
Element on & hot surface indicator lights
Your appliance isequipped with two different types of
radiant surface control indicator lights that will glow on the
control panel i the on indicator and the hot surface
indicator lights.
The element on indicator light will glow when any surface
element is turned ON. A quick glance at this indicator light
after cooking is an easy check to be sure the surface
controls are turned OFF (See Fig. 1).
The hot surface indicator light will glow when any surface
cooking area heats up and will remain on until the glass
cooktop has cooled to a MODERATE level (See Fig. 2).
hot surface indicator light
I
hot @ surface
OFF OFF
i 8
6 4 6
reed reed
Fig. 2
Radiant elements have a limiter that allows the element
to cycle ON and OFF, even at the HI setting. This helps
to prevent damage to the ceramic smoothtop. Cycling at
the HI setting is normal and will occur more often if the
cookware is too small for the radiant element or if the
cookware bottom is not flat.
Be sure to read the detailed instructions for ceramic
glass cooktop cleaning in the Care &Cleaning and
Before You Call checklist sections of this Use & Care
Manual.
7
Types of cooktop elements
The ceramic glass cooktop has radiant surface elements
located below the surface of the glass. The patterns on the
ceramic glass will outline the size and type of element
available. The single radiant element will have one round
outline pattern shown. The dual radiant element isflexible
because you may set just the smaller inner portion as a
single element or both inner and outer portions can be set
to heat together (See Fig. 1).
Using proper cookware
The size and type of cookware used will influence the
setting needed for best cooking results. Besure to follow
the recommendations for using proper cookware as
illustrated in Figs. 2 & 3.
Cookware should have flat bottoms that make good contact
with the entire surface heating element (See Fig. 2). Check
for flatness by rotating a ruler across the bottom of the
cookware (See Fig. 3). For more information about the
ceramic cooktop see"Cooktop cleaning & maintenance" in
the Care &Cleaning section.
Single radiant
surface control
Fig. 1
Dual radiant
surface control
(some models)
Cookware material types
The cookware material determines how evenly and quickly
heat is transferred from the surface element to the pan
bottom. The most popular materials available are:
Aluminum - Excellent heat conductor. Some types of food
will cause it to darken (Anodized aluminum cookware
resists staining & pitting). If aluminum pans slide across the
ceramic cooktop, they may leave metal marks which will
resemble scratches. Remove these marks immediately.
Copper - Excellent heat conductor but discolors easily. May
leave metal marks on ceramic glass (see Aluminum).
Stainless =Slow heat conductor with uneven cooking
results. Is durable, easy to clean and resists staining.
Cast Iron - A slow heat conductor however will retain heat
very well. Cooks evenly once cooking temperature is
reached. Not recommended for use on ceramic cooktops.
t t"
" Curved and warped pan.
e Flat bottom and straight
sides.
® Tight fitting lids.
• Weight of handle does
not tilt pan. Pan is well
®Pan larger than cooking area
marked on cooktop by more
than one-half inch or 12mm.
balanced.
• Pan sizes match the
amount of food to be
prepared and the size of ® Heavy handle tilts pan.
the surface element. _........._ .......
e Made of a material that
conducts heat well.
• Easy to clean. • Pan is smaller or larger
o Always match pot than heating area marked
diameter to element size. on cooktop.
Porcelain=enamel on metal =Heating characteristics will
vary depending on base material. Porcelain-enamel coating
must be smooth to avoid scratching ceramic cooktops.
Glass - Slow heat conductor. Not recommended for
ceramic cooktop surfaces because it may scratch the glass.
Fig. 3
Single radiant surface elements (all models)
To operate the single radiant element:
1. Place correctly sized cookware on single radiant surface
element.
2. Push in and turn the surface control knob in either
direction (Fig. 2) to the desired setting (Refer to the
Suggested radiant surface element settings
table Fig. 1). Start most cooking operations on a
higher setting and then turn to a lower setting to finish
cooking. The surface control knobs do not have to be
set exactly on a particular spot. Usethe graphics
provided as a guide and adjust the control knob as
needed (See Fig. 2). Each surface element provides a
constant amount of heat at each setting. Aglowing red
surface heating area extending beyond the bottom edge
of the cookware indicates the cookware istoo small
for the surface heating area.
3. When cooking is complete, turn the radiant surface
element OFF before removing the cookware.
Suggested radiant surface element
settings
The suggested settings found in Fig.1 below are based
when cooking with medium-weight aluminum pans with
lids. Settings may vary when using other types of pans.
Suggested settings for single and dual radiant
elements table
[0
hi
£
8
3
4
reed
Fig. 2
Radiant surface elements may appear to have cooled
after they have been turned off. The glass surface may
still be hot and burns may occur if the glass surface is
touched before it has cooled sufficiently.
Do not place flammable items such as plastic salt and
pepper shakers, spoon holders or plastic wrappings on
top of the range when it is in use. These items could melt
or ignite. Potholders, towels or wooden spoons could
catch fire if placed too close to the surface elements.
7
J
6
Settings Type of cooking
High (HI - 9) Start most foods, bring water to a
boil, pan broiling
Medium high (7 - 8) Continuea rapid boil, fry, deep fat fry
Medium (5-6) Maintain a slow boil, thicken sauces
and gravies or
steam vegeta bles
Medium Low (2 - 4) Keep foods cooking, poach, stew
Low (LO - 1) Keep warm, melt, simmer
Fig. 1
Do not allowaluminum foil, orANY material that can
melt to ma ke contact with the ceramic glass cooktop,
If these items melt on the cooktop they will damage the
ceramiccooktop.
The size and type of utensil used, and the amount and
type of food being cooked will influence the setting
needed for best cooking results.
The on indicator light will glow when one or more
elements are turned ON. A quick glance at this indicator
light when cooking is finished is an easy check to be sure
all control knobs are turned OFF. The hot surface
indicator light will continue to glow AFTERthe control
knob isturned to the "OFF" position and will glow until
the heating surface area has cooled sufficiently.
Dual radiant surface elements (some models)
Symbols on the backguard are used to indicate which coil of
the dual radiant element will heat. The o symbol indicates
the inner coil only. The @symbol indicates both inner and
outer coils will heat.
To operate a dual radiant element:
1. Place correctly sized cookware on dual radiant surface
element.
2. Push inand turn the surface control knob clockwise to
begin heating both the inner and outer portions of the
dual element. If only the inner heating portion is
needed like for smaller cookware, push in and turn the
knob counter-clockwise to start.
3. When cooking iscomplete, turn the dual radiant surface
element OFF before removing the cookware.
Start most cooking operations on a higher setting and then
turn to a lower setting to finish cooking. The surface control
knobs do not have to be set exactly on a particular mark.
Use the marks as a guide and adjust the control knob as
needed. A glowing red surface heating area extending
beyond the bottom edge of the cookwa re indicates the
cookware is too small for the surface heating area.
o OFF
® o
to [o
Heating with inner (small)
element only
o OFF @
6 ,
• o
to Lo
Heating with both
elements
You may switch from either coil setting at any time during
cooking. See Suggested radiant surface element
settings table on previous page.
Radiant surface elements may appear to have cooled
after they have been turned off. The glass surface may
still be hot and burns may occur if the glass surface is
touched before it has cooled sufficiently.
Do not place flammable items such as plastic salt and
pepper shakers, spoon holders or plastic wrappings on
top of the range when it is in use. These items could melt
or ignite. Potholders, towels or wooden spoons could
catch fire if placed too close to the surface elements.
Do not allowaluminum foil, orANY material that can
melt to ma ke contact with the ceramic glass cooktop,
If these items melt on the cooktop they will damage the
ceramiccooktop.
Areas that heat are shown
darkened.
Fig. 1
Fig. 2
The size and type of utensil used, and the amount and
type of food being cooked will influence the setting
needed for best cooking results.
The on indicator light will glow when one or more
elements are turned ON. A quick glance at this indicator
light when cooking is finished is an easy check to be sure
all control knobs are turned OFF. The hot surface
indicator light will continue to glow AFTERthe control
knob is turned to the "OFF" position and will glow until
the heating surface area has cooled sufficiently.
Home Canning
Be sure to read and observe all the following points when
home canning with your appliance. Check with the USDA
(United States Department of Agriculture) website and be
sure to read all the information they have available as well
as follow their recommendations for home canning
procedures.
• Use only quality flat bottom canners when home canning.
Use a straight-edge to check canner bottom (see
"Cookware material types" in the Before setting
surface controls section).
• Use only a completely flat bottom canner with no
ridges that radiate from the bottom center when home
canningusing a ceramic cooktop.
= Hake sure the diameter of the canner does not
exceed I inch beyond the surface element
markings or burner, It is recommended to use smaller
diameter canners on electric coil and ceramic glass
cooktops.
• Start with hot tap water to bring water to boil more
quickly.
Radiant surface elements may appear to have cooled
after they have been turned off. The glass surface may
still be hot and burns may occur if the glass surface is
touched before it has cooledsufficiently.
Do not place flammable items such as plastic salt and
pepper shakers, spoon holders or plastic wrappings on
top of the range when it is in use. These items couldmelt
or ignite. Potholders, towels or wooden spoons could
catch fire if placed too closeto the surface elements.
Do not allowaluminum foil, orANY material that can
melt to ma ke contact with the ceramic glass cooktop,
If these items melt on the cooktop they will damage the
ceramiccooktop.
• Use the highest heat setting when first bringing the water
to a boil. Once boiling isachieved, reduce heat to lowest
possible setting to maintain that boil.
surface cooking areas at the same time. This may cause
the ceramic cooktop to fracture.
READ THE INSTRUCTIONS CAREFULLY BEFORE USING THE OVEN.
Forsatisfactory use of your oven, become familiar with the various pad features and functions of the oven as described below.
Feature indicator lights--
These indicator lights show if
bake or broil is active.
bake .......... A __
Bake pad--Use to select the
bake feature.
Broil pad-- Use to select the
variable broil feature.
Timer on-off pad-- Use to set or cancel the
minute timer, The minute timer does not start or
stop cooking.
Clock pad-- Use to
set the time of day.
Setting the dock
When the appliance isfirst plugged in or when the power
supply to the appliance has been interrupted, the display
will flash "12:00". It is recommended to always set the
clockfor the correct time of day before using the appliance.
To set the clock:
1. Press clock once (do not hold key pad down).
2. Within 5 seconds, press and hold the A or V until
the correct time of day appears in the display.
Changing the temperature display mode
(°F or°C)
The electronic oven control is set to display °F (Fahrenheit)
when shipped from the factory. The display may be
changed to show either Fahrenheit or Celsius oven
temperatures.
Up and down arrow
pads-- Use with the
feature or function
pads to set oven
temperature or
adjusting the clock and
minute timer,
Clear off pad-- Use to clear any feature
previously entered except the time of day and
minute timer. Press clear off to stop cooking.
To change the temperature display mode from °F to
°C (Celsius) or from °C to °F (Fahrenheit).
.
Press and hold broil (for 6-8 seconds) until For C
appears in the display. At this time the display will show
the current temperature display mode whether set for F
or C. Before proceeding read the notes below.
.
Press either A or V key pad to toggle between F
(Fahrenheit) or C (Celsius) mode choices.
.
To accept the change, wait until the oven control
provides the acceptance beep (See Notes below).
.
The display will return to the time of day with the
temperature display mode changed the next time the
oven is set for bake or broil.
• If at any time during the process of changing the
temperature display mode you decide not to change
the mode, press the clear off key pad once before the
acceptance beep.
• The temperature display mode cannot bechanged
when bake or broil is active.
Setting the minute timer
I. Press timeron=off.
2. Press the A to increase the time inone minute
Setting bake
The oven can be programmed to bake at any temperature
from 170°F to 550°F (77°C to 287°C). The factory preset
bake temperature is350°F (177°C).
increments. Press and hold the A to increase the
time in 10 minute increments. The timer can be set for
any amount of time from 1 minute to 11 hours and 59
minutes.
Note: If the V pad is pressed first, the timer will
advance to 11 hours and 59 minutes.
3. When the set time has run out, the timer will sound a 3
second tone. 0:00 will show in the display until timer
on=off is pressed.
To change the timer while it is in use
While the timer is active and shows in the display, press
and hold the A or V to increase or decrease the time
remaining.
To cancel the minute timer before the set time has
run out
Press timer on-off once .
To set bake
1. Press bake." "appears in the display.
2. Within 5 seconds, press the A or V •The display
will show "350°F (177°C). '' By pressing and holding
the A or V, the temperature can then be adjusted
in 5°F increments (1°C if the control is set to display
Celsius).
3. As soon as the A or V pad is released, the oven
will begin preheating to the selected temperature.
When the oven reaches the desired baking
temperature, the control will beep once.
To change the oven temperature after bake has
started
1. Press bake. Visually check the bake temperature and
that it needs to be changed.
2. Press the A or V pad to increase or decrease the
set temperature to the desired new oven temperature.
• The minute timer will not start or stop the cooking
process. It serves as an extra timer in the kitchen that
will beep when the set time has run out. The minute
timer can be used alone or while using any of the other
oven features.
• If another feature isactive when the minute timer is
active, the minute timer will show in the display. To
view information about other active features, press the
pad for that feature.
To cancel baking at any time, press clear off.
Dark or dull pans absorb more heat than shiny bakeware
resulting in dark or overbrowning of foods. It may be
necessary to reduce the oven temperature or cook time
to prevent overbrowning of some foods. Dark pans are
recommended for pies. Shiny pans are recommended
for cakes, cookies and muffins.
Setting broil
Use the broil feature to cook meats that require direct
exposure to radiant heat for optimum browning results.
When broiling always remember to arrange the oven
racks while oven is still cool.
For medium done steaks, position the oven rack closer to
the broil element (positions 4 or 5; Fig. 1). For well-done
foods such as chicken, fish, lobster or thick cuts of meat,
position the oven rack further from the broil element.
Insert
To set Broil
1. Arrange the oven rack while oven is still cool. Position
the oven rack as needed.
2. Press broil. "----" will appear indisplay.
3. Press and hold the A or V until the desired broil
setting level appears in the display. Press the A for HI
broil orthe V for LO broil. Most foods may be broiled
at the HI broil setting. Select the LO broil setting to
avoid excess browning or drying of foods that should be
cooked to the well-done stage.
4. For optimum results, preheat oven for 5 minutes
before adding food,
5. Place the insert on the broil pan (some models; Fig.2),
then place the food on the broil pan insert.
6. Place the broiler pan and insert on the oven rack.
7. Open the oven door to the broil stop position when
broiling.
8. Broil on one side until food is browned. Turn and broil
food on 2nd side.
9. When broiling is finished press clear off.
Broil pan
Fig. 1 Fig. 2
Should an oven fire occur, close the oven door and turn
the oven OFF. If the fire continues, use a fire
extinguisher. DO NOT put water or flour on the fire. Flour
may be explosive.
• The broiler pan and the insert (some models) allows
grease to drain and be kept away from the high heat of
the broiler. DO NOT use the pan without the insert. DO
NOTcover the insert with aluminum foil; the exposed
grease could ignite.
• To insure proper results when broiling use ONLY
Electrolux Home Products, Inc, approved broil pan &
insert,
Always pull the oven rack outto the stop position before
turning or removing the food.
Adjusting oven temperature
Your appliance has been factory calibrated and tested to
ensure an accurate baking temperature. For the first few
uses, follow your recipe times and temperature
recommendations carefully. If you thinkthe oven is cooking
too hot or too cool for your recipe times, you can adjust the
control so the oven cooks hotter or cooler than the
temperature displayed.
To adjust oven temperature
1. Press & hold the bake key pad and release after the
display shows the factory temperature setting of 00. If
the oven temperature has been previously adjusted
from the factory setting, the latest adjusted value will
appear in the display instead.
2. You may increase the oven temperature in 5°F
increments with each press of the A key pad. You
may also adjust the oven temperature downward in 5°F
increments with each press of the V key pad (total
adjustment range is +35°F to -35 ° F).
.
To accept the change, wait until the oven control
provides the acceptance beep (See Notes).
4.
The oven temperature adjustment has been accepted
by the oven control and the display will return to the
time of day.
Operating oven light (some models)
The interior oven light will automatically turn ON when the
oven door is opened. Press the oven light switch located on
the upper left control panel to turn the interior oven light ON
and OFF whenever the oven door is closed.
The interior oven light is located at the upper left rear wall
of the oven interior. To change the interior oven light, see
"Changing the oven light" in the Care &cleaning section.
Circuit protection (some models)
For protection against surcharge, a 15 amp, 120volt circuit
breaker reset is provided near the electric outlet located on
top of backguard panel (See Fig. 1). If needed, press circuit
brea ker switch to reset.
circuit oven
breaker electric light
switch outlet switch
\ I /
F
backguard
panel
Fig. 1
• If at any time during the process of adjusting the oven
temperature feature you decide not to make the
change, press the clear off key pad once before the
acceptance beep.
• The oven temperature adjustment feature can not be
modified if bake or broil isactive.
• The oven temperature adjustment may be made if
your oven control has been set for °C (Celsius)
temperature display mode. In this case each
press of the a or V key pad will adjust in 1°C
increments upward (maximum + 18°C) or downward
(maximum -18°C), depending on which arrow key pad
is pressed.
• DO NOT USE oven thermometers such as those found
in grocery stores to check the temperature settings
inside your oven. These oven thermometers may vary
as much as 20 to 4-0degrees from actual
temperatures.
Cleaning recommendation table
Surface type Recommendation
Control knobs
- Painted bodyparts
- Painted decorativetrim
- Aluminum, plasticorvinyltrim
pieces
Control panel Before cleaning the controlpanel, turn all controls OFFand if needed remove any
- Decorative trim (some models) knobs from the panel. Clean using hot, soapy water and a dishcloth. Be sure to
- Stainless Steel (some models) Clean heavier soils with hot, soapy water and a dishcloth. Rinse with clean water and
- Oven interior & door liner Gentle scouring with a soapy non-abrasive scouring pad will remove most spots.
- Porcelainenamelbroilerpanand Rinse with a 1:1 solution of clear water and ammonia. Zfnecessary, cover difficult
broiler pan insert (some models) spots with an ammonia-soaked paper towel for 30 to 40 minutes. Rinse with clean
For general cleaning, use hot, soapy water and a cloth. For more difficult soils and
built=upgrease, apply a liquid detergent directly onto the soil. Leave on soil for 30 to
60 minutes. Rinse with a damp cloth and dry. Do not use abrasive cleaners on any
of these materials; they can scratch. To remove control knobs, turn to the OFF
position; grasp firmly and pull straight offthe shaft. To replace knobs after cleaning,
line up the flat sides of both the knob and the shaft; then push the knob into place.
squeeze excess water from the dishcloth before wiping the control panel;
especially when wiping around the controls area. Excess water inor around the
controls may cause damage to the appliance. When rinsing, use clean water and a
dishcloth and be sure to squeeze excess water from dishcloth before wiping the
control panel.
a cloth. Do not use cleaners with high concentrations of chlorides or
chlorine. Do not use harsh scrubbing cleaners. Only use kitchen cleaners that are
especially made for cleaning stainless steel. Always be sure to wipe the cleaners off
from the surface as bluish stains may occur during heating that cannot be removed.
water and a damp cloth, and then scrub with a soap-filled non-abrasive scouring pad.
Rinse and wipe dry with a clean cloth. Do not allow food spills with a high sugar or
acid content (milk, tomatoes, sauerkraut, fruit juices or pie filling) to remain on the
surface; they may cause a dull spot even after cleaning.
The oven interior is porcelain coated and is safe to clean using oven cleaners
following manufacturer's instructions. After cleaning, remove any oven cleaner or the
porcelain may become damaged during future heating. Do not spray oven cleaner on
any electrical controls or switches. Do not spray or allow oven cleaner to build up on
the oven temperature sensing bulb. Do not spray cleaner on oven door trim, door
gasket, plastic drawer glides, handles or any exterior surfaces of the range.
Clean any soils from the oven frame, the door liner outside the oven door gasket and
the small area at the front center of the oven bottom. Clean with hot, soapy water.
Rinse using clean water and a cloth.
Oven racks Remove oven racks from oven before cleaning. Clean by using a mild, abrasive
cleaner following manufacturer's instructions. Rinse with clean water and dry.
Oven door Use soap & water to thoroughly clean the top, sides and front of the oven door. Rinse
well. You may use a glass cleaner on the outside glass of the oven door. Do not
immerse the door in water. Do not spray or allow water or the glass cleaner
to enter the door vents. Do not use oven cleaners, cleaning powders or any
harsh abrasive cleaning materials on the outside of the oven door.
Ceramiccooktop Do not use spray oven cleaners on the cooktop. See cooktop cleaning and
maintenance in the Care &Cleaning section.
Cooktop maintenance
Cooktop cleaning
Consistent and proper cleaning is essential to
maintaining your ceramicglasscooktop,
Prior to using your cooktop for the first time, apply some of
the glass-ceramic cooktop cleaner supplied with your new
applia nce. Buff with a non-abrasive cloth or no-scratch
cleaning pad. This will make cleaning easier when soiled
from cooking. The special cooktop cleaning cream leaves a
protective finish on the glass to help prevent scratches and
abrasions.
Sliding aluminum or copper clad bottom pans on the
cooktop can cause metal markings on the cooktop surface.
These marks should be removed immediately after the
cooktop has cooled using the cooktop cleaning cream. Metal
marks can become permanent if not removed prior to
future use.
Cookware (cast iron, metal, ceramic or glass) with rough or
dirty bottoms can mark or scratch the cooktop surface.
DO not:
- Slide anything metal or glass across the cooktop.
o Use cookware with dirt or dirt build up on bottom;
replace with clean cookware before using.
Before cleaning the cooktop, be sure the controls are
turned to OFF and the cooktop is COOL.
For light to moderate soil:
Apply a few drops of glass=ceramic cooktop cleaner directly
to the cooktop. Use a paper towel or use a non-abrasive
plastic type no-scratch cleaning pad to clean the entire
cooktop surface. Hake sure the cooktop is cleaned
thoroughly, leaving no residue.
For heavy, burned on soil:
Apply a few drops of glass=ceramic cooktop cleaner directly
to the soiled area. Rub the soiled area using a non=abrasive
plastic type no-scratch cleaning pad, applying pressure as
needed. Do not use the pad you use to clean the cooktop
for any other purpose.
If soils remain, carefully scrape soils with a metal razor
blade scraper, holding scraper at a 30 degree angle to the
surface. Remove loosened soils with cooktop cleaning
cream and buff surface clean.
Use your cooktop as a cutting board or work surface in
the kitchen.
Cook foods directly on the cooktop surface without a pan.
Drop heavy or hard objects on the ceramic glass cooktop,
they may cause it to crack.
./ j
Cooktop cleaning (cont'd)
Plastic or foods with a high sugar content:
These types of soils need be removed immediately if spilled
or melted onto the ceramic cooktop surface. Permanent
damage (such as pitting of the cooktop surface) may occur
if not removed immediately,
After turning the surface elements OFF, use a razor blade
scraper or a metal spatula with a mitt and scrape the soil
from the hot surface (as illustrated). Allow the cooktop to
cool, and use the same method for heavy or burned on
soils.
Damage to the ceramic glass cooktop may occur if you
use an abrasive type cleaning pad. Only use cleaning
products that have been specifically designed for ceramic
glass cooktops.
Caution for aluminum use on the cooktop
• Aluminum Foil =Use of aluminum foil on a hot cooktop
will damage the ceramic cooktop. Do not use thin
aluminum cooking utensils or allow aluminum foil to
touch the ceramic cooktop under ANY circumstances.
DO NOT use a cooktop cleaner on a hot cooktop.
The fumes can be hazardous to your health and
can chemically damage the ceramic glass surface.
Do not use the following on the cooktop:
o Do not use abrasive cleaners and scouring pads, such as
metal and some nylon pads. They may scratch the
cooktop, making it more difficult to clean.
Do not use harsh cleaners, such as chlorine bleach,
ammonia or oven cleaners, as they may etch or discolor
the cooktop.
- Do not use dirty sponges, cloths or paper towels, as they
can leave soil or lint on the cooktop which can burn and
cause discoloration.
Aluminum utensils =The melting point of aluminum
is much lower than that of other metals. Care must be
taken when aluminum pots or pans are used on the
cooktop. If aluminum pans are allowed to boil dry
when using the cooktop, not only will the utensil be
damaged or destroyed, but it may fuse to, break or
mark the ceramic glass surface, permanently
damaging the cooktop surface.
Replacing oven light
Besure the range isunplugged and all parts are COOLbefore
replacing oven light. Weara leather-faced glove for protection
against possible broken glass.
The interior oven light bulb is located at the upper left rear of
the oven cavity.
To replace the oven light bulb
1. Turn electrical power off at the main source or unplug
the range.
2. Replace bulb with a new 40 watt appliance bulb.
3. Turn power back on again at the main source (or plug
the appliance back in).
4. The clock will then need to be reset. To reset, see
"Setting the clock" in this Use& Care Guide.
:J
Removing and replacing the Eft-off oven door
ii
The oven door isheavy. For safe, temporary storage, lay the
oven door flat with the inside of the door facing down.
To remove oven door
1. Open oven door completely (horizontal with floor-Fig. 1).
2. Remove 2 screws located on the inside of the oven door
liner (See A Fig, 2).
3. Insert the 2 screws into the door hinge holes located on
the side of the hinge arm, one into each hinge (See B
Fig. 2).
4. Close oven door until the door stops, (do not force the
door to close any further). The placement of these
screws should keep door open in about a 45 degree
position.
5. Grasp oven door firmly on both sides and slide door up
and off hinges at the same angle (See Fig, 3).
6. To clean oven door, follow the instructions provided
listed in the cleaning chart under "oven door".
To replace oven door
1. Be sure the hinge arms remain at the 45 degree angle
position. Be sure the screws are still locking the hinge
arms from moving. If the screws fall out of the hinge
holes, the hinge(s) may snap back against the oven frame
and could pinch fingers or chip the porcelain finish on the
oven front frame.
2. Hold door at the sides near the top while resting the
lower front of door on your knee. Insert the door
channels at the bottom of door over the door hinges,
(See Fig. 3).
3. Allow the door to slide down into the door hinges evenly
at the same 45 degree angle. The hinge arms should be
inserted into the bottom corners as far as they can go.
4. Open door completely (horizontal with floor) and remove
both screws from holes in door hinges.
5. Reinstall the 2 screws into the door liner (See C Fig. 2).
6. If the door is not in alignment with the oven frame,
remove door and repeat the above steps.
Oven door hinge
locations
with oven door
fully open.
Fig. 1
Fig. 2
about 45
eg _e._
Oven Door
Hinge
Fig. 3
Cleaning under lower element (some models)
Special door care instructions - Most oven doors
contain glass that can break, Read the following
recommendations:
• Do not close the oven door until all the oven racks are fully
in place.
• Do not hit the glass with pots, pans, or any other object.
• Scratching, hitting, jarring or stressing the glass may
weaken its structure causing an increased risk of breakage
at a later time.
The oven bake and broil elements may appear to have
cooled after they have been turned OFF. The elements
may still be hot and burns may occur if these elements
are touched before they have cooled sufficiently.
For models that have a visible lower bake element
ONLY - This bake element was designed to be tilted up
using your hand from the front of the bake element for
cleaning purposes. Remove the bottom oven rack before
raising the element. Do not to raise the element more than
4 or 5inches from the resting position.
SolutionProblem
Poor baking results, Many factors affect baking results. Make sure the proper oven rack position
is used. Center food in the oven and space pans to allow air to circulate.
Allow the oven to preheat to the set temperature before placing food in the
oven. Try adjusting the recipe's recommended temperature or baking time.
If you fee! the oven istoo hot or cool, see Adjusting oven temperature
section in this Use & Care Guide.
Appliance is not level. * Be sure floor is level, strong & stable enough to adequately support range.
If floor is sagging or sloping, contact acarpenter to correct the situation.
Poor installation. Place oven rack in center of oven. Place a level on the
oven rack. Adjust leveling legs at base of appliance until the rack is level.
Kitchen cabinet alignment may make range appear not level. Be sure
cabinets are square & have sufficient room for appliance clearance.
Cannot moveapplianceeasily. Appliance - Cabinets not square or are built in too tightly. Contact builder or installer to
must be accessible for service, make appliance accessible.
Carpet interferes with appliance. Provide sufficient space so appliance can be
lifted over carpet.
Surface element too hot or not hot _ Incorrect control setting. Besure the correct control isONfor the element that
enough, you are attempting to use.
Surface element does not heat. - Lightweight or warped pans used. Use only flat, evenly balanced, medium
or heavyweight cookware. Flat pans heat better than warped pans.
Cookware materials and weight of the material affect heating. Heavy &
medium-weight pans heat evenly. Because lightweight pans heat unevenly,
foods may burn easily.
Entire appliance does not operate. The time of day is not set, The time of day must first be set in order to
operate the oven. See Setting the clock inthe Setting Oven Controls
section.
Make sure cord/plug is plugged correctly into outlet.
Service wiring is not complete. Contact your dealer, installing agent or
authorized service agent.
Electrical power outage. Check house lights to be sure. Call your local
electric company for service.
Oven portion of appliance does not * Be sure the oven controls are set properly for the desired cooking feature.
operate. See Setting Oven Controls in this manual or read the instructions "Entire
appliance does not operate" in this checklist.
Oven light does not work. _ Be sure the light issecure in the socket. Also see Changing & replacing the
oven light section.
.......... , _ _ _ _ _
Problem Solution
Oven smokes excessively during broiling.
o Incorrect setting. Follow broil instructions in Setting Oven Controls.
Make sure oven door isopened to broil stop position,
Meat too close to the broil element. Reposition the oven rack to provide
proper clearance between the meat & the element. Preheat the broil
element for searing.
Meat not properly prepared. Remove excess fat from meat. Cut remaining
fatty edges to prevent curling, but do not cut into lean.
Broiler pan and insert wrong side up and grease not draining. Always
place insert on the broiler pan with ribs up & slots down to allow grease
to drip into pan (some models).
- Grease has built up on oven surfaces. Regular cleaning is necessary when
broiling frequently. Old grease or food spatters cause excessive smoking.
Flames inside oven or smoking from o Excessive spillovers in oven. For example this will happen for pie
oven vent. spillovers or large amounts of grease left on the oven bottom. Wipe up
excessive spillovers before starting oven. If flames or excessive smoke
are present see Setting broil inthe Setting Oven Controls section.
Oven control panel Beeps & diSPlaYSany ; oven control has detected afauit oi erroi condition: Piess ciear off to ....
F code error, clear the display & stop beeping. Try the bake or broil feature again. If the
Fcode error repeats, remove power from appliance, wait 5 minutes and
then repower appliance and set clock for the time of day. Try the bake or
broil feature again. If the fault recurs, record fault and call for service.
Scratches or abrasions on cooktop _ Coarse particles such as salt or sand between cooktop and utensils can
surface, cause scratches. Be sure cooktop surface and bottoms of utensils are
clean before usage. Small scratches do not affect cooking and will
become less visible with time.
Cleaning materials not recommended for ceramic-glass cooktop have been
used. See Cooktop cleaning and maintenance inthe Care &Cleaning
section of this Use & Care Guide.
• Cookware with rough bottom has been used. Use smooth, fiat-bottomed
cookwa re.
Metal marks on the cooktop. - Sliding or scraping of metal utensils on cooktop surface. Do not slide
metal utensils on cooktop surface. Use a ceramic-glass cooktop cleaner to
remove the marks. See"Cooktop cleaning and maintenance" in the Care
&Cleaning section.
surface, SeeCooktop Cleaning and Maintenance inthe Care &Cleaning section,
Areas of discoloration with metallic sheen o Mineral deposits from water and food. Remove using aceramic-glass cooktop
on cooktopsurface, cleaner. Use cookware with clean, dry bottoms.
Yourapplianceiscoveredbyaoneyearlimitedwarranty.Foroneyearfromyouroriginaldateof
purchase,Electroluxwill payallcostsfor repairingorreplacinganypartsofthisappliancethatprove
to bedefectiveinmaterialsorworkmanshipwhensuchapplianceis installed,usedandmaintainedin
accordancewiththeprovidedinstructions.
Exclusions
This warranty does not cover the following:
1. Products with original serial numbers that have been removed, altered or cannotbe readily determined.
2. Product that has beentransferred from its original owner to another party or removed outside the USAor
Canada.
3. Rust on the interior or exterior of the unit.
4. Products purchased"as-is" are not covered by this warranty.
5. Food loss due to any refrigerator or freezer failures.
6. Products usedin a commercialsetting.
7. Servicecallswhich do not involve malfunction or defects in materials or workmanship, or for appliances
not in ordinary household use or used other than in accordance with the provided instructions.
8. Servicecallsto correct the installation of your appliance or to instruct you how to use your appliance.
9. Expensesfor making the appliance accessible for servicing, such as removal of trim, cupboards, shelves,
etc., which are not a part of the appliance when it is shipped from the factory.
10. Servicecallsto repair or replace appliance light bulbs, air filters, water filters, other consumables, or knobs,
handles, or other cosmetic parts.
11. Surcharges including, but not limited to, any after hour,weekend, or holiday service calls, tolls, ferry trip
charges, or mileage expense for service callsto remote areas, including the state of Alaska.
12. Damagesto the finish of appliance or home incurred during installation, including but not limited to floors,
cabinets, walls, etc.
13. Damages caused by: services performed by unauthorized service companies, use of parts other than
genuine Electrolux parts or parts obtained from persons other than authorized service companies, or
external causes such asabuse, misuse, inadequate power supply, accidents, fires, or acts of God.
DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES
CUSTOMER'S SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE PRODUCT
REPAIR OR REPLACEMENT AS PROVIDED HEREIN, CLAIMS BASED ON IMPLIED WARRANTIES, INCLUDING
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR
OR THE SHORTEST PERIOD ALLOWED BY LAW, BUT NOT LESS THAN ONE YEAR, ELECTROLUX SHALL NOT
BE LIABLE FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH AS PROPERTY DAMAGE AND INCIDENTAL
EXPENSES RESULTING FROM ANY BREACH OF THIS WRITTEN LIMITED WARRANTY OR ANY IMPLIED
WARRANTY, SOME STATES AND PROVINCES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL
OR CONSEQUENTIAL DAMAGES, OR LIMITATIONS ON THE DURATION OF IMPLIED WARRANTIES, SO THESE
LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU, THIS WRITTEN WARRANTY GIVES YOU SPECIFIC
LEGAL RIGHTS, YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE,
If You Need
Service
Keep your receipt, delivery slip, or some other appropriate payment record to establish the warranty period
should service be required. If service is performed, it is in your best interest to obtain and keep all receipts.
Service under this warranty must be obtained by contacting Electrolux at the addresses or phone
numbers below.
This warranty only applies in the USA and Canada. In the USA,your appliance is warranted by Electrolux Major Appliances
North America, a division of Electrolux Home Products, Inc. In Canada, your appliance is warranted by Electrolux Canada Corp.
Electrolux authorizes no person to change or add to any obligations under this warranty. Obligations for service and parts under
this warranty must be performed by Electrolux or an authorized service company. Product features or specifications as described
or illustrated are subject to change without notice.
USA
1.800,944.9044
Electrolux Major Appliances
North America
P.O. Box 212378
Augusta, GA 30907
Electrolux
Mississauga, Ontario, Canada
:[.800.265.8352
Electrolux Canada Corp.
5855 Terry Fox Way
Canada
L5V 3E4
Loading...
