Frigidaire 241666500 User Manual

Use & Care Manual

Beverage Center II

Welcome 2 Safety Instructions 3 Installation 4-5 Door Reversal 6 Features At A Glance 7 Temperature Controls 7 First Steps 8-12 Helpful Hints 13 Beverage Center Extra Features Optional Ice Service 14 Energy Saving Tips 15 Vacation and Moving Tips 15

.....................................

.....................

..................................

.............................

.................

..................................

...............................

......................................

...................

.....................

..........

READ AND SAVE THESE INSTRUCTIONS

Normal Operating Sounds 16 Care & Cleaning 17-18 Warranty Information 19 Troubleshooting 20-21 BeforeYou Call 22

..........................

..................

.........................

...........................

..........

P/N 241666500 (0905)

WELCOME & CONGRATULATIONS

Serial Plate

Congratulations on your purchase of a new beverage center! We here at Electrolux Home Products, Inc. are very proud of our product and we are completely committed to providing you with the best service possible. Your satisfaction is our #1 priority.

Please read this Use & Care Manual very carefully. It contains valuable information on how to properly maintain your new beverage center.

We know you’ll enjoy your new beverage center and Thank Yo u for choosing our product. We hope you consider us for future purchases.

PLEASE READ AND SAVE THESE INSTRUCTIONS

This Use & Care Manual provides specific operating instructions for your model. Use your beverage center only as instructed in this manual. These instructions are not meant to cover every possible condition and situation that may occur. Common sense and caution must be practiced when installing, operating and maintaining any appliance.

Please record your model and serial numbers below for future reference. This information is found on your serial plate located inside the refrigerator compartment.

NOTENOTE

NOTE

NOTENOTE

Use only soap and water to clean serial plate.

Questions?

1-800-944-9044

(United States)

1-800-265-8352

(Canada)

Extend Your Warranty Protection

With An

Extended Service Contract

CALL 1-800-944-9044

To Enjoy These Benefits:

• Total freedom from repair bills so

unexpected repairs won’t upset your budget.

• Fast, convenient toll-free service is just a

phone call away.

Model Number: Serial Number: Purchase Date:

PLEASE COMPLETE AND MAIL IN THE

PRODUCT REGISTRATION CARD

INCLUDED WITH YOUR BEVERAGE CENTER.

• Top-quality repairs by factory-trained experts.

• Quick access to genuine replacement parts

so you can rest assured your Beverage Center is repaired with the proper components.

Please attach sales receipt

here for future reference.

IMPORTANT SAFETY INSTRUCTIONS

WARNING WARNING

WARNING

WARNING WARNING

Please Read All Instructions Before Using This beverage center.

FOR YOUR SAFETY

• Do not store or use gasoline, or other flammable liquids in the vicinity of this or any other appliance. Read product labels for warnings regarding flammability and other hazards.

• Do not operate the beverage center in the presense of explosive fumes.

• Avoid contact with any moving parts of the automatic ice maker. (some models)

CHILD SAFETY

Destroy or recycle the carton, plastic bags, and any exterior wrapping material immediately after this beverage center is unpacked. Children should NEVER use these items to play with. Cartons covered with rugs, bedspreads, plastic sheets or stretch wrap may become airtight chambers, and can quickly cause suffocation.

WARNING WARNING

WARNING

WARNING WARNING

These guidelines must be followed to ensure that safety mechanisms in this beverage center will operate properly.

ELECTRICAL INFORMATION

• The beverage center must be plugged into its own dedicated 115 Volt, 60 Hz., AC only electric outlet. The

power cord of the appliance is equipped with a threeprong grounding plug for your protection against electrical shock hazards. It must be plugged directly into a properly grounded three-prong receptacle. The receptacle must be installed in accordance with local codes and ordinances. Consult a qualified electrician. Do not use an extension

cord or adapter plug.

• If the power cord is damaged, it should be replaced by the manufacturer, service technician or a qualified person to prevent any risk.

• Never unplug this beverage center by pulling on the power cord. Always grip the plug firmly, and pull straight out from the receptacle to prevent damaging the power cord.

• Unplug this beverage center before cleaning and before replacing a light bulb to avoid electrical shock.

• Performance may be affected if the voltage varies by 10% or more. Operating this beverage center with insufficient power can damage the compressor. Such damage is not covered under your warranty.

• Do not plug the unit into an outlet controlled by a wall switch or pull cord to prevent this beverage center from being turned off accidentally.

• Avoid connecting this beverage center to a Ground Fault Interruptor (GFI) circuit.

PROPER DISPOSAL OF YOUR BEVERAGE CENTER Risk of child entrapment

Child entrapment and suffocation are not problems of the past. Junked or abandoned refrigerators or freezers are still dangerous – even if they will sit for “just a few days.” If you are getting rid of your old refrigerator or freezer, please follow the instructions below to help prevent accidents.

Before you throw away your old refrigerator/ freezer:

• Remove doors.

• Leave shelves in place so children may not easily climb inside.

• Have refrigerant removed by a qualified service technician.

IMPORIMPOR

IMPOR

IMPORIMPOR

Turning the Air Flow and Temperature Controls to “0” turns off the compressor and prevents your Beverage Center from cooling, but does not disconnect the power to the light bulb and other electrical components. To turn off power to your Beverage Center you must unplug the power cord from the wall outlet.

•CO2 canisters must be handled with extreme care. They

• ALWAYS connect CO2 gas canisters to a pressure

• NEVER drop or throw the CO2 canister.

• NEVER connect gas canister directly to keg.

• ALWAYS keep CO

• In case of CO2 leakage, ventilate and evacuate the area

• ALWAYS keep canister secured in an upright position.

• Check the Department of Transportation (D.O.T.) test

• Return outdated canister to your gas supplier for one

ANTANT

ANT

ANTANT

WARNING WARNING

WARNING

WARNING WARNING

CO2 CANISTER SAFE HANDLING

contain potentially hazardous high pressure compressed gas.

regulator.

canisters in a cool place (70º or less)

and away from heat.

immediately.

date on the canister neck and do not use if older than 5 years.

that is within the time limit.

INSTALLATION

This Use & Care Manual provides specific operating instructions for your model. Use this beverage center only as instructed in this Use & Care Manual. Before starting this

beverage center, follow these important first steps.

LOCATION

• Choose a place that is near a grounded electrical outlet.

Do Not use an extension cord or an adapter plug.

• If possible, place this beverage center out of direct sunlight and away from the range, dishwasher or other heat sources.

• This beverage center must be installed on a floor that is level and strong enough to support a fully loaded beverage center.

• Consider water supply availability for models equipped with an automatic ice maker.

CAUTION CAUTION

CAUTION

CAUTION CAUTION

• Do Not install the beverage center where the temperature will drop below 55°F (13°C) or rise above 110°F (43°C). The compressor will not be able to maintain proper temperatures inside the beverage center.

• DO NOT block the toe grille on the lower front of your beverage center. Sufficient air circulation is essential for the proper operation of your beverage center.

• THIS BEVERAGE CENTER IS NOT INTENDED FOR OUTDOOR USE.

LEVELING

All four corners of your beverage center must rest firmly on a solid floor. Your beverage center is equipped with adjustable leveling screws to help level your unit.

To Level Your Beverage Center:

1. Remove toe grille.

2. Use adjustable wrench to adjust leveling screws.

NOTENOTE

NOTE

NOTENOTE

Raise the front of the beverage center enough so the doors close freely when opened halfway. The beverage center should slope ¼” to ½” from front to back. Then level the beverage center from side to side.

INSTALLATION Installation Clearances

• Allow the following clearances for ease of installation, proper air circulation, and plumbing and electrical connections:

Sides & Top 3/8” Back 1”

DOOR OPENING

NOTENOTE

NOTE

NOTENOTE

If your beverage center is placed with the door hinge side against a wall, you may have to allow additional space so the door can be opened wider.

Your beverage center should be positioned to allow easy access to a counter when removing food. To make this possible, the direction in which the doors open can be reversed. See

Door Removal & Reversal Instructions

Raise

Stationary Front Roller

with Leveling Screw

CACA

UTIONUTION

UTION

CACA

UTIONUTION

DO NOT ATTEMPT TO MOVE OR RELOCATE THE BEVERAGE CENTER WITH A KEG INSIDE.

INSTALLATION - CONNECTING ICE MAKER TO WATER SUPPLY

WARNING WARNING

WARNING

WARNING WARNING

To avoid electric shock, which can cause death or severe personal injury, disconnect the beverage center from electrical power before connecting a water supply line to the beverage center.

CAUTION CAUTION

CAUTION

CAUTION CAUTION

To Avoid Property Damage:

• Copper tubing is recommended for the water supply line. Water supply tubing made of ¼” plastic is not recommended since it greatly increases the potential for water leaks. Manufacturer will not be responsible for any damage if plastic tubing is used for supply line.

• DO NOT install water supply tubing in areas where temperatures fall below freezing.

• Chemicals from a malfunctioning softener can damage the ice maker. If the ice maker is connected to soft water, ensure that the softener is maintained and working properly.

IMPORIMPOR

IMPOR

IMPORIMPOR

ANTANT

ANT

ANTANT

To Connect Water Supply Line To Ice Maker Inlet Valve

1. Disconnect beverage center from electric power source.

2. Place end of water supply line into sink or bucket. Turn ON water supply and flush supply line until water is clear. Turn OFF water supply at shutoff valve.

3. Unscrew plastic cap from water valve inlet and discard cap.

4. Slide brass compression nut, then ferrule (sleeve) onto water supply line, as shown.

5. Push water supply line into water valve inlet as far as it will go (¼ inch). Slide ferrule (sleeve) into valve inlet and finger tighten compression nut onto valve. Tighten another half turn with a wrench; DO NOT over tighten.

6. With steel clamp and screw, secure water supply line to rear panel of beverage center as shown.

7. Coil excess water supply line (about 2½ turns) behind beverage center as shown and arrange coils so they do not vibrate or wear against any other surface.

8. Turn ON water supply at shutoff valve and tighten any connections that leak.

9. Reconnect beverage center to electrical power source.

10. To turn ice maker on, lower wire signal arm (see ice maker front cover for ON/OFF position of arm).

Ensure that your water supply line connections comply with all local plumbing codes.

Before Installing The Water Supply Line, You Will Need

• Basic Tools: adjustable wrench, flat-blade screwdriver,

and PhillipsTM screwdriver

• Access to a household cold water line with water pressure between 30 and 100 psi.

• A water supply line made of ¼ inch (6.4 mm) OD, copper tubing. To determine the length of copper tubing needed, you will need to measure the distance from the ice maker inlet valve at the back of the beverage center to your cold water pipe. Then add approximately 7 feet (2.1 meters), so the beverage center can be moved out for cleaning (as shown).

• A shutoff valve to connect the water supply line to your household water system. DO NOT use a self-piercing type shutoff valve.

• A compression nut and ferrule (sleeve) for connecting the water supply line to the ice maker inlet valve.

NOTENOTE

NOTE

NOTENOTE

Water line kit number 5303917950, available from your appliance dealer at additional cost, contains 25 feet (7.6 meters) of ¼ inch OD copper tubing, a saddle type shutoff valve (nonpiercing), (2) ¼ inch brass compression nuts, (2) ferrules/sleeves, and instructions for installing a water supply line.

IMPORIMPOR

IMPOR

IMPORIMPOR

It takes approximately 24 hours for the ice maker to begin producing ice. Air in new plumbing lines may cause ice maker to cycle two or three times before making a full tray of ice. New plumbing may cause ice to be discolored or have poor flavor. Discard ice made during the first 24 hours.

ANTANT

ANT

ANTANT

Door Stop

Hinge Hole Plug

Cabinet Hole Plugs

Shim

Hinge Pin

Washer

Center Hinge

Screws

Door Stop

Door Stop Screw

Hinge Hole Plug

Handle Hole Plugs

Screw

Top Hinge Screw

Center

Hinge

Screw

DOOR REMOVAL / REVERSAL INSTRUCTIONS

Bottom

Hinge Screw

DOOR REMOVAL AND REVERSAL INSTRUCTIONS:

NOTENOTE

NOTE

NOTENOTE

Screws

Top Hinge

The direction in which your beverage center doors open (door swing) can be reversed, from left to right or right to left, by moving the door hinges from one side to the other. Reversing the door swing should be performed by a qualified person.

IMPORIMPOR

IMPOR

IMPORIMPOR

ANTANT

ANT

ANTANT

Before you begin, turn the beverage center temperature control to “0” and remove the electrical power cord from the wall outlet. Remove any food from door shelves.

1. Remove toe grille.

2. Remove top hinge with 3/8” hex driver and lift freezer door off of center hinge pin. Set door aside.

3. Unscrew center hinge pin using adjustable wrench and save for reassembly. Ensure plastic washer stays on hinge pin.

4. Lift refrigerator door off of bottom hinge and set aside.

5. Remove center hinge and shim by removing inside screw and loosening two outside screws enough to allow hinge and shim to slide out. Tighten screws.

6. Loosen two outside screws on opposite side of refrigerator, remove inside screw and install center hinge.

7. Remove two screws on bottom hinge with 3/8” socket wrench.

8. Install bottom hinge on opposite side with the two screws removed from step 7.

9. Unscrew bottom hinge pin using adjustable wrench. Move hinge pin to other hole in hinge and tighten with adjustable wrench.

10. Move beverage center door stops to opposite side. Before starting screws, use an awl to puncture the foam.

11. Position beverage center door onto bottom hinge pin and screw center hinge pin through center hinge into top of door. Close beverage center door to help align hinge hole.

12. Tighten center hinge pin with adjustable wrench.

13. Remove cabinet and hinge hole plugs and move to opposite side.

14. Lower freezer door onto center hinge pin.

15. Close freezer door. Have an assistant lift up on opposite side of door while tightening screws to install top hinge.

16. Replace toe grille.

17. Plug in electrical power cord and turn beverage center temperature control to the “5” position. Adjust setting as necessary.

Ice Maker (Accessory)

Ice Bucket (Accessory)

FEATURES AT A GLANCE

Door Racks

Freezer Shelf

Air Flow Control

Temperature

Features may vary

Control

according to model

Shelf

Shelf Tower

Keg Support Shelf

Slide Out Baskets

TEMPERATURE CONTROLS

COOL DOWN PERIOD

To ensure safe food storage, allow the beverage center to operate with the doors closed for at least 12 hours before loading it with food and beverages.

Hose Clips

Faucet Opening

Door Racks

BEVERAGE CENTER CONTROLS

Temperature Control

This rotary control is the primary control for the refrigerated compartment temperature. If the beverage center is too warm, adjust this control in the “Colder” direction. If the beverage center is too cold, adjust this control in the “Cold” direction.

Temperature Control (some models)

Air Flow Control

This rotary control is the primary control for the freezer compartment temperature. If the freezer is too warm, adjust this control in the “Colder” direction. If the freezer is too cold, adjust this control in the “Cold” direction.

TEMPERATURE SETTING AND ADJUSTMENT

For beer storage, the recommended initial setting is 5. Under most conditions, this setting will provide for dispensed beer between 34-38° F. You may adjust as required to suit your individual taste and the beverage center operating conditions.

After a control adjustment, always allow 24 hours for the beer to stabilize at the new temperature before making

To maintain temperatures, a fan circulates air in the beverage center compartments. For good circulation, do not block cold air vents with food items.

IMPORIMPOR

IMPOR

IMPORIMPOR

Turning the beverage center temperature control to “0” turns off the compressor, but does not disconnect the power to the light bulb and other electrical components. To turn off power to your beverage center, you must unplug the power cord from the wall outlet.

additional adjustments.

NOTENOTE

NOTE

NOTENOTE

When purchasing a beer keg, always purchase a keg cold (<38°F), transport as quickly as possible, and get it installed in the cold beverage center within 2 hours. Under most conditions, these guidelines will allow serving of properly cooled beer within 24 hours. Purchasing a keg at a temperature above 38°F, and/or exposure to elevated temperatures longer than 2 hours will require additional time for the beer to be cooled to optimum serving temperature.

Air Flow Control (some models)

ANTANT

ANT

ANTANT
